磨机负荷检测及建模方法研究进展

王廷; 赵建军; 陶乐; 田蕊; 邹文杰

doi:10.3969/j.issn.1000-6532.2023.03.018

磨机负荷检测及建模方法研究进展

1.
北京科技大学土木与资源工程学院，北京　100083

2.
矿冶过程自动控制技术国家重点实验室，北京　100089

基金项目: 矿冶过程自动控制技术国家重点实验室开放基金（BGRIMM-KZSKL-2019-02）；中央高校基本科研业务费（FRF-IP-20-03）

详细信息

作者简介: 王廷（1995-），男，硕士研究生，研究方向为矿物加工工程

通讯作者: 邹文杰（1986-），女，副教授，研究方向为矿物加工工程。

中图分类号: TD453

收稿日期: 2020-07-25

刊出日期: 2023-06-25

Research Progress of Mill Load Detection and Modeling Methods

1.
School of Civil and Resource Engineering, University of Science and Technology Beijing, Beijing, China

2.
State Key Laboratory of Process Automation in Mining & Metallurgy, Beijing, China

More Information

Corresponding author: Zou Wenjie, wjzou@ustb.edu.cn

Received Date: 25 July 2020

Publish Date: 25 June 2023

摘要

摘要:
这是一篇矿业工程领域的论文。选矿厂节能降耗需求强烈，球磨机负荷检测是实现磨机控制、优化磨矿流程的关键技术。本文归纳了近年来磨机负荷的检测方法：压差法、磨音法、振动法、功率法、超声波法、基于多源信号融合的间接检测方法；总结并分析了磨机负荷的建模方法。未来一段时间内，多源信息融合的间接法将仍是检测磨机负荷的主要方法，改进神经网络为基础的建模方法、新型在线检测方法以及建立高效精准的负荷检测模型是磨机负荷检测的主要发展方向。
- 磨机负荷 /
- 软测量 /
- 建模 /
- 神经网络 /
- 在线检测 /
- 矿业工程
Abstract:
This is a paper in the field of mining engineering. With the increasing demands for energy conservation and consumption reduction in mineral processing plants, ball mill load measurement is the key technology to realize mill control and optimize the grinding process. This paper summarizes the measurement methods of mill load in the recent years: differential pressure method, grinding sound method, vibration method, power method, ultrasonic method, indirect detection method based on multi-source signal fusion. Moreover, it summarizes and analyzes the mill load modeling methods that have emerged inrecent years. In the future, the indirect methods of multi-source information fusion will still be the main methods to detect mill load, modeling methods based on improvement of neural network and new online detection methods, as well as the establishment of efficient and accurate load detection models will be the main development direction of mill load detection.
- Mill load /
- Soft measurement /
- Modeling /
- Neural network /
- Online detection /
- Mining engineering

HTML全文

表 1 各单源检测手段原理及优缺点

Table 1. Principles, advantages and disadvantages of the single-source detection methods

检测方法	检测原理	优点	缺点
振动法	球磨机筒体和轴承等部位安装振动传感器，振动能量与磨机负荷的关系	较灵敏，能显示磨机内物料的变化	易受钢球等磨矿介质、衬板磨损的影响
磨音法	磨机内介质和筒壁相互碰撞产生的机械噪声特性与磨机负荷变化相关	形成系列产品，能预测大致的料球比	易受相邻磨机和环境噪音的影响，难于判断介质充填率和矿浆浓度
压差法	检测磨机入料口和出料口的压强差，以经验公式表征磨机负荷	适用于干式磨机，无需进行复杂的磨机负荷参数检测	极度依靠工人经验，测量精度较低
功率法	以介质与矿浆运动所消耗的功率预测磨机负荷	受周边环境影响较小，检测结果精确	灵敏度不高，受电网电压波动影响大
超声波法	超声波在介质中的传播特性检测磨机料位，预测负荷	适用于干式磨机，穿透能力强，灵敏度高	信号传播存在衰减和畸变

下载: 导出CSV

参考文献(36)

