Study on the deformation mechanism and large deformation control method of a strongly weathered carbonaceous slate tunnel in western China
-
摘要:
为解决国家兰海高速(G75)定西段岷县隧道在建设过程中原支护设计方案出现的软岩大变形问题, 通过软岩类型分析、围岩变形力学机制分析, 提出针对不同力学机制的力学转化对策, 引入在矿山及边坡等岩石领域广泛应用的高预紧力恒阻大变形锚索, 提出了"超前支护+长短NPR锚索优化布置主动支护+钢拱架+混凝土喷浆永久支护"的高预应力主被动联合支护技术。通过数值模拟和现场监测效果对比研究, 结果表明, 现场试验段围岩最大变形量仅为73 mm, 恒阻大变形锚索的预紧力均在280~300 kN范围内, 可见优化后不同支护技术均对围岩变形起到了控制作用, 有效发挥了恒阻让压支护的作用, 控制效果明显。
Abstract:In response to the significant soft rock deformation challenges encountered during the construction of the Minxian Tunnel along the Lanzhou-Haikou Expressway (G75), this study conducted a comprehensive analysis of soft rock types and the underlying mechanical mechanisms governing the deformation of the surrounding rock. It presented tailored mechanical transformation strategies to address diverse mechanical mechanisms. Also, it introduced the application of anchor cable with high pre-tightening force, constant resistance and large deformation, a proven solution widely employed in mining and rock engineering. Furthermore, the research proposed a high-prestress and active and passive combined support technique, encompassing pre-reinforced retaining structure, optimally arranged active retaining structure with long and short NPR anchor cables, steel arches, and permanent retaining structure of shotcrete. By implementing numerical simulations and on-site monitoring, the results demonstrated a remarkable reduction in the maximum deformation of the surrounding rock in the test section to only 73 mm, and the pre-tightening forces applied to the anchor cable with constant resistance and large deformation ranged from 280 to 300 kN, underscoring the effectiveness of the optimized retaining technique in controlling surrounding rock deformation. This research highlights the pivotal role of retaining structure with constant resistance and yielding support, which significantly improves deformation control.
-
-
表 1 黏土矿物成分相对含量统计表
Table 1. Statistical table of relative contents of clay mineral composition
编号 黏土矿物相对含量/% S I/S C/S It Kao C 1 / / / 69 6 2 2 / / / 60 5 35 3 / / / 66 / 34 4 / / / 47 / 53 5 / / / 62 / 38 注：S—蒙皂石类；I/S—伊蒙混层；It—伊利石；Kao—高岭石；C—绿泥石；C/S—绿蒙混层
