Geochemistry and zircon U-Pb age of the Permian radial diabase dyke from southern Xinyuan area, Western Tianshan Mountains, Xinjiang, and their geological significance
-
摘要:
南天山古洋盆闭合、碰撞造山时限等洋-陆格局的演化过程是西天山备受关注的地球动力学问题，紧邻那拉提北缘断裂的新源地区二叠纪放射状辉绿岩墙提供了解决这个问题的良好机会。新源地区辉绿岩具辉绿结构，斑晶为斜长石和普通辉石，基质主要由斜长石、辉石、绿泥石等副矿物组成。岩石为富钠贫钾、过铝质、钙碱性岩浆系列。辉绿岩岩墙富集Rb、Th和La等元素，明显亏损Nb、Ta等元素，显示εNd（t）为正值（+3.3~+3.8）和低的初始锶比值（（87Sr/86Sr）i=0.70479~0.70548），幔源物质明显。与该区石炭纪玄武岩地球化学性质相似，岩浆可能为二叠纪软流圈和岩石圈相互作用的产物，其起源与软流圈上涌有关。辉绿岩岩墙LA-ICP-MS锆石U-Pb年龄为280.4±3.6Ma，被解释为岩脉成岩年龄，即岩脉形成于二叠纪。结合区域构造背景，推测辉绿岩岩脉形成于塔里木地块与中天山-伊犁地块碰撞闭合后的板内伸展环境，并与南天山洋洋壳岩石圈板块断离密切相关。
-
关键词:
- 辉绿岩岩墙 /
- 二叠纪 /
- 岩石成因 /
- LA-ICP-MS锆石U-Pb年龄 /
- 新疆西天山
Abstract:The accretionary processes of the Western Tianshan Mountains is a hot topic but there is no consensus on the final closure of the Paleo-South Tianshan Ocean basin and subsequent post-collision process. The Permian radial diabase dyke exposed near the North Nalati Fault provides an opportunity for understanding these problems. The dyke shows a typical ophitic texture. The phenocryst is composed of plagioclase and pyroxene, and the substrate is mainly composed of plagioclase, pyroxene, chlorite and some other accessory minerals. The diabase dyke hassodium-rich, potassium-poor and peraluminous characteristics, and hence belongs to the calc-alkaline series. The dyke is characterized by depletion of Nb and Ta and enrichment of Rb, Th and La, and has mantle source material with positive εNd(t) values (+ 3.3~+ 3.8) and low initial Sr((879Sr/86Sr)i=0.70479~0.70548)). These geochemical characteristics are similar to those of the Carboniferous basalt of the study area, suggesting that the parental magma was formed by the interaction of asthenosphere and lithosphere. Zircon U-Pb dating of the dyke yielded an age of 280.4 ±3.6Ma. Combined with regional tectonic background, the authors hold that these Permian diabaseswere formed fromintraplate extension after the collision stage which was closely related to the oceanic lithosphere break-off.
-
-
图 6 新源南部辉绿岩墙稀土元素球粒陨石标准化配分模式（a）、微量元素原始地幔标准化蛛网图（b）和锆石稀土元素球粒陨石配分模式图（c）（大哈拉军山组火山岩数据据参考文献[58]）
Figure 6.
