1∶50 000 Mineral Geological Map Database of the Huangzhuguan Map-sheet in the Xicheng Pb-Zn Orefield, Gansu
-
摘要:
甘肃省黄渚关幅(I47E013015)1∶50 000 矿产地质图根据《矿产地质调查技术要求(1∶50 000)》(DD 2019—02)和行业的统一标准及要求，充分利用1∶50 000、1∶250 000等区域地质调查工作成果资料，采用数字填图系统进行野外地质专项填图，并应用室内与室外填编图相结合的方法编制完成。本图幅矿产地质图重点对泥盆系西汉水群的建造类型进行了重新划分，建立了泥盆纪成铅锌期3个建造单元，即含铅锌碳酸盐岩建造(D1a1a)、富铅锌碳酸盐岩建造(D1a1c)、贫铅锌千枚岩夹灰岩建造(D1a2)；建立了图幅内EW向褶皱–断裂构造系统；突出表达铅锌矿含矿建造及与铅锌矿成矿密切相关的特殊岩性层，辅以岩相古地理略图和构造纲要图，创新表达了喷流沉积阶段及热液改造阶段与铅锌矿成矿有关的地质要素。本数据库包含16个地层单位、5期侵入岩、3期构造相关数据、4个同位素年龄数据、12个岩石全分析数据、30个矿点数据，数据容量约为30.6 MB。这些数据充分反映了1∶50 000矿产地质调查示范性成果，可对其他类似区域提供借鉴作用。
Abstract:The 1∶50 000 mineral geological map of the Huangzhuguan Map-sheet, Gansu (I47E013015) is compiled in accordance with the Technical Requirements of Solid Mineral Geological Survey (DD 2019–02) and unified industrial standards and requirements. On the basis of existing 1∶50 000 and 1∶250 000 regional geological survey results, the work was performed through field geology-specific mapping both outdoors and indoors with the help of digital mapping systems. The Huangzhuguang mineral geological map redivides the formation types of the Devonian Xihanshui Group, and establishes three formation units of the Devonian lead and zinc-forming period, including lead-zinc-bearing carbonate rock formation (D1a1a), lead-zinc-rich carbonate rock formation (D1a1c), and lead-zinc-poor phyllite with limestone formation (D1a2). The map also establishes the EW fold–fault structure systems within the map-sheet area, highlights the lead-zinc ore-bearing formations and the special lithologic layers closely related to the metallogenesis of lead and zinc, and innovatively presents geological features related to the metallogenesis of lead and zinc in the exhalation sedimentation period and hydrothermal reformation period supplemented by a lithofacies paleogeographic sketch map and a tectonic outline map. The database contains 16 stratigraphic units, five stages of intrusive rocks, three stages of structures, four isotopic ages, 12 pieces of whole-rock analytical data, and 30 pieces of mineral deposit data, with a data volume of 30.6 MB. The database gives a full presentation of the demonstrative results of 1∶50 000 mineral geological survey and can provide reference for other similar areas.
-
Key words:
- Xicheng orefield /
- Changba /
- Huangzhuguan Map-sheet /
- 1∶50 000 /
- exhalative sedimentation /
- database /
- geological survey engineering /
-
-
表 1 数据库(集)元数据简表
条目 描述 数据集(库)名称 甘肃省黄渚关幅1∶50 000矿产地质图数据库 数据集(库)作者 沉积岩类：贾祥祥，甘肃省地质矿产勘查开发局第一地质矿产勘查院
岩浆岩类：王树明，甘肃省地质矿产勘查开发局第一地质矿产勘查院
变质岩类：贾祥祥，甘肃省地质矿产勘查开发局第一地质矿产勘查院
地质构造类：贾儒雅，中国地质调查局发展研究中心，自然资源部矿产勘查技术指导中心数据时间范围 2016—2018年 地理区域 东经105°30′00″～105°45′00″，北纬33°50′00″～34°00′00″ 数据格式 *.wl，*.wt，*.wp 数据量 30.6 MB 数据服务系统网址 http://dcc.cgs.gov.cn 基金项目 中国地质调查局地质调查项目“整装勘查区找矿预测与技术应用示范”(编号：121201004000172201) 语种 中文 数据集(库)组成 数据库包括：1∶50 000地质图库、角图和整饰。地质图库包括沉积岩、岩浆岩、变质岩、第四系、脉岩、构造、地质界线、产状、矿床(点)、蚀变、岩性花纹、各类代号等。角图包括沉积岩建造、侵入岩建造、脉岩、构造，典型矿床(区)平面图、重要勘探线剖面图、地质剖面图及构造纲要图、岩相古地理图等，以及矿产图例、矿产地名录、矿化蚀变图例、成矿区(带)位置图；整饰部分包括接图表、中国地质调查局局徽、图名、比例尺、坐标参数、责任表等
下载: 导出CSV
表 2 甘肃西成铅锌矿田黄渚关幅矿产地信息简表
序号 矿产地名称 规模 成因类型 主要含矿
