Geology and genesis of the Dahuangshan REE-Nb-Fe polymetallic mineralization zone in Karakoram Range
-
摘要:
对喀喇昆仑山大黄山稀土-铌-铁钛多金属矿化带地质特征及矿床成因进行研究，为该区找矿勘查工作部署提供依据。通过详细的野外地质调查，在总结大黄山稀土-铌-铁钛多金属矿化带地质特征的基础上，配合镜下鉴定、矿床地球化学分析，探讨矿床成因类型与成矿作用，分析成矿期后的构造变形，预测矿化体的空间就位，提出找矿方向和找矿思路。大黄山稀土-铌-铁钛多金属矿化带含矿建造沉积环境为近陆滨-浅海碳酸盐岩台地相。矿化带处于石炭系帕斯群灰岩组（a组）上段（含矿泥质灰岩段）上部，区内延伸大于30km，西段发现2条矿化体（Ⅰ-1、Ⅰ-1），东段发现7条矿化体（Ⅱ-1~Ⅱ-7）。单矿化体一般长170~2000 m，厚度10~32 m，矿化体产状与地层产状一致，层控特征明显。矿石化学测试结果表明，矿化体内含Fe、Al、Ti、LREE、Nb、Ta等多种金属成矿元素。矿床成因类型为近陆滨海相沉积型。矿源为古陆源区红土型风化壳，以沉积物重力流和胶体溶液混合流体形式快速搬运，并在近陆滨岸地带以事件沉积作用快速卸载堆积而成。成矿期后，含矿建造遭受了强烈的构造改造，形成了总体呈NWW向展布的断褶带，带内发育的复式-叠加反"S"型褶皱构造构成了区内最特征的控矿构造样式。该带找矿前景好，找矿潜力大，通过进一步的矿产地质工作，有望在该带实现Fe、Al、Ti，尤其是稀有、稀土元素的重要找矿突破。
Abstract:The study on geology and genesis of the rare earth niobium iron titanium polymetallic mineralization zone in Dahuangshan, Kunlun Mountain, Kara can provide the basis for the exploration work in this area.Based on detailed field geological survey and summarizing of the geological characteristics of the Dahuangshan RE-Nb-Fe-Ti deposit, together with microscopic identification and geochemical analysis, the genetic types and mineralization of the iron ore are discussed.The analysis of structural deformation after metallogenic period can lead to the prediction of orebody location and prospecting target generation.The depositional environment of the ore-bearing formation in the Dahuangshan REE-Nb-Fe-Ti mineralization belt is littoral-shallow sea carbonate platform facies.The mineralization zone is located in the upper part (limestone Formation) of the Pasi Group (ore-bearing argillaceous limestone), and extends over 30 km in the area, two mineralized bodies (Ⅰ-1, Ⅰ-1) were found in the west section, and seven mineralized bodies (Ⅱ-1~Ⅱ-7) were found in the east section, Single mineralized bodies are generally 170-2000 m long and 10-32 m thick.whose attitude is consistent with strata.The ore assaying show that the mineralized bodies contain RE-Nb-Fe-Ti and other metallogenic elements.The genetic type of the deposit is offshore marine sedimentary type.The ore source is lateritic weathering crust in ancient continental area.It is presumed that the original rock is rapidly transported by mixing fluid of sediment gravity flow and colloidal solution, and rapidly unloaded and accumulated by event sedimentation in coastal zone.After the metallogenic period, the ore-bearing formation underwent intense structural transformation.The mineralized layer and the ore-bearing formation were deformed synchronously with various ore-controlling structures.The eastern part of the ore-bearing formation is characterized by a compound-superimposed fold structure, while the western part is characterized by a compression fault block-steeply dipping monoclinic structure.This area shows great prospecting potential.Through further mineral geological work, it is expected to achieve important prospecting breakthroughs for Fe, Al and Ti, especially rare and rare earth elements.After the metallogenic period, the ore-bearing structure underwent a strong structural transformation, and formed a fault-fold belt with NWW direction on the whole.The compound-superimposed inverted "S" fold structure developed in the belt constituted the most characteristic ore-controlling structural style in the area. This area shows great prospecting potential.Through further mineral geological work, it is expected to achieve important prospecting breakthroughs for Fe, Al and Ti, especially rare and rare earth elements.
