摘要:
软岩遇水具有显著的劣化效应，以往研究主要集中于软岩的流变特性，对水-岩作用下软岩的含水损伤研究较少，但水-岩作用下软岩的含水损伤效应对工程建设的指导至关重要。因此，以滇中地区粉砂质泥岩为研究对象，对干燥状态、天然含水率和饱水条件下的粉砂质泥岩试样进行三轴压缩蠕变试验。试验结果表明：（1）不同含水率试样在初始加载阶段产生的应变量均远大于后期逐级加载阶段的应变增加量，且随着含水率的增加初始加载蠕变量逐渐增大；（2）随着含水率的提升，最终蠕变量逐渐增加，试样进入加速蠕变阶段的应力阈值逐渐降低，长期强度也显著降低。根据试验结果，基于损伤理论，引入一个非线性黏塑性体考虑含水情况对蠕变的影响，提出基于经典Burgers模型并具有水-岩作用劣化特征的含水损伤蠕变本构模型。通过1stopt软件辨识参数，并验证了模型的准确性和可适性。研究结果对于滇中红层软岩的含水损伤特性研究提供了一定的参考。
Abstract:Soft rocks have significant degradation effects when they encounter water. Previous studies focused mainly on the rheological properties of soft rocks. Water damage of soft rocks under water-rock reactions was seldom examined. The effects of water damage on soft rocks under water-rock reactions are important in the guidance of project constructions. Therefore, this article takes the silty mudstone in the central Yunnan area as the research object, and the triaxial compression creep test on the silty mudstone samples is performedunder dry conditions, natural water content and saturated water conditions. The test results show that (1) the strain of the samples with different water content during the initial loading stage is much larger than the strain increase in the later stage of the stage loading, and the initial loading creep variable gradually increases with the increasing water content. (2) As the water content increases, the final creep variable gradually increases, and the stress threshold of the sample entering the accelerated creep stage gradually decreases, but the long-term strength is significantly reduced. Based on the test results and the damage theory, a nonlinear viscoplastic body is introduced to consider the effect of water content on creep, and a water damage constitutive model based on the classic Burgers model with water-rock degradation characteristics is proposed. The parameters are identified by the 1stopt software, and the accuracy and adaptability of the model are also verified. The research results can provide a certain reference for the research on the water damage characteristics of the red rock in central Yunnan.
-
-
表 1 粉砂质泥岩全岩矿物含量
Table 1. Full rock mineral contents of thesilty mudstone
矿物 黏土矿物 石英 钾长石 斜长石 方解石 赤铁矿 含量/% 36.6 16.9 4.1 18.3 19.7 4.4
下载: 导出CSV
表 2 饱和含水率试验结果
Table 2. Saturated water content test result
含水状态 岩样编号 烘干前
质量/g烘干后
质量/g含水率/
(%)平均含水率/
%天然含水率 A1 52.2 51.2 1.92 1.67 A2 54.2 53.4 1.48 A3 49.9 49.1 1.60 饱和含水率 B1 48.7 47.3 2.95 3.02 B2 53.1 51.6 2.90 B3 54.3 52.6 3.23
下载: 导出CSV
表 3 不同含水率抗剪强度参数
Table 3. Shear strength parameters of different water content
含水状态 内摩擦角φ/° 黏聚力C/MPa 干燥状态（0%） 43.52 4.64 天然状态（1.67%） 39.37 4.18 饱水状态（3.02%） 36.48 3.70
下载: 导出CSV
表 4 不同含水率加载方案
Table 4. Loading schemes with different moisture content
含水状态 分级荷载/MPa 干燥状态（0%） 7 14 21 28 35 42 — 天然状态（1.67%） 4 8 12 16 20 24 28 饱水状态（3.02%） 2 4 6 8 10 — —
下载: 导出CSV
表 5 含水损伤蠕变模型参数
Table 5. Parametersused in the water damage creep model
含水状态 加载应力/MPa
/GPa
/GPa
/（GPa·h）
/（GPa·h）
/（GPa·h）
