SEDIMENTARY CHARACTERISTICS AND ENVIRONMENTAL SIGNIFICANCE OF HONGMEN COASTAL BARRIER,LIANYUNGANG, NORTHEASTERN JIANGSU PROVINCE
-
摘要: 通过钻孔、年代地层、沉积物粒度和有孔虫组合综合分析,并配合探地雷达,对洪门古沙堤的成因类型以及古海岸环境进行了探讨。洪门古沙堤沉积物和海州湾现代沙滩、苏北平原贝壳堤相比较,颗粒集中在粗砂-极粗砂范围,分选性偏差,极有可能形成于靠近河口或受河口影响的环境。探地雷达揭示洪门古沙堤曾有过向海方向的进积和生长,指示当时沙源丰富。洪门古沙堤的浅钻地层反映了洪门地区在6 400 aBP左右为滨海沼泽环境,此时期与青莲岗文化期的年代相吻合;湖沼沉积结束后,洪门地区迎来了中全新世的最大海侵,受周围地形的制约,洪门地区可能形成了河口浅海湾环境,普遍沉积了2 m左右的青灰色淤泥沉积,有孔虫组合反映当时的环境并非完全开敞,而是受到一定程度限制的近岸浅水环境,反映了洪门地区为浅海湾环境;6 000 aBP左右,随着砂砾质沉积物供应的丰富以及相对海平面下降,洪门古沙堤开始发育,直到5 000 aBP苏北和连云港地区普遍发生海退,古沙堤发育结束。Abstract: Based on core log, 14C dating,grain size analysis as well as ground-penetrating radar images, genesis of Hongmen coastal barrier and the environment were discussed. Four cores are available along ground-penetrating radar transects. The cored sedimentary succession in the coastal barrier of Hongmen area can be subdivided into three units from bottom to up. The bottom unit is mainly composed of gray to dark gray clay with calcareous concretion, which is interpreted as an exposed unit formed 6 400 aBP. This unit followed by an extensive transgression clay, probably formed in a near-shore, shallow (Deposits of Hongmen coastal barrier are coarser than those of modern Haizhou Bay beach and cheniers of northern Jiangsu coastal plain. The grains are concentrated between 0~1 Φ, with a worse sorting than in modern Haizhou Bay beach sediments. It indicates that the Hongmen coastal barrier is very close to a river mouth area where flooding can carry coarse materials.The ground-penetrating radar is tentatively used to augment standard geomorphic and stratigraphic techniques. The radar images show a series of seaward oblique reflectors, which indicate a coastal progradation during barrier growth. This coastal progradation can be interpreted as having lots of material supply during that time. The results show the ground-penetrating radar is a useful technology for interpreting coastal barrier stratigraphy which can be applied to informed, sensible land use planning and environmental assessments.
-
Key words:
- coastal barrier /
- grain size /
- ground-penetrating radar /
- Hongmen /
- Lianyungang
-
-
[1] Jol H M,Smith D G and Meyers R A.Digital ground-penetrating radar(GPR):A new geophysical tool for coastal barrier research (example from the Atlantic, Gulf and Pacific coast, U.S.A.)[J]. Journal of Coastal Research, 1996,12:960-968.
[2] Neal A, Richards J, Pye K. Structure and development of shell cheniers in Essex, southeast England, investigated using high-frequency ground-penetrating radar[J]. Marine Geology, 2002, 185:435-469.
[3] Van Overmeeren R A. Radar facies of unconsolidated sediments in the Netherlands:a radar stratigraphy interpretation method for hydrogeology[J]. Journal of Applied Geophysics, 1998, 40:1-18.
[4] Yin Y, Zhu D K,Martini I P, et al. Application of ground-penetrating radar for barrier spit stratigraphic interpretation, Hainan Island, China[J]. Journal of Coastal Research, 2004,43 special issue:179-201.
[5] 顾家裕,严钦尚,虞志英.苏北中部滨海平原贝壳砂堤[J]. 沉积学报,1983,1(2):47-59.
[GU Jia-yu,YAN Qin-shang,YU Zhi-ying.The cheniers of the northern coastal plain of Jiangsu Province[J]. Acta Sedimentologica Sinica, 1983,1(2):47-59.]
[6] 赵希涛,王绍鸿. 江苏阜宁西园全新世风暴沉积与海岸沙丘的发现及其意义[J]. 中国科学B辑,1992(9):994-1001.[ZHAO Xi-tao, WANG Shao-hong. Holocene storm sediments and the significance of the coastal sand dune in Funing Xiyuan,Jiangsu[J]. Science in China(Series B),1992
(9):994-1001.]
[7] 朱诚,程鹏,卢春成,等. 长江三角洲及苏北沿海地区7000年以来海岸线演变规律分析[J]. 地理科学,1996, 16(3):207-213.
[ZHU Cheng,CHENG Peng,LU Chun-cheng.Palaeo coastline evolution law of Yangtze River delta and coastal area North Jiangsu Province since 7000a BP[J].Scientia Geographica Sinica,1996,16(3):210-213.]
[8] 张传藻.海州湾岸线发育特征[J].海洋科学,1982(3):81-93.[ZHANG Chuan-zao. Developmental characteristics of the coastline in Haizhou Bay[J]. Ocean Science,1982
(3):81-93.]
[9] 虞志英,陈德昌,唐寅德. 关于苏北平原海岸古砂堤形成年代的认识[J]. 海洋科学,1982(4):25-28.[YU Zhi-ying,CHEN De-chang,TANG Yin-de.On the formation of fossil barriers in the middle flat of northern Jiangsu[J]. Ocean Science, 1982
(4):25-28.]
[10] 任美鄂. 江苏省海岸带和海涂资源综合调查报告[M].北京:海洋出版社, 1986.[REN Mei-e.Synthetic report of Jiangsu coastal zone and tidal flat resources[M].Beijing:China Ocean Press,1986.]
[11] 王富葆. 海州湾西安埋葬贝壳堤与晚更新世以来的海面变化[C]//中国第四纪海岸线学术讨论会论文集.北京:海洋出版社,1985.[WANG Fu-bao. The buried shell beach ridges and the sea-level changes from late Pleistocene in the west coast of the Haizhou Bay[C]//Proceedings of Quaternary coastline symposium,China. Beijing:China Ocean press,1985.]
[12] 张传藻.连云港地理与经济[M].南京:河海大学出版社,1999:302-324.[ZHANG Chuan-zao.Lianyungang Geography and Economy[M]. Nanjing:Hehai University Press, 1999:302
-324.]
[13] Smith G D,Jol M H. Radar structure of a Gilbert-type delta, Peyto Lake, Banf National Park[J]. Canada. Sedimentary Geology, 1997,113:195-209.
[14] Van Heteren S, Fitzgerald D U, Mckinlay P A,et al. Radar facies of paraglacial barrier systems[J]. Coastal New England, USA. Sedimentary, 1998,45:181-200.
[15] 王振宇.南黄海海州湾外侧钙质结核特征及其成因的研究[J],上海地质, 1990(3):19-29.[WANG Zhen-yu, Characteristics and the origin of the calcareous concretion outside the Haizhou Bay in South Yellow Sea[J]. Shanghai Geology, 1990
(3):19-29.]
-
