秘鲁西北部早白垩世Oyotún组火山岩层序、年代学及地球化学特征——对古Farallon板块俯冲作用细节的揭示

,  ,  ,  ,  ,

文章导航 > 地质通报 > 2017 > 36(12): 2243-2263

上一篇

下一篇

段政, 郭维民, 曾勇, 刘君安, AsteteIgor, GuerreroLeyla. 秘鲁西北部早白垩世Oyotún组火山岩层序、年代学及地球化学特征——对古Farallon板块俯冲作用细节的揭示[J]. 地质通报, 2017, 36(12): 2243-2263.
引用本文: 段政, 郭维民, 曾勇, 刘君安, AsteteIgor, GuerreroLeyla. 秘鲁西北部早白垩世Oyotún组火山岩层序、年代学及地球化学特征——对古Farallon板块俯冲作用细节的揭示[J]. 地质通报, 2017, 36(12): 2243-2263.
shu
DUAN Zheng, GUO Weimin, ZENG Yong, LIU Jun'an, ASTETE Igor, GUERRERO Leyla. Sequence, age and geochemistry of volcanic rocks of the Early Cretaceous Oyotún Formation in northwestern Peru: Revelation for the details of paleo-Farallon subduction[J]. Geological Bulletin of China, 2017, 36(12): 2243-2263.
Citation: DUAN Zheng, GUO Weimin, ZENG Yong, LIU Jun'an, ASTETE Igor, GUERRERO Leyla. Sequence, age and geochemistry of volcanic rocks of the Early Cretaceous Oyotún Formation in northwestern Peru: Revelation for the details of paleo-Farallon subduction[J]. Geological Bulletin of China, 2017, 36(12): 2243-2263.
shu

秘鲁西北部早白垩世Oyotún组火山岩层序、年代学及地球化学特征——对古Farallon板块俯冲作用细节的揭示

  • 1.

    中国地质调查局南京地质调查中心, 江苏 南京 210016

  • 2.

    秘鲁地质矿产冶金研究院(INGEMMET), 秘鲁 利马 15074

  • 基金项目:
    中国地质调查局项目《海上丝绸之路大洋洲和南美洲矿产资源潜力评价》（编号：DD20160110）
详细信息

  • 中图分类号: P534.53;P588.14

Sequence, age and geochemistry of volcanic rocks of the Early Cretaceous Oyotún Formation in northwestern Peru: Revelation for the details of paleo-Farallon subduction

  • 1.

    Nanjing Center, China Geological Survey, Nanjing 210016, Jiangsu, China

  • 2.

    Instituto Geológico Minero y Metalúrgico(INGEMMET), Lima 15074, Peru

    摘要

  • Oyotún组火山岩为中安第斯西北缘中生代出露范围最广的一套火山岩，对研究中安第斯早白垩世壳幔相互作用具有重要意义。研究区西部Oyotún组火山岩出露面积小，厚度薄，岩性单一，而东部出露范围大，厚度厚，岩性复杂。LA-ICP-MS锆石U-Pb定年表明，Oyotún组火山岩时代集中在139.7~131.0Ma之间。主量元素SiO2含量介于54.44%~72.33%之间，中等富MgO（0.56%~1.55%），偏铝-强过铝，A/CNK=0.98~3.51，富集Cs、Rb、Th、U、Pb和轻稀土元素，无明显Eu异常，亏损Nb、Ta、Ti、P等，具明显的火山弧特征。Oyotún组火山岩εHf（t）值在3.37~8.42之间，且底部εHf（t）值显著低于顶部，指示其可能形成于活动陆缘弧后伸展背景下，由亏损地幔衍生的新生玄武质下地壳，经板片流体作用而产生的低程度部分熔融过程，并受到太古宙古老陆壳物质的混染，其混染程度随时代变新而逐渐减小。

    The Oyotún Formation volcanic rocks are extremely widely distributed Mesozoic volcanic rocks in Northwestern Central Andes, and have important implications for understanding the Early Cretaceous crust-mantle interactions in Central Andes. The volcanic rocks are exposed in a small area with thin thickness and uniform lithology in the west, and are outcropped extensively with large thickness and more complex lithofacies in the west. LA-ICP-MS zircon U-Pb dating shows that the Oyotún volcanic rocks are concentrated in the range of 139.7~131.0Ma. Geochemically, the Oyotún Formation volcanic rocks show the SiO2 range from 54.44% to 72.33%, medium enrichment of MgO (0.56%~1.55%), metaluminous-strong peraluminous nature (A/CNK=0.98~3.51), enrichment of Cs, Rb, Th, U, Pb and LREE with indistinct negative europium anomalies, and depletion of Nb, Ta, Ti, P, suggesting obvious characteristics of volcanic arc. The εHf(t) of Oyotún Formation volcanic rocks are between 3.37 and 8.42, with the εHf(t) values at the bottom significantly lower than the values at the top, indicating that the rocks possibly originated from the process of low degree partial melting of the juvenile basaltic crust through the action of plate fluid, with the contamination of Archean ancient continent materials. The degree of contamination decreased when the ages became younger. The juvenile basaltic crust was probably derived from depleted mantle in an extension setting on the active continental margin.

    • HTML全文
  • 加载中

  • 图 1  秘鲁西北部Chiclayo地区地质简图

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  研究区中生代地层柱状对比

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 图版Ⅰ

    Figure 图版Ⅰ.

    下载: 全尺寸图片 幻灯片

    图 3  研究区Oyotún组火山岩锆石U-Pb年龄谐和图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  研究区东部Pucará地区Oyotún组火山岩锆石U-Pb年龄谐图

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  研究区Oyotún组火山岩TAS分类图解（a）[21]和SiO2-K2O分类图解（b）[22]（图a的岩石系列分界线据参考文献[23]）

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  研究区Oyotún组火山岩哈克图解

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  研究区Oyotún组火山岩原始地幔标准化微量元素蛛网图（a）与球粒陨石标准化稀土元素配分模式图（b）（原始地幔值据参考文献[24]；球粒陨石值据参考文献[25]）

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  研究区Oyotún组火山岩锆石206Pb/238U年龄-εHf(t)关系

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 9  研究区Oyotún组火山岩构造环境判别图解（底图据参考文献[43-45]修改）

    Figure 9.