[1]	汤健, 田福庆, 贾美英, 等. 基于频谱数据驱动的旋转机械设备负荷软测量[M]. 北京: 国防工业出版社, 2015. TANG J, TIAN F Q, JIA M Y, et al. Load soft measurement of rotating machinery and equipment based on spectrum data drive[M]. Beijing: National Defense Industry Press, 2015.
[2]	王泽红, 陈炳辰. 球磨机负荷检测的现状与发展趋势[J]. 中国粉体技术, 2001, 1(1):19-23. WANG Z H, CHEN B C. Current status and development trend of ball mill load detection[J]. China Powder Technology, 2001, 1(1):19-23. doi: 10.3969/j.issn.1008-5548.2001.01.006 WANG Z H, CHEN B C. Current status and development trend of ball mill load detection[J]. China Powder Technology, 2001, 1( 1): 19-23. doi: 10.3969/j.issn.1008-5548.2001.01.006
[3]	李艳姣. 磨机负荷优化计算与专家控制[D]. 唐山: 河北联合大学, 2014. LI Y J. Mill load optimization calculation and expert control[D]. Tangshan: Hebei Union University, 2014.
[4]	汤健, 赵立杰, 岳恒, 等. 磨机负荷检测方法研究综述[J]. 控制工程, 2010, 17(5):565-570+574. TANG J, ZHAO L J, YUE H, et al. A review of the research on mill load detection methods[J]. Control Engineering, 2010, 17(5):565-570+574. doi: 10.3969/j.issn.1671-7848.2010.05.001 TANG J, ZHAO L J, YUE H, et al. A review of the research on mill load detection methods[J]. Control Engineering, 2010, 17(5): 565-570+574. doi: 10.3969/j.issn.1671-7848.2010.05.001
[5]	高纯生, 刘鑫, 谢文涓, 等. 基于EWT-奇异值熵的磨机负荷识别方法[J]. 矿业研究与开发, 2019, 39(11):130-136. GAO C S, LIU X, XIE W J, et al. Mill load identification method based on EWT-singular value entropy[J]. Mining Research and Development, 2019, 39(11):130-136. doi: 10.13827/j.cnki.kyyk.2019.11.026 GAO C S, LIU X, XIE W J, et al. Mill load identification method based on EWT-singular value entropy[J]. Mining Research and Development, 2019, 39(11): 130-136. doi: 10.13827/j.cnki.kyyk.2019.11.026
[6]	B Behera, B K Mishra, C V R Murty. Experimental analysis of charge dynamics in tumbling mills by vibration signature technique[J]. Minerals Engineering, 2006, 20(1).
[7]	郭振宇, 邹国斌, 杨凌凌, 等. 基于DCS采集的振动数据的磨机负荷分析[J]. 有色金属(选矿部分), 2019(4):69-74. GUO Z Y, ZOU G B, YANG L L, et al. Mill load analysis based on vibration data collected by DCS[J]. Nonferrous Metals (Mineral Processing), 2019(4):69-74. GUO Z Y, ZOU G B, YANG L L, et al. Mill load analysis based on vibration data collected by DCS[J]. Nonferrous Metals (Mineral Processing), 2019(4): 69-74.
[8]	Jianquan Shi, Gangquan Si, Shuiwang Li. Feature extraction based on the fractional Fourier transform for vibration signals with application to measuring the load of a tumbling mill[J]. Control Engineering Practice, 2019, 84.
[9]	熊洋. 基于振动特征提取的球磨机负荷预测研究[D]. 赣州: 江西理工大学, 2016. XIONG Y. Research on load prediction of ball mill based on vibration feature extraction[D]. Ganzhou: Jiangxi University of Science and Technology, 2016.
[10]	刘卓, 柴天佑, 汤健. 基于多尺度振动和振声频谱特征自适应提取与选择的磨机负荷参数软测量[J]. 控制与决策, 2019, 34(12):2603-2610. LIU Z, CHAI T Y, TANG J. Soft measurement of mill load parameters based on adaptive extraction and selection of multi-scale vibration and vibration-acoustic spectrum features[J]. Control and Decision, 2019, 34(12):2603-2610. doi: 10.13195/j.kzyjc.2018.0369 LIU Z, CHAI T Y, TANG J. Soft measurement of mill load parameters based on adaptive extraction and selection of multi-scale vibration and vibration-acoustic spectrum features[J]. Control and Decision, 2019, 34(12): 2603-2610 doi: 10.13195/j.kzyjc.2018.0369
