基于红外热成像技术的石窟壁面凝结水形成规律研究

马策; 蒋小伟; 闫宏彬; 周鹏宇; 任建光; 樊尧; 范潇; 万力

doi:10.16030/j.cnki.issn.1000-3665.202011006

基于红外热成像技术的石窟壁面凝结水形成规律研究

1.
中国地质大学（北京）水资源与环境学院, 北京　100083

2.
云冈研究院, 山西大同　037034

基金项目: 国家重点研发计划项目（2019YFC1520500）；山西省文物局文物保护科技项目（208141400237）

详细信息

作者简介: 马策（1994-），男，博士研究生，主要从事包气带水汽运移方面研究工作。E-mail：mc@cugb.edu.cn

通讯作者: 蒋小伟（1982-），男，教授，主要从事水文地质学的教学与科研工作。 E-mail：jxw@cugb.edu.cn

中图分类号: P462.3⁺2；P641.1

收稿日期: 2021-11-03

修回日期: 2021-12-01

刊出日期: 2022-07-25

A study of the formation pattern of condensation water in grottoes based on the infrared thermal imaging technology

1.
School of Water Resource and Environment, China University of Geosciences （Beijing）, Beijing　100083, China

2.
Yungang Research Institute, Datong, Shanxi　037034, China

More Information

Corresponding author: JIANG Xiaowei, jxw@cugb.edu.cn

Received Date: 03 November 2021

Revised Date: 01 December 2021

Publish Date: 25 July 2022

摘要

摘要:
凝结水会加剧石质文物的风化，以往确定凝结水量的实验设备布置复杂、监测范围有限，并且无法实时反映凝结状态，从而制约了对凝结水形成过程的认识以及对石质文物凝结水的有效防治。文章利用红外热成像技术开展凝结水形成规律研究，实现了对石窟壁面凝结水的大范围无损连续观测，并利用微波水分测试技术进行验证。针对一次降雨事件，对云冈石窟第19窟壁面进行了连续100 h的红外热成像监测，揭示了降雨前和降雨期间的壁面温度昼夜变化规律，通过对比空气露点温度识别出2个具备凝结水形成条件的时期：降温前凝结期，从降雨前16 h开始到降雨期间气温发生骤降为止；降温后凝结期，从气温骤降开始到降雨结束后12 h。同时，利用微波水分仪进行了连续56 h的浅表层岩石含水率动态监测，发现尽管壁面上无法用肉眼直接观察到凝结水，但岩石内部含水率增大，表明岩石内部已经优先凝结。降雨过程中气温在1 h内从18.5℃骤降到15.6 °C引起大气中的水汽凝结，导致露点温度下降，使得壁面不再具备凝结水形成条件。该研究对石质文物的凝结水防治具有重要的指导意义。
- 凝结水 /
- 红外热成像 /
- 微波水分仪 /
- 岩石含水率 /
- 云冈石窟
Abstract:
Condensation water can accelerate weathering of stone relics. Previous methods for detecting condensation water in grottoes have some shortcomings, such as the complex equipment layout and limited monitoring range, and are unable to reflect the real-time condensation state, which restrict the effective prevention and control of condensation water in grottoes. In this paper, the infrared thermal imaging technology, which can be used to obtain continuous and large-scale observation of temperature on the wall of grottoes, and the microwave moisture measurement technology, which can be used to obtain rock moisture inside the wall, are both used to study the formation mechanism of condensation water. During the occurrence of a rainfall event, a wall in cave 19 of the Yungang Grottoes was monitored by the infrared thermal imaging for 100 hours. This set of data reveals the diurnal variation pattern of temperature before and during the rainfall event, and two periods beneficial for the formation of condensation water were identified by comparing with the air dew point temperature. The two periods are the condensation period before cooling which starts from 16 hours before rainfall to a sudden drop of temperature during rainfall and the condensation period after cooling which starts from the sudden drop of temperature to 12 hours after the end of rainfall. At the same time, the dynamic monitoring of the shallow rock moisture content for 56 hours was carried out with a microwave moisture meter. Although condensation water cannot be directly observed on the wall, the microwave moisture meter shows that water content in the rock increases, indicating that water has been preferentially condensed inside the rock. It is also found that the sudden drop of air temperature (from 18.5 °C to 15.6 °C in 1 hour) during the process of rainfall causes the condensation of water vapor in atmosphere, which causes a significant decline in the dew point temperature, and the condition of condensation water formation is not fulfilled. This phenomenon is of important guiding significance for the prevention and control of condensation water.
- condensation water /
- infrared imaging /
- micro-wave moisture meter /
- rock moisture /
- Yungang Grottoes

HTML全文

图 1 （a）19窟西北角底部的苔藓分布和（b）19窟北壁西侧监测点布置

Figure 1.

