Low Impact Development construction of peak cluster depression based on regulation of epikarst zone
-
摘要:
岩溶峰丛洼地地区石漠化、饮水困难和水污染等环境问题高发，生态环境十分脆弱。低影响开发概念的引入有助于规范开发行为，促进水资源的高效利用，降低石漠化和地下河污染风险。根据水文条件和开发方式岩溶洼地空间分为坡耕地水土流失敏感区、表层岩溶泉水源地敏感区和落水洞污染输入敏感区。低影响开发模式总体是在3类敏感区实现5个管理目标。坡耕地敏感区的低影响开发目标设置为降低农田耗水量和减少水土流失，开发途径是减少蒸发和调控坡面洪水径流。表层岩溶泉敏感区的管理目标是降雨－径流资源化利用和饮用水安全保障，通过实施雨水收集回用工程和设置水源地保护区来实现。落水洞敏感区需要通过设置径流缓冲区和沉淀过滤池来预防污染物进入。我国南方石漠化地区探索和总结出以表层岩溶带降雨－径流管理为特征的低影响开发模式。该模式要求峰丛顶部留置生态保护区涵养水源。岩溶洼地底部为落水洞排洪预留缓冲区，利用岩溶裂缝设置下凹式绿地，实现自然渗透和净化。“峰”、“洼”之间过渡区划定水源地保护区边界，同时设法增加雨水资源化利用率，补充生态和生活缺水量。低影响开发模式也适用于峰丛洼地发育的东南亚和中美洲等地区。
Abstract:Most of the bare karst areas environments with the widest distribution in southern China have peak cluster depression landforms. With high incidence of many environmental problems such as rocky desertification, flood, water shortage, and water pollution, the karst environment there is proved to be very fragile. For the bare karst environment, it has a very developed subterranean river drainage networks, causing most of the water resources to enter the aquifer, and then flow and discharge rapidly through the underground karst conduits. For a long time, as a karst living environment, the lack of water and soil resources have become the main cause of environmental degradation.The introduction of the concept of Low Impact Development (LID) is necessary and timely in the karst peak-cluster depression area, based the rich research and practice in southern China. It is believed to be effective for promoting the utilization of water resources, reducing human disturbance, and covering the other environmental problems, such as rocky desertification and risk of underground river pollution. The LID methods based on the regulation of the epikarst zone and sinkholes are mainly suitable for guiding the development of karst land in dolines and depressions. It is realized by solving the questions of how to plan the land use and to design the rural infrastructure according to the special hydrogeological conditions and epikarst hydrological process. The concept and technology of LID in view of urban facilities will give guidance for the construction of a holistic environmental remediation project in a rural area, including water resources storage, pollutant treatment, and land restoration for rocky desertification. It is very helpful to promote rural revitalization in the remote and fragile ecological environment area of karst rocky mountains. Karst dolines naturally have topographic and hydrogeological conditions that promote rapid rainfall infiltration. Controlled by monsoon climate, the karst environment is characterized by distinct rainy season and dry season. Due to the lack of soil cover, storm water forms various types of runoff on the rocky slope, which flows into the underground river eventually through epikarst zone and sinkholes. The epikarst zone with a high degree of karstification has high hydraulic conductivity and regulation and storage function with a large number of small caves. It is the main water storage space on the slope and forms the epikarst spring. The bottom of the depression is flat with continuous soil cover. The flood is discharged by the sinkhole, but sometimes the groundwater inversely enters the karst depression through the sinkhole, resulting in waterlogging. Karst depressions are widely used as living space and agricultural planting. According to its terrains, development practice and disturbance intensity, the land of karst doline can be divided into three kinds of sensitive areas, and they are, (1) sloping farmland with risk of soil erosion, (2) epikarst springs for drinking water source with risk of pollution, and (3) the sinkholes with risk of contaminant input. The LID model would try to achieve five management goals in the three sensitive areas.(1) The goal of LID in the sloping farmland is to minimize water consumption by crop irrigation and to protect precious and thin soil from erosion, which technically can be achieved by requiring a filtering system such as building terraced fields, interception basin and straw mulching, so as to regulate soil moisture and slope flood runoff. (2) The management goals of the sensitive areas of epikarst springs are the utilization of rainfall-runoff resources and the ensurence of drinking water safety, which technically can be achieved by implementing rainwater harvesting projects and setting up water source protection area. (3) Contaminant interception and absorption facilities, such as buffer zone and sedimentation and filtration ditch, should be built in the sensitive area of sinkhole for achieving the goal of stopping contaminants entering groundwater. The LID model for peak cluster, or “LID based on epikarst”, which is characterized by rainfall -runoff management in the epikarst zone, has been explored and summarized in the karst rocky desertification region of South China. The model requires reserving the water resources in the woodland area at the top of the peak in the process of development planning and utilization of karst depression, for enhancing the recharge by infiltration through epikarst zone. In the intensive utilization of land at the bottom of karst dolines, the buffer zone would be reserved for controlling flood discharge by sinkholes, and a low elevation green belt is set with filled karst grooves for promoting natural infiltration and purification. In the transition zone between “peak” and “doline”, the scope and boundary conditions of water confluence at epikarst spring should be clearly defined, and the boundary of the water source protection zone should be determined. At the same time, it is necessary to increase the utilization of rainwater to supplement the water shortage of ecosystems and living. Although LID model based on epikarst is raised from the rocky desertification control in southern China, it could be possibly extend to the karst areas in other regions such as Southeast Asia, where peak-cluster is also well developed.