下载: 导出CSV
表 2 全岩矿物成分相对含量统计表
Table 2. Statistical table of relative contents of the mineral compositions of the whole rock
编号 矿物含量/% 石英 黏土矿物 白云石 菱铁矿 黄铁矿 钾长石 石盐 1 56.3 39.6 3.2 / / / 0.9 2 35.2 55.1 / 6.1 / 2.2 1.4 3 62.4 18.6 14.4 / 1.1 2.7 0.8 4 68.6 22.8 4.6 2.8 / / 1.2 5 45.8 19.0 / 3.2 / 2.1 0.9
下载: 导出CSV
表 3 岷县隧道新型控制技术支护参数及原支护技术参数对比表
Table 3. Comparison table for support parameters of the new control technique and the original technique for the Minxian tunnel
原支护方案 新型支护方案 支护形式 支护参数 支护方式 支护参数 超前支护 小导管 ∅×L=42 mm×4500 mm，外插角10°，间排距350 mm×1200 mm 小导管 ∅×L=42 mm×4500 mm，外插角10°，间排距350 mm×1200 mm 初期支护 普通锚杆 全断面支护，∅×L=25 mm×3500 mm，间排距1000 mm×600 mm 短NPR锚索 全断面施工，∅×L=21.8 mm×7300 mm，间排距1000 mm×600 mm ∅×L=89 mm×3500 mm 长NPR锚索 拱顶施工，∅×L=21.8 mm×12300 mm，间排距2000 mm×600 mm 锁脚注浆锚管 拱顶施工，∅ 8 mm，框架尺寸150 mm ×150 mm 柔性网 型号JD PET120×120MS，网格尺寸100 mm×100 mm 钢筋网 C25混凝土，厚度260 mm W钢带 Q235钢：W×L=280 mm×3000 mm，孔径100 mm×100 mm 喷射混凝土 全断面I20a工字钢，排距600 mm 托盘 钢板：W×L×T=300 mm×300 mm×16 mm 钢拱架 钢拱架 全断面I20a工字钢，排距600 mm 喷射混凝土 C25混凝土，厚度260 mm 永久支护 钢筋砼衬砌 C30钢筋混凝土，厚度500 mm 钢筋砼衬砌 C30钢筋混凝土，厚度500 mm 注：∅为直径；L为长度；W为宽度；T为厚度
下载: 导出CSV
表 4 岩体力学参数
Table 4. Mechanical parameters of rock mass
材料 密度/(kg/m3) 弹性模量/GPa 泊松比 内聚力/MPa 内摩擦角/(°) 抗拉强度/MPa 法向刚度/GPa 剪切刚度/GPa 岩体 2500 1.05 0.25 0.8 21 0.5 - - 板理面 - - - 0.5 18 0.1 30 12
下载: 导出CSV
表 5 锚杆及锚索力学参数
Table 5. Mechanical parameters of bolt and anchor cable
横截面积/m2 弹性模量/GPa 抗拉强度/GPa 水泥浆黏结刚度/(N/m2) 水泥浆黏聚强度/Pa 预紧力/N 普通锚杆 3.79×10-4 210 0.182 2×107 2×105 70×103 普通锚索 3.73×10-4 200 0.445 2×107 3×105 150×103 NPR锚索 3.73×10-4 200 0.938 2×107 3×105 280×103
下载: 导出CSV
表 6 钢拱架-喷射混凝土等效支护体力学参数
Table 6. Mechanical parameters of the equivalent retaining structure of steel arch and shotcrete
钢拱架 混凝土型号 混凝土厚度/mm 等效容重/(kN/m3) 等效弹性模量/GPa 等效泊松比 I20a C25 260 23 31.55 0.20 HW175 C25 260 24 51.43 0.22
下载: 导出CSV
表 7 数值模拟方案
Table 7. Numerical simulation schemes
方案 变更内容 锚杆/m 钢拱架 原方案 原支护 3.5 I20a 方案a 更换钢拱架 3.5 H175 方案b 原锚杆—普通锚索 7 I20a 方案c 普通锚索(短+长) 7+12 I20a 方案d NPR锚索(短+长) 7+12 I20a
下载: 导出CSV
-
BARTON N, 1988. Rock mass classification and tunnel reinforcement selection using the q-system[C]//Symposium on Rock Classification Systems for Engineering Purposes. Cincinnati, Ohio, USA.