表 1 新源南部辉绿岩墙LA-ICP-MS锆石U-Th-Pb同位素测定结果
Table 1. LA-ICP-MS U-Th-Pb data for zircons from diabase dyke in southern Xinyuan area
样点编号 元素含量/10-6 Th/U 同位素比值 年龄/Ma 238U 232Th 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 20-01 1418 4294 3.03 0.054 0.002 0.338 0.012 0.045 0.001 283.9 6.1 392.6 96.5 20-02 4436 13171 2.97 0.052 0.001 0.327 0.007 0.046 0.001 286.6 5.8 298.1 71.8 20-03 1431 3606 2.52 0.056 0.002 0.347 0.010 0.045 0.001 282.9 5.9 456.3 79.6 20-04 1302 2207 1.69 0.053 0.002 0.336 0.010 0.045 0.001 285.0 5.9 367.3 84.4 20-05 2388 7741 3.24 0.055 0.001 0.333 0.008 0.043 0.001 272.3 5.5 451.8 72.9 20-06 1605 3262 2.03 0.053 0.001 0.325 0.008 0.044 0.001 280.5 5.7 329.9 76.7 20-07 4354 16456 3.78 0.053 0.001 0.334 0.008 0.045 0.001 285.0 5.7 356.5 72.5 20-08 20389 5304 2.60 0.058 0.002 0.349 0.010 0.044 0.001 275.8 5.7 531.3 79.7 20-09 771 1167 1.51 0.051 0.002 0.312 0.013 0.044 0.001 279.7 6.0 245.8 106.5 20-10 2198 5204 2.37 0.052 0.002 0.314 0.009 0.043 0.001 274.0 5.7 306.0 86.0
下载: 导出CSV
表 2 新源南部辉绿岩墙主量、微量及稀土元素组成
Table 2. Major, trace elements and REE data for diabase dyke in southern Xinyuan area
样品号 HSX-1 HSX-3 HSX-4 HSX-5 HSX-6 SiO2 47.72 47.47 47.46 47.64 47.45 TiO2 3.13 3.32 3.34 3.30 3.55 Al2O3 14.04 13.70 13.70 13.52 13.67 Fe2O3 13.77 8.68 7.50 8.61 10.05 FeO 2.65 7.90 8.34 7.82 6.84 MnO 0.22 0.24 0.26 0.24 0.23 MgO 5.19 5.44 5.51 5.44 4.93 CaO 8.76 8.60 9.51 9.12 8.81 Na2O 3.06 2.98 2.85 2.84 2.97 K2O 0.80 0.97 0.82 0.78 0.74 P2O5 0.66 0.70 0.71 0.70 0.75 烧失量 2.26 2.74 2.13 2.07 3.30 Rb 29.80 40.60 39.90 38.00 32.90 Ba 321 340 270 311 399 Th 2.65 2.53 2.44 2.77 2.80 U 0.86 0.83 0.88 0.91 0.99 Nb 6.40 6.84 6.78 7.34 8.11 Ta 0.64 0.61 0.59 0.66 0.69 Sr 334 318 321 317 324 Zr 341 349 336 386 413 Hf 9.04 9.48 9.12 10.40 10.60 Y 51.40 52.50 55.60 63.20 64.50 La 17.90 20.50 19.40 23.30 24.70 Ce 44.50 48.10 47.60 55.60 54.60 Pr 6.28 7.31 6.97 8.30 8.37 Nd 30.70 34.10 33.50 38.30 39.00 Sm 8.24 9.47 9.31 10.60 10.90 Eu 3.13 3.36 3.13 3.41 3.61 Gd 7.67 8.72 8.67 9.68 10.3 Tb 1.57 1.77 1.7 1.91 1.99 Dy 9.74 10.7 10.7 11.9 12.3 Ho 2.02 2.22 2.26 2.52 2.52 Er 5.21 5.51 5.73 6.06 6.28 Tm 1.04 1.09 1.09 1.24 1.22 Yb 6.03 6.34 6.39 7.13 7.28 Lu 0.84 0.88 0.90 0.98 0.96 注：锆石单矿物从HXS-1样品中挑选；主量元素含量单位为%，微量和稀土元素含量单位为10-6
下载: 导出CSV
表 3 新源南部辉绿岩墙Sr-Nd同位素组成
Table 3. Sr-Nd isotopic compositions ofdiabasedyke in southern Xinyuan area
样品号 HXS-1 HXS-3 HXS-4 HXS-5 HXS-6 87Rb/86Sr 0.304 0.439 0.394 0.371 0.319 87Sr/86Sr 0.706695 0.707055 0.706770 0.706275 0.756585 147Sm/144Nd 0.1684 0.1676 0.1686 0.1690 0.1671 143Nd/144Nd 0.512766 0.512756 0.512779 0.512759 0.512795 (87Sr/86Sr)i 0.70548 0.70530 0.70520 0.70479 0.75531 (143Nd/144Nd)i 0.512457 0.512448 0.512470 0.512449 0.512488 εNd(t) 3.5 3.3 3.8 3.4 4.1 fSm/Nd -0.14 -0.15 -0.14 -0.14 -0.15 tDM 1297 1307 1259 1338 1166 注：(147Sm/144Nd)CHUR=0.1967, (143Nd/144Nd)CHUR=0.512638, (87Rb/86Sr)CHUR=0.0847, (87Sr/86Sr)CHUR=0.7047, 计算辉绿岩墙的εNd(t)和tDM时T=280.4Ma
下载: 导出CSV
-
[1] Walker G P L, Eyre P R. Dike complexes in American Samoa[J]. Journal of volcanology and geothermal research, 1995, 69(3):241-254.
