钒渣常压直接酸溶浸出实验

熊雨婷; 王玲; 刘建欣; 贾蓝波; 刘淑贤; 聂轶苗

doi:10.3969/j.issn.1000-6532.2023.03.006

钒渣常压直接酸溶浸出实验

华北理工大学矿业工程学院河北省矿业开发与安全技术重点实验室，河北　唐山　063210

基金项目: 国家自然科学基金（52004091）；河北省自然科学基金（E2019209494）；唐山市科技计划项目（19130216g，19130218g）

详细信息

作者简介: 熊雨婷（1994-），女，硕士研究生，主要研究方向为矿产资源综合利用

通讯作者: 王玲（1977-），女，副教授，主要从事矿产资源综合利用及环境矿物学相关研究。

中图分类号: TD951

收稿日期: 2021-08-18

刊出日期: 2023-06-25

Investigation of Acid Leaching of Vanadium Slag under the Atmospheric Pressure

Hebei Province Key Laboratory of Mining Exploitation and Security Technology, College of Mining Engineering, North China University of Science and Technology, Tangshan, Hebei, China

More Information

Corresponding author: Wang Ling, wanglingts_@163.com

Received Date: 18 August 2021

Publish Date: 25 June 2023

摘要

摘要:
这是一篇冶金工程领域的论文。以河北承德某钢厂钒渣为研究对象，针对当前钒渣“钠化焙烧-水浸提钒”生产工艺易产生有毒有害气体且钒回收率低、多种有价金属未能综合回收利用的现状，本文在Fe-V-H₂O系热力学研究基础上，对钒渣常压下直接硫酸溶解浸出过程中磨矿细度、反应温度、酸浓度、液固比、浸出反应时间及搅拌速度等影响因素进行了实验研究。结果表明，浸出反应温度、硫酸浓度及液固比对钒浸出具有显著影响，在粒度D₉₅约16 μm，反应温度90 ℃、液固比8∶1、H₂SO₄浓度4 mol/L、浸出反应时间8 h、搅拌速度400 r/min的条件下，钒浸出率为86.33%；酸溶过程中产生的无定形SiO₂可能覆盖在未溶解完全的矿物颗粒表面而阻碍矿物的进一步酸溶反应。
- 钒渣 /
- 不焙烧 /
- 常压酸浸 /
- 钒浸出率 /
- 冶金工程
Abstract:
This is a paper in the field of metallurgical engineering. The vanadium slag of a steel plant in Chengde, Hebei Province was used as the object of study. In view of the production of toxic and harmful gases of the current process of "sodium roasting-vanadium extractionby water leaching" of vanadium slag, low recovery of vanadium and the failure of comprehensive utilization of valuable metals. Based on the thermodynamic study of Fe-V-H₂O system, the effects of grinding fineness, reaction temperature, sulfuric acid concentration, liquid-solid ratio, leaching reaction time and stirring speed on vanadium slag leaching were investigated under atmospheric condition. The results show that leaching temperature, sulfuric acid concentration and liquid-solid ratio have significant effects on vanadium slag leaching. Under the conditions of particle size of D₉₅ for 16 μm, reaction temperature for 90 ℃, liquid-solid ratio for 8∶1, concentration of H₂SO₄ for 4 mol/L, leaching time for 8 h and stirring speed for 400 r·min^-1, vanadium leaching rate is 86.33%. The amorphous SiO₂ produced in the process of acid dissolution may cover the surface of incompletely dissolved mineral particles and hinder the further acid dissolution of them.
- Vanadium slag /
- Non-roasting /
- Acid leaching under atmospheric pressure /
- Vanadium leaching rate /
- Metallurgical engineering

HTML全文

图 1 钒渣XRD

Figure 1.

下载: 全尺寸图片幻灯片

图 2 Fe-V-H₂O 系25 ℃和100 ℃时 E-pH

Figure 2.

下载: 全尺寸图片幻灯片

图 3 酸浸条件对钒渣浸出的影响

Figure 3.

下载: 全尺寸图片幻灯片

图 4 钒渣浸出前后X射线粉末衍射

Figure 4.

下载: 全尺寸图片幻灯片

图 5 钒渣浸出前后微观形貌

Figure 5.

