Trade-off and synergy of ecosystem services of a karst critical zone based on land use scenario simulation: Take Mengzi karst graben basin as a study case
-
摘要:
以蒙自喀斯特断陷盆地为例，利用CLUE-S模型设置自然演化、微度、适度、强力生态治理情景并探究2030年不同情景对生态系统服务的影响及权衡与协同特征。结果表明：（1）2018年蒙自喀斯特断陷盆地植被净初级生产力（NPP）、产水量、覆盖型喀斯特区土壤保持量、裸露型喀斯特区土壤保持量、食物供给量分别增加了13.98%、38.97%、23.04%、25%、105.43%，且各种服务变化存在一定的空间差异性；（2）随着生态治理力度加大，2030年NPP和土壤保持量不断增加，产水量不断减少，食物供给量在强力生态治理情景下减少，在其他三种情景下增加；（3）NPP与产水量、食物供给量为权衡关系，与土壤保持量为协同关系；产水量与土壤保持量为权衡关系，与食物供给量为协同关系；土壤保持量与食物供给量为权衡关系；（4）相较于2018年，适度生态治理情景下四种生态系统服务之间的协调性最好，是较为合理的生态治理模式。
Abstract:The karst critical zone is the near-surface layer of the Earth including vegetation, soil, water, and rocks in the karst area. It is sensitive to the changes of external environment due to the karst power provided by the Five Circles. And the karst critical zone has been regarded as one of the important ecological barrier areas in China. It is very necessary to study the ecological environment in the zone. Therefore, taking the Mengzi karst graben basin (MKGB) as a case, this study hopes to provide some suggestions for ecological governance in the karst critical zone.
MKGB is located in the southeast of Honghe Hani-Yi Autonomous Prefecture in Yunnan Province. Its boundary is almost consistent with the third-largest karst underground river system (the Nandong underground river watershed) in South China. With the influence of natural and human activities, karst rocky desertification is severe in this area. The forest is mainly composed of artificial forest, secondary forest and shrub forest. The ecosystem is imbalanced and the capability of ecosystem services has been reducing. At present, China has launched the project to control rocky desertification, and the main way is to return farmland to forest or grassland. Previous studies have also shown that optimizing land use mode can achieve win-win results between ecological environment and human benefits. However, the pattern and intensity of land use change is unclear in the control of rock desertification. It will be difficult to make reasonable policies for ecological protection if the problem is not paid more attention to. Ecosystem services and the relationship (trade-off and synergy) are important indicators to measure the structure of ecosystem. Therefore, we quantitatively analyzed the current status of ecosystem services and simulated the land use change to maximize ecosystem services in MKGB. In this study, we evaluated regional Net Primary Productivity (NPP), water yield, soil retention of covered and bare karst areas and food supply by respectively using Carnegie-Ames Stanford Approach (CASA model), Integrated Valuation of Ecosystem Services and Tradeoffs (InVEST model), the Revised Universal Soil Loss Equation (RUSLE model) and food supply model. Besides, in order to find the optimal land use mode, we also set up four scenarios—natural scenario, mild ecological governance scenario, moderate ecological governance scenario and strong ecological governance scenario—by the Conversion of Land Use and its Effects at Small Region Extent (CLUE-S model). Then we explored the impacts of different ecological governance scenarios on ecosystem services and their tradeoff or synergistic characteristics.
Results show that ecological land use experienced an increasing trend from 2006 to 2018, which reflected that the land conversion was reasonable in the process of rock desertification control, and the effect of rock desertification control was obvious. In 2030, the continuous strengthening of ecological governance will contribute to the increase of forest land and the decrease of cultivated land. Secondly, NPP, water yield, soil retention of covered and bare karst areas and food supply increased by 13.98%, 38.97%, 23.04%, 25% and 105.43%, respectively in MKGB, and there were certain spatial differences in the changes of various services in 2018. Thirdly, with the implementation of ecological governance measures, NPP and soil retention will show an increasing trend, but water yield will decrease continuously in 2030. The food supply will decrease in the strong ecological governance scenario, but increase in the other three scenarios. This result demonstrates that ecological governance measures can promote NPP and soil retention, but they will also limit the growth of water yield and food supply to some extent. Fourthly, NPP presents a trade-off relationship with water yield and food supply, and a synergic relationship with soil retention. Water yield shows a trade-off relationship with soil retention, and a synergic relationship with food supply. Soil retention and food supply are in a trade-off relationship. Finally, compared with the situation in 2018, the degree of trade-off in the moderate ecological governance scenario is acceptable, implying that it will be a reasonable ecological governance.
Therefore, we should pay close attention to the control of rocky desertification in the areas with the slope > 20° in the future. We believe the conclusions of this study can provide a clear direction for the control of rocky desertification. However, there still exist limitations. For example, the accuracy of basic data should be continuously improved, and more factors affecting the ecosystem services should also be taken into account in future studies.
-
Key words:
- rocky desertification /
- ecosystem /
- CLUE-S model /
- trade-off and synergy /
- karst graben basin
-
-
表 1 蒙自喀斯特断陷盆地未来土地利用情景设置规则
Table 1. Rules for setting future land use scenarios in MKGB
情景 描述 自然情景 按照2012-2018年土地演化趋势确定。 微度生态治理情景 坡度＞25°的耕地转化为林地；15°~25°坡度范围内轻度石漠化区的耕地转化为果园；
15°~25°坡度范围内中重度石漠化区的耕地转化为林地。适度生态治理情景 坡度＞20°的耕地转化为林地；15°~20°坡度范围内轻度石漠化区的耕地转化为果园；
15°~20°坡度范围内中重度石漠化区的耕地转化为林地。强力生态治理情景 坡度＞15°的耕地转化为林地。
下载: 导出CSV
表 2 2030年蒙自喀斯特断陷盆地耕地、果园和林地面积相较于2018年的变化状况(km2)
Table 2. Projected changes of cultivated land, orchard land and forest land in Mengzi karst graben basin in 2030 compared with the changes in 2018 (km2)
自然情景 微度生态治理情景 适度生态治理情景 强力生态治理情景 耕地减少面积 154.50 202.31 208.72 215.82 果园增加面积 32.53 34.24 34.26 28.52 林地增加面积 24.66 126.39 138.81 152.74
下载: 导出CSV
表 3 不同情景下生态系统服务权衡与协同关系
Table 3. Relationship between trade-off and synergy of ecosystem services in different scenarios
NPP—产水量 NPP—土壤保持 NPP—食物供给 产水量—土壤保持 产水量—食物供给 土壤保持-食物供给 自然情景 −0.473** 0.362** −0.377** −0.122** 0.307** −0.134** 微度生态治理情景 −0.524** 0.444** −0.414** −0.261** 0.403** −0.074** 适度生态治理情景 −0.508** 0.451** −0.412** −0.252** 0.358** −0.170** 强力生态治理情景 −0.515** 0.453** −0.417** −0.260** 0.360** −0.175** 注：**表示通过了显著性检验。
下载: 导出CSV
-