    下载: 全尺寸图片 幻灯片

    表 1  Oyotún组火山岩LA-ICP-MS锆石U-Th-Pb分析数据

    Table 1.  LA-ICP-MS zircon U-Th-Pb dating data of Oyotún Formation

    分析点号 Pb*/10-6 Th/10-6 U/10-6 Th/U 207Pb/206Pb 207Pb/235U 206Pb/238U 207Pb/235U 206Pb/238U 208Pb/232Th
    比值 1σ 比值 1σ 比值 1σ 年龄/Ma 1σ 年龄/Ma 1σ 年龄/Ma 1σ
    样品 西部Salas地区Oyotún组顶部的英安质晶玻屑凝灰岩
    TW2313-0-1-01 28.35 548.67 1023.13 0.54 0.0485 0.0017 0.1376 0.0048 0.0205 0.0003 130.9 4.3 130.6 1.9 125.9 5.3
    TW2313-0-1-02 74.09 245.71 342.43 0.72 0.1004 0.0056 1.9710 0.1382 0.1371 0.0030 1105.7 47.3 828.0 16.8 1065.6 53.7
    TW2313-0-1-04 40.54 250.40 725.07 0.35 0.0601 0.0020 0.3570 0.0130 0.0430 0.0010 310.0 9.8 271.4 6.4 292.8 14.3
    TW2313-0-1-05 78.69 105.83 523.72 0.20 0.0700 0.0017 1.2519 0.0364 0.1285 0.0020 824.3 16.4 779.3 11.7 864.7 34.7
    TW2313-0-1-06 20.92 437.02 754.98 0.58 0.0571 0.0044 0.1567 0.0113 0.0204 0.0007 147.8 9.9 130.4 4.6 137.8 9.2
    TW2313-0-1-07 44.67 688.01 907.87 0.76 0.0497 0.0017 0.2245 0.0081 0.0327 0.0006 205.6 6.7 207.1 3.4 208.2 7.9
    TW2313-0-1-08 17.89 284.82 590.05 0.48 0.0495 0.0029 0.1468 0.0087 0.0215 0.0006 139.1 7.7 137.2 3.8 163.8 12.6
    TW2313-0-1-09 51.32 1179.70 1548.02 0.76 0.0494 0.0017 0.1473 0.0051 0.0215 0.0004 139.5 4.5 137.3 2.3 143.3 5.4
    TW2313-0-1-10 24.32 475.57 795.18 0.60 0.0517 0.0020 0.1510 0.0058 0.0213 0.0004 142.8 5.1 135.6 2.3 140.6 5.8
    TW2313-0-1-11 30.44 761.92 972.51 0.78 0.0499 0.0019 0.1420 0.0053 0.0206 0.0003 134.8 4.7 131.6 2.1 139.6 5.5
    TW2313-0-1-12 26.36 517.95 843.01 0.61 0.0479 0.0019 0.1405 0.0054 0.0212 0.0003 133.5 4.8 135.0 1.9 145.0 5.7
    TW2313-0-1-13 70.13 62.91 76.58 0.82 0.2083 0.0050 16.0650 0.4299 0.5529 0.0110 2880.7 25.6 2837.3 45.6 2667.9 99.1
    TW2313-0-1-14 28.42 611.53 971.85 0.63 0.0500 0.0021 0.1418 0.0055 0.0206 0.0004 134.6 4.9 131.5 2.6 130.3 6.0
    TW2313-0-1-15 39.44 1071.78 1267.04 0.85 0.0537 0.0021 0.1537 0.0060 0.0206 0.0004 145.2 5.3 131.6 2.4 124.5 6.0
    TW2313-0-1-16 89.88 99.88 102.08 0.98 0.1984 0.0058 13.5670 0.3663 0.4886 0.0085 2720.0 25.5 2564.6 36.8 2562.0 108.0
    TW2313-0-1-17 20.63 374.42 702.91 0.53 0.0567 0.0026 0.1602 0.0070 0.0203 0.0004 150.9 6.1 129.5 2.3 140.7 6.8
    TW2313-0-1-18 20.00 371.51 677.89 0.55 0.0539 0.0030 0.1524 0.0080 0.0204 0.0004 144.1 7.0 130.1 2.3 142.3 7.9
    TW2313-0-1-19 20.98 403.37 699.38 0.58 0.0494 0.0026 0.1448 0.0075 0.0213 0.0004 137.3 6.7 135.6 2.7 142.4 7.7
    TW2313-0-1-20 39.65 903.48 1322.81 0.68 0.0575 0.0026 0.1600 0.0068 0.0201 0.0003 150.7 5.9 128.0 2.1 129.6 4.7
    TW2313-0-1-21 38.69 1101.03 1165.38 0.94 0.0547 0.0024 0.1530 0.0066 0.0201 0.0003 144.5 5.8 128.2 2.1 132.8 5.5
    TW2313-0-1-22 23.45 441.99 791.75 0.56 0.0548 0.0026 0.1579 0.0073 0.0209 0.0005 148.8 6.4 133.1 2.9 145.9 6.4
    TW2313-0-1-24 34.07 51.60 398.83 0.13 0.0580 0.0020 0.6047 0.0217 0.0750 0.0012 480.2 13.7 466.2 7.4 527.9 27.3
    样品 西部Badanggrande地区Oyotún组顶部的英安质含角砾晶屑熔结凝灰岩
    TW3141-1-1-01 23.73 666.12 925.97 0.72 0.0496 0.0016 0.1385 0.0049 0.0200 0.0003 131.7 4.3 127.4 1.9 130.4 4.9
    TW3141-1-1-02 26.29 721.67 1031.04 0.70 0.0506 0.0015 0.1406 0.0042 0.0199 0.0003 133.6 3.8 127.1 1.7 121.6 3.9
    TW3141-1-1-03 25.74 666.29 1023.93 0.65 0.0467 0.0015 0.1312 0.0043 0.0202 0.0003 125.2 3.9 129.1 1.9 124.2 4.0
    TW3141-1-1-04 28.47 828.98 1104.29 0.75 0.0516 0.0017 0.1451 0.0054 0.0204 0.0004 137.6 4.8 130.0 2.6 132.4 5.8
    TW3141-1-1-05 29.25 746.36 1150.02 0.65 0.0479 0.0014 0.1344 0.0041 0.0202 0.0003 128.0 3.7 128.7 1.7 124.0 3.8
    TW3141-1-1-06 18.53 424.43 723.43 0.59 0.0478 0.0015 0.1363 0.0045 0.0205 0.0003 129.7 4.0 130.8 1.8 124.0 4.3
    TW3141-1-1-07 35.73 1038.11 1352.88 0.77 0.0477 0.0012 0.1347 0.0038 0.0204 0.0003 128.3 3.4 130.1 2.0 123.9 3.7
    TW3141-1-1-08 32.56 859.89 1165.23 0.74 0.0479 0.0014 0.1420 0.0042 0.0214 0.0003 134.8 3.7 136.6 2.0 126.9 4.2
    TW3141-1-1-09 22.92 534.71 859.76 0.62 0.0460 0.0016 0.1352 0.0049 0.0212 0.0003 128.7 4.4 135.5 1.9 126.7 4.5
    TW3141-1-1-10 20.23 442.70 775.89 0.57 0.0469 0.0016 0.1369 0.0050 0.0211 0.0003 130.3 4.4 134.6 2.2 132.1 4.3
    TW3141-1-1-11 18.42 384.62 711.93 0.54 0.0471 0.0018 0.1355 0.0049 0.0211 0.0003 129.0 4.4 134.6 2.2 137.0 5.2
    TW3141-1-1-12 20.45 443.38 806.68 0.55 0.0501 0.0015 0.1413 0.0043 0.0204 0.0003 134.2 3.8 130.3 1.8 125.1 4.3