下载: 全尺寸图片幻灯片

表 1 钒渣主要化学组成/%

Table 1. Main chemical compositions of vanadium slag

Fe₂O₃ SiO₂ Al₂O₃ CaO MgO Cr₂O₃ MnO₂ TiO₂ V₂O₅ 其他

30.60 20.04 2.73 1.44 1.18 3.47 4.40 9.37 11.33 0.44

下载: 导出CSV

参考文献(16)

[1]	赵备备, 李兰杰, 柳林, 等. 废钒触媒提钒工艺[J]. 矿产综合利用, 2019(6):81-84. ZHAO B B, LI L J, LIU L, et al. Study on the vanadium extraction process of spent vanadium catalyst[J]. Multipurpose Utilization of Mineral Resources, 2019(6):81-84. ZHAO B B, LI L J, LIU L, et al. Study on the vanadium extraction process of spent vanadium catalyst[J]. Multipurpose Utilization of Mineral Resources, 2019(6): 81-84.
[2]	胡艺博, 叶国华, 左琪, 等. 从石煤钒矿酸浸液中萃取提钒的研究进展与前景[J]. 矿产综合利用, 2020(1):10-15. HU Y B, YE G H, ZUO Q, et al. The research progress and prospect of extractants for vanadium from acid leaching solution of stone coal vanadium ore[J]. Multipurpose Utilization of Mineral Resources, 2020(1):10-15. doi: 10.3969/j.issn.1000-6532.2020.01.002 HU Y B, YE G H, ZUO Q, et al. The research progress and prospect of extractants for vanadium from acid leaching solution of stone coal vanadium ore[J]. Multipurpose Utilization of Mineral Resources, 2020(1): 10-15. doi: 10.3969/j.issn.1000-6532.2020.01.002
[3]	程倩, 王明, 宁新霞, 等. 从某低品位炭质钒矿石中酸浸-萃取-氨沉淀提钒实验研究[J]. 矿产综合利用, 2021(3):17-21. CHEN Q, WANG M, NING X X, et al. Process of vanadium extraction from a low-grade carbonaceous vanadium by acid leaching-extraction-ammonia precipitation[J]. Multipurpose Utilization of Mineral Resources, 2021(3):17-21. CHEN Q, WANG M, NING X X, et al. Process of vanadium extraction from a low-grade carbonaceous vanadium by acid leaching-extraction-ammonia precipitation [J]. Multipurpose Utilization of Mineral Resources, 2021(3): 17-21.
[4]	丁满堂. 含钒钢渣提钒利用研究[J]. 矿产综合利用, 2020(6):69-72. DING M T. Research on utilization of vanadium extraction from vanadium-bearing steel slag[J]. Multipurpose Utilization of Mineral Resources, 2020(6):69-72. DING M T. Research on utilization of vanadium extraction from vanadium-bearing steel slag[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 69-72.
[5]	张国权, 张廷安, 吕国志, 等. 转炉钒渣氧压酸浸提钒探索实验[J]. 钢铁钒钛, 2014, 35(3):1-4. ZHANG G Q, ZHANG T A, LV G Z, et al. Exploratory experiments on vanadium extraction from converter vanadium slag by oxygen pressure acid leaching[J]. Steel, Vanadium and Titanium, 2014, 35(3):1-4. doi: 10.7513/j.issn.1004-7638.2014.03.001 ZHANG G Q, ZHANG T A, LV G Z, et al. Exploratory experiments on vanadium extraction from converter vanadium slag by oxygen pressure acid leaching[J]. Steel, Vanadium and Titanium, 2014, 35(3): 1-4. doi: 10.7513/j.issn.1004-7638.2014.03.001
[6]	张国权, 张廷安, 吕国志, 等. 钛白废酸加压酸浸转炉钒渣提钒的研究[J]. 稀有金属材料与工程, 2015(8):1894-1898. ZHANG G Q, ZHANG T A, LV G Z, et al. Study on vanadium extraction from titanium white waste acid pressurized acid leaching converter slag[J]. Rare Metal Materials and Engineering, 2015(8):1894-1898. ZHANG G Q, ZHANG T A, LV G Z, et al. Study on vanadium extraction from titanium white waste acid pressurized acid leaching converter slag[J]. Rare Metal Materials and Engineering, 2015(8): 1894-1898.
[7]	Kong X, Chen J, Tang Y, et al. Enhanced removal of vanadium(V from groundwater by layered double hydroxide-supported nanoscale zerovalent iron[J]. Journal of Hazardous Materials, 2019.
