新疆富蕴县库额尔齐斯铁矿成因机制探讨研究

张超; 刘锋; 杨富全

新疆富蕴县库额尔齐斯铁矿成因机制探讨研究

1.
广东省地质局七一九地质大队，广东肇庆 526020

2.
国土资源部成矿作用与资源评价重点实验室，中国地质科学院矿产资源研究所，北京 100037

基金项目:
国家科技支撑计划项目(2011BAB06B03-02); 国土资源部公益性行业专项资金课题(200911007-10,200911043-02)

详细信息

作者简介: 张超，工程师，矿床学专业。E-mail: czcl719@sina.com

通讯作者: 刘锋，研究员，主要从事矿床地球化学的研究。E-mail: liufeng@cags.ac.cn

中图分类号: O657.63; P578.12

收稿日期: 2012-02-24

录用日期: 2012-10-24

A Discussion on Genetic Mechanism of the Kuerqis Iron Deposit in Fuyun County, Xinjiang

1.
No.719 Geological Party, Bureau of Geological Exploration of Guangdong Province, Zhaoqing 526020, China

2.
Key Laboratory of Metallogeny and Mineral Assessment, Ministry of Land and Resources, Institute of Mineral Resources, Chinese Academy of Geological Sciences, Beijing 100037, China

More Information

Corresponding author: Fen LIU, liufeng@cags.ac.cn

Received Date: 24 February 2012

Accepted Date: 24 October 2012

摘要

摘要: 目前针对阿尔泰南缘一带的小型富铁矿床研究明显不足。本文研究了库额尔齐斯富铁矿的成矿时代及成矿机制，为区域铁成矿规律和成矿预测提供基础资料。野外地质调查表明，该矿床地质特征具有火山沉积成因，但主要与花岗斑岩侵入的热液活动有关，二长花岗岩对铁矿有破坏作用。利用激光剥蚀-多接收器电感耦合等离子体质谱法测定了矿区两个花岗岩体的年龄，利用同位素质谱计测定了矿床中黄铁矿的硫同位素组成，分析表明花岗斑岩锆石18个测点在谐和线上成群分布，²⁰⁶Pb/²³⁸U年龄值集中在273～282.6 Ma，加权平均年龄为(278.7±0.94) Ma(MSDW=1.6)；二长花岗岩12个测点集中成群分布，²⁰⁶Pb/²³⁸U年龄值集中在271.8～276.8 Ma，加权平均年龄为(274.1±1.1) Ma(MSDW=0.47)。黄铁矿的δ³⁴S值变化于-7.2‰～0.7‰，多为负值，但大多数集中在0值附近，表明深源岩浆在向上运移过程中可能与围岩或早期沉积铁矿发生了明显的硫同位素交换，暗示铁的富集成矿主要发生在花岗斑岩侵入的热液期。综合区域研究认为，矿区花岗岩均属于阿尔泰南缘广泛发育的早二叠世时期岩浆事件，形成于板内伸展拉张环境。该期岩浆活动也伴随了铁等广泛的金属成矿作用。
- LA-MC-ICP-MS U-Pb定年 /
- 硫同位素组成 /
- 岩浆热液成因 /
- 库额尔齐斯铁矿
Abstract: The large iron deposits in the southern margin of Altay had been studied systematically, but researches on some small Fe-rich type such as Kuerqis iron deposit are still obviously insufficient. In this paper, a study of the chronology and genetic mechanism to supply basic information for regional metallogeny and mineral assessment is documented. The Kuerqis iron deposit is located in the Erqis tectonic belt in the southern margin of Altay. The field investigation suggests that the deposit is dominantly related to hydrothermal activity of granitic porphyry besides the volcanic sedimentary genesis, meanwhile the iron deposit was destroyed by monzonitic granite. The ages of two granite intrusions in the deposit area and S isotope composition of pyrites in ore were determined by Laser Ablation-Multicollector Inductively Coupled Plasma-Mass Spectrometry (LA-MC-ICP-MS) and MAT 251 EM Mass Spectrograph. The ²⁰⁶Pb/²³⁸U ages of 18 data points of zircons in granitic porphyry concentrated on the concordia line range from 273 Ma to 282.6 Ma and the weighted average age is (278.7±0.94) Ma with MSDW=1.6. The ²⁰⁶Pb/²³⁸U ages of 12 data points of zircons in monzonitic granite concentrated on the concordia line range from 271.8 Ma to 276.8 Ma and the weighted average age is (274.1±1.1) Ma with MSDW=0.47. δ³⁴S in pyrites varies from -7.2‰ to 0.7‰ and most are negative and near 0. The characteristic of δ³⁴S perhaps reflects the significant exchange of S isotope between magma from deep source and wall-rocks or the earlier sedimentary iron deposit during ascending magma. The mineralization prominently occurred in the hydrothermal period of granitic porphyry. Combined with former studies, it suggested that two granite intrusions in the deposit area intruded in a plate extension environment during the early-Permian when granite intrusions developed widely in the southern margin of Altay. Moreover, the extensive mineralization of iron and other elements perhaps occurred in this granitic event.
- LA-MC-ICP-MS U-Pb dating /
- sulfur isotopic composition /
- granitic hydrothermalism /
- Kuerqis iron deposit