CAO C Y, SHI C H, LEI M F, et al., 2018. Squeezing failure of tunnels: A case study[J]. Tunnelling and Underground Space Technology, 77: 188-203. doi: 10.1016/j.tust.2018.04.007
DAI Y H, CHEN W Z, TIAN H M, et al., 2015. Study on large deformation and supporting scheme of soft rock in Daliang tunnel [J]. Chinese Journal of Rock Mechanics and Engineering, 34 (S2): 4149-4156. (in Chinese with English abstract)
DONG F T, 2001. Loose circle support theory and application technology of roadway surrounding rock [M]. Beijing: China Coal Industry Publishing House. (in Chinese)
DONG F T, GUO Z H, 1992. Surrounding rock loose circle roadway support theory [J]. Optical Blasting Anchor Spray Communication (1): 1-5. (in Chinese)
DONG F T, 2001. The supporting theory based on broken rock zone and its application technology[M]. Beijing: China Coal Industry Publishing House. (in Chinese)
GUO B, ZHANG Y B, 2009. Research on the control technology for large deformation of carbon schist of Xinshuhe Tunnel [J]. Journal of Railway Engineering Society (11): 40-44. (in Chinese with English abstract) doi: 10.3969/j.issn.1006-2106.2009.11.010
GUO C B, ZHANG Y S, WANG T, et al., 2017. Discussion on geological hazards and major engineering geological problems in the middle part of the North-South active tectonic zone, China [J]. Journal of Geomechanics, 23 (5): 707-722. (in Chinese with English abstract)
GUO F L, 2010. Research on large deformation mechanism of soft rock of Baozhen tunnel [D]. Beijing: Beijing Jiaotong University. (in Chinese with English abstract)
GUO Z H, DONG F T, 1995. Loosening zone of surrounding rock and roadway support [J]. Mine Pressure and Roof Management, 000(3): 111-114. (in Chinese)
HAN R G, 1987. New Austrian Method of Underground Engineering [M]. Beijing: Science Press. (in Chinese)
HE M C, JING H H, SUN X M, 2000. Research progress of soft rock engineering geomechanics in China coal mine [J]. Journal of Engineering Geology, 8(1): 46-62. (in Chinese with English abstract)
HE M C, JING H H, SUN X M, 2002. Soft rock engineering mechanics [M]. Beijing: Science Press. (in Chinese)
HE M C, GONG W L, WANG J, et al., 2014. Development of a novel energy-absorbing bolt with extraordinarily large elongation and constant resistance[J/OL]. International Journal of Rock Mechanics and Mining Sciences, 67: 29-42.
HOEK E, DIEDERICHS M S, 2006. Empirical estimation of rock mass modulus [J]. International Journal of Rock Mechanics and Mining Sciences, 43(2): 203-215. doi: 10.1016/j.ijrmms.2005.06.005
HONG K R, 2019. Development and Thinking of Tunnels and Underground Engineering in China in Recent 2 Years(From 2017 to 2018) [J]. Tunnel Construction, 39 (5): 710-723. (in Chinese with English abstract)
LI B, ZHANG W, WEN R, 2022. Study on the hydraulic fracturing in-situ stress measurement in super-long highway tunnels in southern Shaanxi: engineering geological significance [J]. Journal of Geomechanics, 28 (2): 191-202. (in Chinese with English abstract)
LI G L, ZHU Y Q, 2008. Control technology for large deformation of highland stressed weak rock in Wushaoling tunnel [J]. Journal of Railway Engineering Society, 25 (3): 54-59. (in Chinese with English abstract)
LI L, 2017. Study on squeezing large deformation mechanism and control technology of phyllite tunnel [D]. Beijing: Beijing Jiaotong University. (in Chinese with English abstract)
LI T C, 2011. Large deformation control technology for Maoyushan tunnel in soft rock under high in-situ stresses [J]. Modern Tunnel Technology, 48 (2): 59-67. (in Chinese with English abstract)
LI Y Y, LI S Q, 2008. Analysis of surrounding rock bearing mechanism in deep soft rock roadways with associate support of anchoring and grouting [J]. Journal of Hunan University of Science and Technology(Natural Science Edition), 23 (1): 10-14. (in Chinese with English abstract)
LIU Y, WU X J, LIU Z Q, et al., 2014. Discussion of and solutions for the large deformation mechanism of a tunnel in carbonaceous slate [J]. Modern Tunnelling Technology, 51(6): 19-24. (in Chinese with English abstract)
LUO G, 2019. Statistics of super-long highway tunnels over 10 km in China [J]. Tunnel Construction (Chinese and English), 39 (8): 1380-1383. (in Chinese with English abstract)
MENG L B, PAN H S, LI T B, et al., 2017. Secondary lining cracking mechanism and the best time for supporting the Zhegushan Tunnel [J]. Modern Tunnelling Technology, 54(2): 129-136. (in Chinese with English abstract)
MENG W, TIAN T, SUN D S, et al., 2022. Research on stress state in deep shale reservoirs based on in-situ stress measurement and rheological model[J]. Journal of Geomechanics, 28(4): 537-549. (in Chinese with English abstract)
Ministry of Housing and Urban-Rural Development of the People's Republic of China, 2015. Standard for engineering classification of rock mass: GB/T 50218-2014[S]. Beijing: China Planning Press. (in Chinese)
PROCTOR, R V, WHITE T L, 1946. Rock tunneling with steel supports[M]. Youngstown, OH: Commercial Shearing and Stamping Co.
