扬子北缘南华系武当群锆石U-Pb年龄: 对扬子北缘南华纪裂解模式的启示

,  ,  ,  ,  ,

文章导航 > 地质通报 > 2022 > 41(12): 2224-2243

上一篇

下一篇

孔令耀, 杨成, 李琳静, 周峰, 郭盼, 陈超. 扬子北缘南华系武当群锆石U-Pb年龄: 对扬子北缘南华纪裂解模式的启示[J]. 地质通报, 2022, 41(12): 2224-2243. doi: 10.12097/j.issn.1671-2552.2022.12.013
引用本文: 孔令耀, 杨成, 李琳静, 周峰, 郭盼, 陈超. 扬子北缘南华系武当群锆石U-Pb年龄: 对扬子北缘南华纪裂解模式的启示[J]. 地质通报, 2022, 41(12): 2224-2243. doi: 10.12097/j.issn.1671-2552.2022.12.013
shu
KONG Lingyao, YANG Cheng, LI Linjing, ZHOU Feng, GUO Pan, CHEN Chao. Zircon U-Pb age of Wudang Group: implication to the breakup model of North Yangtze Block during the Early Neoproterozoic[J]. Geological Bulletin of China, 2022, 41(12): 2224-2243. doi: 10.12097/j.issn.1671-2552.2022.12.013
Citation: KONG Lingyao, YANG Cheng, LI Linjing, ZHOU Feng, GUO Pan, CHEN Chao. Zircon U-Pb age of Wudang Group: implication to the breakup model of North Yangtze Block during the Early Neoproterozoic[J]. Geological Bulletin of China, 2022, 41(12): 2224-2243. doi: 10.12097/j.issn.1671-2552.2022.12.013
shu

扬子北缘南华系武当群锆石U-Pb年龄: 对扬子北缘南华纪裂解模式的启示

  • 1.

    湖北省地质调查院, 湖北 武汉 430034

  • 2.

    湖北省地质勘查工程技术研究中心, 湖北 武汉 430034

  • 基金项目:
    中国地质调查局项目《湖北省1;5万长岗店幅(编号: H49E003020)、均川幅(H49E003021)、客店坡幅(H49E004020)、古城畈幅(H49E004021)、三阳店幅(H49E005021)区域地质调查》(编号: DD20160030)和湖北省地质局项目《武当-桐柏-大别造山带重要地质过程及其资源效应研究》(编号: KJ2022-6)
详细信息
    作者简介: 孔令耀(1989-)，男，硕士，工程师，从事区域地质调查工作。E-mail：951121661@qq.com

  • 中图分类号: P597+.3;P62

Zircon U-Pb age of Wudang Group: implication to the breakup model of North Yangtze Block during the Early Neoproterozoic

  • 1.

    Hubei Geological Survey, Wuhan 430034, Hubei, China

  • 2.

    Hubei Research Center of Geological Exploration and Engineering Technology, Wuhan 430034, Hubei, China

    摘要

  • 扬子北缘出露的武当群是南秦岭地区最重要的基底组成物质, 记录了南秦岭最古老的物质信息。为探讨扬子北缘南华纪的地层序列与裂谷演化模式, 对湖北随州地区武当群典型剖面上的碎屑岩和火山岩进行锆石U-Pb测年, 确定了武当群的沉积层序, 并结合武当、随州地区的武当群锆石年龄, 认为武当地区武当群年龄较随州地区老30 Ma左右, 显示扬子北缘的南华纪裂谷具有自西向东逐渐打开的"剪刀式"裂解特征。武当群碎屑锆石主要峰值年龄为722 Ma、759 Ma、820 Ma、2014 Ma和2445 Ma, 与扬子陆块碎屑锆石的峰值具有较好的对应, 指示了武当群与扬子陆块强烈的亲缘性, 峰值2014 Ma则反映武当群可能有来自桐柏—大别地区的物源信息; 722~759 Ma的峰值代表扬子北缘南华纪早期裂解最强烈的时期, 该裂解事件可能是扬子北缘Rodinia超大陆裂解过程的体现。

    The Wudang Group exposed in the northern margin of Yangtze Block is one of the most important basement of South Qinling Orogen, and it records the oldest provenance information of South Qinling Orogen. In order to explore the stratigraphic sequence of Wudang Group and rift evolution model of Nanhua period in the northern margin of Yangtze Block, we dated the zircon U-Pb age of clasolite and volcanics from typical geological sections of Wudang Group in Suizhou area, and determined the sedimentary sequence of Wudang Group. Combined with the chronological information of Wudang Group in Suizhou and Wudang area from previous researches, we find that the stratigraphic age of Wudang Group in Wudang area is older about 30 Ma than the ages in Suizhou area, which shows that the rift during Neoproterozoic may be cracking gradually like a "scissor" from west to east in the northern margin of Yangtze Block. The main age peaks of detrital zircons from Wudang Group is about 722 Ma, 759 Ma, 820 Ma, 2014 Ma and 2445 Ma, which has a good correlation with main age peaks of detrital zircons from Yangtze Block, suggesting that the main provenance of Wudang Group is coming from the Yangtze Block. The age peak of 2014 Ma shows there may be provenance information from Tongbai-Dabie area, and the age peak about 722~759 Ma represents the strongest period of breaking up in the northern margin of Yangtze Block, whick may be the embodiment of the Rodinia supercontinent break-up in the northern margin of Yangtze Block.

    • HTML全文
  • 加载中

  • 图 1  南秦岭武当—随州地区区域地质简图

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  随州南部典型武当群实测地质剖面

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 图版Ⅰ

    Figure 图版Ⅰ.

    下载: 全尺寸图片 幻灯片

    图 3  武当群样品锆石阴极发光(CL)图像

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  武当群样品PM203-12-1碎屑锆石U-Pb年龄谐和图和年龄频率直方图

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  武当群样品PM203-17-1岩浆锆石U-Pb年龄谐和图和平均年龄图

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  武当群样品PM204-7-1(a、b)和PM408-21-1(c、d)碎屑锆石U-Pb年龄谐和图和年龄频率直方图

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  南秦岭随州—武当地区武当群年龄对比图

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  随州、武当地区武当群碎屑锆石频谱特征对比(a)和武当群与扬子陆块碎屑锆石频谱特征对比(b)

    Figure 8.

