Determination of Sulfur in Soil by Inductively Coupled Plasma-Optical Emission Spectrometry with Four Acids Open Dissolution
-
摘要: 当前土壤中硫元素的测定方法主要是X射线荧光光谱法和燃烧法，上述两种方法分析速度慢，对高、低含量样品的分析精度较差，难以满足大批量样品快速、准确分析的要求。为提高分析速度和结果的准确度，本文建立了用盐酸-硝酸-氢氟酸-高氯酸（四酸）溶解土壤样品，电感耦合离子体发射光谱法测定硫的方法。通过考察王水消解、王水水浴消解和四酸消解的溶样效果，测定结果表明采用四酸能更好地溶解土壤样品中的硫。方法检出限为10 μg/g，测量范围为33.3~50000 μg/g，相对标准偏差为0.47%~4.05%。本方法简单快速，准确度高，已经过数千件实际样品验证，在不增加分析成本的情况下，一份溶液还可以同时测定钾钠钙镁铁锰铍锂镧铈钪钒钴镍钛等元素，适合在地质行业推广应用。
-
关键词:
- 电感耦合等离子体发射光谱法 /
- 土壤 /
- 硫 /
- 敞口酸溶
Abstract: At present, sulfur in soil is mainly determined by X-ray Fluorescence Spectrometry and tube furnace combustion iodine methods. The analysis speed of these two methods is slow, and the analysis accuracy is poor for both high and low content samples, difficult to meet the requirements of accurate and rapid determination of many samples. In order to improve the speed and accuracy of analysis, a new method for the determination of sulfur in soil samples by Inductively Coupled Plasma-Optical Emission Spectrometry combined with four acids digestion was developed. In this paper the digestion effect of aqua regia, aqua hot water bath and HCl-HNO3-HF-HClO4 is compared. The four acids digestion method was proven to better dissolve sulfur in soil samples. The method is simple, rapid and accurate with a low detection limit of 10 μg/g, analysis range between 33.3 μg/g and 50000 μg/g, and relative standard deviation between 0.47% and 4.05%. Many elements such as potassium, sodium, calcium, magnesium, iron, manganese, beryllium, lithium, lanthanum, cerium, scandium, vanadium, cobalt, nickel, and titanium can be determined simultaneously in a solution without increasing analysis cost. The method, which has been verified with actual samples, is suitable for application in the geological industry. -
-
表 1 四酸、王水、王水水浴溶解结果
Table 1. Analytical results of samples disoluted with four acids, aqua regia and aqua waterbath methods
标准物质编号 硫含量(μg/g) 三种溶解方法测定值与标准值的相对误差(%) 标准值 四酸溶解测定值 王水溶解测定值 王水水浴溶解测定值 四酸溶解 王水溶解 王水水浴溶解 GBW07446 108±14 112 99 103 3.70 -8.33 -4.63 GBW07451 440±42 436 390 410 -0.91 -11.36 -6.82 GBW07456 254±12 257 238 246 1.18 -6.30 -3.15 GBW07457 281±26 279 203 214 -0.71 -27.76 -23.84
下载: 导出CSV
表 2 电热板温度的影响
Table 2. Effect of electric heating plate temperature
电热板表面温度(℃) GBW07446 GBW07453 硫标准值(μg/g) 硫测定值(μg/g) 硫溶出率(%) 硫标准值(μg/g) 硫测定值(μg/g) 硫溶出率(%) 130 108±14 74 68.52 2000±300 1632 81.60 140 108±14 98 90.74 2000±300 1730 86.50 150 108±14 113 104.63 2000±300 1977 98.85 160 108±14 107 99.07 2000±300 1993 99.65 170 108±14 110 101.85 2000±300 1998 99.90 180 108±14 116 107.41 2000±300 2013 100.65 190 108±14 112 103.70 2000±300 2007 100.35 200 108±14 110 101.85 2000±300 1987 99.35 210 108±14 104 96.30 2000±300 1965 98.25 220 108±14 87 80.56 2000±300 1891 94.55 230 108±14 76 70.37 2000±300 1874 93.70
下载: 导出CSV
表 3 浸泡时间的选择
Table 3. Choice of soaking time
标准物质编号 粗粒级主要矿物 不同浸泡时间下溶解情况 0 h 4 h 8 h 12 h GBW07401 石英、长石 反应，冒泡 有少量固体 有极少量固体 基本清亮 GBW07403 石英、长石 无明显反应 有少量固体 基本清亮 基本清亮 GBW07407 褐铁矿、石英、高岭土 无明显反应 有少量固体 基本清亮 基本清亮 GBW07408 碳酸盐物质、长石、石英、黑云母、白云母、褐铁矿、贝壳 反应剧烈，大量冒泡 有少量白色、黑色固体 有极少量固体 基本清亮
