Application of High-temperature Methane Adsorption Experiment to Study the Adsorption Capacity of Methane in Shales from the Wufeng Formation, Northeast Sichuan
-
摘要: 页岩甲烷吸附能力是决定页岩气井开采方案的重要参数，对评估页岩气藏潜力意义重大。干酪根类型、总有机碳含量、矿物组成、成熟度和孔径等是影响页岩吸附性能的因素，但针对高温高压下过剩吸附现象对页岩甲烷吸附能力影响的研究还需开展进一步的探索。为揭示四川盆地东北地区五峰组页岩甲烷吸附能力，本文通过场发射扫描电镜、低温氮气吸附和高压甲烷吸附实验，研究了高温高压下页岩的甲烷吸附能力，并分析了页岩孔隙结构等对页岩吸附能力的影响。结果表明：①五峰组页岩孔隙结构非均质性强，发育有机孔隙、粒（晶）间孔隙、粒（晶）内孔隙和粒（晶）间溶孔等多种孔隙；②比表面积平均为19.1282m2/g；孔体积平均为0.0195cm3/g；孔径平均为5.2226nm；③修正后的饱和吸附气量为2.56m3/t；④五峰组页岩甲烷吸附性能受控于比表面积、孔体积；有机质含量越大、有机质热演化程度越低，其甲烷吸附性能越强；⑤孔隙结构是影响页岩甲烷吸附能力的重要内因。同时指出低压条件下的实验吸附曲线不适合直接评价页岩甲烷吸附能力。Abstract:
BACKGROUNDShale methane adsorption capacity is not only a significant parameter to determine the exploration and exploitation plan, but also a critical criterion to evaluate the potential of a shale gas reservoir. Types of kerogen, total organic carbon content, mineral composition, maturity, and pore size are factors that affect shale adsorption performance; however, not enough attention is being focused on the influence of excess adsorption under high temperature and high pressure on shale methane adsorption capacity. OBJECTIVESTo reveal the influence of excess adsorption under high temperature and high pressure on the adsorption capacity of methane from the Wufeng Formation shale in Northeast Sichuan. METHODSBased on methods of field emission scanning electron microscopy, low-temperature nitrogen adsorption test, and high-pressure methane adsorption test, the shale methane adsorption capacity under high temperature and pressure was studied, and the influence of shale pore structure on the shale adsorption capacity was analyzed. RESULTSThe types of pore structure in the Wufeng Formation shale were diverse, including organic, intergranular, intercrystalline, and intergranular dissolved pore. The average specific surface area was 19.1282m2/g, while average pore volume and pore diameters were 0.0195cm3/g and 5.2226nm, respectively. The corrected adsorption capacity of shale in the Wufeng Formation was 2.56m3/t. The Wufeng Formation shale methane adsorption performance was controlled by specific surface area and pore volume. The larger the organic matter content, the lower the thermal evolution of organic matter and the stronger its methane adsorption performance. Pore structure was an important internal factor affecting the shale methane adsorption capacity. CONCLUSIONSThe experimental adsorption curve under low pressure is not suitable for directly evaluating the shale methane adsorption capacity. -
Key words:
- Northeast Sichuan /
- the Wufeng Formation /
- shale /
- methane /
- adsorption capacity /
- pore /
- supercritical state
-
-
表 1 五峰组页岩样品的基础地球化学和矿物组分数据
Table 1. Basic geochemical and mineral composition data for shale samples, the Wufeng Formation
样品编号 有机碳含量(%) 镜质反射率(%) 矿物成分含量(%) 石英 长石 方解石 白云石 黄铁矿 伊利石 绿泥石 1 1.18 3.02 40.11 28.47 10.42 3.47 3.44 7.29 2.72 2 1.78 3.09 47.34 18.32 3.19 3.35 3.24 12.88 5.20 3 1.58 3.17 38.18 13.28 8.04 12.14 2.87 12.28 13.12 4 3.78 3.19 33.47 18.49 7.4 2.49 5.42 14.20 5.94 5 4.64 2.96 61.14 9.1 5.98 2.41 4.24 14.40 1.80 6 3.90 2.89 61.35 8.24 2.85 1.87 3.02 20.80 1.71 7 3.13 2.90 44.45 11.42 3.38 2.46 0.00 23.24 5.80 8 3.91 2.94 45.08 16.88 2.15 2.01 0.00 29.05 4.76
