Main Influencing Factors and Solutions in the Analysis of Volatile Organic Compounds in Water
-
摘要: 应用吹扫捕集-气相色谱-质谱法测定水中挥发性有机物，多种因素影响着定量分析的准确性，包括样品瓶的清洗及标准配制、样品和标准溶液的保存、载气气源的纯度、仪器状态检查及参数选择、分离度及积分方式。本文提出在分析过程中样品瓶必须清洗干净，以免污染样品；样品和标准溶液的保存时间过长会降低目标物的回收率；载气和吹扫气会带入杂质；分离度的大小将影响峰高和峰面积测量的准确度。针对分析中氯乙烯的回收、二氯甲烷的交叉污染、浑浊样品的处理等常见问题提供了解决方案，推荐采用选择扫描方式进行分析，并根据样品基体的情况来选择定量离子，将分析的初始温度降至40℃以下并保持2～3 min，以保证氯乙烯的回收率；实验室保持良好的通风环境，避免二氯甲烷交叉污染；色谱柱的最高温度升至220℃以上并保持2～3 min，可以排除萘及分子烷烃的干扰，保证分析的连续性；对于浑浊样品，推荐在野外取样时进行在线过滤或直接采用静态顶空方式进行测定。Abstract: Purge and Trapping-Gas Chromatography-Mass Spectrometry was used to determine volatile organic compounds in water. The accuracy of the quantitative analysis was affected by several factors, including standard preparation, preservation of samples and standard solution, and gas purity during analysis, sample bottles should be kept as clean as possible to avoid pollution. The preservation of samples and standard solution over long time can reduce the recoveries of target compounds. Impurities arise from the carrier gas and sweep gas and the separating degree affects the accuracy of the measurements of peak height and peak area, which consequently affects analysis precision. The solution to this problem is presented in this paper. Selected ion monitoring (SIM)was chosen generally, and a quantitative ion was selected according to the matrix. The initial temperature was dropped to 40℃, and maintained for 2-3 minutes, in order to assure the recovery of vinyl chloride. The laboratory should have a good ventilation environment to avoid cross contamination from methylene chloride. The highest temperature of the chromatographic column was increased to 220℃, and maintained for 2-3 minutes, in order to ensure the continuity of the analysis and eliminate interference from alkanes and naphthalene. For turbidity samples, an on-line filter in the field or using Static Headspace-Gas Chromatography technique directly is recommended.
-
Key words:
- water sample /
- volatile organic compounds /
- analysis accuracy /
- influencing factors
-
-
表 1 不同存放时间后标准溶液的回收率
Table 1. The recoveries of standard solutions after different storage time
化合物 回收率/% 1 2 3 4 5 6 氯乙烯 108.3 95.7 88.2 61.7 55.3 66.2 1，1-二氯乙烯 96.8 96.7 78.9 62.1 59.1 83.3 二氯甲烷 105.3 105.5 79.6 73.5 68.7 99.4 1，2-二氯乙烯 104.7 102.8 85.8 82.8 71.0 91.6 1，1-二氯乙烷 107.7 105.3 89.8 83.8 81.6 96.0 氯仿 109.9 104.8 93.9 82.1 76.8 101.5 1，1，1-三氯乙烷 99.4 92.1 89.7 86.2 80.7 86.2 四氯化碳 96.3 95.9 89.5 84.9 78.8 81.2 苯 108.5 96.5 89.1 85.5 80.9 96.6 1，2-二氯乙烷 107.9 104.0 84.4 80.9 75.7 102.5 三氯乙烯 101.6 93.2 87.4 83.2 75.1 91.7 1，2-二氯丙烷 104.0 92.7 82.1 79.8 77.5 95.5 溴二氯甲烷 105.1 92.5 89.2 87.8 77.0 96.8 反-1，3-二氯丙烯 99.4 91.2 89.5 73.3 58.7 91.2 甲苯 100.9 97.2 94.9 88.7 77.2 88.3 顺-1，3-二氯丙烯 101.1 93.3 81.4 74.3 62.7 91.7 1，1，2-三氯乙烷 103.3 91.7 87.8 86.7 77.0 94.2 四氯乙烯 94.5 95.3 85.2 87.2 64.0 83.4 氯二溴甲烷 101.0 96.5 89.3 91.1 76.6 93.0 氯苯 98.7 102.2 87.6 92.2 76.3 88.0 乙苯 100.0 96.7 93.2 92.2 78.4 85.7 间/对二甲苯 99.1 97.2 96.9 92.5 97.1 85.7 邻二甲苯 99.4 95.5 95.1 94.2 79.8 86.8 苯乙烯 99.4 90.5 88.5 80.9 64.4 87.1 溴仿 101.6 94.3 92.6 89.5 71.3 90.2 1，1，2，2-四氯乙烷 109.1 99.5 96.2 94.0 84.3 97.7 间二氯苯 104.6 95.3 96.3 93.1 78.4 88.8 对二氯苯 104.9 95.3 94.4 92.4 76.9 88.8 邻二氯苯 105.1 95.4 96.6 95.1 81.3 90.0 1，2，4-三氯苯 92.9 92.2 90.7 87.8 64.4 79.6 注：回收率1为分装浓标在4个月后测得，回收率2、3、4、5分别为配制于40 mL样品中的6.0 μg/L标准溶液在3天、7天、14天、21天后测得，回收率6为6.0 μg/L样品溶液经过定量滤纸过滤后测得。
下载: 导出CSV
-
[1] EPA method 8260B, Volatile Organic Compounds by Gas Chromatography/Mass Spectrometry[S].