    TW3141-1-1-13 17.75 359.53 709.04 0.51 0.0492 0.0019 0.1418 0.0054 0.0208 0.0003 134.6 4.8 132.9 1.9 125.8 4.5
    TW3141-1-1-15 16.75 380.91 679.03 0.56 0.0493 0.0020 0.1357 0.0064 0.0198 0.0003 129.2 5.7 126.1 2.1 129.0 6.1
    TW3141-1-1-16 19.58 413.38 780.98 0.53 0.0466 0.0015 0.1313 0.0044 0.0203 0.0003 125.2 4.0 129.4 2.0 127.5 4.6
    TW3141-1-1-17 20.60 457.21 799.42 0.57 0.0475 0.0016 0.1330 0.0045 0.0202 0.0003 126.8 4.1 128.8 1.8 131.6 4.9
    TW3141-1-1-18 26.14 659.14 980.18 0.67 0.0482 0.0017 0.1391 0.0049 0.0209 0.0004 132.2 4.4 133.5 2.6 131.9 5.0
    TW3141-1-1-19 20.04 420.59 737.62 0.57 0.0492 0.0016 0.1445 0.0050 0.0210 0.0003 137.1 4.5 134.3 1.8 136.1 4.8
    TW3141-1-1-20 25.81 552.80 924.61 0.60 0.0463 0.0015 0.1396 0.0045 0.0217 0.0003 132.7 4.0 138.6 1.9 135.1 4.9
    TW3141-1-1-21 21.39 488.07 822.52 0.59 0.0489 0.0017 0.1358 0.0045 0.0201 0.0003 129.3 4.0 128.2 1.7 120.3 3.8
    TW3141-1-1-22 26.59 650.52 1011.41 0.64 0.0476 0.0014 0.1323 0.0038 0.0201 0.0003 126.1 3.4 128.1 1.6 120.3 3.8
    TW3141-1-1-23 17.54 320.47 675.73 0.47 0.0483 0.0019 0.1386 0.0054 0.0209 0.0003 131.8 4.8 133.3 2.0 126.2 4.7
    TW3141-1-1-24 20.57 453.77 786.60 0.58 0.0503 0.0017 0.1413 0.0045 0.0203 0.0003 134.2 4.0 129.5 1.9 121.6 4.6
    样品 东部Cutervo地区Oyotún组底部的英安质含角砾强熔结凝灰岩
    TW6102-1-1-01 14.10 206.54 416.51 0.50 0.0521 0.0024 0.1645 0.0073 0.0231 0.0004 154.6 6.4 147.1 2.4 158.4 7.7
    TW6102-1-1-02 13.58 258.99 425.00 0.61 0.0571 0.0029 0.1667 0.0086 0.0211 0.0004 156.5 7.5 134.6 2.4 145.7 6.1
    TW6102-1-1-03 19.85 322.17 629.46 0.51 0.0521 0.0022 0.1601 0.0076 0.0221 0.0004 150.8 6.7 140.7 2.2 150.6 7.1
    TW6102-1-1-04 20.02 364.87 672.99 0.54 0.0476 0.0018 0.1411 0.0053 0.0215 0.0003 134.1 4.7 137.4 2.1 135.7 6.3
    TW6102-1-1-05 15.06 285.33 434.62 0.66 0.0637 0.0024 0.1834 0.0070 0.0209 0.0003 171.0 6.0 133.6 1.9 157.9 6.4
    TW6102-1-1-06 18.11 283.85 589.74 0.48 0.0560 0.0036 0.1627 0.0108 0.0211 0.0004 153.0 9.4 134.6 2.5 157.9 13.0
    TW6102-1-1-07 13.90 245.69 453.27 0.54 0.0534 0.0022 0.1545 0.0065 0.0211 0.0003 145.9 5.7 134.3 2.2 146.3 7.0
    TW6102-1-1-08 14.57 242.75 478.60 0.51 0.0567 0.0033 0.1683 0.0118 0.0210 0.0004 158.0 10.2 134.3 2.6 147.9 8.7
    TW6102-1-1-09 19.76 334.73 634.24 0.53 0.0500 0.0022 0.1477 0.0062 0.0216 0.0004 139.9 5.5 137.8 2.4 148.0 6.3
    TW6102-1-1-10 14.92 340.30 415.35 0.82 0.0622 0.0032 0.1878 0.0102 0.0219 0.0005 174.7 8.8 139.7 2.9 170.6 9.1
    TW6102-1-1-11 21.24 332.57 666.23 0.50 0.0460 0.0018 0.1378 0.0053 0.0219 0.0003 131.1 4.7 139.4 1.9 146.6 6.0
    TW6102-1-1-12 8.28 128.01 253.82 0.50 0.0550 0.0029 0.1667 0.0088 0.0222 0.0004 156.5 7.7 141.7 2.8 153.0 8.1
    TW6102-1-1-14 21.15 362.73 639.92 0.57 0.0491 0.0018 0.1528 0.0056 0.0226 0.0004 144.4 4.9 143.8 2.3 153.5 5.5
    TW6102-1-1-15 11.80 172.60 375.24 0.46 0.0577 0.0027 0.1724 0.0079 0.0217 0.0003 161.5 6.9 138.7 2.2 151.7 7.1
    TW6102-1-1-16 12.40 237.68 381.36 0.62 0.0487 0.0021 0.1496 0.0065 0.0224 0.0004 141.5 5.7 142.8 2.4 136.4 5.6
    TW6102-1-1-17 22.18 355.11 741.43 0.48 0.0491 0.0016 0.1503 0.0050 0.0223 0.0003 142.1 4.4 142.1 2.2 138.2 4.7
    TW6102-1-1-18 21.40 321.80 683.02 0.47 0.0482 0.0018 0.1509 0.0050 0.0229 0.0004 142.7 4.4 146.1 2.4 146.9 5.2
    TW6102-1-1-19 12.55 146.11 430.79 0.34 0.0501 0.0025 0.1561 0.0079 0.0226 0.0004 147.3 7.0 144.2 2.7 138.7 7.5
    TW6102-1-1-20 10.34 178.02 326.84 0.54 0.0506 0.0023 0.1537 0.0063 0.0223 0.0003 145.2 5.5 142.0 2.1 139.5 6.4
    TW6102-1-1-21 21.87 339.42 758.47 0.45 0.0512 0.0036 0.1563 0.0155 0.0215 0.0003 147.5 13.6 137.4 2.2 153.1 17.4
    TW6102-1-1-22 28.69 780.32 847.55 0.92 0.0630 0.0028 0.1860 0.0079 0.0214 0.0004 173.2 6.7 136.3 2.3 119.6 4.7
    TW6102-1-1-23 16.95 225.16 605.08 0.37 0.0517 0.0032 0.1600 0.0111 0.0221 0.0004 150.7 9.7 141.0 2.7 151.8 8.6
    TW6102-1-1-24 16.46 297.20 504.40 0.59 0.0523 0.0017 0.1683 0.0057 0.0232 0.0004 157.9 5.0 147.6 2.3 153.9 6.0
    样品 东部Sammca地区Oyotún组顶部石泡流纹岩
    TW6001-1-1-01 14.91 277.38 534.66 0.52 0.0530 0.0038 0.1503 0.0125 0.0201 0.0004 142.2 11.1 128.5 2.6 142.5 7.0
    TW6001-1-1-02 22.03 437.01 747.41 0.58 0.0485 0.0020 0.1382 0.0058 0.0204 0.0003 131.4 5.2 130.5 1.8 138.4 5.2