SHEN H M, 1995. Recommendation of Norway tunnel construction method NTM [J]. Journal of Railway Engineering Society, (3): 40-48. (in Chinese with English abstract)
SUN G J, DENG X L, YUAN P B, 2021. Research on Disaster Mechanism and Control of Permian Mudstone Tunnel in North China[J]. Railway Investigation and Surveying, 47(2): 44-49. (in Chinese with English abstract)
SUN Y C, XIN M G, WANG Y, et al., 2022. Measurement and Regression Analysis of the Tunnel Geostress of a Heavy Haul Railway[J]. Railway Investigation and Surveying, 48(1): 16-20, 44. (in Chinese with English abstract)
TAO Z G, ZHAO S, ZHANG M X, et al., 2018. Numerical simulation research on mechanical properties of constant resistance bolt/cable with large deformation [J]. Journal of Mining and Safety Engineering, 35 (1): 40-48. (in Chinese with English abstract)
TERZAGHI K, 1960. Theoretical soil mechanics[M]. XU Z Y, trans. Beijing: Geological Press. (in Chinese)
TIAN H M, CHEN W Z, TAN X J, et al., 2011. Study on reasonable support scheme on soft rock tunnel in high geostress zone[J]. Chinese Journal of Rock Mechanics and Engineering, 30 (11): 2285-2292. (in Chinese with English abstract)
TIAN S M, GONG J F, 2020. Statistics of China Railway Tunnels as of the end of 2019 [J]. Tunnel Construction, 40 (2): 292-297. (in Chinese with English abstract)
WANG B, LI T B, HE C, et al., 2012. Analysis of failure properties and formatting mechanism of soft rock tunnel in Meizoseismal areas [J]. Chinese Journal of Rock Mechanics and Engineering, 31 (5): 928-936. (in Chinese with English abstract)
WANG S R, LIU Z W, QU X H, et al., 2009. Large deformation mechanics mechanism and rigid-gap-flexible-layer supporting technology of soft rock tunnel [J]. China Journal of Highway and Transport, 22 (6): 90-95. (in Chinese with English abstract)
XIA R H, CUI X P, ZHOU Q, 2015. Analysis of tunnel lining deformation in complex geology and engineering control technology [J]. Journal of Railway Engineering Society, 32 (8): 66-72. (in Chinese with English abstract)
ZHANG C, LOU Y M, SUN S H, et al., 2003. Application and discussion on floor arch board technology in project with water inrush and swelling soft rock [J]. Coal Science and Technology, 31 (6): 53-55. (in Chinese with English abstract)
ZHANG D H, WANG M S, FU H X, et al., 2004. Determination of paremeters for bolts in strong extrusion tunnel [J]. Journal of Rock Mechanics and Engineering (13): 2201-2204. (in Chinese with English abstract)
ZHANG P, SUN Z G, WANG Q N et al., 2017. In-situ stress measurement and stability analysis of surrounding rocks in the north section of deep buried tunnel in Muzhailing [J]. Journal of Geomechanics, 23 (6): 893-903. (in Chinese with English abstract)
戴永浩, 陈卫忠, 田洪铭, 等, 2015. 大梁隧道软岩大变形及其支护方案研究[J]. 岩石力学与工程学报, 34(S2): 4149-4156. https://www.cnki.com.cn/Article/CJFDTOTAL-YSLX2015S2063.htm
董方庭, 郭志宏, 1992. 围岩松动圈巷道支护理论[J]. 光爆锚喷通讯(1): 1-5. https://www.cnki.com.cn/Article/CJFDTOTAL-XSKJ201911016.htm
董方庭, 2001. 巷道围岩松动圈支护理论及应用技术[M]. 北京: 煤炭工业出版社.
