Recharge characteristics and protection of karst groundwater in major leakage area of Yufu river in Jinan
-
摘要:
玉符河是济南趵突泉域的重点渗漏带之一，是天然河道型渗漏带，其流域面积较大，具有较好来水条件，且卧虎山水库与锦绣城水库水系联通工程使其具备调水补源的条件，能通过增加外调补水增加重点渗漏带的补水能力。文章根据渗漏补给功能特征，采用RS、GPS、GS、物探测量、水文地质试验等技术手段，利用岩性、构造、地形、渗透性、植被覆盖度五大矢量数据的叠加分析方法，以主河道为中心划定玉符河重点渗漏带的保护范围，并利用变化参数法计算出玉符河重点渗漏带多年平均天然地下水补给量约为1 290万m3，其是岩溶地下水的重要补给来源。玉符河重点渗漏带的补水效果主要是通过提升西郊区域岩溶地下水水位，阻止趵突泉南部山区地下水向北径流过程中的向西分流，使地下水集中向泉水出露区汇聚，从而增大泉水的出流量。在保护渗漏带自然入渗功能的前提下，可充分挖掘玉符河重点渗漏带的补水功能，通过调水补源、河道生态修复、入河污染控制等措施，增大玉符河重点渗漏带的渗漏补给量。
Abstract:Jinan, called as "the city of thousands of springs", is famous for its large number of springs. The saying "the seventy-two famous springs in Jinan top those elsewhere" reflects a profound spring culture with a long history. Therefore, spring water conservation and research are very important. However, in Baotu Spring Group, the reduction of water level and spring flow in the dry season have to be faced with . The direct recharge area and the major leakage zone in the region of Baotu Spring are important recharge areas for karst groundwater. Especially, the major leakage zone is an important supply channel for spring water. As a natural river leakage zone with a large watershed area and better inflow conditions, the Yufu river is one of the major leakage zones in the region of Baotu Spring. Besides, by increasing the water replenishment capacity of major leakage zones with external water replenishment, the water system connection project of Wohushan Reservoir and Jinxiucheng Reservoir can transport and replenish water to the Yufu river.
Taking the main river as a research focus, we delimited the protection range of the major leakage zone of the Yufu river. In order to finish the delimitation, we analyzed the water replenishment function of leakage and adopted the techniques such as RS, GPS, GS, geophysical surveys and hydrogeological tests and LSDPV method. Meanwhile, the calculation by the method of variation parameters shows that the average recharge of nature groundwater in the major leakage zone of the Yufu river has reached 12.90 million m3 for recent years, becoming an important recharge source for karst groundwater. The water replenishment effect in the major leakage zone of the Yufu river has been achieved mainly by raising the karst groundwater level in the western area so as to prevent the westward diversion of groundwater in the northern runoff process in the southern mountainous area of Baotu Spring. In this process, the groundwater is concentrated in the spring outcropping area, and hence the spring discharge may increase. On the condition of protecting the nature infiltration of leakage zone, we can fully explore the water replenishment function and increase the replenishment of major leakage zones of the Yufu river by water diversion, ecological restoration and pollution control. The research finding shows that delimiting major protection areas for leakage zones is important for us to ensure the continuous gushing of springs. This study also provides a basis for the accurate and scientific protection of springs as well as technical support for urban development planning and protection of the famous springs in Jinan.
-
-
表 1 玉符河重点渗漏带渗水试验成果
Table 1. Infiltration tests in major leakage zones of the Yufu river
类型 试验点号 坐标 K/m·d−1 X Y 第四系 1-1 36.5205 116.919 4 10.49 1-2 23.23 1-3 18.13 钻孔试验 YFH2-1 36.537 4 116.886 9 66.66 YFH2-2 25.28 YFH-JK 251.94
下载: 导出CSV
-
[1] 宋剑英, 王建龙, 赵梦圆, 宫永伟, 李俊奇. 海绵城市建设促渗保泉方案及其效果评估: 以济南市海绵城市建设试点区为例[J]. 水利水电技术, 2019, 50(5):20-26.
SONG Jianying, WANG Jianlong, ZHAO Mengyuan, GONG Yongwei, LI Junqi. Evaluation of sponge city for the spring protection via improving groundwater recharge capacity: A case study of sponge city development in Jinan[J]. Water Resources and Hydropower Engineering, 2019, 50(5):20-26.