-
-
表 1 峰丛洼地开发及环境管理措施
Table 1. Development of peak cluster depression and environmental management measures
类型 峰丛洼地的开发及环境影响 环境管理措施 岩石 土壤 植被 水 中国南方
岩溶坡改梯、采石、路基、隧道建设等改变岩溶结构 坡耕地土壤遭受严重侵蚀，质量下降 森林遭砍伐退化为灌木林或草坡 地表水、地下水、雨水综合利用缓解干旱，但产生更多生活废水 进行石漠化生态修复，建立环境友好的产业发展模式 印尼岩溶 采用石块砌墙保土，修建坡耕地 坡耕地种植引起水土流失 森林面积减少，转变为耕地或经济果木林 雨水资源化利用，同时农业活动和生活垃圾污染地下水 开发利用地下河建成集中供水点 菲律宾
岩溶采石、地震和台风引起滑坡和崩塌加速了岩溶风化和地质景观破坏 很小改变 森林面积减少，濒危物种受到威胁 开发岩溶泉和开采地下水。极端天气引起水资源短缺 建立保护区对环境进行全面的保护
下载: 导出CSV
表 2 岩溶洼地低影响开发的技术方法
Table 2. Technical methods of Low Impact Development in karst depressions
低影响开发目标 技术设计 技术实现 （1）充分利用雨水 构建人工集雨面，将雨水收集与表层岩溶带调蓄结合起来，利用岩溶空间的蓄水和净化能力 采用屋顶、路面、小广场作为集水面，并配置水质净化设施。利用表层岩溶带形成的自然排泄出口修建蓄水池。雨水收集后注入表层岩溶带，利用表层岩溶带的净化能力和调蓄功能 （2）保证表层岩溶泉饮用水安全 调查坡面表层岩溶带发育特征，建立表层岩溶泉保护区 绘制表层岩溶发育剖面图，编制表层岩溶带水文地质图，划分表层岩溶泉水源地保护的核心区和缓冲区 （3）降低农田耗水 选种优良品种、探索农林混作模式、增强土壤保水能力 修建渗水池、挡土墙，进行坡改梯，实施客土回填、秸秆还田 （4）减少水土流失 增强表土抗侵蚀性、拦蓄坡面流、堵住地下漏失 通过拦水坝收集地表径流。落水洞周围设置下凹式绿地和植草沟等拦截沉淀泥沙 （5）保护地下水环境 划定地下水生态保护红线，增强水源涵养作用 在陡坡、裸岩地、风水林、水源林等有条件的地区设置为生态保护区。严禁弃渣和垃圾填埋、污水处理未达标排放等行为
下载: 导出CSV
-
[1] Marín A I, Martín Rodríguez J F, Barberá J A. Groundwater vulnerability to pollution in karst aquifers, considering key challenges and considerations: application to the Ubrique springs in southern Spain[J]. Hydrogeology Journal, 2021, 29:379-396. doi: 10.1007/s10040-020-02279-8
[2] Gunn J. Karst groundwater in UNESCO protected areas: a global overview[J]. Hydrogeology Journal, 2021, 29:297-314. doi: 10.1007/s10040-020-02206-x
[3] Gregorič A C. Typical Doline and Surface Landforms of Kras (Slovenia): Karst Landscape Features and Possibilities for Their Conservation[J]. Geoheritage, 2021, 13:26. doi: 10.1007/s12371-021-00544-0
[4] 蒋忠诚, 罗为群, 童立强, 程洋, 杨奇勇, 吴泽燕, 梁建宏. 21世纪西南岩溶石漠化演变特点及影响因素[J]. 中国岩溶, 2016, 35(5):461-468.
JIANG Zhongcheng, LUO Weiqun, TONG Liqiang, CHENG Yang, YANG Qiyong, WU Zeyan, LIANG Jianhong. Evolution features of rocky desertification and influence factors in karst areas of southwest China in the 21st century[J]. Carsologica Sinica, 2016, 35(5):461-468.
