BIOSTRATIGRAPHIC DIVISION AND REGIONAL CORRELATION OF WUFENG FORMATION AND LONGMAXI FORMATION IN JINKECUN SECTION, SOUTHWESTERN MARGIN OF SICHUAN BASIN
-
摘要:
为了探究上扬子海盆在奥陶纪-志留纪之交的沉积环境、明确四川盆地西南缘金坷村筠连地区有机质页岩沉积层位，通过对金坷村剖面五峰组-龙马溪组岩石地层及生物地层的研究，识别出自晚奥陶世凯迪阶WF2带至早志留世埃隆阶LM6带的9个连续生物带及组合.认为金坷村地区是上扬子海盆最早进入前陆期的地区，时间为鲁丹阶LM1期.金坷村剖面与其北部的新地2井、宁211井、威202井生物地层对比发现，自南向北黑色页岩笔石带上限自LM6延伸至LM9，呈逐渐增高的趋势.金坷村剖面富有机质页岩层位于WF2-LM4带，厚度20.6 m，为该地区页岩气勘探开发提供了一定的基础资料.
Abstract:To explore the sedimentary environment of Upper Yangtze Basin at the turn of Ordovician-Silurian period and determine the sedimentary horizon of organic shale in Junlian area on the southwestern margin of Sichuan Basin, nine continuous biozones and combinations from Late Ordovician Katian WF2 zone to Early Silurian Aeronian LM6 zone are identified based on the study of lithostratigraphy and biostratigraphy of Wufeng Formation-Longmaxi Formation in Jinkecun section. It is believed that Jinkecun area is the first to enter the foreland period in the Upper Yangtze Basin, in the time of Rhuddanian LM1 stage. The biostratigraphic correlation between Jinkecun section and XD-2, N-211 and W-202 wells on the north indicates that the upper limit of black shale graptolite zone extends from LM6 to LM9 from south to north, showing a gradually increasing trend. The organic-rich shale in Jinkcun section is located in WF2-LM4 zones with a thickness of 20.6 m, which provides basic data for shale gas exploration and development in the area.
-
-
表 1 区域生物地层划分、沉积厚度及TOC含量对比
Table 1. Regional comparison of biostratigraphy, sedimentary thickness and TOC content
系 统 阶 笔石带 沉积时间/Ma 金坷村剖面（本文） 盐津1井[17] 长宁211井[18] 新地2井[15] 自201井[19] 威202井[20] 沉积厚度/m TOC/% 沉积厚度/m TOC/% 沉积厚度/m TOC/% 沉积厚度/m TOC/% 沉积厚度/m TOC/% 沉积厚度/m TOC/% 志留系 兰多维列统 埃隆阶 LM9 > 25 > 6？ LM8 0.27 33.16 0.55 52.99 0.74 5.64 5.16 2.10 LM7 0.45 > 140 38.57 0.86 40.65 1.31 6.53 4.29 LM6 1.56 1.91 53.50 61.71 1.42 36.53 2.76 3.53 10.52 3.70 鲁丹阶 LM5 0.8 6.80 1.83 12.93 13.53 1.48 2.10 3.94 1.03 5.74 3.30 LM4 0.9 2.00 5.99 12.44 10.24 4.50 9.20 5.85 3.30 4.45 4.90 LM3 0.93 1.20 6.06 4.99 4.25 12.40 3.79 5.14 LM2 0.43 6.00 4.13 3.69 奥陶系 上奥陶统 赫南特阶 LM1 0.6 2.71 6.80 1.07 6.16（？） WF4 0.73 0.40 1.83 0.35 2.63 5.59 9.66 3.51 7.70 7.81 凯迪阶 WF3 1.86 9.40 2.48 8.09 2.32 3.00 WF2 0.6 1.60 2.27 3.51 2.56 0.84 2.10
下载: 导出CSV
-
[1] 邹才能, 董大忠, 王玉满, 等. 中国页岩气特征、挑战及前景(一)[J]. 石油勘探与开发, 2015, 42(6): 689-701. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201602003.htm
Zou C N, Dong D Z, Wang Y M, et al. Shale gas in China: Characteristics, challenges and prospects (I)[J]. Petroleum Exploration and Development, 2015, 42(6): 689-701. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201602003.htm
[2] 郭旭升, 胡东风, 文治东, 等. 四川盆地及周缘下古生界海相页岩气富集高产主控因素——以焦石坝地区五峰组-龙马溪组为例[J]. 中国地质, 2014, 41(3): 893-901. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201403016.htm
Guo X S, Hu D F, Wen Z D, et al. Major factors controlling the accumulation and high productivity in marine shale gas in the Lower Paleozoic of Sichuan Basin and its periphery: A case study of the Wufeng-Longmaxi formation of Jiaoshiba area[J]. Geology in China, 2014, 41(3): 893-901. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201403016.htm