HTML全文

图 1 库额尔齐斯铁矿床地质图(矿区地质图据甘肃煤田一四五队修编，构造图据文献^[4]编绘)

Figure 1.

下载: 全尺寸图片幻灯片

图 2 花岗斑岩(a)和二长花岗岩(b)中锆石的阴极发光图像

Figure 2.

下载: 全尺寸图片幻灯片

图 3 花岗斑岩锆石LA-MC-ICP-MS U-Pb年龄谐和图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 二长花岗岩锆石LA-MC-ICP-MS U-Pb年龄谐和图

Figure 4.

下载: 全尺寸图片幻灯片

图 5 库额尔齐斯铁矿硫同位素图解

Figure 5.

下载: 全尺寸图片幻灯片

表 1 矿区花岗斑岩和二长花岗岩锆石U-Pb定年数据

Table 1. The U-Pb dating data of granitic porphyry and monzonitic granite

花岗斑岩锆石U-Pb同位素分析数据
测点	w_B/(μg·g^-1)		Th/U	²⁰⁶Pb/²³⁸U		²⁰⁷Pb/²³⁵U		²⁰⁸Pb/²³²Th		²⁰⁷Pb/²⁰⁶Pb		²⁰⁶Pb/²³⁸U		²⁰⁷Pb/²³⁵U		²⁰⁷Pb/²⁰⁶Pb		谐和度
测点	U	Th	Th/U	比值	1σ	比值	1σ	比值	1σ	比值	1σ	年龄/Ma	1σ	年龄/Ma	1σ	年龄/Ma	1σ	谐和度
ker01-1	353.5	286.2	0.81	0.044	0.000364	0.32	0.00264	0.0035	0.00024	0.052	0.00040	279.2	2.2	281.6	2.0	305.6	12.0	99%
ker01-2	242.4	128.7	0.53	0.045	0.000394	0.35	0.0031	0.0038	0.00031	0.056	0.00041	283.1	2.4	301.6	2.3	450.0	21.3	93%
ker01-3	236.0	141.4	0.60	0.044	0.000360	0.32	0.00305	0.0034	0.00029	0.053	0.00041	280.2	2.2	283.5	2.3	322.3	18.5	98%
ker01-4	265.0	138.2	0.52	0.045	0.000357	0.32	0.00243	0.0026	0.00023	0.052	0.00034	282.1	2.2	283.6	1.9	301.9	17.6	99%
ker01-5	304.8	145.3	0.48	0.044	0.000311	0.32	0.00244	0.0033	0.00023	0.053	0.00031	279.1	1.9	282.2	1.9	309.3	13.0	98%
ker01-6	384.9	298.1	0.77	0.045	0.000306	0.33	0.00249	0.0027	0.00016	0.053	0.00031	282.6	1.9	285.9	1.9	322.3	14.8	98%
ker01-7	341.1	166.0	0.49	0.045	0.000338	0.32	0.00263	0.0040	0.00026	0.052	0.00030	282.0	2.1	283.9	2.0	298.2	17.6	99%
ker01-8	281.3	133.9	0.48	0.044	0.000321	0.31	0.0026	0.0031	0.00025	0.052	0.00033	277.9	2.0	276.9	2.0	333.4	14.8	99%
ker01-9	207.5	132.1	0.64	0.044	0.000281	0.32	0.00319	0.0023	0.00021	0.052	0.00041	278.4	1.7	279.7	2.5	287.1	-13.9	99%
ker01-10	228.2	148.9	0.65	0.044	0.000295	0.33	0.00262	0.0023	0.00019	0.054	0.00040	279.8	1.8	289.4	2.0	368.6	16.7	96%
ker01-11	186.3	131.1	0.70	0.043	0.000345	0.31	0.00325	0.0026	0.00022	0.052	0.00039	274.3	2.1	275.0	2.5	279.7	18.5	99%
