川东北元坝中部须家河组构造裂缝形成期次分析

,  ,  ,  ,

文章导航 > 西北地质 > 2018 > 51(1): 265-271

上一篇

下一篇

李玉玺, 范存辉, 李虎, 韩雨恬, 秦启荣. 川东北元坝中部须家河组构造裂缝形成期次分析[J]. 西北地质, 2018, 51(1): 265-271.
引用本文: 李玉玺, 范存辉, 李虎, 韩雨恬, 秦启荣. 川东北元坝中部须家河组构造裂缝形成期次分析[J]. 西北地质, 2018, 51(1): 265-271.
shu
LI Yuxi, FAN Cunhui, LI Hu, HAN Yutian, QIN Qirong. Formation Stagesabout Structural Fractures of Xujiahe Formation in Fault-Fold Belt of Central Yuanba Area, Northeast Sichuan[J]. Northwestern Geology, 2018, 51(1): 265-271.
Citation: LI Yuxi, FAN Cunhui, LI Hu, HAN Yutian, QIN Qirong. Formation Stagesabout Structural Fractures of Xujiahe Formation in Fault-Fold Belt of Central Yuanba Area, Northeast Sichuan[J]. Northwestern Geology, 2018, 51(1): 265-271.
shu

川东北元坝中部须家河组构造裂缝形成期次分析

  • 1.

    西南石油大学地球科学与技术学院, 四川 成都 610500

  • 2.

    西南石油大学地球科学与技术学院, 四川 成都 610500;中国石油塔里木油田分公司, 新疆 库尔勒 841000

  • 基金项目: 国家重大科技专项“低渗透储层天然裂缝测井识别和分布预测研究”（2011ZX05013-006-008）、四川省应用基础研究项目“冲断带前缘地腹高陡逆断裂形成机理及裂缝发育量化预测”（2017JY0176）

Formation Stagesabout Structural Fractures of Xujiahe Formation in Fault-Fold Belt of Central Yuanba Area, Northeast Sichuan

  • 1.

    School of Geoscience and Technology, Southwest Petroleum University, Chengdu 610500, Sichuan, China

  • 2.

    School of Geoscience and Technology, Southwest Petroleum University, Chengdu 610500, Sichuan, China;Tarim Oilfield Company, Petro China, Korla 841000, Xinjiang, China

    摘要
  • 四川盆地元坝中部须家河组储层裂缝主要以构造裂缝为主，构造作用所形成的裂缝是致密砂岩储层主要的渗滤通道和储集空间。研究区构造缝主要以低角度剪切缝和高角度剪切缝为主，裂缝长度变化范围较大，宽度较窄，具有间距大、密度小的特征，裂缝充填主要以全充填和半充填为主，充填物以方解石为主，充填程度不高，总体上有效性较好。在不考虑第一期成岩缝的前提下，确定了研究构造裂缝形成期次共3期：第一期为形成于燕山运动晚期的北东（30°±5°）、北西（315°±5°）向“X”型共轭剪切缝；第二期裂缝为形成于喜马拉雅运动早—中期的南北（0°±5°）、北东东（75°±10°）向“X”型共轭剪切缝；第三期裂缝为形成喜马拉雅运动晚期北西西（290°±10°）向剪切缝。
    The reservoir of Xujiahe Formation in Fault-Fold Belt of central Yuanba area are mainly structural fractures, which serve as the main percolation channels and reservoir spaces in tight sandstone reservoirs.The structural fractures in this studying area are mainly dominated by low-and high-angle shearing cracks.These cracks have wide changing range in length and narrow width, with large spacing and low density.And these cracks are mainly filled by calcite, muddy and carbonaceous fillings through the full-and semi-filling methods, without high filling degree but with better overall effectiveness.Without considering the diagenetic fracture, three stages of structural fractures are developed in this studying area.The first stage fractures are formed in Late Yanshanian tectonic movement, developing with orientation strikes in NE(30°±5°), NW (315°±5°)trending.The second stage fractures are formed in early-middle Himalaya tectonic movement, with orientation strikes in NEE(75°±10°)and SN(0°±5°)trending.The third stage fractures are formed in late-Himalaya tectonic movement, with orientation strikes in NWW(290°±10°)trending.
    • HTML全文
  • 加载中
    • 参考文献(24)

  • 周文.裂缝性油气储集层评价方法[M].成都:四川科学技术出版社, 1998.