    下载: 全尺寸图片 幻灯片

    表 1  样品锆石U-Th-Pb同位素测年结果

    Table 1.  LA-ICP-MS zircon U-Th-Pb isotope dating results of the samples

    测试点号 元素含量/10-6 Th/U 比值 年龄/Ma 谐和度
    232Th 238U 207Pb/ 206Pb 1σ 207Pb/ 235Pb 1σ 206Pb/ 238U 1σ 207Pb/ 206Pb 1σ 207Pb/ 235Pb 1σ 206Pb/ 238U 1σ
    PM203-12-1
    01 77.5 182.4 0.4 0.0685 0.0013 1.3365 0.0267 0.1417 0.0020 883 38 862 12 855 12 99%
    02 106.0 139.5 0.8 0.0656 0.0012 1.2075 0.0243 0.1337 0.0021 794 32 804 11 809 12 99%
    03 187.7 277.2 0.7 0.1225 0.0015 5.9937 0.0984 0.3551 0.0055 1994 22 1975 14 1959 26 99%
    04 73.4 161.6 0.5 0.0665 0.0014 1.2349 0.0300 0.1351 0.0023 833 38 817 14 817 13 99%
    05 159.4 247.3 0.6 0.0662 0.0012 1.2645 0.0263 0.1387 0.0020 813 37 830 12 837 11 99%
    06 65.8 129.2 0.5 0.0681 0.0012 1.2959 0.0260 0.1383 0.0021 872 37 844 11 835 12 98%
    07 92.7 124.4 0.7 0.0638 0.0016 1.1110 0.0271 0.1270 0.0021 744 52 759 13 771 12 98%
    08 264.5 482.3 0.5 0.0668 0.0009 1.2860 0.0242 0.1398 0.0023 831 -169 840 11 844 13 99%
    09 329.1 467.2 0.7 0.0679 0.0009 1.3084 0.0192 0.1397 0.0017 878 28 849 8 843 10 99%
    10 52.0 102.0 0.5 0.0662 0.0014 1.2400 0.0299 0.1362 0.0025 813 44 819 14 823 14 99%
    11 21.2 72.2 0.3 0.0691 0.0020 1.4894 0.0436 0.1569 0.0028 902 60 926 18 939 15 98%
    12 213.5 546.9 0.4 0.0698 0.0008 1.3569 0.0206 0.1405 0.0016 920 25 871 9 848 9 97%
    13 68.8 158.0 0.4 0.0651 0.0011 1.1884 0.0269 0.1319 0.0024 776 33 795 13 799 14 99%
    14 134.4 150.4 0.9 0.0630 0.0013 1.1044 0.0244 0.1274 0.0026 709 44 755 12 773 15 97%
    15 73.8 130.9 0.6 0.0643 0.0015 1.1693 0.0290 0.1319 0.0027 752 48 786 14 799 15 98%
    16 141.6 234.1 0.6 0.0648 0.0011 1.1615 0.0247 0.1300 0.0026 769 37 783 12 788 15 99%
    17 131.8 229.4 0.6 0.0662 0.0011 1.2849 0.0304 0.1402 0.0027 813 36 839 14 846 15 99%
    18 84.9 153.4 0.6 0.0667 0.0013 1.2929 0.0231 0.1409 0.0023 828 45 843 10 850 13 99%
    19 34.8 73.6 0.5 0.0685 0.0019 1.3757 0.0400 0.1460 0.0026 883 55 879 17 879 15 99%
    20 65.7 120.1 0.5 0.0652 0.0014 1.3114 0.0305 0.1455 0.0022 781 44 851 13 876 13 97%
    21 33.1 69.7 0.5 0.0682 0.0019 1.3312 0.0389 0.1415 0.0024 876 58 859 17 853 13 99%
    22 228.6 388.8 0.6 0.1567 0.0161 4.1502 0.5299 0.1673 0.0052 2420 175 1664 105 997 29 49%
    23 114.9 210.3 0.5 0.0661 0.0013 1.2466 0.0250 0.1374 0.0029 809 41 822 11 830 16 99%
    24 91.5 150.0 0.6 0.0663 0.0014 1.1962 0.0263 0.1315 0.0029 815 45 799 12 796 17 99%
    25 138.0 158.8 0.9 0.0664 0.0014 1.2489 0.0309 0.1356 0.0021 820 46 823 14 820 12 99%
    26 53.4 74.2 0.7 0.0681 0.0020 1.3204 0.0416 0.1402 0.0029 872 61 855 18 846 17 98%
    27 125.4 270.7 0.5 0.0661 0.0011 1.2600 0.0301 0.1367 0.0026 811 40 828 14 826 15 99%
    28 33.8 59.4 0.6 0.0810 0.0022 1.7619 0.0490 0.1572 0.0033 1222 54 1032 18 941 18 90%
    29 67.8 174.2 0.4 0.1775 0.0023 12.6689 0.2613 0.5126 0.0107 2631 21 2655 19 2668 45 99%
    30 113.3 341.9 0.3 0.0664 0.0010 1.2860 0.0275 0.1394 0.0026 820 31 840 12 841 15 99%
    31 225.0 279.9 0.8 0.0643 0.0011 1.1546 0.0268 0.1296 0.0028 754 35 779 13 786 16 99%
    32 70.2 133.7 0.5 0.0680 0.0012 1.3318 0.0269 0.1415 0.0023 878 37 860 12 853 13 99%
    33 49.1 83.6 0.6 0.0656 0.0019 1.1305 0.0325 0.1251 0.0024 794 55 768 15 760 14 98%
    34 86.2 267.2 0.3 0.0680 0.0013 1.3153 0.0283 0.1406 0.0029 878 39 852 12 848 16 99%
    35 183.7 276.2 0.7 0.0664 0.0013 1.2154 0.0277 0.1323 0.0020 820 36 808 13 801 11 99%
    36 38.3 301.3 0.1 0.0641 0.0010 1.0934 0.0228 0.1235 0.0020 746 40 750 11 751 11 99%
    37 228.3 277.3 0.8 0.0664 0.0014 1.1921 0.0235 0.1313 0.0026 820 46 797 11 795 15 99%
    38 197.7 294.5 0.7 0.0673 0.0014 1.2785 0.0336 0.1388 0.0036 848 47 836 15 838 20 99%
    39 48.7 117.6 0.4 0.0651 0.0012 1.2795 0.0307 0.1421 0.0021 789 41 837 14 857 12 97%
    40 111.7 234.1 0.5 0.0662 0.0012 1.2654 0.0318 0.1385 0.0028 813 39 830 14 836 16 99%
    41 46.0 182.5 0.3 0.0650 0.0012 1.1517 0.0259 0.1283 0.0019 776 35 778 12 778 11 99%
    42 161.6 350.1 0.5 0.0664 0.0011 1.2055 0.0268 0.1316 0.0023 820 35 803 12 797 13 99%
    43 159.2 305.9 0.5 0.0659 0.0011 1.2205 0.0236 0.1343 0.0021 806 34 810 11 812 12 99%
    44 31.9 89.7 0.4 0.0660 0.0017 1.1684 0.0308 0.1290 0.0025 806 54 786 14 782 14 99%
    45 89.1 212.1 0.4 0.0670 0.0012 1.2899 0.0257 0.1397 0.0020 839 -163 841 11 843 11 99%
    46 33.1 118.5 0.3 0.0681 0.0014 1.3237 0.0317 0.1410 0.0021 872 47 856 14 850 12 99%
    47 102.5 215.0 0.5 0.0670 0.0012 1.2368 0.0258 0.1341 0.0021 839 38 817 12 811 12 99%
    48 59.6 95.4 0.6 0.0666 0.0013 1.2365 0.0301 0.1349 0.0022 833 41 817 14 815 13 99%
    49 151.9 276.1 0.6 0.0662 0.0012 1.2003 0.0235 0.1316 0.0015 813 37 801 11 797 8 99%
    50 118.9 149.0 0.8 0.0659 0.0012 1.1764 0.0223 0.1293 0.0016 806 39 790 10 784 9 99%
    51 120.6 364.8 0.3 0.0694 0.0009 1.3883 0.0196 0.1449 0.0016 909 27 884 8 872 9 98%
    52 140.5 238.5 0.6 0.0664 0.0010 1.2681 0.0226 0.1383 0.0019 818 31 832 10 835 11 99%
    53 83.3 135.4 0.6 0.0710 0.0015 1.5041 0.0373 0.1530 0.0022 967 41 932 15 918 13 98%
    54 117.7 118.4 1.0 0.0724 0.0014 1.3154 0.0245 0.1317 0.0018 996 40 852 11 798 10 93%
    55 66.6 101.2 0.7 0.0660 0.0019 1.1885 0.0327 0.1306 0.0021 806 59 795 15 791 12 99%
    56 26.8 69.3 0.4 0.0701 0.0020 1.4347 0.0395 0.1486 0.0028 931 57 904 16 893 16 98%
    57 115.9 271.2 0.4 0.0668 0.0011 1.2210 0.0263 0.1324 0.0027 831 32 810 12 801 15 98%
    58 45.9 143.6 0.3 0.1141 0.0017 5.0252 0.1105 0.3195 0.0072 1865 26 1824 19 1787 35 97%
    59 106.8 133.0 0.8 0.0641 0.0013 1.1639 0.0280 0.1314 0.0024 746 43 784 13 796 14 98%
