Source of ore Forming Materials and Genesis of Zhupogou Gold Deposit in West Qinling Mountains
-
摘要:
猪婆沟金矿位于西秦岭之北秦岭鸳鸯镇–关子镇蛇绿混杂岩带的 反“S”形构造的转折端，金矿体赋存在早古生代李子园群中，矿体的产出受NW向和NE向韧性断裂及其次级构造控制，矿体形态为脉状。矿床热液期主成矿阶段石英中包裹体主要为气液两相包裹体、含子晶三相包裹体。含子晶三相包裹体的冰点温度为−4.8～−4.3℃；气液两相包裹体的冰点温度为−5.3～−0.1℃。该阶段含子晶三相包裹体的均一温度为141.3～198.6℃，平均为160.7℃；气液两相包裹体的均一温度为128.9～285.3℃，平均为174.1℃。成矿流体的均一温度值为130～170℃，峰值范围较宽。流体盐度为1.40～8.28% NaCleqv，平均为5.84% NaCleqv，具有中低温、低盐度特征；石英δ18OH2O值为−3.29‰～4.42 ‰，δD值为−110.1‰～−86.6 ‰，成矿流体来源于原生岩浆水，在岩浆分异成矿的过程中，大气降水的含量逐渐增多。主成矿阶段黄铁矿和毒砂δ34S值为10.7‰～11.5‰，矿物质分别来源于岩浆岩和地层；Pb同位素组成相似，主要来源于造山带铅，有部分上地壳铅和地幔铅加入，成矿物质来源于岩浆岩和地层两个端元，具有多期次特征。综合分析认为，猪婆沟金矿成因类型属沉积变质−岩浆期后热液叠加改造的构造蚀变岩型金矿床。
Abstract:Zhupogou gold deposit is located at the turning end of the anti "s" shaped structure of the Yuanyang town Guanzi town Ophiolitic Melange belt in the north of the West Qinling Mountains. The gold deposit is hosted in the early Paleozoic Liziyuan group. The occurrence of the ore body is controlled by NW and NE trending ductile faults and their secondary structures, and the shape of the ore body is vein. The inclusions in quartz in the main metallogenic stage of the hydrothermal period of the deposit are mainly gas-liquid two-phase inclusions and three-phase inclusions containing daughter crystals. The freezing point temperature range of three-phase inclusions containing daughter crystals is −4.8～−4.3 ℃; The freezing point temperature of gas-liquid two-phase inclusions ranges from −5.3 to −0.1 ℃. At this stage, the homogenization temperature of three-phase inclusions containing daughter crystals is in the range of 141.3～198.6 ℃, with an average of 160.7 ℃; The gas-liquid two-phase inclusions are in the range of 128.9～285.3 ℃, with an average of 174.1 ℃. The homogenization temperature of ore-forming fluid is 130～170 ℃, and the peak range is wide. Fluid salinity is 1.40%～8.28% Nacleqv, average 5.84% NaCleqv. It has the characteristics of medium low temperature and low salinity; quartz δ18OH2O is −3.29‰～4.42‰, δD is −110.1‰～−86.6‰, and the ore-forming fluid comes from primary magma water. In the process of magmatic differentiation and mineralization, the content of atmospheric precipitation gradually increases. Pyrite and arsenopyrite in the main metallogenic stage δ34S value is 10.7‰～11.5‰, and the minerals are derived from magmatic rocks and strata respectively; Pb isotopic composition is similar, mainly from the orogenic belt, with some upper crust lead and mantle lead added. The metallogenic material comes from the two end elements of magmatic rock and stratum. Comprehensive analysis shows that the genetic type of Zhupogou gold deposit belongs to the tectonic altered rock type gold deposit of sedimentary metamorphism post magmatic hydrothermal superimposition.