下载: 全尺寸图片幻灯片

图 2 （a1-h1）8个典型时刻温度分布和（a2-h2）对应时刻的具备凝结水形成条件的分布范围

Figure 2.

下载: 全尺寸图片幻灯片

图 3 （a）壁面典型位置的温度对比和r4处壁温和（b）气温的实测数据与雨前温度趋势拟合

Figure 3.

下载: 全尺寸图片幻灯片

图 4 壁温和露点对比以及凝结时期划分图

Figure 4.

下载: 全尺寸图片幻灯片

图 5 利用微波水分仪获得的壁面浅表层含水率随时间变化规律

Figure 5.

下载: 全尺寸图片幻灯片

参考文献(30)

[1]	TURKINGTON A V, PARADISE T R. Sandstone weathering:A century of research and innovation[J]. Geomorphology,2005,67(1/2):229 − 253.
[2]	WELLS T, HANCOCK G, FRYER J. Weathering rates of sandstone in a semi-arid environment (Hunter Valley, Australia)[J]. Environmental Geology,2008,54(5):1047 − 1057. doi: 10.1007/s00254-007-0871-y
[3]	PARADISE T R. Petra revisited:An examination of sandstone weathering research in Petra, Jordan[J]. Special Paper 390:Stone Decay in the Architectural Environment,2005,390:39 − 49.
[4]	卢良兆. 岩石学[M]. 北京: 地质出版社, 2017 LU Zhaoliang. Petrology [M]. Beijing: Geological Publishing House, 2017. （in Chinese）
[5]	严绍军, 方云, 孙兵, 等. 渗水对龙门石窟的影响及治理分析[J]. 现代地质,2005,19(3):475 − 478. [YAN Shaojun, FANG Yun, SUN Bing, et al. Influence of water permeation and analysis of treatment for the Longmen grottoes[J]. Geoscience,2005,19(3):475 − 478. (in Chinese with English abstract) YAN Shaojun, FANG Yun, SUN Bing, et al. Influence of water permeation and analysis of treatment for the Longmen grottoes [J], Geoscience. 2005, 19(3): 475-478. (in Chinese with English abstract)
[6]	董佩, 王旭升, 万力, 等. 云冈石窟覆盖层特征及其对石窟渗水的影响[J]. 科技导报,2013,31(10):62 − 66. [DONG Pei, WANG Xusheng, WAN Li, et al. Characteristics of the overlying sediments in Yungang grottoes and its impact on surface water infiltration[J]. Science & Technology Review,2013,31(10):62 − 66. (in Chinese with English abstract) doi: 10.3981/j.issn.1000-7857.2013.10.009 DONG Pei, WANG Xusheng, WAN Li, et al. Characteristics of the overlying sediments in Yungang grottoes and its impact on surface water infiltration[J]. Science & Technology Review, 2013, 31(10): 62-66. (in Chinese with English abstract) doi: 10.3981/j.issn.1000-7857.2013.10.009
[7]	刘强. 石质文物保护[M]. 北京: 科学出版社, 2012 LIU Qiang. Protection of stone cultural relics[M]. Beijing: Science Press, 2012. （in Chinese）
[8]	WEI J P, ZHU B L. Study on the sandstone weathering sensitivity caused by the changes of temperature and humidity[J]. Advanced Materials Research,2011,243/249:645 − 649. doi: 10.4028/www.scientific.net/AMR.243-249.645
[9]	CHEN J, BLUME H P, BEYER L. Weathering of rocks induced by lichen colonization—A review[J]. Catena,2000,39(2):121 − 146. doi: 10.1016/S0341-8162(99)00085-5
[10]	COOMBES M A, NAYLOR L A, VILES H A, et al. Bioprotection and disturbance:Seaweed, microclimatic stability and conditions for mechanical weathering in the intertidal zone[J]. Geomorphology,2013,202:4 − 14. doi: 10.1016/j.geomorph.2012.09.014
[11]	汪军, 徐金明, 龚明权, 等. 基于扫描电镜图像和微观渗流模型的云冈石窟砂岩风化特征分析[J]. 水文地质工程地质,2021,48(6):122 − 130. [WANG Jun, XU Jinming, GONG Mingquan, et al. Investigating weathering features of sandstones in the Yungang Grottoes based on SEM images and micro-scale flow model[J]. Hydrogeology & Engineering Geology,2021,48(6):122 − 130. (in Chinese with English abstract) WANG Jun, XU Jinming, GONG Mingquan, et al. Investigating weathering features of sandstones in the Yungang Grottoes based on SEM images and micro-scale flow model[J]. Hydrogeology & Engineering Geology, 2021, 48（6）: 122 − 130. （in Chinese with English abstract）
[12]	翁履谦, 杨海峰, 王逢睿, 等. 云冈石窟砂岩微观风化特征研究[J]. 材料导报:纳米与新材料专辑,2011,A(2):425 − 428. [WENG Lvqian, YANG Haifeng, WANG Fengrui, et al. Research on characterization of sandstone weathering of Yungang grottoes[J]. Materials Reports,2011,A(2):425 − 428. (in Chinese with English abstract) WENG Lvqian, YANG Haifeng, WANG Fengrui, et al. , Research on characterization of sandstone weathering of Yungang grottoes[J]. materials Reports, 2011, A(2): 425-428. (in Chinese with English abstract)