[2] 徐衍兰, 高宗军, 李佳佳. PHREEQC在济南泉水来源判别中的应用与效果[J]. 地下水, 2015, 37(1):4-5. doi: 10.3969/j.issn.1004-1184.2015.01.002
XU Yanlan, GAO Zongjun, LI Jiajia. Application and effects of PHREEQC in the source of Ji'nan Spring catchment[J]. Ground Water, 2015, 37(1):4-5. doi: 10.3969/j.issn.1004-1184.2015.01.002
[3] 汪洋, 李娟, 席北斗, 姬永红, 唐军, 刘剑聪, 崔亚莉. 基于数值模拟的岩溶地下水源保护区划分技术研究[J]. 中国岩溶, 2018, 37(6):799-809.
WANG Yang, LI Juan, XI Beidou, JI Yonghong, TANG Jun, LIU Jiancong, CUI Yali. Research on the division technology of karst groundwater source protection area based on numerical simulation[J]. Carsologica Sinica, 2018, 37(6):799-809.
[4] 管清花, 李福林, 王爱芹, 冯平, 田婵娟, 陈学群, 刘丹. 济南市岩溶泉域地下水化学特征与水环境演化[J]. 中国岩溶, 2019, 38(5):653-662.
GUAN Qinghua, LI Fulin, WANG Aiqin, FENG Ping, TIAN Chanjuan, CHEN Xuequn, LIU Dan. Hydrochemistry characteristics and evolution of karst spring groundwater system in Jinan[J]. Carsologica Sinica, 2019, 38(5):653-662.
[5] 万利勤. 济南泉域岩溶地下水的示踪研究[D]. 北京: 中国地质大学(北京), 2008.
WAN Liqin. Tracing study of karst groundwater in Jinan spring area[D]. Beijing:China University of Geosciences (Beijing), 2008.
[6] 梁永平, 申豪勇, 赵春红, 王志恒, 唐春雷, 赵一, 谢浩, 石维芝. 对中国北方岩溶水研究方向的思考与实践[J]. 中国岩溶, 2021, 40(3):363-380.
LIAGN Yongping, SHEN Haoyong, ZHAO Chunhong, WANG Zhiheng, TANG Chunlei, ZHAO Yi, XIE Hao, SHI Weizhi. Thinking and practice on the research direction of karst water in Northern China[J]. Carsologica Sinica, 2021, 40(3):363-380.
[7] 陈学群, 刘彩虹, 管清花, 田婵娟, 李成光, 辛光明. 趵突泉泉域洼地型强渗漏带特征及保护措施[J]. 人民黄河, 2020, 42(4):60-64. doi: 10.3969/j.issn.1000-1379.2020.04.012
CHEN Xuequn, LIU Caihong, GUAN Qinghua, TIAN Chanjuan, LI Chengguang, XIN Guangming. Characteristics and protection measures of depression type strong seepage zone in Baotu Spring area[J]. Yellow River, 2020, 42(4):60-64. doi: 10.3969/j.issn.1000-1379.2020.04.012
[8] 李传生, 祁晓凡, 王雨山, 安永会, 邢立亭. 我国北方典型岩溶地下水位对降水及气象指数的响应特征: 以鲁中地区为例[J]. 中国岩溶, 2019, 38(5):643-652.
LI Chuansheng, QI Xiaofan, WANG Yushan, AN Yonghui, XING Liting. Response characteristics of typical karst groundwater levels of central Shandong Province to precipitation and climatic index[J]. Carsologica Sinica, 2019, 38(5):643-652.
[9] 杜新强, 贾思达, 方敏, 冶雪艳. 海绵城市建设对区域地下水资源的补给效应[J]. 水资源保护, 2019, 35(2):13-17, 24. doi: 10.3880/j.issn.1004-6933.2019.02.002
DU Xinqiang, JIA Sida, FANG Min, YE Xueyan. Recharge effect of sponge city construction on regional groundwater resources[J]. Water Resources Protection, 2019, 35(2):13-17, 24. doi: 10.3880/j.issn.1004-6933.2019.02.002
[10] 刘玲, 王良学, 栾新杰. 济南市海绵城市建设与兴隆流域治理措施研究[J]. 水利规划与设计, 2017(8):40-42. doi: 10.3969/j.issn.1672-2469.2017.08.014
LIU Ling, WANG Liangxue, LUAN Xinjie. Research on the construction of sponge city in Jinan and the measures for the management of Xinglong river basin[J]. Water Resources Planning and Design, 2017(8):40-42. doi: 10.3969/j.issn.1672-2469.2017.08.014
[11] 孟庆斌, 邢立亭, 滕朝霞. 济南泉域“三水”转化与泉水恢复关系研究[J]. 山东大学学报(工学版), 2008(5):82-87.
