Determination of 23 Metal Elements in Detailed Soil Survey Samples by Inductively Coupled Plasma-Mass Spectrometry with Three Acid Stepwise Digestion
-
摘要: 土壤详查样品具有数量大、基质复杂、有机质含量高的特点，传统上采用多种混合酸体系的消解方法，不仅会造成有机质消解不完全，消解后的溶液中常有黑色的碳质存在，而且样品消解后只用稀硝酸提取，一些难溶氧化物、硫酸盐、氟化物难以形成可溶性盐，致使提取不彻底，若用逆王水提取则易大量引入氯离子造成氯的多原子离子质谱干扰。本文针对上述问题，充分利用硝酸、氢氟酸、高氯酸的不同特性，采用电热板控温，三酸分步加入法消解土壤样品，对于消解后的样品，采用硝酸-盐酸（体积比20：1）作为提取剂，有效降低了氯的多原子离子质谱干扰且提取彻底。结果表明：本方法能够消解土壤中有机质和硅酸盐组分，具有试剂用量少、氯的质谱干扰小、操作流程简单、工作效率高等优点，方法检出限（3s）更低（0.0008~0.90mg/kg）。将该方法应用于暗棕壤、石灰岩土壤、黄棕壤国家标准物质中23种元素的测定，其测定结果明显优于传统的消解方法，相对标准偏差（RSD，n=6）为0.022%~5.83%，相对误差为-8.33%~9.17%，测定时与认定值相符。该方法具有较高的适用性和可靠性。
-
关键词:
- 土壤详查样品 /
- 金属元素 /
- 硝酸-氢氟酸-高氯酸消解 /
- 电感耦合等离子体质谱法
Abstract:OBJECTIVES The soil detailed survey samples have the characteristics of large quantity, complex matrix, and high organic matter content. The traditional digestion method using a variety of mixed acid systems not only leads to incomplete digestion of organic matter, but also leaves black carbon in the solution after digestion. Because the sample is only extracted with dilute nitric acid, some insoluble oxides, sulfates, and fluorides are difficult to form soluble salts, resulting in incomplete extraction. If the reverse aqua regia is used during extraction, it is easy to introduce a large amount of chloride ions and cause the interference problem of chlorine multi-atomic ion mass spectrometry. OBJECTIVES In order to accurately determine 23 metal elements in soil. The analysis efficiency and quality can be improved by making full use of the different characteristics of nitric acid, hydrofluoric acid and perchloric acid in sample digestion. METHODS Soil samples were digested on electric heating plate, by stepwise addition of nitric acid, hydrofluoric acid and perchloric acid. For the digested samples, nitric acid-hydrochloric acid (20:1, V/V) mixed solution was used as the extractant, effectively reducing the interference of chlorine polyatomic ion mass spectrum and extracting elements thoroughly. Twenty-three metal elements in the soil were simultaneously determined by inductively coupled plasma-mass spectrometry (ICP-MS). RESULTS This method can effectively digest organic matter and silicate components in soil. It has the advantages of less reagent consumption, less mass spectrum interference of chlorine, simple operation process, high working efficiency, and lower detection limit (0.0008-0.90mg/kg, 3s). This method was applied to the national level standard substance such as dark brown soil, limestone soil, yellow brown soil samples for the determination of 23 elements, and the measurement result was superior to the traditional digestion method. The precision (RSD, n=6) was 0.022%-5.83% and relative error was -8.33% to 9.17%. The results are consistent with the certified values, indicating that the method is applicable and reliable. CONCLUSIONS The method for the simultaneous determination of 23 elements in soil samples by ICP-MS with three acid stepwise digestion has high applicability and reliability. -