    TW6001-1-1-03 21.57 384.93 749.69 0.51 0.0529 0.0025 0.1514 0.0071 0.0207 0.0004 143.2 6.3 131.9 2.3 155.5 6.6
    TW6001-1-1-04 14.21 184.07 438.88 0.42 0.0495 0.0023 0.1645 0.0074 0.0240 0.0004 154.6 6.5 152.8 2.4 160.3 7.3
    TW6001-1-1-05 15.35 267.92 446.35 0.60 0.0516 0.0023 0.1758 0.0077 0.0248 0.0004 164.5 6.6 157.8 2.7 160.3 8.6
    TW6001-1-1-06 19.40 262.77 589.07 0.45 0.0521 0.0031 0.1730 0.0105 0.0238 0.0004 162.0 9.1 151.5 2.3 162.6 7.1
    TW6001-1-1-07 22.13 426.57 704.56 0.61 0.0489 0.0034 0.1399 0.0086 0.0209 0.0005 133.0 7.6 133.4 3.3 142.1 7.8
    TW6001-1-1-08 10.76 231.96 356.07 0.65 0.0543 0.0036 0.1528 0.0087 0.0209 0.0005 144.4 7.7 133.0 3.2 120.0 6.8
    TW6001-1-1-09 13.07 224.34 376.80 0.60 0.0540 0.0033 0.1780 0.0104 0.0242 0.0005 166.4 9.0 153.8 3.2 162.6 8.5
    TW6001-1-1-10 12.88 212.93 375.97 0.57 0.0499 0.0023 0.1698 0.0084 0.0245 0.0005 159.2 7.3 156.0 2.8 153.4 7.5
    TW6001-1-1-11 31.31 725.51 1050.87 0.69 0.0494 0.0016 0.1407 0.0046 0.0205 0.0003 133.7 4.1 130.6 1.8 123.3 4.0
    TW6001-1-1-12 19.55 369.66 657.11 0.56 0.0503 0.0018 0.1455 0.0048 0.0210 0.0003 138.0 4.2 133.9 1.7 129.1 5.0
    TW6001-1-1-13 14.90 237.04 439.60 0.54 0.0517 0.0019 0.1738 0.0064 0.0243 0.0004 162.7 5.5 154.7 2.4 152.4 5.2
    TW6001-1-1-14 16.57 227.44 494.05 0.46 0.0501 0.0020 0.1738 0.0070 0.0251 0.0004 162.7 6.1 159.6 2.7 150.7 6.7
    TW6001-1-1-15 18.01 259.44 603.65 0.43 0.0579 0.0031 0.1688 0.0097 0.0208 0.0004 158.3 8.4 132.9 2.7 158.1 11.0
    TW6001-1-1-16 16.75 254.46 505.62 0.50 0.0521 0.0019 0.1786 0.0069 0.0246 0.0004 166.9 5.9 156.8 2.4 149.3 6.0
    TW6001-1-1-17 19.72 392.94 675.82 0.58 0.0467 0.0016 0.1349 0.0045 0.0208 0.0003 128.5 4.0 132.7 2.1 131.0 4.5
    TW6001-1-1-18 16.02 253.01 434.13 0.58 0.0510 0.0029 0.1762 0.0106 0.0249 0.0006 164.8 9.1 158.3 3.8 181.7 10.3
    TW6001-1-1-19 17.15 216.48 523.74 0.41 0.0483 0.0018 0.1682 0.0060 0.0253 0.0004 157.9 5.2 160.8 2.2 154.5 6.4
    TW6001-1-1-20 19.97 326.38 593.76 0.55 0.0499 0.0017 0.1691 0.0060 0.0244 0.0004 158.6 5.2 155.5 2.4 156.5 5.8
    TW6001-1-1-21 17.36 296.25 502.54 0.59 0.0494 0.0019 0.1698 0.0061 0.0250 0.0004 159.3 5.3 159.1 2.2 148.4 5.2
    TW6001-1-1-22 11.41 144.12 363.35 0.40 0.0495 0.0024 0.1660 0.0076 0.0244 0.0004 155.9 6.7 155.3 2.4 149.5 7.4
    TW6001-1-1-23 15.70 271.72 453.61 0.60 0.0540 0.0023 0.1817 0.0075 0.0245 0.0004 169.5 6.5 156.0 2.8 154.0 6.7
    TW6001-1-1-24 28.72 515.17 1015.30 0.51 0.0473 0.0014 0.1395 0.0044 0.0212 0.0003 132.6 3.9 135.3 1.9 138.5 4.9
    样品 东部Pucará地区Oyotún组顶部英安岩
    TW4105-1-1-01 10.42 283.37 308.36 0.92 0.0599 0.0049 0.1606 0.0116 0.0200 0.0006 151.2 10.1 127.5 3.7 144.8 11.6
    TW4105-1-1-02 4.31 78.49 145.13 0.54 0.0579 0.0030 0.1549 0.0076 0.0201 0.0005 146.2 6.7 128.1 3.3 139.1 9.0
    TW4105-1-1-03 9.32 227.27 279.87 0.81 0.0506 0.0025 0.1444 0.0068 0.0211 0.0005 136.9 6.0 134.7 3.4 137.4 7.8
    TW4105-1-1-04 5.89 111.66 197.23 0.57 0.0590 0.0034 0.1614 0.0098 0.0201 0.0005 151.9 8.6 128.0 3.0 134.4 8.0
    TW4105-1-1-05 5.54 93.69 193.77 0.48 0.0514 0.0026 0.1478 0.0081 0.0206 0.0004 140.0 7.1 131.6 2.7 131.8 7.4
    TW4105-1-1-06 5.80 115.41 186.50 0.62 0.0519 0.0026 0.1430 0.0073 0.0201 0.0004 135.7 6.4 128.2 2.5 130.8 7.1
    TW4105-1-1-07 4.06 55.63 138.89 0.40 0.0529 0.0040 0.1427 0.0103 0.0206 0.0005 135.4 9.1 131.3 3.3 170.7 11.4
    TW4105-1-1-09 3.82 57.57 132.58 0.43 0.0583 0.0040 0.1620 0.0108 0.0205 0.0005 152.5 9.4 130.8 3.0 147.7 9.4
    TW4105-1-1-10 10.50 229.24 333.74 0.69 0.0499 0.0025 0.1468 0.0083 0.0210 0.0005 139.1 7.4 134.0 2.9 134.7 6.4
    TW4105-1-1-11 7.55 160.39 235.40 0.68 0.0549 0.0033 0.1557 0.0088 0.0209 0.0004 147.0 7.8 133.3 2.7 144.0 7.6
    TW4105-1-1-12 3.83 63.97 134.44 0.48 0.0547 0.0039 0.1541 0.0124 0.0209 0.0007 145.5 10.9 133.4 4.1 141.7 12.3
    TW4105-1-1-13 10.70 170.61 363.68 0.47 0.0529 0.0029 0.1533 0.0098 0.0206 0.0004 144.8 8.6 131.6 2.5 152.9 7.4
    TW4105-1-1-14 6.83 123.90 231.28 0.54 0.0494 0.0031 0.1359 0.0080 0.0205 0.0004 129.4 7.2 130.7 2.8 156.1 9.6
    TW4105-1-1-15 4.07 67.47 138.21 0.49 0.0613 0.0044 0.1658 0.0118 0.0204 0.0005 155.7 10.3 130.2 3.3 176.1 13.3
    TW4105-1-1-16 8.34 146.11 268.60 0.54 0.0507 0.0026 0.1453 0.0078 0.0211 0.0004 137.7 6.9 134.3 2.4 154.7 8.0
      注：Pb*为放射性成因Pb
    下载: 导出CSV

