摘要:
娘子关泉域群泉是中国北方最大的岩溶泉,泉域汇水面积达7 436 km2,前人认为:泉域内岩溶水由北、西、南3面向娘子关一带径流汇集,由于娘子关一带下奥陶系燧石团块或条带白云岩相对隔水层隆起,并被桃河侵蚀出露,使岩溶地下水溢出地表成泉群,其主要含水层为中奥陶系含石膏碳酸盐岩。但各泉的水化学、同位素特征有差异,娘子关泉群并不是出自统一源。文章通过水化学、同位素、水文地质剖面等方法研究得出: 娘子关泉域存在两个含水层、三个子系统:中奥陶系灰岩含水层和中上寒武系白云岩含水层;西部奥陶系岩溶水系统、东部奥陶系岩溶水系统和东部中上寒武系岩溶水系统。泉域内城西泉与程家泉出露于中奥陶系下马家沟组泥灰岩之上,含水层为中奥陶系灰岩裂隙、溶隙水,由于区域下马家沟组泥灰岩隆起隔水出露地表成泉,属于东部奥陶系岩溶水系统;坡底泉、五龙泉、河北泉、水帘洞泉、苇泽关泉其补给主要来源于中上寒武系含水岩组,为承压上升泉,属于东部中上寒武系岩溶水系统。
Abstract:As a main natural discharge point of karst groundwater, Niangziguan spring group consists of 11 springs and is located in Niangziguan town, Yangquan City, Shanxi Province. It is distributed on the floodplain and terrace of the Taohe river, the Wenhe river and the Mianhe river, with an exposed elevation of 360 m to 392 m. Among these springs, Chengjia spring is the highest and Jinqu spring is the lowest. The annual average flow of spring group is 9.48 m3·s−1 and the flow differences of springs are large, among which the difference of Wulong spring is the largest. Niangziguan spring group is the largest karst spring in northern China, with a catchment area of 7,436 km2. Previous studies believe that karst water in the spring area flows from north, west and south to Niangziguan area, and the chert mass or strip dolomite of lower Ordovicianin Niangziguan area relatively rises to the aquifuge, and is eroded and exposed by the Taohe River, which makes the karst groundwater overflow to the surface and form a spring group. The main aquifer is made up of gypsum-bearing carbonate rock of middle Ordovician. However, because Niangziguan springs are not from the same source, their hydrochemistry and isotope are different. Therefore, it is necessary to study the source of Niangziguan spring group. This study is conducted with the methods of hydrochemistry, isotope and hydrogeological section, and is concluded that there are two aquifers and three subsystems in Niangziguan spring area. The aquifer consists of middle Ordovician limestone aquifer and middle upper Cambrian dolomite one. Subsystem distribution is comprised of Ordovician karst water system in the west, and Ordovician karst water system and middle upper Cambrian karst water system both in the East. Chengxi spring and Chengjia spring are exposed on the marl of lower Majiagou formation of middle Ordovician, and their aquifers consist of fissure and fissure water of Middle Ordovician limestone. Because the marl of lower Majiagou formation is uplifted in this region, the surface spring-the eastern Ordovician karst water system-is formed. Mainly supplied by the water-bearing formation of middle upper Cambrian, Podi spring, Wulong spring, Shibanmo spring, Shuiliandong spring and Weizeguan spring are pressure-bearing ascending springs and belong to the middle upper Cambrian karst water system in the east.