-
表 1 多元素标准溶液
Table 1. Standard solution of multiple elements
样品编号 多元素组合浓度(μg/L) Cd、In Li、Cu、Pb、Zn、Cr、Ni、Ⅴ、As Be、Mo、Tl Co、Ga、W、Cs、Sb、Bi Mn、Ba Sn Sr 1-1 0.00 0.00 0.00 0.00 0.00 0.00 0.00 1-2 0.010 2.00 0.10 0.50 25.0 0.25 10.0 1-3 0.020 4.00 0.25 1.00 50.0 0.50 20.0 1-4 0.050 8.00 0.50 2.00 100 1.00 40.0 1-5 0.10 10.0 0.75 5.00 200 1.50 60.0 1-6 0.20 20.0 1.00 10.0 300 2.00 80.0 1-7 0.50 40.0 1.50 15.0 400 2.50 100 1-8 1.00 80.0 2.00 20.0 500 3.00 150 1-9 2.00 100 2.50 25.0 600 4.00 200 1-10 3.00 120 3.50 30.0 800 6.00 300 1-11 4.00 160 4.00 35.0 1000 8.00 400 1-12 5.00 200 5.00 40.0 1200 10.0 500
下载: 导出CSV
表 2 土壤标准物质GBW07454中23种金属元素的测定结果
Table 2. Analytical results of 23 metallic elements in the GBW07454 soil reference material
待测元素 认定值(mg/kg) 12次测定平均值(mg/kg) RSD(%) 7Li 32±2 30.3 5.01 9Be 1.9±0.1 1.85 3.25 51Ⅴ 77±4 79.6 1.08 52Cr 66±4 66.7 3.36 55Mn 632±21 615 1.59 59Co 12±0.5 11.8 0.67 60Ni 30±1 29.4 1.98 65Cu 23.6±1.0 24.5 4.13 66Zn 66±2 67.9 3.38 71Ga 14.9±0.4 15.1 0.32 75As 12.9±0.5 13.8 6.08 88Sr 192±6 197 1.86 98Mo 0.72±0.07 0.77 2.79 114Cd 0.175±0.01 0.172 3.54 115In 0.049±0.005 0.048 7.37 118Sn 2.9±0.4 3.05 3.44 121Sb 1.13±0.05 1.16 4.95 133Cs 7.2±0.3 6.98 1.99 137Ba 495±16 502 1.06 182W 8.3±0.5 8.56 6.06 205Tl 0.59±0.06 0.57 3.81 208Pb 22±1 21.8 0.98 209Bi 0.32±0.01 0.31 4.85
下载: 导出CSV
表 3 本方法和标准方法的检出限对比
Table 3. Comparison of detection limits between this method and standard method
元素 检出限(mg/kg) 本方法 标准方法 Li 0.026 0.06 Be 0.004 0.006 Ⅴ 0.79 3 Cr 0.20 2 Mn 0.14 0.2 Tl 0.001 0.003 Co 0.005 0.02 Ni 0.08 0.6 Cu 0.32 0.6 Zn 0.90 1.1 Ga 0.07 0.1 Pb 0.22 0.003 As 0.25 - Sr 0.30 0.4 Mo 0.005 0.02 Cd 0.003 0.021 In 0.0008 0.002 Bi 0.009 0.015 Sn 0.02 - Sb 0.01 0.02 Cs 0.002 0.003 Ba 0.95 1.1 W 0.006 0.02
下载: 导出CSV
表 4 本方法和标准方法的实验条件对比
Table 4. Comparison of experimental conditions between this method and standard method
对比项目 本文方法 标准方法 取样量 0.1000g 0.2500g 耗酸量 硝酸5mL，氢氟酸4mL，高氯酸1mL 硝酸10mL，氢氟酸15mL，高氯酸3mL 样品处理时间 3h左右 25h以上 消解步骤 针对土壤样品特点，三酸分三步控温加入 分两次加入三种混合酸，各种酸的利用效率低 提取方法 硝酸-盐酸(20:1，体积比)并用水稀释一倍溶液5mL提取 加王水8mL蒸发至2~3mL提取，Cl-浓度高 溶液稀释 定容至100mL容量瓶中，无稀释 定容至25mL试管中，稀释10倍
下载: 导出CSV
表 5 方法精密度和准确度
Table 5. Precision and accuracy tests of the method
元素 GBW07401 GBW07403 GBW07404 认定值(mg/kg) 测定平均值(mg/kg) RSD(%) 相对误差(%) 认定值(mg/kg) 测定平均值(mg/kg) RSD(%) 相对误差(%) 认定值(mg/kg) 测定平均值(mg/kg) RSD(%) 相对误差(%) 7Li 35±1 34.1 1.31 -3.22 18.4±0.8 18.7 0.47 4.73 55±2 54.2 1.08 -1.61 9Be 2.5±0.3 2.42 2.57 -3.20 1.4±0.3 1.44 3.68 2.86 1.85±0.34 1.97 1.52 6.49 51Ⅴ 86±4 85.6 1.06 -0.47 36±4 38.2 2.49 6.11 247±14 241 1.36 -2.43 52Cr 62±4 62.5 1.03 0.81 32±6 31.0 0.87 -3.13 370±16 366 0.27 -1.08 55Mn 1760±63 1721 2.49 -2.22 304±21 296 2.55 -2.63 1420±75 