摘要:
锂(Li)和硼(B)同位素是地质作用过程中良好的示踪剂，被广泛应用于岩石起源、矿床成因和环境演化等领域。但锂、硼在MC-ICP-MS仪器分析中的“记忆效应”明显，不同实验室已报道的MC-ICP-MS分析中锂、硼背景占信号比变化范围大(0.01%～5%)，所采用的背景控制方法和效果也各不相同，因此给锂、硼同位素的准确测定带来困难。为研究MC-ICP-MS锂、硼同位素记忆效应及其抑制方案，提高测试的稳定性，本文参考前人研究成果，设计不同背景清洗方案，并对各种国际标样(IRMM-016、JG-2、ERM-AE121、ERM-AE122、NASS-7)和实验室内部标准(Alfa Li、Alfa B)进行长期测试，检验实验方案的长期重现性。结果表明：仅使用0.3%氯化钠溶液清洗背景可以显著降低锂背景信号，从20mV下降至4mV，并保证7Li背景值在24h内低于5mV，实验室内部标准溶液Alfa Li的δ7Li长期测试外精度为0.13‰(2SD，n=73)。氟化钠、氨水等清洗液并不能显著降低本研究所使用仪器的硼背景，因此选择使用灵活的空白扣除方法来保证数据稳定性。实验室内部标准溶液Alfa B的δ11B长期测试外精度为0.19‰(2SD，n=60)。本文锂、硼同位素国际标样的测试结果与前人数据在误差范围内一致，证明了实验结论的可靠性。
Abstract:Lithium (Li) and boron (B) isotopes are excellent tracers in geological processes. In order to study and eliminate the memory effects of lithium and boron element in isotopic measurements using MC-ICP-MS, different background rinsing protocols were designed with reference to previous research. The δ7Li and δ11B values of different types of reference materials were tested to evaluate the long-term reproducibility of the measurements using designated rinsing protocols for at least six months. The results show that using only 0.3% NaCl solution to clean the background for 60s can significantly reduce the lithium background signal and ensure the 7Li background signal is less than 5mV within 24h. The long-term external precision of δ7Li values for Alfa Li, an in-house standard, was 0.13‰ (2SD, n=73). Rinsing solutions, such as NAF and NH3·H2O could not significantly reduce the boron background of the instrument. However, the flexible blank subtracting method was used for precise determination of δ11B values. The long-term external precision of δ11B values for Alfa B was 0.19‰ (2SD, n=60). The average δ7Li and δ11B values of different types of reference materials were tested using these rinsing protocols, and the results were well consistent with reported data, supporting the applicability of the conclusions. The BRIEF REPORT is available for this paper at
http://www.ykcs.ac.cn/en/article/doi/10.15898/j.ykcs.202310260167 .-
Key words:
- memory effect /
- lithium /
- boron /
- MC-ICP-MS /
- 0.3% NaCl solution /
- blank deduction
-
-
图 2 5%氯化钠溶液清洗背景60s后，在正常测试过程中样品7Li灵敏度(200ng/g)、7Li背景(a)和7Li/6Li 测试内精度(SE)(b)的变化
Figure 2.
图 7 标准样品EPM-AE 121(a)、EPM-AE 122(b)、Alfa B(c)和NASS-7(d)相对于NIST951a的δ11B测定值及其参考值
Figure 7.