[2] Windley B F. The evolving continents[M]. John Wiley and Sons, 1984.
[3] 李献华, 胡瑞忠.粤北白垩纪基性岩脉的年代学和地球化学[J].地球化学, 1997, 26(2):14-31. doi: 10.3321/j.issn:0379-1726.1997.02.004
[4] 侯贵廷, 李江海, Halls H C, 等.华北晚前寒武纪铁镁质岩脉的流动构造和侵位机制[J].地质学报, 2003, 77(2):210-215 doi: 10.3321/j.issn:0001-5717.2003.02.009
[5] 董传万, 张登荣, 徐夕生, 等.福建晋江中-基性岩脉的锆石SHRIMP U-Pb定年和岩石地球化学[J].岩石学报, 2006, 22(6):1696-1702
[6] Thompson R N, Gibson S A, Dickin A P, et al. Early Cretaceous basalt and picrite dykes of the southern Etendeka region, NW Namibia:windows into the role of the Tristan mantle plume in Paraná-Etendekamagmatism[J]. Journal of Petrology, 2001, 42(11):2049-2081. doi: 10.1093/petrology/42.11.2049
[7] Chen B, Zhai M. Geochemistry of late Mesozoic lamprophyre dykes from the Taihang Mountains, north China, and implications for the sub-continental lithospheric mantle[J]. Geological Magazine, 2003, 140(1):87-93. doi: 10.1017/S0016756802007124
[8] Xiao W J, Zhang L C, Qin K Z, et al. Paleozoic accretionary and collisional tectonics of the Eastern Tianshan (China):implications for the continental growth of central Asia[J]. American Journal of Science, 2004, 304(4):370-395. doi: 10.2475/ajs.304.4.370
[9] Gao J, Long L, Klemd R, et al. Tectonic evolution of the South Tianshanorogen and adjacent regions, NW China:geochemical and age constraints of granitoid rocks[J]. International Journal of Earth Sciences, 2009, 98(6):1221-1238. doi: 10.1007/s00531-008-0370-8
[10] Coleman R G. Continental growth of northwest China[J]. Tectonics, 1989, 8(3):621-635. doi: 10.1029/TC008i003p00621
[11] Allen M B, Windley B F, Zhang C. Palaeozoic collisional tectonics and magmatism of the Chinese Tien Shan, central Asia[J]. Tectonophysics, 1993, 220(1):89-115. http://cn.bing.com/academic/profile?id=e5e3738ee0790f6251d682c3628db26d&encoded=0&v=paper_preview&mkt=zh-cn
[12] 车自成, 刘洪福, 刘良.中天山造山带的形成与演化[M].北京:地质出版社, 1994:1-135.
