Research on Geochemical Characteristics of Soil in a Chemical Industrial Factory Site in Jinan City
-
摘要: 随着我国城市产业布局升级，高污染、高能耗的化工企业被关停或搬离，研究这些企业遗留地块土壤的地球化学特征对污染场地风险管控具有重要的现实意义。本文在济南市某废弃化工厂原厂区采集了100件土壤样品，测试SiO2、Al2O3、CaO、Fe2O3、K2O、MgO、Na2O、As、Ba、Br、Ce、Cl、Co、Cu、Ga、Hf、La、Mn、Nb、Nd、Ni、P、Pb、Rb、S、Sc、Sr、Th、Ti、V、Y、Zn、Zr、Cr、Cr（Ⅵ）、铬形态、pH值、有机质等42项指标，研究厂区土壤中元素的地球化学特征。结果表明：研究区土壤中的总铬量在1025~2450 mg/kg，Cr（Ⅵ）含量在557.0~996.5 mg/kg，Cr（Ⅵ）含量占总铬量的46.77%。在0~80 cm深度内，总铬、Cr（Ⅵ）含量随深度的变化并不明显。随着深度增加，离子交换态铬占总铬的比例有逐渐降低的趋势，而残渣态铬占总铬的比例增大。土壤的总铬含量与pH值呈线性负相关，相关系数为-0.8470，而Cr（Ⅵ）与有机质、pH值相关性均不显著。聚类分析发现Cr元素的来源单独成为一类，主要为化工厂长期堆放大量铬渣引起的人为污染所致，其他组分与全国土壤、黄淮海平原土壤则有着相似的自然源。Abstract: With the upgrade of urban industrial distribution, high pollution and energy-intensive companies were closed and moved. It is of great importance to investigate the geochemical characteristics of these abandoned soils for risk control of polluted sites. 100 soil samples at the site of a former chemical industrial factory in Jinan were collected and 42 indices, including concentration of total Cr, Cr(Ⅵ) and pH were analyzed to understand the geochemical characteristics of the site. Results show that total Cr concentration of the collected samples was 1025-2450 mg/kg and Cr(Ⅵ) concentration was 557.0-996.5 mg/kg (46.77% of the total Cr). At soil depth ranging from 0 to 80 cm, concentration change of total Cr and Cr(Ⅵ) was not significant. With the increase of soil depth, proportion of exchangeable Cr tended to decrease while residue Cr tended to increase. Total Cr concentration showed negative correlation with pH value while Cr(Ⅵ) did not show significant correlation with pH value. Cluster analysis demonstrated that the source of Cr in the site soil was different from that of other elements, which was mainly caused by the man-made pollution due to long-term heaps of chromium slag at the chemical plant. The other components had similar natural sources to the soil in the country and the Huang-Huai-Hai Plain.
-
Key words:
- geochemical characteristics /
- total Cr /
- Cr (Ⅵ) /
- soil /
- cluster analysis /
- chemical industrial factory
-
-
表 1 污染场地土壤铬形态分析数据统计
Table 1. Concentrations of different forms of Cr in polluted soil
采样编号 Cr含量(mg/kg) 离子交换态 碳酸盐结合态 铁锰氧化物结合态 有机结合态 残渣态 A1 606.5 39.72 88.72 97.28 465.0 B1 651.8 49.52 96.76 99.80 443.6 C1 557.8 47.80 99.92 112.8 480.8 D1 559.5 63.72 160.6 206.4 726.8 A2 538.5 48.08 117.1 128.4 546.0 B2 561.2 55.72 139.8 164.3 644.6 C2 590.5 52.64 122.3 154.6 638.1 D2 658.5 61.88 176.9 237.0 893.9 A3 586.0 52.72 89.04 101.2 453.0 B3 595.0 60.6 164.2 199.4 764.0 最大值 658.5 63.72 176.9 237.0 893.9 最小值 538.5 39.72 88.72 97.28 443.6 平均值 590.5 53.24 125.5 150.1 605.6 变异系数(%) 6.74 13.98 26.31 33.63 25.46 注：采样编号中的1、2、3代表采样点1、采样点2、采样点3；A是0~20 cm土壤层，B是20~40 cm土壤层，C是40~60 cm土壤层，D是60~80 cm土壤层。
下载: 导出CSV
表 2 污染场地土壤的常量、微量组分数据统计分析
Table 2. Statistical analysis of constant and trace components in polluted soil
