Determination of Boron in Geological Samples by ICP-OES with Low-pressure Closed Digestion
-
摘要: 采用酸溶-电感耦合等离子体发射光谱法（ICP-OES）测定地质样品中的全硼量，关键环节在于如何防止样品消解过程中硼元素的损失，降低测量过程中的基体干扰、光谱干扰和记忆效应。基于以上问题，本文采用氢氟酸-硝酸-高氯酸-磷酸在低压密闭溶样罐中消解样品，溶出的硼元素与少量磷酸充分络合，防止硼的挥发损失；以基体及主成分浓度与样品相类似的地质类固体标准物质绘制标准曲线做线性校准，有效匹配和降低样品的基体干扰；采用仪器自带的操作软件，观察分析谱线附近是否存在其他元素的干扰，来确定背景扣除最佳的位置及宽度，降低ICP-OES测量中的光谱干扰；以10%的王水作为进样系统的冲洗液，有效消减测量过程中的记忆效应。当稀释因子为200时，方法的检出限（3SD）为1.2μg/g，定量限（10SD）为4.0μg/g；用岩石、土壤及水系沉积物国家一级标准物质对精密度及准确度进行分析验证，11次测定相对标准偏差为1.8%~7.9%，相对误差为-3.6%~6.3%；以外检分析结果为参考，对硼含量在定量限以上的样品测定，相对误差为-9.3%~12.5%。Abstract:
BACKGROUND Total boron in geological samples is determined by inductively coupled plasma-optical emission spectroscopy (ICP-OES) with acid digestion. The key steps are preventing the loss of boron during the sample digestion stage and reducing matrix interference, spectral interference and memory effect during measurement. OBJECTIVES To establish a method for the determination of boron in geological samples by ICP-OES with low-pressure closed digestion. METHODS Using HF-HNO3-HClO4-H3PO4 to digest samples in a low-pressure closed sample tank, the dissolved boron element is fully complexed with a small amount of phosphoric acid to prevent the volatilization loss of boron. The standard curve was calibrated using the geological solid standard material with similar concentration of matrix and major components to effectively match and reduce the matrix interference of the sample. The operating software provided by the instrument was used to observe and analyze the interference of other elements near the spectral line and to determine the best position and width of background subtraction to reduce the spectral interference in the ICP-OES measurement. 10% Aqua regia was used as the rinsing liquid of the sample introduction system, which effectively reduced the memory effect during measurement. RESULTS When the dilution factor was 200, the detection limit (3SD) was 1.2μg/g, and the quantitative limit (10SD) was 4.0μg/g. The precision and accuracy were analyzed and verified by using the national first-class standard substances in rock, soil and river sediment, the relative standard deviations (n=11) were from 1.8% to 7.9%, and the relative errors were from -3.6% to 6.3%. Compared with the results of external tests, the relative error of boron content above the quantitative limit ranged from -9.3% to 12.5%. CONCLUSIONS The method is suitable for the accurate measurement of boron above 4.0μg/g in geological samples. -
-
表 1 ICP-OES仪器工作条件
Table 1. Working conditions of the ICP-OES instrument
工作参数 设定条件 发射功率 1150W 重复测量次数 1次 分析泵速 50r/min 冲洗泵速 100r/min 泵稳定时间 5s 雾化器气体流量 0.5L/min 辅助气流量 0.5L/min 冲洗时间 20s 短波积分时间 15s 长波积分时间 5s 垂直观测高度 12mm
下载: 导出CSV
表 2 固体标准物质绘制的标准曲线的回归方程及线性相关系数
Table 2. Regression equation and linear coefficient of standard curve drawn by solid reference material
硼元素分析谱线 回归方程 线性相关系数 B(λ=249.678nm) y=1970.1x+25.271 r=0.9993 B(λ=208.893nm) y=506.95x+12.634 r=0.9998 B(λ=208.959nm) y=961.5x+16.561 r=0.9996
下载: 导出CSV
表 3 方法精密度和准确度
Table 3. Precision and accuracy tests of the method
标准物质
编号硼含量(μg/g) RSD
(%)相对误差
(%)认定值 11次分次测量值 平均值 GBW07104 4.7±0.8 4.9 5.1 4.5 4.2 4.1 4.4
5.2 4.8 4.4 4.6 4.34.6 7.9 -2.1 GBW07108 16±4 17 18 17 17 15 16
17 16 17 18 1617 5.3 6.3 GBW07405 53±6 56 54 57 56 55 57
55 56 54 56 5556 1.8 5.7 GBW07453 83±7 80 79 80 78 79 82
79 81 82 81 7880 1.8 -3.6 GBW07386 60±3 59 58 59 61 60 58
59 61 58 57 5959 2.1 -1.7 GBW07307 143±16 139 142 141 137 138 141