[13] Gao J, John T, Klemd R, et al. Mobilization of Ti-Nb-Ta during subduction:evidence from rutile-bearing dehydration segregations and veins hosted in eclogite, Tianshan, NW China[J]. Geochimica et Cosmochimica Acta, 2007, 71(20):4974-4996. doi: 10.1016/j.gca.2007.07.027
[14] Gao J, Klemd R. Formation of HP-LT rocks and their tectonic implications in the western TianshanOrogen, NW China:geochemical and age constraints[J]. Lithos, 2003, 66(1):1-22. http://cn.bing.com/academic/profile?id=3c79cf8637f01bed0502d208eaf1a2d4&encoded=0&v=paper_preview&mkt=zh-cn
[15] 夏林圻, 张国伟, 夏祖春, 等.天山古生代洋盆开启, 闭合时限的岩石学约束[J].地质通报, 2002, 21(2):55-62. doi: 10.3969/j.issn.1671-2552.2002.02.002 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20020220&flag=1
[16] 高俊, 龙灵利, 钱青, 等.南天山:晚古生代还是三叠纪碰撞造山带?[J].岩石学报, 2006, (5):3-15. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200812010
[17] 李锦轶, 何国琦, 徐新, 等.新疆北部及邻区地壳构造格架及其形成过程的初步探讨[J].地质学报, 2006, (1):150-170. http://d.old.wanfangdata.com.cn/Periodical/dizhixb200601017
[18] Su W, Gao J, Klemd R, et al. U-Pb zircon geochronology of Tianshaneclogites in NW China:implication for the collision between the Yili and Tarim blocks of the southwestern Altaids[J]. European Journal of Mineralogy, 2010, 22(4):473-478. doi: 10.1127/0935-1221/2010/0022-2040
[19] 李曰俊, 宋文杰, 买光荣, 等.库车和北塔里木前陆盆地与南天山造山带的耦合关系[J].新疆石油地质, 2001, 22(5):376-381. doi: 10.3969/j.issn.1001-3873.2001.05.004
[20] 张立飞, 艾永亮, 李强, 等.新疆西南天山超高压变质带的形成与演化[J].岩石学报, 2005, 4:1029-1038. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200504001
[21] 肖文交, 韩春明, 袁超, 等.新疆北部石炭纪-二叠纪独特的构造-成矿作用:对古亚洲洋构造域南部大地构造演化的制约[J].岩石学报, 2006, (5):16-30. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200605002
[22] Zhang L, Ai Y, Li X, et al. Triassic collision of western Tianshanorogenic belt, China:evidence from SHRIMP U-Pb dating of zircon from HP/UHP eclogiticrocks[J]. Lithos, 2007, 96(1):266-280.
[23] 李天福, 杨军臣.天山西段木札尔特河和独库公路沿线火山岩与晚古生代板块构造的关系[J].西北地质科学, 1997, 18(2):11-20. http://www.cnki.com.cn/Article/CJFDTotal-XBFK199702001.htm
[24] 陈丹玲, 刘良, 车自成, 等.中天山骆驼沟火山岩的地球化学特征及其构造环境[J].岩石学报, 2001, 17(3):378-384. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200103005
[25] 车自成, 刘良, 刘洪福, 等.论伊犁古裂谷[J].岩石学报, 1996, 12(3):478-490. doi: 10.3321/j.issn:1000-0569.1996.03.014
[26] 夏林圻, 张国伟, 夏祖春, 等.天山古生代洋盆开启、闭合时限的岩石学约束——来自震旦纪、石炭纪火山岩的证据[J].地质通报, 2002, 21(2):55-62. doi: 10.3969/j.issn.1671-2552.2002.02.002 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20020220&flag=1