-
-
表 1 岩溶地下水水化学特征
Table 1. Hydrochemical characteristics of karst groundwater
编号 类型 pH Ca2+ Mg2+ K+ Na+ Cl− Sr δD δ18O 34S 水化学类型 /mg·L−1 /mg·L−1 /mg·L−1 /mg·L−1 /mg·L−1 /mg·L−1 /mg·L−1 /mg·L−1 /‰ /‰ /‰ N01 左权石港村 7.70 98.7 24.6 1.5 11.7 11.1 127.2 244.5 0.86 −68.0 −9.2 18.2 HCO3·SO4-Ca·Mg N02 昔阳大寨水源
地岩溶井7.55 75.8 18.9 1.2 6.6 9.0 44.9 262.0 0.38 −74.6 −10.2 7.2 HCO3-Ca·Mg N03 寿阳岩溶井 7.21 123.7 40.9 1.5 14.1 8.2 284.4 240.6 2.96 −73.1 −10.2 23.1 HCO3·SO4-Ca·Mg N04 小河村斜井岩溶井 7.24 235.0 45.7 4.9 124.2 111.1 596.0 320.2 1.17 −61.3 −8.2 4.7 HCO3-Ca·Mg N05 盂县岩溶井 7.36 291.6 44.4 1.6 95.0 34.9 744.7 359.0 1.26 −67.3 −9.1 18.1 HCO3·SO4-Ca N06 温池水源地岩溶井 7.60 90.6 22.6 0.9 9.6 12.2 90.4 277.5 0.63 −70.0 −9.6 8.5 HCO3·SO4-Ca·Mg N07 河底镇岩溶井 7.08 312.5 85.2 2.0 31.0 40.2 816.5 293.0 1.89 −65.5 −8.8 12.8 SO4-Ca·Mg N08 神子山岩溶井 7.56 82.3 25.0 1.3 11.7 12.3 68.8 262.9 0.54 −70.5 −9.5 3.7 HCO3-Ca·Mg N09 程家泉岩溶井 7.28 165.5 45.1 6.5 128.9 125.7 405.8 291.1 0.79 −62.2 −8.2 5.3 HCO3·SO4-Ca·Na N10 坡底泉 7.35 135.2 41.8 2.1 42.9 55.7 271.8 263.9 2.14 −71.6 −9.5 15.5 HCO3·SO4-Ca·Mg N11 城西泉 7.40 112.1 34.8 2.1 39.5 48.0 185.6 260.0 1.59 −67.1 −9.1 9.2 HCO3·SO4-Ca·Mg N12 五龙泉 7.36 131.4 39.7 2.1 42.1 55.7 251.7 263.9 1.97 −69.3 −9.4 16.7 HCO3·SO4-Ca·Mg N13 河北泉 7.32 134.1 41.2 2.1 43.1 57.7 262.0 267.8 2.10 −69.9 −9.4 17.4 HCO3·SO4-Ca·Mg N14 苇泽关泉 7.19 134.5 42.2 2.1 44.6 57.8 268.2 265.8 2.09 −70.5 −9.6 17.8 HCO3·SO4-Ca·Mg N15 水帘洞泉 7.31 135.0 42.0 2.1 44.5 57.9 267.3 265.8 2.10 −70.1 −9.5 17.4 HCO3·SO4-Ca·Mg N16 禁区泉 7.47 134.5 42.3 2.1 44.2 58.0 266.6 263.9 2.12 −70.6 −9.5 17.5 HCO3·SO4-Ca·Mg N17 滚泉 7.44 134.2 42.2 2.1 44.0 58.2 269.9 262.0 2.07 −70.4 −9.6 16.7 HCO3·SO4-Ca·Mg -
[1] 沈照理, 王焰新. 水—岩相互作用研究的回顾与展望[J]. 地球科学, 2002, 27(2):127-133.
SHEN Zhaoli, WANG Yanxin. Review and Outlook of Water Rock Interaction Studies[J]. Earth Science, 2002, 27(2):127-133.
[2] 王焰新, 马腾, 郭清海, 马瑞. 地下水与环境变化研究[J]. 地学前缘, 2005(S1):14-21.
WANG Yanxin, MA Teng, GUO Qinghai, MA Rui. Groundwater and environmental change[J]. Earth Science Frontiers, 2005(S1):14-21.
[3] 袁道先. 中国岩溶地球化学研究的进展[J]. 水文地质工程地质, 1990(5):41-42.
YUAN Daoxian. Advances in Karst geochemistry in China[J]. Hydrogeology & Engineering Geology, 1990(5):41-42.
[4] 唐春雷, 梁永平, 王维泰, 赵春红,申豪勇. 龙子祠泉域岩溶水水化学—同位素特征[J]. 桂林理工大学学报, 2017, 37(1):53-58. doi: 10.3969/j.issn.1674-9057.2017.01.007
TANG Chunlei, LIANG Yongping, WANG Weitai, ZHAO Chunhong,SHEN Haoyong. Hydrogeochemical and isotopic Characteristic of the karst Groundwater Systems, in Longzici spring basin[J]. Journal of Guilin University of Technology, 2017, 37(1):53-58. doi: 10.3969/j.issn.1674-9057.2017.01.007
[5] Q Xiao, Y Jiang, L Shen, D Yuan. Origin of calcium sulfate-type water in the Triassic carbonate thermal water system in Chongqing, China: A chemical and isotopic reconnaissance[J]. Applied Geochemistry, 2018, 89:49-58. doi: 10.1016/j.apgeochem.2017.11.011
[6] W Smykatz-Kloss, H Kossl, H Hotzl. The gypsum karst area of Foum Tatahouine, Southern Tunisia: Mineralogy and hydrogeochemistry[J]. Chemical Geology, 1990, 84(1):206-207.