建造构造估算资源量 1 甘肃省成县爷殿山铁矿 矿化点 热液型 砂岩建造 2 甘肃省成县庙沟铅锌矿 矿化点 喷流沉积型 大理岩建造 3 甘肃省西和县漩潭沟铅锌矿 矿点 喷流沉积型 千枚岩建造 4 甘肃省成县厂坝北铅锌（铜）矿 矿化点 热液型 大理岩建造 Cu 244 kg 5 甘肃省成县清水沟外围铅锌矿 矿点 喷流沉积型 片岩建造 Pb+Zn 165 913 t 6 甘肃省成县挖泉山大理岩矿 大型 区域变质 大理岩建造 7 甘肃省成县厂坝铅锌矿 特大型 喷流沉积型 硅钙面 Pb 586 910 t;
Zn 2 807 870 t8 甘肃省成县厂坝白云岩矿 大型 区域变质 白云岩建造 9 甘肃省成县清水沟钨矿 矿化点 热液型 砂岩建造 10 甘肃省成县二郎对长沟金矿 矿点 蚀变岩型 砂岩建造 11 甘肃省成县二郎对长沟铅锌矿 矿点 喷流沉积型 碳酸盐岩建造 12 甘肃省成县李家沟铅锌矿 特大型 喷流沉积型 片岩建造 13 甘肃省成县向阳山西铅锌矿 中型 喷流沉积型 片岩建造 Pb+Zn 2 414.9 t 14 甘肃省成县徐明山铅锌矿 矿化点 喷流沉积型 大理岩建造 Pb 4 789 t; Zn 42 852 t 15 甘肃省成县二郎对长沟铁矿 矿化点 热液型 硅钙面 16 甘肃省成县老硐上铅锌矿 矿点 喷流沉积型 白云岩建造 Pb+Zn 105 304.9 t 17 甘肃省成县向阳山铅锌矿 中型 喷流沉积型 硅钙面 Pb+Zn 208 809 t 18 甘肃省成县大沙湾铜矿 矿化点 热液型 片岩建造 19 甘肃省成县官子沟铅锌矿 矿点 喷流沉积型 大理岩建造 Pb 106.7 t; Zn 719.2 t 20 甘肃省成县小沟里金矿 中型 热液型 千枚岩建造 Au 7 696.72 kg 21 甘肃省成县空子沟铅锌矿 矿化点 喷流沉积型 千枚岩建造 Pb+Zn 2 778.34 t 22 甘肃省成县冉家河铅锌矿 矿化点 喷流沉积型 千枚岩建造 23 甘肃省成县甘沟铅锌多金属矿 中型 喷流沉积型 碳酸盐岩建造 Pb 6 518.6 t;
Zn 54 958.4 t24 甘肃省成县小沟里铅锌矿 矿化点 喷流沉积型 千枚岩建造 25 甘肃省成县马门下大理岩矿 大型 区域变质 大理岩建造 26 甘肃省成县熊家河铅锌矿 矿点 喷流沉积型 碳酸盐岩建造 Pb 1 763 t; Zn 8 818 t 27 甘肃省成县毕家山铅锌（铜）矿 大型 喷流沉积型 硅钙面 Pb 9 322.89 t;
Zn 39 748.87 t28 甘肃省成县甘蔗沟铅锌多金属矿 矿点 喷流沉积型 碳酸盐岩建造 Pb+Zn 25 160.06 t; Ag 7 085.73 t 29 甘肃省成县三架山铅锌矿 矿点 喷流沉积型 碳酸盐岩建造 30 甘肃省成县陈家庄铅锌矿 矿点 喷流沉积型 碳酸盐岩建造
下载: 导出CSV
表 3 沉积岩建造一览表
岩石地层单位 建造单元特征 系 统 群 组 段 代号 建造类型 厚度/m 岩石组合 新近系 甘肃群 N1G 砾岩建造 695 红色块状砾岩、砂砾岩、黏土质粉砂岩、黏土岩 白垩系 鸡山组 K1js 陆相碎屑岩建造 1202 杂色泥岩、粉砂岩夹紫红色砂岩、砾岩，炭质泥岩夹劣质煤层 三叠系 光盖山组 上段 T1gg2 碳酸盐岩夹砂岩建造 789 灰–深灰色薄层状灰岩夹薄层状钙质细砂岩、钙质粉砂岩、钙质板岩，偶见砾屑灰岩夹层 下段 T1gg1 碎屑岩夹碳酸盐岩建造 124 岩屑(石英)砂岩、钙质砂岩、钙质粉砂岩、钙质板岩夹薄层灰岩、角砾状灰岩、灰质砾岩透镜体 泥盆系 上统 西汉水群 双狼沟组 上段 D3sl2 粉砂岩与砂岩互层夹灰岩建造 223. 长石石英细砂岩、粉砂岩、钙质砂岩夹薄层结晶、灰岩、泥灰岩 下段 D3sl1 千枚岩与板岩互层夹灰岩建造 267.9 绢云千枚岩、千枚岩、绢云板岩、板岩、钙质粉砂质板岩 中统 红岭山组 D2–3hl 生物泥晶灰岩夹礁灰岩 476 生屑灰岩、条带状泥晶灰岩、泥质条带灰岩、生屑泥晶灰岩，局部夹礁灰岩碎块、礁灰岩条带 黄家沟组 上段 D2h2 板岩夹千枚岩建造 454.4 下部为绿泥石千枚岩夹薄层微晶灰岩生物灰岩透镜体，上部为千枚状板岩夹千枚岩 下段 D2h1 砂岩建造 350.7 薄层状长石石英砂岩、变长石砂岩 下统 安家岔组 上段 焦沟层 D1a2 贫铅锌千枚岩夹灰岩
建造434.2 下部为中层状细晶灰岩与绢云千枚岩互层，中部为中层状结晶灰岩、条带状细晶灰岩，上部为绢云绿泥千枚岩夹结晶灰岩、薄层状泥晶灰岩、中层条带状结晶灰岩 在厂坝一带受热变质作用相变为石英片岩夹大理岩化灰岩、大理岩透镜体 下段 厂坝层 D1a1c 富铅锌碳酸盐岩建造 908.2 薄层状条带状细晶灰岩、薄层条带状灰岩、大理岩化灰岩、中厚层状含炭质灰岩 在厂坝一带受热变质作用相变为，下部二云石英片岩、二云片岩、方解石石英片岩等；上部为石英岩夹大理岩 D1a1b 砂岩建造 191.2 中厚层状–块状长石石英砂岩、石英千
枚岩在厂坝一带受热变质作用相变为石英片岩、黑云母石英片岩 D1a1a 含铅锌碳酸盐岩建造 360 绢云千枚岩夹礁灰岩、礁灰岩碎块、骨架灰岩
下载: 导出CSV
表 4 侵入岩建造一览表
时代 建造单元特征 代 纪 世 岩体名称 代号 建造类型 岩性特征 年龄/Ma 中生代 三叠纪 晚三叠世 厂坝岩体 ηγT 黑云母二长花岗岩建造 灰白色中–粗粒黑云母二长花岗岩 184~196(K–Ar) 榆树坝岩体 ηοT 闪长岩建造 细粒石英二长岩、中细粒石英二长闪长岩 217±4(锆石U–Pb) 黄渚关—沿川子岩体 ηδοT 辉长岩建造 紫苏辉长岩 184~222(K–Ar) 严家河岩体 γδμT 花岗闪长玢岩建造 灰白色花岗闪长玢岩 挖泉山岩体 ψδT 辉石闪长岩
建造深绿色辉石闪长岩 195.5(K–Ar) 晚古生代 泥盆纪 双碌碡岩体 ΣPz1 超基性岩建造 暗绿色超基性岩
下载: 导出CSV
Table 1. Metadata Table of Database (Dataset)
Items Description Database (Dataset) name 1∶50 000 Mineral Geological Map Database of the Huangzhuguan Map-sheet, Gansu Database (Dataset) authors Sedimentary rocks: Jia Xiangxiang, The First Geological Mineral Exploration Institute of Gansu Provincial Geology and Mineral Bureau
Magmatic rocks: Wang Shuming, The First Geological Mineral Exploration Institute of Gansu Provincial Geology and Mineral Bureau
Metamorphic rocks: Jia Xiangxiang, The First Geological Mineral Exploration Institute of Gansu Provincial Geology and Mineral Bureau