142 148 145 140 144142 2.3 -0.7 GBW07309 54±6 52 54 51 52 55 51
53 55 52 51 5353 2.8 -1.9 GBW07304a 91±5 88 92 87 89 86 89
93 88 87 90 8989 2.4 -2.2
下载: 导出CSV
表 4 地质样品分析
Table 4. Analytical results of geological samples
样品编号 硼含量(μg/g) 相对误差
(%)本法分析结果 外检分析结果 BZ-1 45.8 43.5 5.3 BZ-2 30.5 32.9 -7.3 BZ-3 37.7 35.8 5.3 BZ-4 12.5 11.2 11.6 BZ-5 4.5 4.0 12.5 BZ-6 322 314 2.5 BZ-7 61.3 58.8 4.3 BZ-8 16.5 18.2 -9.3 BZ-9 10.4 9.5 9.5 BZ-10 2.4 1.9 26.3 注：外检分析数据为电感耦合等离子体发射光谱法测定结果。
下载: 导出CSV
-
[1] 《岩石矿物分析》编委会.岩石矿物分析(第四版第二分册)[M].北京:地质出版社, 2011:376-381.
The editorial committee of Rock and Mineral Analysis.Rock and mineral analysis (The fourth edition:Vol.Ⅱ)[M].Beijing:Geological Publishing House, 2011:376-381.
[2] 闫春燕, 伊文涛, 马培华, 等.微量硼的测定方法研究进展[J].理化检验(化学分册), 2008, 44(2):197-201. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=lhjy-hx200802040
Yan C Y, Yi W T, Ma P H, et al.Recent progress of methods for determination of micro-amounts of boron[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis), 2008, 44(2):197-201. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=lhjy-hx200802040
[3] 曹成东, 魏轶, 刘江斌.发射光谱法同时测定地球化学样品中微量银铍硼锡铋钼[J].岩矿测试, 2010, 29(4):458-460. http://www.ykcs.ac.cn/article/id/ykcs_20100427
Cao C D, Wei Y, Liu J B.Simultaneous determination of trace silver, beryllium, boron, tin, bismuth and molybdenum in geochemical samples by emission spectrometry[J].Rock and Mineral Analysis, 2010, 29(4):458-460. http://www.ykcs.ac.cn/article/id/ykcs_20100427
[4] 郝志红, 姚建贞, 唐瑞玲, 等.直流电弧全谱直读原子发射光谱法(DC-Arc-AES)测定地球化学样品中痕量硼、钼、银、锡、铅的方法研究[J].光谱学与光谱分析, 2015, 35(2):527-533. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gpxygpfx201502055
Hao Z H, Yao J Z, Tang R L, et al.Study on the method for determination of trace boron, molybdenum, silver, tin and lead in geochemical samples by direct current arc full spectrum direct reading reading atomic emission spectrometry (DC-Arc-AES)[J].Spectroscopy and Spectral Analysis, 2015, 35(2):527-533. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gpxygpfx201502055
[5] 郭颖超, 张晓敏, 姚福存, 等.CCD-Ⅰ型平面光栅电弧直读发射光谱仪测定地球化学样品中银锡硼[J].黄金, 2016, 37(10):85-88. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysjswz201704045
Guo Y C, Zhang X M, Yao F C, et al.Determination of silver, tin and boron in geochemical samples by CCD-Ⅰ plane grating electric arc direct reading emission spectrometer[J].Gold, 2016, 37(10):85-88. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysjswz201704045
[6] 肖细炼, 王亚夫, 陈燕波, 等.交流电弧光电直读发射光谱法测定地球化学样品中银硼锡[J].冶金分析, 2018, 38(7):27-32. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201807004
Xiao X L, Wang Y F, Chen Y B, et al.Determination of silver, boron and tin in geochemical samples by alternating current arc optoelectronic direct reading emission spectrometry[J].Metallurgical Analysis, 2018, 38(7):27-32. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201807004
[7] 孙慧莹, 李小辉, 朱少旋, 等.原子发射光谱法测定地球化学样品中银、锡、硼的含量[J].理化检验(化学分册), 2019, 55(10):1231-1234. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=lhjy-hx201910024
Sun H Y, Li X H, Zhu S X, et al.Determination of silver, tin and boron in geochemical samples by atomic emission spectrometry[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis), 2019, 55(10):1231-1234. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=lhjy-hx201910024
[8] Zeibig G.Determination of total, leachable and mobile boron in sedimentary rocks by ICP-AES[J].Mikrochimica Acta, 1989, 99(3):389-397. http://link.springer.com/article/10.1007/BF01244695