下载: 导出CSV
表 4 国家标准物质中硫含量的分析结果
Table 4. Analytical results of sulfur in national standard references
标准物质编号 硫含量(μg/g) 相对误差(%) RSD (%) 标准值 本法测定平均值(n=12) GBW07446 108±14 108.4 0.37 4.05 GBW07447 (7000) 7041.94 0.60 0.50 GBW07448 (816) 820.06 0.50 2.00 GBW07449 27000±2900 26995.59 -0.02 0.47 GBW07450 (167) 171.17 2.50 3.66 GBW07451 440±42 442.96 0.67 1.12 GBW07452 (420) 422.02 0.48 1.46 GBW07453 2000±300 2000.51 0.03 1.63 GBW07454 170±22 170 0.00 3.02 GBW07455 162±10 157.25 -2.93 3.59 GBW07456 254±12 254.93 0.37 2.58 GBW07457 281±21 281.36 0.13 2.04 注：括号内数据为参考值。
下载: 导出CSV
表 5 三种分析方法的结果比较
Table 5. A comparison of the three analytical methods
样品编号 XRF法 管式炉碘量法 本法(四酸溶样ICP-OES法) 硫含量三次测定平均值(μg/g) RSD(%) 硫含量三次测定平均值(μg/g) RSD(%) 硫含量三次测定平均值(μg/g) RSD(%) 1 112* 5.63 83.1 11.46 78.3 6.42 2 143 2.42 124 8.97 136.7 3.82 3 266 2.41 270 5.43 274.2 2.33 4 355 1.62 349 4.32 343.1 2.67 5 527 1.74 534 3.66 536.3 1.82 6 832 0.86 827 4.22 816.4 0.69 7 966 2.42 933 5.21 946.6 1.11 8 1386 1.57 1276 4.14 1233 0.68 9 5233 2.44 4320 3.12 4362 2.43 10 5604* 1.87 7465 4.17 7654 3.26 11 28335* 1.52 21364 3.13 21362 2.03 12 55027* 1.62 42187 1.86 43227 2.74 13 176 2.87 188 7.33 182.4 3.11 14 256 2.11 263 4.87 261.2 2.46 15 687 1.14 693 3.22 684.2 2.03 16 778 1.06 786 4.16 781.4 1.06 17 1125 1.68 1139 3.55 1132 0.97 18 7864* 1.93 8546 3.68 8574 1.33 19 29365* 1.44 24652 4.15 24468 2.36 20 43225* 1.67 40271 2.87 40298 1.93
下载: 导出CSV
-
[1] 孙建中, 戴昭华, 盛学斌.华北地区土壤中硫的赋存特征[J].环境科学学报, 1997, 17(2):187-192. http://www.actasc.cn/hjkxxb/ch/reader/create_pdf.aspx?file_no=19970210
Sun J Z, Dai Z H, Sheng X B.Occurrence of sulfur in soil in Northern China[J].Acta Scientiae Circumstantiae, 1997, 17(2):187-192. http://www.actasc.cn/hjkxxb/ch/reader/create_pdf.aspx?file_no=19970210
[2] 刘潇潇, 王钧, 曾辉.中国温带草地土壤硫的分布特征及其与环境因子的关系[J].生态学报, 2016, 36(24):7919-7928. http://d.old.wanfangdata.com.cn/Periodical/stxb201624003
Liu X X, Wang J, Zeng H.Spatial variation in surface soil sulfur in the temperate grasslands of China and environmental constraints[J].Acta Ecologica Sinica, 2016, 36(24):7919-7928. http://d.old.wanfangdata.com.cn/Periodical/stxb201624003
[3] 黎卫亮, 王鹏.直接燃烧-红外吸收光谱法测定土壤、水系沉积物中的碳和硫[J].理化检验(化学分册), 2013, 49(10):1268-1269. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY200811016.htm
Li W L, Wang P.Determination of carbon and sulfur in soil and stream sediments by direct combustion infrared absorption spectrometry[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis), 2013, 49(10):1268-1269. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY200811016.htm
[4] 施善林, 李东麟, 李晓晗.高频燃烧红外吸收法测定镍铁合金中硫含量[J].有色矿冶, 2015, 31(3):52-54. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysky201503016
Shi S L, Li D L, Li X H.Determination of sulfur in ferro-nickel alloy by high frequency-infrared absorption method[J].Non-ferrous Mining and Metallurgy, 2015, 31(3):52-54. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysky201503016
[5] 王世芳, 韩平, 王纪华, 等.X射线荧光光谱分析法在土壤重金属检测中的应用研究进展[J].食品安全质量检测学报, 2016, 7(11):4394-4400. http://www.doc88.com/p-9032859830297.html