下载: 导出CSV
表 2 五峰组页岩氮气吸附-脱附测试结果
Table 2. Nitrogen adsorption-desorption test results of shale, the Wufeng Formation
样品编号 比表面积(m2/g) 孔体积(cm3/g) 平均孔径(nm) 1 10.1165 0.0121 6.0117 2 12.9502 0.0148 5.9612 3 12.8416 0.0181 6.4301 4 21.2751 0.0254 4.4651 5 22.1228 0.0226 4.3706 6 22.7677 0.0243 5.1415 7 24.3068 0.0211 5.0861 8 26.6449 0.0181 4.3146
下载: 导出CSV
-
[1] 位云生, 贾爱林, 何东博, 等.中国页岩气与致密气开发特征与开发技术异同[J].天然气工业, 2017, 37 (11):43-52. doi: 10.3787/j.issn.1000-0976.2017.11.006
Wei Y S, Jia A L, He D B, et al.Comparative analysis of development characteristics and technologies between shale gas and tight gas in China[J]. Natural Gas Industry, 2017, 37(11):43-52. doi: 10.3787/j.issn.1000-0976.2017.11.006
[2] 马永生, 蔡勋育, 赵培荣.中国页岩气勘探开发理论认识与实践[J].石油勘探与开发, 2018, 45(4):561-574. http://d.old.wanfangdata.com.cn/Periodical/syktykf201804003
Ma Y S, Cai X Y, Zhao P R.China's shale gas exploration and development:Understanding and practice[J]. Petroleum Exploration and Development, 2018, 45(4):561-574. http://d.old.wanfangdata.com.cn/Periodical/syktykf201804003
[3] 胡东风, 张汉荣, 倪楷, 等.四川盆地东南缘海相页岩气保存条件及其主控因素[J].天然气工业, 2014, 34(6):17-23. doi: 10.3787/j.issn.1000-0976.2014.06.003
Hu D F, Zhang H R, Ni K, et al.Main controlling factors for gas preservation conditions of marine shales in southeastern margins of the Sichuan Basin[J]. Natural Gas Industry, 2014, 34(6):17-23. doi: 10.3787/j.issn.1000-0976.2014.06.003
[4] 朱汉卿, 贾爱林, 位云生, 等.昭通示范区龙马溪组页岩微观孔隙结构特征及吸附能力[J].油气地质与采收率, 2018, 25(4):1-6. http://d.old.wanfangdata.com.cn/Periodical/yqdzycsl201804001
Zhu H Q, Jia A L, Wei Y S, et al.Characteristics of microscopic pore structure and methane adsorption capacity of shale in the Longmaxi Formation in the Zhaotong Area[J]. Petroleum Geology and Recovery Efficiency, 2018, 25(4):1-6. http://d.old.wanfangdata.com.cn/Periodical/yqdzycsl201804001
[5] 孙梦迪, 于炳松, 陈颂, 等.渝东南地区下寒武统牛蹄塘组页岩储层特征及甲烷吸附能力——以渝科1井和酉科1井为例[J].东北石油大学学报, 2015, 39(1):69-79. doi: 10.3969/j.issn.2095-4107.2015.01.009
Sun M D, Yu B S, Chen S, et al.The reservoir characteristics and adsorption capacity of the Lower Cambrian Niutitang Formation shale in southeast of Chongqing:A case study of Well Yuke1 and Well Youke1[J]. Journal of Northeast Petroleum University, 2015, 39(1):69-79. doi: 10.3969/j.issn.2095-4107.2015.01.009
[6] 魏志红, 魏祥峰.页岩不同类型孔隙的含气性差异——以四川盆地焦石坝地区五峰组—龙马溪组为例[J].天然气工业, 2014, 34(6):37-41. doi: 10.3787/j.issn.1000-0976.2014.06.006
Wei Z H, Wei X F.Comparison of gas-bearing property between different pore types of shale:A case from the Upper Ordovician Wufeng and Longmaxi Fms in the Jiaoshiba Area, Sichuan Basin[J]. Natural Gas Industry, 2014, 34(6):37-41. doi: 10.3787/j.issn.1000-0976.2014.06.006
[7] 王香增, 张丽霞, 李宗田, 等.鄂尔多斯盆地延长组陆相页岩孔隙类型划分方案及其油气地质意义[J].石油与天然气地质, 2016, 37(1):1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201601001