    60 80.9 96.7 0.8 0.0672 0.0015 1.1928 0.0278 0.1289 0.0023 843 44 797 13 781 13 98%
    61 49.3 85.8 0.6 0.0657 0.0015 1.1893 0.0322 0.1314 0.0029 798 46 796 15 796 17 99%
    62 26.6 61.9 0.4 0.0662 0.0017 1.3692 0.0416 0.1496 0.0027 813 49 876 18 899 15 97%
    63 149.1 564.1 0.3 0.0751 0.0019 1.6203 0.0585 0.1545 0.0021 1070 52 978 23 926 12 94%
    64 67.5 139.9 0.5 0.0644 0.0012 1.1221 0.0258 0.1266 0.0026 767 39 764 12 769 15 99%
    65 142.5 154.3 0.9 0.0641 0.0012 1.0874 0.0259 0.1228 0.0022 746 39 747 13 747 12 99%
    66 74.2 141.2 0.5 0.0661 0.0013 1.1936 0.0244 0.1314 0.0023 809 42 798 11 796 13 99%
    67 191.2 222.0 0.9 0.0654 0.0012 1.1892 0.0239 0.1318 0.0020 787 42 796 11 798 11 99%
    68 22.6 56.9 0.4 0.0646 0.0019 1.1035 0.0377 0.1245 0.0028 761 62 755 18 756 16 99%
    69 51.6 120.5 0.4 0.0649 0.0013 1.1505 0.0264 0.1284 0.0020 772 43 777 12 778 12 99%
    70 85.9 144.7 0.6 0.0667 0.0015 1.1688 0.0285 0.1272 0.0021 828 44 786 13 772 12 98%
    71 110.1 187.3 0.6 0.0666 0.0013 1.2247 0.0268 0.1331 0.0019 828 47 812 12 805 11 99%
    72 165.7 411.9 0.4 0.0665 0.0010 1.2912 0.0265 0.1405 0.0023 820 31 842 12 848 13 99%
    73 37.4 79.6 0.5 0.0654 0.0016 1.1515 0.0285 0.1285 0.0026 787 46 778 13 779 15 99%
    74 225.8 239.4 0.9 0.1239 0.0015 6.2074 0.0988 0.3629 0.0051 2014 20 2005 14 1996 24 99%
    75 62.6 207.0 0.3 0.0680 0.0012 1.3287 0.0255 0.1417 0.0017 878 35 858 11 854 10 99%
    76 18.1 42.1 0.4 0.0688 0.0021 1.3098 0.0457 0.1381 0.0027 894 63 850 20 834 15 98%
    77 49.7 85.1 0.6 0.0712 0.0025 1.4758 0.0513 0.1509 0.0021 965 68 921 21 906 12 98%
    78 96.5 199.0 0.5 0.0677 0.0014 1.2788 0.0276 0.1372 0.0017 859 43 836 12 829 10 99%
    79 193.9 239.3 0.8 0.1159 0.0014 4.0570 0.0683 0.2535 0.0031 1894 21 1646 14 1457 16 87%
    80 67.4 90.5 0.7 0.0664 0.0016 1.3146 0.0362 0.1439 0.0028 820 55 852 16 867 16 98%
    81 96.5 124.5 0.8 0.0659 0.0016 1.2265 0.0288 0.1370 0.0035 1200 52 813 13 828 20 98%
    82 47.9 107.3 0.4 0.0636 0.0017 1.0790 0.0292 0.1238 0.0027 728 57 743 14 752 16 98%
    83 96.8 160.5 0.6 0.0640 0.0015 1.0744 0.0257 0.1223 0.0024 743 48 741 13 744 14 99%
    84 216.9 471.8 0.5 0.0667 0.0011 1.2239 0.0251 0.1331 0.0026 831 33 812 11 805 15 99%
    85 67.1 127.8 0.5 0.0642 0.0015 1.1272 0.0337 0.1268 0.0025 746 48 766 16 770 14 99%
    86 21.1 51.4 0.4 0.0687 0.0065 1.3076 0.0498 0.1499 0.0053 900 196 849 22 900 29 94%
    87 57.2 146.4 0.4 0.0632 0.0014 1.1659 0.0277 0.1342 0.0024 717 50 785 13 812 14 96%
    88 29.6 131.8 0.2 0.1786 0.0027 13.6542 0.3144 0.5545 0.0108 2640 25 2726 22 2844 45 95%
    89 237.0 309.6 0.8 0.0583 0.0011 1.1832 0.0265 0.1469 0.0016 543 41 793 12 884 9 89%
    90 45.5 74.1 0.6 0.0612 0.0020 1.0975 0.0360 0.1312 0.0027 656 73 752 17 795 16 94%
    91 157.4 254.8 0.6 0.0586 0.0015 1.0825 0.0344 0.1340 0.0023 550 56 745 17 811 13 91%
    92 68.3 111.4 0.6 0.0583 0.0017 1.0475 0.0375 0.1306 0.0027 539 65 728 19 791 16 91%
    93 80.0 135.0 0.6 0.0601 0.0016 1.1615 0.0382 0.1401 0.0027 609 57 783 18 845 15 92%
    94 231.5 298.9 0.8 0.0589 0.0013 1.1301 0.0325 0.1398 0.0031 565 45 768 15 843 17 90%
    95 70.3 125.0 0.6 0.0595 0.0014 1.1371 0.0311 0.1391 0.0027 587 19 771 15 839 15 91%
    96 18.7 50.2 0.4 0.0672 0.0023 1.2888 0.0456 0.1397 0.0024 844 75 841 20 843 14 99%
    97 42.6 70.9 0.6 0.0625 0.0020 1.1827 0.0364 0.1387 0.0031 700 72 793 17 837 17 94%
    98 56.6 106.4 0.5 0.0640 0.0016 1.2162 0.0349 0.1379 0.0025 743 47 808 16 833 14 96%
    PM203-17-1
    01 214.9 188.3 1.1 0.0757 0.0030 1.2701 0.0594 0.1216 0.0031 1087 80 832 27 740 18 88%
    02 222.0 244.1 0.9 0.0666 0.0014 1.1190 0.0270 0.1211 0.0014 828 46 762 13 737 8 96%
    03 107.9 116.8 0.9 0.1713 0.0114 3.2494 0.2538 0.1302 0.0031 2570 111 1469 61 789 18 39%
    04 190.1 259.1 0.7 0.0742 0.0026 1.1280 0.0456 0.1095 0.0019 1048 70 767 22 670 11 86%
    05 214.5 347.5 0.6 0.0685 0.0012 1.1548 0.0270 0.1219 0.0022 883 32 780 13 742 13 95%
    06 71.4 192.8 0.4 0.0810 0.0025 1.0051 0.0315 0.0900 0.0015 1233 61 706 16 555 9 76%
    07 269.2 446.7 0.6 0.0668 0.0010 1.1266 0.0232 0.1216 0.0019 831 -169 766 11 740 11 96%
    08 77.6 142.8 0.5 0.0667 0.0012 1.2323 0.0287 0.1332 0.0020 828 38 815 13 806 12 98%
    09 277.6 135.4 2.0 0.0863 0.0029 1.5678 0.0765 0.1288 0.0034 1346 65 958 30 781 19 79%
    10 716.5 403.3 1.8 0.0698 0.0017 1.1606 0.0392 0.1190 0.0017 924 49 782 18 725 10 92%
    11 145.0 214.2 0.7 0.0737 0.0017 1.1178 0.0346 0.1090 0.0016 1031 45 762 17 667 9 86%
    12 227.7 268.7 0.8 0.0723 0.0011 1.3180 0.0280 0.1317 0.0022 994 35 854 12 798 12 93%
    13 105.9 104.8 1.0 0.0937 0.0051 1.4859 0.0923 0.1134 0.0019 1502 303 925 38 692 11 71%
    14 140.7 340.6 0.4 0.0682 0.0012 1.1962 0.0272 0.1268 0.0023 876 35 799 13 770 13 96%
    15 203.6 205.2 1.0 0.0761 0.0022 1.1787 0.0367 0.1119 0.0017 1098 57 791 17 684 10 85%
    16 62.3 105.8 0.6 0.0685 0.0016 1.1572 0.0295 0.1224 0.0021 887 47 781 14 744 12 95%
    17 181.3 277.1 0.7 0.1159 0.0114 2.4197 0.3064 0.1358 0.0045 1894 178 1248 91 821 26 58%
    18 206.2 288.6 0.7 0.0645 0.0011 1.0831 0.0229 0.1212 0.0014 759 37 745 11 737 8 98%
    19 169.3 170.3 1.0 0.0773 0.0025 1.1857 0.0342 0.1119 0.0014 1128 66 794 16 684 8 85%
    20 237.3 365.0 0.7 0.0747 0.0019 1.2917 0.0393 0.1245 0.0020 1061 50 842 17 757 11 89%
    21 167.6 158.0 1.1 0.0683 0.0016 1.0830 0.0287 0.1147 0.0017 880 48 745 14 700 10 93%
    22 133.3 151.4 0.9 0.0836 0.0023 1.4122 0.0478 0.1222 0.0025 1283 54 894 20 743 14 81%
    23 418.5 337.5 1.2 0.3313 0.0134 7.9555 0.4508 0.1650 0.0046 3623 62 2226 51 984 25 22%