-
-
表 1 大黄山稀土-铌-铁-钛多金属矿化带内矿(化)体基本特征
Table 1. Ore bodies in Dahuangshan REE-Nb-Fe-Ti polymetallic mineralization zone
序号 矿体编号 形态 产状 长度/m 平均厚度/m Nb2O5/10-6 Ta2O5/10-6 REE2O3/10-6 Ti/% TFe/% 控制手段 1 Ⅰ-1 层状 242°∠44° 800 12 4.83 33.30 地表追索+探槽 2 Ⅰ-2 层状 232°∠42° 2000 10 4.90 22.97 3 Ⅱ-1 层状 222°∠62° 658 22 4.80 19.28 4 Ⅱ-2 层状 245°∠81° 743 15.9 476 29 1731 4.99 20.00 5 Ⅱ-3 层状 215°∠40° 580 32.3 276 19 918 3.35 21.45 6 Ⅱ-4 层状 260°∠56° 660 26.1 739 42 669 4.39 19.28 7 Ⅱ-5 层状 335°∠30° 631 22 403 23.62 544 4.01 17.88 8 Ⅱ-6 层状 210°∠55° 170 18 5.89 23.40 9 Ⅱ-7 层状 265°∠78° 780 20 5.36 20.45
下载: 导出CSV
表 2 大黄山稀土-铌-铁钛多金属矿化带内钛元素物相分析结果
Table 2. Phase analysis of titanium of ores from the Dahuangshan REE-Nb-Fe-Ti polymetallic mineralization zone
物相种类 钛铁矿中钛 金红石中钛 钛磁铁矿中钛 榍石和硅酸盐中钛 总量 TiO2/% TiO2/% TiO2/% TiO2/% TiO2/% 含量 4.78 1.89 1.20 < 0.01 7.87 百分比/% 60.74 24.01 15.25 0 100
下载: 导出CSV
表 3 大黄山稀土-铌-铁-钛多金属矿化带内矿石地球化学测试结果
Table 3. Assaying results of ores in the Dahuangshan REE-Nb-Fe-Ti polymetallic mineralization zone
样品 MnO/TiO2 Na/Mg Fe/Ti Al/(Al+Fe+Mn) D6-1 0.03 0.69 0.92 0.85 D2-1 0.01 0.92 4.76 0.47 D8-1 0.001 0.13 2.86 0.48 D9-1 0.002 6.98 1.76 0.77 D10-1 0.01 2.78 7.07 0.38 D11-1 0.01 2.69 4.57 0.43
下载: 导出CSV
表 4 大黄山稀土-铌-铁-钛多金属矿化带内矿石稀土元素测试结果
Table 4. REE assaying results of ores from the Dahuangshan REE-Nb-Fe-Ti polymetallic mineralization zone
10-6 样品号 TC3-2XT
WL6-1TC2-3XT
WL2-1TC2-1XT
WL8-1TC2-1XT
WL9-1TC2-1XT
WL10-1TC3-1XT
WL9-1La 192.00 196.00 226.00 412.00 130.00 136.00 Ce 318.00 366.00 483.00 802.00 313.00 304.00 Pr 35.80 54.40 72.80 101.00 30.70 40.00 Nd 112.00 219.00 290.00 474.00 112.00 158.00 Sm 17.00 40.40 41.80 64.90 19.80 28.90 Eu 4.62 11.60 10.20 15.10 6.63 8.42 Gd 12.80 34.80 31.60 48.00 18.60 25.30 Tb 1.47 4.93 3.60 4.89 2.36 3.55 Dy 5.75 20.60 12.70 15.10 10.00 15.70 Ho 0.91 2.93 1.88 2.11 1.48 2.52 Er 2.26 6.28 4.57 5.75 3.69 6.00 Tm 0.28 0.70 0.55 0.62 0.48 0.79 Yb 1.60 4.01 3.26 3.87 3.09 4.68 Lu 0.22 0.47 0.42 0.51 0.38 0.56 Y 21.50 61.30 38.90 45.40 37.00 61.20 LREE 679.42 887.40 1123.80 1869.00 612.13 675.32 HREE 25.29 74.72 58.58 80.85 40.08 59.10 LREE/HREE 26.87 11.88 19.18 23.12 15.27 11.43 LaN/YbN 11.31 4.61 6.54 10.04 3.97 2.74
下载: 导出CSV
-
[1] 程裕淇. 中国区域地质概论[M]. 北京: 地质出版社, 1994: 1-200.
