ACOUSTIC CHARACTERISTICS OF HYDRATE-BEARING SEDIMENTS：A COMPARATIVE ANALYSIS OF EXPERIMENTAL AND NUMERICAL SIMULATIONS RESULTS
-
摘要:
含水合物沉积物声学特性在水合物勘探中非常重要。针对含水合物沉积物声学特性，前人通过实验模拟及岩石物理建模已取得一定的进展，但基于实验条件开展的数值模拟及其结果的对比研究仍鲜有涉及。笔者拟采用实验室物理模拟与实验储层数值模拟相结合的方法，通过物理实验模拟获得水合物储层声学特征。在此基础上，以实验物理模型以及声波采集系统为基本构建对应条件下的近似地质模型和声波观测系统，分别在50 kHz和80 Hz频率条件下获得具有不同水合物饱和度储层的波形记录和波场快照，并获得不同时间点和饱和度条件下的储层速度，对比分析实验模拟与数值模拟获得结果的异同。研究表明在3种模拟条件下获得的不同时刻的含水合物储层声速对应关系良好，数值模拟结果很好地印证了实验室模拟实验的结果，表明在实验室内进行相应物理模型的岩石物理模拟实验具有可行性。将实验模拟与数值模拟结果同野外探测数据对比分析，具有一致的变化趋势，表明物理模拟实验和数值模拟结果对野外勘探数据分析具有重要的指导意义。
Abstract:Acoustic characteristics of hydrate-bearing sediments are very important in hydrate exploration. So far, some important research progresses have been reached in experimental simulation and rock physics modeling. However, the numerical simulation based on experimental conditions and comparative studies between the above are still lacking. This paper intends to obtain the acoustic characteristics of hydrate reservoir through physical experiment simulation by combining laboratory physical simulation together with experimental reservoir numerical simulation. On the basis, a geological model is constructed based on the simulated experimental device model, and the reservoir velocity results obtained at the frequencies of 50 kHz and 80 Hz under different hydrate saturation conditions, and the wave field snapshots at different time points and saturation conditions are obtained. Comparative analysis of the similarities and differences are carried out between the results obtained by experimental simulation and numerical simulation. The research shows that the correlation between the wave velocity of the hydrate reservoir at different times obtained under the three simulation conditions is good. The numerical simulation results confirm the results of the laboratory simulation experiments, suggesting that it is feasible to carry out corresponding rock physical simulation experiments in laboratory. Comparing the results of experimental simulation and numerical simulation experiment with field detection data, there is a consistent change trend, indicating that the results of physical simulation experiment and numerical simulation have important guiding significance for field exploration data analysis.
-
-
表 1 实验样品各层
位在不同水合物饱和度条件下的数值模型输入参数 Table 1. The input parameters of the numerical model for each layer of the experimental sample under different hydrate saturations
时间 层位 Kf
/GPaKm
/GPaKdry
/GPaPm
/（g/cm3）ρf
/（g/cm3）κ
/（10−15 m2 )ϕ
/%0 h 层4 2.5 58.32 1.209 2.692 1.032 2.0 39.8 层3 2.5 58.32 1.334 2.692 1.032 1.53 38.3 层2 2.5 58.32 1.209 2.692 1.032 2.0 39.8 层1 2.5 58.32 1.334 2.692 1.032 1.53 38.3 54 h 层4 2.6 47.383 1.175 2.676 1.032 1.32 37.5 层3 2.57 50.319 1.28 2.684 1.032 1.18 36.9 层2 2.6 47.383 1.175 2.676 1.032 1.32 37.5 层1 2.53 53.656 1.288 2.686 1.032 1.34 37.6 148 h 层4 2.87 38.538 1.395 2.644 1.032 0.467 32.2 层3 2.87 38.806 1.509 2.656 1.032 0.363 31 层2 2.87 38.538 1.395 2.644 1.032 0.467 32.2 层1 2.87 38.806 1.509 2.656 1.032 0.363 31 245 h 层4 4.15 58.32 1.046 2.692 1.032 2.0 39.8 层3 4.35 58.32 1.155 2.692 1.032 1.53 38.3 层2 4.11 58.32 1.046 2.692 1.032 2.0 39.8 层1 3.89 58.32 1.155 2.692 1.032 1.53 38.3 注：表中Kf，Km，Kdry，ρm，ρf，κ和ϕ分别表示孔隙流体的等效体积模量，沉积物组成矿物的等效体积模量，沉积物骨架的等效体积模量，沉积物组成矿物的等效密度，孔隙流体的等效密度，沉积物的渗透率和沉积物的孔隙度。
