Geological characteristics of the deposits, protolith restoration and paleoenvironment of the Aobaoshan crystalline graphite deposit concentrated area in Dunhuang block
-
摘要:
研究目的 为解决敦煌地块敖包山晶质石墨矿集区晶质石墨矿床研究程度较低的问题，通过对该区变质岩原岩特征及古构造环境进行深入研究，以期为该区的成矿规律研究提供地质依据。
研究方法 本文运用岩石地球化学方法对该区变质岩进行原岩恢复，探讨其形成时的古构造环境。
研究结果 二云石英片岩、黑云斜长片麻岩和斜长角闪岩均具有轻稀土富集的特征。斜长角闪岩K2O＜Na2O，具有弱的Nb、Ta亏损和强烈的Zr、Hf亏损，LREE/HREE=2.21~6.97，轻重稀土元素分馏程度较弱；黑云斜长片麻岩和二云石英片岩K2O>Na2O，富集大离子亲石元素Rb、K等，亏损Ba、Nb、Ta、Zr、Hf、Ti、Sr等元素，具有明显的Eu负异常，LREE/HREE平均值分别为12.44和8.89，轻重稀土元素分异较强烈。
结论 敖包山晶质石墨矿集区变质岩原岩形成于浅水区，水动力环境较弱。斜长角闪岩的原岩为亚碱性基性火山岩，形成于岛弧环境；二云石英片岩和黑云斜长片麻岩的原岩为页岩、黏土岩，构造环境为活动大陆边缘，古沉积环境为干燥气候带条件下富氧的海陆交互相，古水体介质为半咸水。
Abstract:This paper is the result of mineral exploration engineering.
Objective Due to the relatively low research level of crystalline graphite deposits in the Aobaoshan crystalline graphite deposit-concentrated area in Dunhuang block, the protolith restoration and paleoenvironment of this area are studied profoundly, which will provide a geological foundation for metallogenic regularity.
Methods The protolith of the metamorphic rocks in the Aobaoshan crystalline graphite deposit-concentrated area is restored using the method of petrochemistry, and the paleotectonic environment of its formation is discussed.
Results Two-mica quartz schist, biotite plagioclase gneiss and plagioclase amphibolite are enriched in the light rare earth elements. The plagioclase amphibolites have less K2O contents than Na2O. They are weakly depleted in Nb and Ta, and strong depleted in Zr and Hf, and have the ratios of LREE/HREE ranging from 2.21 to 6.97, indicating the weak fractionation degree of light and heavy rare earth elements. The biotite plagioclase gneisses and two-mica quartz schists have higher K2O contents than Na2O. They show the enrichment in large ion lithophile elements, such as Rb and K, and the depeletion in Ba, Nb, Ta, Zr, Hf, Ti and Sr, and obvious Eu negative anomalies. The average ratios of LREE/HREE of the biotite plagioclase gneiss and two-mica quartz schist are 12.44 and 8.89, respectively, indicating strong differentiation of light and heavy rare earth elements.
Conclusions It is inferred that the protoliths of the metamorphic rocks from the Aobaoshan crystalline graphite deposit-concentrated area were formed in shallow water area with weak hydrodynamic environment. The protoliths of the plagioclase amphibolites in the Aobaoshan crystalline graphite deposit-concentrated area are subalkaline basic volcanic rock, and they were formed in an island arc. The protoliths of biotite plagioclase gneisses and two-mica quartz schists are shale and clayrock, and they were formed at active continental margins. The paleosedimentary environment was oxygen-rich interactive marine and terrestrial deposition in dry climate zone, and the paleowater medium was brackish water.
-
-
图 6 敖包山晶质石墨矿集区样品的原始地幔标准化图解（a）和球粒陨石标准化图解（b）（原始地幔和球粒陨石标准化值来自Palme and O'Neill，2014）
Figure 6.
图 7 Zr/TiO2-Ni图解（a, 底图据Winchester et al., 1980）；Ga/Sc-Nb/Y图解（b, 底图据Winchester and Floyd, 1977）；(al+fm)-(c+alk)-Si图解（c, 底图据Simonen, 1953）；La/Yb-∑REE图解（d, 底图据王仁民等, 1987）
Figure 7.