Geological structures: Jia Ruya, Development and Research of China Geological Survey; Mineral Exploration Technical Guidance Center, Ministry of Natural ResourcesData acquisition time 2016–2018 Geographic area 105°30′00″–105°45′00″E, 33°50′00″–34°00′00″N Data format *.wl, *.wt, *.wp Data size 30.6 MB Data service system URL http://dcc.cgs.gov.cn Fund project China Geological Survey Project “Prospecting Prediction and Technical Application Demonstration in Integrated Exploration Area” (No.: 121201004000172201) Language Chinese Database (Dataset) composition The database includes a 1∶50 000 geological map library, corner maps and finishing. The geological map library includes sedimentary rocks, magmatic rocks, metamorphic rocks, Quaternary, dykes, structures, geological boundaries, attitudes, ore deposits (spots), alterations, lithologic patterns, and various codes. The corner map includes sedimentary rock formations, intrusive rock formations, dykes, structures, typical ore deposit plane map, profile map of important exploration lines, geological profile map, and tectonic outline map, lithofacies paleogeographic sketch map, as well as mineral legend, mineral deposit directory, mineralization alteration legend, and metallogenic zone location map. The finishing part includes the index map, China Geological Survey emblem, map name, scale, coordinate parameters, and duty table
下载: 导出CSV
Table 2. List of the mineral deposits occurred in the Huangzhuguang Map-sheet area, Xicheng lead-zinc orefield, Gansu
No. Mineral deposit name Size Origin type Main ore-forming formation-structure Estimated resources 1 Yedianshan iron deposit, Chengxian County, Gansu Mineralized spot Hydrothermal type Sandstone formation 2 Miaogou lead-zinc deposit, Chengxian County, Gansu Mineralized spot Exhalative sedimentary type Marble formation 3 Xuantangou lead-zincdeposit, Xihe County, Gansu Ore occurrence Exhalative sedimentary type Phyllite formation 4 North Changba lead-zinc (copper) deposit, Chengxian County, Gansu Mineralized spot Hydrothermal type Marble formation Cu 244 kg 5 Qingshuigou lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Schist formation Pb+Zn 165 913 t 6 Waquanshan marble deposit, Chengxian County, Gansu Large Regional metamorphic type Marble formation 7 Changba lead-zinc deposit, Chengxian County, Gansu Super-large Exhalative sedimentary type Si-Ca interface (interface between the pluton and carbonate rock) Pb 586 910 t;
Zn 2 807 870 t8 Changba dolomite deposit, Chengxian County, Gansu Large Regional metamorphic type Dolomite formation 9 Qingshuigou tungsten deposit, Chengxian County, Gansu Mineralized spot Hydrothermal type Sandstone formation 10 Erlangduichanggou gold deposit, Chengxian County, Gansu Ore occurrence Altered rock type Sandstone formation 11 Erlangduichanggou lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Carbonate rock formation 12 Lijiagou lead-zinc deposit, Chengxian County, Gansu Super-large Exhalative sedimentary type Schist formation 13 West Xiangyangshan lead-zinc deposit, Chengxian County, Gansu Medium Exhalative sedimentary type Schist formation Pb+Zn 2 414.9 t 14 Xumingshan lead-zinc deposit, Chengxian County, Gansu Mineralized spot Exhalative sedimentary type Marble formation Pb 4 789 t; Zn 42 852 t 15 Erlangduichanggou iron deposit, Chengxian County, Gansu Mineralized spot Hydrothermal type Si-Ca interface (interface between the pluton and carbonate rock) 16 Laodongshang lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Dolomite formation Pb+Zn 105 304.9 t 17 Xiangyangshan lead-zinc deposit, Chengxian County, Gansu Medium Exhalative sedimentary type Si-Ca interface (interface between the pluton and carbonate rock) Pb+Zn 208 809 t 18 Dashawan copper deposit, Chengxian County, Gansu Mineralized spot Hydrothermal type Schist formation 19 Guanzigou lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Marble formation Pb 106.7 t; Zn 719.2 t 20 Xiaogouli gold deposit, Chengxian County, Gansu Medium Hydrothermal type Phyllite formation Au 7 696.72 kg 21 Kongzigou lead-zinc deposit, Chengxian County, Gansu Mineralized spot Exhalative sedimentary type Phyllite formation Pb+Zn 2 778.34 t 22 Ranjiahe lead-zinc deposit, Chengxian County, Gansu Mineralized spot Exhalative sedimentary type Phyllite formation 23 Gangou lead-zinc plymetallic deposit, Chengxian County, Gansu Medium Exhalative sedimentary type Carbonate rock formation Pb 6 518.6 t; Zn 54 958.4 t 24 Xiaogouli lead-zinc deposit, Chengxian County, Gansu Mineralized spot Exhalative sedimentary type Phyllite formation 25 Mamenxia marble deposit, Chengxian County, Gansu Large Regional metamorphic type Marble formation 26 Xiongjiahe lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Carbonate rock formation Pb 1 763 t; Zn 8 818 t 27 Bijiashan lead-zinc (copper) deposit, Chengxian County, Gansu Large Exhalative sedimentary type Si-Ca interface (interface between the pluton and carbonate rock) Pb 9 322.89 t; Zn 39 748.87 t 28 Ganzhegou lead-zinc polymetallic deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Carbonate rock Pb+Zn 25 160.06 t;
Ag 7 085.73 t29 Sanjiashan lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Carbonate rock formation 30 Chenjiazhuang lead-zinc deposit, Chengxian County, Gansu Ore occurrence Exhalative sedimentary type Carbonate rock formation
下载: 导出CSV
Table 3. List of sedimentary rock formations
Lithostratigraphic Unit Characteristics of Formation Unit System Series Group Formation Member Code Formation Type Thickness/m Rock Combination Neogene Gansu Group N1G Conglomerate formation 695 Red massive conglomerate, gritstone, clayey siltstone, claystone Cretaceous Jishan Formation K1js Continental clastic rock formation 1202 Particolored mudstone, siltstone with purplish red sandstone, conglomerate, carbonaceous mudstone with dirt coal seam Triassic Guanggaishan Formation Upper T1gg2 Carbonate rock with sandstone formation 789 Gray to dark gray thin stratiform limestone with thin stratiform calcareous fine sandstone, carbonaceous siltstone, calcareous slate, occasionally with calcirudyte interbeds Lower T1gg1 Clastic rock with carbonate rock formation 124 Lithic (quartz) sandstone, calcareous sandstone, carbonaceous siltstone, calcareous slate with thin limestone, brecciated limestone, calcareous conglomerate lenses Devonian Upper Xihanshui Group Shuanglanggou Formation Upper D3sl2 Siltstone-sandstone interlayer with limestone formation 223. Feldspar quartz fine sandstone, siltstone, calcareous sandstone with thin crystals, limestone, marlite Lower D3sl1 Phyllite-slate interlayer with limestone formation 267.9 Sericite phyllite, phyllite, sericite slate, slate, calcareous silty slate