R2 干燥状态 7 1.68 0.95 82.58 138.21 0.13 0.951 14 1.65 0.93 73.22 120.07 0.15 0.984 21 1.60 0.89 71.85 88.15 0.15 0.932 28 1.58 0.84 68.43 62.49 0.17 0.911 35 1.56 0.82 52.71 49.75 0.12 0.956 42 1.53 0.77 33.58 30.16 2.95 0.16 0.973 天然状态 4 1.4 0.82 71.0 112.4 − 0.12 0.965 8 1.36 0.83 63.5 103.6 − 0.11 0.976 12 1.27 0.75 63.3 79.3 − 0.13 0.987 16 1.25 0.68 56.7 50.7 − 0.16 0.988 20 1.18 0.64 46.2 46.1 − 0.17 0.981 24 1.10 0.60 33.5 32.3 − 0.17 0.963 28 1.13 0.51 27.8 20.5 2.78 0.18 0.950 饱水状态 2 1.21 0.72 63.44 88.2 0.14 0.955 4 1.18 0.71 60.13 85.3 0.15 0.981 6 1.15 0.68 45.12 62.6 0.12 0.962 8 1.10 0.62 33.98 33.4 0.14 0.938 10 1.08 0.59 25.79 19.1 2.63 0.16 0.986
下载: 导出CSV
-
[1] 周翠英, 梁宁, 刘镇. 红层软岩遇水作用的孔隙结构多重分形特征[J]. 工程地质学报,2020,28(1):1 − 9. [ZHOU Cuiying, LIANG Ning, LIU Zhen. Multifractal characteristics of pore structure of red beds soft rock at different saturations[J]. Journal of Engineering Geology,2020,28(1):1 − 9. (in Chinese with English abstract)
[2] 邓华锋, 张恒宾, 李建林, 等. 水-岩作用对砂岩卸荷力学特性及微观结构的影响[J]. 岩土力学,2018,39(7):2344 − 2352. [DENG Huafeng, ZHANG Henbin, LI Jianlin, et al. Effect of water-rock interaction on unloading mechanical properties and microstructure of sandstone[J]. Rock and Soil Mechanics,2018,39(7):2344 − 2352. (in Chinese with English abstract)
[3] 周翠英, 李伟科, 向中明, 等. 水-应力作用下软岩细观结构摩擦接触分析[J]. 岩土力学,2015,36(9):2458 − 2466. [ZHOU Cuiying, LI Weike, XIANG Zhongming, et al. Analysis of mesoscopic frictional contacts in soft rocks under water-stress interaction[J]. Rock and Soil Mechanics,2015,36(9):2458 − 2466. (in Chinese with English abstract)
[4] 曹文贵, 李翔. 岩石损伤软化统计本构模型及参数确定方法的新探讨[J]. 岩土力学,2008,29(11):2952 − 2956. [CAO Wengui, LI Xinag. A new discussion on damage softening statistical constitutive model for rocks and method for determining its parameters[J]. Rock and Soil Mechanics,2008,29(11):2952 − 2956. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2008.11.011
[5] 曹文贵, 戴笠, 张超. 深部岩石统计损伤本构模型研究[J]. 水文地质工程地质,2016,43(4):60 − 65. [CAO Wengui, DAI Li, ZHANG Chao. A study of statistical damage constitutive models for deep earth rocks[J]. Hydrogeology & Engineering Geology,2016,43(4):60 − 65. (in Chinese with English abstract)
[6] 吕爱钟, 丁志坤, 焦春茂, 等. 岩石非定常蠕变模型辨识[J]. 岩石力学与工程学报,2008,27(1):16 − 21. [LU Aizhong, DING Zhikun, JIAO Chunmao, et al. Identification of non-stationary creep constitutive models of rock[J]. Chinese Journal of Rock Mechanics and Engineering,2008,27(1):16 − 21. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2008.01.003
[7] 王来贵, 赵娜, 何峰, 等. 岩石蠕变损伤模型及其稳定性分析[J]. 煤炭学报,2009,34(1):64 − 68. [WANG Laigui, ZHAO Na, HE Feng, et al. Rock creep damage model and its stability analysis[J]. Journal of China Coal Society,2009,34(1):64 − 68. (in Chinese with English abstract) doi: 10.3321/j.issn:0253-9993.2009.01.013
[8] 陈卫忠, 王者超, 伍国军, 等. 盐岩非线性蠕变损伤本构模型及其工程应用[J]. 岩石力学与工程学报,2007,26(3):467 − 472. [CHEN Weizhong, WANG Zhechao, WU Guojun, et al. Nonlinear creep damage constitutive model of rock salt and its application to engineering[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(3):467 − 472. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2007.03.004