1405 1.34 -1.06 59Co 14.2±1.0 13.9 0.79 -2.11 5.5±1.0 5.74 2.02 4.36 22±2 20.9 1.46 -5.00 60Ni 20.4±1.8 21.3 0.09 4.41 12±2.7 13.1 0.09 9.17 64±5 64.3 0.04 0.47 65Cu 21±2 20.7 0.05 -1.43 11.4±1.6 10.9 0.04 -4.39 40±3 39.7 0.05 -0.75 66Zn 680±25 675 0.02 -0.74 31±4 32.9 0.04 6.13 210±13 215 0.04 2.38 71Ga 19.3±1.1 18.9 1.05 -2.07 31±5 31.3 0.84 0.73 31±3 31.7 1.19 2.26 75As 34±4 32.3 2.56 -5.00 4.4±0.9 4.68 3.87 6.36 58±6 59.1 1.23 1.90 88Sr 155±7 158 0.08 1.94 380±25 369 0.06 -2.89 77±6 79.4 1.25 3.12 98Mo 1.4±0.1 1.46 2.78 4.29 0.31±0.13 0.33 5.83 6.45 2.6±0.3 2.59 1.61 -0.38 114Cd 4.3±0.4 4.43 0.06 3.02 0.06±0.022 0.058 0.05 -3.33 0.35±0.06 0.37 0.09 5.71 115In 0.08±0.02 0.082 0.03 2.50 0.031±0.03 0.029 0.10 -6.45 0.12±0.03 0.11 1.06 -8.33 118Sn 6.1±0.7 6.03 1.77 -1.15 2.5±0.4 2.59 3.60 3.60 5.7±0.9 5.95 1.92 4.39 121Sb 0.87±0.21 0.82 0.92 -5.75 0.44±0.08 0.47 1.58 6.82 6.3±1.1 6.17 2.36 -2.06 133Cs 9±0.7 8.87 0.43 -1.44 3.2±0.4 3.25 0.88 1.56 21.4±1.0 19.8 0.29 -7.48 137Ba 590±32 599 0.10 1.53 1210±65 1187 0.03 -1.90 213±20 220 1.43 3.29 182W 3.1±0.3 3.21 3.68 3.55 0.96±0.12 1.04 4.85 8.33 6.2±0.5 6.09 2.07 -1.77 205Tl 1.0±0.2 1.02 1.96 2.00 0.48±0.05 0.5 2.50 4.17 0.94±0.25 0.97 2.25 3.19 208Pb 98±6 98.8 0.03 0.82 26±3 26.2 0.06 0.77 58±5 57.4 0.06 -1.03 209Bi 1.2±0.1 1.17 2.78 -2.50 0.17±0.03 0.18 4.62 5.88 1.04±0.13 0.99 3.82 -4.81
下载: 导出CSV
-
[1] 贺攀红, 杨珍, 龚治湘.氢化物发生-电感耦合等离子体发射光谱法同时测定土壤中的痕量砷铜铅锌镍钒[J].岩矿测试, 2020, 39(2):235-242. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201904160048
He P H, Yang Z, Gong Z X.Simultaneous determination of trace arsenic, copper, lead, zine, niclel and vanadium in soils by hydride generation-inductively coupled plasma-optical emission spectrometry[J].Rock and Mineral Analysis, 2020, 39(2):235-242. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201904160048
[2] 张更宇, 刘伟, 崔世荣, 等.分类消解-电感耦合等离子体原子发射光谱法测定环境土壤中15种金属元素的含量[J].理化检验(化学分册), 2018, 54(4):428-432. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=lhjy-hx201804013
Zhang G Y, Liu W, Cui S R, et al.Determination of 15 metal elements in environmental soil by inductively coupled plasma atomic emission spectrometry with classification digestion[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis), 2018, 54(4):428-432. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=lhjy-hx201804013
[3] 黄勤, 凤海元, 吴忠忠.电感耦合等离子体质谱法测定环境评价性土壤中铬铜镉铅[J].化学研究与应用, 2017, 29(9):1444-1448. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hxyjyyy201709030
Huang Q, Feng H Y, Wu Z Z.Determination of Cr, Cu, Cd and Pb in environmental evaluation soils by inductively coupled plasma-mass spectrometry[J].Chemical Research and Application, 2017, 29(9):1444-1448. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hxyjyyy201709030
[4] 赵小学, 赵宗生, 陈纯, 等.电感耦合等离子体质谱法内标元素选择的研究[J].中国环境监测, 2016, 32(1):84-87. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghjjc201601016
