A Study on Hydrocarbon Generation Capacity of Graptolite in Marine Hydrocarbon Source Rocks in Southern China
-
摘要: 我国南方海相页岩中普遍发育的笔石与海相页岩气成因具有密切的关系，但笔石是否具有页岩气生烃能力，一直未有可靠的、直接的相关实验证实。本文通过采集笔石含量丰富的黑色页岩，手工挑选纯笔石样品并进行热解生烃模拟实验研究，证实了笔石页岩中的笔石是一种较好的生烃母质。笔石样品的碳含量较高，贡献了笔石页岩的大部分碳来源。达到生油高峰后的笔石热解生烃产物主要为天然气-轻质油，这两部分生烃产物占总生烃产物的94%以上，且其中的气态烃占总烃比例达到了54%左右。分析认为，笔石的热解生烃特征介于Ⅲ型有机质和Ⅱ型有机质之间，近似于Ⅲ型有机质生烃特征，以气态烃产物为主。由此推论，在笔石热成熟演化过程中，其有机质生烃能力可能更高，与目前南方广泛发育页岩气的成因息息相关。Abstract: The common development of graptolite in marine shale of Southern China has a close relationship with the formation of marine shale gas, but whether graptolite has hydrocarbon generating ability of shale gas has not been directly confirmed by relevant experiments. In this study, pure graptolite from black graptolite shale was selected and the graptolite sample was hand-picked for the experimental study on pyrolysis hydrocarbon generation. The results show that the graptolite is a good parent material. The carbon content of the graptolite is high, accounting for most carbon sources of graptolite shale. The main products of pyrolysis hydrocarbon generation are shale gas and light oil, which accounts for more than 94% of the total hydrocarbon generation products, whereas the shale gas accounts for 54%. The pyrolysis product is similar to that between type-Ⅲ organic matter (OM) and type-Ⅱ OM is more similar to that of type-Ⅲ OM, which is mainly gaseous hydrocarbon products. The hydrocarbon generation ability of graptolite may be higher during thermal maturation process, which is closely related to the genesis of widespread shale gas in Southern China at present.
-
-
表 1 笔石页岩及笔石体样品热解分析结果
Table 1. The pyrolysis results of graptolite shale and graptolite samples
样品编号 岩性 地质年代 S1
(mg/g)S2
(mg/g)Tmax
(℃)TOC
(%)HI
(mg/g TOC)OI MB-2(全岩) 黑色泥岩 O3w 0.54 1.77 455 3.04 58 8 MB-3(全岩) 黑色泥岩 S1l 0.69 2.88 458 3.88 74 5 MB-2(笔石) 笔石 O3w 6.55 31.71 464 42.93 74 43 MB-3(笔石) 笔石 S1l 15.18 60.36 456 71.34 85 2
下载: 导出CSV
表 2 典型不同有机质类型样品基本地球化学参数
Table 2. The basic geochemical parameters of typical organic matter samples
样品编号 样品 层位 S2
(mg/g)TOC
(%)HI
(mg/g TOC)Tmax
(℃)有机质类型 Ro
(%)GRS 绿河页岩 E 183.21 20.55 892 447 Ⅰ 0.67 JS1 禄劝泥灰岩 D2 3.4 0.8 425 439 Ⅱ1 0.59 GY 广元黑色页岩 P2 45.15 11.74 385 435 Ⅱ2 0.56 YD 贵州鱼洞煤样 P2 142.2 60.94 233 439 Ⅲ 0.71
下载: 导出CSV
表 3 典型不同有机质类型样品生烃产率分析结果
Table 3. The analysis results of hydrocarbon generating yield of typical organic matter samples
样品编号 C1 C2~C4 C5~C14 C15+ 总烃(CT) 百分比
(%)生烃产率
(mg/g岩石)百分比
(%)生烃产率
(mg/g岩石)百分比
(%)生烃产率
(mg/g岩石)百分比
(%)生烃产率
(mg/g岩石)百分比
(%)生烃产率
(mg/g岩石)GRS 15.35 8.38 27.01 14.74 111.49 60.85 29.36 16.03 183.21 100 JS1 0.40 11.68 0.61 17.99 1.88 55.25 0.51 15.08 3.40 100 GY 9.58 21.22 9.35 20.71 21.16 46.87 3.80 8.41 45.15 100 YD 55.58 39.08 24.67 17.35 44.16 31.05 13.66 9.61 142.20 100
下载: 导出CSV
-
[1] 邹才能, 董大忠, 王社教, 等.中国页岩气形成机理、地质特征及资源潜力[J].石油勘探与开发, 2010, 37(6):641-653. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201006003.htm
