Distribution and ecological restoration of abandoned open-pit mines in Jiangsu section of the Yangtze River Economic Belt
-
摘要:
江苏省长江沿岸废弃矿山修复治理是长江经济带生态修复的关键节点区域，如何快速、直观地获得区域内废弃矿山的分布和修复工程进展，成为长江经济带废弃矿山生态修复工程的重要工作之一。以江苏长江干流两岸10 km范围为研究区，以2017—2020 年4 期高分辨率遥感影像为数据源，采用ArcGIS平台人机交互解译和野外验证的方式，获取了研究区内露天废弃矿山分布情况、地质环境问题和生态修复情况等信息。结果表明：镇江市和南京市需修复面积较大，区内露天废弃矿山主要表现为矿山的采场和中转场地两类占地，涉及矿种以建筑石料用灰岩和建筑用砂矿为主；存在的主要矿山环境问题有地形地貌破坏、矿山地质灾害、矿区生态环境破坏和水土污染等；2018—2020 年研究区已修复面积和正在修复面积均呈上升趋势，截至2020 年10 月，研究区废弃矿山修复效果良好，修复面积占67.08%；主要生态修复措施有自然恢复、客土回填、土地平整、削坡、土地综合治理等。建议在进行修复治理工程时，最大限度地保护矿区原有地貌，充分利用土地资源。调查结果和建议可为同类型地区露天废弃矿山生态修复治理提供技术参考。
Abstract:The abandoned mines along the Yangtze River in Jiangsu Province is the key area along the Yangtze River Economic Belt, which need to be restored and governed. Among the ecological restoration projects, it has been one of the difficulties that how to quickly and intuitively track the progress of the distribution and restoration of a great many abandoned mines in the region. In this paper, the author takes the 10 km area on both sides of the Belt as study object. And selects high-resolution remote sensing images in each year from 2017 to 2020 as the data source. By human-computer interactive interpretation on the ArcGIS platform and field verification, the author obtains the information such as the distribution of open-pit abandoned mines, geological environment problems and ecological restoration in the study area. This paper mainly focus on the geological environment problems existing in abandoned mines and summarizes the ecological restoration measures. It is shown that it ’s a wide area need to be restored in Zhenjiang and Nanjing. The area of open-pit abandoned mines mainly focus on the quarries and transit sites of the mines, with construction limestone and construction sand mines as the main types of mines involved. The environmental problems mainly include topography and geomorphological destruction, geological disasters, ecological environment damage and soil and water pollution, etc. And the part rehabilitated and being rehabilitated of the study area show an increasing trend from 2018 to 2020. As of October 2020, the restoration area of abandoned mines has been effective, with 67.08% of the area restored. The main ecological restoration measures include natural restoration, soil backfilling, land leveling, slope cutting and integrated land management. It is recommended that the original landform of the mining area should be protected to the maximum extent and the land resources fully utilized when carrying out restoration and treatment. The results and suggestions provide technical reference for the ecological restoration and treatment of open-pit abandoned mines in the same type of area.
-
-
表 1 各监测年度影像类型
Table 1. Image types of each monitoring year
监测年份 数据类型 成像时间 空间分辨率/m 2017 BJ2 9—11月 1 2018 BJ2、GJ1 9—11月 0.5～1.0 2019 BJ2、GF2 9—11月 0.8～2.0 2020 GF6、GF2 9—10月 2
下载: 导出CSV
表 2 正在修复图斑统计表（2020年10月）
Table 2. Statistics of under restoration spot（Oct. 2020）
主要修复措施 工程数量 面积/hm2 场地平整 23 100.22 覆土堆填 14 135.85 削坡降坡 8 51.54
下载: 导出CSV
表 3 完成修复图斑统计表（2020年10月）
Table 3. Statistics of complete restoration spot（Oct. 2020）
修复前地类 修复后地类 修复措施 图斑数量 面积/hm2 采场 林地 覆土/废渣清运/
场地平整/种植/
自然复绿/
设置隔离栏3 6.64 草地 1 1.02 坑塘水面 2 8.21 空闲地 25 243.89 中转场地 耕地 废渣清运/覆土/
场地平整/种植/
复垦/建设房屋1 7.92 草地 1 3.82 工矿仓储用地 2 11.68 空闲地 19 82.74 固体废弃物 林地 废渣清运/覆土/
场地平整/种植1 0.56 空闲地 1 9.67 矿山建筑 空闲地 覆土/场地平整 2 9.44
下载: 导出CSV
-
[1] 吴传清, 黄磊. 长江经济带绿色发展的难点与推进路径研究[J]. 南开学报(哲学社会科学版),2017(3):50 − 61. [WU Chuanqing, HUANG Lei. The difficulties and approaches of green development in the Yangtze River Economic Belt[J]. Nankai Journal (Philosophy Literature and Social Science Edition),2017(3):50 − 61. (in Chinese with English abstract)