Middle Honglingshan Formation D2–3hl Biomicrite with reef limestone formation 476 Bioclastic limestone, banded micrite, argillaceous banded limestone, bioclastic micrite, with local reef fragment limestone, reef limestone bands Huangjiagou Formation Upper D2h2 Slate with phyllite formation 454.4 The lower part consists of chlorite phyllite with thin micrite biolithite lenses; the upper part consists of phyllitic slate with phyllite Lower D2h1 Sandstone formation 350.7 Thin stratiform feldspar quartz sandstone, meta-feldspar sandstone Lower Anjiacha Formation Upper Jiaogou layer D1a2 Pb-Zn-poor phyllite with limestone formation 434.2 The lower part consists of medium-thick stratiform micrite-sericite phyllite interlayer; the middle part consists of medium-thick stratiform crystalline limestone, banded micrite; the upper part consists of sericite chlorite with crystalline limestone, thin stratiform micrite, medium-thick stratiform banded crystalline limestone In and around Changba, the lithology changes to quartz schist with marblized limestone, marble lenses as a result of thermal metamorphosis. Lower Changba layer D1a1c Pb-Zn-rich carbonate rock formation 908.2 Thin stratiform banded fine-grained limestone, thin banded limestone, marblized limestone, medium-thick stratiform carbonaceous limestone In and around Changba, the lithology changes to two-mica quartz schist, two-mica schist, calcite quartz schist in the lower part, and quartzite with marble in the upper part, as a result of thermal metamorphosis. D1a1b Sandstone formation 191.2 Medium-thick stratiform to massive feldspar quartz sandstone, quartz phyllite In and around Changba, the lithology changes to quartz schist, biotite quartz schist as a result of thermal metamorphosis D1a1a Pb-Zn-bearing carbonate rock formation 360 Sericite phyllite with reef limestone, reef fragment limestone, skeleton limestone
下载: 导出CSV
Table 4. List of intrusive rock formations
Time Characteristics of Formation Unit Era Period Epoch Rock Body Name Code Formation Type Lithology Age/Ma Mesozoic Triassic Late Triassic Changba rock body ηγT Biotite monzonitic granite formation Grayish white medium to coarse-grained biotite monzonitic granite 184–196 (K–Ar) Yushuba rock body ηοT Diorite formation Fine-grained quartz monzonite, medium-fine-grained quartz monzonite diorite 217±4 (Zircon U–Pb) Huangzhuguan–Yangchuanzi rock body ηδοT Gabbro formation Hypersthene gabbro 184–222 (K–Ar) Yanjiahe rock body γδμT Granite diorite porphyrite formation Grayish white granite diorite porphyrite Waquanshan rock body ψδT Pyroxene diorite formation Dark green pyroxene diorite 195.5 (K–Ar) Late Paleozoic Devonian Shuangliuzhou rock body ΣPz1 Ultramafic rock formation Dark green ultramafic rock
下载: 导出CSV
-
[1] 程小久, 翟裕生. 1995. 沉积盆地中同生断层及对层控(Pb–Zn–Ba–Cu–Ag)矿床的控制[J]. 现代地质, 9(3): 343−348. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ503.009.htm
[2] 方维萱, 胡瑞忠, 张国伟, 芦纪英. 2001. 秦岭造山带泥盆系热水沉积岩相的亚相和微相划分划分及特征[J]. 地质与勘探, 37(2): 50−54. doi: 10.3969/j.issn.0495-5331.2001.02.013
[3] 国阿千, 丁振举, 文成雄. 2011. 甘肃西成矿田花岗岩锆石U–Pb定年及地质意义[J]. 矿物学报, (A1): 581−582. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB2011S1298.htm
[4] 霍福臣, 李永军. 1995. 西秦岭造山带的建造与地质演化[M]. 西安: 西北大学出版社.