苟彪, 张奕斌, 2009. 新蜀河隧道炭质片岩大变形控制技术研究[J]. 铁道工程学报(11): 40-44. https://www.cnki.com.cn/Article/CJFDTOTAL-TDGC200911009.htm
郭长宝, 张永双, 王涛, 等, 2017. 南北活动构造带中段地质灾害与重大工程地质问题概论[J]. 地质力学学报, 23(5): 707-722. https://journal.geomech.ac.cn/article/id/f1e76c0c-1fca-447c-a551-7eaad567800f
郭富利, 2010. 堡镇软岩隧道大变形机理及控制技术研究[D]. 北京: 北京交通大学.
郭志宏, 董方庭, 1995. 围岩松动圈与巷道支护[J]. 矿山压力与顶板管理, (3-4): 111-114. https://www.cnki.com.cn/Article/CJFDTOTAL-KSYL5Z1.026.htm
韩瑞庚, 1987. 地下工程新奥法[M]. 北京: 科学出版社.
何满潮, 景海河, 孙晓明, 2000. 软岩工程地质力学研究进展[J]. 工程地质学报, 8(1): 46-62. https://www.cnki.com.cn/Article/CJFDTOTAL-GCDZ200001009.htm
何满潮, 景海河, 孙晓明, 2002. 软岩工程力学[M]. 北京: 科学出版社.
洪开荣, 2019. 近2年我国隧道及地下工程发展与思考(2017—2018年)[J]. 隧道建设, 39(5): 710-723. https://www.cnki.com.cn/Article/CJFDTOTAL-JSSD201905003.htm
李彬, 张文, 文冉, 2022. 陕南特长公路隧道水压致裂法地应力测量结果及工程地质意义分析[J]. 地质力学学报, 28(2): 191-202. https://journal.geomech.ac.cn/cn/article/doi/10.12090/j.issn.1006-6616.2021053
李国良, 朱永全, 2008. 乌鞘岭隧道高地应力软弱围岩大变形控制技术[J]. 铁道工程学报, 25(3): 54-59. https://www.cnki.com.cn/Article/CJFDTOTAL-TDGC200803010.htm
李磊, 2017. 千枚岩隧道挤压性大变形机理及控制技术研究[D]. 北京: 北京交通大学.
李廷春, 2011. 毛羽山隧道高地应力软岩大变形施工控制技术[J]. 现代隧道技术, 48(2): 59-67. https://www.cnki.com.cn/Article/CJFDTOTAL-XDSD201102012.htm
李永友, 李树清, 2008. 深部软岩巷道锚注联合支护围岩承载机理分析[J]. 湖南科技大学学报(自然科学版), 23(1): 10-14. https://www.cnki.com.cn/Article/CJFDTOTAL-XTKY200801002.htm
刘阳, 伍晓军, 刘志强, 等, 2014. 关于碳质板岩隧道大变形机理及应对措施的探讨[J]. 现代隧道技术, 51(6): 19-24. https://www.cnki.com.cn/Article/CJFDTOTAL-XDSD201406005.htm
罗刚, 2019. 中国10 km以上超长公路隧道统计[J]. 隧道建设, 39(8): 1380-1383. https://www.cnki.com.cn/Article/CJFDTOTAL-JSSD201908030.htm
孟陆波, 潘皇宋, 李天斌, 等, 2017. 鹧鸪山隧道二次衬砌开裂机理及支护时机探讨[J]. 现代隧道技术, 54(2): 129-136. https://www.cnki.com.cn/Article/CJFDTOTAL-XDSD201702020.htm
孟文, 田涛, 孙东生, 等, 2022. 基于原位地应力测试及流变模型的深部泥页岩储层地应力状态研究[J]. 地质力学学报, 28(4): 537-549. https://journal.geomech.ac.cn/cn/article/doi/10.12090/j.issn.1006-6616.2022041
长江水利委员会长江科学院, 2014. 工程岩体分级标准: GB/T 50218— 2014[S]. 北京: 中国计划出版社, 2014.