下载: 导出CSV
表 2 实验模拟与数值模拟纵波速度对比
Table 2. Comparison of P-wave velocity between experimental simulation and numerical simulation
/(m/s) 实验模拟（超声频率50 kHz） 数值模拟（震源频率50 kHz） 数值模拟（震源频率80 Hz） 0 h 层4 1 905.97 1 984.13 1 946.17 层3 1 807.22 1 875.00 1 830.57 层2 1 880.87 1 971.09 1 868.79 层1 1 762.63 1 825.93 1 768.58 54 h 层4 1 996.00 2 068.97 2 028.15 层3 1 880.87 1 936.73 1 866.93 层2 1 977.58 2 061.86 2 017.17 层1 1 845.01 1 879.70 1 874.38 148 h 层4 2 084.78 2 161.38 2 068.21 层3 2 043.59 2 118.64 2 072.77 层2 2 105.26 2 172.34 2 126.70 层1 2 074.68 2 142.86 2 088.89 245 h 层4 2 504.17 2 497.92 2 520.11 层3 2 564.10 2 669.04 2 585.97 层2 2 469.13 2 535.93 2 503.33 层1 2 417.40 2 457.00 2 425.81
下载: 导出CSV
-
[1] Boswell R,Collett T S. Current perspectives on gas hydrate resources[J]. Energy & Environmental Science,2011,4:1206-1215.
[2] Chong Z R,Yang S H B,Babu P,et al. Review of natural gas hydrates as an energy resource:Prospects and challenges[J]. Applied Energy,2016,162:1633-1652. doi: 10.1016/j.apenergy.2014.12.061
[3] 孙运宝,赵铁虎,蔡 峰. 国外海域天然气水合物资源量评价方法对我国的启示[J]. 海洋地质前沿,2013,29(1):31-39.
[4] Li J F,Ye J L,Qin X W,et al. The first offshore natural gas hydrate production test in South China Sea[J]. China Geology,2018,1(1):5-16. doi: 10.31035/cg2018003
[5] 孙致学,朱旭晨,刘 垒,等. 联合深层地热甲烷水合物开采方法及可行性评价[J]. 海洋地质与第四纪地质,2019,39(2):146-156.
[6] 李彦龙,陈 强,胡高伟,等. 神狐海域W18/19区块水合物上覆层水平渗透系数分布[J]. 海洋地质与第四纪地质,2019,39(2):157-163.
[7] 业渝光. 天然气水合物实验探测和测试技术[J]. 海洋地质前沿,2011,27(6):37-43.
[8] 龚建明,廖 晶,尹维翰,等. 北印度洋马克兰增生楔天然气水合物的成藏模式[J]. 海洋地质与第四纪地质,2018,38(2):148-155.
[9] Pecher I A,Henrys S A,Wood W T,et al. Focussed fluid flow on the Hikurangi Margin,New Zealand — Evidence from possible local upwarping of the base of gas hydrate stability[J]. Marine Geology,2010,272(1/4):99-113. doi: 10.1016/j.margeo.2009.10.006
[10] 孙建孟,罗 红,焦 滔,等. 天然气水合物储层参数测井评价综述[J]. 地球物理学进展,2018,33(2):715-723.
[11] Ye J L,Wei J G,Liang J Q,et al. Complex gas hydrate system in a gas chimney,South China Sea[J]. Marine and Petroleum Geology,2019,104:29-39. doi: 10.1016/j.marpetgeo.2019.03.023
[12] Winters W J,Waite W F,Mason D H,et al. Methane gas hydrate effect of sediment acoustic and strength properties[J]. Journal of Petroleum Science and Engineering,2007,56:127-135. doi: 10.1016/j.petrol.2006.02.003
[13] Priest J A,Best A I,Clayton C,et al. A laboratory investigation into the seismic velocities of methane gas hydrate-bearing sand[J]. Journal of Geophysical Research,2005,110:B04102.
[14] Priest J A,Rees E V L,Clayton C. Influence of gas hydrate morphology on the seismic velocities of sands[J]. Journal of Geophysical Research,2009,114:B11205. doi: 10.1029/2008JD011387
[15] 胡高伟,业渝光,张 剑,等. 松散沉积物中天然气水合物生成、分解过程与声学特性的实验研究[J]. 现代地质,2008,22(3):465-474. doi: 10.3969/j.issn.1000-8527.2008.03.018
[16] Hu G W,Ye Y G,Zhang J,et al. Acoustic properties of gas hydrate-bearing consolidated sediments and experimental testing of elastic velocity models[J]. Journal of Geophysical Research,2010,115:B02102.