[5] 贾祥祥, 王树明, 贾儒雅. 2020. 甘肃省黄渚关幅 1∶50 000 矿产地质图数据库 [DB/OL]. 地质科学数据出版系统. (2020-12-30). DOI: 10.35080/data.C.2020.P31.
[6] 李益桂, 杨钟堂, 赵德智. 1988. 厂坝铅锌矿床的基本地质构造特征及构造控制作用[C].中国地质科学院陕西地质矿产研究所所刊, 第21号: 1–16.
[7] 李建中, 高兆奎. 1993. 西秦岭下泥盆世沉积环境及其与铅锌矿的关系[J]. 地质论评, 39(2): 156−162. doi: 10.3321/j.issn:0371-5736.1993.02.009
[8] 马国良, 祁思敬, 李英, 薛春纪. 1996. 甘肃厂坝铅锌矿床喷气沉积成因研究[J]. 地质找矿论丛, (3): 36−44. https://www.cnki.com.cn/Article/CJFDTOTAL-DZZK603.004.htm
[9] 潘桂棠, 肖庆辉, 陆松年, 邓晋福, 冯益民, 张克信, 张智勇, 王方国, 邢光福, 郝国杰, 冯艳芳. 2009. 中国大地构造单元划分[J]. 中国地质, 36(1): 1−28. doi: 10.3969/j.issn.1000-3657.2009.01.001
[10] 宋春晖, 武安斌. 1992. 西成矿田海底热水喷溢沉积成因硅质岩及其与矿化关系[J]. 沉积学报, 10(4): 60−67. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB199204006.htm
[11] 孙矿生, 彭德启. 2004. 甘肃省铅锌矿成矿系列及控矿因素[J]. 甘肃地质学报, 13(1): 1−9. https://www.cnki.com.cn/Article/CJFDTOTAL-GSDZ200401001.htm
[12] 武安斌, 宋春晖, 孙省利. 1992. 甘肃省西成矿田中泥盆统沉积相古地理与控矿作用. 兰州: 兰州大学出版社.
[13] 王集磊, 何伯墀. 1996. 中国秦岭型铅锌矿床[M]. 北京: 地质出版社.
[14] 王春女, 杜泽忠, 于晓飞, 李永胜, 吕鑫, 孙海瑞, 杜轶伦. 2019. 甘肃省花牛山幅1∶50 000矿产地质图数据库[J]. 中国地质, 46(S1): 55−65. doi: 10.12029/gc2019Z107
[15] 叶天竺, 吕志成, 庞振山, 张德会, 刘士毅, 王全明, 刘家军, 程志中, 李超岭, 肖克炎, 甄世民, 杜泽忠, 陈正乐. 2014. 勘查区找矿预测理论与方法(总论)[M]. 北京: 地质出版社.
[16] 叶天竺, 韦昌山, 王玉往, 祝新友, 庞振山, 姚书振, 秦克章, 韩润生, 叶会寿, 孙景贵, 蔡煜琦, 甄世民, 薛建玲, 范宏瑞, 倪培, 曾庆栋, 蒋少涌, 杜杨松, 李胜荣, 郝立波, 张均, 陈正乐, 耿林, 潘家永, 蔡锦辉, 黄智龙, 李厚民, 孙丰月, 陈衍景, 陈郑辉, 杜泽忠, 陶文, 肖昌浩, 张志辉, 贾儒雅, 陈辉, 姚磊. 2017. 勘查区找矿预测理论与方法(各论)[M]. 北京: 地质出版社.
