Overview of field monitoring for acid mine water system of the coal mine in Shandi river basin
-
摘要:
酸性矿井水在我国鲁西南、山西、内蒙、云南和贵州等煤矿区普遍存在，酸性矿井水其pH往往在2~5之间，高SO42−、HB、TDS、Fe、Mn。这些物质进入地下水、地表水或土壤后，会对其造成严重危害。文章选择山西阳泉市典型废弃煤矿区山底河流域为研究区，通过水文地质调查，水文地质钻探，水文地质剖面等方法阐述山底流域地层岩性，水文地质条件概况，得出受煤矿开采影响，与天然条件下相比山底河流域的地表水和地下水的补给、径流、排泄条件均发生了根本变化。补给通过破坏产生的导水裂隙带运移，以垂向运动为主；径流通过坑道，导水裂隙带运移，以横向运动为主；排泄以矿坑排水和泉水溢出方式为主。并简述山底河流域煤矿酸性矿井水试验站观测站分布情况与水化学特征。
Abstract:Acid mine drainage (AMD) is widespread in coal mining areas such as southwest Shandong, Shanxi, Inner Mongolia, Yunnan and Guizhou. The pH value of acidic mine water often ranges between 2 and 5, with high sulfate, Hb, TDS(Total dissolved solids), Fe, Mn and others. The acidic characteristics of acid mine water make Hg, as, CD, Pb, Co, Ni and other trace elements dissolve in the coal seam, and hence accelerate the reaction speed of phenolic organics and increase the toxicological composition. These harmful substances will do severe harm to groundwater, surface water or soil. Shanxi Province, known as the "coal sea", is located in the middle reach of the Yellow River Basin. But the problem of coal resource depletion in Shanxi Province is gradually exposed. In 2010, the mined-out area covered about 20,000 square kilometers, accounting for one eighth of the land area of Shanxi Province. In the coming decades, a large number of acid mine water from closed coal mines in Shanxi Province will overflow and enter the surface water, and the groundwater will become a "permanent pollution source" exerting an extensive and profound impact. With two major water systems—the Yellow River Basin and the Haihe River Basin, Shanxi Province is known as the "water tower of north China Plain". Every year, nearly 5 billion cubic meters of surface water flows overseas, but the polluted surface water and groundwater resources may threaten the ecological environment of other river basins. Significant progress has been made in the study of the mechanism of acid mine water and environmental problems. However, most of the study areas are concentrated in Guizhou and other places in Southwest China, and relatively little research has been conducted in Shanxi, one of the semi-arid and semi humid areas, where the problem of potential acid drainage in coal mines is more serious. In this paper, the Shandi River Basin, a typical abandoned coal mine area in Yangquan City, Shanxi Province, is selected as the study area. Through hydrogeological survey, hydrogeological drilling, hydrogeological profile and other methods, the formation lithology and hydrogeological conditions of the Shandi river basin are described. It is concluded that due to the influence of coal mining, the supply, runoff and discharge conditions of surface water and groundwater in Shandi river basin have changed fundamentally, compared with natural conditions. The recharge mainly migrates vertically through the water-conducting fracture zone generated by destruction. The runoff mainly flows transversely through the tunnel and the water conducting-fracture zone. The drainage takes on two main types, pit drainage and spring overflow. The pH value of acid mine water in mountain basin is 2.47-7.28, averaging 4.17. Ca2+ value is 141.81-525.00 mg·L−1, averaging 408.48 mg·L−1. SO42− value is 1,084.55-13,683.47 mg·L−1, averaging167.82 mg·L−1. The hydro chemical types are Na-SO4, Ca·Mg-SO4, Mg-SO4andMg·Ca-SO4. The cations are mainly Ca2+, Mg2+ and Na+, and the anions are mainly SO42−. The acidification reaction rate of FeS2 in closed reduction environment is slow, but fast in open oxidation environment. The pH value of AMD at the main discharge outlet of Shandi river basin is 2.47, and the SO42− value is 3,848.5mg·L−1. The groundwater in this basin is mainly supplied by the infiltration of precipitation, surface water and coal mine drainage in the mined-out area, and finally discharges from Shandi village. Covering an area of 58.4 km2, Shandi river basin is a complete and independent water circulation system where open-pit mining, in-situ mining and closed pit mining are integrated. In this circulation system, water in all kinds converges in the mined-out area, and then discharges. With unique hydrogeological conditions, the basin is a field monitoring and testing site specific for the production, migration and discharge of acid drainage in coal mines. At the same time, it is also a research site for prevention and treatment.