表 1 Nu Sapphire MC-ICP-MS仪器基本配置
Table 1. Basic configuration of the Nu Sapphire MC-ICP-MS instrument
工作参数 实验条件 工作参数 实验条件 射频功率 1300W 炬管 石英炬管 加速电压 6000V，高能模式 雾化器气体(Ar)压力 ～30psi 冷却气(Ar)流速 13L/min 锥 镍锥，湿锥 辅助气(Ar)流速 0.9～1.0L/min 接收器设置 H6-11B；L6-10B
H9-6Li；L6-7Li雾化器及流速 玻璃雾化器，PFA雾化器，100/50μL/min 分辨率 低分辨
下载: 导出CSV
表 2 标准物质锂同位素组成测定值与参考值
Table 2. The measured and reported δ7LiL-SVEC values of standards
标准物质 δ7LiL-SVEC参考值
(‰)δ7LiL-SVEC测试值
(‰)2SD
(‰)n IRMM-016 −0.17～0.40a 0.12 0.07 50 USTC-Li −19.30b −19.37 0.12 56 Alfa Li − 13.71 0.13 73 JG-2 0.15～0.32c 0.13 0.11 12 注：“−”表示无参考值。Alfa Li为实验室内部标准溶液，无参考值。a. IRMM-016的δ7LiL-SVEC参考值来源于GeoReM(Geological and Environmental Reference Materials)数据库及对应参考文献，仅统计MC-ICP-MS测试结果。b. USTC-Li 的δ7LiL-SVEC参考值由中国科技大学肖益林教授提供。c. JG-2的δ7LiL-SVEC参考值来源于Bouman等(2004)［30］、Jeffcoate等(2004)［15］、Li 等(2019)［31］、Lin等(2016)［32］和Zhu等(2020)［33］。
Note:“−” indicates the absence of a reference value. Alfa Li serves as the internal standard solution in the laboratory，and no reference value is available. a. The δ7LiL-SVEC reference value of IRMM-016 is derived from the Geological and Environmental Reference Materials (GeoReM) database and corresponding references，considering only the MC-ICP-MS test results. b. The δ7LiL-SVEC reference value of USTC-Li is provided by Professor Xiao Yilin from the University of Science and Technology of China. c. The δ7LiL-SVEC reference values of JG-2 are derived from Bouman et al. (2004) [30］，Jeffcoate et al. (2004) ［15］，Li et al. (2019) ［31］，Lin et al. (2016) ［32］ and Zhu et al. (2020) ［33］.
下载: 导出CSV
表 3 标准物质硼同位素组成测定值与参考值
Table 3. The determined values and reference values of the B isotope composition in the reference materials
标准物质 δ11BNIST951参考值
(‰)δ11BNIST951a测试值
(‰)2SD
(‰)n ERM-AE121 19.54～20.33a 19.78 0.31 64 ERM-AE122 39.3～39.74a 39.54 0.33 36 Alfa B − −4.66 0.19 60 海水标样NASS-7 − 40.03 0.33 35 天然海水 39.98±0.35b − − − 天然海水 39.45～40.26b − − − 海水标样NASS-2 39.63～39.90c − − − 海水标样NASS-5 39.40～39.89c − − − 海水标样NASS-6 39.41～39.81c − − − 注：“−”表示无参考值。Alfa B为实验室内部标准溶液，无参考值。a. ERM-AE121和ERM-AE122的δ11BNIST 951参考值来自GeoReM数据库及对应参考文献。数据包括了样品相对于NIST SRM951和NIST SRM951a的参考值。b. 天然海水δ11BNIST 951参考值引自Chen等(2019)［27］及其中参考文献。c. NASS系列海水δ11BNIST 951参考值引自GeoReM数据库及对应参考文献。
Note: “−” indicates the absence of a reference value. Alfa B is a laboratory standard solution without a designated reference value. a. The δ11BNIST 951 reference values of ERM-AE121 and ERM-AE122 are from the GeoReM database and corresponding references. The data include reference values of the sample with respect to NIST SRM951 and NIST SRM951a. b. The reference value of δ11BNIST 951 in natural seawater is cited from Chen et al. (2019) ［27］ and other references. c. The reference value of δ11BNIST 951 for NASS series seawater is sourced from the GeoReM database and corresponding references.