[17] 俞中辉, 祝新友, 童随友, 宋建冶, 汪东波, 卫治国. 2008. 西成地区铅–锌矿、金矿硫铅同位素特征及成矿关系的研究[J]. 矿产与地质, 127(3): 196−203. doi: 10.3969/j.issn.1001-5663.2008.03.002
[18] 叶会寿, 王义天, 王瑞廷等. 2016. 秦岭Au–Pb–Zn成矿带成矿地质特征及潜力分析[J]. 地质学报, 90(7): 1423−1446. doi: 10.3969/j.issn.0001-5717.2016.07.027
[19] 张新虎, 田黎萍, 刘建宏, 李海林, 牛洪斌, 徐家乐, 张翔, 任丰寿. 2013. 甘肃省区域成矿及找矿[M]. 北京: 地质出版社.
[20] 张长青, 芮宗瑶, 陈毓川, 王登红, 陈郑辉, 娄德波. 2013. 中国铅锌矿资源潜力和主要战略接续区[J]. 中国地质, 40(1): 248−272. doi: 10.3969/j.issn.1000-3657.2013.01.017
[21] 祝新友, 汪东波, 王瑞廷,卫治国,邱小平. 2005. 西成地区碳酸盐岩REE特征及厂坝矿床白云岩成因[J]. 矿床地质, 24(6): 613−620. doi: 10.3969/j.issn.0258-7106.2005.06.005
[22] 张复新, 王俊发. 1991. 陕西秦岭地区泥盆系同生断裂、岩相与海底喷流沉积铅锌矿床[J]. 矿床地质, 10(3): 217−231. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ199103003.htm
[23] 祝新友, 汪东波, 卫治国, 王瑞廷, 邱小平. 2006. 甘肃西成地区南北铅锌矿带矿床成矿特征及相互关系[J]. 中国地质, 33(6): 1361−1377. doi: 10.3969/j.issn.1000-3657.2006.06.020
[1] Cheng Xiaojiu, Zhai Yusheng. 1995. Synsedimentary fault and its control of stratabound (Pb–Zn–Ba–Cu–Ag) deposits in sedimentary basin[J]. Geoscience, 9(3): 343−348 (in Chinese with English abstract).
[2] Fang Weixuan, Hu Ruizhong, Zhang Guowei, Lu Jiying. 2001. On classifications and characteristics of the Devonian hydrothermal sedimentary facies in the Qinlling orogen[J]. Geology and Prospecting, 37(2): 50−54 (in Chinese with English abstract).
[3] Guo Aqian, Ding Zhenju, Wen Chenxiong. 2011. Zircon U-Pb dating of the granite in Xicheng orefield, Gansu Province and its geological significance[J]. Acta Mineralogica Sinica, (A1): 581−582 (in Chinese).
[4] Huo Fuchen, Li Yongjun. 1995. The formation and geological evolution of the West Qinling orogenic belt[M]. Xi’an: Northwest University Press (in Chinese).
[5] Jia Xiangxiang, Wang Shuming, Jia Ruya. 2020. 1∶50 000 Mineral Geological Map Database of the Huangzhuguan Map-sheet, Gansu[DB/OL]. Geoscientific Data & Discovery Publishing System. (2020-12-30). DOI: 10.35080/data.C.2020.P31.
[6] Li Jianzhong, Gao Zhaokui. 1993. The middle Devonian sedimentary environment of the West Qinling mountains and its relationship with lead and zinc deposits[J]. Geological Review, 39(2): 156−162 (in Chinese with English abstract).
[7] Li Yigui, Yang Zhongtang, Zhao Dezhi. 1988. Basic geological structural characteristics and structural control of Changba Pb-Zn deposit[C]. Journal of Shaanxi Institute of Geology and mineral resources, Chinese Academy of Geological Sciences, No. 21: 1–16(in Chinese).
[8] Ma Guoliang, Qi Sijing, Li Ying, Xue Chunji. 1996. A study of the exhalative origin of the Changba lead-zinc deposit, Gansu Province[J]. Contributions to Geology and Mineral Resources Research, (3): 36−44 (in Chinese with English abstract).
[9] Pan Guitang, Xiao Qinghui, Lu Songnian, Deng Jinfu, Feng Yimin, Zhang Kexin, Zhang Zhiyong, Wang Fangguo, Xing Guangfu, Hao Guojie, Feng Yanfang. 2009. Subdivision of tectonic units in China[J]. Geology in China, 36(1): 1−28 (in Chinese with English abstract).
[10] Song Chunhui, Wu Anbin. 1992. Hydrothermal exhalative sedimentary siliceous rocks and their relationship with Pb–Zn mineralization in Xicheng orefield, Gansu, China[J]. Acta Sedimentologica Sinica, 10(4): 60−67 (in Chinese with English abstract).