-
-
表 1 山底河流域煤矿酸性水循环试验站水质及流量监测点汇总表
Table 1. Summary of water quality and flow monitoring points of acid water circulation test station of coal mines in Shandi river basin
站点名称 监测点
类别监测点
高程/m监测内容 山底站 降水 864 降水量/mm 西沟站 降水 973 榆林垴钻孔 矿坑水 991.5 pH、水温、电导率、溶解氧、Ca2+、Mg2+、K+、Na+、NH4+、Fe2+、Fe3+、Cl−、SO42−、CO32−、HCO3−、Mn、溶解性总固体等 小沟露天矿 矿坑水 857 庙沟泉 矿坑水 865 柳沟泉 矿坑水 832 山底河高桥堰 矿坑水 827 跃进煤矿岩溶井 岩溶水 908 山底村岩溶井 岩溶水 830 河底镇岩溶井 岩溶水 836 柳沟观测堰 矿坑水 831 主排泄点流量 山底河高桥观测堰 矿坑水 827 总出口流量（地表水+主排泄点） 温河入口观测堰 矿坑水 803.1 入温河口流量（地表水+主排泄点－灰岩段渗漏量）
下载: 导出CSV
-
[1] 武强, 刘宏磊, 赵海卿, 张萌, 刘守强. 解决矿山环境问题的九节鞭[J]. 煤炭学报, 2019, 44(1):10-22.
WU Qiang, LIU Honglei, ZHAO Haiqing, ZHANG Meng. LIU Shouqiang. Discussion on the nine aspects of addressing environmental problems of mining[J]. Journal of China Coal Society, 2019, 44(1):10-22.
[2] 唐春雷, 郑秀清, 梁永平. 龙子祠泉域岩溶地下水水化学特征及成因[J]. 环境科学, 2020, 41(5):2087-2095. doi: 10.13227/j.hjkx.201910078
TANG Chunlei, ZHENG Xiuqing, LIANG Yongping. Hydrochemical characteristics and formation causes of ground karst water systems in the Longzici spring catchment[J]. Environmental Science, 2020, 41(5):2087-2095. doi: 10.13227/j.hjkx.201910078
[3] 谢芳, 衰老矿井循环经济发展模式研究[D]. 青岛: 山东科技大学, 2008.
XIE Fang, Studies on the development model of circular economy in declined mine[D]. Qingdao: Shandong University of science and technology, 2008.
[4] 张立宽, 武强. 新中国70年煤炭工业铸就十大辉煌[J]. 中国能源, 2019, 41(10):4-8.
ZHANG Liquan, WU Qiang. Ten brilliance created by the coal industry within 70 years[J]. China of Energy, 2019, 41(10):4-8.
[5] 陆文娟. 2013年全国资源枯竭城市转型与发展论坛会议综述[J]. 全国商情, 2013(24):8-9.
LU Wenjuan. Summary of 2013 National Forum on transformation and development of resource exhausted cities[J]. China Circulation Economy, 2013(24):8-9.
[6] 武强, 涂坤. 我国发展面临能源与环境的双重约束分析及对策思考[J]. 科学通报, 2019, 64(15):1535-1544. doi: 10.1360/N972018-01057
WU Qiang, TU Kun. Analysis and countermeasures of China's development facing the dual constraints of energy and environment[J]. Chian Science Bulletin, 2019, 64(15):1535-1544. doi: 10.1360/N972018-01057
[7] 曹金亮, 张建萍, 王刚, 段丽军, 樊燕. 山西省矿山地质环境问题特征[J]. 华北自然资源, 2019(1):102-103.
CAO Jinliang, ZHANG Jianping, WANG Gang, DUAN Lijun, FAN Yan. Characteristics of mine geological environment problems in Shanxi Province[J]. Huabei Natural Resources, 2019(1):102-103.