[13]	黄继忠, 郑伊, 张悦, 等. 云冈石窟砂岩水汽扩散特性研究[J]. 西北大学学报:自然科学版,2021,51(3):370 − 378. [HUANG Jizhong, ZHENG Yi, ZHANG Yue, et al. The water vapor diffusion characteristics of sandstone in Yungang Grottoes[J]. Journal of Northweat University (Natural Science Edition),2021,51(3):370 − 378. (in Chinese with English abstract) HUANG Jizhong, ZHENG Yi, ZHANG Yue, et al. The water vapor diffusion characteristics of sandstone in Yungang Grottoes[J]. Journal of Northweat University (Natural Science Edition), 2021, 51(3): 370-378. (in Chinese with English abstract)
[14]	刘硕, 白雪亮, 张彬, 等. 桂海碑林摩崖石刻水害成因分析及防治对策[J]. 水文地质工程地质,2020,47(2):126 − 133. [LIU Shuo, BAI Xueliang, ZHANG Bin, et al. Cause analysis and control measures of water damages in Guihai’s stone inscription[J]. Hydrogeology & Engineering Geology,2020,47(2):126 − 133. (in Chinese with English abstract) LIU Shuo, BAI Xueliang, ZHANG Bin, et al. Cause analysis and control measures of water damages in Guihai's stone inscription[J]. Hydrogeology & Engineering Geology, 2020, 47(2): 126-133. (in Chinese with English abstract)
[15]	张红梅, 马国栋, 速宝玉. 大同云岗石窟文物渗水病害防治方案探讨[J]. 水文地质工程地质,2004,31(5):64 − 67. [ZHANG Hongmei, MA Guodong, SU Baoyu. A discussion of the treatment of water-seepage disease of the stone carvings in the Yungang Grotto near Datong[J]. Hydrogeology & Engineering Geology,2004,31(5):64 − 67. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-3665.2004.05.016 ZHANG Hongmei, MA Guodong, SU Baoyu. A discussion of the treatment of water-seepage disease of the stone carvings in the Yungang Grotto near Datong[J]. Hydrogeology & Engineering Geology, 2004, 31(5): 64-67. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-3665.2004.05.016
[16]	朱华, 杨刚亮, 方云, 等. 龙门石窟潜溪寺凝结水病害形成机理及防治对策研究[J]. 中原文物,2008(4):109 − 112. [ZHU Hua, YANG Gangliang, FANG Yun, et al. Research on formation mechanism and prevention countermeasures for condensation water disease on Qianxi Temple of Longmen Grottoes[J]. Cultural Relics of Central China,2008(4):109 − 112. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-1731.2008.04.018 ZHU Hua, YANG Gangliang, FANG Yun, et al. Research on formation mechanism and prevention countermeasures for condensation water disease on Qianxi Temple of Longmen Grottoes[J]. Cultural Relics of Central China, 2008, (4): 109-112. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-1731.2008.04.018
[17]	万力, 曹文炳, 王旭升, 等. 云冈石窟水汽转化特征的初步研究[J]. 工程勘察,2012,40(11):6 − 11. [WAN Li, CAO Wenbing, WANG Xusheng, et al. Preliminary investigation on water-vapor transfer in Yungang Grottoes[J]. Geotechnical Investigation & Surveying,2012,40(11):6 − 11. (in Chinese with English abstract) WAN Li, CAO Wenbing, WANG Xusheng, et al. Preliminary investigation on water-vapor transfer in Yungang Grottoes[J]. Geotechnical Investigation & Surveying, 2012, 40(11): 6-11. (in Chinese with English abstract)
[18]	WYRWAŁ J, MARYNOWICZ A. Vapour condensation and moisture accumulation in porous building wall[J]. Building and Environment,2002,37(3):313 − 318. doi: 10.1016/S0360-1323(00)00097-4
[19]	TULLER M, OR D, DUDLEY L M. Adsorption and capillary condensation in porous media:Liquid retention and interfacial configurations in angular pores[J]. Water Resources Research,1999,35(7):1949 − 1964. doi: 10.1029/1999WR900098