[27] 夏林圻, 夏祖春, 徐学义, 等.天山石炭纪大火成岩省与地幔柱[J].地质通报, 2004, 23(9/10):903-910. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=200409162&flag=1
[28] 夏林圻, 李向民, 夏祖春, 等.天山石炭-二叠纪大火成岩省裂谷火山作用与地幔柱[J].西北地质, 2006, 39(1):1-49. doi: 10.3969/j.issn.1009-6248.2006.01.001
[29] Xia L Q, Xu X Y, Xia Z C, et al. Petrogenesis of Carboniferous rift-related volcanic rocks in the Tianshan, northwestern China[J]. Geological Society of America Bulletin, 2004, 116(3/4):419-433. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=f7c27b3c9f79fa077dd0284ce3a343fc
[30] 姜常义, 吴文奎, 张学仁, 等.从岛弧向裂谷的变迁——来自阿吾拉勒地区火山岩的证据[J].岩石矿物学杂志, 1995, 14(4):289-300. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199500805007
[31] 赵振华, 白正华, 熊小林, 等.西天山北部晚古生代火山-浅侵位岩浆岩40Ar/39Ar同位素定年[J].地球化学, 2003, 32(4):317-327. doi: 10.3321/j.issn:0379-1726.2003.04.003
[32] 朱永峰, 张立飞, 古丽冰, 等.西天山石炭纪火山岩SHRIMP年代学及其微量元素地球化学研究[J].科学通报, 2005, 50(18):2004-2014. doi: 10.3321/j.issn:0023-074X.2005.18.014
[33] Zhu Y, Zhang L, Gu L, et al. The zircon SHRIMP chronology and trace element geochemistry of the Carboniferous volcanic rocks in western TianshanMountains[J]. Chinese Science Bulletin, 2005, 50(19):2201-2212. doi: 10.1007/BF03182672
[34] Zhu Y F, Xuan G, Song B, et al. Petrology, Sr-Nd-Hf isotopic geochemistry and zircon chronology of the Late Palaeozoic volcanic rocks in the southwestern Tianshan Mountains, Xinjiang, N W China[J]. Journal of the Geological Society, London, 2009, 166:1085-1099. doi: 10.1144/0016-76492008-130
[35] 钱青, 高俊, 熊贤明, 等.西天山昭苏北部石炭纪火山岩的岩石地球化学特征, 成因及形成环境[J].岩石学报, 2006, 22(5):1307-1323. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200605020
[36] 王博, 舒良树, Cluzel D, 等.新疆伊犁北部石炭纪火山岩地球化学特征及其地质意义[J].中国地质, 2006, 33(3):498-508. doi: 10.3969/j.issn.1000-3657.2006.03.006
[37] Wang B, Shu L S, Cluzel D, et al. Geochemical constraints on Carboniferous volcanic rocks of the Yili Block (Xinjiang, NW China):implication for the tectonic evolution of Western Tianshan[J]. Journal of Asian Earth Sciences, 2007, 29(1):148-159. doi: 10.1016/j.jseaes.2006.02.008
[38] Wang B, Cluzel D, Shu L S, et al. Evolution of calc-alkaline to alkaline Magmatism through Carboniferous convergence to Permian transcurrent tectonics, western Chinese Tianshan[J]. International Journal of Earth Sciences, 2009, 98(6):1275-1298. doi: 10.1007/s00531-008-0408-y
[39] 龙灵利, 高俊, 钱青, 等.西天山伊犁地区石炭纪火山岩地球化学特征及构造环境[J].岩石学报, 2008, (4):77-88. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200804009