[8] 李鹏飞. 山西八分之一土地成采空区[J]. 共产党员, 2011(21):49.
LI Pengfei. One eighth of the land in Shanxi is mined out area[J]. Communist Party Member, 2011(21):49.
[9] 李凤明, 王儒军, 王存煜. 资源枯竭型矿区综合治理与可持续发展[J]. 煤矿开采, 2004(3):7-10. doi: 10.3969/j.issn.1006-6225.2004.03.003
LI Fengming, WANG rujun, WANG Cunyu. Synthetically control and continuable development of resource exhausted mine area[J]. Coal Mining Technology, 2004(3):7-10. doi: 10.3969/j.issn.1006-6225.2004.03.003
[10] 贺秀全, 曹金亮, 许枝. 山西煤矿采空区塌陷地震特征与预报研究[J]. 中国地质灾害与防治学报, 1997(S1):116-121.
HE Xiuquan, CAO Jinliang, XU Zhi. Study on the Feature of collapse Earth quake Cause by Coal Ming and its forecast, Shanxi[J]. The Chinese Journal of Geological Hazard and Control, 1997(S1):116-121.
[11] Kiiskila J D, LI Kefeng, Sarkar D , Datta R. Metabolic response of vetiver grass (Chrysopogon zizanioides) to acid mine drainage[J]. Chemosphere, 2020, 240:124961.
[12] Ren K , Zeng J , Liang J, Yuang D X , Jiao Y J, Peng C , Pan X D. Impacts of acid mine drainage on karst aquifers: Evidence from hydrogeochemistry, stable sulfur and oxygen isotopes[J]. Science of The Total Environment, 2020.
[13] A Kastyuchik, A Karam, Ader Mohammed. The effect of electro-activation and eggshell powder on the neutralization of acid mine drainage[J]. Journal of Sustainable Mining, 2017, 16(3):73-82. doi: 10.1016/j.jsm.2017.09.002
[14] 赵峰华, 煤矿酸性水地球化学[M]. 北京: 煤炭工业出版社, 2005.
ZHAO Fenghua. Geo-chemistry of acid water in coal mine [M]. Beijing: Coal Industry Press, 2005.
[15] N F Gray. Acid mine drainage composition and the implications for its impact on lotic systems[J]. Water Research, 1998, 32(7):2122-2134. doi: 10.1016/S0043-1354(97)00449-1
[16] I S Chang, P K Shin, B H Kim. Biological treatment of acid mine drainage under sulphate-reducing conditions with solid waste materials as substrate[J]. Water Research, 2000, 34(4):1269-1277. doi: 10.1016/S0043-1354(99)00268-7
[17] M D González-Martínez, C Huguet, J Pearse, N Mcintyre, L A Camacho. Assessment of potential contamination of Paramo soil and downstream water supplies in a coal-mining region of Colombia[J]. Applied Geochemistry, 2019, 108:104382. doi: 10.1016/j.apgeochem.2019.104382
[18] J Zhang, F Liu, H Huang, R Wang, B Xu. Occurrence, risk and influencing factors of polycyclic aromatic hydrocarbons in surface soils from a large-scale coal mine, Huainan, China[J]. Ecotoxicology and Environmental Safety, 2020, 192:110269. doi: 10.1016/j.ecoenv.2020.110269
[19] 梁永平, 赵春红, 唐春雷, 申豪勇, 王志恒, 郭芳芳. 山西娘子关泉水及污染成因再分析[J]. 中国岩溶, 2017, 36 (5): 633-640.
LIANG Yongping, ZHAO Chunhong, TANG Chunlei, WANG Zhiheng, GUO Fangfang. Reanalysis on water and pollution causes of Niangziguan Spring in Shanxi Province [J] Carsologica Sinica, 2017, 36 (5): 633-640.