[2] 潘裕生. 昆仑山区构造区划初探[J]. 自然资源学报, 1989, 4(3): 196-203. doi: 10.3321/j.issn:1000-3037.1989.03.002
[3] 潘裕生. 青藏高原第五缝合带的发现与论证[J]. 地球物理学报, 1994, 37(2): 184-192. doi: 10.3321/j.issn:0001-5733.1994.02.006
[4] Wang X, Zhang X, Gao J, et al. A slab break-off model for the submarine volcanic-hosted iron mineralization in the Chinese Western Tianshan: Insights from Paleozoic subduction-related to post-collisional magmatism[J]. Ore Geology Reviews, 2018, 92: 144-160. doi: 10.1016/j.oregeorev.2017.11.015
[5] Li W, Dong Y, Guo A, et al. Chronology and tectonic significance of Cenozoic faults in the Liupanshan Arcuate Tectonic Belt at the northeastern margin of the Qinghai-Tibet Plateau[J]. Journal of Asian Earth Sciences, 2013, 73: 103-113. doi: 10.1016/j.jseaes.2013.04.026
[6] Wang C, Liu A, Wang H, et al. Recognition and tectonic implications of an extensive Neoproterozoic volcano-sedimentary rift basin along the southwestern margin of the Tarim Craton, northwestern China[J]. Precambrian Research, 2013, 257: 65-82.
[7] Liu L, Ya B, Lei L, et al. Early Paleozoic granitic magmatism related to the processes from subduction to collision in South Altyn, NW China[J]. Science China Earth Sciences, 2015, 58: 1513-1522. doi: 10.1007/s11430-015-5151-1
[8] Fan Y, Wan Y, Wang H, et al. Application of airborne hyperspectral remote sensing image data in the gold-silver-lead-zinc ore district of Huaniushan, Gansu, China[J]. Eologia Croatica, 2021, 74(1): 73-84 doi: 10.4154/gc.2021.04
[9] 巫建华, 刘帅. 大地构造学概论与中国大地构造学纲要[M]. 北京: 地质出版社, 2008.
[10] 杨克明. 论西昆仑大陆边缘构造演化及塔里木西南盆地类型[J]. 地质论评, 1994, 1: 9-18. doi: 10.3321/j.issn:0371-5736.1994.01.002
[11] 潘裕生, 周伟明, 许荣华, 等. 昆仑山早古生代地质特征与演化[J]. 中国科学(D辑), 1996, 26(4): 302-307. doi: 10.3321/j.issn:1006-9267.1996.04.003
[12] 潘裕生. 青藏高原的形成与隆升[J]. 地学前缘, 1999, 6(3): 153-163. doi: 10.3321/j.issn:1005-2321.1999.03.015
[13] 姜春发, 朱松年. 构造迁移论概述[J]. 中国地质科学院院报, 1992, 25: 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB199200000.htm
[14] 姜春发. 中央造山带几个重要地质问题及其研究进展(代序)[J]. 地质通报, 2002, 21(Z2): 453-455. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=200208112&flag=1
[15] 姜春发, 杨经绥, 冯秉贵, 等. 昆仑开合构造[M]. 北京: 地质出版社, 1992: 161-168.
[16] 李涛, 王宗秀. 塔里木地块北部横向构造及断条模式[J]. 中国地质, 2006, 33(1): 14-27. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200601001.htm
[17] 陆松年, 李怀坤, 陈志宏. 塔里木与扬子新元古代热-构造事件特征、序列和时代——扬子与塔里木连接(YZ-TAR)假设[J]. 地学前缘, 2003, 10(4): 321-326. doi: 10.3321/j.issn:1005-2321.2003.04.001
[18] 杨经绥, 王希斌, 史仁灯, 等. 青藏高原北部东昆仑南缘德尔尼蛇绿岩: 一个被肢解了的古特提斯洋壳[J]. 中国地质, 2004, 31(3): 225-239. doi: 10.3969/j.issn.1000-3657.2004.03.001
[19] 李文渊, 张照伟, 高永宝, 等. 秦祁昆造山带重要成矿事件及其构造演化响应[C]//陈毓川, 薛春纪, 张长青. 主攻深部挺进西部放眼世界——第九届全国矿床会议论文集. 北京: 地质出版社, 2008: 15-16.