图 10 SiO2-K2O/Na2O（a）和SiO2/Al2O3-K2O/Na2O（b）图解（底图据Roser and Korsch, 1986）
Figure 10.
表 1 敖包山晶质石墨矿集区岩石化学分析结果
Table 1. Petrochemical analyses of Aobaoshan crystalline graphite deposit-concentrated area
下载: 导出CSV
-
Ai J, Lü X B, Li Z W, Wu Y L. 2018. A super-large graphite deposit discovered in granite rocks at Huangyangshan, Xinjiang, China[J]. China Geology, 1: 164-166. doi: 10.31035/cg2018016
Bhatia M R, Crook K A W. 1986. Trace element characteristics of greywackes and tectonic setting discrimination of sedimentary basin[J]. Contribution to Mineralogy and Petrology, 92(2): 181-193. doi: 10.1007/BF00375292
Chen Shiqiang, Li Shengye, Jia Xin, Fan Xinxiang, Wang Xiaoqiang. 2021. Geochemical Characteristics and Genesis of the Aobaogou Crystalline Graphite Deposit in Subei County, Gansu Province[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 40 (6): 1-10(in Chinese with English abstract).
Deng Hongwen, Qian Kai. 1993. Sedimentary Geochemistry and Environment Analysis[M]. Lanzhou: Gansu Science and Technology Press(in Chinese with English abstract).
Deng Shaojun, Zhu Yuyin, Li Hujie. 2020. Protolith recovery and discussion on paleosedimentary environment of Pinghe graphite metamorphic rocks in Nanjiang[J]. Journal of Southwest University of Science and Technology, 35 (1): 22-30(in Chinese with English abstract).
Duan L A, Wei Y F, Liu Q Y, Yang X Y. 2020. Discovery of the Dahongshan ultra-large crystalline graphite deposit, Urad Zhongqi of Inner Mongolia, China[J]. China Geology, 3(1): 182-183. doi: 10.31035/cg2020019
Fu Quan, Zhang Yinding, Xue Tao. 2020. Geological characteristics and genesis of crystal graphite deposit in Baitaigou East, Subei Country[J]. Introduction to China's non-metallic mineral industry, (3): 14-18(in Chinese with English abstract).
Gansu Bureau of Mineral Exploration and Development. 1989. Regional Geological Records of Gansu Province[M]. Beijing: Geological Publishing House.
He Liang, Lin Bin, Zhaxi Pingcuo, Basang Duoji, Du Qiu, Shao Rui, Zhang Qizhi, He Wenge. 2021. The first large-sized graphite deposit in Tibet: Geology of the Qingguo graphite deposit and U-Pb age of its ore-bearing pluton[J]. Geology in China, 48 (2): 359-373(in Chinese with English abstract).
Jia Xin, Yu Junpeng, Fan Xinxiang, Zhao Enhou, Chen Shiqiang, Zheng Liangying, Wang Xiaoqiang. 2020. Characteristics and metallogenic potentiality analysis of crystalline graphite Deposits at aobaoshan area in eastern section of altun tagh mountain[J]. Gansu Geology, 29 (Z2): 61-66(in Chinese with English abstract).
Jones B, Manning D A C. 1994. Comparison of geochemical indices used for the interpretation of palaeoredox conditions in ancient mudstones[J]. Chemical Geology, 111(111): 111-129.
Li C, Arndt N T, Tang Q, Ripley E M. 2015. Trace element indiscrimination diagrams[J]. Lithos, 232: 76-83. doi: 10.1016/j.lithos.2015.06.022
Li Chao, Wang Denghong, Zhao Hong, Pei Haoxiang, Lieutenant Li Xin, Zhou Limin, Du Andao, Qu Wenjun. 2015. Minerogenetic regularity of graphite deposits in China[J]. Mineral Deposits, 34 (6): 1223-1236(in Chinese with English abstract).
Liu Li, Chen Gang, Chen Yanwen, Shen Zuogang, Luo Xiaohong. 2019. Study on Subei Yingzui mountain area metallogenic conditions and metallogenic regularity of the crystalline graphite mine[J]. China Non-metallic Minerals Industry, (3): 22-59(in Chinese with English abstract).