-
-
表 1 猪婆沟金矿床H–O同位素测试样品采样信息表
Table 1. sampling information of H–O isotope test samples of Zhupogou gold deposit
样品号 成矿阶段 岩石/矿物 矿石类型 采样位置 ZK2702-1 II 石英 蚀变岩型 Ⅰ-2矿体 ZBGB01-2 II 石英 ZBGB03-2 II 石英 ZBGB04-2 II 石英 ZBGB05-2 III 石英 块状硫化物型 Ⅰ-10矿体 ZBGB05-3 III 石英 ZBGB06-2 III 石英 ZBGB06-4 III 石英 ZBGB07-2 III 石英
下载: 导出CSV
表 2 猪婆沟金矿床流体包裹体H–O同位素组成表（‰）
Table 2. H–O isotopic composition of fluid inclusions in Zhupogou gold deposit (‰)
样品号 成矿
阶段岩性 δDV-SMOW δOV-SMOW T（℃） δ18OH2O ZK2702-1 II 石英 −101.7 15.6 208.4 4.42 ZBGB01-2 II 石英 −110.1 13.8 196.9 1.90 ZBGB03-2 II 石英 −102.7 13.1 196.9 1.20 ZBGB04-2 II 石英 −98.1 12.7 196.9 0.80 ZBGB05-2 III 石英 −86.8 13.1 196.9 1.20 ZBGB05-3 III 石英 −95.1 16 196.9 4.10 ZBGB06-2 III 石英 −90.7 11.6 156.7 −3.29 ZBGB06-4 III 石英 −97.9 13 156.7 −1.89 ZBGB07-2 III 石英 −86.6 14 208.4 2.82 注：δ18OH2O为计算值，石英-水：1000ln = δ18O含水矿物−δ18OH2O = 3.38×106T−2−3.4（郑永飞，2000）。
下载: 导出CSV
表 3 猪婆沟金矿床岩矿石及硫化物采样信息和S同位素组成表
Table 3. Sampling information and S isotopic composition of ore and sulfide in Zhupogou gold deposit
样品原号 采样介质 矿物 δ34SV-CDT（‰） ZBGB01-3 二长花岗岩 黄铁矿 10.8 ZBGB03-3 二长花岗岩 黄铁矿 10.9 ZBGB04-1 金矿石 毒砂 11.0 ZBGB05-1 金矿石 毒砂 10.8 ZBGB06-1 金矿石 毒砂 10.7 ZBGB07-1 金矿石 毒砂 11.5 ZBGB01-1 金矿石 毒砂 10.8 ZBGB02-1 金矿石 毒砂 10.8 ZK5303-1 含黄铁矿碳酸盐脉 黄铁矿 4.5
下载: 导出CSV
表 4 猪婆沟金矿床样品采样信息及Pb同位素组成表
Table 4. Lead isotopic composition of Zhubogou gold deposit
样号 阶段/产状 206Pb/204Pb 2σ 207Pb/204Pb 2σ 208Pb/204Pb 2σ 208Pb/206Pb 2σ 207Pb/206Pb 2σ ZBGB01-4 Ⅱ 18.639 0.0007 15.628 0.0006 38.458 0.0017 2.063 0.00004 0.838 0.00001 ZBGB01-4-1 Ⅱ 18.412 0.0008 15.620 0.0008 38.423 0.0022 2.087 0.00005 0.848 0.00002 ZK2702-2-1 Ⅱ 19.657 0.0007 15.717 0.0007 39.403 0.0020 2.004 0.00005 0.800 0.00001 ZK2702-2-2 Ⅱ 19.752 0.0006 15.722 0.0006 39.465 0.0021 1.998 0.00006 0.796 0.00001 ZBGB04-1 Ⅱ 18.190 0.0007 15.596 0.0006 38.282 0.0019 2.104 0.00005 0.857 0.00001 ZBGB06-2 Ⅲ 18.230 0.0008 15.593 0.0008 38.230 0.0025 2.097 0.00007 0.855 0.00002 ZBGB01-1 Ⅲ 18.179 0.0007 15.597 0.0008 38.309 0.0025 2.107 0.00005 0.858 0.00001 Pb-5 毒砂 18.193 0.0007 15.592 0.0008 38.260 0.0024 2.103 0.00006 0.857 0.00002 Pb-3 毒砂 18.198 0.0009 15.594 0.0009 38.266 0.0026 2.103 0.00005 0.857 0.00001 Pb-4 毒砂 18.179 0.0007 15.589 0.0009 38.244 0.0024 2.104 0.00007 0.858 0.00002 注：测试由中国科学院青岛海洋所中心实验室完成，2016。
下载: 导出CSV
表 5 猪婆沟金矿流体包裹体显微测温数据表
Table 5. Micro temperature measurement data of fluid inclusions in Zhupogou gold mine
样号 寄主矿物 观察与测试的包裹体 冰点
T（℃）盐度
（% NaCleqv）完全均一T（℃） 密度（g/cm3） 类型 个数 相比 成矿早阶段（黄铁矿-石英阶段） ZK2702-1 石英 V-L 23 5～20 −20.1～−12.4 16.34～22.44 165.4～268.6 0.894～1.047 V-L-S 5 V5～10;S5～20 −17.4 20.52 148.6～289.4 0.922 成矿主阶段（多金属硫化物-石英阶段） ZBG05-3 石英 V-L 10 5～20 −5.3～−0.1 1.40～8.28 131.2～285.3 0.874～1.012 ZBG06-2 石英 V-L 15 V5～10;S10 −5.2～−0.1 2.41～8.14 128.9～208.1 0.928～1.035 V-L-S 3 5～10 −4.8～−4.3 6.88～7.59 141.3～198.6 0.945～1.034
下载: 导出CSV
-
[1] 白彦祥, 李伟, 郑璇. 猪波沟金矿床成矿规律研究[J]. 大科技, 2018, 2: 151-152
BAI Yanxiang, LI Wei, ZHENG Xuan. Study on metallogenic regularity of Zhubogou gold deposit [J]. Da Science and Technology, 2018, 2: 151-152.