Zou C N, Dong D Z, Wang S J, et al.Geological characteristics, formation mechanism and resource potential of shale gas in China[J].Petroleum Exploration and Development, 2010, 37(6):641-653. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201006003.htm
[2] 张金川, 聂海宽, 徐波, 等.四川盆地页岩气成藏地质条件[J].天然气工业, 2008, 28(2):151-156. http://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200802057.htm
Zhang J C, Nie H K, Xu B, et al.Geological condition of shale gas accumulation in Sichuan basin[J].Natural Gas Industry, 2008, 28(2):151-156. http://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200802057.htm
[3] 郭彤楼, 刘若冰.复杂构造区高演化程度海相页岩气勘探突破的启示——以四川盆地东部盆缘JY1井为例[J].天然气地球科学, 2013, 24(4):643-651. http://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201304000.htm
Guo T L, Liu R B.Implications from marine shale gas exploration breakthrough in complicated structural area at high thermal stage:Taking Longmaxi Formation in Well JY1 as an example[J].Natural Gas Geoscience, 2013, 24(4):643-651. http://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201304000.htm
[4] 郭彤楼, 张汉荣.四川盆地焦石坝页岩气田形成与富集高产模式[J].石油勘探与开发, 2014, 41(1):28-36. doi: 10.11698/PED.2014.01.03
Guo T L, Zhang H R.Formation and enrichment mode of Jiaoshiba shale gas field, Sichuan basin[J].Petroleum Exploration and Development, 2014, 41(1):28-36. doi: 10.11698/PED.2014.01.03
[5] 魏志红.富有机质页岩有机质孔发育差异性探讨——以四川盆地五峰组-龙马溪组笔石页岩为例[J].成都理工大学学报(自然科学版), 2015, 42(3):361-365. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG201503013.htm
Wei Z H.Difference of organic pores in organic matter:A case from graptolite shales of Wufeng Formation-Longmaxi Formation in Sichuan basin, China[J].Journal of Chengdu University of Technology (Science & Technology Edition), 2015, 42(3):361-365. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG201503013.htm
[6] 樊隽轩, Melchin M J, 陈旭, 等.华南奥陶-志留系龙马溪组黑色笔石页岩的生物地层学[J].中国科学(地球科学), 2012, 42(1):130-139. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201201015.htm
Fan J X, Melchin M J, Chen X, et al.Biostratigraphy and geography of the Ordovician-Silurian Lungmachi black shales in South China[J].Scientia Sinica Terrae, 2012, 42(1):130-139. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201201015.htm
[7] 张元动, 陈旭, Goldman D, 等.华南早-中奥陶世主要环境下笔石动物的多样性与生物地理分布[J].中国科学(地球科学), 2010, 40(9):1164-1180. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201009008.htm
Zhang Y D, Chen X, Goldman D, et al.Diversity and paleobiogeographic distribution patterns of early and middle ordovician graptolites in distinct depositional environments of South China[J].Scientia Sinica Terrae, 2010, 40(9):1164-1180. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201009008.htm
[8] 苏文博, 李志明, Ettensohn F R, 等.华南五峰组-龙马溪组黑色岩系时空展布的主控因素及其启示[J].地球科学——中国地质大学学报, 2007, 32(6):819-827. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200706014.htm
Su W B, Li Z M, Ettensohn F R, et al.Distribution of black shale in the Wufeng-Longmaxi Formations (Ordovician-Silurian), South China:Major controlling factors and implications[J].Earth Science-Journal of China University of Geosciences, 2007, 32(6):819-827. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200706014.htm