    24 143.4 176.8 0.8 0.0687 0.0014 1.0938 0.0292 0.1149 0.0019 900 39 750 14 701 11 93%
    25 107.8 139.9 0.8 0.1148 0.0071 2.0757 0.1650 0.1246 0.0027 1876 112 1141 54 757 16 59%
    26 99.4 123.3 0.8 0.0916 0.0055 1.4718 0.1291 0.1122 0.0026 1461 113 919 53 686 15 70%
    27 281.1 176.7 1.6 0.0679 0.0017 1.1251 0.0341 0.1196 0.0018 878 53 765 16 728 10 95%
    28 99.5 775.7 0.1 0.0659 0.0008 1.0683 0.0163 0.1174 0.0014 1200 26 738 8 715 8 96%
    29 837.4 523.6 1.6 0.0668 0.0010 1.1139 0.0276 0.1203 0.0022 831 -169 760 13 732 13 96%
    30 126.5 202.7 0.6 0.0658 0.0019 1.1012 0.0444 0.1207 0.0028 1200 61 754 21 735 16 97%
    PM204-7-1
    01 127.9 268.5 0.5 0.0668 0.0008 1.2168 0.0182 0.1321 0.0014 831 26 808 8 800 8 98%
    02 62.7 101.3 0.6 0.0654 0.0011 1.1241 0.0213 0.1249 0.0015 787 36 765 10 759 9 99%
    03 194.4 246.8 0.8 0.0662 0.0009 1.2436 0.0227 0.1365 0.0021 813 30 821 10 825 12 99%
    04 180.5 354.0 0.5 0.1138 0.0011 5.2690 0.0678 0.3356 0.0036 1861 18 1864 11 1865 17 99%
    05 74.2 136.5 0.5 0.0660 0.0010 1.2668 0.0240 0.1392 0.0020 806 30 831 11 840 11 98%
    06 26.0 74.4 0.3 0.0695 0.0016 1.5421 0.0428 0.1616 0.0034 917 49 947 17 966 19 98%
    07 150.7 213.2 0.7 0.0642 0.0011 1.1387 0.0218 0.1290 0.0020 750 32 772 10 782 12 98%
    08 265.5 328.8 0.8 0.0647 0.0009 1.1931 0.0229 0.1338 0.0023 765 25 797 11 810 13 98%
    09 272.2 582.6 0.5 0.0674 0.0008 1.3165 0.0172 0.1415 0.0015 850 25 853 8 853 8 99%
    10 164.0 325.6 0.5 0.0661 0.0012 1.2363 0.0233 0.1362 0.0024 809 38 817 11 823 14 99%
    11 113.2 202.4 0.6 0.0665 0.0010 1.2514 0.0216 0.1361 0.0015 833 32 824 10 823 9 99%
    12 187.5 411.4 0.5 0.0647 0.0008 1.1569 0.0171 0.1295 0.0015 765 26 780 8 785 9 99%
    13 137.4 235.4 0.6 0.0931 0.0028 1.8105 0.0538 0.1408 0.0016 1500 57 1049 19 849 9 78%
    14 71.9 83.2 0.9 0.0659 0.0015 1.2337 0.0332 0.1353 0.0021 1200 48 816 15 818 12 99%
    15 43.6 208.5 0.2 0.0646 0.0012 1.1646 0.0231 0.1305 0.0017 761 240 784 11 791 9 99%
    16 30.8 85.7 0.4 0.0684 0.0016 1.3778 0.0301 0.1467 0.0026 880 47 880 13 883 14 99%
    17 105.8 205.5 0.5 0.0667 0.0011 1.3091 0.0263 0.1420 0.0019 828 37 850 12 856 11 99%
    18 90.7 128.7 0.7 0.0661 0.0012 1.2950 0.0292 0.1421 0.0026 809 42 844 13 857 15 98%
    19 110.0 219.3 0.5 0.0690 0.0030 1.3191 0.0269 0.1435 0.0032 902 89 854 12 864 18 98%
    20 68.2 163.4 0.4 0.0648 0.0012 1.1932 0.0262 0.1339 0.0026 769 37 797 12 810 15 98%
    21 192.7 418.9 0.5 0.0661 0.0011 1.2812 0.0250 0.1407 0.0023 809 33 837 11 848 13 98%
    22 249.9 313.2 0.8 0.0637 0.0011 1.2052 0.0249 0.1377 0.0026 731 35 803 11 831 15 96%
    23 549.4 1329.8 0.4 0.0657 0.0008 1.2254 0.0165 0.1349 0.0012 798 31 812 8 816 7 99%
    24 105.1 186.4 0.6 0.0713 0.0012 1.4299 0.0266 0.1452 0.0017 965 34 902 11 874 10 96%
    25 102.8 146.9 0.7 0.0667 0.0012 1.2439 0.0242 0.1354 0.0022 831 35 821 11 819 12 99%
    26 83.7 212.6 0.4 0.0709 0.0010 1.6568 0.0281 0.1692 0.0023 954 29 992 11 1008 12 98%
    27 620.5 754.1 0.8 0.0663 0.0008 1.2525 0.0188 0.1367 0.0016 817 26 825 9 826 9 99%
    28 130.8 141.1 0.9 0.0668 0.0011 1.2668 0.0239 0.1375 0.0019 831 35 831 11 830 11 99%
    29 52.6 98.4 0.5 0.0641 0.0013 1.1988 0.0283 0.1360 0.0024 744 44 800 13 822 13 97%
    30 161.8 330.2 0.5 0.0631 0.0009 1.1044 0.0190 0.1268 0.0016 722 30 755 9 770 9 98%
    31 53.2 134.1 0.4 0.0842 0.0042 1.9192 0.1328 0.1584 0.0032 1298 96 1088 46 948 18 86%
    32 263.9 371.1 0.7 0.0641 0.0009 1.2087 0.0231 0.1367 0.0016 743 27 805 11 826 9 97%
    33 134.9 263.8 0.5 0.0636 0.0010 1.2116 0.0286 0.1385 0.0025 728 34 806 13 836 14 96%
    34 285.9 487.0 0.6 0.0657 0.0011 1.3146 0.0288 0.1452 0.0019 798 35 852 13 874 11 97%
    35 190.5 195.5 1.0 0.0624 0.0014 1.2595 0.0310 0.1469 0.0021 687 51 828 14 883 12 93%
    36 141.8 399.9 0.4 0.0601 0.0024 1.1876 0.0268 0.1383 0.0024 606 92 795 12 835 14 95%
    37 199.7 282.7 0.7 0.0585 0.0017 1.0921 0.0299 0.1313 0.0022 550 65 750 15 795 13 94%
    38 92.5 162.0 0.6 0.0615 0.0013 1.2143 0.0269 0.1437 0.0020 654 44 807 12 865 11 93%
    39 209.6 407.6 0.5 0.0645 0.0009 1.2910 0.0239 0.1455 0.0025 759 31 842 11 875 14 96%
    40 167.5 269.5 0.6 0.0692 0.0014 1.4451 0.0274 0.1515 0.0017 906 41 908 11 909 9 99%
    41 198.2 383.6 0.5 0.0668 0.0011 1.3376 0.0261 0.1445 0.0015 831 33 862 11 870 8 99%
    42 72.8 430.4 0.2 0.0657 0.0009 1.3458 0.0242 0.1481 0.0020 794 34 866 10 890 11 97%
    43 151.8 196.4 0.8 0.0653 0.0011 1.1940 0.0220 0.1321 0.0019 785 35 798 10 800 11 99%
    44 521.8 746.3 0.7 0.0649 0.0008 1.2113 0.0168 0.1347 0.0015 772 26 806 8 815 8 98%
    45 191.5 376.9 0.5 0.0658 0.0009 1.3021 0.0225 0.1427 0.0019 1200 30 847 10 860 11 98%
    46 55.2 126.5 0.4 0.0703 0.0014 1.3848 0.0309 0.1423 0.0021 1000 42 882 13 858 12 97%
    47 117.0 198.3 0.6 0.0657 0.0012 1.2378 0.0249 0.1365 0.0024 794 33 818 11 825 14 99%
    48 106.0 184.5 0.6 0.0665 0.0012 1.2892 0.0291 0.1399 0.0027 833 38 841 13 844 15 99%
    49 173.7 377.9 0.5 0.0664 0.0011 1.2732 0.0253 0.1384 0.0024 817 34 834 11 835 14 99%
    50 41.9 104.7 0.4 0.0686 0.0016 1.3671 0.0361 0.1441 0.0033 887 81 875 15 868 19 99%
    51 58.4 81.2 0.7 0.0667 0.0017 1.2821 0.0331 0.1396 0.0026 828 54 838 15 842 15 99%
    52 120.2 415.9 0.3 0.0676 0.0010 1.3684 0.0252 0.1466 0.0026 857 27 875 11 882 15 99%
    53 306.6 506.0 0.6 0.0647 0.0009 1.1785 0.0189 0.1317 0.0018 765 29 791 9 797 10 99%
    54 44.4 72.2 0.6 0.1362 0.0037 2.0910 0.0459 0.1132 0.0024 2179 48 1146 15 691 14 50%
    55 167.3 319.5 0.5 0.0658 0.0010 1.2471 0.0241 0.1370 0.0019 1200 31 822 11 828 11 99%
    56 247.1 390.7 0.6 0.0658 0.0011 1.2754 0.0273 0.1405 0.0022 798 37 835 12 848 13 98%
