蒙古戈壁阿尔泰巴音陶勒盖地区二长花岗岩LA-ICP-MS锆石U-Pb年龄及其地质意义
LA-ICP-MS zircon U-Pb dating of monzogranite in Bayintolgoi, Gobi-Altay, Mongolia, and its geological implications
-
摘要: 蒙古戈壁阿尔泰省巴音陶勒盖地区地处南戈壁-阿尔泰构造带南缘,区内构造活动活跃,中酸性侵入岩比较发育。采用LA-ICP-MS锆石U-Pb测年技术,对区内二长花岗岩中的锆石进行同位素年龄研究。阴极发光图像显示,锆石颗粒多为自形-半自形,且有明显的初始岩浆振荡环带,少见蚀变微区,结合较高的Th/U值(0.65~1.79),断定其为典型的岩浆成因锆石;30颗锆石的206Pb/238U年龄加权平均值为300.2±0.9Ma,显示二长花岗岩成岩时代为晚石炭世,代表了华力西中期的一次构造-岩浆事件,为约束南戈壁-阿尔泰构造带晚石炭世深成岩浆活动时限提供了新证据。Abstract: Bayintolgoi region in Mongolia is located in the southern South-Gobi-Altay tectonic zone. In this region, tectonic move-ment is active and intermediate-acidic intrusive rocks are well developed. Analysis of LA-ICP-MS zircon U-Pb ages was conduct-ed for zircons from monzogranite in Bayintolgoi, Mongolia. As revealed by the cathodoluminescence images, all the zircons from monzogranite are euhedral-subhedral and have oscillatory zoning, with almost all the zircons having high Th/U ratios. These charac-teristics suggest a magmatic genesis of the analyzed zircons. 30 zircons yielded a weighted mean 206Pb/238U age of 300.2±0.9Ma. The results show that the monzogranite was formed in Upper Carboniferous and there existed a tectonic-magmatic event in the Middle Variscan. These data provide new evidence for the Upper Carboniferous orogeny in South-Gobi-Altay tectonic zone.
-
Key words:
- monzogranite /
- LA-ICP-MS zircon U-Pb ages /
- South-Gobi-Altay /
- Mongolia
-
-
[1] 李俊建, 张锋, 任军平, 等. 中蒙边界地区构造单元划分[J]. 地质通报, 2015, 34(4):636-662.
[2] 李俊建, 刘新秒, 王国明, 等. 蒙古地质矿产概况[M]. 天津:天津科学技术出版社, 2013:1-273.
[3] Tomurtogoo O, Badarch G. Mongolia geological map of Mongolia (at the Scale 1:1000,000) and its explanatory note[M]. Mineral Re-sources Authority of Mongolia and Mongolian Academy of Sciences (MRAM-MAS), Ulaanbaatar, 1998:4-20.
[4] Tomurtogoo O. Tectonical Map of Mongolia Boundary Area[M]. Ulaanbaatar, 2002.
[5] 韩宝福, 季建清, 宋彪, 等. 新疆准噶尔晚古生代陆壳垂向生长(Ⅰ)——后碰撞深成岩浆活动的时限[J]. 岩石学报, 2006, 22(5):1077-1086.
[6] 苏玉平, 唐红峰, 侯广顺, 等. 新疆西准噶尔达拉布特构造带铝质A型花岗岩的地球化学研究[J]. 地球化学, 2006, 35(1):55-67.
[7] 童英, 王涛, 洪大卫, 等. 北疆及邻区石炭-二叠纪花岗岩时空分布特征及其构造意义[J]. 岩石矿物学杂志, 2010, 29(6):619-641.
[8] Chen J F, Han B F, Ji J Q, et al. Zircon U-Pb ages and tectonic im-plications of Paleozoic plutons in northern West Junggar, North Xin-jiang, China[J]. Lithos, 2010, 115(1/4):137-152.