[9] 王秀平, 牟传龙, 葛详英, 等.川南及邻区龙马溪组黑色岩系矿物组分特征及评价[J].石油学报, 2015, 36(2):150-162. doi: 10.7623/syxb201502003
Wang X P, Mou C L, Ge X Y, et al.Mineral component characteristics and evaluation of black rock series of Longmaxi Formation in southern Sichuan and its periphery[J].Acta Petrolei Sinica, 2015, 36(2):150-162. doi: 10.7623/syxb201502003
[10] 王淑芳, 董大忠, 王玉满, 等.四川盆地志留系龙马溪组富气页岩地球化学特征及沉积环境[J].矿物岩石地球化学通报, 2015, 34(6):1203-1212. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201506017.htm
Wang S F, Dong D Z, Wang Y M, et al.Geochemical characteristics the sedimentation environment of the gas-enriched shale in the Silurian Longmaxi Formation in the Sichuan basin[J].Bulletin of Mineralogy, Petrology and Geochemistry, 2015, 34(6):1203-1212. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201506017.htm
[11] 林彤, 雍自权, 刘树根, 等.川东南石林地区五峰组-龙马溪组黑色页岩特征[J].东北石油大学学报, 2015, 39(3):83-93. http://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201503012.htm
Lin T, Yong Z Q, Liu S G, et al.Basic characteristics of shale of Wufeng-Longmaxi Formation in Shilin, southeast of Sichuan basin[J].Journal of Northeast Petroleum University, 2015, 39(3):83-93. http://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201503012.htm
[12] 郭秀梅, 王剑, 杨宇宁, 等.渝东北地区五峰组-龙马溪组黑色页岩储层特征[J].沉积与特提斯地质, 2015(2):54-59. http://cdmd.cnki.com.cn/Article/CDMD-10616-1013288912.htm
Guo X M, Wang J, Yang Y N, et al.Black shale reservoirs from the Wufeng and Longmaxi Formations in northeastern Chongqing[J].Sedimentary Geology and Tethyan Geology, 2015(2):54-59. http://cdmd.cnki.com.cn/Article/CDMD-10616-1013288912.htm
[13] 刘树根, 王世玉, 孙玮, 等.四川盆地及其周缘五峰组-龙马溪组黑色页岩特征[J].成都理工大学学报(自然科学版), 2013, 40(6):621-639. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG201306002.htm
Liu S G, Wang S Y, Sun W, et al.Characteristics of black shale in Wufeng Formation and Longmaxi Formation in Sichuan basin and its peripheral areas[J].Journal of Chengdu University of Technology (Science & Technology Edition), 2013, 40(6):621-639. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG201306002.htm
[14] 刘大锰, 侯孝强, 蒋金鹏.笔石组成与结构的微区分析[J].矿物学报, 1996, 16(1):53-57. http://www.cnki.com.cn/Article/CJFDTOTAL-KWXB199601008.htm
Liu D M, Hou X Q, Jiang J P.The composition and structure of graptolite-A micro-area analysis[J].Acta Mineralogica Sinica, 1996, 16(1):53-57. http://www.cnki.com.cn/Article/CJFDTOTAL-KWXB199601008.htm
[15] 马施民, 邹晓艳, 朱炎铭, 等.川南龙马溪组笔石类生物与页岩气成因相关性研究[J].煤炭科学技术, 2015, 43(4):106-109. http://www.cnki.com.cn/Article/CJFDTOTAL-MTKJ201504025.htm
Ma S M, Zou X Y, Zhu Y M, et al.Study on relationship between graptolite and shale gas origin of Longmaxi Formation in southern Sichuan[J].Coal Science and Technology, 2015, 43(4):106-109. http://www.cnki.com.cn/Article/CJFDTOTAL-MTKJ201504025.htm