[9] Lihareva N, Kosturkova P, Vakarelska T.Application of sodium carbonate-zinc oxide decomposition mixture on ICP-AES determination of boron in tourmaline[J].Fresenius' Journal of Analytical Chemistry, 2000, 367(1):84-86. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=f67c2e1f6ab3a60f95159d7f7a5c802a
[10] Peng Z K, Liu Z N.Accurate determination of boron content in halite by ICP-OES and ICP-MS[J].International Journal of Analytical Chemistry, 2019:1-5. http://www.researchgate.net/publication/333474550_Accurate_Determination_of_Boron_Content_in_Halite_by_ICP-OES_and_ICP-MS
[11] 李冰, 马新荣, 杨红霞, 等.封闭酸溶-电感耦合等离子体原子发射光谱法同时测定地质样品中硼砷硫[J].岩矿测试, 2003, 22(4):241-247. http://www.ykcs.ac.cn/article/id/ykcs_20030465
Li B, Ma X R, Yang H X, et al.Determination of boron, arsenic and sulfur in geological samples by inductively coupled plasma atomic emission spectrometry with sample treatment by pressurized decomposition[J].Rock and Mineral Analysis, 2003, 22(4):241-247. http://www.ykcs.ac.cn/article/id/ykcs_20030465
[12] Kataoka H, Okamoto Y, Tsukahara S, et al.Separate vaporisation of boric acid and inorganic boron from tungsten sample cuvette-tungsten boat furnace followed by the detection of boron species by inductively coupled plasma mass spectrometry and atomic emission spectrometry (ICP-MS and ICP-AES)[J].Analytica Chimica Acta, 2008, 610(2):179-185. doi: 10.1016/j.aca.2008.01.043
[13] 顾继红, 于媛君, 王赫男, 等.电感耦合等离子体原子发射光谱法测定高炉渣中硼[J].冶金分析, 2008, 28(6):19-23. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx200806004
Gu J H, Yu Y J, Wang H N, et al.Determination of boron in blast furnace slag by inductively coupled plasma atomic emission spectrometry[J].Metallurgical Analysis, 2008, 28(6):19-23. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx200806004
[14] 武明丽.ICP-AES法测定土壤样品中的硼[J].山东化工, 2011, 40(7):48-49. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xdkxyq201602026
Wu M L.Determination of boron in soil by ICP-AES[J].Shandong Chemical Industry, 2011, 40(7):48-49. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xdkxyq201602026
[15] 辛文彩, 林学辉, 徐磊.ICP-AES测定海洋沉积物中的硼[J].现代仪器, 2011, 17(5):91-92. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xdyq201105030
Xin W C, Lin X H, Xu L.Determination of boron in marine sediments by ICP-AES[J].Modern Instruments, 2011, 17(5):91-92. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xdyq201105030
[16] 赵志飞, 陈芝桂, 唐兴敏, 等.全谱直读等离子体发射光谱法测定土壤中的硼[J].资源环境与工程, 2012, 26(6):638-640. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbdk201206019
Zhao Z F, Chen Z G, Tang X M, et al.Determination of boron in soil samples by inductively coupled plasma optical emission spectrometry[J].Resources Environment and Engineering, 2012, 26(6):638-640. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbdk201206019
[17] Turner B L, Bielnicka A, Dalling J W, et al.Interference by iron in the determination of boron by ICP-OES in mehlich-Ⅲ extracts and total element digests of tropical forest soils[J].Communications in Soil Science and Plant Analysis, 2016, 47(21):2378-2386. doi: 10.1080/00103624.2016.1228952
[18] 王佳翰, 汤凯, 龙军桥, 等.敞开消解-ICP-OES同时测定地球化学样品中硫、磷、砷、硼[J].化学试剂, 2018, 40(1):53-56. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=huaxsj201801011
Wang J H, Tang K, Long J Q, et al.Simultaneous determination of sulfur, phosphorus, arsenic, and boron in geochemical samples by ICP-OES with open digestion[J].Chemical Reagent, 2018, 40(1):53-56. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=huaxsj201801011