Wang X Z, Zhang L X, Li Z T, et al.Pore type classification scheme for continental Yanchang Shale in Ordos Basin and its geological significance[J]. Oil & Gas Geology, 2016, 37(1):1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201601001
[8] 曹茜, 周文, 陈文玲, 等.鄂尔多斯盆地南部延长组长7段陆相页岩气地层孔隙类型、尺度及成因分析[J].矿物岩石, 2015, 35(2):90-97. http://d.old.wanfangdata.com.cn/Periodical/kwys201502011
Cao Q, Zhou W, Chen W L, et al.Analysis of pore types, sizes and genesis in continental shale gas reservoir of Chang 7 of Yanchang Formation, Ordos Basin[J]. Journal of Mineral Petrology, 2015, 35(2):90-97. http://d.old.wanfangdata.com.cn/Periodical/kwys201502011
[9] 张廷山, 杨洋, 龚其森, 等.四川盆地南部早古生代海相页岩微观孔隙特征及发育控制因素[J].地质学报, 2014, 88(9):1728-1740. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201409009
Zhang Y S, Yang Y, Gong Q S, et al.Characteristics and mechanisms of the micro-pores in the Early Palaeozoic Marine Shale, Southern Sichuan Basin[J]. Acta Geologica Sinica, 2014, 88(9):1728-1740. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201409009
[10] 刘尧文, 王进, 张梦吟, 等.四川盆地涪陵地区五峰—龙马溪组页岩气层孔隙特征及对开发的启示[J].石油实验地质, 2018, 40(1):44-50. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201801007
Liu Y W, Wang J, Zhang M Y, et al.Pore features of shale gas layer in Wufeng—Longmaxi Formation in Fuling area of Sichun Basin and the application to development[J]. Petroleum Geology & Experiment, 2018, 40(1):44-50. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201801007
[11] 帅琴, 黄瑞成, 高强, 等.页岩气实验测试技术现状与研究进展[J].岩矿测试, 2012, 31(6):931-938. doi: 10.3969/j.issn.0254-5357.2012.06.003 http://www.ykcs.ac.cn/article/id/ykcs_20120604
Shuai Q, Huang R C, Gao Q, et al.Research development of analytical techniques for shale gas[J]. Rock and Mineral Analysis, 2012, 31(6):931-938. doi: 10.3969/j.issn.0254-5357.2012.06.003 http://www.ykcs.ac.cn/article/id/ykcs_20120604
[12] 白名岗, 夏响华, 张聪, 等.场发射扫描电镜及PerGeos系统在安页1井龙马溪组页岩有机质孔隙研究中的联合应用[J].岩矿测试, 2018, 37(3):225-234. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201803260030
Bai M G, Xia X H, Zhang C, et al.Study on shale organic porosity in the Longmaxi Formation, AnYe-1 Well using field emission-scanning electron microscopy and PerGeos system[J]. Rock and Mineral Analysis, 2018, 37(3):225-234. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201803260030
[13] 王羽, 金婵, 汪丽华, 等.应用氩离子抛光-扫描电镜方法研究四川九老洞组页岩微观孔隙特征[J].岩矿测试, 2015, 34(3):278-285. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2015.03.003
Wang Y, Jin C, Wang L H, et al.Characterization of pore structures of Jiulaodong Formation shale in the Sichuan Basin by SEM with Ar-ion milling[J]. Rock and Mineral Analysis, 2015, 34(3):278-285. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2015.03.003
[14] Gasparik M, Ghanizadeh A, Bertier P, et al.High-pressure methane sorption isotherms of black shales from the Netherlands[J]. Energy & Fuels, 2012, 26(8):4995-5004. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=0ec5ad23d44c09f6c58a54c78b57bf22
[15] Cheng M, Li G S, Chen L J, et al.Mechanisms analysis of shalegas supercritical adsorption and modeling of isorption adsorption[J]. Journal of China Coal Society, 2014, 39(Supplement1):179-183.