下载: 导出CSV
-
[1] 万红琼, 孙贺, 刘海洋, 等. 俯冲带锂同位素地球化学: 回顾与展望[J]. 地学前缘, 2015, 22(5): 29−43. doi: 10.13745/j.esf.2015.05.002
Wan H Q, Sun H, Liu H Y, et al. Li isotope geochemistry in subduction zones: Review and prospect[J]. Earth Science Frontiers, 2015, 22(5): 29−43. doi: 10.13745/j.esf.2015.05.002
[2] 陆一敢, 肖益林, 王洋洋, 等. 锂同位素在矿床学中的应用: 现状与展望[J]. 地球科学, 2021, 46(12): 4346−4365. doi: 10.3799/dqkx.2020.390
Lu Y G, Xiao Y L, Wang Y Y, et al. Exploration of Li isotope in application of ore deposits[J]. Earth Science, 2021, 46(12): 4346−4365. doi: 10.3799/dqkx.2020.390
[3] Penniston-Dorland S, Liu X M, Rudnick R L. Lithium isotope geochemistry[J]. Reviews in Mineralogy and Geochemistry, 2017, 82(1): 165−217. doi: 10.2138/rmg.2017.82.6
[4] 郭顺. 俯冲-碰撞带硼循环[J]. 矿物岩石地球化学通报, 2021, 40(5): 1049−1060, 997. doi: 10.19658/j.issn.1007-2802.2021.40.063
Guo S. Boron cycling in subduction-collision zones[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2021, 40(5): 1049−1060, 997. doi: 10.19658/j.issn.1007-2802.2021.40.063
[5] 李银川, 董戈, 雷昉, 等. 硼同位素分馏的实验理论认识和矿床地球化学研究进展[J]. 地学前缘, 2020, 27(3): 14−28. doi: 10.13745/j.esf.sf.2020.4.43
Li Y C, Dong G, Lei F, et al. Experimental and theoretical understanding of boron isotope fractionation and advances in ore deposit geochemistry study[J]. Earth Science Frontiers, 2020, 27(3): 14−28. doi: 10.13745/j.esf.sf.2020.4.43
[6] 张艳灵, 肖应凯, 马云麒, 等. 鹿角珊瑚硼同位素组成与海水表面pH值的相关性研究[J]. 分析化学, 2019, 47(1): 138−146. doi: 10.19756/j.issn.0253-3820.181516
Zang Y L, Xiao Y K, Ma Y Q, et al. Study on the correlation between boron isotope composition of Acropora staghorn and water surface pH value[J]. Chinese Journal of Analytical Chemistry, 2019, 47(1): 138−146. doi: 10.19756/j.issn.0253-3820.181516
[7] 刘明亮, 正安婷, 尚建波, 等. 高温地热流体中硼的地球化学研究进展[J]. 地球科学, 2023, 48(3): 878−893. doi: 10.3799/dqkx.2022.235
Liu M L, Zheng A T, Shang J B, et al. Research progress of boron geochemistry in high-temperature geothermal fluids[J]. Earth Science, 2023, 48(3): 878−893. doi: 10.3799/dqkx.2022.235
[8] 李慧芳, 马云麒, 李丽娟, 等. 热电离质谱法测定锂同位素的研究进展[J]. 盐湖研究, 2014, 22(4): 50−56.
Li H F, Ma Y Q, Li L J, et al. Research progress of lithium isotope determination by thermoelectric ionization mass spectrometry[J]. Journal of Salt Lake Research, 2014, 22(4): 50−56.
[9] 韦刚健, Graham Mortimer, Malcolm McCulloch. 珊瑚高精度硼同位素组成分析: PTIMS与NTIMS方法的对比研究[J]. 地球化学, 2009, 38(2): 114−122. doi: 10.19700/j.0379-1726.2009.02.002
Wei G J, Mortimer G, McCulloch M. Measurement of high-precision boron isotopic compositions in coral samples: Comparison between PTlMS and NTIMS methods[J]. Geochimica, 2009, 38(2): 114−122. doi: 10.19700/j.0379-1726.2009.02.002
[10] 赵悦, 侯可军, 田世洪, 等. 常用锂同位素地质标准物质的多接收器电感耦合等离子体质谱分析研究[J]. 岩矿测试, 2015, 34(1): 28−39. doi: 10.15898/j.cnki.11-2131/td.2015.01.006
Zhao Y, Hou K J, Tian S H, et al. Study on measurements of lithium isotopic compositions for common standard reference materials using multi-collector inductively coupled plasma-mass spectrometry[J]. Rock and Mineral Analysis, 2015, 34(1): 28−39. doi: 10.15898/j.cnki.11-2131/td.2015.01.006
[11] 张俊文, 孟俊伦, 赵志琦, 等. 多接收电感耦合等离子质谱法准确测定天然地质样品中的锂同位素组成[J]. 分析化学, 2019, 47(3): 415−422. doi: 10.19756/j.issn.0253-3820.181444
Zhang J W, Meng J L, Zhao Z Q, et al. Multireceiver inductively coupled plasma mass spectrometry for accurate determination of lithium isotope composition in natural geological samples[J]. Chinese Journal of Analytical Chemistry, 2019, 47(3): 415−422. doi: 10.19756/j.issn.0253-3820.181444
[12] 蔺洁, 刘勇胜, 胡兆初, 等. MC-ICP-MS准确测定地质样品中锂同位素组成[J]. 矿物岩石地球化学通报, 2016, 35(3): 458−464. doi: 10.3969/j.issn.1007-2802.2016.03.008
Lin J, Liu Y S, Hu Z C, et al. Accurate analysis of lithium isotopic composition of geological samples by MC-ICP-MS[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2016, 35(3): 458−464. doi: 10.3969/j.issn.1007-2802.2016.03.008