ker01-12	186.5	127.4	0.68	0.044	0.000357	0.32	0.00354	0.0027	0.00023	0.052	0.00047	277.6	2.2	279.7	2.7	298.2	20.4	99%
ker01-13	198.0	128.0	0.65	0.044	0.000311	0.31	0.00297	0.0029	0.00023	0.051	0.0004	278.2	1.9	273.5	2.3	235.3	16.7	98%
ker01-14	197.4	113.2	0.57	0.042	0.000352	0.30	0.00311	0.0026	0.00021	0.052	0.00038	266.0	2.2	269.7	2.4	301.9	16.7	98%
ker01-15	310.0	147.0	0.47	0.044	0.000295	0.32	0.00228	0.0024	0.00019	0.052	0.00031	279.0	1.8	279.9	1.8	287.1	13.0	99%
ker01-16	187.1	109.2	0.58	0.044	0.000296	0.31	0.00291	0.0026	0.00022	0.052	0.00037	279.1	1.8	277.7	2.3	264.9	13.9	99%
ker01-17	423.5	265.6	0.63	0.044	0.000318	0.31	0.00236	0.0023	0.00015	0.051	0.00027	279.4	2.0	277.3	1.8	261.2	8.3	99%
ker01-18	300.4	101.3	0.34	0.044	0.000312	0.31	0.00259	0.0037	0.00028	0.051	0.00030	279.2	1.9	275.0	2.0	239.0	8.3	98%
ker01-19	190.1	113.8	0.60	0.043	0.000421	0.30	0.00375	0.0021	0.00021	0.051	0.00048	273.0	2.6	270.1	2.9	255.6	50.0	98%
ker01-20	257.3	154.9	0.60	0.043	0.000321	0.30	0.00264	0.0022	0.0002	0.051	0.00036	273.3	2.0	268.1	2.1	233.4	16.7	98%
二长花岗岩锆石U-Pb同位素分析数据
测点	w_B/(μg·g^-1)		Th/U	²⁰⁶Pb/²³⁸U		²⁰⁷Pb/²³⁵U		²⁰⁸Pb/²³²Th		²⁰⁷Pb/²⁰⁶Pb		²⁰⁶Pb/²³⁸U		²⁰⁷Pb/²³⁵U		²⁰⁷Pb/²⁰⁶Pb		谐和度
测点	U	Th	Th/U	比值	1σ	比值	1σ	比值	1σ	比值	1σ	年龄/Ma	1σ	年龄/Ma	1σ	年龄/Ma	1σ	谐和度
ker02-1	681.1	82.6	0.12	0.043	0.00032	0.31	0.00239	0.0030	0.00031	0.052	0.00025	273.4	2.0	275.1	1.8	300.1	9.3	99%
ker02-2	241.9	113.1	0.47	0.044	0.00035	0.31	0.00334	0.0031	0.00029	0.052	0.00040	275.0	2.1	277.3	2.6	294.5	21.3	99%
ker02-3	196.3	24.8	0.13	0.067	0.00109	0.51	0.00962	0.0166	0.00168	0.055	0.00036	420.4	6.6	420.8	6.5	416.7	-17.6	99%
ker02-4	122.8	32.0	0.26	0.055	0.00060	0.40	0.00459	0.0097	0.00097	0.053	0.00039	347.4	3.7	342.5	3.3	322.3	16.7	98%
ker02-5	960.7	239.4	0.25	0.044	0.00028	0.31	0.00238	0.0026	0.00020	0.052	0.00027	275.0	1.7	274.1	1.8	264.9	13.0	99%
ker02-6	613.7	114.6	0.19	0.043	0.00030	0.31	0.00244	0.0035	0.00032	0.051	0.00022	273.1	1.9	271.8	1.9	261.2	41.7	99%