[16] Zhou L, Zhou Y P, Li M, et al.Experimental and modeling study of the adsorption of supercritical methane on a high surface activated carbon[J]. Langmuir, 2000, 16(14):5955-5959. doi: 10.1021/la991159w
[17] Zhang T W, Geoffrey S E, Stephen C R, et al.Effect of organic matter type and thermal maturity on methane adsorption in shale gas systems[J]. Organic Geochemistry, 2012, 47:120-131. doi: 10.1016/j.orggeochem.2012.03.012
[18] Ross D J K, Bustin R M.The importance of shale composition and pore structure upon gas storage potential of shale gas reservoirs[J]. Marine and Petroleum Geology, 2009, 26(6):916-927. doi: 10.1016/j.marpetgeo.2008.06.004
[19] Rahman M U, Kazi T G, Shaikh H, et al.Fractionation of manganese in soil samples collected from the Lakhra Coal Field in Pakistan using two modes of atomic absorption spectrometry[J]. Atomic Spectroscopy, 2018, 39(6):258-263.
[20] Lashari A A, Kazi T G, Ali J, et al.Evaluation of sequential extraction schemes for the ETAAS determination of cadmium concentrations in coal samples from the Thar Coalfield, Pakistan[J]. Atomic Spectroscopy, 2018, 39(5):203-209.
[21] Satyanarayanan M, Balaram V, Sawant S S, et al.Rapid determination of REEs, PGEs, and other trace elements in geological and environmental materials by high resolution inductively coupled plasma mass spectrometry[J]. Atomic Spectroscopy, 2018, 39(1):1-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=399d63251e1afd27679392d6e00fdd4d
[22] 王运海.四川盆地平桥地区五峰—龙马溪组页岩微观孔隙特征研究[J].石油实验地质, 2018, 40(3):337-344. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201803006
Wang Y H.Micro-pore characteristics of shale from Wufeng—Longmaxi Formations in Pingqiao area, Sichuan Basin[J]. Petroleum Geology & Experiment, 2018, 40(3):337-344. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201803006
[23] 胡华.黑色页岩中黄铁矿与有机质含量的关系及勘探意义[D].荆州: 长江大学.2017.
Hu H.Study on the Relationship of Pyrite and Content of Organic Matter in Marine Black Shale and Its Significance for Shale Gas Exploration[D]. Jingzhou: Yangtze University, 2017.
[24] 张景廉, 张平中.黄铁矿对有机质成烃的催化作用讨论[J].地球科学进展, 1996(3):282-287. doi: 10.3321/j.issn:1001-8166.1996.03.009
Zhang J L, Zhang P Z.A discussion of pyrite catalysis on the hydrocarbon generation process[J]. Advance in Earth Sciences, 1996(3):282-287. doi: 10.3321/j.issn:1001-8166.1996.03.009
[25] 马存飞, 董春梅, 栾国强, 等.苏北盆地古近系页岩有机质孔发育特征及影响因素[J].中国石油大学学报(自然科学版), 2017, 41(3):2-13. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sydxxb201703001
Ma C F, Dong C M, Luan G Q, et al.Characteristics and its influencing factors of organic-matter pores in Paleogene Shale, Subei Basin[J]. Journal of China University of Petroleum, 2017, 41(3):2-13. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sydxxb201703001
[26] 周理, 吕昌忠, 王怡林, 等.述评超临界温度气体在多孔固体上的物理吸附[J].化学进展, 1999, 11(3):221-226. doi: 10.3321/j.issn:1005-281X.1999.03.001
Zhou L, Lü C Z, Wang Y L, et al.Physisorption of gases on porous solids at above-critical temperatures[J]. Progess in Chemistry, 1999, 11(3):221-226. doi: 10.3321/j.issn:1005-281X.1999.03.001
[27] Chalmers G R L, Bustin R M.The organic matter distribution and methane capacity of the Lower Cretaceous strata of Northeastern British Columbia, Canada[J]. International Journal of Coal Geology, 2007, 70(1-3):223-239. doi: 10.1016/j.coal.2006.05.001