[17] Hu G W,Ye Y G,Zhang J,et al. Acoustic properties of hydrate-bearing unconsolidated sediments measured by the bender element technique[J]. Chinese Journal of Geophysics,2012,55(6):635-647. doi: 10.1002/cjg2.1758
[18] Hu G W,Y e,Y G,Zhang J,et al. Acoustic response of gas hydrate formation in sediments from South China Sea[J]. Marine and Petroleum Geology,2014,52:1-8. doi: 10.1016/j.marpetgeo.2014.01.007
[19] Bu Q T,Hu G W,Ye Y G,et al. The elastic wave velocity response of methane gas hydrate formation in vertical gas migrationsystems[J]. Journal of Geophysics and Engineering,2017,14(3):555-569. doi: 10.1088/1742-2140/aa6493
[20] Bu Q T,Hu G W,Ye Y G,et al. Experimental study on 2-D acoustic characteristics and hydrate distribution in sand[J]. Geophysical Journal International,2017,211(2):1012-1026.
[21] Bu Q T,Hu G W,Liu C L,et al. Acoustic characteristics and micro-distribution prediction during hydrate dissociation in sediments from the South China Sea[J]. Journal of Natural Gas Science & Engineering,2019,65:135-144.
[22] 孟庆生,何樵登,朱建伟,等. 基于BISQ 模型双相各向同性介质中地震波数值模拟[J]. 吉林大学学报(地球科学版),2003,33(2):217-221.
[23] 阚光明. 海底沉积物声波传播特性及数值模拟[D]. 青岛: 中国海洋大学, 2007.
[24] 彭传正,李才明,王明春. 基于改进BISQ模型的地震波场数值模拟[J]. 物探化探计算技术,2007,29(1):15-18. doi: 10.3969/j.issn.1001-1749.2007.01.005
[25] Leclaire P,Cohen‐Ténoudji F,Aguirre‐Puente J. Extension of Biot’s theory of wave propagation to frozen porous media[J]. The Journal of the Acoustical Society of America,1994,96(6):3753-3768. doi: 10.1121/1.411336
[26] 方跃龙. 含水合物松散沉积物的二维超声成像技术研究[D]. 青岛: 中国石油大学(华东), 2015.
[27] 许马光. 基于双相介质理论的天然气水合物识别方法研究[D]. 青岛: 中国海洋大学, 2015.
[28] Wright J F, Nixon F M, Dallimore S R, et a1. A method for direct measurement of gas hydrate amounts based on the bulk dielectric properties of laboratory test media[C]//The Proceedings of the 4th International Conference on Gas Hydrates. Yokohama, 2002: 745-749.
[29] Zhu X,Mcmechan G A. Numerical simulation of seismic responses of poroelastic reservoirs using Biot theory [J]. Geophysics,1991,56(3):328-339.
[30] 杨佳佳,何兵寿,张建中. 海底天然气水合物 OBS 多分量地震正演模拟[J]. 应用地球物理,2014,11:418-428.
[31] Wu N Y,Liu C L,Hao X L. Experimental simulations and methods for natural gas hydrate analysis in China[J]. China Geology,2018,1(1):61-71. doi: 10.31035/cg2018008
[32] 赵 群,郭 建,郝守玲,等. 模拟天然气水合物的岩石物理特性模型实验[J]. 地球物理学报,2005,48(3):649-655. doi: 10.3321/j.issn:0001-5733.2005.03.024
[33] 彭一民,孙进忠. 超声地震模型实验相似准则[J]. 勘察科学技术,1987(5):52,58-61.
[34] Helgerud M,Dvorkin J,Nur A,et al. Elastic wave velocity in marine sediments with gas hydrates:Effective medium modeling[J]. Geophysical Research Letters,1999,26:2021-2024. doi: 10.1029/1999GL900421
[35] 梁 劲,王明君,陆敬安,等. 南海北部神狐海域含天然气水合物沉积层的速度特征[J]. 天然气工业,2013,33(7):29-35. doi: 10.3787/j.issn.1000-0976.2013.07.005
[36] 梁 劲,王明君,陆敬安,等. 南海神狐海域含水合物地层测井响应特征[J]. 现代地质,2010,24(3):506-514. doi: 10.3969/j.issn.1000-8527.2010.03.014
-