[2] 陈衍景, 张静, 张复新, 等. 西秦岭地区卡林-类卡林型金矿床及其成矿时间、构造背景和模式[J]. 地质论评, 2004, 50(2): 134-152
CHEN Yanjing, ZHANG Jing, ZHANG Fuxin, et al. Carlin like Carlin type gold deposits in the West Qinling Mountains and their metallogenic time, tectonic setting and model [J]. Geological Review, 2004, 50 (2): 134-152.
[3] 冯建忠, 汪东波, 邵世才, 等. 西秦岭小沟里石英脉型金矿床成矿地质特征及成因[J]. 矿床地质, 2002, 21(2): 159-167
FENG Jianzhong, WANG Dongbo, SHAO Shicai, et al. Metallogenic geological characteristics and genesis of XIAOGOULI quartz vein type gold deposit in West Qinling [J]. Deposit Geology, 2002, 21 (2): 159-167.
[4] 郭玲利. 山东某金矿成矿物质来源与矿床成因模式分析[J]. 安徽地质, 2016, 26(3): 194-197
GUO Lingli. Analysis of ore-forming material source and genetic model of a gold deposit in Shandong [J]. Anhui Geology, 2016, 26(3): 194-197.
[5] 胡晓隆, 赵利利. 对北秦岭太阳寺矿集区金矿成矿特征的初步认识[J]. 甘肃地质, 2008, 17(1): 41-46
HU Xiaolong, ZHAO Lili. A preliminary understanding of the metallogenic characteristics of gold deposits in the taiyangsi ore concentration area of the North Qinling Mountains [J]. Gansu Geology, 2008, 17 (1): 41-46.
[6] 洪树炯, 袁万明, 袁二军. 东昆仑热液矿床的流体包裹体特征[J]. 中国矿业, 2020, 29(S02): 241-244
HONG Shujiong, YUAN Wanming, YUAN Erjun. Characteristics of fluid inclusions in hydrothermal deposits in East Kunlun [J]. China Mining, 2020, 29(S02): 241-244.
[7] 洪百雄. 甘肃天水金长沟金矿地质特征与找矿标志[J]. 甘肃科技, 2016, 32(18): 35-39
HONG Baixiong. Geological characteristics and prospecting indicators of Jinchanggou gold deposit in Tianshui, Gansu [J]. Gansu Science and Technology, 2016, 32(18): 35-39.
[8] 李康宁, 张江苏, 徐进, 等. 西秦岭甘南加甘滩金矿床流体包裹体及氢-氧-硫-铅同位素特征[J]. 地质通报, 2023, 42(6): 941−952.
LI Kangning, ZHANG Jiangsu, XU Jin, et al. Fluid inclusions and H-O-S-Pb isotopic characteristics of the Jiagantan gold deposit in Gannan, West Qinling[J]. Geological Bulletin of China, 2023, 42(6): 941−952.
[9] 雷时斌, 齐金忠. 甘肃阳山金矿带地球动力学体制与多因耦合成矿作用[J]. 地质与勘探, 2007, 43(2): 33-39
LEI Shibin, QI Jinzhong. Geodynamic system and polygenetic coupling mineralization in Yangshan gold belt, Gansu Province [J]. Geology and Exploration, 2007, 43 (2): 33-39.
[10] 刘伟. 甘肃天水猪波沟金矿床同位素地球化学特征研究[J]. 矿产与地质, 2020, 34(1): 64-72
LIU Wei. Study on Isotope Geochemical Characteristics of Zhubogou Gold Deposit in Tianshui, Gansu [J]. Minerals and Geology, 2020, 34(1): 64-72.
[11] 齐金忠, 袁士松, 李莉, 等. 甘肃省文县阳山金矿床地质地球化学研究[J]. 矿床地质, 2003, 22(1): 24-31
QI Jinzhong, YUAN Shisong, LI Li, et al. Geological and geochemical study of Yangshan gold deposit in Wen County, Gansu Province [J]. Deposit Geology, 2003, 22 (1): 24-31.
[12] 齐金忠, 李莉, 袁士松, 等. 甘肃省阳山金矿床石英脉中锆石SHRIMP U-Pb年代学研究[J]. 矿床地质, 2005, 24(2): 141-150
QI Jinzhong, LI Li, YUAN Shisong, et al. SHRIMP U-Pb chronology of zircon in quartz vein of Yangshan gold deposit, Gansu Province [J]. Deposit Geology, 2005, 24 (2): 141-150.