    57 153.5 393.4 0.4 0.0666 0.0011 1.2900 0.0291 0.1405 0.0025 833 34 841 13 848 14 99%
    58 43.3 89.0 0.5 0.0665 0.0015 1.2582 0.0297 0.1378 0.0024 820 45 827 13 832 14 99%
    59 559.0 527.2 1.1 0.0662 0.0009 1.2342 0.0210 0.1350 0.0018 813 27 816 10 816 10 99%
    60 54.7 156.3 0.4 0.0653 0.0011 1.2017 0.0258 0.1331 0.0018 783 36 801 12 806 10 99%
    61 105.5 223.9 0.5 0.0976 0.0105 1.8512 0.2094 0.1333 0.0029 1589 203 1064 75 806 16 72%
    62 44.1 84.4 0.5 0.0678 0.0016 1.2943 0.0322 0.1386 0.0022 865 49 843 14 837 13 99%
    63 35.2 61.8 0.6 0.0700 0.0016 1.4760 0.0411 0.1528 0.0030 929 46 921 17 916 17 99%
    64 116.8 225.1 0.5 0.0686 0.0011 1.3642 0.0304 0.1437 0.0022 887 34 874 13 865 13 99%
    65 256.0 352.1 0.7 0.0657 0.0010 1.2241 0.0266 0.1351 0.0025 796 33 812 12 817 14 99%
    66 127.0 198.4 0.6 0.0706 0.0015 1.3215 0.0300 0.1356 0.0020 946 43 855 13 820 11 95%
    67 426.2 421.8 1.0 0.0666 0.0009 1.1955 0.0209 0.1297 0.0017 828 28 799 10 786 10 98%
    68 69.0 293.6 0.2 0.0652 0.0009 1.2053 0.0190 0.1340 0.0019 789 30 803 9 811 11 99%
    69 140.6 167.1 0.8 0.0672 0.0011 1.2643 0.0214 0.1363 0.0017 843 33 830 10 824 9 99%
    70 70.9 84.5 0.8 0.0664 0.0015 1.2297 0.0300 0.1342 0.0023 818 46 814 14 812 13 99%
    71 116.6 260.1 0.4 0.0672 0.0009 1.3310 0.0217 0.1429 0.0018 856 29 859 9 861 10 99%
    72 145.2 391.2 0.4 0.0644 0.0010 1.1469 0.0204 0.1291 0.0023 754 31 776 10 783 13 99%
    73 222.3 285.5 0.8 0.0698 0.0010 1.3612 0.0250 0.1409 0.0024 924 30 872 11 850 13 97%
    74 84.4 163.3 0.5 0.0681 0.0011 1.3573 0.0239 0.1438 0.0019 872 33 871 10 866 11 99%
    75 170.4 280.6 0.6 0.0643 0.0010 1.1474 0.0182 0.1290 0.0018 752 33 776 9 782 10 99%
    76 120.6 308.7 0.4 0.0646 0.0010 1.1377 0.0203 0.1271 0.0019 761 31 771 10 771 11 99%
    77 145.4 170.5 0.9 0.0678 0.0013 1.2743 0.0309 0.1353 0.0024 861 40 834 14 818 14 98%
    78 216.6 421.3 0.5 0.0658 0.0010 1.2357 0.0211 0.1356 0.0019 798 31 817 10 820 11 99%
    79 67.1 86.1 0.8 0.0663 0.0016 1.2314 0.0309 0.1348 0.0024 817 50 815 14 815 14 99%
    80 98.7 196.5 0.5 0.0676 0.0011 1.3016 0.0252 0.1391 0.0018 857 33 846 11 840 10 99%
    81 78.5 94.1 0.8 0.0671 0.0014 1.2381 0.0271 0.1339 0.0018 840 44 818 12 810 11 99%
    82 175.3 600.9 0.3 0.0673 0.0007 1.3144 0.0204 0.1413 0.0018 856 22 852 9 852 10 99%
    83 171.3 281.1 0.6 0.0653 0.0010 1.1731 0.0207 0.1304 0.0017 783 32 788 10 790 10 99%
    84 33.9 54.4 0.6 0.0673 0.0016 1.2807 0.0323 0.1393 0.0028 856 50 837 14 841 16 99%
    85 84.5 181.3 0.5 0.0667 0.0013 1.3385 0.0304 0.1460 0.0024 828 40 863 13 879 13 98%
    86 212.5 467.8 0.5 0.0672 0.0015 1.2583 0.0249 0.1376 0.0027 856 51 827 11 831 15 99%
    87 180.8 246.5 0.7 0.0640 0.0009 1.1537 0.0223 0.1306 0.0020 743 31 779 11 792 12 98%
    88 70.4 144.4 0.5 0.0626 0.0011 1.0879 0.0215 0.1258 0.0019 694 37 748 10 764 11 97%
    89 306.4 479.9 0.6 0.0659 0.0009 1.2607 0.0199 0.1380 0.0020 806 28 828 9 833 11 99%
    90 132.1 165.8 0.8 0.0659 0.0013 1.2521 0.0271 0.1370 0.0022 803 47 824 12 828 13 99%
    91 309.6 309.0 1.0 0.0904 0.0028 1.1082 0.0280 0.0930 0.0036 1433 59 757 13 573 21 72%
    92 30.4 68.7 0.4 0.0688 0.0020 1.3834 0.0394 0.1452 0.0030 892 61 882 17 874 17 99%
    93 97.9 127.1 0.8 0.0652 0.0015 1.2790 0.0312 0.1410 0.0033 789 50 836 14 850 19 98%
    94 93.6 130.6 0.7 0.0681 0.0016 1.3114 0.0295 0.1381 0.0031 872 44 851 13 834 18 97%
    95 44.7 72.4 0.6 0.0646 0.0016 1.1943 0.0291 0.1336 0.0033 761 52 798 13 808 19 98%
    96 163.6 243.5 0.7 0.0671 0.0013 1.2973 0.0240 0.1392 0.0027 839 -160 845 11 840 15 99%
    97 97.3 129.1 0.8 0.0665 0.0013 1.2614 0.0264 0.1363 0.0026 822 39 829 12 824 15 99%
    98 131.5 204.9 0.6 0.0679 0.0011 1.3254 0.0206 0.1406 0.0022 878 35 857 9 848 13 98%
    99 47.0 76.9 0.6 0.0706 0.0015 1.5126 0.0346 0.1544 0.0027 946 44 936 14 926 15 98%
    100 38.0 89.6 0.4 0.0664 0.0016 1.2074 0.0310 0.1315 0.0024 820 55 804 14 796 14 99%
    101 243.3 200.6 1.2 0.0634 0.0010 1.0963 0.0222 0.1246 0.0018 720 33 752 11 757 11 99%
    PM408-21-1
    01 194.2 178.2 1.1 0.0681 0.0010 1.1341 0.0155 0.1212 0.0013 872 31 770 7 737 8 95%
    02 220.4 150.8 1.5 0.0649 0.0010 1.0976 0.0195 0.1227 0.0015 770 232 752 9 746 9 99%
    03 362.3 477.3 0.8 0.0664 0.0007 1.0785 0.0141 0.1176 0.0011 820 20 743 7 717 6 96%
    04 175.1 106.2 1.6 0.1274 0.0059 1.8149 0.0800 0.1047 0.0012 2063 82 1051 29 642 7 51%
    05 186.4 161.2 1.2 0.0642 0.0011 1.0686 0.0181 0.1210 0.0014 750 32 738 9 736 8 99%
    06 202.4 238.6 0.8 0.0637 0.0008 1.0559 0.0163 0.1201 0.0013 731 31 732 8 731 8 99%
    07 95.4 89.5 1.1 0.0785 0.0034 1.1954 0.0417 0.1127 0.0017 1161 92 798 19 688 10 85%
    08 221.8 154.4 1.4 0.0662 0.0010 1.0859 0.0171 0.1190 0.0011 813 33 747 8 725 6 97%
    09 382.2 320.7 1.2 0.0648 0.0008 1.0704 0.0155 0.1197 0.0013 769 26 739 8 729 8 98%
    10 127.4 103.7 1.2 0.0676 0.0011 1.1567 0.0206 0.1242 0.0012 855 40 780 10 755 7 96%
    11 27.4 37.7 0.7 0.0760 0.0031 1.0284 0.0404 0.0989 0.0014 1094 80 718 20 608 8 83%
    12 364.9 167.0 2.2 0.0643 0.0009 1.0565 0.0149 0.1194 0.0013 750 34 732 7 727 8 99%
    13 75.3 88.9 0.8 0.0630 0.0011 1.0535 0.0199 0.1213 0.0014 709 37 731 10 738 8 98%
    14 256.0 215.2 1.2 0.0647 0.0008 1.0939 0.0154 0.1226 0.0011 765 23 750 7 746 6 99%
    15 257.9 204.0 1.3 0.0638 0.0008 1.0849 0.0186 0.1232 0.0015 744 26 746 9 749 9 99%
    16 267.9 116.6 2.3 0.0651 0.0011 1.1252 0.0215 0.1255 0.0018 789 35 765 10 762 10 99%
    17 372.1 269.4 1.4 0.0648 0.0007 1.1211 0.0178 0.1254 0.0015 769 24 763 9 762 9 99%
