Site selection evaluation of engineering geology of the Lenghu Saishiteng Mountain Observatory
-
摘要:
青海省冷湖赛什腾山具有国际一流的光学天文观测条件，是我国光学天文发展的宝贵战略资源。围绕冷湖赛什腾山天文台建设面临的工程地质选址问题，在收集前人已开展的地质调查成果的基础上，利用遥感影像、无人机航拍、数值模拟和人工地面调查相结合的方法进行工程地质选址评价。为了确保赛什腾山已经确定的2处已建平台和2处空置平台的工程地质稳定性，首先进行了人工地面踏勘、采取岩石样品和模拟地震作用下已建平台的边坡三维响应研究，以确定平台的稳定性；在重点工作区使用InSAR监测分析地形形变，确定重点工作区工程地质稳定性；最后使用BP神经网络模型算法对赛什腾山地区进行区域工程地质稳定性评价。评价结果表明：2处已建平台虽有断层分布但对工程建设的影响较小；2处空置平台场地内及周边未发现断层破碎带及断裂构造通过。基于分析结果，建议尽量减少在填方区布设工程及重要设备，保证填方边坡坡度小于自然休止角，对于人工开挖或填筑形成的碎石土边坡应进行适当工程处理以确保工程安全及设备正常使用，并基于不同层次的评价结果推荐出4 300 m与4 050 m 2个平台。
Abstract:The Lenghu Saishiteng Mountain in Qinghai Province has the international first-class optical astronomy observation conditions. It creates a major opportunity for the development of optical astronomy in China and provides a valuable strategic resource for international optical astronomy development. Closely focusing on the engineering and geological site selection problem facing the construction of the Lenghu Saishiteng Mountain Observatory, the engineering and geological site selection evaluation is carried out on the basis of extensive collection of the geological survey results obtained by previous authors, by using a combination of remote sensing images, unmanned aerial photography, numerical simulation and manual ground survey. At this stage, two constructed platforms and two vacant platforms have been identified in Mount Saishiteng. In order to ensure the stability of engineering geological conditions of the constructed platforms and vacant platforms, firstly, manual ground investigation, rock samples and 3D response of slopes of constructed platforms under simulated seismic effects are conducted to determine the stability of platforms. InSAR monitoring and analysis of terrain deformation is then used in the key working area to determine the engineering geological stability of the key working area, and the BP neural network model algorithm is finally used to evaluate the regional engineering and geological stability of the Saishiteng Mountain area. The evaluation results show that although there are faults in the two constructed platforms, the impact on the construction is relatively small; no fault fragmentation zones and fracture structures are found in and around the two vacant platforms. Suggestions are made for the construction of the observatory to minimize the placement of engineering works and important equipment in the filling area, to ensure that the slope of the filling side slope is less than the natural rest angle, and to carry out appropriate engineering treatment for the rubble soil side slopes formed by manual excavation or filling ensure engineering safety and normal use of equipment. At the same time, two recommended platforms of 4300 m and 4050 m are recommended based on the evaluation results of different levels.
-
-
表 1 断层赋值表
Table 1. Fault assignment table
断层等级 缓冲区1 缓冲区2 缓冲区3 缓冲区4 缓冲区5 距离/m 赋值 距离/m 赋值 距离/m 赋值 距离/m 赋值 距离/m 赋值 1级断层 1000 20 2000 16 3000 12 4000 8 5000 4 2级断层 300 15 600 12 900 9 1200 6 1500 3 3级断层 100 10 200 8 300 6 400 4 500 2 4级断层 30 5 60 4 90 3 120 2 150 1
下载: 导出CSV
表 2 岩体、土体强度状况赋值表
Table 2. Assignment of rock mass and soil condition
岩体、土体 赋值结果 晚二叠世坚硬块状侵入岩岩组 10 晚奥陶世坚硬块状侵入岩岩组 9 坚硬、较坚硬的片状熔岩岩组 8 早古生代火山岩岩组 7 较坚硬片状砾、砂、板、千枚岩岩组 6 软硬相间层-薄层状变质砾、砂岩及页岩岩组；软硬相
间层-薄层状变质岩或碎屑岩夹碳酸盐岩岩组；软硬
相间层-薄层状碳酸盐岩与变质岩或碎屑岩岩组5 晚奥陶世石英闪长花岗岩 4 软弱层状-薄层状砂泥岩岩组 3 软弱层状砂、泥（灰）岩岩组 2 黏性土、盐渍土、砂类土、卵砾类土 1 苏干湖 0
下载: 导出CSV
表 3 平台工程适宜性评价
Table 3. Platform engineering suitability evaluation
平台类别 评价得分 已建平台（3830 m平台） 6.57942 已建平台（4200 m平台） 7.32686 空置平台（4100 m平台） 7.21152 空置平台（4000 m平台） 7.41247 推荐平台（4300 m平台） 7.62298 推荐平台（4050 m平台） 7.13246
下载: 导出CSV
-
[1] MOREL S, BALLESTER P, BAUVIR B, et al. Preparing MIDI science operation at VLTI[C]//New Frontiers in Stellar Interferometry. Bellingham: SPIE-the International Society for Optical Engineering, 2004, 5491: 1666 − 1677.