[13] 谭文娟, 赵国斌, 魏建设, 等. 黄河流域矿产资源禀赋、分布规律及开发利用潜力[J]. 西北地质, 2023, 56(2): 163−174.
TAN Wenjuan, ZHAO Guobin, WEI Jianshe, et al. Characteristics, Distribution and Utilization Potential of Mineral Resources in the Yellow River Basin[J]. Northwestern Geology, 2023, 56(2): 163−174.
[14] 王洁明, 董苏庆, 雷群英. 陕西金矿成矿规律与找矿靶区圈定[J]. 西北地质, 2023, 56(5): 308-321.
WANG Jieming, DONG Suqing, LEI Qunying. Metallogenic Regularity and Prospecting Target Delineation of Shaanxi Gold Deposit[J]. Northwestern Geology, 2023, 56(5): 308-321.
[15] 吴晓波, 吴军, 李昌寿, 等. 云南大坪金铜铅锌银多金属矿床地球化学特征[J]. 有色矿冶, 2011, 27(4): 6-10 doi: 10.3969/j.issn.1007-967X.2011.04.002
WU Xiaobo, WU Jun, LI Changshou, et al. Geochemical characteristics of Daping gold copper lead zinc silver polymetallic deposit, Yunnan [J]. Nonferrous Metals Mining and Metallurgy, 2011, 27 (4): 6-10. doi: 10.3969/j.issn.1007-967X.2011.04.002
[16] 闫升好, 王安建, 高兰, 等. 大水式金矿床稳定同位素、稀土元素地球化学研究[J]. 矿床地质, 2000, 19(1): 37-45
YAN Shenghao, WANG Anjian, GAO Lan, et al. Geochemistry of stable isotopes and rare earth elements in Dashui type gold deposits [J]. Deposit Geology, 2000, 19 (1): 37-45.
[17] 杨礼敬, 胡晓隆, 许亚玲. 柴家庄金矿成矿模式及找矿方向探讨[J]. 甘肃地质学报, 2004, 13(2): 74-80
YANG Lijing, HU Xiaolong, Xu Yaling. Discussion on metallogenic model and prospecting direction of CHAIJIAZHUANG gold deposit [J]. Gansu Geological Journal, 2004, 13 (2): 74-80.
[18] 袁士松, 李文良, 张勇, 等. 甘肃省文县阳山超大型金矿床成矿作用及成矿模式[J]. 地质与资源, 2008, 17(2): 92-101
YUAN Shisong, LI Wenliang, ZHANG Yong, et al. Mineralization and metallogenic model of Yangshan super large gold deposit in Wen County, Gansu Province [J]. Geology and Resources, 2008, 17 (2): 92-101.
[19] 赵彦庆, 叶得金, 李永琴, 等. 西秦岭大水金矿的花岗岩成矿作用特征[J]. 现代地质, 2003, 017(002): 151-156
ZHAO Yanqing, YE Dejin, LI Yongqin, et al. Characteristics of granite mineralization of Dashui gold deposit in West Qinling [J]. Modern Geology, 2003, 017 (002): 151-156.
[20] 张峻. 甘肃东沟金矿床地质矿化特征及找矿方向[J]. 甘肃地质, 2008, 17(04): 45-50
ZHANG Jun. Geological mineralization characteristics and prospecting direction of Donggou gold deposit in Gansu Province [J]. Gansu Geology, 2008, 17 (04): 45-50.
[21] 张复新, 季军良, 龙灵利, 等. 南秦岭卡林型—似卡林型金矿床综合地质地球化学特征[J]. 地质论评, 2001, 47(5): 492-499
ZHANG Fuxin, JI Junliang, LONG Lingli, et al. Comprehensive geological and geochemical characteristics of Carlin like Carlin type gold deposits in the South Qinling Mountains [J]. Geological Review, 2001, 47 (5): 492-499.
[22] 张复新, 王立社, 侯俊富. 秦岭造山带黑色岩系与金属矿床类型及成矿系列[J]. 中国地质, 2009, 26(3): 694-704 doi: 10.3969/j.issn.1000-3657.2009.03.016
ZHANG Fuxin, WANG Lishe, HOU Junfu. The black rock series and the types and metallogenic series of metal deposits in the Qinling orogenic belt [J]. Chinese Geology, 2009, 26 (3): 694-704. doi: 10.3969/j.issn.1000-3657.2009.03.016
[23] 郑永飞. 稳定同位素地球化学[M]. 北京: 科学出版社, 2000
ZHENG Yongfei. Stable isotope geochemistry [M]. Beijing: Science Press, 2000.
[24] Ohmoto H. Systematics of sulfur and carbon isotopes in hydrothermal ore deposits. Econ. Geol. , 1972, 67: 551~578.
-