Liu Xiang. 2019. The Protolith Deposition Ages, Source Provenance and Tectonic Significance of Metasedimentary Rocks from the Dunhuang Block[D]. Xi'an: Northwest University(in Chinese with English abstract).
Liu Yongshun, Yu Haifeng, Xin Houtian, Lu Songnian, Xiuqunye, Li Quan. 2009. Tectonic units division and Precambrian significant geological events in Altyn Tagh Mountain, China[J]. Geological Bulletin of China, 28 (10): 1430-1438(in Chinese with English abstract). doi: 10.3969/j.issn.1671-2552.2009.10.009
Mu Kebin, Lian Zhiyi, Wang Xueyin. 2019. Geological characteristics, metallogenic conditions and prospecting signs of the Baishitougou graphite deposit in the southern margin of the Altun, Gansu[J]. Geology and Exploration, 55(3): 701-711(in Chinese with English abstract).
Ning Kuobu, Lin Shiliang, Sun Zhiming, Liu Wei, Luo Maojin, Ma Zhixin. 2022. A new discovery of 1.42 million tons of large crystalline graphite ore in the Yanbian area of Panzhihua, Sichuan[J]. Geology in China, 49(2): 671-672(in Chinese with English abstract).
Palme, H, O'Neill H S C. 2014. Cosmochemical estimates of mantle composition[C]//Holland H D, Turekian K K (eds. ). Treatise on Geochemistry. Elsevier, Amsterdam, 1-39.
Roser B P, Korsch R J. 1986. Determination of tectonic setting of sandstone-mudstone suite using SiO2 content and K2O/Na2O ratio[J]. Journal of Geology, 94(5): 635-650. doi: 10.1086/629071
Simonen A. 1953. Stratigraphy and sedimentation of the Svecofennidic, Early Archean supracrustal rocks in southwestern Finland[J]. Bulletin of the Geological Society of Finland, 160: 1-64.
Sun L, Xu C P, Xiao K Y, Zhu Y S, Yan L Y. 2018. Geological characteristics, metallogenic regularities and the exploration of graphite deposits in China[J]. China Geology, 3: 425-434.
Tian Jingchun, Zhang Xiang. 2016. Sedimentary Geochemistry[M]. Beijing: Geological Publishing House(in Chinese with English abstract).
Wang Dongsheng, Liu Qiang. 2020. Geological characteristics and geological economic significance of Aobaoshan crystalline graphite ore concentration area in Gansu[J]. Mineral Resources and Geology, 34 (6): 457-462, 485(in Chinese with English abstract).
Wang Dongsheng, Ma Fuping. 2017. Gansu Province Subei County Gongliu orebody characteristics, ore graphite crystal gorge and prospecting, ore genesis of ore prospecting[J]. Digital Design, 6 (4): 228-232(in Chinese with English abstract).
Wang Nan, Wu Cailai, Ma Changqian, Lei Min, Guo Wenfeng, Zhang Xin, Chen Hongjie. 2016. Geochemistry, zircon U- Pb geochronology and Hf isotopic characteristics for Granites in southern Dunhuang block[J]. Acta Petrologica Sinica, 32 (12): 3753-3780(in Chinese with English abstract).
Wang Renmin, He Gaopin, Chen Zhenzhen. 1987. The Plot for Recovering Protoliths of Metamorphic Rocks[M]. Beijing: Geological Publishing House(in Chinese with English abstract).
Wang Yiyou, Guo Wenying, Zhang Guodong. 1979. Application of some geochemical indicators in determining of sedimentary environment of the Funing Group (Paleogene), Jin-Hu Depression, Kiangsu Province[J]. Journal of Tongji University, (2): 51-60(in Chinese with English abstract).