[20] 康磊, 校培喜, 高晓峰, 等. 西昆仑西段晚古生代-中生代花岗质岩浆作用及构造演化过程[J]. 中国地质, 2015, 42(3): 533-552. doi: 10.3969/j.issn.1000-3657.2015.03.011
[21] 李文渊, 张照伟, 高永宝, 等. 秦祁昆造山带重要成矿事件与构造响应[J]. 中国地质. 2011, 38(5): 1135-1149. doi: 10.3969/j.issn.1000-3657.2011.05.002
[22] 孙海田, 李纯杰, 李锦荣, 等. 新疆西昆仑昆盖山地区铜矿资源找矿地质条件[J]. 中国地质, 1997, 24(11): 29-30. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI199711010.htm
[23] 王书来, 汪东波, 祝新友. 新疆西昆仑金(铜)矿找矿前景分析[J]. 地质找矿论丛, 2000, 15(3): 224-229. doi: 10.3969/j.issn.1001-1412.2000.03.004
[24] 西北地质矿产研究所. 西北地区矿产资源找矿潜力[M]. 北京: 地质出版社, 2006.
[25] 杨合群, 姜寒冰, 谭文娟, 等. 西北地区重要矿产概论[M]. 武汉: 中国地质大学出版社, 2017: 19.
[26] 李先军, 赵祖应. 西昆仑北段矿产分布特征及找矿方向浅析[J]. 地质与勘探, 2009, 45(2): 1-7. doi: 10.3969/j.issn.1001-1986.2009.02.001
[27] 李宝强, 杨万志, 赵树铭, 等. 西昆仑成矿带成矿特征及勘查远景[J]. 西北地质, 2006, 39(2): 128-142. doi: 10.3969/j.issn.1009-6248.2006.02.008
[28] 李文渊. 中国西北部成矿地质特征及找矿新发现[J]. 中国地质, 2015, 42(3): 365-380. doi: 10.3969/j.issn.1000-3657.2015.03.001
[29] Qin Y, Feng Q, Chen G, et al. Devonian post-orogenic extension-related volcano-sedimentary rocks in the northern margin of the Tibetan Plateau, NW China: Implications for the Paleozoic tectonic transition in the North Qaidam Orogen[J]. Journal of Asian Earth Sciences. 2018, 156: 145-166. doi: 10.1016/j.jseaes.2018.01.009
[30] Hou Q, Mou C, Wang Q, et al. Provenance and tectonic setting of the Early and Middle Devonian Xueshan Formation, the North Qilian Belt, China[J]. Geological Journal, 2018, 53: 1404-1422. doi: 10.1002/gj.2963
[31] Fan Y, Wang H. Application of remote sensing to identify copper-lead-zinc deposits in the Heiqia Area of the West Kunlun Mountains, China[J]. Scientific Reports, 2020, (10): 12309. http://www.nature.com/articles/s41598-020-68464-7
[32] Fan Y, Wang H, Yang X, et al. Application of high resolution remote sensing technology for the iron ore deposits of the West Kunlun mountains in China[J]. Eologia Croatica, 2021, 74(1): 57-72 doi: 10.4154/gc.2021.03
[33] 董永观, 郭坤一, 肖惠良, 等. 西昆仑地区成矿远景[J]. 中国地质, 2003, 30(2): 173-178. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200302009.htm
[34] 褚少雄. 西昆仑及其邻区成矿地质背景及成矿规律探讨[D]. 中国地质大学硕士学位论文, 2008.
[35] 贾群子. 新疆西昆仑块状硫化物铜矿床[M]. 北京: 地质出版社, 1999.