    表 2  Oyotún组火山岩主量、微量及稀土元素分析结果

    Table 2.  Major, trace and rare earth elements abundances of the Oyotún Formation

    样品 YH3141 YH3144 YH4105 YH2313 YH6302 YH6104
    岩性 英安质含角砾熔结凝灰岩 流纹质角砾熔结凝灰岩 英安岩 英安质晶玻屑凝灰岩 玄武安山岩 英安质含角砾晶屑熔结凝灰岩
    SiO2 63.58 72.33 63.92 60.35 54.44 65.63
    A12O3 20.3 13.93 16.12 21.54 17.24 15.14
    Fe2O3 1.21 0.49 1.91 1.23 3.19 2.34
    FeO 1.24 1.9 2.62 4.91 4.72 2.76
    CaO 0.34 2.61 3.5 0.4 4.17 1.07
    MgO 1.41 0.56 1.6 1.24 3.89 1.55
    Na2O 1.9 3.43 4.53 1.3 3.99 6.07
    K2O 5.53 2.44 2.46 3.02 3.07 1.83
    TiO2 0.85 0.23 0.5 0.84 0.78 0.68
    MnO 0.034 0.08 0.12 0.09 0.19 0.13
    P2O3 0.14 0.056 0.12 0.022 0.22 0.21
    烧失量 2.90 1.52 2.10 4.50 3.25 2.16
    总量 99.43 99.58 99.50 99.44 99.15 99.57
    tZr/℃ 897 749 764 926 730 790
    A/CNK 2.09 1.07 0.98 3.51 0.99 1.09
    Cs 7.63 3.56 1.8 7.2 2.1 0.021
    Rb 196 154 59.4 102 71 0.600
    Ba 1004 330 882 1130 1600 6.600
    Th 17.7 15.4 6.5 10.1 4.7 0.080
    U 5.02 3.97 1.5 2.2 1.8 0.020
    Pb 4.26 8.61 15.8 13.2 13.2 0.150
    Ga 23.8 13.6 16.9 24.4 17.8 15.7
    Nb 14.4 5.71 5.9 11.7 4.9 0.658
    Ta 1.11 0.6 0.44 0.82 0.3 0.037
    Sr 108 195 280 231 446 19.900
    Zr 301 98 156 301 128 10.500
    Hf 8.9 3.4 4.9 7.8 2.1 0.283
    Y 27.2 10.4 24.9 14.2 18.8 1205.000
    Yb 4.17 1.39 2.6 1.4 2 4.300
    Sc 18.1 4.83 14.6 20.5 27.5 16.9
    V 67.3 32.3 97.4 60.5 140 33.3
    Cr 6.23 14.1 12.9 14.1 29 9.95
    Co 4.38 3.2 9.4 6.1 24.2 4.1
    Ni 3.09 3.83 4.3 5.5 10 2.42
    La 53.2 36.8 34.2 15.8 25.8 53.2
    Ce 64.9 60.1 69.9 39 56.8 64.9
    Pr 9.52 4.4 6.2 3 5.42 9.52
    Nd 35.8 14.4 24.6 11.4 23 35.8
    Sm 6.83 2.44 5.4 2.4 5.86 6.83
    Eu 1.22 0.63 1.2 0.78 1.35 1.22
    Gd 5.15 2.15 4.4 2.2 4.89 5.15
    Tb 0.85 0.33 0.8 0.44 1 0.85
    Dy 4.8 1.72 4.5 2.7 5.9 4.8
    Ho 1.08 0.36 0.92 0.5 1.21 1.08
    Er 3.37 1.1 2.6 1.2 3.39 3.37
    Tm 0.61 0.2 0.41 0.19 0.55 0.61
    Yb 4.17 1.39 2.6 1.4 3.49 4.17
    Lu 0.65 0.23 0.38 0.18 0.49 0.65
      注：A/CNK=n（Al2O3）/n（Ca2O+Na2O+K2O）；tZr（℃）为锆石饱和温度[15]；主量元素含量单位为%；微量和稀土元素单位为10-6
    下载: 导出CSV