[2] MA B, SHANG Z, HU Y, et al. Night-time measurements of astronomical seeing at Dome A in Antarctica[J]. Nature,2020,583(7818):771 − 774. doi: 10.1038/s41586-020-2489-0
[3] 张柏荣, 于建明, 谭徽松. 中国第三次天文台选址高潮及对丽江高美古地区天文观测条件的初步估计[J]. 天文研究与技术,1996(增刊1):1 − 8. [ZHANG Bairong, YU Jianming, TAN Huisong. The third high tide of astronomical site selection in China and primary estimation of astronomical observation conditions at gaomeigu Lijiang Yunnan[J]. Astronomical Research & Technology,1996(Sup1):1 − 8. (in Chinese with English abstract)
ZHANG Bairong, YU Jianming, TAN Huisong. The third high tide of astronomical site selection in China and primary estimation of astronomical observation conditions at gaomeigu Lijiang Yunnan[J]. Astronomical Research & Technology, 1996(S1): 1-8. (in Chinese with English abstract)
[4] 戎昭金, 崔峻, 何飞, 等. 我国行星物理学的发展现状与展望[J]. 中国科学院院刊,2019,34(7):760 − 768. [RONG Zhaojin, CUI Jun, HE Fei, et al. Status and prospect for Chinese planetary physics[J]. Bulletin of Chinese Academy of Sciences,2019,34(7):760 − 768. (in Chinese with English abstract)
RONG Zhaojin, CUI Jun, HE Fei, et al. Status and prospect for Chinese planetary physics[J]. Bulletin of Chinese Academy of Sciences, 2019, 34(7): 760-768. (in Chinese with English abstract)
[5] REN Y, ZHANG D X, ZHOU K M, et al. 10.6 μm heterodyne receiver based on a superconducting hot-electron bolometer mixer and a quantum cascade laser[J]. AIP Advances,2019,9(7):075307. doi: 10.1063/1.5090132
[6] FU Y, LI L, WANG D, et al. 28-GHz CMOS VCO with capacitive splitting and transformer feedback techniques for 5G communication[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems,2019,27(9):2088 − 2095. doi: 10.1109/TVLSI.2019.2914481
[7] 戴锦程, 郑玉元, 郭明, 等. 结构面赤平投影极点图的统计分形在岩体工程分类中的应用—以中科院国家天文台500米口径大射电望远镜(FAST)台址为例[J]. 贵州地质,2010,27(4):309 − 311. [DAI Jincheng, ZHENG Yuyuan, GUO Ming, et al. The application of statistic fractal stereographic projection point diagram of structural plane in the rock mass engineering classification:Take the FAST of science national astronomical observatories of the Chinese academy of science as the example[J]. Guizhou Geology,2010,27(4):309 − 311. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-5943.2010.04.016
DAI Jincheng, ZHENG Yuyuan, GUO Ming, et al. The application of statistic fractal stereographic projection point diagram of structural plane in the rock mass engineering classification——take the FAST of science national astronomical observatories of the Chinese academy of science as the example[J]. Guizhou Geology, 2010, 27(4): 309-311. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-5943.2010.04.016
[8] JIANG P, TANG N Y, HOU L G, et al. The fundamental performance of FAST with 19-beam receiver at L band[J]. Research in Astronomy and Astrophysics,2020,20(5):64. doi: 10.1088/1674-4527/20/5/64
[9] DENG L, YANG, CHEN X, et al. Lenghu on the Tibetan Plateau as an astronomical observing site[J]. Nature,2021,596(7872):353 − 356. doi: 10.1038/s41586-021-03711-z
[10] 何飞, 尧中华, 魏勇. 冷湖行星光学遥感发展与展望[J]. 地球与行星物理论评,2021,52(4):361 − 372. [HE Fei, YAO Zhonghua, WEI Yong. Development and prospect of planetary optical remote sensing at Lenghu[J]. Reviews of Geophysics and Planetary Physics,2021,52(4):361 − 372. (in Chinese with English abstract)
HE Fei, YAO Zhonghua, WEI Yong. Development and prospect of planetary optical remote sensing at Lenghu[J]. Reviews of Geophysics and Planetary Physics, 2021, 52(4): 361-372. (in Chinese with English abstract)
[11] 张永双, 雷伟志, 石菊松, 等. 四川省北川县擂鼓盆地地壳稳定性与城镇选址[J]. 地质学报,2008,82(12):1758 − 1768. [ZHANG Yongshuang, LEI Weizhi, SHI Jusong, et al. Crustal stability of the leigu basin in Beichuan County, Sichuan Province and its possibility for a new town site[J]. Acta Geologica Sinica,2008,82(12):1758 − 1768. (in Chinese with English abstract) doi: 10.3321/j.issn:0001-5717.2008.12.011