[11]	汤健,乔俊飞,刘卓,等. 磨矿过程的球磨机研磨机理数值仿真及磨机负荷参数软测量综述[J]. 北京工业大学学报, 2018, 44(11):1459-1470. TANG J, QIAO J F, LIU Z, et al. Numerical simulation of ball mill grinding mechanism for grinding process and review of soft measurement of mill load parameters[J]. Journal of Beijing University of Technology, 2018, 44(11):1459-1470. 11
[12]	王颖洁. 钢球磨煤机料位的软测量及其动态过程建模与控制[D]. 南京: 东南大学, 2005. WANG Y J. Soft measurement of ball coal mill level and its dynamic process modeling and control[D]. Nanjing: Southeast University, 2005.
[13]	杨志刚, 张杰, 李艳姣. 磨音影响因素分析与磨机负荷检测方法综述[J]. 金属矿山, 2015(2):139-144. YANG Z G, ZHANG J, LI Y J. Analysis of influence factors of grinding sound and review of mill load detection methods[J]. Metal Mine, 2015(2):139-144. YANG Z G, ZHANG J, LI Y J. Analysis of influence factors of grinding sound and review of mill load detection methods[J]. Metal Mine, 2015(2): 139-144.
[14]	唐耀庚. 模糊逻辑控制在磨机负荷控制中的应用[J]. 电气传动, 2002(5):31-33. TANG Y G. Application of fuzzy logic control in mill load control[J]. Electrical Drive, 2002(5):31-33. doi: 10.3969/j.issn.1001-2095.2002.05.008 TANG Y G. Application of fuzzy logic control in mill load control[J]. Electrical Drive, 2002(5): 31-33. doi: 10.3969/j.issn.1001-2095.2002.05.008
[15]	郑鉴君. 联合粉磨系统磨机负荷辨识方法研究[D]. 济南: 济南大学, 2015. ZHENG J J. Research on mill load identification method of combined grinding system[D]. Jinan: University of Jinan, 2015.
[16]	张杰, 王建民, 杨志刚. 承德某选矿厂磨机运行专家系统[J]. 金属矿山, 2013(7):144-148. ZHANG J, WANG J M, YANG Z G. An expert system for mill operation in a concentrator in Chengde[J]. Metal Mine, 2013(7):144-148. doi: 10.3969/j.issn.1001-1250.2013.07.037 ZHANG J, WANG J M, YANG Z G. An expert system for mill operation in a concentrator in Chengde[J]. Metal Mine, 2013(7): 144-148. doi: 10.3969/j.issn.1001-1250.2013.07.037
[17]	姜德轩. 基于球磨机负荷优化控制的磨音检测[D]. 济南: 济南大学, 2011. JIANG D X. Grinding sound detection based on ball mill load optimization control[D]. Jinan: University of Jinan, 2011.
[18]	杜江. 高精度智能型磨音测量仪的研制[D]. 重庆: 重庆邮电大学, 2018. DU J. Development of high-precision intelligent grinding sound measuring instrument[D]. Chongqing: Chongqing University of Posts and Telecommunications, 2018.
[19]	田黎. 一种应用于水泥磨机的新型噪声料位测量系统[C]. 中国硅酸盐学会, 2015: 205-211. TIAN L. A new type of noise level measurement system applied to cement mills[C]. Chinese Ceramic Society, 2015: 205-211.
[20]	黄成祥, 陈敏, 王庸贵. 球磨机负荷智能监控系统的研究[J]. 机械, 1999(6):8-9+45. HUANG C X, CHEN M, WANG Y G. Research on intelligent monitoring system of ball mill load[J]. Machinery, 1999(6):8-9+45. HUANG C X, CHEN M, WANG Y G. Research on intelligent monitoring system of ball mill load[J]. Machinery, 1999(6): 8-9+45.
[21]	禤莉明, 何祖威. 采用超声Lamb波测量钢球磨煤机的料位[J]. 动力工程, 2006(6):859-864. XUAN L M, HE Z W. Using ultrasonic Lamb wave to measure the level of steel ball coal mill[J]. Power Engineering, 2006(6):859-864. XUAN L M, HE Z W. Using ultrasonic Lamb wave to measure the level of steel ball coal mill[J]. Power Engineering, 2006(6): 859-864.