    表 3  Oyotún组火山岩LA-MC-ICP-MS锆石Hf同位素分析结果

    Table 3.  LA-MC-ICP-MS zircon Hf isotopes of the Oyotún volcanic rocks

    分析点号 年龄/Ma l76Hf/l77Hf 1σ 176Lu/177Hf 176Yb/177Hf (176Hf/177Hf)i εHf(t) 1σ TDM1/Ga TDM2/Ga
    样品 西部Salas地区Oyotún组顶部英安质晶玻屑凝灰岩
    TW2313-0-01 130.63 0.282870 0.000025 0.001750 0.044348 0.282865 6.17 0.863388 0.553681 0.795624
    TW2313-0-08 137.17 0.282881 0.000013 0.002113 0.057131 0.282875 6.66 0.460747 0.542873 0.768868
    TW2313-0-09 137.31 0.282880 0.000013 0.002112 0.057131 0.282875 6.65 0.469186 0.543725 0.770118
    TW2313-0-10 135.60 0.282875 0.000012 0.001881 0.054068 0.28287 6.45 0.43054 0.547723 0.781286
    TW2313-0-11 131.63 0.282884 0.000014 0.001505 0.042141 0.28288 6.72 0.486565 0.529008 0.760641
    TW2313-0-12 134.96 0.282881 0.000014 0.001748 0.048778 0.282876 6.65 0.481467 0.537374 0.767782
    TW2313-0-14 131.53 0.282875 0.000015 0.001500 0.039776 0.282872 6.41 0.537922 0.541647 0.780677
    TW2313-0-15 131.56 0.282894 0.000013 0.001464 0.039666 0.282891 7.09 0.455212 0.513751 0.737334
    TW2313-0-17 129.55 0.282872 0.000015 0.001676 0.040209 0.282868 6.24 0.515231 0.548842 0.789967
    TW2313-0-18 130.06 0.282842 0.000013 0.001098 0.025024 0.282839 5.23 0.441451 0.583267 0.854717
    TW2313-0-19 135.61 0.282838 0.000012 0.001517 0.034014 0.282834 5.17 0.41826 0.595656 0.863023
    TW2313-0-20 128.02 0.282997 0.000054 0.002044 0.044969 0.282992 10.59 1.886737 0.371932 0.509681
    TW2313-0-21 128.17 0.282935 0.000016 0.001838 0.039629 0.28293 8.42 0.548119 0.460169 0.649516
    TW2313-0-22 133.13 0.283115 0.000017 0.001744 0.035874 0.283111 14.91 0.584267 0.196612 0.235072
    样品 西部Badangrande地区Oyotún组顶部英安质含角砾晶屑熔结凝灰岩
    TW3141-1-1-1 127.44 0.282832 0.000018 0.002301 0.059538 0.282827 4.74 0.63094 0.616693 0.884387
    TW3141-1-1-10 134.58 0.282903 0.000015 0.001640 0.041430 0.282899 7.45 0.527908 0.503454 0.716631
    TW3141-1-1-11 134.61 0.282854 0.000016 0.001552 0.039823 0.28285 5.72 0.565144 0.572882 0.827121
    TW3141-1-1-12 130.29 0.282870 0.000017 0.001495 0.036754 0.282866 6.18 0.595266 0.549709 0.794137
    TW3141-1-1-13 132.90 0.282878 0.000015 0.001070 0.027721 0.282875 6.57 0.531822 0.531891 0.771838
    TW3141-1-1-15 126.09 0.282856 0.000016 0.001999 0.050297 0.282851 5.55 0.564635 0.577909 0.831204
    TW3141-1-1-16 129.41 0.282878 0.000016 0.001311 0.033417 0.282875 6.48 0.577113 0.534778 0.774306
    TW3141-1-1-17 128.85 0.282881 0.000017 0.001653 0.044177 0.282877 6.55 0.579009 0.535266 0.769499
    TW3141-1-1-18 133.51 0.282883 0.000017 0.001428 0.035481 0.28288 6.74 0.577784 0.529176 0.761135
    TW3141-1-1-19 134.26 0.282854 0.000015 0.001280 0.033278 0.282851 5.73 0.52001 0.569179 0.82652
    TW3141-1-1-2 127.07 0.282852 0.000013 0.001706 0.042570 0.282848 5.46 0.448814 0.578899 0.837831
    TW3141-1-1-20 138.56 0.282927 0.000017 0.002354 0.057633 0.282921 8.30 0.582034 0.478694 0.665234
    TW3141-1-1-21 128.20 0.282853 0.000013 0.001234 0.032290 0.28285 5.58 0.455062 0.569592 0.831499
    TW3141-1-1-3 129.14 0.282874 0.000012 0.001782 0.045151 0.282869 6.28 0.4108 0.548069 0.787101
    TW3141-1-1-4 130.04 0.282889 0.000014 0.001203 0.029206 0.282886 6.88 0.498611 0.518267 0.749619
    TW3141-1-1-5 128.67 0.282877 0.000013 0.001764 0.043895 0.282873 6.40 0.467102 0.542529 0.779024
    TW3141-1-1-6 130.83 0.282840 0.000014 0.001193 0.029772 0.282837 5.18 0.474888 0.587195 0.858677
    TW3141-1-1-7 130.12 0.282880 0.000014 0.001365 0.034096 0.282876 6.55 0.504612 0.533374 0.770753
    TW3141-1-1-8 136.61 0.282876 0.000015 0.001450 0.036197 0.282873 6.55 0.519941 0.539554 0.77539
    TW3141-1-1-9 135.46 0.282842 0.000015 0.001399 0.035025 0.282838 5.32 0.529693 0.588187 0.85364
    样品 东部Pucará地区Oyotún组顶部英安岩
    TW4105-1-01 127.51 0.282861 0.000012 0.001458 0.037827 0.282858 5.83 0.43157 0.5612 0.814478
    TW4105-1-02 128.06 0.282913 0.000013 0.001312 0.035345 0.28291 7.68 0.464745 0.485096 0.696468
    TW4105-1-03 134.74 0.282827 0.000013 0.002045 0.055302 0.282822 4.72 0.445964 0.620234 0.891289
    TW4105-1-04 128.00 0.282928 0.000016 0.001397 0.038379 0.282925 8.22 0.566403 0.463996 0.661882
    TW4105-1-05 131.65 0.282848 0.000014 0.001592 0.041696 0.282844 5.44 0.494427 0.582488 0.843101
    TW4105-1-06 128.21 0.282868 0.000015 0.001114 0.029143 0.282865 6.12 0.522545 0.546358 0.796807
    TW4105-1-07 131.26 0.282839 0.000016 0.000970 0.024697 0.282837 5.18 0.555711 0.585019 0.859282
    TW4105-1-09 130.85 0.282837 0.000017 0.001293 0.032424 0.282834 5.05 0.594221 0.593578 0.866824
    TW4105-1-10 133.97 0.282852 0.000016 0.001413 0.035580 0.282849 5.66 0.553907 0.573278 0.830693
    TW4105-1-11 133.26 0.282859 0.000014 0.001651 0.043547 0.282855 5.86 0.502542 0.567421 0.817479
    TW4105-1-12 133.42 0.282847 0.000013 0.001153 0.029785 0.282844 5.47 0.471085 0.577234 0.842147
    TW4105-1-13 131.57 0.282904 0.000014 0.001910 0.047569 0.282899 7.39 0.493477 0.50605 0.718085
    TW4105-1-14 130.74 0.282860 0.000015 0.000926 0.023357 0.282858 5.90 0.53198 0.554964 0.812417
    TW4105-1-15 130.20 0.282833 0.000014 0.001221 0.030371 0.28283 4.90 0.481507 0.59856 0.8765
    TW4105-1-16 134.31 0.282908 0.000015 0.001670 0.044439 0.282904 7.61 0.51179 0.496741 0.705793
    样品 东部Cutervo地区Oyotún组底部英安质含角砾熔结凝灰岩
    TW6102-1-1-01 147.13 0.282796 0.000014 0.001276 0.031580 0.282792 3.94 0.495904 0.652311 0.950829
    TW6102-1-1-02 134.64 0.282817 0.000012 0.002021 0.051607 0.282812 4.38 0.407262 0.634025 0.913201
    TW6102-1-1-03 140.70 0.282858 0.000014 0.001531 0.037338 0.282854 5.98 0.487984 0.56734 0.815394
    TW6102-1-1-04 137.41 0.282843 0.000012 0.001175 0.029727 0.28284 5.41 0.417009 0.583385 0.849211
    TW6102-1-1-05 133.58 0.282818 0.000015 0.001556 0.037616 0.282814 4.42 0.530536 0.625194 0.909777
    TW6102-1-1-06 134.64 0.282828 0.000013 0.001580 0.039213 0.282824 4.79 0.438641 0.611114 0.886601
    TW6102-1-1-07 134.33 0.282812 0.000016 0.001539 0.037972 0.282809 4.24 0.560048 0.632796 0.921668
    TW6102-1-1-08 134.27 0.282843 0.000022 0.002044 0.048664 0.282838 5.28 0.75417 0.596789 0.855217
    TW6102-1-1-09 137.75 0.282834 0.000016 0.001977 0.049853 0.282829 5.05 0.550882 0.60825 0.872449
    TW6102-1-1-10 139.71 0.282864 0.000020 0.002823 0.067826 0.282856 6.05 0.686193 0.578836 0.809918
    TW6102-1-1-11 139.43 0.282826 0.000016 0.002952 0.075784 0.282818 4.70 0.575494 0.637378 0.896162
    TW6102-1-1-12 141.67 0.282858 0.000015 0.001822 0.047776 0.282853 5.97 0.510728 0.571839 0.816604
    TW6102-1-1-14 143.76 0.282840 0.000013 0.002077 0.052678 0.282834 5.34 0.464815 0.602571 0.858442
    TW6102-1-1-15 138.66 0.282820 0.000015 0.001111 0.027350 0.282818 4.65 0.509511 0.614131 0.898559
    TW6102-1-1-16 142.81 0.282889 0.000019 0.002036 0.048606 0.282884 7.08 0.653384 0.529697 0.746701
    TW6102-1-1-17 142.09 0.282857 0.000012 0.001779 0.044691 0.282852 5.94 0.436694 0.573019 0.819015
    TW6102-1-1-18 146.13 0.282798 0.000012 0.001278 0.030887 0.282794 3.99 0.432847 0.649203 0.946442
    TW6102-1-1-19 144.22 0.282824 0.000015 0.001709 0.042431 0.28282 4.85 0.530449 0.61842 0.890148
    TW6102-1-1-20 141.95 0.282785 0.000017 0.002059 0.049110 0.282779 3.37 0.609108 0.682329 0.983319
    TW6102-1-1-21 137.43 0.282814 0.000015 0.001443 0.034954 0.28281 4.36 0.51291 0.629236 0.916346
    下载: 导出CSV
    • 参考文献(45)
  • [1]