MENG Qingbin, XING Liting, TENG Zhaoxia. The relationship of spring protection and transformation pattern between precipitation groundwater and surface water in the Jinan spring region[J]. Journal of Shandong University (Engineering Science), 2008(5):82-87.
[12] 刘彩虹, 陈学群, 田婵娟, 辛光明, 管清花, 李成光. 小岭村改造项目对济南泉域小岭强渗漏带的影响[J]. 长江科学院院报, 2020, 37(11):40-45. doi: 10.11988/ckyyb.20190872
LIU Caihong, CHEN Xuequn, TIAN Chanjuan, XIN Guangming, GUAN Qinghua, LI Chengguang. Impacts of Xiaoling Urban Village Renovation Project on leakage zone of Baotu Spring area, Jinan[J]. Journal of Yangtze River Scientific Research Institute, 2020, 37(11):40-45. doi: 10.11988/ckyyb.20190872
[13] 邢立亭. 济南泉域岩溶地下水开发布局研究[J]. 人民黄河, 2007, 29(2):46-47. doi: 10.3969/j.issn.1000-1379.2007.02.021
XING Liting. Study on the development and layout of karst groundwater in Jinan spring area[J]. Yellow River, 2007, 29(2):46-47. doi: 10.3969/j.issn.1000-1379.2007.02.021
[14] 王迪迪. 济南市回灌保泉方案安全评价体系研究[D]. 济南: 山东大学, 2014.
WANG Didi. Study on safety evaluation system for "Recharge Spring Protection" program in Jinan[D]. Jinan:Shandong University (Jinan), 2014.
[15] 魏建国, 张爱军, 蔡建波. 核心竞争力视域下济南市泉水保护机制研究[J]. 山东农业工程学院学报, 2017, 34(11):87-92. doi: 10.3969/j.issn.1008-7540.2017.11.018
WEI Jianguo, ZHANG Aijun, CAI Jianbo. A Study on the mechanism of the spring protection in Jinan in the core competitiveness perspective[J]. The Journal of Shandong Agriculture and Engineering University, 2017, 34(11):87-92. doi: 10.3969/j.issn.1008-7540.2017.11.018
[16] 于欣沛, 张慧, 张腾戈. 基于遥感技术的土地利用/土地覆盖的研究综述[C]. 中国环境科学学会. 2015年中国环境科学学会学术年会论文集, 2015: 1814-1819.
YU Xinpei, ZHANG Hui, ZHANG Tengge. Review of research on land use/land cover based on remote sensing technology[C]. Chinese Society for Environmental Sciences. Proceedings of 2015 Academic Annual Meeting of Chinese Society of Environmental Sciences, 2015:1814-1819.
[17] 黄凯, 杨飞. 浅析野外渗水试验及其渗透系数的计算[J]. 河南科技, 2013(22):191-192.
HUANG Kai, YANG Fei. Analysis of infiltration test in the field and calculation of its permeability coefficient[J]. Journal of Henan Science and Technology, 2013(22):191-192.
[18] 王东玥. 海绵城市在济南促渗保泉中的应用[J]. 城市建设理论研究(电子版), 2018(20):185-186.
WANG Dongyue. Application of sponge city in promoting infiltration and protecting springs in Jinan[J]. Theoretical Research in Urban Construction (Electronic Edition), 2018(20):185-186.
[19] 李道真. 山丘区三水转化及应用变参进行区域水资源计算方法研究(上)[J]. 中国人口资源与环境, 1989(1):44-49.
LI Daozhen. Study on calculating method of variable parameters in areal water resource evaluation and the interaction between surface water and groundwater[J]. Chinese Journal of Population, Resources and Environment, 1989(1):44-49.
[20] 李道真. 山丘区三水转化及应用变参进行区域水资源计算方法研究(下)[J]. 中国人口资源与环境, 1990(1):36-44.
LI Daozhen. Study on calculating method of variable parameters in areal water resource evaluation and the interaction between surface water and groundwater[J]. Chinese Journal of Population, Resources and Environment, 1990(1):36-44.
[21] 王红. 水土保持典型措施对地下水补给生态基流的影响研究[D]. 北京: 中国科学院大学, 2014.
WANG Hong. Study on the influence of typical measures of soil and water conservation on ecological base flow of groundwater recharge[D]. Beijing:University of Chinese Academy of Sciences, 2014.
[22] 王敏. 济南市南部山区水环境现状评价及保护性开发影响研究[D]. 济南: 山东师范大学, 2002.
WANG Min. Evaluation of water environment in southern mountain area of Jinan City and study on the impact of protective development[D]. Jinan:Shandong Normal University (Jinan), 2002.
-