[2] 李义,董建芳,张宇.地下水中挥发性有机物的吹扫捕集-气相色谱-质谱法测定[J].岩矿测试,2010,29(5): 513-517. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201005010.htm
[3] 左海英,张莉,张永涛,桂建业.挥发性有机物检测中内标法与外标法的比较[J].南水北调与水利科技,2009,7(4): 67-73. http://www.cnki.com.cn/Article/CJFDTOTAL-NSBD200904027.htm
[4] 周密,刘德全,林旭,李少艾.吹扫捕集/气相色谱法测定空气中挥发性有机物[J].中国环境监测,2004,20(4): 12-14. http://www.cnki.com.cn/Article/CJFDTOTAL-IAOB200404004.htm
[5] 黄健祥,胡玉玲,李攻科.选择性固相微萃取涂层的研究进展[J].分析科学学报,2008,24(1): 97-102. http://www.cnki.com.cn/Article/CJFDTOTAL-FXKX200801030.htm
[6] 申书昌,宋文成,贾鹏禹.硅氧烷-聚氨酯共聚物的制备及其作为固相微萃取头涂层用于分离水中芳香族化合物[J].理化检验:化学分册,2010,46(12): 1444-1446. http://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201012034.htm
[7] 李晓晶,贺小平,黄聪,甘平胜,于鸿.固相微萃取-气相色谱法同时测定饮用水中27种有机磷农药[J]. 中国卫生检验杂志,2009,19(6): 1231-1233. http://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ200906010.htm
[8] 秦宏兵,顾海东,孙欣阳,朱健禾.顶空固相微萃取-气相色谱法测定水中四乙基铅[J].中国环境监测,2012(4): 82-84. http://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201306019.htm
[9] 曾丹丹,陈宏,黄国方,廖建萌,罗林.固相微萃取技术在挥发性有机物分析中的应用研究进展[J].广东化工,2009,36(8): 315-316. http://www.cnki.com.cn/Article/CJFDTOTAL-GDHG200908153.htm
[10] 李文超,王永花,孙成,杨绍贵.分子印迹技术与固相微萃取技术联用的研究进展[J].环境化学,2011,30(9): 1663-1671. http://www.cnki.com.cn/Article/CJFDTOTAL-HJHX201109023.htm
[11] 刘静,曾兴宇,烟卫.自动顶空固相微萃取气相色谱法同步分析水中17种有机物[J].分析试验室,2012,29(12): 55-58. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201012014.htm
[12] 何小波,刘秀华,林涛.饮用水中氯仿和四氯化碳的顶空固相微萃取气相色谱测定法[J].环境与健康杂志,2010,27(7): 629-631. http://www.cnki.com.cn/Article/CJFDTOTAL-HJYJ201007028.htm
[13] 孔娜,邹小兵,黄锐,夏之宁,魏欣旸.微波辅助-顶空液相微萃取在线联用-高效液相色谱法测定环境水样中的敌敌畏[J].色谱,2010,28(12): 1200-1203. http://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ201012020.htm
[14] 余胜兵,朱炳辉,许瑛华. 聚氯乙烯(PVC)管材中氯乙烯单体的溶解沉淀-顶空-气相色谱法测定[J].分析测试学报,2010,29(10): 1083-1086. doi: 10.3969/j.issn.1004-4957.2010.10.018
[15] Huang S P, Huang S D. Determination of organochlorine pesticides in water using solvent cooling assisted dynamic hollow-fiber-supported headspace liquid-phase microextracrion [J].Journal of Chromatography A, 2007,1176: 19-25. doi: 10.1016/j.chroma.2007.10.073
[16] Bordajandi L R, Ramosl J J, Sanz J, Gonzalez M J, Ramos L. Comprehensive two-dimensional gas chromato-graphy in the screening of persistent organohalogenated pollutants in environmental samples[J]. Journal of Chromatography A, 2008,1186: 312-324. doi: 10.1016/j.chroma.2007.12.013
[17] 唐巧玉,周毅峰.快速溶剂萃取法提取水芹中总黄酮工艺研究[J].食品科学,2010,31(22): 190-193. http://www.cnki.com.cn/Article/CJFDTOTAL-SPKX201022042.htm
[18] 周延生, 王涵文,关亚风.加压溶剂萃取法萃取大气颗粒物中的烷烃[J].分析化学,2004,32(8): 983-987. http://www.cnki.com.cn/Article/CJFDTOTAL-FXHX200408000.htm
[19] 陈云霞,游静,梁冰,王国俊.吹扫/捕集-热脱附气相色谱法研究吸附剂富集水中痕量挥发性有机物的效果[J].分析化学,27(10): 1186-1189. doi: 10.3321/j.issn:0253-3820.1999.10.017
[20] 左海英,桂建业,张琳.吹扫捕集-气相色谱/质谱联用测定水中30种挥发性有机物[J].南水北调与水利科技,2008,6(6): 81-83. http://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201521008.htm
[21] 郭永泽,张玉婷,李娜,刘磊,邵辉,李辉,程奕.农产品中多种农药残留的气相色谱-质谱联用法测定[J].分析测试学报,2010,29(12): 1186-1195. doi: 10.3969/j.issn.1004-4957.2010.12.013
[22] 章晴,邹积鑫,石高军.超高效液相色谱-质谱联用法与气相色谱-质谱联用法分析水性印油印记的主要成分[J].色谱,2010,28(12): 1132-1136. http://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ201012006.htm
-
