Improvement of the Anomaly Spot-checking Method in Sample Analysis during a Geochemical Reconnaissance Survey
-
摘要: 在地球化学样品多元素分析过程中，为了实现地球化学异常点抽查和整批测试质量监控的双重目的，本文提出了一种基于地球化学异常统计的多区间分元素组异常点抽样方法。该方法主要包括：①按照正态分布或对数正态分布假设，对各元素，将该元素的测量值集，划分为离群低值区间、累积频率分布区间（有多个区间）和离群高值区间，统计每个样品中各元素测量值所属区间；②将测量元素分为几个元素组，统计各元素组中每个样品的总异常元素数、高异常元素数和低异常元素数；③对Au元素组，设置各个区间的抽检比例，随机抽取异常点抽检样品；对其他元素组，按照“总异常元素数”为第一顺序、“高异常元素数”为第二顺序和“低异常元素数”为第三顺序，按降序排序所有样品，顺序抽取异常点抽检样品；④必要时进行分析批补充抽检样品。该方法兼顾了地球化学异常和实验室测试“异常”的抽查；同时考虑非异常点抽查和分析批平衡抽检，有效解决了有限抽样数量和抽样代表性不足两者之间的矛盾；并开发了EXCEL应用程序，应用于实验室地球化学样品分析异常点抽检取得了满意效果。Abstract: In order to meet the double goals of picking up real geochemical anomalies and monitoring inner laboratory analytical quality during multiple element analysis of geochemical samples, a multi-interval and element-grouping sampling procedure (MIEGSP) based on the statistical method of geochemical anomalies is proposed. The MIEGSP mainly includes:(1) the set of each element's (logarithmic) measurements supposed to obey normal distribution and is divided into successive intervals including low/high value outlier ones and cumulative frequency distributions. Each measurement is assigned to a specific interval. (2) Target elements are grouped, total anomaly number (TAN), high anomaly number (HAN) and low anomaly number (LAN) in each group are calculated. (3) The samples with gold anomaly are randomly picked up according to the ratios of each interval, whereas samples with other element anomaly are orderly picked up from those samples characterized by higher TAN, HAN and LAN values. (4) If necessary, supplementary samples are randomly picked up from certain analytical batches. The MIEGSP takes into account, not only geochemical anomalies and experimental analysis anomalies, but also supplements of non-anomalies and analytical batch balance sampling. It has resolved the paradox between limited sample amount and the lack of sampling representativeness. An EXCEL program for anomaly sampling based on the Macros (VBA) was developed. The MIEGSP has been successfully applied to routine analysis of geochemical reconnaissance survey samples.
-
Key words:
- geochemical sample analysis /
- anomaly spot-checking /
- EXCEL application /
- quality control
-
-
表 1 元素的区间抽查比例
Table 1. Anomaly spot-checking ratios of intervals of outliers and cumulative frequency distributions
离群区间或累积频率分布区间 样品数量 区间内抽查比例(%) 抽样数量 (-∞, 0) m0 r0 m0·r0 [0, P1] m1 r1 m1·r1 (P1, P2] m2 r2 m2·r2 …… …… …… …… (Pi-1, Pi] mi ri mi·ri …… …… …… …… (Pn-1, Pn] mn rn mn·rn (Pn, 1] mn+1 rn+1 mn+1·rn+1 (1, +∞) mn+2 rn+2 mn+2·rn+2
下载: 导出CSV
表 2 剔除离群值后各个元素的对数均值和对数方差
Table 2. Averages and variances of elements' logarithmic contents excluding outliers
元素 Au Ag Sn As Ba Be Co 样品总数 1609 1609 1609 1609 1609 1609 1609 低离群值数 8 0 6 14 6 8 5 高离群值数 92 117 48 80 8 22 0 lg[X0] 0.103 -1.084 0.584 0.828 2.692 0.401 1.144 lg[S0] 0.314 0.257 0.165 0.285 0.15 0.144 0.246 元素 Cr Cu Li Ni Sr Zn 样品总数 1609 1609 1609 1609 1609 1609 低离群值数 1 20 13 12 62 25 高离群值数 1 46 12 1 9 73 lg[X0] 1.78 1.364 1.574 1.397 2.206 1.969 lg[S0] 0.34 0.283 0.132 0.324 0.165 0.085
下载: 导出CSV
表 3 Au元素分布区间的抽查比例
Table 3. Au anomaly spot-checking ratios of the 9 intervals
序号 分布区间 样品数量 区间抽查比例(%) 抽样数量 1 (-∞, 0) 8 100 8 2 [0, 0.015] 6 100 6 3 (0.015, 0.15] 90 4* 4 4 (0.15, 0.25] 379 4* 16 5 (0.25, 0.75] 582 4* 24 6 (0.75, 0.95] 340 4* 14 7 (0.95, 0.985] 97 4* 4 8 (0.985, 1] 15 100 15 9 (1, +∞) 92 100 92 合计 - 1609 11.37 183 注：“*”为在异常点样品抽检模块时设置的抽检比例。
下载: 导出CSV
-
[1] 田密. 水系沉积物低弱地球化学异常提取方法研究[D]. 长春: 吉林大学, 2017: 2-9.
Tian M. The Study of Identification Method on Weak Geochemical Anomaly of Stream Sediment[D]. Changchun: Jilin University, 2017: 2-9.
