Study on Firing Technique of Celadon Wares Excavated from Caocun Kiln in Linzhang, Hebei Province
-
摘要: 河北地区古代瓷窑产品的理化测试工作多集中于隋唐、宋金时期的器物，北朝等早期产品的分析数据则少有报道。本文运用X射线荧光光谱、X射线衍射、岩相、吸水率测试和烧成温度测定等分析方法，对曹村窑址出土青釉样品的工艺特征开展研究。结果表明，2件样品釉层氧化钙含量分别为17.86%和14.1%，烧成温度分别达到1150.1℃和1185.2℃，证明这2件样品属于青瓷，从而证实了曹村窑是已发现的我国北方早期烧制青瓷的窑口之一；其余样品釉层氧化铅含量大于42%，部分样品吸水率低于5%，X射线衍射结果显示胎体中出现莫来石相，证明曹村窑可以生产出瓷胎铅釉陶。结合样品烧成温度均在1000℃以上，远高于铅釉成熟温度，推断曹村窑的瓷胎铅釉陶在北朝时期已经使用了二次烧成工艺。这一复杂工艺的产生，有可能为唐三彩的出现作了技术铺垫。Abstract: Current research on ancient porcelain in Hebei province is focused mainly on samples of Sui, Tang, Song and Jin Dynasty, while porcelain of the Northern Dynasties attracts little attention. This paper reports a method using X-ray Fluorescence Spectrometry (XRF) analysis, X-ray Diffraction (XRD), lithofacies analysis, water absorption test and dilatometer were to study the celadon wares excavated from the Caocun Kiln. In two samples, the contents of CaO were found to be 17.86% and 14.1%, with sintering temperatures of 1150.1℃ and 1185.2℃. In the remaining samples, the contents of PbO were no less than 42%, the water absorptions of partial samples were less than 5%, and mullite was found in the X-ray diffraction pattern. In conclusion, both celadon porcelain and lead-glaze pottery were found in the excavated artifact, which provides evidence to support the hypothesis that the Caocun kiln was one of the earliest kilns, manufacturing celadon porcelain in the north of China. The lead-glaze potteries were secondary sintered based on the sintering temperature of more than 1000℃, which was much higher than that for lead-glaze pottery. This new production technique may pave the way for tricolored glazed pottery at the Tang Dynasty. Conducting experiments such as these is helpful in the understanding of the development process of porcelains in North China.
-
-
表 1 样品烧成温度
Table 1. Firing temperature of the samples
样品编号 烧成温度/℃ Lc01 1052.1 Lc02 1181.7 Lc03 1119.9 Lc04 1101.9 Lc05 1000.2 Lc06 1055.6 Lc07 1044.8 Lc08 1160.6 Lc09 1153.4 CC01 1150.1 CC02 1185.2
下载: 导出CSV
表 2 样品釉层化学组成
Table 2. Chemical composition of the glazes in samples
样品编号 wB/% SiO2 Al2O3 PbO CaO Fe2O3 K2O P2O5 Lc01釉 40.662 11.264 42.337 1.326 2.283 1.308 0.820 Lc02釉 26.976 7.308 62.480 1.284 - 0.583 0.793 Lc03釉 40.129 10.672 43.529 0.792 1.790 1.625 1.463 Lc04釉 38.025 11.740 46.344 3.002 - 0.890 - Lc05釉 31.663 5.974 59.901 0.959 0.868 0.635 - Lc06釉 25.891 4.424 64.814 1.178 1.256 0.447 1.422 Lc07釉 25.220 5.705 62.125 1.907 1.790 0.732 1.502 Lc09釉 37.862 12.499 43.392 1.851 1.665 1.323 - CC01釉 56.390 15.290 - 17.860 3.260 3.760 0.990 CC02釉 55.040 21.970 - 14.100 4.720 2.130 -
下载: 导出CSV
表 3 样品胎体化学组成
Table 3. Chemical composition of the bodies in samples
样品编号 wB/% SiO2 Al2O3 PbO CaO Fe2O3 MgO K2O TiO SO3 Lc01胎 58.609 26.616 0.465 3.300 3.742 - 3.706 1.410 2.152 Lc02胎 52.166 20.751 0.182 6.530 4.534 1.525 3.456 1.409 7.910 Lc03胎 61.962 22.473 1.457 2.695 3.096 1.557 3.888 1.255 1.618 Lc04胎 62.472 25.928 0.836 1.828 3.007 1.116 3.503 1.257 - Lc05胎 63.957 26.347 0.610 1.747 1.553 0.766 3.381 1.207 - Lc06胎 62.850 26.977 - 1.236 2.102 1.001 3.416 1.256 1.163 Lc07胎 62.575 25.528 0.264 1.660 2.459 1.367 3.680 1.245 1.222 Lc08胎 65.027 24.560 0.052 1.757 2.510 - 3.163 1.956 0.724 Lc09胎 58.334 26.135 3.662 3.289 2.750 1.425 3.106 1.300 -
下载: 导出CSV
表 4 样品吸水率
Table 4. Water absorption of the samples
样品编号 m/g 吸水率/% 干重 饱水重 Lc01 32.09478 33.38478 4.02 Lc02 38.25151 40.93750 7.02 Lc03 11.59437 12.01521 3.63 Lc04 20.63156 21.35250 3.49 Lc05 15.12442 17.07270 12.88 Lc06 15.39489 18.18783 18.14 Lc07 9.05563 10.48190 15.75
下载: 导出CSV
-
[1] 李江.河北省临漳曹村窑址初探与试掘简报[M]//中国古陶瓷学会.中国古陶瓷研究(第十六辑).北京: 紫禁城出版社, 2010: 43-52.