[28] Chalmers G R, Bustin R M, Power I M.Characterization of gas shale pore systems by porosimetry, pycnometry, surface area, and field emission scanning electron microscopy/transmission electron microscopy image analyses:Examples from the Barnett, Woodford, Haynesville, Marcellus, and Doig units[J]. AAPG Bulletin, 2012, 96(6):1099-1119. doi: 10.1306/10171111052
[29] 周尚文, 李奇, 薛庆华, 等.页岩容量法和重量法等温吸附实验对比研究[J].化工进展, 2017, 36(5):1690-1697. http://d.old.wanfangdata.com.cn/Periodical/hgjz201705020
Zhou S W, Li Q, Xue Q H, et al.Comparative study on the volumetric and gravimetric method for isothermal adsorption experiment of shale[J]. Chemical Industry and Engineering Progress, 2017, 36(5):1690-1697. http://d.old.wanfangdata.com.cn/Periodical/hgjz201705020
[30] Bose T K, Chahine R, Marchildon L, et al.New dielectric method for the measurement of physical adsorption of gases at high pressure[J]. Review of Scientific Instruments, 1987, 58(12):2279-2283. doi: 10.1063/1.1139336
[31] 鲍云杰, 邓模, 翟常博, 等.页岩对甲烷的吸附作用及其固气效应初步研究——以渝东南残留向斜为例[J].石油实验地质, 2016, 38(4):509-513. http://d.old.wanfangdata.com.cn/Periodical/sysydz201604014
Bao Y J, Deng M, Zhai C B, et al.Methane adsorption and sealing effects of shale—A case study of relict synclines in the Southeastern Chongqing[J]. Petroleum Geology & Experiment, 2016, 38(4):509-513. http://d.old.wanfangdata.com.cn/Periodical/sysydz201604014
[32] 张晓明, 石万忠, 舒志国, 等.涪陵地区页岩含气量计算模型及应用[J].地球科学——中国地质大学学报, 2017, 42(7):1157-1168. http://d.old.wanfangdata.com.cn/Periodical/dqkx201707012
Zhang X M, Shi W Z, Shu Z G, et al.Calculation model of shale gas content and its application in Fuling Area[J]. Editorial Committee of Earth Science—Journal of China University of Geosciences, 2017, 42(7):1157-1168. http://d.old.wanfangdata.com.cn/Periodical/dqkx201707012
[33] 朱汉卿, 贾爱林, 位云生, 等.蜀南地区富有机质页岩孔隙结构及超临界甲烷吸附能力[J].石油学报, 2018, 39(4):391-401. http://d.old.wanfangdata.com.cn/Periodical/syxb201804003
Zhu H Q, Jia A L, Wei Y S, et al.Pore structure and supercritical methane sorption capacity of organic-rich shales in Southern Sichuan Basin[J]. Acta Petrolei Sinica, 2018, 39(4):391-401. http://d.old.wanfangdata.com.cn/Periodical/syxb201804003
[34] 吴艳艳, 曹海虹, 丁安徐, 等.页岩气储层孔隙特征差异及其对含气量影响[J].石油实验地质, 2015, 37(2):231-236. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201502016
Wu Y Y, Cao H H, Ding A X, et al.Pore characteristics of a shale gas reservoir and its effect on gas content[J]. Petroleum Geology & Experiment, 2015, 37(2):231-236. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201502016
[35] 赵靖舟, 王芮, 耳闯.鄂尔多斯盆地延长组长7段暗色页岩吸附特征及其影响因素[J].地学前缘, 2016, 23(1):146-153. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201601013
Zhao J Z, Wang R, Er C.Adsorption characteristics of Chang 7 shale from the Triassic Yanchang Formation in Ordos Basin, and its controlling factor[J]. Earth Science Frontiers, 2016, 23(1):146-153. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201601013
[36] 郭少斌, 翟刚毅, 包书景, 等.干酪根及黏土单矿物对甲烷吸附能力的差异性[J].石油实验地质, 2017, 39(5):682-693. http://d.old.wanfangdata.com.cn/Periodical/sysydz201705014
Guo S B, Zhai G Y, Bao S J, et al.Difference of methane adsorption capacity of kerogen and clay minerals[J]. Petroleum Geology & Experiment, 2017, 39(5):682-693. http://d.old.wanfangdata.com.cn/Periodical/sysydz201705014
-