ker02-7	581.1	53.3	0.09	0.044	0.00045	0.32	0.00354	0.0050	0.00054	0.052	0.00029	276.8	2.8	278.3	2.7	300.1	11.1	99%
ker02-8	7.3	3.9	0.53	0.068	0.00167	0.54	0.03039	0.1032	0.02170	0.059	0.00331	421.2	10.1	438.2	20.0	553.7	119.4	96%
ker02-9	460.0	23.0	0.05	0.044	0.00029	0.31	0.00230	0.0119	0.00148	0.052	0.00027	275.7	1.8	275.2	1.8	272.3	11.1	99%
ker02-10	143.5	68.1	0.47	0.043	0.00031	0.30	0.00360	0.0042	0.00052	0.051	0.00053	273.7	1.9	270.1	2.8	239.0	24.1	98%
ker02-11	160.2	79.0	0.49	0.043	0.00032	0.31	0.00372	0.0042	0.00045	0.052	0.00050	272.8	2.0	272.2	2.9	333.4	22.2	99%
ker02-12	654.5	20.0	0.03	0.044	0.00026	0.31	0.00241	0.0099	0.00124	0.052	0.00026	274.7	1.6	275.3	1.9	279.7	-16.7	99%
ker02-13	415.7	90.2	0.22	0.043	0.00026	0.31	0.00247	0.0041	0.00039	0.052	0.00031	271.8	1.6	273.6	1.9	300.1	13.0	99%
ker02-14	159.8	190.8	1.19	0.056	0.00042	0.42	0.00401	0.0033	0.00024	0.055	0.00047	350.1	2.5	359.6	2.9	433.4	18.5	97%
ker02-15	291.4	175.2	0.60	0.043	0.00044	0.31	0.00400	0.0029	0.00026	0.051	0.00037	274.4	2.7	272.8	3.1	257.5	14.8	99%
ker02-16	117.6	55.1	0.47	0.055	0.00051	0.41	0.00564	0.0040	0.00043	0.054	0.00053	346.7	3.1	351.5	4.0	383.4	22.2	98%
ker02-17	398.6	32.4	0.08	0.043	0.00033	0.31	0.00299	0.0074	0.00105	0.051	0.00027	274.2	2.0	272.7	2.3	257.5	38.9	99%
ker02-18	211.8	80.6	0.38	0.055	0.00043	0.40	0.00403	0.0044	0.00045	0.054	0.00037	343.9	2.6	344.9	2.9	350.1	10.2	99%
ker02-19	179.1	85.7	0.48	0.055	0.00045	0.41	0.00357	0.0047	0.00045	0.054	0.00037	346.8	2.8	351.1	2.6	383.4	14.8	98%
ker02-20	345.3	137.4	0.40	0.056	0.00044	0.42	0.00319	0.0034	0.00033	0.055	0.00032	348.2	2.7	357.0	2.3	416.7	-17.6	97%

下载: 导出CSV

表 2 矿床硫同位素组成结果

Table 2. The isotopic component for sulfur in deposit

样品编号	矿物名称	δ³⁴S_V-CDT/‰
Ker 14	黄铁矿	-7.2
Ker 15	黄铁矿	-3.9
Ker 20	黄铁矿	-2.9
Ker 21	黄铁矿	-0.6
Ker 22	黄铁矿	0.1
Ker 23	黄铁矿	-0.5
Ker 24	黄铁矿	-1.8
Ker 25	黄铁矿	0.3
Ker 26	黄铁矿	-2.4
Ker 27	黄铁矿	-2.5
Ker 34	黄铁矿	-1.4
Ker 35	黄铁矿	0.3
Ker 36	黄铁矿	0.7
Ker 40	黄铁矿	0.1
Ker 41	黄铁矿	-1.7

下载: 导出CSV