[5] 袁成军, 熊康宁, 容丽, 翁应芳. 喀斯特石漠化生态恢复中的生物多样性研究进展[J]. 地球与环境, 2021, 49(3):336-345.
YUAN Chengjun, XIONG Kangning, RONG Li, WENG Yingfang. Research progress on the biodiversity during the ecological restoration of karst rocky desertification[J]. Earth and Environment, 2021, 49(3):336-345.
[6] 罗旭玲, 王世杰, 白晓永, 谭秋, 冉晨, 陈欢, 习慧鹏, 陈飞, 操玥, 吴路华, 李汇文, 钟昕. 西南喀斯特地区石漠化时空演变过程分析[J]. 生态学报, 2021, 41(2):680-693.
LUO Xuling, WANG Shijie, BAI Xiaoyong, TAN Qiu, RAN Chen, CHEN Huan, XI Huipeng, CHEN Fei, CAO Yue, WU Luhua, LI Huiwen, ZHONG Xin. Analysis on the spatio- temporal evolution process of rocky desertification in Southwest Karst area[J]. Acta Ecologica Sinica, 2021, 41(2):680-693.
[7] 王克林, 岳跃民, 陈洪松, 曾馥平. 科技扶贫与生态系统服务提升融合的机制与实现途径[J]. 中国科学院院刊, 2020, 35(10):1264-1272.
WANG Kelin, YUE Yuemin, CHEN Hongsong, ZENG Fuping. Mechanisms and Realization Pathways for Integration of Scientific Poverty Alleviation and Ecosystem Services Enhancement[J]. Bulletin of Chinese Academy of Science, 2020, 35(10):1264-1272.
[8] 姜光辉, 郭芳. 岩溶水柜集流坡面的径流模式和调控建议[J]. 水科学进展, 2021, 32(2):271-278.
JIANG Guanghui, GUO Fang. Runoff pattern and adjusting measure of the karst slope for tanks[J]. Advances of Water Science, 2021, 32(2):271-278.
[9] 住房和城乡建设部印发: 《海绵城市建设技术指南: 低影响开发雨水系统构建》[J]. 建设科技, 2015(1): 10.
Ministry of Housing and Urban-Rural Development issued:technical guidelines for sponge city construction: low-impact development of rainwater system construction[J].Construction Science and Technology, 2015(1):10.
[10] LIANG Fuyuan, DU Yunyan, GE Yong, LI Ce. A quantitative morphometric comparison of cockpit and doline karst landforms[J]. Journal of Geography Sciences, 2014, 24:1069-1082. doi: 10.1007/s11442-014-1139-6
[11] 王宇. 岩溶高原地下水径流系统垂向分带[J]. 中国岩溶, 2018, 37(1):1-8.
WANG Yu. Vertical zoning of groundwater runoff system in karst plateau[J]. Carsologica Sinica, 2018, 37(1):1-8.
[12] 何师意, 袁道先,Do Tuyet. 越南北部岩溶特征及其相关环境问题[J]. 中国岩溶, 1999,12(1):90-95.
HE Shiyi, YUANG Daoxian, Do Tuyet. Characteristics of karst in northern Vietnam and its relevant environmental problems[J]. Carsologica Sinica, 1999,12(1):90-95.
[13] JIANG Guanghu, CHEN Zhao, Chaiporn Siripornpibul, Eko Haryono, GUO Fang. The karst water environment in Southeast Asia: Characteristics, Challenges, and approaches[J]. Hydrogeology Journal, 2021, 29: 129-135.
[14] Riyanto Indra Agus,Widyastuti M,Cahyadi Ahmad,Agniy Romza Fauzan,Adji Tjahyo Nugroho. Groundwater Management Based on Vulnerability to Contamination in the Tropical Karst Region of Guntur Spring, Gunungsewu Karst, Java Island, Indonesia[J]. Environment Process, 2020, 7:1277-1302. doi: 10.1007/s40710-020-00460-5
[15] 张宪鑫. 浅析印尼巴齐丹火电厂岩溶地基处理[J]. 东方电气评论, 2010, 24(3):55-61. doi: 10.3969/j.issn.1001-9006.2010.03.012
ZHANG Xianxin. Method of karstification groundwork treatment for Indonesia Pacitan Power Plant[J]. Dongfang Electric Review, 2010, 24(3):55-61. doi: 10.3969/j.issn.1001-9006.2010.03.012
[16] Moyra E, J Wilson. Cenozoic carbonates in Southeast Asia: implications for equatorial carbonate development[J]. Sedimentary Geology, 2002, 147(3-4): 295-428.
[17] Boquet Y. It’s More Fun in the Philippines? The Challenges of Tourism[M]. In: The Philippine Archipelago. Springer Geography. Springer, Cham, 2017.