[3] 郭旭升, 胡东风, 魏志红, 等. 涪陵页岩气田的发现与勘探认识[J]. 中国石油勘探, 2016, 21(3): 24-37. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201603003.htm
Guo X S, Hu D F, Wei Z H, et al. Discovery and exploration of Fuling shale gas field[J]. China Petroleum Exploration, 2016, 21(3): 24-37. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201603003.htm
[4] 聂海宽, 金之钧, 马鑫, 等. 四川盆地及邻区上奥陶统五峰组-下志留统龙马溪组底部笔石带及沉积特征[J]. 石油学报, 2017, 38(2): 160-174. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201702004.htm
Nie H K, Jin Z J, Ma X, et al. Graptolites zone and sedimentary characteristics of Upper Ordovician Wufeng Formation-Lower Silurian Longmaxi Formation in Sichuan Basin and its adjacent areas[J]. Acta Petrolei Sinica, 2017, 38(2): 160-174. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201702004.htm
[5] 王玉满, 李新景, 董大忠, 等. 上扬子地区五峰组-龙马溪组优质页岩沉积主控因素[J]. 天然气工业, 2017, 37(4): 9-20. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201704004.htm
Wang Y M, Li X J, Dong D Z, et al. Main factors controlling the sedimentation of high-quality shale in Wufeng-Longmaxi fm, Upper Yangtze region[J]. Natural Gas Industry, 2017, 37(4): 9-20. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201704004.htm
[6] 董大忠, 施振生, 管全中, 等. 四川盆地五峰组-龙马溪组页岩气勘探进展、挑战与前景[J]. 天然气工业, 2018, 38(4): 67-76. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201804013.htm
Dong D Z, Shi Z S, Guan Q Z, et al. Progress, challenges and prospects of shale gas exploration in the Wufeng-Longmaxi reservoirs in the Sichuan Basin[J]. Natural Gas Industry, 2018, 38(4): 67-76. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201804013.htm
[7] 施振生, 王红岩, 林长木, 等. 威远-自贡地区五峰期-龙马溪期古地形及其对页岩储层品质的控制[J]. 地层学杂志, 2020, 44(2): 163-173. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ202002004.htm
Shi Z S, Wang H Y, Lin C M, et al. Paleotopography of Weiyuan-Zigong area in Wufengian-Lungmachian stages (Ordovician-Silurian transition) and its effect on the quality of shale gas reservoir[J]. Journal of Stratigraphy, 2020, 44(2): 163-173. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ202002004.htm
[8] 樊隽轩, Melchin M J, 陈旭, 等. 华南奥陶-志留系龙马溪组黑色笔石页岩的生物地层学[J]. 中国科学: 地球科学, 2012, 42(1): 130-139. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201201015.htm
Fan J X, Melchin M J, Chen X, et al. Biostratigraphy and geography of the Ordovician-Silurian Lungmachi black shales in South China[J]. Science China Earth Sciences, 2011, 54(12): 1854-1863. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201201015.htm
[9] 陈旭, 樊隽轩, 张元动, 等. 五峰组及龙马溪组黑色页岩在扬子覆盖区内的划分与圈定[J]. 地层学杂志, 2015, 39(4): 351-358. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201504001.htm
Chen X, Fan J X, Zhang Y D, et al. Subdivision and delineation of the Wufeng and Lungmachi black shales in the subsurface areas of the Yangtze Platform[J]. Journal of Stratigraphy, 2015, 39(4): 351-358. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201504001.htm
[10] 刘宝珺, 许效松, 潘杏南, 等. 中国南方古大陆沉积地壳演化与成矿[M]. 北京: 科学出版社, 1993: 1-134.