[2] 李前志, 周军, 刘磊, 等.岩石地球化学异常下限的确定方法对比——以云南思姑锡矿区为例[J].地质找矿论丛, 2015, 30(3):429-434. doi: 10.6053/j.issn.1001-1412.2015.03.016
Li Q Z, Zhou J, Liu L, et al.Comparison of low limit determination methods of petro-geochemical anomaly-Taking Sigu area of Yunnan as an example[J].Contributions to Geology and Mineral Resources Research, 2015, 30(3):429-434. doi: 10.6053/j.issn.1001-1412.2015.03.016
[3] Cheng Q M, Agterberg F P, Bonham-Carter G F.A spatial analysis method for geochemical anomaly separation[J].Journal of Geochemical Exploration, 1996, 56(3):183-195. doi: 10.1016/S0375-6742(96)00035-0
[4] 李庆谋, 成秋明.分形奇异(特征)值分解方法与地球物理和地球化学异常重建[J].地球科学, 2004, 29(1):109-118. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200401019.htm
Li Q M, Cheng Q M.Fractal singular-value (egin-value) decomposition method for geophysical and geochemical anomaly reconstruction[J].Earth Science, 2004, 29(1):109-118. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200401019.htm
[5] 陈国雄. 基于分形与小波理论的成矿复杂信息提取与识别方法研究[D]. 武汉: 中国地质大学, 2016: 17-27.
Chen G X. Identifying Weak but Complex Geophysical and Geochemical Anomalies Caused by Buried Ore Bodies Using Fractal and Wavelet Methods[D]. Wuhan: China University of Geosciences, 2016: 17-27.
[6] 曹园园, 李新虎.地球化学综合异常的圈定及找矿效果[J].物探与化探, 2017, 41(1):58-64. http://www.wutanyuhuatan.com/CN/Y2017/V41/I1/58
Cao Y Y, Li X H.Delineation of synthetic geochemical anomaly and evaluation of its effectiveness in ore prospecting[J].Geophysical and Geochemical Exploration, 2017, 41(1):58-64. http://www.wutanyuhuatan.com/CN/Y2017/V41/I1/58
[7] 陈永良, 路来君, 李学斌.多元地球化学异常识别的核马氏距离方法[J].吉林大学学报(地球科学版), 2014, 44(1):396-408. http://d.wanfangdata.com.cn/Periodical_cckjdxxb201401040.aspx
Chen Y L, Lu L J, Li X B.Kernel mahalanobis distance for multivariate geochemical anomaly recognition[J].Journal of Jilin University (Earth Science Edition), 2014, 44(1):396-408. http://d.wanfangdata.com.cn/Periodical_cckjdxxb201401040.aspx
[8] 季斌, 周涛发, 袁峰, 等.地球化学异常信息的空间自相关提取方法[J].测绘科学, 2017, 42(8):1-6. http://www.cqvip.com/QK/90556A/201607/669506907.html
Ji B, Zhou T F, Yuan F, et al.A method for identifying geochemical anomalies based on spatial autocorrelation[J].Science of Surveying and Mapping, 2017, 42(8):1-6. http://www.cqvip.com/QK/90556A/201607/669506907.html
[9] 杨锦发.地球化学调查样品测试异常值抽查方法的优化[J].岩矿测试, 2004, 23(3):212-215. http://www.ykcs.ac.cn/article/id/ykcs_20040356
Yang J F.Discussion on abnormal spot-checking methods in geochemical sample analysis[J].Rock and Mineral Analysis, 2004, 23(3):212-215. http://www.ykcs.ac.cn/article/id/ykcs_20040356
[10] 刘淑亮, 温良, 刘玲, 等.1:5万区矿调地球化学样品的分析质量监控[J].地质通报, 2014, 33(1):127-134. http://www.oalib.com/paper/4896800
Liu S L, Wen L, Liu L, et al.Quality monitoring of geochemical sample analysis in 1:50000 regional geological and mineral resources survey[J].Geological Bulletin of China, 2014, 33(1):127-134. http://www.oalib.com/paper/4896800
[11] 焦振志. 区域地球化学调查样品分析异常点抽检方法: 201410111978. 5[P]. 2014-06-18.
Jiao Z Z. Anomaly spot-checking method for geochemical reconnaissance survey sample analysis: 201410111978. 5[P]. 2014-06-18.
[12] 赵玉岩, 陆继龙, 郝立波, 等.基于网络的地球化学样品分析管理和质量监控系统[J].岩矿测试, 2010, 29(6):723-728. http://www.ykcs.ac.cn/article/id/ykcs_20100622
Zhao Y Y, Lu J L, Hao L B, et al.Management and quality control system for geochemical sample analysis based on network[J].Rock and Mineral Analysis, 2010, 29(6):723-728. http://www.ykcs.ac.cn/article/id/ykcs_20100622
[13] 葛建华, 徐国栋, 朱华平.Excel图形化处理地球化学数据的应用研究[J].物探化探计算技术, 2016, 38(1):120-124. https://www.cnki.com.cn/qikan-HLKX200702031.html
Ge J H, Xu G D, Zhu H P.The application research on geochemical data processed by Excel graphics[J].Computing Techniques for Geophysical and Geochemical Exploration, 2016, 38(1):120-124. https://www.cnki.com.cn/qikan-HLKX200702031.html
[14] 赵志飞, 闫晖, 姚岚, 等.正态分布在区域地球化学调查样品分析质量评价中的应用探讨[J].岩矿测试, 2013, 32(1):96-100. http://www.ykcs.ac.cn/article/id/e9df0ce7-322c-453d-8bdd-cea5b8bf7258
Zhao Z F, Yan H, Yao L, et al.Application of normal distribution to estimate the quality of regional geochemical survey samples[J].Rock and Mineral Analysis, 2013, 32(1):96-100. http://www.ykcs.ac.cn/article/id/e9df0ce7-322c-453d-8bdd-cea5b8bf7258
-