[22]	韩亚辉, 郝成. 关于大量程超声波料位计的算法修正讨论[J]. 价值工程, 2014, 33(25):301-302. HAN Y H, HAO C. Discussion on the algorithm modification of large-range ultrasonic level gauge[J]. Value Engineering, 2014, 33(25):301-302. doi: 10.14018/j.cnki.cn13-1085/n.2014.25.533 HAN Y H, HAO C. Discussion on the algorithm modification of large-range ultrasonic level gauge[J]. Value Engineering, 2014, 33(25): 301-302. doi: 10.14018/j.cnki.cn13-1085/n.2014.25.533
[23]	罗小燕, 邵凡, 陈慧明, 等. 基于多源信号融合的球磨机负荷预测方法研究[J]. 振动与冲击, 2019, 38(8):232-237. LUO X Y, SHAO F, CHEN H M, et al. Research on load prediction method of ball mill based on multi-source signal fusion[J]. Vibration and Shock, 2019, 38(8):232-237. LUO X Y, SHAO F, CHEN H M, et al. Research on load prediction method of ball mill based on multi-source signal fusion[J]. Vibration and Shock, 2019, 38(8): 232-237.
[24]	加力康. 基于多源融合技术的转子系统载荷识别研究[D]. 太原: 太原理工大学, 2016. JIA L K. Research on rotor system load identification based on multi-source fusion technology[D]. Taiyuan: Taiyuan University of Technology, 2016.
[25]	卢小江. 基于多源信号融合技术的球磨机负荷预测方法研究[D]. 赣州: 江西理工大学, 2017. LU X J. Research on load forecasting method of ball mill based on multi-source signal fusion technology [D]. Ganzhou: Jiangxi University of Science and Technology, 2017.
[26]	蔡改贫, 赵小涛, 张丹荣, 等. 基于ASOS-ELM的湿式球磨机负荷软测量方法[J]. 振动测试与诊断, 2020, 40(1):184-192+211. CAI G P, ZHAO X T, ZHANG D R, et al. ASOS-ELM-based soft load measurement method of wet ball mill[J]. Vibration Testing and Diagnosis, 2020, 40(1):184-192+211. CAI G P, ZHAO X T, ZHANG D R, et al. ASOS-ELM-based soft load measurement method of wet ball mill[J]. Vibration Testing and Diagnosis, 2020, 40(1): 184-192+211.
[27]	邓展, 王建民. 基于RBF神经网络的磨机负荷智能控制的研究[J]. 矿业研究与开发, 2018, 38(2):89-94. DENG Z, WANG J M. Research on intelligent control of mill load based on RBF neural network[J]. Mining Research and Development, 2018, 38(2):89-94. DENG Z, WANG J M. Research on intelligent control of mill load based on RBF neural network[J]. Mining Research and Development, 2018, 38(2): 89-94.
[28]	赵立杰, 李彬, 汪滢, 等. 磨机负荷参数快速去相关神经网络集成模型[J]. 控制工程, 2017, 24(9):1952-1957. ZHAO L J, LI B, WANG Y, et al. Neural network integrated model for fast decorrelation of mill load parameters[J]. Control Engineering, 2017, 24(9):1952-1957. ZHAO L J, LI B, WANG Y, et al. Neural network integrated model for fast decorrelation of mill load parameters[J]. Control Engineering, 2017, 24(9): 1952-1957.
[29]	罗小燕, 戴聪聪, 程铁栋, 等. 基于改进EWT-多尺度熵和KELM的球磨机负荷识别方法[J]. 化工学报, 2020, 71(3):1264-1277. LUO X Y, DAI C C, CHENG T D, et al. Ball mill load identification method based on improved EWT-multi-scale entropy and KELM[J]. CIESC Journal, 2020, 71(3):1264-1277. LUO X Y, DAI C C, CHENG T D, et al. Ball mill load identification method based on improved EWT-multi-scale entropy and KELM[J]. CIESC Journal, 2020, 71(3): 1264-1277.
