Study on Ablation Behaviors and Ablation Rates of a 193nm ArF Excimer Laser System for Selected Substrates in LA-ICP-MS Analysis
-
摘要: 探究LA-ICP-MS分析中不同基体的剥蚀行为和剥蚀速率，可为激光参数设定、基体匹配选择、数据质量保证等方面提供重要参考。本文研究了193 nm ArF准分子激光系统对人工合成/地质样品玻璃、常见矿物和粉末压片的剥蚀行为，同时探究了激光参数（束斑直径、能量密度和剥蚀频率）对剥蚀速率的影响情况。从剥蚀坑形貌可知，193nm ArF激光对玻璃和绝大多数矿物的剥蚀行为良好，但对石英相对较差，这可能与石英内含有微观包裹体，剥蚀过程中局部受热不均有关。粉末压片的剥蚀行为呈现出不可控，可通过提高粉末压片的压制压力或降低粉末颗粒的粒径来改善剥蚀行为；当剥蚀深度大于1.5倍束斑直径时，剥蚀速率随剥蚀深度的增加而逐渐减小，剥蚀深度最多可达束斑直径的两倍左右（RESOlution M-50型号激光系统，3.0 J/cm2激光能量密度）；剥蚀速率随激光能量密度的增加而增大，但基本不受剥蚀频率（2~20 Hz）影响。不同基体具有特征的剥蚀速率，本文报道了43种基体的剥蚀速率参数，总体而言，NIST系列玻璃的剥蚀速率大于地质样品玻璃，碳酸盐矿物和硫化物矿物大于硅酸岩矿物，粉末压片大于玻璃和常见矿物。
-
关键词:
- LA-ICP-MS /
- 193nm ArF激光 /
- 剥蚀行为 /
- 剥蚀速率 /
- 能量密度
Abstract: Understanding laser ablation behaviors of different target materials is essential for optimum laser parameters, external reference materials selection, as well as for data quality assurance. In this study, ablation behaviors of a 193nm ArF excimer laser for silicate glasses, common minerals, and powder pellets were investigated. Ablation rates influenced by laser parameters (including spot size, energy density, and laser frequency) were evaluated. Topographic images of craters generated during ablation illustrate that glasses and most minerals have controllable ablation behaviors, except for quartz. The worse ablation behavior of quartz may be ascribed to the micro-fluid inclusions, which could result in the overheating effect in laser pits. In general, powder pellets have worse ablation behaviors, but the increase of tableting pressure or reducing the particle grain size could improve the ablation behaviors. Ablation rates gradually decrease if the ablation depth is larger than 1.5 times of the spot size. The maximum ablation depth can reach twice the spot size when the energy density is 3.0 J/cm2 for the RESOlution M-50 laser system). Ablation rates increase with the increase of laser energy density, but ablation rates are not affected by the laser frequency (2-20 Hz). Ablation rates are specific to the individual substrates. In conclusion, the ablation rate data of 43 substrates, in which ablation rates of powder pellets are larger than glasses and minerals, whereas those of carbonates and sulfides are larger than silicate minerals, and those of NIST glasses are larger than geological glasses.-
Key words:
- LA-ICP-MS /
- 193nm ArF excimer laser /
- ablation behavior /
- ablation rate /
- energy density
-
-
图 2 NIST610、BCR-2G、磷灰石、黄铁矿、石英、MACS-3、GBW01730和PB40-1的剥蚀坑三维形貌图(激光能量密度为5.0 J/cm2，束斑直径为75 μm)
Figure 2.
图 4 剥蚀速率随激光能量密度和剥蚀频率的变化情况。能量密度实验是在设定激光频率5 Hz、束斑直径75 μm、剥蚀时间20 s等固定参数下，通过改变能量密度来进行；剥蚀频率实验是在设定能量密度为4.2 J/cm2、束斑直径75 μm、150激光脉冲等固定参数下，通过改变剥蚀频率来进行
Figure 4.
图 5 43种基体的激光剥蚀速率。激光能量为2.0 J/cm2(石英除外，为5.0 J/cm2)，每个点重复三次以上，图中的误差棒为深度测量的一倍标准偏差
Figure 5.
表 1 LA-ICP-MS仪器工作参数
Table 1. Operation conditions of LA-ICP-MS system
激光剥蚀系统 电感耦合等离子体质谱 激光类型 RESOlution M-50 ArF准分子 ICP-MS Element 2 波长 193 nm RF功率 1500 W 脉冲时间 20 ns 屏蔽圈(Pt) 悬浮 能量密度 1.0~11.0 J/cm2 冷却气(Ar)流量 15.00 L/min 激光频率 2~20 Hz 辅助气(Ar)流量 1.00 L/min 剥蚀池 Laurin Technic S-155 载气(Ar)流量 0.95 L/min 激光束斑直径 10~90 μm 停留时间 10 ms 剥蚀气(He)流量 0.65 L/min 检测器 计数与模拟 剥蚀时间 20~120 s 分辨率 低(~300)
下载: 导出CSV
-