[40] Biske Y S, Seltmann R. Paleozoic Tian-Shan as a transitional region between the Rheic and Urals-Turkestan oceans[J]. Gondwana Research, 2010, 17(2):602-613. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=a7c532ee3da24b57dffa28b9ef71467b
[41] 薛春纪, 赵晓波, 莫宣学, 等.西天山巨型金铜铅锌成矿带构造成矿演化和找矿方向[J].地质学报, 2014, 88(12):2490-2531. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201412025
[42] 薛春纪, 赵晓波, 莫宣学, 等.西天山"亚洲金腰带"及其动力背景和成矿控制与找矿[J].地学前缘, 2014, 21(5):128-155. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201405011
[43] 朱志新, 李锦轶, 董连慧, 等.新疆西天山古生代侵入岩的地质特征及构造意义[J].地学前缘, 2011, 18(2):170-179. http://d.old.wanfangdata.com.cn/Periodical/dxqy201102015
[44] 杨天南, 李锦轶, 孙桂华, 等.中天山早泥盆世陆弧:来自花岗质糜棱岩地球化学及SHRIMP U/Pb定年的证据[J].岩石学报, 2006, 22(1):41-48. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200601004
[45] 龙灵利, 高俊, 雄贤明, 等.新疆中天山南缘比开(地区)花岗岩地球化学特征及年代学研究[J].岩石学报, 2007, 23(4):719-732. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200704004
[46] 朱志新, 王克卓, 郑玉洁, 等.新疆伊犁地块南缘志留纪和泥盆纪花岗质侵入体锆石SHRIMP定年及其形成时构造背景的初步探讨[J].岩石学报, 2006, 22(5):1193-1200. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200605011
[47] 韩宝福, 何国琦, 吴泰然, 等.天山早古生代花岗岩锆石U-Pb定年、岩石地球化学特征及其大地构造意义[J].新疆地质, 2004, 22(1):4-11. doi: 10.3969/j.issn.1000-8845.2004.01.002
[48] 朱永峰, 安芳, 薛云兴, 等.西南天山特克斯科桑溶洞火山岩的锆石U-Pb年代学研究[J].岩石学报, 2010, 26:2255-2263. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201008003
[49] 薛云兴, 朱永峰.西南天山哈拉达拉岩体的锆石SHRIMP年代学及地球化学研究[J].岩石学报, 2009, 25(6):1353-1363. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200906007
[50] 张招崇, 董书云, 黄河, 等.西南天山二叠纪中酸性侵入岩的地质学和地球化学:岩石成因和构造背景[J].地质通报, 2009, 28(12):1827-1839. doi: 10.3969/j.issn.1671-2552.2009.12.015 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20091214&flag=1
[51] 齐进英.新疆准噶尔脉岩群地质及成因[J].岩石学报, 1993, 9(3):287-299. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB199303006.htm
[52] 李辛子, 韩宝福, 季建清, 等.新疆克拉玛依中基性岩墙群的地质地球化学和K-Ar年代学[J].地球化学, 2004, 33(6):574-584. doi: 10.3321/j.issn:0379-1726.2004.06.005
[53] 欧阳征健, 周鼎武, 林晋炎, 等.博格达山白杨河地区中基性岩墙地球化学特征及其地质意义[J].大地构造与成矿学, 2006, 30(4):495-503. doi: 10.3969/j.issn.1001-1552.2006.04.012
[54] Tang G J, Wang Q, Derek A. Wyman, et al. Metasomatized lithosphere-asthenosphere interaction during slab roll-back:Evidence from Late Carboniferous gabbros in the Luotuogou area, Central Tianshan[J]. Lithos, 2012, 155:67-80. doi: 10.1016/j.lithos.2012.08.015
[55] 林靓, 钱青, 王艳玲, 等.西天山昭苏北部大哈拉军山组火山岩中辉长岩体的形成时代、地球化学特征及地质意义[J].岩石学报, 2015, 31(6):1749-1760. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201506018
[56] 龙灵利, 王玉往, 唐萍芝, 等.西天山CuNi_VTiFe复合型矿化镁铁-超镁铁杂岩-哈拉达拉岩体成岩成矿背景特殊性讨论[J].岩石学报, 2012, 28(7):2015-2028.
