Potential evaluation of geothermal resources: exemplifying some municipalities and key strata in Ordos Basin as a study case
-
摘要:
针对鄂尔多斯盆地地热资源储量认识不统一、浅层地热能开发方式不明确、地热资源有利层位及有利区划定有分歧的3个问题,采用不同的评价方法分别对鄂尔多斯盆地水热型地热资源、浅层地热能和干热岩型地热资源进行了潜力和远景评估,结合地热资源的开发利用方式和效益对鄂尔多斯盆地的地热资源进行了综合分析。分析结果表明,鄂尔多斯盆地地热资源相对丰富,盆地内部分层位水热型地热资源量折合标准煤249.4×108 t,地热资源年可开采量折合标准煤748.1×104 t;7个地级以上城市浅层地热能资源年可采量折合标准煤281.2×104 t;干热岩潜力资源量折合标准煤16.63×1012 t。盆地内部地热资源有利区主要分布于榆林-横山-靖边及子长-安塞-延安一带。目前鄂尔多斯盆地0~200 m浅层地热能开发主要以地埋管地源热泵为主,地下水源热泵为辅。200~6000 m中深层地热资源开发主要以深埋管换热方式和采灌结合方式开采。开发地热能,节能减排效果明显,值得大力推广。
Abstract:There exists debate in the geothermal field of Ordos Basin, including ambiguous understanding of geothermal resources reserves, nubilous development mode of shallow geothermal energy and difference in the delimitation of favorable horizon and prospects.Different evaluation methods were used to evaluate the potential and prospect of hydrothermal geothermal resources, shallow geothermal energy and dry hot rock geothermal resources in Ordos Basin.Combined with the development mode and benefit of geothermal resources, the geothermal resources in Ordos Basin was comprehensively analyzed.The analysis results show that Ordos Basin is relatively rich geothermal resources.The geothermal resources of hydrothermal type is equivalent to 24.94 billion tons of standard coal.The annual exploitable amount of geothermal resources is equivalent to 7.481 million tons of standard coal.The annual recoverable amount of shallow geothermal energy resources in 7 cities above prefecture level is equivalent to 2.812 million tons of standard coal, and the potential resources of dry hot rock are equivalent to 16.63 trillion tons of standard coal.The favorable areas of geothermal resource in the basin are mainly distributed in Yulin City -Hengshan County-Jingbian County and Zichang County Ansai County Yan'an City.At present, the development of 0~200 m shallow geothermal energy in Ordos Basin is mainly based on ground source heat pump, supplemented by ground water source heat pump.The development of 200~6000 m deep geothermal resource is mainly by the way of deep buried pipe heat exchange and the combination of mining and irrigation.Because of the obvious effect of geothermal energy development, energy conservation and emission reduction, it is worth promoting vigorously.
-
-
图 5 U型水平对接管式取热系统[23]
Figure 5.
图 6 采灌结合地热梯级开发利用模式图(据参考文献[25]修改)
Figure 6.
表 1 鄂尔多斯盆地地级市浅层地热能热容量、换热功率计算(考虑土地利用系数)
Table 1. Calculation of heat capacity and heat transfer rate of shallow geothermal resource in Ordos Basin