[20] 唐春雷, 郑秀清, 梁永平, 张发旺, 景泽. 山西太原晋祠—平泉水力联系及对晋祠泉复流的贡献[J]. 中国地质, 2020, 47(6):1755-1764. doi: 10.12029/gc20200612
TANG Chunlei, ZHENG Xiuqing, LIANG Yongping, ZHANG Fawang,JING ze. The hydraulic connection between Jinci and Pingquan in Taiyuan and its contribution to the reflow of Jinci spring[J]. Geology in China, 2020, 47(6):1755-1764. doi: 10.12029/gc20200612
[21] 唐春雷, 梁永平, 王维泰, 赵春红, 申豪勇. 龙子祠泉域岩溶水水化学-同位素特征[J]. 桂林理工大学学报, 2017, 37(1):53-58. doi: 10.3969/j.issn.1674-9057.2017.01.007
TANG Chunlei, LIANG Yongping, WANG Weitai, ZHAO Chunhong, SHEN Haoyong. Hydrogeochemical and isotopic Characteristic of the karst Groundwater Systems, in Longzici spring basin[J]. Journal of Guilin University of Technology, 2017, 37(1):53-58. doi: 10.3969/j.issn.1674-9057.2017.01.007
[22] 唐春雷, 赵春红, 申豪勇, 梁永平, 王志恒. 娘子关泉群水化学特征及成因[J]. 环境科学, 2021, 42(3):1416-1423. doi: 10.13227/j.hjkx.202007047
TANG Chunlei, ZHAO Chunhong, SHEN Haoyong, LIANG Yongping, WANG Zhiheng. Chemical characteristics and causes of groups water in Niangziguan Spring[J]. Environmental Science, 2021, 42(3):1416-1423. doi: 10.13227/j.hjkx.202007047
[23] C Tang, H Jin, Y Liang. Using Isotopic and Hydrochemical Indicators to Identify Sources of Sulfate in Karst Groundwater of the Niangziguan Spring Field, China[J]. Water, 2021, 13(3):390. doi: 10.3390/w13030390
[24] 梁永平, 申豪勇, 赵春红, 王志恒, 唐春雷. 对中国北方岩溶水研究方向的思考与实践[J]. 中国岩溶, 2021, 40(3):363-380.
LIANG Yongping, SHEN Haoyong, ZHAO Chunhong, WANG Zhiheng, TANG Chunlei. Thinking and practice on the research direction of karst water in northern China[J]. Carsologica Sinica, 2021, 40(3):363-380.
[25] 唐春雷, 晋华, 梁永平, 王志恒, 唐春雷. 娘子关泉域岩溶地下水位变化特征及成因[J]. 中国岩溶, 2020, 39(6):810-816.
TANG Chunlei, JIN Hua, LIANG Yongping, WANG Zhiheng, TANG Chunlei. Characteristics and Formation causes of Karst Groundwater Level variation in Niangziguan Spring Area[J]. Carsologica Sinica, 2020, 39(6):810-816.
[26] 韩行瑞, 高红波, 梁永平, 时坚. 大规模采煤对岩溶区水环境的影响[J]. 中国岩溶, 1994, 13(2):95-105.
HAN Xingrui, GAO Hongbo, LIANG Yongping, SHI Jian. The effect of large-scale coal mining on karst water environment[J]. Carsologica Sinica, 1994, 13(2):95-105.
[27] P Singer. Acid mine drainage: The rate-limiting step[J]. Science, 1970, 167(2):1121-1123.
[28] R L P Kleinmann, D A Crerar, R R Pacelli. Biogeo-chemistry of acid mine drainage and a method to control acid formation[J]. Mining Engineering, 2019, 33:300-306.
[29] M B Goldhaber. Experimental study of metastable sulfur oxyanion formation during pyrite oxidation at pH 6-9 and 30 ℃[J]. American Journal of Science, 1983, 283(3):193-217. doi: 10.2475/ajs.283.3.193
[30] Carl O Moses, D Kirk Nordstrom , Janet S Herman , Aaron L Mills. Aqueous pyrite oxidation by dissolved oxygen and by ferric iron[J]. Geochimica et Cosmochimica Acta 1987, 51(6): 1561-1571.
[31] L C Bryner, A K Jameson. Microorganisms in leaching sulfide minerals[J]. Applied Microbiology, 1958, 6(4):281-287. doi: 10.1128/am.6.4.281-287.1958
[32] L Bryner, R Anderson. Microorganisms in leaching sulfide minerals[J]. Industrial & Engineering Chemistry, 1957, 49(10):1721-1724.
-