[18] 王宇, 张华, 张贵, 彭淑惠, 杨文礼, 蔡保新, 冯敏, 王梓溦. 云南省石漠化调查及治理综述[J]. 中国岩溶, 2016, 35(5):486-496.
WANG Yu, ZHANG Hua, ZHANG Gui, PENG Shuhui, YANG Wenli, CAI Baoxin, FENG Min, WANG Ziwei. Review of the investigation and integrated renovation on rocky desertification in Yunnan Province, China[J]. Carsologica Sinica, 2016, 35(5):486-496.
[19] 郭永丽, 姜光辉, 赵红亮, 王紫燕, 苑晓雨. 峰丛洼地典型家庭水柜水量及水质的动态变化特征[J]. 中国农村水利水电, 2017(10):40-44. doi: 10.3969/j.issn.1007-2284.2017.10.008
GUO Yongli, JIANG Guanghui, ZHAO Hongliang, WANG Ziyan, YUAN Xiaoyu. Dynamic variation characteristics of water quantity and water quality of typical family water tanks in peak-cluster depression[J]. China Rural Water and Hydropower, 2017(10):40-44. doi: 10.3969/j.issn.1007-2284.2017.10.008
[20] 高璟钰, 朱林阁, 李晓娜. 生物慢滤技术在石漠化农村中的探索与实践[J]. 中国农村水利水电, 2016 (7):25-29.
GAO Jiangyu, ZHU Linge, LI Xiaona. Exploration and implementation of bio-slow sand filtration technology in rural rocky desertification Areas [J]. China Rural Water and Hydropower, 2016 (7):25-29.
[21] 王涛, 吴启美, 莫光员, 张朝晖. 涟江上游表层岩溶泉水污染源解析[J]. 环境化学, 2021, 40(3):729-736. doi: 10.7524/j.issn.0254-6108.2020010304
WNG Tao, WU Qimei, MO Guangyuan, ZHANG Zhaohui. Analysis on pollution sources of epikarst spring water in the upper reach of Liangjiang River[J]. Environmental Chemistry, 2021, 40(3):729-736. doi: 10.7524/j.issn.0254-6108.2020010304
[22] 黄凯, 刘瑞禄, 覃莉, 宋涛, 刘忠仙, 李瑞. 不同降雨条件下坡长对喀斯特坡面土壤侵蚀的影响[J]. 应用生态学报, 2021, 32(1):271-280.
HUANG Kai, LIU Ruilu,QIN Li, SONG Tao, LIU Zhongxian, LI Rui. Effects of slope length on soil erosion of karst slope under different rainfall conditions[J]. Chinese Journal of Applied Ecology, 2021, 32(1):271-280.
[23] 盘礼东, 李瑞, 黎庆贵, 黄凯, 张琳卿. 黔西喀斯特区秸秆覆盖对坡耕地产流产沙特征的响应[J]. 水土保持学报, 2021, 35(1):9-16.
PAN Lidong, LI Rui, LI Qinggui, HUANG Kai, ZHANG Linqing. Effects of straw mulching on runoff and sediment characteristics of sloping farmland in the karst area of western Guizhou[J]. Journal of Soil and Water Conservation, 2021, 35(1):9-16.
[24] 黄玉清, 何成新, 王晓英, 李先琨, 陆树华. 西南喀斯特山区农果草系统耦合及生产效益分析: 以广西平果县果化镇龙何屯为例[J]. 中国生态农业学报, 2007, 15(6):156-160.
HUANG Yuqing, HE Chengxin, WANG Xiaoying, LI Xiankun, LU Shuhua. ntegrated crop, fruit and pasture system and its eco-economic benefits in Southwest China karst terrain:A case study of Longhe Village, Guohua Town, Pingguo County, Guangxi Zhuang Autonomous Region[J]. Chinese Journal of Eco-Agriculture, 2007, 15(6):156-160.
[25] 吴清林, 梁虹, 熊康宁, 李瑞. 石漠化环境水土综合整治与山地混农林业前沿理论与对策[J]. 水土保持学报, 2018, 32(2):11-18,33.
WU Qinglin, LIANG Hong, XIONG Kangning, LI Rui. Frontier theories and countermeasures for integrated regulation of soil and water loss and mountainous agroforestry in rocky desertification environment[J]. Journal of Soil and Water Conservation, 2018, 32(2):11-18,33.
[26] 中华人民共和国国家环境保护标准. 农村饮用水水源地环境保护技术指南( HJ 2032-2013), 2013.
Ministry of Environmental Protection, PRC. Guideline on technologies of pollution prevention and control for rural drinking water sources envimental protection, HJ 2032-2013, 2013.
-