[13] 李子夏, 逯海. 一步离子交换-多接收电感耦合等离子体质谱法测定高钙生物样品的硼同位素组成[J]. 岩矿测试, 2020, 39(3): 417−424. doi: 10.15898/j.cnki.11-2131/td.201909290141
Li Z X, Lu H. Determination of boron isotope composition in high calcium biological samples by one-step ion exchange and multiple reception inductively coupled plasma mass spectrometry[J]. Rock and Mineral Analysis, 2020, 39(3): 417−424. doi: 10.15898/j.cnki.11-2131/td.201909290141
[14] Cai Y, Rasbury E T, Wooton K M, et al. Rapid boron isotope and concentration measurements of silicate geological reference materials dissolved through sodium peroxide sintering[J]. Journal of Analytical Atomic Spectrometry, 2021, 36: 2153−2163. doi: 10.1039/D1JA00195G
[15] Jeffcoate A B, Elliott T, Thomas A, et al. Precise/small sample size determinations of lithium isotopic compositions of geological reference materials and modern seawater by MC-ICP-MS[J]. Geostandards and Geoanalytical Research, 2004, 28: 161−172. doi: 10.1111/j.1751-908X.2004.tb01053.x
[16] He M Y, Deng L, Lu H, et al. Elimination of the boron memory effect for rapid and accurate boron isotope analysis by MC-ICP-MS using NaF[J]. Journal of Analytical Atomic Spectrometry, 2019, 34: 1026−1032. doi: 10.1039/C9JA00007K
[17] 冯林秀, 李正辉, 曹秋香, 等. 硼同位素分析测试技术研究进展[J]. 岩矿测试, 2023, 42(1): 16−38. doi: 10.15898/j.cnki.11-2131/td.202209140170
Feng L X, Li Z H, Chao Q X, et al. A review on the development of boron isotope analytical techniques[J]. Rock and Mineral Analysis, 2023, 42(1): 16−38. doi: 10.15898/j.cnki.11-2131/td.202209140170
[18] 李超, 王登红, 屈文俊, 等. 关键金属元素分析测试技术方法应用进展[J]. 岩矿测试, 2020, 39(5): 658−669. doi: 10.15898/j.cnki.11-2131/td.201907310115
Li C, Wang D H, Qu W J, et al. A review and perspective on analytical methods of critical metal elements[J]. Rock and Mineral Analysis, 2020, 39(5): 658−669. doi: 10.15898/j.cnki.11-2131/td.201907310115
[19] Foster G L, Marschall H R, Palmer M R. Boron isotopes: The fifth element[M]. Switzerland: Springer Cham, 2018: 13-31.
[20] 徐洁, 张贵宾, 李楠, 等. LA-MC-ICPMS电气石及白云母原位硼同位素测试方法及应用[J]. 岩石矿物学杂志, 2020, 39(3): 323−334. doi: 10.3969/j.issn.1000-6524.2020.03.008
Xu J, Zhang G B, Li N, et al. In situ boron isotope analysis method for tourmaline and muscovite by LA-MC-ICPMS and its applications[J]. Acta Petrologica et Mineralogica, 2020, 39(3): 323−334. doi: 10.3969/j.issn.1000-6524.2020.03.008
[21] 蒋少涌, 陈唯, 赵葵东, 等. 基于LA-(MC)-ICP-MS的矿物原位微区同位素分析技术及其应用[J]. 质谱学报, 2021, 42(5): 623−640. doi: 10.7538/zpxb.2021.0135
Jiang S Y, Chen W, Zhao K D, et al. In situ micro-analysis of isotopic compositions of solid minerals using LA-(MC)-ICP-MS methods and their applications[J]. Journal of Chinese Mass Spectrometry Society, 2021, 42(5): 623−640. doi: 10.7538/zpxb.2021.0135
[22] Steinmann L K, Oeser M, Horn I, et al. In situ high-precision lithium isotope analyses at low concentration levels with femtosecond-LA-MC-ICP-MS[J]. Journal of Analytical Atomic Spectrometry, 2019, 34(7): 1447−1458. doi: 10.1039/c9ja00088g
[23] Evans D, Gerdes A, Coenen D, et al. Accurate correction for the matrix interference on laser ablation MC-ICPMS boron isotope measurements in CaCO3 and silicate matrices[J]. Journal of Analytical Atomic Spectrometry, 2021, 36(8): 1607−1617. doi: 10.1039/d1ja00073j
[24] 刘纯瑶, 苟龙飞, 邓丽, 等. 离子交换过程中锂同位素分馏对锂同位素测试准确度的影响[J]. 岩矿测试, 2019, 38(1): 35−44. doi: 10.15898/j.cnki.11-2131/td.201806060070
Liu C Y, Gou L F, Deng L, et al. Effects of Li isotopic fractionation during ion exchange on the measurement accuracy of Li isotopes[J]. Rock and Mineral Analysis, 2019, 38(1): 35−44. doi: 10.15898/j.cnki.11-2131/td.201806060070
[25] 苏嫒娜, 田世洪, 李真真, 等. MC-ICP-MS高精度测定锂同位素分析方法[J]. 地学前缘, 2011, 18(2): 304−314.