城市 评价面积/km2 200 m以浅热容量/1013kJ 地下水源热泵换热功率/106 kW 地埋管地源热泵总换热功率/106 kW 地源热泵系统换热功率/106 kW 夏季制冷 冬季供暖 夏季制冷 冬季供暖 夏季制冷 冬季供暖 来源 鄂尔多斯市 121.60 4.73 0.00 0.00 1.68 0.49 1.68 0.49 本文 庆阳 23.50 1.92 0.00 0.00 0.43 0.20 0.43 0.20 本文 平凉市 32.00 3.81 0.00 0.00 0.60 0.27 0.60 0.27 本文 固原市 72.76 6.37 0.00 0.00 1.30 0.65 1.30 0.65 本文 榆林 395.40 9.30 0.00 0.00 5.28 1.96 5.28 1.96 [18] 延安 86.31 3.89 0.00 0.00 1.61 0.79 1.61 0.79 [18] 铜川 123.83 5.94 \ \ \ \ 1.83 1.19 [18] 表 2 浅层地热能潜力评价结果
Table 2. Evaluation results of shallow geothermal energy potential
城市 地下水源热泵供暖和制冷面积/107 m2 地埋管地源热泵供暖和制冷面积/107 m2 地源热泵供暖和制冷面积/107 m2 夏季制冷 冬季供暖 夏季制冷 冬季供暖 夏季制冷 冬季供暖 鄂尔多斯市 0 0 1.6213 0.6627 1.6213 0.6627 庆阳市 0 0 0.4141 0.2665 0.4141 0.2665 平凉市 0 0 0.5837 0.3574 0.5837 0.3574 固原市 0 0 1.2598 0.8751 1.2598 0.8751 榆林市 0 0 5.1014 2.6309 5.1014 2.6309 延安市 0 0 1.5556 1.0604 1.5556 1.0604 铜川市 \ \ \ \ 1.7681 1.5973 表 3 鄂尔多斯盆地主要层位中低温地热资源评价
Table 3. Evaluation of moderate and low-temperature geothermal resource of main horizons in Ordos Basin
主要层位 砂体体积/1012 m3 地层总热量 地热资源可采量 地热水资源量/(1011 m3) 地热流体可开采量/(108 m3·a-1) 地热水热能/1016kcal 地热流体可开采热量 考虑回灌条件下地热流体可采量/(109 m3·a-1) 考虑回灌条件下地热流体可开采热量 地层热量/1017 kcal 换算标煤/108 t 地热流体可采量/1013 kcal 换算标煤/108 t 地热水热能/1016 kcal 热水储能换算标准煤/108 t 地热流体可开采量/(1012 kcal·a-1) 换算标准煤/(104 t·a-1) 考虑回灌条件下地热流体可开采热量/(1014 kcal·a-1) 换算标准煤/(104 t·a-1) 富县 1.612 0.330 47.157 3.301 0.047 3.507 1.052 0.757 10.809 2.270 32.426 2.981 0.643 918.737 延安组 13.401 2.745 392.090 27.446 0.392 8.630 2.589 1.862 26.598 5.585 79.793 7.336 1.583 2260.792 延长组 44.146 18.293 2613.221 182.925 2.613 19.548 5.864 8.532 121.886 25.596 365.658 16.616 7.252 10360.323 下石盒子 5.533 4.827 689.640 48.275 0.690 2.077 0.623 1.909 27.267 5.726 81.802 1.765 1.622 2317.716 直罗组总 4.506 0.751 107.305 7.511 0.107 6.894 2.068 1.211 17.293 3.632 51.880 5.860 1.029 1469.946 奥陶 14.869 11.827 1689.582 118.271 1.690 3.803 1.141 3.186 45.514 9.558 136.543 3.232 2.708 3868.721 总计 84.067 38.022 5431.690 387.730 5.539 37.565 11.269 17.456 249.367 52.367 748.102 31.930 14.837 21196.235 表 4 鄂尔多斯盆地3~10 km深处干热岩资源
Table 4. Dry hot rock resources at the depth of 3~10 km in Ordos Basin
计算层位深度 干热岩资源量 干热岩可开采量(按2%可提取) 资源量/1019kJ 折合标准煤/1012 t 资源量/1018kJ 折合标准煤/1012 t 6.0~7.0 9.79 3.34 2.90 0.067 7.0~8.0 11.38 3.88 3.37 0.078 8.0~9.0 12.99 4.43 3.84 0.089 9.0~10.0 14.58 4.98 4.32 0.01 3.0~10.0 48.74 16.63 14.43 0.333 -
[1] 王贵玲, 张薇, 梁继运, 等. 中国地热资源潜力评价[J]. 地球学报, 2017, 38(4): 449-450, 134, 451-459. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201704002.htm
[2] 蔺文静, 刘志明, 王婉丽, 等. 中国地热资源及其潜力评估[J]. 中国地质, 2013, 40(1): 312-321. doi: 10.3969/j.issn.1000-3657.2013.01.021
[3] 尹立河, 侯光才, 张茂省, 等. 鄂尔多斯盆地地热系统[J]. 工程勘察, 2008, (2): 34-38. https://www.cnki.com.cn/Article/CJFDTOTAL-GCKC200802013.htm
[4] 霍改兰, 屈永清, 马少华, 等. 鄂尔多斯盆地地热资源形成条件研究[J]. 西部资源, 2011, 05): 67-69. https://www.cnki.com.cn/Article/CJFDTOTAL-XBZY201105044.htm
[5] 孔维臻. 地热资源开发利用经济评价研究[D]. 中国地质大学博士学位论文, 2013.