[16] 戴娜, 钟宁宁, 张瑜, 等.氩离子抛光/扫描电镜分析方法在笔石有机质研究中的应用[J].电子显微学报, 2015, 34(5):416-420. http://www.cnki.com.cn/Article/CJFDTOTAL-DZXV201505011.htm
Dai N, Zhong N N, Zhang Y, et al.Ar ion milling/SEM analysis on graptolitinite macerals[J].Journal of Chinese Electron Microscopy Society, 2015, 34(5):416-420. http://www.cnki.com.cn/Article/CJFDTOTAL-DZXV201505011.htm
[17] 贝思D E B, 柯克N H, 赵宇虹, 等.利用扫描电子显微镜对笔石超微构造的研究[J].古生物学报, 1988, 27(5):527-535. http://www.cnki.com.cn/Article/CJFDTOTAL-GSWX198805000.htm
Bates D E B, Kirk N H, Zhao Y H, et al.Ultra structural studies on graptolites using scanning electron microscope[J].Acta Palaeontologica Sinica, 1988, 27(5):527-535. http://www.cnki.com.cn/Article/CJFDTOTAL-GSWX198805000.htm
[18] 汤庆艳, 张铭杰, 张同伟, 等.生烃热模拟实验方法述评[J].西南石油大学学报(自然科学版), 2013, 35(1):52-62. http://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201301006.htm
Tang Q Y, Zhang M J, Zhang T W, et al.A review on pyrolysis experimentation on hydrocarbon generation[J].Journal of Southwest Petroleum University (Science & Technology Edition), 2013, 35(1):52-62. http://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201301006.htm
[19] 胡国艺, 李志生, 罗霞, 等.两种热模拟体系下有机质生气特征对比[J].沉积学报, 2004, 22(4):718-723. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200404025.htm
Hu G Y, Li Z S, Luo X, et al.The comparison of gas generation potential and model between two different thermal simulation systems[J].Acta Sedimentologica Sinica, 2004, 22(4):718-723. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200404025.htm
[20] 史基安, 王琪, 赵欣.不同类型烃源岩气态烃的生成特征研究——来自差热-色谱联机热模拟实验方法的证据[J].沉积学报, 1999, 17(2):136-140. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB902.022.htm
Shi J A, Wang Q, Zhao X.Study on the generation characteristics of gaseous hydrocarbons from different types of hydrocarbon source rocks-Evidence from the method of on-line thermal simulation of differential heat gas chromatography[J].Acta Sedimentologica Sinica, 1999, 17(2):136-140. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB902.022.htm
[21] Espitali J, Ungerer P, Irwin I, et al.Primary cracking of kerogens.Experimenting and modelling C1, C2-C5, C6-C15 and C15+ classes of hydrocarbons formed[J].Organic Geochemistry, 1988, 13(4):893-899. http://www.sciencedirect.com/science/article/pii/0146638088902434
[22] Mackenzie A S, Quigley T M.Principles of geochemical prospect appraisal[J].AAPG Bulletin, 1988, 72(4):399-415. https://www.researchgate.net/publication/255928198_Principles_of_geochemical_prospect_appraisal
[23] Horsfield B.Practical criteria for classifying kerogens:Some observations from pyrolysis-gas chromatography[J].Geochimica et Cosmochimica Acta, 1989, 53(4):891-901. doi: 10.1016/0016-7037(89)90033-1
[24] 钱门辉, 侯读杰, 蒋启贵, 等.西湖凹陷煤系烃源岩显微组分组成特征及地质意义[J].石油实验地质, 2012, 34(2):182-185. doi: 10.11781/sysydz201202182
Qian M H, Hou D J, Jiang Q G, et al.Features and geologic significance of maceral composition of coal-bearing source rocks in Xihu sag[J].Petroleum Geology and Experiment, 2012, 34(2):182-185. doi: 10.11781/sysydz201202182
-