[7] M A Schiavo, S Hauser, P P Povinec. Stable isotopes of water as a tool to study groundwater-seawater interactions in coastal south-eastern Sicily[J]. Journal of Hydrology, 2009, 364(1):40-49.
[8] M Musgrove, L A Stern, J L Banner. Springwater geochemistry at Honey Creek State Natural Area, central Texas: Implications for surface water and groundwater interaction in a karst aquifer[J]. Journal of Hydrology, 2010, 388(1):144-156.
[9] 唐春雷, 王桃良, 王维泰, 赵春红. 极端降水条件下北京西山黑龙关泉响应研究[J]. 水文, 2016, 36(6):70-75.
TANG Chunlei, WANG Taoliang, WANG Weitai, ZHAO Chunhong. Response of Heilongguan Spring to Extreme Precipitation in Xishan Mountain Area, Beijing[J]. Journal of China Hydrology, 2016, 36(6):70-75.
[10] 唐春雷, 郑秀清, 梁永平, 张发旺,景泽. 山西太原晋祠—平泉水力联系及对晋祠泉复流的贡献[J]. 中国地质, 2020, 47(6):1755-1764. doi: 10.12029/gc20200612
TANG Chunlei, ZHENG Xiuqing, LIANG Yongping, ZHANG Fawang,JING Ze. The hydraulic connection between Jinci and Pingquan in Taiyuan and its contribution to the reflow of Jinci spring[J]. Geology in China, 2020, 47(6):1755-1764. doi: 10.12029/gc20200612
[11] 高旭波, 王万洲, 侯保俊, 高列波,张建友,张松涛,李成城,姜春芳. 中国北方岩溶地下水污染分析[J]. 中国岩溶, 2020, 39(3):287-298.
GAO Xubo, WANG Wanzhou, HOU Baojun, GAO Liebo, ZHANG Jianyou, ZHANG Songtao, LI Chengcheng, JIANG Chunfang. Analysis of karst groundwater pollution in northern China[J]. Carsologica Sinica, 2020, 39(3):287-298.
[12] 梁永平, 韩行瑞. 优化技术在娘子关泉域岩溶地下水开采资源量评价与管理中的应用[J]. 水文地质工程地质, 2006(4):67-71. doi: 10.3969/j.issn.1000-3665.2006.04.017
LIANG Yongping, HAN Xingrui. Application of optimal technique to evaluation of expl oitable karstwater resources and its management in Niangziguan spring basin[J]. Hydrogeology& Engineering Geology, 2006(4):67-71. doi: 10.3969/j.issn.1000-3665.2006.04.017
[13] 刘再华. 娘子关泉群水的来源再研究[J]. 中国岩溶, 1989, 8(8):22-29.
LIU Zaihua. Restudy on the Source of Niangziguan springs[J]. Carsologica Sinica, 1989, 8(8):22-29.
[14] 李义连, 王焰新, 周来茹, 高红波,张江华. 地下水矿物饱和度的水文地球化学模拟分析: 以娘子关泉域岩溶水为例[J]. 地质科技情报, 2002, 21(1):32-36.
LI Yilian, WANG Yanxin, ZHOU Lairu, GAO Hongbo,ZHANG Jianghua. Hydrogeochemical Modeling on Saturation of minerals in Groundwater: A case study at Niangziguan, Northern China[J]. Geological Science and Technology Information, 2002, 21(1):32-36.
[15] 袁道先. 我国北方岩溶研究的形势和任务[J]. 中国岩溶, 2010, 29(3):219-221. doi: 10.3969/j.issn.1001-4810.2010.03.001
YUAN Daoxian. The situation and tasks for northern karst research of our country[J]. Carsologica Sinica, 2010, 29(3):219-221. doi: 10.3969/j.issn.1001-4810.2010.03.001
[16] 赵春红, 梁永平,卢海平,唐春雷,申豪勇,王志恒. 娘子关泉域岩溶水SO42−、δ34S特征及其环境意义[J]. 中国岩溶, 2019, 38(6):867-875.
ZHAO Chunhong, LIANG Yongping,LU Haiping,TANG Chunlei,SHEN Haoyong,WANG Zhiheng. Chemical characteristics and environmental significance of SO42− and sulfur isotope in the karst watershed of the Niangziguan spring, Shanxi Province[J]. Carsologica Sinica, 2019, 38(6):867-875.