[6] 杨献忠, 李麟, 康丛轩, 等. 鄂尔多斯古陆金刚石成矿条件及找矿潜力[J]. 地质通报, 2019, 38(1): 22-26. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20190103&flag=1
[7] 任战利, 于强, 崔军平, 等. 鄂尔多斯盆地热演化史及其对油气的控制作用[J]. 地学前缘, 2017, 24(3): 137-148. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201703016.htm
[8] 任战利, 张盛, 高胜利, 等. 鄂尔多斯盆地构造热演化史及其成藏成矿意义[J]. 中国科学(D辑), 2007, (S1): 23-32. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2007S1003.htm
[9] 祁凯. 鄂尔多斯盆地中-新生代热体制及岩石圈动力演化初探[D]. 西北大学硕士学位论文, 2018.
[10] 刘绍文, 王良书, 贾承造, 等. 中国中西部盆地区岩石圈热-流变学结构及其对前陆盆地成因演化的意义[J]. 地学前缘, 2008, (3): 113-122. doi: 10.3321/j.issn:1005-2321.2008.03.008
[11] 庞忠和, 李义曼, 赵丰年, 等. 地热能术语(NB/T10097-2018)[S]. 北京: 中国石化出版社, 2019.
[12] 周阳, 邓念东, 王凤, 等. 浅层地热能适宜性分区结构的分形原理[J]. 中国地质调查, 2017, 4(1): 18-23. https://www.cnki.com.cn/Article/CJFDTOTAL-DZDC201701003.htm
[13] 王楠. 长春市城区浅层地热能评价及地下水源热泵采灌模式研究[D]. 吉林大学博士学位论文, 2016.
[14] 张薇, 王贵玲, 刘峰, 等. 中国沉积盆地型地热资源特征[J]. 中国地质, 2019, 46(2): 255-268. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201902005.htm
[15] 蔺文静, 刘志明, 马峰, 等. 我国陆区干热岩资源潜力估算[J]. 地球学报, 2012, 33(5): 807-811. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201205018.htm
[16] 汪集旸, 胡圣标, 庞忠和, 等. 中国大陆干热岩地热资源潜力评估[C]//中国科学院地质与地球物理研究所2012年度(第12届)学术年会, 2013.
[17] 任战利, 刘丽, 崔军平, 等. 盆地构造热演化史在油气成藏期次研究中的应用[J]. 石油与天然气地质, 2008, 29(4): 502-506. doi: 10.3321/j.issn:0253-9985.2008.04.013
[18] 周阳, 穆根胥, 刘建强, 等. 典型地貌单元浅层地热能资源量赋存规律[J]. 地质科技情报, 2018, 37(4): 232-238, 268. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201804032.htm
[19] 董秋生, 黄贤龙, 郎振海, 等. 废弃油井改造为地热井技术分析[J]. 探矿工程(岩土钻掘工程), 2016, 43(6): 18-21. doi: 10.3969/j.issn.1672-7428.2016.06.004
[20] 甄华, 莫中浩. 报废油井改造成地热井的方法[J]. 煤气与热力, 2007, 27(1): 47-50. doi: 10.3969/j.issn.1000-4416.2007.01.013
[21] 刘峰, 王贵玲, 张薇, 等. 江西宁都县北部大地热流特征及地热资源成因机制[J]. 地质通报, 2020, 39(12): 1883-1890. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20201202&flag=1
[22] Majer E L, Baria R, Stark M, et al. Induced seismicity associated with Enhanced Geothermal Systems[J]. Geothermics, 2007, 36(3): 185-222. doi: 10.1016/j.geothermics.2007.03.003
[23] 任文波. 渭河盆地中深层地热资源特征及开发利用[D]. 西北大学硕士学位论文, 2019.
[24] 王贵玲, 张发旺, 刘志明. 国内外地热能开发利用现状及前景分析[J]. 地球学报, 2000, 21(2): 134-139. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB200002003.htm
[25] 马伟斌, 龚宇烈, 赵黛青, 等. 我国地热能开发利用现状与发展[J]. 中国科学院院刊, 2016, 31(2): 199-207. https://www.cnki.com.cn/Article/CJFDTOTAL-KYYX201602008.htm
① 任战利,任文波,刘润川,等.鄂尔多斯盆地地热资源调查分布评价成果报告.中国地质调查局西安地质调查中心合作项目,2018.
② 任战利,任文波,刘润川,等.陕西地热资源调查分布评价报告.陕西延长石油(集团)有限责任公司研究院合作项目,2017.
③ 西安西大科技工程研究院.陕西省地热资源开发利用评价.陕西西安:陕西延长石油(集团)有限责任公司研究院,2017.
-