[2] 张玉韩, 王步清, 侯华丽. 长江经济带矿业产业协调发展研究[J]. 中国矿业,2018,25(8):58 − 63. [ZHANG Yuhan, WANG Buqing, HOU Huali. Research into the mining industry coordinated development of the Yangtze River Economic Belt[J]. China Mining Magazine,2018,25(8):58 − 63. (in Chinese with English abstract)
[3] 段学军, 虞孝感, 邹辉. 长江经济带开发构想与发展态势[J]. 长江流域资源与环境,2015,24(10):1621 − 1629. [DUAN Xuejun, YU Xiaogan, ZOU Hui. Analysis on the development strategy and trend of Yangtze River Economic Belt[J]. Resources and Environment in the Yangtze Basin,2015,24(10):1621 − 1629. (in Chinese with English abstract) doi: 10.11870/cjlyzyyhj201510001
[4] 武强, 陈奇. 矿山环境问题诱发的环境效应研究[J]. 水文地质工程地质,2008,35(5):81 − 85. [WU Qiang, CHEN Qi. An analysis of environmental effects induced by environmental problems in mines[J]. Hydrogeology & Engineering Geology,2008,35(5):81 − 85. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-3665.2008.05.019
[5] 李建中, 张进德. 我国矿山地质环境调查工作探讨[J]. 水文地质工程地质,2018,45(4):169 − 172. [LI Jianzhong, ZHANG Jinde. Discussion on the work of mine geo-environmental investigation of China[J]. Hydrogeology & Engineering Geology,2018,45(4):169 − 172. (in Chinese with English abstract)
[6] 殷亚秋, 杨金中, 汪洁, 等. 长江经济带废弃矿山占损土地遥感调查与生态修复对策[J]. 国土资源遥感,2020,32(2):170 − 176. [YIN Yaqiu, YANG Jinzhong, WANG Jie, et al. Remote sensing survey of land occupied and damaged by abandoned mines along the Yangtze River Economic Belt and research on ecological remediation countermeasures[J]. Remote Sensing For Land & Resources,2020,32(2):170 − 176. (in Chinese with English abstract)
[7] 刘向敏. 生态产品价值实现视域下矿山废弃地生态修复与重建[J]. 中国矿业,2020,29(11):72 − 75. [LIU Xiangmin. Ecological restoration and reconstruction of mining wasteland from the perspective of value realization of ecological products[J]. China Mining Magazine,2020,29(11):72 − 75. (in Chinese with English abstract)
[8] 武强, 陈奇. 矿山环境治理模式及其适用性分析[J]. 水文地质工程地质,2010,37(6):91 − 96. [WU Qiang, CHEN Qi. An analysis of the mine environmental treatment model and its applicability[J]. Hydrogeology & Engineering Geology,2010,37(6):91 − 96. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-3665.2010.06.018
[9] 陈绪钰. 基于多时相遥感数据的矿山生态环境动态变化研究[J]. 金属矿山,2011(10):127 − 130. [CHEN Xuyu. Study on dynamic variation of environment in the mine based on multi-temporal remote sensing data[J]. Metal Mine,2011(10):127 − 130. (in Chinese with English abstract)
[10] 贾斌, 宋少秋. 废弃矿山生态修复治理技术应用—以北京房山区废弃矿山为例[J]. 矿产勘查,2019,10(11):2831 − 2834. [JIA Bin, SONG Shaoqiu. Application of ecological restoration and treatment technology in abandoned mines: A case study on abandoned mines in Fangshan district, Beijing[J]. Mineral Exploration,2019,10(11):2831 − 2834. (in Chinese with English abstract) doi: 10.3969/j.issn.1674-7801.2019.11.021
[11] 常青, 杨希, 从常奎, 等. ArcGIS在矿山地质环境保护与治理恢复中的应用[J]. 中国地质灾害与防治学报,2014,25(1):131 − 134. [CHANG Qing, YANG Xi, CONG Changkui, et al. Application of ArcGIS in mining geological environment protection and recovery[J]. The Chinese Journal of Geological Hazard and Control,2014,25(1):131 − 134. (in Chinese with English abstract)
[12] 姜月华, 林良俊, 陈立德, 等. 长江经济带资源环境条件与重大地质问题[J]. 中国地质,2017,44(6):1045 − 1061. [JIANG Yuehua, LIN Liangjun, CHEN Lide, et al. Research on conditions of resources and environment and major geological problems in the Yangtze River Economic Zone[J]. Geology in China,2017,44(6):1045 − 1061. (in Chinese with English abstract)
[13] 成金华, 彭昕杰. 长江经济带矿产资源开发对生态环境的影响及对策[J]. 环境经济研究,2019,4(2):125 − 134. [CHENG Jinhua, PENG Xinjie. Influence of mineral resources development on ecological environment in Yangtze River Economic Belt and its countermeasures[J]. Journal of Environmental Economics,2019,4(2):125 − 134. (in Chinese with English abstract)
[14] 杨金中, 秦绪文, 聂洪峰, 等. 中国矿山遥感监测[M]. 北京: 测绘出版社, 2014.