    Ramos V A.Plate tectonic setting of the Andean Cordillera[J].Episodes, 1999, 22:183-190. https://www.researchgate.net/profile/Victor_Ramos8/publication/279938014_Plate_tectonic_setting_of_the_Andean_Cordillera/links/55ce2bc508ae6a88138473c2.pdf?inViewer=true&disableCoverPage=true&origin=publication_detail

    [2]

    Ramos V A, Litvak V D, Folguera A, et al.An Andean tectonic cycle:From crustal thickening to extension in a thin crust (34°-37°SL)[J].Geosci.Front., 2014, 5(3):351-367. doi: 10.1016/j.gsf.2013.12.009

    [3]

    Cawood, P A.Terra Australis Orogen:Rodinia breakup and development of the Pacific and Iapetus margins of Gondwana during the Neoproterozoic and Paleozoic[J].Earth-Science Reviews, 2005, 69:249-279. doi: 10.1016/j.earscirev.2004.09.001

    [4]

    Chew D M, Schaltegger, Kosler J, et al.U-Pb geochronologic evidence for the evolution of the Gondwananmargin of the north-central Andes[J].Geological Society of America Bulletin, 2007, 119:697-711. doi: 10.1130/B26080.1

    [5]

    Miškovic A, Spikings R, Chew D M, et al.Tectonomagmatic evolution of Western Amazonia:geochemical characterization and zircon U-Pb geochronologic constraints from the Peruvian Eastern Cordilleran granitoids[J].Geological Society of America Bulletin, 2009, 121:1298-1324. doi: 10.1130/B26488.1

    [6]

    Davidson J P, Harmon R S, Wörner G.The source of central Andean magmas; Some considerations[J].Geological Society of America, 1991, 265:233-244. doi: 10.1130/SPE265

    [7]

    Fontbote L, Gorzawski H.Genesis of the Missis-sippi Valley-type Zn-Pb Deposit of San Vicente, Central Peru:geologic and isotopic (Sr, O, C, S, Pb) evidence[J].Economic Geology, 1990, 85:1402-1437. doi: 10.2113/gsecongeo.85.7.1402

    [8]

    Fischer R P, Hilpert L S.Geology of the Uravan mineral belt[M].US Government Printing Office.1952:1-100.

    [9]

    Fischer R P, Botinelly T.Vanadium-uranium deposits of the Rifle Creek area, Garfield County, Colorado, with a section on mineralogy[M].US Government Printing Office, 1960:1-120.

    [10]

    秘鲁共和国能源部冶金矿业地质局.国家地质图A系列第38号(JAYANCA (13-d), CHOTA (14-f), INCAHUASI (13-e), CELENDIN(14-g), CUTERVO (13-f), PACASMAYO (15-d), CHICLAYO (14-d), CHONGOYAPE (14-e), CHEPEN(5-e) (中文版)[M].利马:秘鲁冶金矿业地质局出版, 1984:1-60.

    [11]

    段政, 邢光福, 余明刚, 等.浙闽边界区晚中生代火山作用时序与过程分析[J].地质论评, 2013, 59(3):454-469. http://www.wenkuxiazai.com/doc/5515564b08a1284ac950434b.html

    [12]

    Hu Z C, Liu Y S, Gao S, et al.Improved in situ Hf isotope ratio analysis of zircon using newly designed X skimmer cone and Jet sample cone in combination with the addition of nitrogen by laser ablation multiple collector ICP-MS[J].Journal of Analytical Atomic Spectrometry, 2012, 27(9):1391-1399. doi: 10.1039/c2ja30078h

    [13]

    Dodson M H, McClelland-Brown E.Isotopic and paleaomagnetic evidence for rates of cooling, uplift and erosion[C]//The chronology of geological record.London, Geological Society Memoir.1985, 10:315-325.http://mem.lyellcollection.org/content/10/1/315

    [14]

    Ewart A, Green D C, Carmichael I S E, et al.Voluminous low temperature rhyolitic magmas in New Zealand[J].Contributions to Mineralogy and Petrology, 1971, 33(2):128-144. doi: 10.1007/BF00386111

    [15]

    Watson E B, Harrison T M.Zircon saturation revisited:temperature, composition effects in a variety of crustal magma types[J].Earth Planet Science Letters, 1983, 64:295-304. doi: 10.1016/0012-821X(83)90211-X

    [16]

    Wipf M, Zeilinger G, Diane S, et al.Focused subaerial erosion during ridge subduction:impact on the geomorphology in south-central Peru[J].Terra Nova, 2008, 20:1-10. doi: 10.1111/ter.2008.20.issue-1

    [17]

    Scaillet S.Numerical error analysis in 40Ar/39Ar dating[J].Chemical Geology, 2000, 162(3/4):269-298. https://www.sciencedirect.com/science/article/pii/0096300377900091

    [18]

    王非, 杨列坤, 王磊, 等.中国东南晚中生代火山沉积地层界线时代——40Ar/39Ar年代学及磁性地层研究[J].中国科学(D辑), 2010, 40(11):1552-1570. http://www.oalib.com/paper/4153161

    [19]

    Cherniak D J, Watson E B.Pb diffusion in zircon[J].Chemical Geology, 2000, 172:5-24. https://www.sciencedirect.com/science/article/pii/S0009254100002333

    [20]