[17] 梁永平, 高洪波, 张江华, 等. 娘子关泉流量衰减原因的初步定量化分析[J]. 中国岩溶, 2005, 34(3): 227-231. doi: 10.3969/j.issn.1001-4810.2005.03.011
LIANG Yongping, GAO Hongbo, ZHANG Jianghua, et al. Preliminary quantitative analysis on the causes of discharge attenuation in Niangziguan spring. [J]. Carsologica Sinica, 2005, 34 (3): 227-231. doi: 10.3969/j.issn.1001-4810.2005.03.011
[18] 梁永平, 赵春红, 唐春雷, 申豪勇,王志恒,郭芳芳. 山西娘子关泉水及污染成因再分析[J]. 中国岩溶, 2017, 36(5):633-640.
LIANG Yongping, ZHAO Chunhong, TANG Chunlei, SHEN Haoyong,WANG Zhiheng,GUO Fangfang. Reanalysis of spring water and its pollution causes of the Niangziguan spring in Shanxi[J]. Carsologica Sinica, 2017, 36(5):633-640.
[19] 唐春雷, 晋华, 梁永平, 赵春红,申豪勇,潘尧云,景泽. 娘子关泉域岩溶地下水位变化特征及成因[J]. 中国岩溶, 2020, 39(6):810-816.
TANG Chunlei, JIN Hua, LIANG Yongping,ZHAO Chunhong, SHEN Haoyong,PAN Yaoyun,JING Ze. Characteristics and Formation causes of Karst Groundwater Level variation in Niangziguan Spring Area[J]. Carsologica Sinica, 2020, 39(6):810-816.
[20] C Tang, H Jin, Y Liang. Using Isotopic and Hydrochemical Indicators to Identify Sources of Sulfate in Karst Groundwater of the Niangziguan Spring Field, China[J]. Water, 2021, 13(3):390. doi: 10.3390/w13030390
[21] B Capaccioni, O Vaselli, F Tassi, A P Santo,A D Huertas. Hydrogeochemistry of the thermal waters from the Sciacca Geothermal Field (Sicily, southern Italy)[J]. Journal of Hydrology, 2011, 396(3):292-301.
[22] R Ma, Y Wang, Z Sun, C Zheng,T Ma,H Prommer. Geochemical evolution of groundwater in carbonate aquifers in Taiyuan, northern China[J]. Applied Geochemistry, 2011, 26(5):884-897. doi: 10.1016/j.apgeochem.2011.02.008
[23] C Kohfahl, C Sprenger, J B Herrera, H Meyer,F F Chacón,A Pekdeger. Recharge sources and hydrogeochemical evolution of groundwater in semiarid and karstic environments: A field study in the Granada Basin (Southern Spain)[J]. Applied Geochemistry, 2008, 23(4):846-862. doi: 10.1016/j.apgeochem.2007.09.009
[24] S Pasvanoğlu. Hydrogeochemistry of thermal and mineralized waters in the Diyadin (Ağri) area, Eastern Turkey[J]. Applied Geochemistry, 2013, 38:70-81. doi: 10.1016/j.apgeochem.2013.08.010
[25] N Keul, G Langer, S Thoms, L J de Nooijer,G J Reichart,J Bijma. Exploring foraminiferal Sr/Ca as a new carbonate system proxy[J]. Geochimica et Cosmochimica Acta, 2017, 202:374-386. doi: 10.1016/j.gca.2016.11.022
[26] 唐春雷, 郑秀清, 梁永平. 龙子祠泉域岩溶地下水水化学特征及成因[J]. 环境科学, 2020, 41(5):2087-2095.
TANG Chunlei, ZHENG Xiuqing, LIANG Yongping. Hydrochemical Characteristics and Formation Causes of Ground Karst Water Systems in the Longzici Spring Catchment[J]. Environmental Science, 2020, 41(5):2087-2095.
[27] J Zhou, Q Zhang, F Kang, Y Zhang,L Yuan,D Wei,S Lin. Using multi-isotopes (34S, 18O, 2H) to track local contamination of the groundwater from Hongshan-Zhaili abandoned coal mine, Zibo city, Shandong province[J]. International Biodeterioration & Biodegradation, 2018, 128:48-55.
[28] H Mohammadzadeh, R Aravena. Investigating the Origin and Interaction between Karstic and Alluvial Aquifers in NW of Zagros Mountain Range, Iran, Using Isotopic and Geochemical Tools[J]. Procedia Earth and Planetary Science, 2015, 13:256-260. doi: 10.1016/j.proeps.2015.07.060
[29] F Xu, H Yuan, G Xu, X Luo. Fluid charging and hydrocarbon accumulation in the Cambrian Long wangmiao Formation of Moxi Structure, Sichuan Basin, SW China[J]. Petroleum Exploration and Development, 2018, 45(3):442-451. doi: 10.1016/S1876-3804(18)30049-1
[30] I Herms, J Jódar, A Soler, I Vadillo,L J Lambán,S Martos-Rosillo,J A Núñez,G Arnó,J Jorge. Contribution of isotopic research techniques to characterize high-mountain-Mediterranean karst aquifers: The Port del Comte (Eastern Pyrenees) aquifer[J]. Science of The Total Environment, 2019, 656:209-230. doi: 10.1016/j.scitotenv.2018.11.188
[31] E S B Santiago, R P Xavier, S G Hagemann, L V S Monteiro,J Cliff. Multiple sulfur isotopes constraints on origin and evolution of the Neoarchean and Paleoproterozoic Cu-Au systems from the Carajás Domain, Amazonian Craton, Brazil[J]. Ore Geology Reviews, 2020, 1038:72.