[57] 赵长缨, 荆振华, 王惠民, 等.新疆新源县一带大哈拉军山组火山岩形成环境探讨[J].陕西地质, 2006, 24(1):37-44. doi: 10.3969/j.issn.1001-6996.2006.01.004
[58] 郭璇, 朱永峰.新疆新源县城南石炭纪火山岩岩石学和元素地球化学研究[J].高校地质学报, 2006, 12(1):62-73. doi: 10.3969/j.issn.1006-7493.2006.01.007
[59] Yuan H, Wu F, Gao S, et al. Determination of U-Pb age and rare earth element concentrations of zircons from Cenozoic intrusions in northeastern China by laser ablation ICP-MS[J]. Chinese Science Bulletin, 2003, 48(22):2411-2421. http://cn.bing.com/academic/profile?id=02d06a466e2667e6b327cd3678adec7d&encoded=0&v=paper_preview&mkt=zh-cn
[60] Yuan H, Gao S, Liu X, et al. Accurate U-Pb age and trace element determinations of zircon by laser ablation-inductively coupled plasma-mass spectrometry[J]. Geostandards and Geoanalytical Research, 2004, 28(3):353-370. doi: 10.1111/ggr.2004.28.issue-3
[61] 闫欣, 许荣华.等离子体质谱法测定岩石中的锆, 铪, 铌, 钽[J].矿物岩石地球化学通报, 2001, 20(4):458-460. doi: 10.3969/j.issn.1007-2802.2001.04.072
[62] Zhang H, Gao S, Zhong Z, et al. Geochemical and Sr-Nd-Pb isotopic compositions of Cretaceous granitoids:constraints on tectonic framework and crustal structure of the Dabieshan ultrahigh-pressure metamorphic belt, China[J]. Chemical Geology, 2002, 186(3):281-299. http://cn.bing.com/academic/profile?id=f54e7e62d1376c060ed965e5e163cfeb&encoded=0&v=paper_preview&mkt=zh-cn
[63] Rubatto D. Zircon trace element geochemistry:partitioning with garnet and the link between U-Pb ages and metamorphism[J]. Chemical Geology, 2002, 184(1):123-138.
[64] Rudnick R L, Fountain D M. Nature and composition of the continental crust:a lower crustal perspective[J]. Reviews of geophysics, 1995, 33(3):267-309. doi: 10.1029/95RG01302
[65] 吴元保, 郑永飞.锆石成因矿物学研究及其对U-Pb年龄解释的制约[J].科学通报, 2004, 49(16):1589-1604. doi: 10.3321/j.issn:0023-074X.2004.16.002
[66] Smith R E, Smith S E. Comments on the use of Ti, Zr, Y, Sr, K, P and Nb in classification of basaltic magmas[J]. Earth and planetary science letters, 1976, 32(2):114-120. doi: 10.1016/0012-821X(76)90049-2
[67] Zhou J X. Geochemistry and Petrogenesis of Igneous Rocks Containing Amphibole and Mica:A Case Study of Plate Collision Involving Scotland and Himalayas[J]. Science Press, 1999:41-72.
[68] Wilson BM. Igneous petrogenesis a global tectonic approach[M]. Springer Science & Business Media, 2007.
[69] Hoskin P W O, Schaltegger U. The composition of zircon and igneous and metamorphic petrogenesis[J]. Reviews in mineralogy and geochemistry, 2003, 53(1):27-62. doi: 10.2113/0530027
[70] Wang Q, Zhu D C, Zhao Z D, et al. Magmatic zircons from I-, S-and A-type granitoids in Tibet:Trace element characteristics and their application to detrital zircon provenance study[J]. Journal of Asian Earth Sciences, 2012, 53:59-66. doi: 10.1016/j.jseaes.2011.07.027
[71] Hart S R, Davis K E. Nickel partitioning between olivine and silicate melt[J]. Earth and Planetary Science Letters, 1978, 40(2):203-219. doi: 10.1016/0012-821X(78)90091-2
[72] Samaniego P, Martin H, Robin C, et al. Transition from calcalkalic to adakiticmagmatism at Cayambe volcano, Ecuador:insights into slab melts and mantle wedge interactions[J]. Geology, 2002, 30(11):967-970. doi: 10.1130/0091-7613(2002)030<0967:TFCATA>2.0.CO;2
[73] Petterson M G, Treloar P J. Volcanostratigraphy of arc volcanic sequences in the Kohistan arc, North Pakistan:volcanism within island arc, back-arc-basin, and intra-continental tectonic settings[J]. Journal of Volcanology and Geothermal Research, 2004, 130(1):147-178. http://cn.bing.com/academic/profile?id=49b88e4e1b64cc0b50138d345d23c4a8&encoded=0&v=paper_preview&mkt=zh-cn
[74] Rollinson H R. Using geochemical data:evaluation, presentation, interpretation[M]. London:Longman Group UK, 2014:40-206
[75] Taylor S R, McLennan S M. The continental crust:its composition and evolution[M]. Oxford:Blackwell Scientific, 1985:312.