沈慧敏, 1995. 推荐挪威隧道施工法NTM[J]. 铁道工程学报(3): 40-48. https://www.cnki.com.cn/Article/CJFDTOTAL-TDGC503.007.htm
孙光吉, 邓小龙, 原鹏博, 2021. 华北二叠系泥岩隧道灾变机理及控制研究[J]. 铁道勘察, 47(2): 44-49. https://www.cnki.com.cn/Article/CJFDTOTAL-TLHC202102010.htm
孙元春, 辛明高, 汪洋, 等, 2022. 某重载铁路隧道地应力测试与反演分析[J]. 铁道勘察, 48(1): 16-20, 44. https://www.cnki.com.cn/Article/CJFDTOTAL-TLHC202201004.htm
太沙基. K. 1960. 理论土力学[M]. 徐志英, 译. 北京: 地质出版社.
陶志刚, 赵帅, 张明旭, 等, 2018. 恒阻大变形锚杆/索力学特性数值模拟研究[J]. 采矿与安全工程学报, 35(1): 40-48. https://www.cnki.com.cn/Article/CJFDTOTAL-KSYL201801006.htm
田洪铭, 陈卫忠, 谭贤君, 等, 2011. 高地应力软岩隧道合理支护方案研究[J]. 岩石力学与工程学报, 30(11): 2285-2292. https://www.cnki.com.cn/Article/CJFDTOTAL-YSLX201111015.htm
田四明, 巩江峰, 2020. 截至2019年底中国铁路隧道情况统计[J]. 隧道建设, 40(2): 292-297. https://www.cnki.com.cn/Article/CJFDTOTAL-JSSD202304018.htm
汪波, 李天斌, 何川, 等, 2012. 强震区软岩隧道大变形破坏特征及其成因机制分析[J]. 岩石力学与工程学报, 31(5): 928-936. https://www.cnki.com.cn/Article/CJFDTOTAL-YSLX201205010.htm
王树仁, 刘招伟, 屈晓红, 等, 2009. 软岩隧道大变形力学机制与刚隙柔层支护技术[J]. 中国公路学报, 22(6): 90-95. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGGL200906012.htm
夏润禾, 崔小鹏, 周泉, 2015. 复杂地质隧道衬砌变形分析与工程治理技术[J]. 铁道工程学报, 32(8): 66-72. https://www.cnki.com.cn/Article/CJFDTOTAL-TDGC201508013.htm
张春, 娄玉民, 孙树华, 等, 2003. 底梁弧板技术在涌水性膨胀型软岩工程中应用[J]. 煤炭科学技术, 31(6): 53-55. https://www.cnki.com.cn/Article/CJFDTOTAL-MTKJ200306019.htm
张德华, 王梦恕, 符华兴, 等, 2004. 强挤压型隧道锚杆支护参数的确定[J]. 岩石力学与工程学报, 23(13): 2201-2204. https://www.cnki.com.cn/Article/CJFDTOTAL-YSLX200413013.htm
张鹏, 孙治国, 王秋宁, 等, 2017. 木寨岭深埋隧道北段地应力测量与围岩稳定性分析[J]. 地质力学学报, 23(6): 893-903. https://journal.geomech.ac.cn/article/id/0febae11-4b7b-4e07-a1a7-24791d29026a
中华人民共和国住房和城乡建设部, 2015. 工程岩体分级标准: GB/T 50218-2014[S]. 北京: 中国计划出版社.
-