[32] C Erarslan, Y Örgün, N Balcı. Source and distribution of pyrite and inorganic sulfur isotopes in the Saray and Pınarhisar Coalfields, North Thrace Basin, Turkey[J]. International Journal of Coal Geology, 2020:227.
[33] B Yang, J Liu, X Shi, H Zhang,X Wang,Y Wu,X Fang. Mineralogy and sulfur isotope characteristics of metalliferous sediments from the Tangyin hydrothermal field in the southern Okinawa Trough[J]. Ore Geology Reviews, 2020:120.
[34] 唐春雷, 赵春红, 申豪勇, 梁永平,王志恒. 娘子关泉群水化学特征及成因[J]. 环境科学, 2021, 42(3):1416-1423.
TANG Chunlei, ZHAO Chunhong, SHEN Haoyong,LIANG Yongping,WANG Zhiheng. Chemical Characteristics and Causes of Groups Water in Niangziguan Spring[J]. Environmental Science, 2021, 42(3):1416-1423.
[35] 杨振华. 浅议矿区水文地质钻探工作[J]. 冶金管理, 2020(3):160,162.
YANG Zhenhua. Discussion on hydrogeological drilling in mining area[J]. China Steel Focus, 2020(3):160,162.
[36] 王磊. 水文地质钻探在土壤调查采样中的应用[J]. 黑龙江科学, 2020, 11(8):48-49. doi: 10.3969/j.issn.1674-8646.2020.08.023
WANG Lei. The Application of Hydrogeologic Drilling in the Sampling Survey of Soil Pollution[J]. Heilongjiang science, 2020, 11(8):48-49. doi: 10.3969/j.issn.1674-8646.2020.08.023
[37] 朱静静, 周宏. 水文地质剖面分析在岩溶水系统研究中的应用: 以鄂西响水洞岩溶水系统为例[J]. 安全与环境工程, 2017, 24(3):1-7,19.
ZHU Jingjing, ZHOU Hong. Application of Hydro geological Profile Analysis to Karst Water System A Case Study on Xiangshuidong Karst Water System in Western Hubei Province[J]. Safety and Environmental Engineering, 2017, 24(3):1-7,19.
[38] 蔡强, 王一楠. 基于组件式GIS的水文地质剖面图自动生成方法研究[J]. 中小企业管理与科技, 2017(5):141-142. doi: 10.3969/j.issn.1673-1069.2017.05.088
CAI Qiang, WANG Yinan. Research on Automatic Generation of Hydro geological Profile Based on Component GIS[J]. Management & Technology of SME, 2017(5):141-142. doi: 10.3969/j.issn.1673-1069.2017.05.088
[39] 刘广英. 巨城地堑对石太客运专线线路方案的影响[J]. 铁道勘察, 2004(6):27-29. doi: 10.3969/j.issn.1672-7479.2004.06.009
LIU Guangying. Impact of Jucheng Graben on Railroad Engineering[J]. Railway Investigation and Surveying, 2004(6):27-29. doi: 10.3969/j.issn.1672-7479.2004.06.009
[40] 郝永红, 黄登宇, 刘洁,王学萌. 娘子关泉域降水补给的时滞研究[J]. 中国岩溶, 2003, 22(2):11-14.
HAO Yonghong, HUANG Dengyu, LIU Jie, WANG Xuemeng. Study on time lag of precipitation recharge in Niangziguan Spring Area[J]. Carsologica Sinica, 2003, 22(2):11-14.
[41] 孙志鸿. 娘子关泉域泉口区岩溶水文地质特征分析[J]. 山西水利科技, 2017(3):51-53,61. doi: 10.3969/j.issn.1006-8139.2017.03.019
SUN Zhihong. Analysis on the Karst Hydrogeology Character of the Niangziguan Spring Exit Region[J]. Shanxi Hydrotechnics, 2017(3):51-53,61. doi: 10.3969/j.issn.1006-8139.2017.03.019
-