[76] Watson E B, Harrison T M. Zircon saturation revisited:temperature and composition effects in a variety of crustal magma types[J]. Earth and Planetary Science Letters, 1983, 64(2):295-304. doi: 10.1016/0012-821X(83)90211-X
[77] 张东阳, 张招崇, 艾羽, 等.西天山莱历斯高尔一带铜(钼)矿成矿斑岩年代学、地球化学及其意义[J].岩石学报, 2009, (6):1319-1331. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200906004
[78] 徐学义, 夏林圻, 马中平, 等.北天山巴音沟蛇绿岩斜长花岗岩SHRIMP锆石U-Pb年龄及蛇绿岩成因研究[J].岩石学报, 2006, 22(1):83-94. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200601009
[79] Xia L Q, Xia Z C, Xu X Y, et al. Carboniferous Tianshan igneous megaprovince and mantle plume[J]. Geological Bulletin of China, 2004, 23(9):903-910. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgqydz200409012
[80] Xia L Q, Xia Z C, Xu X Y, et al. Relative contributions of crust and mantle to the generation of the Tianshan Carboniferous riftrelated basic lavas, northwestern China[J]. Journal of Asian Earth Sciences, 2008, 31(4):357-378. http://cn.bing.com/academic/profile?id=c070039d5fec8680ac27e24635ec7d4e&encoded=0&v=paper_preview&mkt=zh-cn
[81] Chen B, Arakawa Y. Elemental and Nd-Sr isotopic geochemistry of granitoids from the West Junggarfoldbelt (NW China), with implications for Phanerozoic continental growth[J]. Geochimica et Cosmochimica Acta, 2005, 69(5):1307-1320. doi: 10.1016/j.gca.2004.09.019
[82] Han B F, He G Q, Wang X C, et al. Late Carboniferous collision between the Tarim and Kazakhstan-Yiliterranes in the western segment of the South Tian Shan Orogen, Central Asia, and implications for the Northern Xinjiang, western China[J]. EarthScience Reviews, 2011, 109(3):74-93. http://cn.bing.com/academic/profile?id=32767a69c06313d68df800be22d328ca&encoded=0&v=paper_preview&mkt=zh-cn
[83] Long L, Gao J, Klemd R, et al. Geochemical and geochronological studies of granitoid rocks from the Western TianshanOrogen:implications for continental growth in the southwestern Central Asian OrogenicBelt[J]. Lithos, 2011, 126(3):321-340. http://www.sciencedirect.com/science/article/pii/S0024493711002106
[84] 朱志新, 董连慧, 刘淑聪, 等.新疆西天山伊犁地块晚古生代火山岩地质特征及构造意义[J].新疆地质, 2012, 30(3):258-263. doi: 10.3969/j.issn.1000-8845.2012.03.003
[85] 刘松柏, 窦虎, 李海波, 等.新疆东天山博格达地区晚侏罗世中酸性侵入岩的发现、锆石U-Pb年龄及其地质意义[J].地质通报, 2019, 38(2/3):288-294. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=2019020311&flag=1
[86] 冯博, 计文化, 白建科, 等.西天山博罗科努地区志留系碎屑锆石U-Pb定年及其地质意义[J].地质通报, 2019, 38(2/3):276-287. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=2019020310&flag=1
-
