干湿过程中膨胀土最大剪切模量及其预测

陈伟; 孙德安; 张俊然

doi:10.16030/j.cnki.issn.1000-3665.202012033

干湿过程中膨胀土最大剪切模量及其预测

1.
上海大学土木工程系，上海　200444

2.
华北水利水电大学岩土力学与结构工程重点实验室，河南郑州　450045

基金项目: 国家重点研发计划项目(2019YFC1509800)

详细信息

作者简介: 陈伟（1995-），男，硕士研究生，研究方向为非饱和土力学。E-mail：chengwei737475078@qq.com

通讯作者: 孙德安（1962-），男，教授，研究方向为非饱和土力学。E-mail：sundean@shu.edu.cn

中图分类号: TU443

收稿日期: 2020-12-16

修回日期: 2021-01-30

刊出日期: 2021-11-15

The maximum shear modulus of expansive soil during wetting-drying processes and its prediction

1.
Department of Civil Engineering, Shanghai University, Shanghai　200444, China

2.
Henan Province Key Laboratory of Rock and Soil Mechanics and Structural Engineering, North China University of Water Resources and Electric Power, Zhengzhou, Henan　450045, China

More Information

Corresponding author: SUN De’an, sundean@shu.edu.cn

Received Date: 16 December 2020

Revised Date: 30 January 2021

Publish Date: 15 November 2021

摘要

摘要:
为了研究膨胀土在天然环境下的动力特性，本文利用装有弯曲元的三轴仪对南阳膨胀土原状样和重塑样进行了最大剪切模量的测试试验。试验包括在不同围压下的饱和原状南阳膨胀土最大剪切模量测试；将初始干密度相近的原状样和重塑样分别进行脱湿和吸湿，量测整个过程中最大剪切模量的变化，并结合孔隙比进行分析。试验结果表明：饱和南阳膨胀土的最大剪切模量随着围压增大而增大；脱湿过程中南阳膨胀土最大剪切模量与含水率关系曲线要高于吸湿过程的曲线，即最大剪切模量与含水率关系存在滞回特性，这主要是吸力作用的缘故；初始干密度相近条件下原状样的最大剪切模量比重塑样的要小，这是由于原状样内部存在较多大孔隙。本文最后对饱和土最大剪切模量公式进行改进，使之适用于非饱和原状南阳膨胀土最大剪切模量的预测。
- 膨胀土 /
- 最大剪切模量 /
- 弯曲元 /
- 干湿 /
- 预测
Abstract:
In order to examine the dynamic characteristics of expansive soil in natural environment, the maximum shear modulus of undisturbed and remoulded Nanyang expansive soil specimens were tested by using a triaxial apparatus equipping with a pair of bender element. The saturated undisturbed Nanyang expansive soil specimen was tested using the bender element to measure the maximum shear modulus under different confining pressures. The maximum shear modulus of the undisturbed and remoulded specimens with the same dry density were measured in wetting-drying processes and analyzed in combination with the void ratio. The test results indicate that the maximum shear modulus of the saturated Nanyang expansive soil increases with the increasing confining pressure. In the relationship between the maximum shear modulus and water content, the drying curve is higher than the wetting one. It is also found that there is hysteretic characteristics in the maximum shear modulus and water content relationship, which is mainly due to the suction effect. Under similar dry density the maximum shear modulus of undisturbed specimen is smaller than the remoulded one. The reason is that there are more large pores in the undisturbed soil. Finally, an existing formula for the saturated soils is improved for predicting the maximum shear modulus of the unsaturated and undisturbed Nanyang expansive soil.
- expansive soil /
- maximum shear modulus /
- bender element /
- wetting and drying /
- prediction

HTML全文

图 1 弯曲元系统延迟

Figure 1.

下载: 全尺寸图片幻灯片

图 2 南阳原状膨胀土

Figure 2.

下载: 全尺寸图片幻灯片

图 3 南阳膨胀土的颗粒曲线

Figure 3.

下载: 全尺寸图片幻灯片

图 4 装有弯曲元的三轴仪示意图

Figure 4.

下载: 全尺寸图片幻灯片

图 5 弯曲元三轴试样制样模具

Figure 5.

下载: 全尺寸图片幻灯片

图 6 饱和原状和重塑膨胀土的最大剪切模量

Figure 6.

下载: 全尺寸图片幻灯片

图 7 干湿过程中重塑膨胀土最大剪切模量和孔隙比曲线

Figure 7.

下载: 全尺寸图片幻灯片

图 8 干湿过程中原状和重塑样的最大剪切模量

Figure 8.

下载: 全尺寸图片幻灯片

图 9 干湿过程中非饱和原状和重塑膨胀土样的孔隙比

Figure 9.

下载: 全尺寸图片幻灯片

图 10 含水率20%原状和重塑膨胀土样的孔径分布

Figure 10.

下载: 全尺寸图片幻灯片

图 11 饱和土参数拟合

Figure 11.

下载: 全尺寸图片幻灯片

图 12 原状南阳膨胀土的实测值与预测值对比

Figure 12.

下载: 全尺寸图片幻灯片

表 1 南阳膨胀土基本物理指标

Table 1. Basic physical indexes of the Nanyang expansive soil

石英 /%	伊蒙混层 /%	相对密度 G_s	液限 w_L/%	塑限 w_P/%	塑性指标 I_p	自由膨胀率 δ_f/%
61.0	24.2	2.74	47.5	25.3	22.2	52

下载: 导出CSV

表 2 干湿过程中原状南阳膨胀土参数及最大剪切模量的预测值

Table 2. Parameters and the predicted maximum shear modulus values of the undisturbed Nanyang expansive soil during drying and wetting processes

状态	含水率 w/%	孔隙比e	吸力 s/MPa	饱和度 S_r/%	G_max预测值 /MPa
脱湿过程	19.8	0.668	0.21	81.3	76.2
	15.1	0.577	4.26	71.5	144.0
	11.8	0.532	11.50	60.8	183.0
	7.8	0.503	36.40	42.7	225.0
	3.6	0.484	109.40	20.9	251.0
吸湿过程	7.7	0.521	16.60	40.4	185.0
	11.7	0.567	2.03	56.5	121.0
	15.7	0.625	0.16	69.0	77.1
	19.4	0.674	0.02	78.9	64.1
	20.3	0.689	0.01	80.5	62.0
注：吸力使用WP4C露点水势仪测量，。

下载: 导出CSV