    18 236.5 129.4 1.8 0.0638 0.0010 1.0428 0.0196 0.1184 0.0013 744 31 725 10 721 7 99%
    19 376.5 335.5 1.1 0.0661 0.0007 1.1321 0.0147 0.1241 0.0011 809 22 769 7 754 6 98%
    20 197.9 83.4 2.4 0.0645 0.0011 1.0619 0.0201 0.1196 0.0015 767 35 735 10 728 8 99%
    21 1780.5 518.4 3.4 0.0642 0.0006 1.0646 0.0129 0.1202 0.0011 750 20 736 6 732 6 99%
    22 272.0 225.1 1.2 0.0642 0.0008 1.1319 0.0160 0.1278 0.0012 750 26 769 8 775 7 99%
    23 146.6 133.0 1.1 0.0643 0.0010 1.1672 0.0202 0.1318 0.0015 754 31 785 9 798 9 98%
    24 408.6 197.7 2.1 0.0639 0.0009 1.0610 0.0163 0.1205 0.0013 739 30 734 8 734 7 99%
    25 372.4 298.2 1.2 0.0630 0.0007 1.0986 0.0155 0.1264 0.0012 709 24 753 8 768 7 98%
    26 452.6 347.8 1.3 0.0634 0.0007 1.0530 0.0149 0.1205 0.0014 720 22 730 7 734 8 99%
    27 180.5 113.2 1.6 0.0695 0.0011 1.1577 0.0210 0.1210 0.0015 922 33 781 10 737 9 94%
    28 414.9 130.1 3.2 0.0688 0.0013 1.1720 0.0227 0.1237 0.0015 900 38 788 11 752 9 95%
    29 123.2 73.2 1.7 0.0649 0.0013 1.1121 0.0243 0.1243 0.0016 772 44 759 12 755 9 99%
    30 801.3 413.3 1.9 0.0643 0.0006 1.1430 0.0160 0.1287 0.0015 750 19 774 8 780 9 99%
    31 189.2 171.2 1.1 0.0663 0.0011 1.1232 0.0204 0.1228 0.0015 817 34 765 10 747 9 97%
    32 388.3 120.3 3.2 0.0648 0.0012 1.0682 0.0214 0.1192 0.0013 769 37 738 11 726 8 98%
    33 217.2 273.4 0.8 0.0647 0.0008 1.1215 0.0177 0.1256 0.0015 765 23 764 8 763 9 99%
    34 134.1 145.6 0.9 0.0674 0.0010 1.1779 0.0182 0.1265 0.0013 850 30 790 9 768 8 97%
    35 208.9 145.2 1.4 0.0645 0.0010 1.1213 0.0185 0.1261 0.0015 767 33 764 9 765 9 99%
    36 275.2 267.7 1.0 0.0725 0.0017 1.1959 0.0266 0.1197 0.0012 1011 51 799 12 729 7 90%
    37 84.5 61.8 1.4 0.0658 0.0014 1.1497 0.0239 0.1271 0.0015 800 51 777 11 771 9 99%
    38 153.2 115.8 1.3 0.0667 0.0010 1.1858 0.0210 0.1287 0.0015 828 30 794 10 780 9 98%
    39 283.6 407.3 0.7 0.0658 0.0007 1.1783 0.0137 0.1296 0.0011 1200 22 791 6 786 6 99%
    40 332.8 236.4 1.4 0.0655 0.0009 1.1537 0.0185 0.1275 0.0012 791 28 779 9 774 7 99%
    41 430.2 377.8 1.1 0.0640 0.0008 1.1030 0.0139 0.1249 0.0010 743 25 755 7 759 6 99%
    42 128.1 107.7 1.2 0.0678 0.0010 1.2335 0.0175 0.1322 0.0013 861 33 816 8 801 7 98%
    43 225.9 122.8 1.8 0.0682 0.0014 1.1697 0.0269 0.1243 0.0018 876 41 786 13 755 10 95%
    44 331.4 303.4 1.1 0.0660 0.0008 1.2051 0.0193 0.1322 0.0018 807 24 803 9 801 10 99%
    45 127.6 73.8 1.7 0.0811 0.0025 1.4782 0.0570 0.1303 0.0020 1225 60 921 23 790 11 84%
    46 123.5 155.5 0.8 0.0651 0.0010 1.1450 0.0200 0.1275 0.0017 789 31 775 9 774 10 99%
    47 91.2 55.3 1.6 0.0661 0.0015 1.1294 0.0272 0.1240 0.0016 809 48 767 13 753 9 98%
    48 71.0 53.5 1.3 0.0657 0.0015 1.1227 0.0250 0.1245 0.0018 798 53 764 12 756 10 98%
    49 104.9 149.1 0.7 0.0650 0.0009 1.0690 0.0183 0.1189 0.0013 774 228 738 9 724 7 98%
    50 175.1 79.7 2.2 0.0656 0.0013 1.1723 0.0272 0.1295 0.0018 794 41 788 13 785 10 99%
    51 68.1 95.3 0.7 0.0656 0.0011 1.1296 0.0202 0.1248 0.0014 794 31 768 10 758 8 98%
    52 248.1 387.4 0.6 0.0645 0.0006 1.1401 0.0163 0.1279 0.0015 767 25 773 8 776 9 99%
    53 232.1 229.5 1.0 0.0643 0.0008 1.1157 0.0180 0.1255 0.0014 754 32 761 9 762 8 99%
    54 324.7 322.2 1.0 0.0654 0.0007 1.1130 0.0154 0.1233 0.0013 787 22 760 7 749 8 98%
    55 127.2 197.0 0.6 0.0878 0.0026 1.5835 0.0558 0.1296 0.0016 1377 57 964 22 785 9 79%
    56 164.1 130.0 1.3 0.0687 0.0010 1.1801 0.0204 0.1245 0.0013 889 31 791 10 756 8 95%
    57 287.9 418.2 0.7 0.0651 0.0007 1.1206 0.0178 0.1245 0.0016 789 217 763 9 757 9 99%
    58 673.5 602.2 1.1 0.0658 0.0007 1.0741 0.0144 0.1182 0.0013 1200 16 741 7 720 8 97%
    59 227.2 130.0 1.7 0.0649 0.0010 1.1023 0.0186 0.1231 0.0014 772 33 754 9 748 8 99%
    60 136.7 118.0 1.2 0.0654 0.0012 1.1129 0.0199 0.1237 0.0017 789 39 760 10 752 10 98%
    61 445.8 256.4 1.7 0.0651 0.0008 1.1794 0.0185 0.1314 0.0019 789 25 791 9 796 11 99%
    62 205.2 215.7 1.0 0.0646 0.0007 1.1221 0.0162 0.1258 0.0014 761 25 764 8 764 8 99%
    63 224.9 158.9 1.4 0.0632 0.0009 1.0569 0.0165 0.1212 0.0012 722 30 732 8 737 7 99%
    64 327.0 242.9 1.3 0.0646 0.0008 1.1029 0.0166 0.1237 0.0013 761 27 755 8 752 7 99%
    65 55.5 66.0 0.8 0.0640 0.0013 1.1103 0.0254 0.1258 0.0018 743 41 758 12 764 11 99%
    66 57.7 66.5 0.9 0.0660 0.0013 1.1176 0.0245 0.1229 0.0016 806 45 762 12 747 9 98%
    67 395.7 295.2 1.3 0.0648 0.0008 1.1484 0.0162 0.1283 0.0013 769 26 776 8 778 7 99%
    68 172.9 188.9 0.9 0.0632 0.0008 1.1505 0.0209 0.1319 0.0020 717 29 777 10 799 11 97%
    69 311.1 303.3 1.0 0.0643 0.0007 1.1046 0.0140 0.1245 0.0012 754 24 756 7 756 7 99%
    70 172.9 162.6 1.1 0.0638 0.0009 1.0789 0.0162 0.1226 0.0014 744 28 743 8 745 8 99%
    71 298.6 181.8 1.6 0.0658 0.0009 1.1672 0.0187 0.1285 0.0013 800 28 785 9 779 8 99%
    72 847.4 455.1 1.9 0.0710 0.0014 1.2518 0.0272 0.1274 0.0012 967 40 824 12 773 7 93%
    73 208.1 136.3 1.5 0.0685 0.0013 1.0861 0.0242 0.1153 0.0020 883 39 747 12 703 11 94%
    74 340.5 549.4 0.6 0.0638 0.0006 1.0956 0.0144 0.1244 0.0013 744 17 751 7 756 7 99%
    75 106.4 65.7 1.6 0.0645 0.0014 1.0732 0.0240 0.1207 0.0016 767 239 740 12 735 9 99%
    76 350.7 159.2 2.2 0.0643 0.0008 1.1452 0.0204 0.1289 0.0015 750 28 775 10 781 8 99%
    77 618.8 310.4 2.0 0.0655 0.0008 1.1081 0.0166 0.1225 0.0012 791 26 757 8 745 7 98%
    78 497.3 271.2 1.8 0.0653 0.0008 1.1058 0.0142 0.1227 0.0011 783 25 756 7 746 6 98%
    79 326.1 381.2 0.9 0.0000 0.0000 0.8956 0.0556 0.0966 0.0021 error error 649 30 594 12 91%
    80 125.1 96.5 1.3 0.0647 0.0013 1.1100 0.0227 0.1244 0.0014 765 41 758 11 756 8 99%
    注：划横线的数据代表舍弃数据
    下载: 导出CSV