[20]	曹文炳, 万力, 曾亦键, 等. 云冈石窟洞窟内凝结水形成机制与防治研究[C]//2005年云冈国际学术研讨会论文集（保护卷）, 2005 CAO Wenbing, WAN Li, ZENG Yijian, et al. Study on the formation mechanism and prevention of water condensation in Yungang Grottoes[C]//The 2005 Yungang International Symposium Proceedings （Protection Volume）, 2005. （in Chinese）
[21]	安程. 石窟环境监测模拟及整体分析研究[M]. 北京: 科学出版社, 2019 AN Cheng. Monitoring, simulation and overall analysis of grotto environment[M]. Beijing: Science Press, 2019. （in Chinese）
[22]	方云, 黄璇, 王晓东, 等. 龙门石窟潜溪寺凝结水定量测试研究[J]. 现代地质,2011,25(6):1214 − 1218. [FANG Yun, HUANG Xuan, WANG Xiaodong, et al. Quantification research on condensation water on Qianxi temple of Longmen Grottoes[J]. Geoscience,2011,25(6):1214 − 1218. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-8527.2011.06.023 FANG Yun, HUANG Xuan, WANG Xiaodong, et al. Quantification research on condensation water on Qianxi temple of Longmen Grottoes[J]. Geoscience, 2011, 25(6): 1214-1218. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-8527.2011.06.023
[23]	MARTÍNEZ-GARRIDO M I, FORT R, GÓMEZ-HERAS M, et al. A comprehensive study for moisture control in cultural heritage using non-destructive techniques[J]. Journal of Applied Geophysics,2018,155:36 − 52. doi: 10.1016/j.jappgeo.2018.03.008
[24]	GRINZATO E, BISON P G, MARINETTI S. Monitoring of ancient buildings by the thermal method[J]. Journal of Cultural Heritage,2002,3(1):21 − 29. doi: 10.1016/S1296-2074(02)01159-7
[25]	张悦, 黄继忠. 红外技术在文物科学保护中的应用[J]. 自然杂志,2021,43(3):217 − 224. [ZHANG Yue, HUANG Jizhong. Application of infrared technique for scientific conservation of cultural relics[J]. Chinese Journal of Nature,2021,43(3):217 − 224. (in Chinese with English abstract) doi: 10.3969/j.issn.0253-9608.2021.03.007 ZHANG Yue, HUANG Jizhong. Application of infrared technique for scientific conservation of cultural relics[J]. Chinese Journal of Nature, 2021, 43(3): 217-224. (in Chinese with English abstract) doi: 10.3969/j.issn.0253-9608.2021.03.007
[26]	LERMA J L, CABRELLES M, PORTALÉS C. Multitemporal thermal analysis to detect moisture on a building façade[J]. Construction and Building Materials,2011,25(5):2190 − 2197. doi: 10.1016/j.conbuildmat.2010.10.007
[27]	方云, 张俊建, 夏国正, 等. 红外热成像在龙门石窟奉先寺渗水探测中的应用[J]. 现代地质,2013,27(3):750 − 754. [FANG Yun, ZHANG Junjian, XIA Guozheng, et al. Application of infrared thermal imaging on seepage probing of Fengxian temple in Longmen grottoes[J]. Geoscience,2013,27(3):750 − 754. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-8527.2013.03.030 FANG Yun, ZHANG Junjian, XIA Guozheng, et al. Application of infrared thermal imaging on seepage probing of Fengxian temple in Longmen grottoes[J]. Geoscience, 2013, 27(3): 750-754. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-8527.2013.03.030
[28]	吴育华, 刘善军. 岩画渗水病害的红外热成像检测研究[J]. 工程勘察,2010,38(5):31 − 35. [WU Yuhua, LIU Shanjun. Infrared imaging detection on water-permeation of rock paintings[J]. Geotechnical Investigation & Surveying,2010,38(5):31 − 35. (in Chinese with English abstract) WU Yuhua, LIU Shanjun. Infrared imaging detection on water-permeation of rock paintings[J]. Geotechnical Investigation & Surveying, 2010, 38(5): 31-35. (in Chinese with English abstract)
[29]	苏美亮, 方云, 周伟强, 等. 千手观音凝结水的红外热成像检测技术[J]. 物探与化探,2013,37(2):295 − 300. [SU Meiliang, FANG Yun, ZHOU Weiqiang, et al. Infrared imaging detection on avalokitesvara condensation water[J]. Geophysical and Geochemical Exploration,2013,37(2):295 − 300. (in Chinese with English abstract) SU Meiliang, FANG Yun, ZHOU Weiqiang, et al. Infrared imaging detection on avalokitesvara condensation water[J]. Geophysical and Geochemical Exploration, 2013, 37(2): 295-300. (in Chinese with English abstract)
[30]	LU N , LIKOS W J . Unsaturated soil mechanics [M]. New Jersey: Wiley, 2004.