Wang S F, Han P, Wang J H, et al.Application of X-ray fluorescence spectrometry on the detection of heavy metals in soil[J].Journal of Food Safety and Quality, 2016, 7(11):4394-4400. http://www.doc88.com/p-9032859830297.html
[6] Sanina N B, Aisueva T S, Chuparina E V, et al. Toxic and radioactive elements in soils and vegetation of natural and technogenic geosystems of Pribaikalye (Lake Baikal region)[J].Chinese Journal of Geochemistry, 2006, 25(6):245. http://www.cnki.com.cn/Journal/A-A5-DQHB-2006-S1.htm
[7] Doyle A, Saavedra A, Tristao M, et al.Determination of S, Ca, Fe, Ni and V in crude oil by energy dispersive X-ray fluorescence spectrometry using direct sampling on paper substrate[J].Fuel, 2015, 162:39-46. doi: 10.1016/j.fuel.2015.08.072
[8] 沈亚婷, 李迎春, 孙梦荷, 等.波长与能量色散复合式X射线荧光光谱仪特性研究及矿区土壤分析[J].光谱学与光谱分析, 2017, 37(7):2216-2224. http://www.opticsjournal.net/Articles/abstract?aid=OJ170710000199UqWtZw
Shen Y T, Li Y C, Sun M H, et al.Studies on characteristics on a combined wavelength and energy dispersion X-ray fluorescence spectrometer and determinations of major, minor and trace elements in soils around a mining area[J].Spectroscopy and Spectral Analysis, 2017, 37(7):2216-2224. http://www.opticsjournal.net/Articles/abstract?aid=OJ170710000199UqWtZw
[9] 张莉娟, 刘义博, 李小莉, 等.超细粉末压片法-X射线荧光光谱测定水系沉积物和土壤中的主量元素[J].岩矿测试, 2014, 33(4):517-522. http://www.ykcs.ac.cn/article/id/0e710f2f-4494-4aac-a125-852875024d56
Zhang L J, Liu Y B, Li X L, et al.Determination of major elements in stream sediments and soils by X-ray fluorescence spectrometry using pressed-superfine powder pellets[J].Rock and Mineral Analysis, 2014, 33(4):517-522. http://www.ykcs.ac.cn/article/id/0e710f2f-4494-4aac-a125-852875024d56
[10] 黄元.XRF-ICP-AES法测定土壤中的主次元素[J].化学分析计量, 2015, 24(6):73-76. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hxfxjl201506019
Huang Y.Determination of major and minor elements in soil by X-ray fluorescence spectrometry and inductively coupled plasma-atomic emission spectrometry[J].Chemical Analysis and Meterage, 2015, 24(6):73-76. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hxfxjl201506019
[11] 马光强, 谢辉.硫酸钡重量法测定冰铜中总硫[J].冶金分析, 2014, 34(3):73-76. http://www.cqvip.com/QK/90283X/201403/49541994.html
Ma G Q, Xie H.Determination of total sulfur in copper matte barium sulfate gravimetry[J].Metallurgical Analysis, 2014, 34(3):73-76. http://www.cqvip.com/QK/90283X/201403/49541994.html
[12] 刘晓峰, 李子尚, 张志勇, 等.半熔分解硫酸钡重量法测定各类含重晶石矿样中的硫[J].矿冶工程, 2015, 35(1):101-102. http://d.wanfangdata.com.cn/Periodical_kygc201501027.aspx
Liu X F, Li Z S, Zhang Z Y, et al.Determining sulfur in various ore samples containing barite by semi-molten decomposition barium sulfate gravimetric method[J].Mining and Metallurgical Engineering, 2015, 35(1):101-102. http://d.wanfangdata.com.cn/Periodical_kygc201501027.aspx
[13] Busman L M, Dick R P, Tabatabai M A.Determination of total sulfur and chlorine in plant materials by ion chromatography[J].Soil Science Society of America Journal, 1983, 47:1167-1170. doi: 10.2136/sssaj1983.03615995004700060022x