YANG Jinzhong, QIN Xuwen, NIE Hongfeng, et al. Remote sensing monitoring of mine in China[M]. Beijing: Sino Maps Press, 2014. (in Chinese)
[15] 矿产资源开发遥感监测技术规范: DZ/T 0266—2014[S]. 北京: 中国标准出版, 2014: 2 − 8.
Ministry of Land and Resources of the People’s Republic of China. Regulation on remote sensing monitoring of mining exploration: DZ/T 0266—2014[S]. Beijing: Standards Press of China, 2014: 2 − 8. (in Chinese)
[16] 张进德, 郗富瑞. 我国废弃矿山生态修复研究[J]. 生态学报,2020,40(21):7921 − 7930. [ZHANG Jinde, XI Furui. Study on ecological restoration of abandoned mines in China[J]. Acta Ecologica Sinica,2020,40(21):7921 − 7930. (in Chinese with English abstract)
[17] 王成. 历史遗留工矿废弃地复垦潜力及对策分析: 以重庆市永川区为例[J]. 农业与技术,2019,39(22):179 − 180. [WANG Cheng. An analysis on the reclamation potential and countermeasures of industrial and mining wasteland left over from history: A case study of Yongchuan District of Chongqing City[J]. Agriculture & Technology,2019,39(22):179 − 180. (in Chinese)
[18] 崔文静, 黄敬军, 韩涛, 等. 徐州市矿山环境地质问题及防治对策[J]. 中国地质灾害与防治学报,2007,18(4):93 − 97. [CUI Wenjing, HUANG Jingjun, HAN Tao, et al. The mine environmental geological problems and countermeasures of prevention and control in Xuzhou City[J]. The Chinese Journal of Geological Hazard and Control,2007,18(4):93 − 97. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-8035.2007.04.020
[19] 李强. 黑龙江省矿山主要环境地质问题及防治对策[J]. 中国地质灾害与防治学报,2008,19(3):120 − 123. [LI Qiang. Environmental geological problems caused by mining in Heilongjiang Province[J]. The Chinese Journal of Geological Hazard and Control,2008,19(3):120 − 123. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-8035.2008.03.026
[20] 周建海, 张林泽. 浙江余姚废弃露采普通建筑石料矿综合整治实践[J]. 科技创新导报,2016,13(2):8 − 9. [ZHOU Jianhai, ZHANG Linze. Comprehensive treatment practice of abandoned open-pit ordinary building stone mine in Yuyao, Zhejiang Province[J]. Science and Technology Innovation Herald,2016,13(2):8 − 9. (in Chinese)
[21] 欧哲, 王铁, 杨家富, 等. 废弃矿山破碎岩质边坡地质环境治理[J]. 金属矿山,2017(7):178 − 185. [OU Zhe, WANG Tie, YANG Jiafu, et al. Geological environment treatment of broken rock slope in abandoned mines[J]. Metal Mine,2017(7):178 − 185. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-1250.2017.07.037
[22] 邓小芳. 中国典型矿区生态修复研究综述[J]. 林业经济,2015,37(7):14 − 19. [DENG Xiaofang. China’s typical mining area ecological restoration research review[J]. Forestry Economics,2015,37(7):14 − 19. (in Chinese with English abstract)
[23] 刘洋. 无主砂石矿山生态恢复综合规划治理模式探讨[J]. 中国国土资源经济,2019,32(1):67 − 70. [LIU Yang. Discussion on the model of comprehensive planning and management of ecological restoration about unowned sand mine[J]. Natural Resource Economics of China,2019,32(1):67 − 70. (in Chinese with English abstract)
[24] 刘育平, 关凤峻. 论矿山生态修复的投融资模式[J]. 水文地质工程地质,2020,47(3):194 − 197. [LIU Yuping, GUAN Fengjun. Discussion on the investment and financing mode of mine ecological restoration[J]. Hydrogeology & Engineering Geology,2020,47(3):194 − 197. (in Chinese with English abstract)
-