组分 含量(mg/kg) 变异系数 背景值(mg/kg) 超背景值倍数 最大值 最小值 平均值 SiO2 51.52 49.05 50.34 1.59 64.87 0.78 Al2O3 13.06 12.74 12.89 0.79 12.84 1 CaO 7.35 6.91 7.09 2.1 4.1 1.73 Fe2O3 5.48 5.18 5.33 1.59 4.64 1.15 K2O 2.756 2.649 2.69 1.16 2.34 1.15 MgO 2.54 2.5 2.52 0.59 1.88 1.34 Na2O 1.612 1.493 1.57 2.43 1.7 0.92 As 13 11.3 12.02 4.57 11 1.09 Ba 507.6 490.5 497.43 1.1 535 0.93 Br 4.3 2.9 3.7 14.13 3 1.23 Ce 84.4 80 82.45 1.75 1.4 58.89 Cl 206.6 167.1 185.46 6.32 215 0.86 Rb 94.1 56.4 68.87 20.45 100 0.69 S 687.6 336.5 477.3 25.93 140 3.41 Sc 15.5 13.3 14.42 4.46 10 1.44 Sr 168.1 151.1 156.6 3.56 175 0.9 Th 17.9 11.6 15.23 14.58 11 1.39 Ti 3785 3722 3752 0.63 3845 0.98 Co 18.4 15.3 17.18 5.85 12 1.43 Cr 1975 1350 1642.5 15.22 66 24.89 Cu 33.7 30.3 32.12 2.81 23 1.4 Ga 15.1 10 11.69 16.29 14.8 0.79 Hf 3.7 1.8 2.63 31.87 7.7 0.34 La 41.4 24.7 34.6 14.65 35 0.99 Mn 973.1 783.7 869.66 8.09 705 1.23 Nb 17.2 12.8 15.68 8.12 14.8 1.06 Nd 35 20.3 28.22 14.49 26 1.09 Ni 34.2 22.2 26.26 15.43 32 0.82 P 652.4 628.6 644.26 1.06 515 1.25 Pb 27.7 20.3 24.64 9.55 22 1.12 V 84.3 81.5 82.99 1.09 82 1.01 Y 21.1 12.7 15.56 19.48 26 0.6 Zn 458.5 105.5 275.8 52.22 62 4.45 Zr 133.7 115.4 122.18 4.59 230 0.53 pH 8.40 7.86 8.12 2.28 / / 有机质 9.29 7.28 8.06 7.54 13.4 0.6 注：有机质的背景值为山东省土壤背景值，数据来源于《山东省耕地质量提升——土壤改良修复实施方案(2016—2020年)》；其他指标的背景值指黄淮海平原土壤背景值[12]。SiO2、Al2O3、CaO、Fe2O3、K2O、MgO、Na2O、有机质的单位是%。
下载: 导出CSV
-
[1] 赵庆令, 李清彩, 谢江坤, 等.应用富集系数法和地累积指数法研究济宁南部区域土壤重金属污染特征及生态风险评价[J].岩矿测试, 2015, 34(1):129-137. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2015.01.017
Zhao Q L, Li Q C, Xie J K, et al.Characteristics of soil heavy metal pollution and its ecological risk assessment in South Jining district using methods of enrichment factor and index of geoaccumulation[J].Rock and Mineral Analysis, 2015, 34(1):129-137. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2015.01.017
[2] 唐发静, 祖艳群.土壤重金属空间变异的研究方法[J].云南农业大学学报, 2008, 23(4):558-561. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=csjsysywd201022050
Tang F J, Zu Y Q.Research methods of spatial variability of heavy metals in soil[J].Journal of Yunnan Agricultural University, 2008, 23(4):558-561. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=csjsysywd201022050
[3] Li X D, Lee S L, Wong S C, et al.The study of metal contamination in urban soil of Hong Kong using a GIS-based approach[J].Environmental Pollution, 2004, 129:113-124. doi: 10.1016/j.envpol.2003.09.030
[4] Zhang C S.Using multivariate analyses and GIS to identify pollutants and their spatial patterns in urban soils in Galway, Ireland[J].Environmental Pollution, 2006, 142:501-511. doi: 10.1016/j.envpol.2005.10.028
[5] Ilg K, Wilcke W, Safronov G, et al.Heavy metal distribution in soil aggregates:A comparison of recent and archived aggregates from Russia[J].Geoderma, 2004, 123:153-162. doi: 10.1016/j.geoderma.2004.02.006
[6] 任文会, 吴文涛, 陈玉, 等.某废弃化工厂场地土壤重金属污染评价[J].合肥工业大学学报(自然科学版), 2017, 40(4):533-538. http://www.cnki.com.cn/Article/CJFDTotal-STDL201504026.htm
Ren W H, Wu W T, Chen Y, et al.Assessment of heavy metal pollution in soil from an abandoned chemical plant[J].Journal of Hefei University of Technology (Natural Science), 2017, 40(4):533-538. http://www.cnki.com.cn/Article/CJFDTotal-STDL201504026.htm
[7] 孙贤斌, 李玉成.淮南大通煤矿废弃地土壤重金属空间分布及变异特征[J].地理科学, 2013, 33(10):1238-1244. http://www.oalib.com/paper/4170899