[2] 刘毅, 袁胜文.北方早期青瓷初论[J].中原文物, 1992(2): 82-87. http://www.cnki.com.cn/Article/CJFDTOTAL-ZYWW199902011.htm
[3] 李迎华, 杨益民, 周卫荣, 董亚巍, 王昌燧, 金普军, 张尚欣.古代陶范原料配方含有草木灰的化学判断方法[J].岩矿测试, 2009, 28(2): 134-138. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200902015.htm
[4] 朱铁权, 王昌燧, 李艳, 毛振伟, 陈江峰, 后德俊, 蔡路武, 陈丽琼.不同窑口青白瓷瓷胎化学元素特征研究[J].岩矿测试, 2006, 25(2): 114-118. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200602003.htm
[5] 凌雪, 毛振伟, 冯敏, 胡耀武, 王昌燧, 刘洪淼.巩窑唐代早期白瓷的EDXRF线扫描分析[J].光谱学与光谱分析, 2005, 25(7): 1145-1150. http://www.cnki.com.cn/Article/CJFDTOTAL-GUAN200507036.htm
[6] 张茂林, 贾兴和, 毛振伟, 朱铁权, 王昌燧, 黄宇营, 何伟.斯里兰卡曼泰遗址出土青花瓷的化学成分分析及产地初探[J].岩矿测试, 2008, 27(1): 37-40. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200801011.htm
[7] 朱铁权, 王昌燧, 毛振伟, 袁传勋, 徐靖, 姚政权.不同窑口古瓷断面能量色散X射线荧光光谱线扫描分析[J].岩矿测试, 2007, 26(5): 381-384. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200705007.htm
[8] Villa R V, Giménez R G, Domínguez M D, Rucandio M I. Physicochemical and chemometric characterisation of late Roman amphorae from straits of Gibraltar [J]. Microchimica Acta, 2003, 142(1-2): 115-122. doi: 10.1007/s00604-002-0955-z
[9] Colomban P, Liem N Q, Sagon G, Tinh H X, Hoành T B. Microstructure, composition and processing of 15th Century vietnamese porcelains and celadons [J]. Journal of Cultural Heritage, 2003, 4(3): 187-197. doi: 10.1016/S1296-2074(03)00045-1
[10] Schleicher L S, Miller J W, Watkins-Kenney S C, Carnes-McNaughton L F, Wilde-Ramsing M U. Non-destructive chemical characterization of ceramic sherds from Shipwreck 31CR314 and Brunswick Town, North Carolina[J]. Journal of Archaeological Science, 2008, 35(10): 2824-2838. doi: 10.1016/j.jas.2008.05.012
[11] 李迎华, 王昌燧.瓷器测温的模拟实验研究[J].陶瓷学报, 2011, 32(3): 443-447. http://www.cnki.com.cn/Article/CJFDTOTAL-TCXB201103019.htm
[12] 施继龙, 董亚巍, 周卫荣, 戴志强, 王昌燧.萧梁钱范烧成温度的测试分析[J].文物保护与考古科学, 2005(3): 7-11. http://www.cnki.com.cn/Article/CJFDTOTAL-WWBF200503002.htm
[13] 周理坤, 王涛, 李珺, 任雪岩, 王昌燧.南庄头遗址早期陶器烧成温度研究[J].岩矿测试, 2010, 29(2): 148-152. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201002017.htm
[14] 李敏生, 黄素英. 山西襄汾陶寺遗址陶片的测试和分析[J].考古, 1993(2): 176-188. http://www.cnki.com.cn/Article/CJFDTOTAL-KAGU199302011.htm
[15] 李乃胜, 张敬国, 毛振伟, 冯敏, 胡耀武, 王昌燧.五千年前陶质建材的测试研究[J].文物保护与考古科学, 2004(4): 13-20. http://www.cnki.com.cn/Article/CJFDTOTAL-WWBF200402002.htm
[16] 郑乃章, 刘阳, 朱小平, 张勇, 王群.景德镇瓷坯料组成与性能的关系[J].陶瓷学报, 1999, 20(2): 92-98. http://www.cnki.com.cn/Article/CJFDTOTAL-TCXB199902005.htm
[17] 徐安武, 杨晓勇, 林辉, 王昌燧, 王吉怀, 梁中合, 陈星灿.安徽蒙城尉迟寺遗址大口尊古陶器的稀土元素地球化学研究[J].稀土, 1999, 20(3): 3-6. http://www.cnki.com.cn/Article/CJFDTOTAL-XTZZ903.000.htm
[18] 杨益民, 汪丽华, 朱剑, 王昌燧, 阎焰, 陈栋梁, 何伟, 黄宇营, 华巍, 徐伟.红绿彩瓷化妆土的线扫描分析[J].核技术, 2008, 31(9): 653-657. http://www.cnki.com.cn/Article/CJFDTOTAL-HJSU200809003.htm
[19] 罗武干, 秦颍, 田建花, 王昌燧.淮阴高庄战国墓出土青铜器产地初步研究[J].土壤, 2009, 41(4): 670-675. doi: 10.11766/trxb200711120415
[20] 李家治.古代中国陶瓷的科学技术——中国文化中的火凤凰[M]//王昌燧, 主编.科技考古论丛(第二辑).合肥: 中国科学技术大学出版社, 2000: 5-12.
[21] 俞康泰.现代陶瓷色釉料与装饰技术手册[M].武汉: 武汉理工大学出版社, 1999: 135-141.
[22] 李家治.中国科学技术史陶瓷卷[M].北京: 科学出版社, 1998: 116-119, 167,467.
[23] 李家驹.日用陶瓷工艺学[M].武汉: 武汉工业大学出版社, 1992: 293-297.
[24] 陈彦堂.关于汉代低温铅釉陶器研究的几个问题[M]//古代文明(第4卷).北京: 文物出版社, 2008: 303-315.
-