[14] Poznic M, Gabrovsek R, Novic M.Ion chromatography determination of chloride and sulphate in cement[J].Cement and Concrete Research, 1999, 29:441-443. doi: 10.1016/S0008-8846(98)00234-8
[15] 陈梅芹, 杨成方, 吴景雄, 等.矿区河流沉积物中硫的总量测定及过程控制[J].冶金分析, 2015, 35(5):20-24. http://d.wanfangdata.com.cn/Periodical_yjfx201505004.aspx
Chen M Q, Yang C F, Wu J X, et al.Determination of total sulfur in river sediments from mining area and the process control[J].Metallurgical Analysis, 2015, 35(5):20-24. http://d.wanfangdata.com.cn/Periodical_yjfx201505004.aspx
[16] 陈静, 高志军, 陈冲科, 等.X射线荧光光谱法分析地质样品的应用技巧[J].岩矿测试, 2015, 34(1):91-98. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2015.01.012
Chen J, Gao Z J, Chen C K, et al.Application skills on determination of geological sample by X-ray fluorescence spectrometry[J].Rock and Mineral Analysis, 2015, 34(1):91-98. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2015.01.012
[17] 叶家瑜, 江宝林.区域地球化学勘查样品分析方法[M].北京:地质出版社, 2004.
Ye J Y, Jiang B L.Methods for Analysis of Regional Geochemical Exploration Samples[M].Beijing:Geological Publishing House, 2004.
[18] 苏凌云.低温逆王水溶样-电感耦合等离子体原子发射光谱法测定铁矿石中硫和磷[J].冶金分析, 2014, 34(11):69-72. http://d.wanfangdata.com.cn/Periodical_yjfx201411014.aspx
Su L Y.Determination of sulfur and phosphorus in iron ore by inductively coupled plasma atomic emission spectrometry after sample dissolution with inverse aqua reqia in low temperature[J].Metallurgical Analysis, 2014, 34(11):69-72. http://d.wanfangdata.com.cn/Periodical_yjfx201411014.aspx
[19] 李清昌, 薛静.ICP-AES测定矿物中硫的前处理方法的对比[J].有色矿冶, 2013, 29(1):57-58. http://d.old.wanfangdata.com.cn/Periodical/ysky201301019
Li Q C, Xue J.Comparison of pretreatment methods for determination of sulfur in minerals by ICP-AES[J].Non-Ferrous Mining and Metallurgy, 2013, 29(1):57-58. http://d.old.wanfangdata.com.cn/Periodical/ysky201301019
[20] 张文丽, 龙萍, 吴鉴, 等.ICP-AES法测定磷矿浆烟气脱硫剂固液相中硫含量的研究[J].光谱学与光谱分析, 2017, 37(5):1535-1539. http://manu13.magtech.com.cn/gpx/CN/abstract/abstract4379.shtml
Zhang W L, Long P, Wu J, et al.Determination of sulfur in solid and solution of phosphate ore pulp flue gas desulfurization agent with ICP-AES[J].Spectroscopy and Spectral Analysis, 2017, 37(5):1535-1539. http://manu13.magtech.com.cn/gpx/CN/abstract/abstract4379.shtml
[21] 聂西度, 谢华林.柴油中微量硫的发射光谱研究[J].光谱学与光谱分析, 2016, 36(5):1464-1467. http://www.cqvip.com/QK/90993X/201605/668756247.html
Nie X D, Xie H L.Study on the detection of trace sulphur in diesel with inductively coupled plasma optical emission spectroscopy[J].Spectroscopy and Spectral Analysis, 2016, 36(5):1464-1467. http://www.cqvip.com/QK/90993X/201605/668756247.html
[22] 李清彩, 赵庆令, 荀红梅.电感耦合等离子体原子发射光谱法测定多金属矿石中砷镉铟硫锑[J].冶金分析, 2015, 35(2):61-64. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201502013
Li Q C, Zhao Q L, Xun H M.Determination of arsenic, cadmium, indium, sufer and antimony in polymetallic ore by inductively coupled plasma atomic emission spectrometry[J].Metallurgical Analysis, 2015, 35(2):61-64. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201502013