Sun X B, Li Y C.The spatial distribution of soil heavy metals and variation characteristics of Datong abandoned coal mine area in Huainan city[J].Scientia Geographica Sinica, 2013, 33(10):1238-1244. http://www.oalib.com/paper/4170899
[8] 张增奇, 陈军, 付英, 等.济南千佛山地区沉积地层特征地质构造演化及古地理[J].山东国土资源, 2014, 30(10):1-7. doi: 10.3969/j.issn.1672-6979.2014.10.003
Zhang Z Q, Chen J, Fu Y, et al.Sedimentary characteristics geological tectonic evolution and paleogeography of Qianfoshan mountain area in Jinan city[J].Shandong Land and Resources, 2014, 30(10):1-7. doi: 10.3969/j.issn.1672-6979.2014.10.003
[9] 张杰芳, 闫玉乐, 夏承莉, 等.微波碱消解-电感耦合等离子体发射光谱法测定煤灰中的六价铬[J].岩矿测试, 2017, 36(1):46-51. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.01.007
Zhang J F, Yan Y L, Xia C L, et al.Determination of Cr(Ⅵ) in coal ash by microwave alkaline digestion and inductively coupled plasma-optical emission spectrometry[J].Rock and Mineral Analysis, 2017, 36(1):46-51. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.01.007
[10] Dhal B, Thatoi H N, Das N N, et al.Chemical and microbial remediation of hexavalent chromium from contaminated soil and mining/metallurgical solid waste:A review[J].Journal of Hazardous Materials, 2013, 250-251:272-291. https://www.sciencedirect.com/science/article/pii/S0304389413000666
[11] Kwaka S, Yooa J C, Moonb D H, et al.Role of clay minerals on reduction of Cr(Ⅵ)[J]. Geoderma, 2018, 312:1-5. doi: 10.1016/j.geoderma.2017.10.001
[12] 迟清华, 鄢明才.应用地球化学元素丰度数据手册[M].北京:地质出版社, 2007:82-88.
Chi Q H, Yan M C.Handbook of Elemental Abundance for Applied Geochemistry[M].Beijing:Geological Publishing House, 2007:82-88.
[13] 林治家, 陈多福, 刘芊.海相沉积氧化还原环境的地球化学识别指标[J].矿物岩石地球化学通报, 2008, 27(1):72-80. http://industry.wanfangdata.com.cn/dl/Detail/Periodical?id=Periodical_kwysdqhxtb200801012
Lin Z J, Chen D F, Liu Q.Geochemical indices for redox conditions of marine sediments[J].Bulletin of Mineralogy, Petrology and Geochemistry, 2008, 27(1):72-80. http://industry.wanfangdata.com.cn/dl/Detail/Periodical?id=Periodical_kwysdqhxtb200801012
[14] 熊小辉, 肖加飞.沉积环境的地球化学示踪[J].地球与环境, 2011, 39(3):405-414. http://www.doc88.com/p-692102487991.html
Xiong X H, Xiao J F.Geochemical indicators of sedimentary environments:A summary[J].Earth and Environment, 2011, 39(3):405-414. http://www.doc88.com/p-692102487991.html
[15] 赵庆令, 李清彩.电感耦合等离子体发射光谱法测定锆钛砂矿中铪钛锆[J].岩矿测试, 2013, 32(6):883-886. http://www.ykcs.ac.cn/article/id/c47cff27-d31e-48fb-a4cd-b7b8df6b5f6f
Zhao Q L, Li Q C.Determination of Hf, Ti and Zr in zirconium-titanium placer by inductively coupled plasma-atomic emission spectrometry[J].Rock and Mineral Analysis, 2013, 32(6):883-886. http://www.ykcs.ac.cn/article/id/c47cff27-d31e-48fb-a4cd-b7b8df6b5f6f
[16] 邓觉梅, 尹玉静, 于明光, 等.山东省钛矿床的类型分布及其主要地质特征[J].山东国土资源, 2016, 32(3):36-38. http://d.old.wanfangdata.com.cn/Periodical/sddz201603006
Deng J M, Yin Y J, Yu M G, et al.Types distribution and main geological characteristics of titanium deposit in Shandong Province[J].Shandong Land and Resources, 2016, 32(3):36-38. http://d.old.wanfangdata.com.cn/Periodical/sddz201603006
-