Wang Z M, Han C M, Xiao W J, Wang B, Sakyi P A, Ao S J, Zhang J E, Song D F. 2014. Petrology and geochronology of Paleoproterozoic garnet-bearing amphibolites from the Dunhuang Block, Eastern Tarim Craton[J]. Precambrian Research, 255: 163-180. doi: 10.1016/j.precamres.2014.09.025
Wang Zhongmei, Xiao Wenjiao, Han Chunming, Ao Songjian, Wang Luojuan. 2013. Metamorphism, zircon U-Pb dating and tectonic implications of garnet amphibolites from Hongliuxia, Dunhuang, Gansu Province[J]. Acta Petrologica Sinica, 29(5): 1685-1697(in Chinese with English abstract).
Wignall P B. 1994. Black Shales[M]. Oxford: Clarendon Press, 1-46.
Winchester J A, Floyd P A. 1977. Geochemical discrimination of different magma series and their differentiation products using immobile elements[J]. Chemical Geology, 20: 325-343. doi: 10.1016/0009-2541(77)90057-2
Winchester J A, Park R G, Holland J G. 1980. The geochemistry of Lewisian semipelitic schists from the Gairloch District, Wester Ross[J]. Scottish Journal of Geology, 16(2): 165-179.
Yang Jihua, Luo Chongguang, Du Shengjiang, Yu Wenxiu, Yang Yang, Wen Hanjie. 2020. Discussion on the applicability of paleoenvironmental index for sedimentary rocks with high clay content[J]. Acta Mineralogica Sinica, 20 (6): 623-733(in Chinese with English abstract).
Yang Peiqi, Liu Jingdang, Zhang Yanfei, Liang Shuai, Zhao Yue, Liu Shumei. 2017. Ore geochemical characteristics and metallogenic epoch of typical graphite deposits in Jiamusi Massif, Heilongjiang Province[J]. Geology in China, 44(2): 301-315(in Chinese with English abstract).
Yang Zhenxi, Zhao Jichang, Jing Delong, Zhao Qinghu, Zhang Jing, Fan Xinxiang. 2021. Chronological and geochemical characteristics of the porphyritic granodiorite in the Qianhongquan area, Beishan region, Gansu Province, China and their tectonic significances[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 40(1): 228-241(in Chinese with English abstract).
Zhang Xinhu, Liu Jianhong, Liang Minghong, Tian Liping, Li Tongguo, Zhao Yanqing. 2013. Regional Mineralization and Prospecting in Gansu Province[M]. Beijing: Geological Publishing House(in Chinese with English abstract).
Zhang Yanfei, An Zhengzhen, Liang Shuai, Zhai Furong, Zhang Sen, Ju Nan, Jiang Ping, Jin Xiuying, Xiao Rongge. 2022. Distribution characteristics, genetic types and prospecting progress of graphite deposits[J]. Geology in China, 49(1): 135-150(in Chinese with English abstract).
Zhao Jichang, Liu Yonggang, Fan Xinxiang, Hu Xiaochun, Fu Quan, Fang Shaozhong, Yang Zhenxi. 2021. A large crystalline graphite deposit was discovered in the Aobaoshan area of the Dunhuang block[J]. Geology in China, 48(3): 972-973(in Chinese with English abstract).
Zhao Jichang, Zhang Litao, Yang Zhenxi. 2016. Characteristics and tectonic significance of the metamorphic rocks of the first rock group of the Beidahe Group in the Yema Nanshan area, Gansu Province[J]. Gansu Science and Technology, 18: 29-31(in Chinese with English abstract).
Zhao Y, Sun Y, Ao W H, Zhang H, Zhu T. 2019. Depositional age, provenance and tectonic significance of Precambrian metasedimentary rocks from the Dunhuang Complex, NW China: Evidence from field investigation, zircon U-Pb geochronology and whole-rock geochemistry[J]. Precambrian Research, 326: 272-294. doi: 10.1016/j.precamres.2017.12.032
Zhao Yan, Wu Chunrong, Sun Yong, Zhu Tao, Wang Hongliang. 2013. Zircon geochronology and Lu-Hf isotope compositions for Precambrian rocks of the Dunhuang complex in Shuixiakou area, Gansu Province[J]. Acta Petrologica Sinica, 29(5): 1698-1712(in Chinese with English abstract).