Liu B J, Xu X S, Pan X N, et al. Evolution and mineralization of earth crust of paleocontinent in South China[M]. Beijing: Science Press, 1993: 1-134. (in Chinese)
[11] 刘宝珺, 许效松, 徐强. 扬子东南大陆边缘晚元古代-早古生代层序地层和盆地动力演化(英文)[J]. 岩相古地理, 1995, 5(3): 1-16. https://www.cnki.com.cn/Article/CJFDTOTAL-YXGD503.000.htm
Liu B J, Xu X S, Xu Q. Sequence stratigraphy and basin dynamics of the southeastern margin of the Yangtze Plate in South China during the Late Proterozoic to Early Palaeozoic[J]. Sedimentary Facies and Palaeogeography, 1995, 5(3): 1-16. https://www.cnki.com.cn/Article/CJFDTOTAL-YXGD503.000.htm
[12] 张海全, 许效松, 余谦, 等. 扬子板块西北缘晚奥陶-早志留世岩相古地理演化与烃源岩的关系[J]. 石油天然气学报, 2010, 32(2): 43-47. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX201002012.htm
Zhang H Q, Xu X S, Yu Q, et al. Relationship between lithofacies paleogeographic evolution and source rocks of the Late Ordovician-Early Silurian in northwestern Yangtze Plate[J]. Journal of Oil and Gas Technology, 2010, 32(2): 43-47. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX201002012.htm
[13] 陈清, 樊隽轩, 张琳娜, 等. 下扬子区奥陶纪晚期古地理演变及华南"台-坡-盆"格局的打破[J]. 中国科学: 地球科学, 2018, 48(6): 767-777. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201806009.htm
Chen Q, Fan J X, Zhang L N, et al. Paleogeographic evolution of the Lower Yangtze region and the break of the "platform-slope-basin" pattern during the Late Ordovician[J]. Science China Earth Sciences, 2018, 61(5): 625-636. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201806009.htm
[14] 武学进, 陈清, 李关访, 等. 黔北习科1井五峰组-龙马溪组黑色页岩的地层划分与对比[J]. 地层学杂志, 2020, 44(1): 1-11. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ202001001.htm
Wu X J, Chen Q, Li G F, et al. Stratigraphic subdivision and correlation of the Wufeng and Lungmachi black shales from Xike-1 drillcore in northern Guizhou Province, South China[J]. Journal of Stratigraphy, 2020, 44(1): 1-11. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ202001001.htm
[15] 张娣, 余谦, 陆俊泽, 等. 云南永善-大关地区五峰组-龙马溪组黑色页岩生物地层划分与沉积环境探讨: 以新地2井为例[J]. 地球科学, 2020, 45(3): 739-751. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202003003.htm
Zhang D, Yu Q, Lu J Z, et al. Graptolite biozonation of the Wufeng and Longmaxi formations and its environmental implications from the Xindi 2 borehole in Yongshan-Daguan area, NE Yunnan[J]. Earth Science, 2020, 45(3): 739-751. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202003003.htm
[16] 王红岩, 施振生, 孙莎莎, 等. 四川盆地及周缘志留系龙马溪组一段深层页岩储层特征及其成因[J]. 石油与天然气地质, 2021, 42(1): 66-75. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101007.htm
Wang H Y, Shi Z S, Sun S S, et al. Characterization and genesis of deep shale reservoirs in the first member of the Silurian Longmaxi Formation in southern Sichuan Basin and its periphery[J]. Oil & Gas Geology, 2021, 42(1): 66-75. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101007.htm
[17] 梁峰, 王红岩, 拜文华, 等. 川南地区五峰组-龙马溪组页岩笔石带对比及沉积特征[J]. 天然气工业, 2017, 37(7): 20-26. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201707006.htm
Liang F, Wang H Y, Bai W H, et al. Graptolite correlation and sedimentary characteristics of Wufeng-Longmaxi shale in southern Sichuan Basin[J]. Natural Gas Industry, 2017, 37(7): 20-26. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201707006.htm
[18] 罗超, 王兰生, 石学文, 等. 长宁页岩气田宁211井五峰组-龙马溪组生物地层[J]. 地层学杂志, 2017, 41(2): 142-152. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201702003.htm
Luo C, Wang L S, Shi X W, et al. Biostratigraphy of the Wufeng to Longmaxi formation at well Ning 211 of Changning shale gas field[J]. Journal of Stratigraphy, 2017, 41(2): 142-152. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201702003.htm
[19] 王红岩, 郭伟, 梁峰, 等. 川南自201井区奥陶系-志留系间黑色页岩生物地层[J]. 地层学杂志, 2018, 42(4): 455-460. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201804008.htm
Wang H Y, Guo W, Liang F, et al. Biostratigraphy of Ordovician-Silurian black shale at well Zi 201, South Sichuan[J]. Journal of Stratigraphy, 2018, 42(4): 455-460. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201804008.htm