[11] Sun Kuangsheng, Peng Deqi. 2004. Lead-zinc metallogenic types and ore-control factor in Gansu Province[J]. Acta Geologica Gansu, 13(1): 1−9 (in Chinese with English abstract).
[12] Wang Chunnyu, Du Zezhong, Yu Xiaofei, Li Yongsheng, Lyu Xin, Sun Hairui, Du Yilun. 2019. 1∶50 000 Mineral Geological Map Database of the Huaniushan Map-sheet, Gansu[J]. Geology in China, 46(S1): 72−86.
[13] Wang Jilei, He Bochi. 1996. Qinling type lead-zinc deposits in China[M]. Beijing: Geological Publishing House (in Chinese).
[14] Wu Anbin, Song Chunhui, Sun Shengli. 1992. Middle Devonian sedimentary facies paleogeography and ore control in Xicheng orefield, Gansu Province[M]. Lanzhou: Lanzhou University Press (in Chinese).
[15] Ye Tianzhu, Lyu Zhicheng, Pang Zhenshan, Zhang Dehui, Liu Shiyi, Wang Quanming, Liu Jiajun, Cheng Zhizhong, Li Chaoling, Xiao Keyan, Zhen Shimin, Du Zezhong, Chen Zhengle. 2014. Theories and methods of prospecting prediction in prospecting areas (general)[M]. Beijing: Geological Publishing House (in Chinese).
[16] Ye Tianzhu, Wei Changshan, Wang Yuwang, Zhu Xinyou, Pang Zhenshan, Yao Shuzhen, Qin Kezhang, Han Runsheng, Ye Huishou, Sun Jinggui, Cai Yuqi, Zhen Shimin, Xue Jianling, Fan Hongrui, Ni Pei, Zeng Qingdong, Jiang Shaoyong, Du Yangsong, Li Shengrong, Hao Libo, Zhang Jun, Chen Zhengle, Geng Lin, Pan Jiayong, Cai Jinhui, Huang Zhilong, Li Houmin, Sun Fengyue, Chen Yanjing, Chen Zhenghui, Du Zezhong, Tao Wen, Xiao Changhao, Zhang Zhihui, Jia Ruya, Chen Hui, Yao Lei. 2017. Theories and methods of prospecting prediction in prospecting areas (monographs)[M]. Beijing: Geological Publishing House (in Chinese).
[17] Ye Huishou, Wang Yitian, Wang Ruiting, Ding Jianhua, Hu Qiaoqing, Lu Dongyu, He Chunfen, Sun Jia. 2016. Geological characteristics of minerogenesis and prospecting of Qinling Au–Pb–Zn metallogenic belt[J]. Acta Geologica Sinica, 90(7): 1423−1446 (in Chinese with English abstract).
[18] Yu Zhonghui, Zhu Xinyou, Tong Suiyou, Song Jianye, Wang Dongbo, Wei Zhiguo. 2008. Study on characteristics of S, Pb isotopes of the Pb-Zn deposits, Au deposits in Xicheng area and their metallogenic relationship[J]. Mineral Resources and Geology, 127(3): 196−203 (in Chinese with English abstract).
[19] Zhang Changqing, Rui Zongyao, Chen Yuchuan, Wang Denghong, Chen Zhenghui, Lou Debo. 2013. The main successive strategic bases of resources for Pb-Zn deposits in China[J]. Geology in China, 40(1): 248−272 (in Chinese with English abstract).
[20] Zhang Fuxin, Wang Junfa. 1991. Devonian syngenetic faults and lithofacies in relation to submarine exhalative sedimentary lead-zinc deposits in Qinling area, Shaanxi Province[J]. Mineral Deposits, 10(3): 217−231 (in Chinese with English abstract).
[21] Zhang Xinhu, Tian Liping, Liu Jianhong, Li Hailin, Niu Hongbin, Xu Jiale, Zhang Xiang, Ren Fengshou. 2013. Regional mineralization and prospecting in Gansu Province[M]. Beijing: Geological Publishing House (in Chinese).
[22] Zhu Xinyou, Wang Dongbo, Wang Ruiting, Wei Zhiguo, Qiu Xiaoping. 2005. REE characteristics of carbonate rocks in Xicheng Devonian basin and orgin of dolomite in Changba giant lead-zinc deposit[J]. Mineral Deposits, 24(6): 613−620 (in Chinese with English abstract).
[23] Zhu Xinyou, Wang Dongbo, Wei Zhiguo, Wang Ruiting, Qiu Xiaoping. 2006. Metallogenic characteristics and relationship of ore deposits in the north and south lead–zinc zones in the Xicheng area, Gansu[J]. Geology in China, 33(6): 1361−1377 (in Chinese with English abstract).
-