    表 2  南秦岭随州和武当地区武当群测年数据

    Table 2.  Zircon U-Pb ages of Wudang Group of Suizhou and Wudang area in South Qinling Orogen

    地层单位 随州地区 地层单位 武当地区
    岩性 年龄/Ma 资料来源 岩性 年龄/Ma 资料来源
    双台组 702±6 ⑤ 双台组 变质砂岩 755 [3]
    715±6 726±8 [24]
    727±8 726±10
    734±7 变质火山(凝灰)岩 668.4±6.2 [8]
    变质砂岩 720±7 [7] 677.2±3.9
    720±5 680.4±4.6
    722±6 [5] 703.0±7.9 ③
    723.7±4.8 本文 715.0±6.1
    739±4 [23] 750.6±9.7
    734±3 771.2±9.7
    变质火山(凝灰)岩 727±5 727.8±5.7 [11]
    742±6 741.5±5.6
    726.0±5.2 ④ 746±11
    732.9±6.7 本文 705.0±0.5 [10]
    741±7 [6] 706.7±0.1
    711.1±1.6
    763±7 715.2±0.7
    715.6±1.0
    杨坪组 变质砂岩 749±14 本文 716.2±1.1
    749±8 ②
    762±9.9 769±33
    744.0±36 [4]
    755±6 [7] 752 ± 3 [2]
    751 ± 4
    750±5 755 ± 3
    [9] 757 ±2
    755±6 [9] 769 ± 33
    杨坪组 变质砂岩 780 [3]
    注：变质砂岩的年龄取自碎屑锆石最年轻(平均)年龄
    下载: 导出CSV
    • 参考文献(54)
  • [1]

    凌文黎, 程建萍, 王歆华, 等. 武当地区新元古代岩浆岩地球化学特征及其对南秦岭晋宁期区域构造性质的指示[J]. 岩石学报, 2002, 18(1) : 25-36. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200201003.htm

    [2]

    凌文黎, 任邦方, 段瑞春, 等. 南秦岭武当山群、耀岭河群及基性侵入岩群锆石U-Pb同位素年代学及其地质意义[J]. 科学通报, 2007, (12) : 1445-1456. doi: 10.3321/j.issn:0023-074X.2007.12.015

    [3]

    凌文黎, 段瑞春, 柳小明, 等. 南秦岭武当山群碎屑锆石U-Pb年代学及其地质意义[J]. 科学通报, 2010, 55(12) : 1153-1161. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201012012.htm

    [4]

    蔡志勇, 罗洪, 熊小林, 等. 武当群上部变沉积岩组时代归属问题: 单锆石U-Pb年龄的制约[J]. 地层学杂志, 2006, (1) : 60-63. doi: 10.3969/j.issn.0253-4959.2006.01.009

    [5]

    李福林, 李益龙, 周国华, 等. 湖北随州大狼山群片岩中碎屑锆石的U-Pb年龄及其意义[J]. 岩石矿物学杂志, 2010, 29(5) : 488-496. https://www.cnki.com.cn/Article/CJFDTOTAL-YSKW201005004.htm

    [6]

    薛怀民. 扬子克拉通北缘随(州) —枣(阳) 地区新元古代变质岩浆岩的地球化学和SHRIMP锆石U-Pb年代学研究[J]. 岩石学报, 2011, 27(4) : 1116-1130. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201104021.htm

    [7]

    薛怀民, 马芳. 桐柏山造山带南麓随州群变沉积岩中碎屑锆石的年代学及其地质意义[J]. 岩石学报, 2013, 29(2) : 564-580. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201302016.htm

    [8]

    张永清, 张健, 李怀坤, 等. 南秦岭武当山群变质酸性火山岩锆石U-Pb年代学[J]. 地质学报, 2013, 87(7) : 922-930. doi: 10.3969/j.issn.0001-5717.2013.07.002

    [9]

    Yang Z N, Yang K G, Xu Y, et al. Zircon U-Pb geochronology, Hf isotopic composition, and geological implications of the Neoproterozoic meta-sedimentary rocks in Suizhou-Zaoyang area, the northern Yangtze Block[J]. Science China-Earth Sciences, 2015, (11) : 1910-1923.

    [10]

    Wang R R, Xu Z Q, M. Santosh, et al. Middle Neoproterozoic (ca. 705-716 Ma) arc to rift transitional magmatism in the northern margin of the Yangtze Block: Constraints from geochemistry, zircon U-Pb geochronology and Hf isotopes[J]. Journal of Geodynamics, 2017, 109: 59-74. doi: 10.1016/j.jog.2017.07.003

    [11]

    湖北省地质调查院. 中国区域地质志·湖北志[M]. 北京: 地质出版社, 2021.

    [12]

    陈公信, 金经纬. 湖北省岩石地层[M]. 武汉: 中国地质大学出版社, 1996.

    [13]

    李雄伟, 汪国虎. 随南地区武当岩群地层层序[J]. 湖北地矿, 2000, (1) : 3-11. https://www.cnki.com.cn/Article/CJFDTOTAL-HBDK200001000.htm

    [14]

    王宗和. 鄂西北武当山群的划分与对比[J]. 湖北地质, 1989, 3(1) : 17-29. https://www.cnki.com.cn/Article/CJFDTOTAL-HBDK198901002.htm

    [15]

    陈晋镳. 武当山群研究进展[J]. 地质科技通报, 1991, 10: 83-84.

    [16]

    周高, 康维国, 等. 卾北蓝片岩带研究[M]. 北京: 地质出版社, 1991.

    [17]

    周亮亮, 魏均启, 王芳, 等. LA-ICP-MS工作参数优化及在锆石U-Pb定年分析中的应用[J]. 岩矿测试, 2017, 36(4) : 350-359. https://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201704003.htm

    [18]

    Ludwig K R. User's Manual for ISOPLOT 3.00: A Geochronological Toolkit for Microsoft Excel[M]. Berkeley: Berkeley Geochronology Center Special Publication, 2003.

    [19]

    Liu Y S, Hu Z C, Gao S, et al. In situ analysis of major and trace elements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2008, 257: 34-43. doi: 10.1016/j.chemgeo.2008.08.004

    [20]

    Liu Y S, Gao S, Hu Z C, et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons of mantle xenoliths[J]. Journal of Petrology, 2010, 51: 537-571.

    [21]

    Liu Y S, Hu Z C, Zong K Q, et al. . Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LA-ICP-MS[J]. Chinese Sci. Bulletin, 2010, 55: 1535-1546.