Zhao Zhenhua. 2016. Principles of Trace Element Geochemistry (Second Edition)[M]. Beijing: Science Press(in Chinese with English abstract).
Zhou Lian, Su Jie, Huang Junhua, Yan Jiaxin, Xie Xinong, Gao Shan, Dai Mengning, Tengger. 2011. A new paleoenvironmental index for anoxic events-Mo isotopes in black shales from Upper Yangtze marine sediments[J]. Scientia Sinica Terrae, 41(3): 309-319(in Chinese with English abstract). doi: 10.1360/zd-2011-41-3-309
Zhou Shitai. 1984. Examination of 17 petrochemical methods of restoring protoliths of met am orphic rocks[J]. Geological Review, 30(1): 81-84(in Chinese with English abstract). doi: 10.3321/j.issn:0371-5736.1984.01.012
陈世强, 李省晔, 贾鑫, 樊新祥, 王小强. 2021. 甘肃省肃北县敖包沟晶质石墨矿床地球化学特征与成因研究[J]. 矿物岩石地球化学通报, 40(6): 1-10.
邓宏文, 钱凯. 1993. 沉积地球化学与环境分析[M]. 兰州: 甘肃科学技术出版社.
邓绍军, 朱余银, 李虎杰. 2020. 南江坪河石墨矿变质岩原岩恢复及古沉积环境探讨[J]. 西南科技大学学报, 35(1): 22-30. https://www.cnki.com.cn/Article/CJFDTOTAL-XNGX202001004.htm
付全, 张银定, 薛涛. 2020. 肃北白台沟东晶质石墨矿床地质特征及成因探讨[J]. 中国非金属矿工业导刊, (3): 14-18. doi: 10.3969/j.issn.1007-9386.2020.03.005
甘肃省地质矿产局. 1989. 甘肃省区域地质志[M]. 北京: 地质出版社.
何亮, 林彬, 扎西平措, 巴桑多吉, 杜秋, 邵锐, 章奇志, 何文革. 2021. 西藏首例大型石墨矿床——青果矿床地质特征及含矿岩体U-Pb年龄[J]. 中国地质, 48(2): 359-373. http://geochina.cgs.gov.cn/geochina/article/abstract/20210202?st=search
贾鑫, 余君鹏, 樊新祥, 赵恩厚, 陈世强, 郑亮英, 王小强. 2020. 阿尔金山东段敖包山地区晶质石墨矿特征及成矿潜力分析[J]. 甘肃地质, 29(Z2): 61-66.
李超, 王登红, 赵鸿, 裴浩翔, 李欣尉, 周利敏, 杜安道, 屈文俊. 2015. 中国石墨矿床成矿规律概要[J]. 矿床地质, 34 (6): 1223-1236.
刘力, 陈刚, 陈彦文, 沈作刚, 罗小红. 2019. 肃北鹰咀山一带晶质石墨矿成矿条件和成矿规律初探[J]. 中国非金属矿工业导刊, (3): 22-59. doi: 10.3969/j.issn.1007-9386.2019.03.007
刘祥. 2019. 敦煌地块变沉积岩原岩形成年龄、源区性质及其构造意义[D]. 西安: 长安大学.
刘永顺, 于海峰, 辛后田, 陆松年, 修群业, 李铨. 2009. 阿尔金山地区构造单元划分和前寒武纪重要地质事件[J]. 地质通报, 28(10): 1430-1438. doi: 10.3969/j.issn.1671-2552.2009.10.009
穆可斌, 连志义, 王学银. 2019. 甘肃阿尔金南缘白石头沟石墨矿地质特征、成矿条件及找矿标志[J]. 地质与勘探, 55(3): 701-711. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKT201903003.htm
宁括步, 林仕良, 孙志明, 刘伟, 罗茂金, 马志鑫. 2022. 四川攀枝花盐边地区新发现142万吨大型晶质石墨矿[J]. 中国地质, 49(2): 671-672. http://geochina.cgs.gov.cn/geochina/article/abstract/20220224?st=search
田景春, 张翔. 2016. 沉积地球化学[M]. 北京: 地质出版社.