Zhao X X, Zhang Z S, Chen C, et al.Study on selection of internal standard element of ICP-MS[J].Environmental Monitoring in China, 2016, 32(1):84-87. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghjjc201601016
[5] 王云凤, 王江鱼.四种酸体系溶样法对电感耦合等离子体质谱法测定水系沉积物中16种金属元素的影响[J].冶金分析, 2016, 36(7):63-68. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201607010
Wang Y F, Wang J Y.Influence of four sample solution method with acid system on determination of sixteen metal elements in stream sediment by inductively coupled plasma mass spectrometry[J].Metallurgical Analysis, 2016, 36(7):63-68. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201607010
[6] 王初丹, 罗盛旭.硝酸-氢氟酸消解ICP-MS测定海洋沉积物中多种金属元素[J].桂林理工大学学报, 2016, 36(2):337-340. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=glgxy201602024
Wang C D, Luo S X.Determination of metal elements in marine sediments by nitric acid-hydrofluoric acid digestion and ICP-MS[J].Journal of Guilin University of Technology, 2016, 36(2):337-340. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=glgxy201602024
[7] 刘向磊, 孙文军, 文田耀, 等.负载泡塑富集-电感耦合等离子体质谱法测定地质样品中痕量金和银[J].分析化学, 2015, 43(9):1371-1376. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxhx201509022
Liu X L, Sun W J, Wen T Y, et al.Determination of Au and Ag in geological samples by loaded polyurethane foam-inductively coupled plasma-mass spectrometry[J].Chinese Journal of Analytical Chemistry, 2015, 43(9):1371-1376. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxhx201509022
[8] 张萍, 谢华林.ORS-ICP-MS测定工业污泥中的重金属元素[J].环境工程学报, 2014, 8(7):3089-3062. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjwrzljsysb201407076
Zhang P, Xie H L.Determination of heavy metal elements in industrial sludge by ORS-ICP-MS[J].Chinese Journal of Environmental Engineering, 2014, 8(7):3089-3062. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjwrzljsysb201407076
[9] 李斌, 赵春江.我国当前农产品产地土壤重金属污染形势及检测技术分析[J].农业资源与环境学报, 2013, 30(5):1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nyhjyfz201305002
Li B, Zhao C J.Current situation of heavy metals pollution in soil at farmland and detection technologies analysis in China[J].Journal of Agricultural Resources and Environment, 2013, 30(5):1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nyhjyfz201305002
[10] 张霖琳, 梁宵, 加那尔别克·西里甫汗, 等.在土壤及底泥重金属测定中不同前处理和分析方法的比较[J].环境化学, 2013, 32(2):302-306. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201302018
Zhang L L, Liang X, Janarbek X, et al.Comparison of different pretreatment and analytical method of heavy metals in soil and sediment samples[J].Environmental Chemistry, 2013, 32(2):302-306. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201302018
[11] 刘晔, 第五春荣, 柳小明, 等.密闭高温高压溶样ICP-MS测定56种国家地质标准物质中的36种痕量元素——对部分元素参考值修正和定值的探讨[J].岩矿测试, 2013, 32(2):221-228. http://www.ykcs.ac.cn/article/id/749f22d1-0b51-470a-b562-8c13659615b9