[20] 王红岩, 郭伟, 梁峰, 等. 四川盆地威远页岩气田五峰组和龙马溪组黑色页岩生物地层特征与意义[J]. 地层学杂志, 2015, 39(3): 289-293. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201503006.htm
Wang H Y, Guo W, Liang F, et al. Biostratigraphy characteristics and scientific meaning of the Wufeng and Longmaxi formation black shales at well Wei 202 of the Weiyuan shale gas field, Sichuan Basin[J]. Journal of Stratigraphy, 2015, 39(3): 289-293. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201503006.htm
[21] 张先进, 彭松柏, 李华亮, 等. 峡东地区的"三峡奇石"——沉积结核[J]. 地质论评, 2013, 59(4): 627-636. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201304006.htm
Zhang X J, Peng S B, Li H L, et al. "Three Gorges landscape stones": The sedimentary concretion in eastern Three Gorges area[J]. Geological Review, 2013, 59(4): 627-636. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201304006.htm
[22] 庞谦, 李凌, 胡广, 等. 川北地区下寒武统筇竹寺组钙质结核特征及成因机制[J]. 沉积学报, 2017, 35(4): 681-690. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201704003.htm
Pang Q, Li L, Hu G, et al. Characteristics and genetic mechanism of calcareous concretions in the Early Cambrian Qiongzhusi Formation of northern Sichuan Basin[J]. Acta Sedimentologica Sinica, 2017, 35(4): 681-690. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201704003.htm
[23] Mozley P S, Burns S J. Oxygen and carbon isotopic composition of marine carbonate concretions: An overview[J]. Journal of Sedimentary Research, 1993, 63(1): 73-83.
[24] 王玉满, 李新景, 王浩, 等. 四川盆地下志留统龙马溪组结核体发育特征及其沉积环境意义[J]. 天然气工业, 2019, 39(10): 10-21. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201910002.htm
Wang Y M, Li X J, Wang H, et al. Development characteristics of concretions in the Longmaxi Formation of Lower Silurian in the Sichuan Basin and the indicating significance of their depositional environment[J]. Natural Gas Industry, 2019, 39(10): 10-21. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201910002.htm
[25] 张琳娜, 樊隽轩, 陈清. 华南上奥陶统观音桥层的空间分布和古地理重建[J]. 科学通报, 2016, 61(18): 2053-2063. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201618009.htm
Zhang L N, Fan J X, Chen Q. Geographic distribution and palaeogeographic reconstruction of the Upper Ordovician Kuanyinchiao Bed in South China[J]. Chinese Science Bulletin, 2016, 61(18): 2053-2063. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201618009.htm
[26] 张海全, 许效松, 刘伟, 等. 中上扬子地区晚奥陶世-早志留世岩相古地理演化与黑色页岩的关系[J]. 沉积与特提斯地质, 2013, 33(2): 17-24. https://www.cnki.com.cn/Article/CJFDTOTAL-TTSD201302003.htm
Zhang H Q, Xu X S, Liu W, et al. Late Ordovician-Early Silurian sedimentary facies and palaeogeographic evolution and its bearings on the black shales in the Middle-Upper Yangtze area[J]. Sedimentary Geology and Tethyan Geology, 2013, 33(2): 17-24. https://www.cnki.com.cn/Article/CJFDTOTAL-TTSD201302003.htm
[27] 陈旭, 戎嘉余, 周志毅, 等. 上扬子区奥陶-志留纪之交的黔中隆起和宜昌上升[J]. 科学通报, 2001, 46(12): 1052-1056. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200112020.htm
Chen X, Rong J Y, Zhou Z Y, et al. The central Guizhou and Yichang uplifts, upper Yangtze Region, between Ordovician and Silurian[J]. Chinese Science Bulletin, 2001, 46(18): 1580-1584. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200112020.htm
[28] Schieber J. Mud re-distribution in epicontinental basins-Exploring likely processes[J]. Marine and Petroleum Geology, 2016, 71: 119-133.
[29] Kump L R, Arthur M A. Interpreting carbon-isotope excursions: Carbonates and organic matter[J]. Chemical Geology, 1999, 161(1/3): 181-198.
[30] 陈旭, 樊隽轩, 王文卉, 等. 黔渝地区志留系龙马溪组黑色笔石页岩的阶段性渐进展布模式[J]. 中国科学: 地球科学, 2017, 47(6): 720-732. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201706005.htm
Chen X. Fan J X, Wang W H, et al. Stage-progressive distribution pattern of the Lungmachi black graptolitic shales from Guizhou to Chongqing, Central China[J]. Science China Earth Sciences, 2017, 60(6): 1133-1146. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201706005.htm
-