[30]	刘志刚, 蔡改贫, 林龙飞, 等. 主元分析的振动频域特征识别与磨机负荷建模研究[J]. 中国钨业, 2016, 31(3):68-73. LIU Z G, CAI G P, LIN L F, et al. Research on vibration frequency domain feature recognition and mill load modeling based on principal component analysis[J]. China Tungsten Industry, 2016, 31(3):68-73. doi: 10.3969/j.issn.1009-0622.2016.03.014 LIU Z G, CAI G P, LIN L F, et al. Research on vibration frequency domain feature recognition and mill load modeling based on principal component analysis[J]. China Tungsten Industry, 2016, 31(3): 68-73. doi: 10.3969/j.issn.1009-0622.2016.03.014
[31]	司刚全, 李水旺, 石建全, 等. 采用改进果蝇优化算法的最小二乘支持向量机参数优化方法[J]. 西安交通大学学报, 2017, 51(6):14-19. SI G Q, LI S W, SHI J Q, et al. Parameter optimization method of least square support vector machine using improved fruit fly optimization algorithm[J]. Journal of Xi'an Jiaotong University, 2017, 51(6):14-19. SI G Q, LI S W, SHI J Q, et al. Parameter optimization method of least square support vector machine using improved fruit fly optimization algorithm[J]. Journal of Xi'an Jiaotong University, 2017, 51(6): 14-19.
[32]	赵立杰, 邹世达, 郭烁, 等. 基于正则化随机配置网络的球磨机工况识别[J]. 控制工程, 2020, 27(1):1-7. ZHAO L J, ZOU S D, GUO S, et al. Ball mill working condition recognition based on regularized random configuration network[J]. Control Engineering, 2020, 27(1):1-7. doi: 10.14107/j.cnki.kzgc.20190437 ZHAO L J, ZOU S D, GUO S, et al. Ball mill working condition recognition based on regularized random configuration network[J]. Control Engineering, 2020, 27(1): 1-7. doi: 10.14107/j.cnki.kzgc.20190437
[33]	刘卓, 柴天佑, 汤健. 一种多尺度球磨机筒体振动频谱分析与建模方法[J]. 东北大学学报(自然科学版), 2015, 36(3):305-308. LIU Z, CHAI T Y, TANG J. A method of frequency spectrum analysis and modeling of multi-scale ball mill barrel vibration[J]. Journal of Northeastern University (Natural Science Edition), 2015, 36(3):305-308. doi: 10.3969/j.issn.1005-3026.2015.03.001 LIU Z, CHAI T Y, TANG J. A method of frequency spectrum analysis and modeling of multi-scale ball mill barrel vibration[J]. Journal of Northeastern University (Natural Science Edition), 2015, 36(3): 305-308. doi: 10.3969/j.issn.1005-3026.2015.03.001
[34]	蔡改贫, 宗路, 罗小燕, 等. 基于CEEMDAN-云模型特征熵和LSSVM的磨机负荷预测研究[J]. 振动与冲击, 2019, 38(7):128-133. CAI G P, ZONG L, LUO X Y, et al. Research on mill load prediction based on CEEMDAN-cloud model feature entropy and LSSVM[J]. Vibration and Shock, 2019, 38(7):128-133. doi: 10.13465/j.cnki.jvs.2019.07.019 CAI G P, ZONG L, LUO X Y, et al. Research on mill load prediction based on CEEMDAN-cloud model feature entropy and LSSVM[J]. Vibration and Shock, 2019, 38(7): 128-133. doi: 10.13465/j.cnki.jvs.2019.07.019
[35]	刘吉顺, 杨丽荣, 罗小燕, 等. CEEMDAN和样本熵相结合的球磨机负荷识别方法[J/OL]. 机械科学与技术: 1-8. LIU J S, YANG L R, LUO X Y, et al. Load identification method of ball mill based on CEEMDAN and sample entropy[J/OL]. Mechanical Science and Technology: 1-8.
[36]	刘卓, 汤健, 柴天佑, 等. 基于多模态特征子集选择性集成建模的磨机负荷参数预测方法[J/OL]. 自动化学报: 1-15. LIU Z, TANG J, CHAI T Y, et al. A method for predicting mill load parameters based on selective integrated modeling of multi-modal feature subsets[J/OL]. Acta Automatica Sinica: 1-15