[36] 侯增谦, 宋玉财, 李政, 等. 青藏高原碰撞造山带Pb-Zn-Ag-Cu矿床新类型: 成矿基本特征与构造控矿模型[J]. 矿床地质, 2008, 27(2): 123-144. doi: 10.3969/j.issn.0258-7106.2008.02.001
[37] 李文渊, 张照伟, 高永宝, 等. 秦祁昆造山带重要成矿事件与构造响应[J]. 中国地质, 2011, 38(5): 41-50. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201105003.htm
[38] 赵佳楠, 刘正军. 新疆西昆仑造山带北缘中元古代帕什托克闪长岩侵入序列及其地质意义[J]. 中国地质, 2014, 41(1): 92-107. doi: 10.3969/j.issn.1000-3657.2014.01.007
[39] 高晓峰, 校培喜, 康磊, 等. 新疆塔什库尔干塔阿西一带火山岩成因及地质意义[J]. 地球科学-中国地质大学学报, 2013, 38(6): 1169-1182. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201306002.htm
[40] 贠杰, 高晓峰, 校培喜, 等. 西昆仑下石炭统乌鲁阿特组火山岩地球化学特征及地质意义[J]. 中国地质, 2015, 42(3): 587-600. doi: 10.3969/j.issn.1000-3657.2015.03.014
[41] 新疆自治区地质矿产局. 新疆自治区区域地质志[M]. 北京: 地质出版社, 1993: 1-841.
[42] 王永, 李德贵, 肖序常, 等. 西昆仑山前晚新生代构造话动与青藏高原西北缘的隆升[J]. 中国地质, 2006, 33(1): 41-47. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200601003.htm
[43] 于晓飞. 西昆仑造山带区域成矿规律研究[D]. 中国地质大学博士学位论文, 2008.
[44] 李荣社, 计文化, 杨永成, 等. 昆仑山及邻区地质[M]. 北京: 地质出版社, 2008: 1-5.
[45] 伍耀中, 乔耿彪, 陈登辉, 等. 昆仑-阿尔金成矿带金属矿产成矿条件与成矿远景预测[M]. 武汉: 中国地质大学出版社, 2016: 14.
[46] 计文化, 陈守建, 李荣社, 等. 青藏高原及邻区古生代构造-岩相古地理综合研究[M]. 武汉: 中国地质大学出版社, 2014: 112-116.
[47] Gao S, Ling W, Qiu Y, et al. Contrasting geochemical and Sm-Nd isotopic compositions of Archean metasediments from the Kongling high-grade terrain of the Yangtze craton: evidence for cratonic evolution and redistribution of REE during crustal anatexis[J]. Geochimica et Cosmochimica Acta, 1999, 63(13/14): 2071-2088. http://www.sciencedirect.com/science/article/pii/S0016703799001532
[48] Sugisaki R, Yamamoto K, Adachi M. Triassic bedded cherts in central Japan are not pelagic[J]. Nature, 1982, 298(5875): 644-647. doi: 10.1038/298644a0
[49] Murray R W, Buchholtz T B, Marilyn R, et al. Rare earth elements as indicators of different marine depositional environments in chert and shale[J]. Geology, 1990, 18(3): 268. doi: 10.1130/0091-7613(1990)018<0268:REEAIO>2.3.CO;2
[50] Brookins D G. Aqueous geochemistry of rare earth elements[J]. Reviews in Mineralogy and Geochemistry, 1989, 21(1): 201-225.
[51] 刘平, 廖友常, 张雅静. 黔中-渝南石炭纪铝土矿含矿岩系中的海相沉积特征[J]. 中国地质, 2015, 42(2): 641-654 doi: 10.3969/j.issn.1000-3657.2015.02.022
[52] 刘长龄, 覃志安. 我国铝土矿中微量元素的地球化学特征[J]. 沉积学报, 1991, (2): 25-33. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB199102002.htm
[53] 巴多西G. 等著, 顾皓民, 等译, 红土型铝土矿[M]. 沈阳: 辽宁科学技术出版社, 1993.
[54] 张启明, 江新胜, 秦建华, 等. 黔北-渝南地区中二叠世早期梁山组的岩相古地理特征和铝土矿成矿效应[J]. 地质通报, 2012, 31(4): 558-568. doi: 10.3969/j.issn.1671-2552.2012.04.009 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20120409&flag=1
[55] 刘平, 廖友常. 黔中-渝南沉积型铝土矿区域成矿模式及找矿模型[J]. 中国地质, 2014, 41(6): 2063-2082. doi: 10.3969/j.issn.1000-3657.2014.06.020
-