    Wu Y B, Zheng Y F.Genesis of zircon and its constraints on interpretation of U-Pb age[J].Chinese Science Bulletin, 2004, 49(15):1554-1569. doi: 10.1007/BF03184122

    [21]

    Le Maitre R W, Bateman P, Dudek A.A classification of igneous rocks and glossary of terms[C]//Recommendations of the International Union of Geological Sciences Subcommission on the Systematics Igneous Rocks.Oxford:UK, Blackwell Scientific Publications, 1989:1-280.https://catalogue.nla.gov.au/Record/2221970

    [22]

    Le Bas M, Le Maitre R W, Streckeisen A, et al.A chemical classification of volcanic rocks based on the total-silica diagram[J].Journal of Petrology, 1986, 27:745-750. doi: 10.1093/petrology/27.3.745

    [23]

    Irvine T N, Baragar W R A.A guide to the chemical classification of the common volcanic rocks[J].Canadian Journal of Earth Science, 1971, 8:523-548. doi: 10.1139/e71-055

    [24]

    Boynton W V.Geochemistry of the rare earth elements:meteorite studies[C]//Henderson P.Rare Earth Element Geochemistry.Elservier, 1984:63-114.

    [25]

    Hirose K.Melting experiments on lherzolite KLB-1 under hydrous conditions and generation of high-magnesian andesitic melts[J].Geology, 1997, 25(1):42-44. doi: 10.1130/0091-7613(1997)025<0042:MEOLKU>2.3.CO;2

    [26]

    Rudnick R L, Gao S.Composition of the continental crust[J].Treatise of Geochemistry, 2004, 3:1-64. https://www.sciencedirect.com/science/article/pii/0016703795000382

    [27]

    Palme H, O' Neill H St C.Cosmochemical estimates of mantle composition[J].Treatise of Geochemistry, 2004, 2:1-38. https://www.sciencedirect.com/science/article/pii/B9780080959757002011

    [28]

    Trischendorf G, Paelchen W.Zur Klassifikation von Granitoiden.Classification of granitoids[J].Zeitschrift fuer Geologische Wissenachaften.1985.13(5):615-627. https://www.researchgate.net/publication/232960832_Crustal_granitoids

    [29]

    Wu F Y, Li X H, Zheng Y F, et al.Lu-Hf isotopic systematics and their applications in petrology[J].Acta Petrologica Sinica, 2007, 23(2):185-220. https://www.researchgate.net/publication/305531916_Lu-Hf_isotopic_systematics_and_thier_applications_in_petrology

    [30]

    Martin H, Moyen J F.Secular changes in tonalite-trondhjemite-granodiorite composition as markers of the progressive cooling of Earth[J].Geology, 2002, 30(4):319-322. doi: 10.1130/0091-7613(2002)030<0319:SCITTG>2.0.CO;2

    [31]

    Frisch W, Mesched M, Blakey R.Plate Tectonics[M].Springer, Heidelberg, 2011:1-100.

    [32]

    Klein M, Stosch H G, Seck H A.Partitioning of high fieldstrength and rare-earth elements between amphibole and quartzdioritic to tonalitic melts:an experimental study[J].Chemical Geology, 1997, 138(3):257-271. https://link.springer.com/article/10.1007/s00410-014-1060-0

    [33]

    Miskovic A, Spikings R A, Chew D M, et al.Tectonomagmatic evolution of Western Amazonia:geochemical characterization and zircon U-Pb geochronologic constraints from the Peruvian Eastern Cordilleran granitoids[J].Geological Society of America Bulletin, 2009, 121:1298-1324. doi: 10.1130/B26488.1

    [34]

    Villagómez D, Spikings R, Magna T, et al.Geochronology, geochemistry and tectonic evolution of the Western and Central cordilleras of Colombia[J].Lithos, 2011, 125:875-896. doi: 10.1016/j.lithos.2011.05.003

    [35]

    Cochrane R S, Spikings R A, Winkler W, et al.Tectonic evolution of the Ecuadorian margin during the Triassic-Early Cretaceous:a geochronological and geochemical study[C]//14th Congreso Latinoamericano de Geología, Medellin, 2011.

    [36]

    Lucassen F, Kramer W, Bartsch V, et al.Nd, Pb, and Sr isotope composition of juvenile magmatism in the Mesozoic large magmatic province of northern Chile (18-27S):indications for a uniform subarc mantle[J].Contributions to Mineralogy and Petrology, 2006, 152(5):571-589. doi: 10.1007/s00410-006-0119-y

    [37]

    Rosas S, Fontboté L, Tankard A.Tectonic evolution and paleogeography of the Mesozoic Pucara Basin, central Peru[J].Journal of South American Earth Sciences, 2007, 24:1-24. doi: 10.1016/j.jsames.2007.03.002

    [38]

    Clift P D, Kukowski N, Hampel A.Tectonic erosion of the Peruvian forearc, Lima Basin, by subduction and Nazca Ridge collision[J].Tectonics, 2003, 22:1-16. http://www.academia.edu/1036592/Tectonic_erosion_of_the_Peruvian_forearc_Lima_Basin_by_subduction_and_Nazca_Ridge_collision

    [39]

    Ramos J I.Patagonia:a paleozoic continent adrift?[J].Journal of South American Earth Sciences, 2008, 26:236-251. https://www.sciencedirect.com/science/article/pii/S0895981108000527

    [40]

    Tankard A, Welsink H J, Aukes P.Basin development along the Pacific margin of South America.A petroleum exploration perspective[C]//Backbone of the Americas, Joint GSA-AGA Meeting, Mendoza.2006:3-7.

    [41]

    Sempere T, Carlier G, Soler P, et al.Late Permian-Middle Jurassic lithospheric thinning in Peru and Bolivia, and its bearing on Andean-age tectonics[J].Tectonophysics, 2002, 345:153-181. doi: 10.1016/S0040-1951(01)00211-6

    [42]

    Villagómez D, Spikings R.Thermochronology and tectonics of the Central and Western Cordilleras of Colombia:Early CretaceousTertiary evolution of the northern Andes[J].Lithos, 2013, 160:228-249. http://www.sciencedirect.com/science/article/pii/S0024493712004999

    [43]

    Pearce J A, Cann J R.Tectonic setting of basic volcanic rocks determined using trace element analysis[J].Earth and Planetary Science Letters, 1973, 19(2):290-300. doi: 10.1016/0012-821X(73)90129-5

    [44]

    Pearce J A.Trace element characteristics of lavas from destructive plate boundaries[C]//Thorpe R S.Andesites.Wiley Press, 1982:525-548.https://core.ac.uk/display/8801696

    [45]

    Jahn B M, Zhou X H, Li J L.Formation and tectonic evolution of southeastern China and Taiwan:isotopic and geochemical constraints[J].Tectonophysics, 1990, 183:145-160. doi: 10.1016/0040-1951(90)90413-3

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中

图(10)

表(3)

计量
  • 文章访问数:  1182
  • PDF下载数:  10
  • 施引文献:  0
出版历程
收稿日期:  2017-03-20
修回日期:  2017-09-19
刊出日期:  2017-12-25

目录

    版权所有：中国地质调查局发展研究中心 copyright @2020
    返回