    [22]

    郑永飞, 张少兵. 华南前寒武纪大陆地壳的形成和演化[J]. 科学通报, 2007, 52(1) : 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200701000.htm

    [23]

    Yang Y N, Wang X C, Li Q L, et al. Integrated in situ U-Pb age and Hf-O analyses of zircon from Suixian Group in northern Yangtze: New insights into the Neoproterozoic low-δ18O magmas in the South China Block[J]. Precambrian Research, 2016, 273(2016) : 151-164.

    [24]

    Wang L, Griffin W L, Yu J, et al. U-Pb and Lu-Hf isotopes in detrital zircon from Neoproterozoic sedimentary rocks in the northern Yangtze Block: Implications for Precambrian crustal evolution[J]. Gondwana Research, 2013, 23(4) : 1261-1272.

    [25]

    罗郧, 李金发. 武当地块耀岭河群中两类不同性质的酸性火山岩研究[J]. 大地构造与成矿学, 2010, 34(1) : 125-132. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK201001013.htm

    [26]

    邱啸飞, 江拓, 卢山松. 南秦岭随州地区晚新元古代耀岭河群双峰式火山岩的确认及其地质意义[C]//中国矿物岩石地球化学学会第17届学术年会论文摘要集, 2019.

    [27]

    李怀坤, 陆松年, 陈志宏, 等. 南秦岭耀岭河群裂谷型火山岩锆石U-Pb年代学[J]. 地质通报, 2003, 22(10) : 775-781. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=2003010149&flag=1

    [28]

    夏林圻, 夏祖春, 李向民, 等. 南秦岭东段耀岭河群、陨西群、武当山群火山岩和基性岩墙群岩石成因[J]. 西北地质, 2008, (3) : 1-29. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDI200803002.htm

    [29]

    祝禧艳, 陈福坤, 王伟, 等. 豫西地区秦岭造山带武当群火山岩和沉积岩锆石U-Pb年龄[J]. 地球学报, 2008, 29(6) : 817-829. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB200806030.htm

    [30]

    吴年文, 江拓, 徐琼, 等. 南秦岭随枣地块耀岭河组双峰式火山岩: 对扬子克拉通北缘大陆裂解过程的约束[J]. 地质通报, 2021, 40(6) : 920-929. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20210608&flag=1

    [31]

    Tollo R P, Aleinikoff J N, Bartholomew M J, et al. Neoproterozoic A-type granitoids of the central and southern Appalachian: Intraplate magmatism associated with episodic rifting of the Rodinia supercontinent[J]. Precambrian Res., 2004, 128: 3-38.

    [32]

    Xu Y, Du Y, Cawood P A, et al. Detrital zircon provenance of Upper Ordovician and Silurian strata in the northeastern Yangtze Block: Response to orogenesis in South China[J]. Sedimentary Geology, 2012, 267: 63-72.

    [33]

    Yan Y, Hu X, Lin G, et al. Sedimentary provenance of the Hengyang and Mayang basins, SE China, and implications for the Mesozoic topographic change in South China Craton: Evidence from detrital zircon geochronology[J]. Journal of Asian Earth Sciences, 2011, 41(6) : 494-503.

    [34]

    Yao J, Shu L, Santosh M, et al. Geochronology and Hf isotope of detrital zircons from Precambrian sequences in the eastern Jiangnan Orogen: Constraining the assembly of Yangtze and Cathaysia Blocks in South China[J]. Journal of Asian Earth Sciences, 2013, 74: 225-243.

    [35]

    Li H, Jia D, Wu L, et al. Detrital zircon provenance of the Lower Yangtze foreland basin deposits: constraints on the evolution of the early Palaeozoic Wuyi-Yunkai orogenic belt in South China[J]. Geological Magazine, 2013, 150(6) : 959-974.

    [36]

    Duan L, Meng Q, Wu G, et al. Detrital zircon evidence for the linkage of the South China block with Gondwanaland in early Palaeozoic time[J]. Geological Magazine, 2012, 149(6) : 1124-1131.

    [37]

    She Z, Ma C, Wan Y, et al. An Early Mesozoic transcontinental palaeoriver in South China: evidence from detrital zircon U-Pb geochronology and Hf isotopes[J]. Journal of the Geological Society, 2012, 169(3) : 353-362.

    [38]

    Wang W, Zhou M, Yan D, et al. Depositional age, provenance, and tectonic setting of the Neoproterozoic Sibao Group, southeastern Yangtze Block, South China[J]. Precambrian Research, 2012, 192: 107-124.

    [39]

    彭松柏, 李昌年, M Kusky Timothy, 等. 鄂西黄陵背斜南部元古宙庙湾蛇绿岩的发现及其构造意义[J]. 地质通报, 2010, 29(1) : 8-20. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20100102&flag=1

    [40]

    胡正祥, 陈超, 毛新武, 等, 鄂北大洪山晋宁期岛弧火山岩和增生杂岩的厘定及地质意义[J]. 资源环境与工程, 2015, 29(6) : 757-766. https://www.cnki.com.cn/Article/CJFDTOTAL-HBDK201506003.htm

    [41]

    胡正祥, 陈超, 毛新武, 等. 扬子北缘青白口系土门岩组岛弧火山-碎屑岩的定义及意义[J]. 地层学杂志, 2017, 41(3) : 304-317. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201703009.htm

    [42]

    谢纪海, 胡正祥, 毛新武, 等. 鄂北大洪山晋宁期MORB-like玄武岩的识别与洋内俯冲作用[J]. 中国地质, 2019, 46(6) : 1496-1511. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201906017.htm

    [43]

    Peng S, Kusky T M, Jiang X F, et al. Geology, geochemistry, and geochronology of the Miaowan ophiolite, Yangtze craton: Implications for South China's amalgamation history with the Rodinian supercontinent[J]. Gondwana Research, 2012, 21(2/3) : 577-594.

    [44]

    Xu Y, Yang K G, Ali Polat, et al. The ~860 Ma mafic dikes and granitoids from the northern margin of the Yangtze Block, China: A record of oceanic subduction in the early Neoproterozoic[J]. Precambrian Research, 2016, 275: 310-331.

    [45]

    Han Q S, Peng S B, Kusky Timothy, et al. A Paleoproterozoic ophiolitic mélange, Yangtze craton, South China: Evidence for Paleoproterozoic suturing and microcontinent amalgamation[J]. Precambrian Research, 2017, 293: 13-38.

    [46]

    Han Q S, Peng S B, Polat Ali, et al. A ca. 2.1 Ga Andean-type margin built on metasomatized lithosphere in the northern Yangtze craton, China: Evidence from high-Mg basalts and andesites[J]. Precambrian Research, 2018, 309: 309-324.

    [47]

    吴元保, 陈道公, 夏群科, 等. 大别山黄土岭麻粒岩锆石和共生矿物的微量元素分析及其地质意义[J]. 地球化学, 2004, 33(4) : 334-342. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX200404001.htm

    [48]

    陈能松, 刘嵘, 孙敏, 等. 北大别黄土岭长英质麻粒岩的原岩、变质作用及源区热事件年龄的锆石LA-ICPMS U-Pb测年约束[J]. 地球科学—中国地质大学学报, 2006, 31(3) : 294-300. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200603001.htm

    [49]

    郭盼, 陈超, 吴波, 等. 西大别~2.0Ga变质花岗岩的发现及其Hf同位素特征[J]. 中国地质, 2021, 48(4) : 1267-1279. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI202104023.htm

    ①

    湖北地质矿产开发局. 中华人民共和国区域地质调查报告1∶5万安居镇幅、随州市幅、均川幅. 1999.

    ②

    湖北省地质调查院. 中华人民共和国区域地质调查报告1∶25万十堰市幅、襄樊市幅. 2008.

    ③

    湖北省地质调查院. 中华人民共和国区域地质调查报告1∶5万水坪幅、竹山县幅、蔡家坝幅、峪口幅. 2016.

    ④

    湖北省地质调查院. 中华人民共和国区域地质调查报告1∶5万长岗店幅. 均川幅、客店坡幅、古城畈幅、三阳店幅. 2019.

    ⑤

    赵军红. 南秦岭武当群火山-沉积岩地球化学及地质意义. 中国地质大学(武汉), 2018.

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中

图(9)

表(2)

计量
  • 文章访问数:  441
  • PDF下载数:  28
  • 施引文献:  0
出版历程
收稿日期:  2020-07-19
修回日期:  2021-05-20
刊出日期:  2022-12-15

目录

    版权所有：中国地质调查局发展研究中心 copyright @2020
    返回