[9] 范庆忠, 高延法, 崔希海, 等. 软岩非线性蠕变模型研究[J]. 岩土工程学报,2007,29(4):505 − 509. [FAN Qingzhong, GAO Yanfa, CUI Xihai, et al. Study on nonlinear creep model of soft rock[J]. Chinese Journal of Geotechnical Engineering,2007,29(4):505 − 509. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2007.04.006
[10] 范庆忠, 李术才, 高延法. 软岩三轴蠕变特性的试验研究[J]. 岩石力学与工程学报,2007,26(7):1381 − 1385. [FAN Qingzhong, LI Shucai, GAO Yanfa. Experimental study on creep properties of soft rock under triaxial compression[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(7):1381 − 1385. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2007.07.010
[11] 杨春和, 马洪岭, 刘建锋. 循环加、卸载下盐岩变形特性试验研究[J]. 岩土力学,2009,30(12):3562 − 3568. [YANG Chunhe, MA Hongling, LIU Jianfeng. Study of deformation of rock salt under cycling loading and unloading[J]. Rock and Soil Mechanics,2009,30(12):3562 − 3568. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2009.12.002
[12] 蒋昱州, 王瑞红, 朱杰兵, 等. 砂岩的蠕变与弹性后效特性试验研究[J]. 岩石力学与工程学报,2015,34(10):2010 − 2017. [JIANG Yizhou, WANG Ruihong, ZHU Jiebing, et al. Experimental study of creep and elastic aftereffect of sandstone[J]. Chinese Journal of Rock Mechanics and Engineering,2015,34(10):2010 − 2017. (in Chinese with English abstract)
[13] 赵建军, 解明礼, 余建乐, 等. 冻融作用下含裂隙岩石力学特性及损伤演化规律试验研究[J]. 工程地质学报,2019,27(6):1199 − 1207. [ZHAO Jianjun, XIE Mingli, YU Jianle, et al. Experimental study on mechanical properties and damage evolution of fractured rock under freezing-thawing action[J]. Journal of Engineering Geology,2019,27(6):1199 − 1207. (in Chinese with English abstract)
[14] 吴礼舟, 李部, 孙萍. 甘肃甘谷裂隙泥岩剪切蠕变行为及其修正模型研究[J]. 地质力学学报,2017,23(6):923 − 934. [WU Lizhou, LI Bu, SUN Ping. Study on shear creep behavior of mudstone and its correction model of Gangu fissure in Gansu[J]. Journal of Geomechanics,2017,23(6):923 − 934. (in Chinese with English abstract)
[15] 汪辉平, 曹文贵, 王江营, 等. 模拟岩石应变软化变形全过程的统计损伤本构模型研究[J]. 水文地质工程地质,2013,40(4):44 − 49. [WANG Huiping, CAO Wengui, WANG Jianying, et al. A study of the statistical damage constitutive model of rocks considering a full deformation process[J]. Hydrogeology & Engineering Geology,2013,40(4):44 − 49. (in Chinese with English abstract)
[16] 周峙, 张家铭, 刘宇航, 等. 巴东组紫红色泥质粉砂岩损伤特性三轴试验研究[J]. 水文地质工程地质,2012,39(2):56 − 60. [ZHOU Zhi, ZHANG Jiaming, LIU Yuhang, et al. A triaxial testing study of the damage characteristics of purple argillaceous siltstone of the Badong formation[J]. Hydrogeology & Engineering Geology,2012,39(2):56 − 60. (in Chinese with English abstract)
[17] 朱俊杰. 滇中红层软岩水-岩作用机理及时效性变形特性研究[D]. 成都: 成都理工大学, 2019.
ZHU Junjie. Study on water-rock interaction mechanism and time-dependent deformation characteristics of red beds soft rock in central Yunnan[D]. Chengdu: Chengdu University of Technology, 2019. (in Chinese with English abstract)
-