王东升, 刘强. 2020. 甘肃省敖包山晶质石墨矿集区地质特征及地质经济意义[J]. 矿产与地质, 34(6): 457-462, 485.
王东升, 马富平. 2017. 甘肃省肃北县红柳峡晶质石墨矿矿体特征、矿床成因及找矿远景浅析[J]. 数码设计, 6(4): 228-232. https://www.cnki.com.cn/Article/CJFDTOTAL-SMSE201704058.htm
王楠, 吴才来, 马昌前, 雷敏, 郭文峰, 张昕, 陈红杰. 2016. 敦煌地块南部古生代花岗岩地球化学、锆石U-Pb定年及Hf同位素特征研究[J]. 岩石学报, 32(12): 3753-3780. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201612014.htm
王仁民, 贺高品, 陈珍珍, 郑送彦, 耿元生. 1987. 变质岩原岩图解判别法[M]. 北京: 地质出版社.
王益友, 郭文莹, 张国栋. 1979. 几种地球化学标志在金湖凹陷阜宁群沉积环境中的应用[J]. 同济大学学报, (2): 51-60.
王忠梅, 肖文交, 韩春明, 敖松坚, 王洛娟. 2013. 甘肃敦煌红柳峡地区石榴石斜长角闪岩的变质特征、锆石U-Pb年龄及地质意义[J]. 岩石学报, 29(5): 1685-1697.
杨季华, 罗重光, 杜胜江, 于文修, 杨洋, 温汉捷. 2020. 高黏土含量沉积岩古环境指标适用性讨论[J]. 矿物学报, 20(6): 623-733. https://www.cnki.com.cn/Article/CJFDTOTAL-KWXB202006009.htm
杨培奇, 刘敬党, 张艳飞, 梁帅, 赵越, 刘淑梅. 2017. 黑龙江佳木斯地块典型石墨矿床含矿岩石地球化学特征及成矿时代[J]. 中国地质, 44(2): 301-315. http://geochina.cgs.gov.cn/geochina/article/abstract/20170207?st=search
杨镇熙, 赵吉昌, 荆德龙, 赵青虎, 张晶, 樊新祥. 2021. 甘肃北山前红泉地区斑状花岗闪长岩年代学、地球化学特征及其构造意义[J]. 矿物岩石地球化学通报, 40(1): 228-241.
张新虎, 刘建宏, 梁明宏, 田黎萍, 李通国, 赵彦庆. 2013. 甘肃省区域成矿与找矿[M]. 北京: 地质出版社.
张艳飞, 安政臻, 梁帅, 翟富荣, 张森, 鞠楠, 姜平, 金秀英, 肖荣阁. 2022. 石墨矿床分布特征、成因类型及勘查进展[J]. 中国地质, 49(1): 135-150. http://geochina.cgs.gov.cn/geochina/article/abstract/20220109?st=search
赵吉昌, 张立涛, 杨镇熙. 2016. 甘肃野马南山地区北大河岩群一岩组变质岩原岩特征及构造意义[J]. 甘肃科技, 18: 29-31.
赵吉昌, 柳永刚, 樊新祥, 胡小春, 付全, 方绍忠, 杨镇熙. 2021. 敦煌地块敖包山一带发现大型晶质石墨矿床[J]. 中国地质, 48(3): 972-973. http://geochina.cgs.gov.cn/geochina/article/abstract/20210328?st=search
赵燕, 第五春荣, 孙勇, 朱涛, 王洪亮. 2013. 甘肃敦煌水峡口地区前寒武纪岩石的锆石U-Pb年龄、Hf同位素组成及其地质意义[J]. 岩石学报, 29(5): 1698-1712. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201305019.htm
赵振华. 2016. 微量元素地球化学原理(第二版)[M]. 北京: 科学出版社.
周炼, 苏洁, 黄俊华, 颜佳新, 解习农, 高山, 戴梦宁, 腾格尔. 2011. 判识缺氧事件的地球化学新标志-钼同位素[J]. 中国科学: 地球科学, 41(3): 309-319. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201103004.htm
周世泰. 1984. 对17种恢复变质岩原岩的岩石化学方法的检验结果[J]. 地质论评, 30(1): 81-84.
-