    ZHOU Wen.Evaluation method of fractured reservoir[M].Chengdu:Sichuan science and Technology Press, 1998.

    盘昌林,刘树根,马永生,等.川东北地区须家河组天然气成藏主控因素分析[J].断块油田,2011,18(4):418-422.

    PANG Changlin, LIU Shugen, MA Yongsheng, et al.Main controlling factors of natural gas accumulation in Xujiahe formation, Northeastern Sichuan Basin[J].Fault block oilfield, 2011,18 (4):418-422.

    戴朝成,郑荣才,朱如凯,等.四川类前陆盆地须家河组储层特征[J].天然气地球科学,2011, 22(1):47-55.

    DAI Zhaocheng, ZHENG Rongcai, ZHU Rukai, et al.Reservoir characteristics of Xujiahe Formation in Sichuan foreland basin[J].Natural Gas Geoscience, 2011, 22 (1):47-55.

    曾联波.低渗透砂岩储层裂缝的形成与分布[M].北京:科学出版社,2008.

    ZENG Lianbo.Low permeability sandstone reservoir formation and distribution of cracks[M].Beijing:Science Press, 2008.

    周进松,童小兰,冯永宏,等.柴窝堡背斜储层构造裂缝发育特征及控制因素[J].石油学报,2006,27(3):53-56.

    ZHOU Jinsong, TONG Xiaolan, FENG Yonghong,et al.Development characteristics and controlling factors of structural fractures in reservoirs of the anticline[J].Journal of Petroleum Science,2006,27(3):53-56.

    许同海.致密储层裂缝识别的测井方法及研究进展[J].油气地质与采收率,2005, (3):79-82, 92.

    XU Tonghai.Logging methods and research progress in fracture identification of tight reservoirs[J].Oil and Gas Geology and Oil Recovery, 2005, (3):79-82, 92.

    周文,张银德,王洪辉,等.楚雄盆地北部T3-J地层天然裂缝形成期次确定[J].成都理工大学学报:自然科学版,2008,35(2):121-126.

    ZHOU Wen, ZHANG Yinde, WANG Honghui, et al.Determination of the formation period of natural fractures in the T3-J formation in the northern Chuxiong basin[J].Journal of Chengdu University of Technology:Natural Science Edition, 2008,35 (2):121-126.

    赖生华,余谦,周文,等.楚雄盆地北部上三叠统-侏罗系裂缝发育期次[J].石油勘探与开发,2004,31(5):25-29.

    LAI Shenghua, YU Qian, ZHOU Wen, et al.Fracture development period of Upper Triassic Jurassic system in the north of Chuxiong basin[J].Petroleum Exploration and Development, 2004,31 (5):25-29.

    童亨茂.成像测井资料在构造裂缝预测和评价中的应用[J].天然气工业,2006, 26 (9):15-20.

    TONG Hengmao. Imaging logging data used in prediction and evaluation of structural fractures[J].Natural Gas Industry, 2006, 26 (9):15-20.

    杨巍然,张文淮.断裂性质与流体包裹体组合特征[J].地球科学中国地质大学学报,1996,21(3):285-290.

    YANG Weiran, ZHANG Wenhuai.Fracture characteristics and fluid inclusions combination characteristics[J].Journal of Earth Science, China University of Geosciences, 1996,21 (3):285-290.

    郑荣才.储层裂缝研究的新方法-声发射实验[J].石油与天然气地质,1998,19(3):186-189.

    ZHENG Rongcai.A new method for reservoir fracture acoustic emission experiment[J].Petroleum and Natural Gas Geology, 1998,19 (3):186-189.

    丁原辰,张大伦.声发射抹录不尽现象在地应力测量中的应用[J].岩石力学与工程学报, 1991,10(4):313-326.

    DING Yuanchen, ZHANG Dalun.Acoustic emission with the application[J].Chinese Journal of Rock Mechanics and Engineering,1991,10 (4):313-326.