Liu Y, Diwu C R, Liu X M, et al.Determination of 36 trace elements in 56 Chinese national standard reference materials by ICP-MS with pressurized acid-digestion[J].Rock and Mineral Analysis, 2013, 32(2):221-228. http://www.ykcs.ac.cn/article/id/749f22d1-0b51-470a-b562-8c13659615b9
[12] 鲁照玲, 胡红云, 姚洪.土壤中重金属元素电感耦合等离子体质谱定量分析方法的研究[J].岩矿测试, 2012, 31(2):241-246. http://www.ykcs.ac.cn/article/id/ykcs_20120208
Lu Z L, Hu H Y, Yao H.Study on quantitative analysis method for several heavy metals in soil sample by inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2012, 31(2):241-246. http://www.ykcs.ac.cn/article/id/ykcs_20120208
[13] 朱晓贤, 王攀峰, 邰文亮, 等.ICP-MS测量土壤中重金属元素的方法研究[J].地下水, 2020, 42(2):97-100. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dixs202002036
Zhu X X, Wang P F, Tai W L, et al.Study on the method of measuring heavy metal elements in soil by ICP-MS[J].Ground Water, 2020, 42(2):97-100. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dixs202002036
[14] 徐聪, 赵婷, 池海涛, 等.微波消解-ICP-MS法测定土壤及耕作物小麦中的8种重金属元素[J].中国测试, 2019, 45(5):85-92. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgcsjs201905014
Xu C, Zhao T, Chi H T, et al.Determination of eight kinds of heavy metal elements in cultivated soil and the wheat by microwave digestion-ICP-MS method[J].China Measurement & Test, 2019, 45(5):85-92. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgcsjs201905014
[15] 文典, 严冬, 赵沛华, 等.快速高通量全消解ICP-MS法测定《全国土壤污染状况详查》项目中14种元素[J].环境化学, 2018, 37(6):1432-1435. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201806028
Wen D, Yan D, Zhao P H, et al.Fast determination of 14 elements in China soil pollution survey with high throughput full digestion method by ICP-MS[J].Environmental Chemistry, 2018, 37(6):1432-1435. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201806028
[16] 孙杰, 吴玥, 蒋沄泱, 等.稀酸酸解-电感耦合等离子体质谱法测定土壤中14种无机元素的含量[J].理化检验(化学分册), 2017, 54(3):315-321. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QKC20172017042100122050
Sun J, Wu Y, Jiang Y Y, et al.ICP-MS determination of inorganic elements in soil using dilute acid dissolution[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis), 2017, 54(3):315-321. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QKC20172017042100122050
[17] 彭杨, 吴婧, 巢静波, 等.土壤/沉积物中14种金属元素的ICP-MS准确测定方法[J].环境化学, 2017, 36(1):175-182. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201701020
Peng Y, Wu J, Chao J B, et al.A method for the the accurate determination of 14 metal elements in soils sediments by ICP-MS[J].Environmental Chemistry, 2017, 36(1):175-182. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201701020
[18] 李自强, 李小英, 钟琦, 等.电感耦合等离子体质谱法测定土壤重金属普查样品中铬铜镉铅的关键环节研究[J].岩矿测试, 2016, 35(1):37-41. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.01.007