[19] 肖凡, 张宁, 姜云军, 等.密闭酸溶-电感耦合等离子体原子发射光谱法测定地球化学调查样品中硼[J].冶金分析, 2018, 38(6):50-54. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201806009
Xiao F, Zhang N, Jiang Y J, et al.Determination of boron in geochemical survey samples by inductively coupled plasma atomic emission spectrometry after acid dissolution in closed system[J].Metallurgical Analysis, 2018, 38(6):50-54. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201806009
[20] 张军.ICP-AES测定农用地土壤详查深层土中的硼[J].广州化工, 2019, 47(7):110-111. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gzhg201907042
Zhang J.Determination of boron in deep soil of agricultural soil by ICP-AES[J].Guangzhou Chemical Industry, 2019, 47(7):110-111. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gzhg201907042
[21] 魏双, 王力强, 郑智慷, 等.微波消解-电感耦合等离子体发射光谱仪测定土壤样品中的硼[J].地质调查与研究, 2019, 42(4):256-258. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=qhwjyjjz201904003
Wei S, Wang L Q, Zheng Z K, et al.Determination of Boron in soils by microwave digester and ICP-OES[J]. Geological Survey and Research, 2019, 42(4):256-258. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=qhwjyjjz201904003
[22] 姚海云, 鲁红仙, 黎金标.同位素稀释等离子体质谱法测定地质样品中痕量硼[J].分析测试学报, 2006, 25(1):73-76. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxcsxb200601019
Yao H Y, Lu H X, Li J B.Determination of trace boron in geological samples by isotope dilution-inductively coupled plasma mass spectrometry[J].Journal of Instrumental Analysis, 2006, 25(1):73-76. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxcsxb200601019
[23] 赵玲, 冯永明, 李胜生, 等.碱熔-电感耦合等离子体质谱法测定化探样品中硼和锡[J].岩矿测试, 2010, 29(4):355-358. http://www.ykcs.ac.cn/article/id/ykcs_20100406
Zhao L, Feng Y M, Li S S, et al.Determination of boron and tin in geochemical exploration samples by inductively coupled plasma mass spectrometry with alkali fusion sample preparation[J].Rock and Mineral Analysis, 2010, 29(4):355-358. http://www.ykcs.ac.cn/article/id/ykcs_20100406
[24] 宋伟娇, 代世峰, 赵蕾, 等.微波消解-电感耦合等离子体质谱法测定煤中的硼[J].岩矿测试, 2014, 33(3):327-331. http://www.ykcs.ac.cn/article/id/578312dc-f30f-4dd0-94f7-ab986acd1de0
Song W J, Dai S F, Zhao L, et al.Determination of boron in coal samples with microwave digestion by inductively coupled plasma mass spectrometry[J].Rock and Mineral Analysis, 2014, 33(3):327-331. http://www.ykcs.ac.cn/article/id/578312dc-f30f-4dd0-94f7-ab986acd1de0
[25] 杨贤, 张洁, 蔡金芳, 等.电感耦合等离子体质谱法测定地质样品中硼[J].冶金分析, 2014, 34(6):7-10. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201406002
Yang X, Zhang J, Cai J F, et al.Determination of boron in geological samples by inductively coupled plasma mass spectrometry[J].Metallurgical Analysis, 2014, 34(6):7-10. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yjfx201406002
[26] Al-Ammar A, Reitznerová E, Barnes R M.Improving boron isotope ratio measurement precision with quadrupole inductively coupled plasma-mass spectrometry[J].Spectrochimica Acta Part B:Atomic Spectroscopy, 2000, 55(12):1861-1867. doi: 10.1016/S0584-8547(00)00282-2
[27] Menard G, Vlastélic I, Ionov D A, et al.Precise and accurate determination of boron concentration in silicate rocks by direct isotope dilution ICP-MS:Insights into the B budget of the mantle and B behavior in magmatic systems[J].Chemical geology, 2013, 354:139-149. doi: 10.1016/j.chemgeo.2013.06.017
[28] Liu T, He T, Shi Q H, et al.Rapid determination of boron in 61 soil, sediment, and rock reference materials by ICP-MS[J].Atomic Spectroscopy, 2019, 40(2):55-62. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=5dae844eaeb03a5d91c96fae96ae0345
-