[8]	王玲, 崔兆纯, 张羽熙, 等. 钒渣矿物学特征研究[J]. 钢铁钒钛, 2018, 39(1):13-17. WANG L, CUI Z C, ZHANG Y X, et al. Mineralogical characterization of vanadium slag[J]. Steel Vanadium and Titanium, 2018, 39(1):13-17. doi: 10.7513/j.issn.1004-7638.2018.0.003 WANG L, CUI Z C, ZHANG Y X, et al. Mineralogical characterization of vanadium slag[J]. Steel Vanadium and Titanium, 2018, 39(1): 13-17. doi: 10.7513/j.issn.1004-7638.2018.0.003
[9]	古岩, 张廷安, 吕国志, 等. 硫化锌加压浸出过程的电位-pH图[J]. 材料与冶金学报, 2011, 10(2):112-119. GU Y, ZHANG T A, LV G Z, et al. Potential-pH diagram of zinc sulfide pressurized leaching process[J]. Journal of Materials and Metallurgy, 2011, 10(2):112-119. doi: 10.3969/j.issn.1671-6620.2011.02.010 GU Y, ZHANG T A, LV G Z, et al. Potential-pH diagram of zinc sulfide pressurized leaching process[J]. Journal of Materials and Metallurgy, 2011, 10(2): 112-119. doi: 10.3969/j.issn.1671-6620.2011.02.010
[10]	余彬, 孙朝晖, 张廷安, 等. 钒渣无焙烧加压酸浸过程研究[J]. 稀有金属, 2014, 38(6):1134-1140. YU B, SUN C H, ZHANG T A, et al. Study of unroasted pressurized acid leaching process of vanadium slag[J]. Rare Metals, 2014, 38(6):1134-1140. doi: 10.13373/j.cnki.cjrm.2014.06.031 YU B, SUN C H, ZHANG T A, et al. Study of unroasted pressurized acid leaching process of vanadium slag[J]. Rare Metals, 2014, 38(6): 1134-1140. doi: 10.13373/j.cnki.cjrm.2014.06.031
[11]	周雪娇, 魏昶, 李旻廷, 等. 升温条件下V-H_2O系电位-pH图[J]. 矿冶, 2010, 19(4):34-40. ZHOU X J, WEI C, LI M T, et al. Potential-pH diagram of V-H_2O system under elevated temperature conditions[J]. Mineralogy, 2010, 19(4):34-40. doi: 10.3969/j.issn.1005-7854.2010.04.009 ZHOU X J, WEI C, LI M T, et al. Potential-pH diagram of V-H_2O system under elevated temperature conditions[J]. Mineralogy, 2010, 19(4): 34-40. doi: 10.3969/j.issn.1005-7854.2010.04.009
[12]	叶国华, 谢禹, 胡艺博, 等. 低品位石煤钒矿低温硫酸化焙烧-水浸提钒研究[J]. 稀有金属, 2020, 44(7):753-761. YE G H, XIE Y, HU Y B, et al. Low-grade rock coal vanadium ore low-temperature sulfation roasting-water leaching vanadium extraction study[J]. Rare Metals, 2020, 44(7):753-761. YE G H, XIE Y, HU Y B, et al. Low-grade rock coal vanadium ore low-temperature sulfation roasting-water leaching vanadium extraction study[J]. Rare Metals, 2020, 44(7): 753-761.
[13]	Xin L, Pengfei X, Xinghong D, et al. Influencing factors and kinetics analysis on the leaching of iron from boron carbide waste-scrap with ultrasound-assisted method[J]. Ultrasonics-Sonochemistry, 2017.
[14]	杨静翎, 金鑫. 酸浸法提钒新工艺的研究[J]. 北京化工大学学报(自然科学版), 2007, 34(3):254-257. YANG J L, JIN X. Research on the new process of vanadium extraction by acid leaching[J]. Journal of Beijing University of Chemical Technology (Natural Science Edition), 2007, 34(3):254-257. YANG J L, JIN X. Research on the new process of vanadium extraction by acid leaching[J]. Journal of Beijing University of Chemical Technology (Natural Science Edition), 2007, 34(3): 254-257.
[15]	向俊一. 转炉钒渣钙化提钒工艺优化及提钒尾渣综合利用基础研究[D]. 重庆: 重庆大学, 2018. XIANG J Y. Basic research on the optimization of vanadium extraction process and comprehensive utilization of vanadium tailings from converter vanadium slag calcification [D]. Chongqing: Chongqing University, 2018.
[16]	叶国华, 何伟, 路璐, 等. 常温常压下含钒钢渣直接硫酸浸钒的研究[J]. 稀有金属, 2013, 37(5):807-813. YE G H, HE W, LU L, et al. Study of direct sulfuric acid leaching of vanadium from vanadium-containing steel slag at room temperature and pressure[J]. Rare Metals, 2013, 37(5):807-813. doi: 10.3969/j.issn.0258-7076.2013.05.020 YE G H, HE W, LU L , et al. Study of direct sulfuric acid leaching of vanadium from vanadium-containing steel slag at room temperature and pressure[J]. Rare Metals, 2013, 37(5): 807-813. doi: 10.3969/j.issn.0258-7076.2013.05.020