[9] Ma C, Xiao W J, Windley B F, et al. Tracing a subducted ridgetransform system in a Late Carboniferous accretionary prism of the southern Altaids:Orthogonal sanukitoid dyke swarms in western Junggar, NW China[J]. Lithos, 2012, 140/141:152-165.
[10] Xiao W J, Kusky T. Geodynamic processes and metallogenesis of the Central Asian and related orogenic belts:Introduction[J]. Gond-wana Research, 2009, 16(2):167-169.
[11] Geng H Y, Sun M, Yuan C, et al. Geochemical, Sr-Nd and zircon U-Pb-Hf isotopic studies of Late Carboniferous magmatism in the West Junggar, Xinjiang:Implications for ridge subduction?[J]. Chemical Geology, 2009, 266(3/4):364-389.
[12] Yang G X, Li Y J, Gu P Y, et al. Geochronological and geochemical study of the Darbut ophiolitic complex in the West Junggar (NW China):Implications for petrogenesis and tectonic evolution[J]. Gondwana Research, 2012, 21(4):1037-1049.
[13] Liu Y S, Hu Z C, Gao S, et al. In situ analysis of major and trace el-ements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2008, 257(1/2):34-43.
[14] Ludwig K R. User's Manual for Isoplot 3.00:A Geochronological Toolkit for Microsoft Excel[M]. Berkeley:Berkeley Geochronolog-ical Center, 2003:1-71.
[15] 吴元保, 郑永飞. 锆石成因矿物学研究及其对U-Pb年龄解释的制约[J]. 科学通报, 2004, 49(16):1589-1604.
[16] Rubatto D, Gebauer D. Use of cathodoluminescence for U-Pb zir-con dating by IOM Microprobe:Some examples from the western Alps[J]. Cathodoluminescence in Geoscience, Springer-Verlag Ber-lin Heidelberg, Germany, 2000:373-400.
[17] Chen B, Arakawa Y. Elemental and Nd-Sr isotopic geochemistry of granitoids from the West Junggar foldbelt (NW China), with im-plications for Phanerozoic continental growth[J]. Geochimica et Cosmochimica Acta, 2005, 69(5):1307-1320
[18] 宋彪, 李锦轶, 张进, 等. 西准噶尔托里地区塔尔根二长花岗岩锆石U-Pb年龄——托里断裂左行走滑运动开始的时间约束[J]. 地质通报, 2011, 30(1):19-25.
[19] 张招崇, 闫升好, 陈柏林, 等. 新疆东准噶尔北部俯冲花岗岩的SHRIMP U-P锆石定年[J]. 科学通报, 2006, 51(13):1565-1574.
[20] 肖文交, 韩春明, 袁超, 等. 新疆北部石炭纪-二叠纪独特的构造-成矿作用:对古亚洲洋构造域南部大地构造演化的制约[J]. 岩石学报, 2006, 22(5):1062-1076.
[21] 徐学义, 马中平, 夏祖春, 等. 天山石炭-二叠纪后碰撞花岗岩的Nd、Sr、Pb同位素源区示踪[J]. 西北地质, 2005, 38(2):1-18.
[22] 周涛发, 袁峰, 范裕, 等. 西准噶尔萨吾尔地区A型花岗岩的地球动力学意义:来自岩石地球化学和锆石SHRIMP定年的证据[J]. 中国科学(D辑), 2006, 36(1):39-48.
[23] 安芳, 朱永峰. 新疆西准噶尔包古图组凝灰岩锆石SHRIMP年龄及其地质意义[J]. 岩石学报, 2009, 25(6):1437-1445.
[24] 高睿, 肖龙, 王国灿, 等. 西准噶尔晚古生代岩浆活动和构造背景[J]. 岩石学报, 2013, 29(10):3413-3434.
[25] 尹继元, 袁超, 王毓婧, 等. 新疆西准噶尔晚古生代大地构造演化的岩浆活动记录[J]. 大地构造与成矿学, 2013, 35(2):278-291.
-