Li Z Q, Li X Y, Zhong Q, et al.Determination of Cr, Cu, Cd and Pb in soil samples by inductively coupled plasma-mass spectrometry for an investigation of heavy metal pollution[J].Rock and Mineral Analysis, 2016, 35(1):37-41. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.01.007
[19] 荆淼, 王其枫, 王艳萍, 等.电感耦合等离子体质谱法测定土壤中常规元素及稀土元素[J].环境化学, 2016, 35(11):2445-2446. http://www.cqvip.com/QK/95665X/201611/670720373.html
Jing M, Wang Q F, Wang Y P, et al.Detection of metallic elements and rare earth elements in soil by inductively coupled plasma-mass spectrometry[J].Environmental Chemistry, 2016, 35(11):2445-2446. http://www.cqvip.com/QK/95665X/201611/670720373.html
[20] 孙婧, 马丽, 杨兆光.混酸微波辅助萃取ICP-MS测定不同性质土壤中的重金属元素[J].环境化学, 2015, 34(6):1057-1063. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201506005
Sun J, Ma L, Yang Z G.Determination of heavy metal elements in various soils by microwave assisted extraction with acid mixture and ICP-MS[J].Environmental Chemistry, 2015, 34(6):1057-1063. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hjhx201506005
[21] 梁淑轩, 王欣, 吴虹, 等.微波消解/ICP-MS测定水系沉积物中的9种重金属元素[J].光谱学与光谱分析, 2012, 32(3):809-812. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gpxygpfx201203051
Liang S X, Wang X, Wu H, et al.Determination of 9 heavy metal elements in sediment by ICP-MS using microwave digestion for sample preparation[J].Spectroscopy and Spectral Analysis, 2012, 32(3):809-812. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gpxygpfx201203051
[22] 王志广, 陈发荣, 郑立, 等.微波消解-电感耦合等离子体质谱同时测定普里兹湾沉积物中微量元素[J].分析试验室, 2012, 31(8):50-54. http://www.cnki.com.cn/Article/CJFDTotal-FXSY201208015.htm
Wang Z G, Chen F R, Zheng L, et al.Simultaneous determination of trace elements in sediments of Prydz Bay by microwave digestion-inductively coupled plasma mass spectrometry[J].Chinese Journal of Analysis Laboratory, 2012, 31(8):50-54. http://www.cnki.com.cn/Article/CJFDTotal-FXSY201208015.htm
[23] 王君玉, 吴葆存, 李志伟, 等.敞口酸溶-电感耦合等离子体质谱法同时测定地质样品中45个元素[J].岩矿测试, 2011, 30(4):440-445. http://www.ykcs.ac.cn/article/id/ykcs_20110409
Wang J Y, Wu B C, Li Z W, et al.Determination of elemental content in geological samples by one-time acid dissolution and inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2011, 30(4):440-445. http://www.ykcs.ac.cn/article/id/ykcs_20110409
[24] 贾建丽, 于妍, 王晨.环境土壤学[M].北京:地质出版社, 2012:9-37.
Jia J L, Yu Y, Wang C.Environmental pedology[M].Beijing:Chemical Industry Press, 2012:9-37.
[25] 贾维斯K E, 格雷A L, 霍克R S(著).尹明, 李冰(译).电感耦合等离子体质谱手册[M].北京:原子能出版社, 1997:120-124.
Jarvis K E, Glay A L, Hawk R S (Editor).Yin M, Li B(Translator).Handbook of inductively coupled plasma-mass spectrometry[M].Beijing:Geological Publishing House, 1997:120-124.
[26] 《岩石矿物分析》编委会.岩石矿物分析(第四版第四分册)[M].北京: 地质出版社, 2011: 807-809.
[27] The editorial committee of Rock and Mineral Analysis.Rock and mineral analysis (The fourth edition:Vol.Ⅳ)[M].Beijing:Geological Publishing House, 2011:807-809.
-