[23] 高小山, 倪文山, 姚明星, 等.电感耦合等离子体原子发射光谱法测定黑钨精矿中痕量硫磷[J].冶金分析, 2012, 32(6):30-33. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201206007
Gao X S, Ni W S, Yao M X, et al.Determination of trace sulfur and phosphorus in wolframite concentrate by inductively coupled plasma atomic emission spectrometry[J].Metallurgical Analysis, 2012, 32(6):30-33. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201206007
[24] 张穗忠, 李杰.电感耦合等离子体原子发射光谱法测量萤石中硫含量[J].武汉工程职业技术学院学报, 2013, 25(4):1-3. http://www.cnki.com.cn/Article/CJFDTOTAL-WGZG201304002.htm
Zhang S Z, Li J.Measuring of sulfur content in fluorite by inductively coupled plasma atomic emission spectrometry[J].Journal of Wuhan Engineering Institute, 2013, 25(4):1-3. http://www.cnki.com.cn/Article/CJFDTOTAL-WGZG201304002.htm
[25] 胡璇, 石磊, 张炜华.碱熔融-电感耦合等离子体发射光谱法测定高硫铝土矿中的硫[J].岩矿测试, 2017, 36(2):124-129. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.02.005
Hu X, Shi L, Zhang W H.Determination of sulfur in high-sulfur bauxite by alkali fusion-inductively coupled plasma-optical emission spectrometry[J].Rock and Mineral Analysis, 2017, 36(2):124-129. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.02.005
[26] 马生凤, 温宏利, 马新荣, 等.四酸溶样-电感耦合等离子体原子发射光谱法测定铁、铜、锌、铅等硫化物矿石中22个元素[J].矿物岩石地球化学通报, 2011, 30(1):65-72. https://www.wenkuxiazai.com/doc/3b86c674f242336c1eb95eb0-3.html
Ma S F, Wen H L, Ma X R, et al.Determination of 22 elements in iron, copper, zinc, and lead sulphide ores by ICP-AES with four acids digestion[J].Bulletin of Mineralogy, Petrology and Geochemistry, 2011, 30(1):65-72. https://www.wenkuxiazai.com/doc/3b86c674f242336c1eb95eb0-3.html
[27] 年季强, 顾锋, 朱春要, 等.微波消解-电感耦合等离子体原子发射光谱法测定萤石中硅铁镁钾钠磷硫[J].冶金分析, 2015, 35(4):39-43. http://d.wanfangdata.com.cn/Periodical_yjfx201504008.aspx
Nian J Q, Gu F, Zhu C Y, et al.Determination of silicon, ferric, magnesium, potassium, sodium, phosphorus and sulphur in fluorite by microwave digestion-inductively coupled plasma atomic emission spectrometry[J].Metallurgical Analysis, 2015, 35(4):39-43. http://d.wanfangdata.com.cn/Periodical_yjfx201504008.aspx
[28] Cruz S M, Tirk P, Nora F M, et al.Feasibility of sulfur determination in diesel oil by inductively coupled plasma optical emission spectrometry after micro wave induced combustion using flame retardant[J].Fuel, 2015, 160:108-113. doi: 10.1016/j.fuel.2015.07.069
[29] 刘峰, 秦樊鑫, 胡继伟, 等.不同混合酸消解样品对电感耦合等离子体原子发射光谱法测定土壤中重金属含量的影响[J].理化检验(化学分册), 2011, 47(8):951-954. http://www.cqvip.com/QK/96266X/201108/39040877.html
Liu F, Qin F X, Hu J W, et al.Effects of different acid mixtures for sample digestion on the ICP-AES determination of heavy metal elements in soil[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis), 2011, 47(8):951-954. http://www.cqvip.com/QK/96266X/201108/39040877.html
[30] 郭春. 真空紫外光学薄膜制备及其性能检测技术研究[D]. 成都: 中国科学院光电技术研究所, 2014.
Guo C. Study on Preparation and Characterization of Optical Coatings for Vacuum Ultraviolet Applications[D]. Chengdu: Institute of Optics and Electronics, Chinese Academy of Sciences, 2014.
-