Su A N, Tian S H, Li Z Z, et al. High-precision measurement of lithium isotopes using MC-ICP-MS[J]. Earth Science Frontiers, 2011, 18(2): 304−314.
[26] Paul A N, Stewart J A, Agostini S, et al. Refining boron isotopic measurements of silicate samples by multi-collector-inductively coupled plasma-mass spectrometry (MC-ICP-MS)[J]. Geostandards and Geoanalytical Research, 2024, 48(1): 91−108. doi: 10.1111/ggr.12527
[27] Chen X Y, Teng F Z, Catling D C. Fast and precise boron isotopic analysis of carbonates and seawater using Nu Plasma Ⅱ multi-collector inductively coupled plasma mass spectrometry and a simple sample introduction system[J]. Rapid Communications in Mass Spectrometry, 2019, 33: 1169−1178. doi: 10.1002/rcm.8456
[28] Buisson M, Louvat P, Thaler C, et al. High precision MC-ICP-MS measurements of 11B/10B ratios from ng amounts of boron in carbonate samples using microsublimation and direct injection (μ-dDIHEN)[J]. Journal of Analytical Atomic Spectrometry, 2021, 36: 2116−2131. doi: 10.1039/d1ja00109d
[29] Flesch G D, Anderson Jr, A R, et al. A secondary isotopic standard for 6Li/7Li determinations[J]. International Journal of Mass Spectrometry and Ion Physics, 1973, 12(3): 265−272. doi: 10.1016/0020-7381(73)80043-9
[30] Bouman C, Elliott T, Vroon P Z. Lithium inputs to subduction zones[J]. Chemical Geology, 2004, 212: 59−79. doi: 10.1016/j.chemgeo.2004.08.004
[31] Li W, Liu X M, Godfrey L V. Optimisation of lithium chromatography for isotopic analysis in geological reference materials by MC-ICP-MS[J]. Geostandards and Geoanalytical Research, 2019, 43: 261−276. doi: 10.1111/ggr.12254
[32] Lin J, Liu Y, Hu Z, et al. Accurate determination of lithium isotope ratios by MC-ICP-MS without strict matrix-matching by using a novel washing method[J]. Journal of Analytical Atomic Spectrometry, 2016, 31: 390−397. doi: 10.1039/c5ja00231a
[33] Zhu G, Ma J, Wei G, et al. A rapid and simple method for lithium purification and isotopic analysis of geological reference materials by MC-ICP-MS[J]. Frontiers in Chemistry, 2020, 8: 557489. doi: 10.3389/fchem.2020.557489
[34] Bao Z, Huang K, Huang T, et al. Precise magnesium isotope analyses of high-K and low-Mg rocks by MC-ICP-MS[J]. Journal of Analytical Atomic Spectrometry, 2019, 34: 940−953. doi: 10.1039/C9JA00002J
[35] Druce M, Stirling C H, Rolison J M. High-precision zinc isotopic measurement of certified reference materials relevant to the environmental, Earth, planetary and biomedical sciences[J]. Geostandards and Geoanalytical Research, 2020, 44: 711−732. doi: 10.1111/GGR.12341
-