ZHANG Yongshuang, LEI Weizhi, SHI Jusong, et al. Crustal stability of the leigu basin in Beichuan County, Sichuan Province and its possibility for a new town site[J]. Acta Geologica Sinica, 2008, 82(12): 1758-1768. (in Chinese with English abstract) doi: 10.3321/j.issn:0001-5717.2008.12.011
[12] 尚彦军, 李坤, 王开洋. 从施工地质灾害看岩体结构动态控制作用[J]. 岩石力学与工程学报,2013,32(6):1129 − 1136. [SHANG Yanjun, LI Kun, WANG Kaiyang. Insights of innovation and development of rock mass structure dynamic controlling froconstruction-triggered geohazard[J]. Chinese Journal of Rock Mechanics and Engineering,2013,32(6):1129 − 1136. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-6915.2013.06.006
SHANG Yanjun, LI Kun, WANG Kaiyang. Insights of innovation and development of rock mass structure dynamic controlling Froconstruction-Triggered geohazard[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(6): 1129-1136. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-6915.2013.06.006
[13] 胡海涛. 区域地壳稳定性评价的“安全岛”理论及方法[J]. 地质力学学报,2001,7(2):97 − 103. [HU Haitao. The theory and method of evaluation of regional crustal stability based on concept of “safe island”[J]. Journal of Geomechanics,2001,7(2):97 − 103. (in Chinese with English abstract) doi: 10.3969/j.issn.1006-6616.2001.02.001
HU Haitao. The theory and method of evaluation of regional crustal stability based on concept of “safe island”[J]. Journal of Geomechanics, 2001, 7(2): 97-103. (in Chinese with English abstract) doi: 10.3969/j.issn.1006-6616.2001.02.001
[14] 付恒阳, 张静, 周渊博. 陕南移民工程选址空间适宜性评价—以陕西省西乡县为例[J]. 地域研究与开发,2018,37(5):43 − 47. [FU Hengyang, ZHANG Jing, ZHOU Yuanbo. Spatial suitability evaluation of site selection for resettlement project in southern Shannxi:A case of Xixiang County[J]. Areal Research and Development,2018,37(5):43 − 47. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-2363.2018.05.008
FU Hengyang, ZHANG Jing, ZHOU Yuanbo. Spatial suitability evaluation of site selection for resettlement project in southern shannxi: a case of Xixiang County[J]. Areal Research and Development, 2018, 37(5): 43-47. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-2363.2018.05.008
[15] 王学良, 韩振华, 张路青, 等. 高放废物地质处置阿拉善预选区工程地质适宜性评价[J]. 工程地质学报,2018,26(6):1715 − 1723. [WANG Xueliang, HAN Zhenhua, ZHANG Luqing, et al. Regional engineering geology suitability assessment for high-level radioactive waste disposal of pre-selected Alxa area[J]. Journal of Engineering Geology,2018,26(6):1715 − 1723. (in Chinese with English abstract)
WANG Xueliang, HAN Zhenhua, ZHANG Luqing, et al. Regional engineering geology suitability assessment for high-level radioactive waste disposal of pre-selected alxa area[J]. Journal of Engineering Geology, 2018, 26(6): 1715-1723. (in Chinese with English abstract)
[16] RICHARDSON C P, AMANKWATIA K. GIS-based analytic hierarchy process approach to watershed vulnerability in Bernalillo County, new Mexico[J]. Journal of Hydrologic Engineering,2018,23(5):1 − 11.
[17] 陈德茂, 沈志平, 姜鹏, 等. 国家天文台500米口径球面射电望远镜台址球冠型边坡稳定性分析[J]. 水文地质工程地质,2021,48(4):116 − 123. [CHEN Demao, SHEN Zhiping, JIANG Peng, et al. An analysis of the stability of the spherical-cap shaped slope at the Five-hundred-meter Aperture Spherical radio Telescope (FAST), China[J]. Hydrogeology & Engineering Geology,2021,48(4):116 − 123. (in Chinese with English abstract)
CHEN Demao, SHEN Zhiping, JIANG Peng, et al. An analysis of the stability of the spherical-cap shaped slope at the Five-hundred-meter Aperture Spherical radio Telescope(FAST), China[J]. Hydrogeology & Engineering Geology, 2021, 48(4): 116-123. (in Chinese with English abstract)
[18] 卢晓航, 毛晓勇. 青海省赛什腾山地区构造特征及靶区优选[J]. 青海国土经略,2015(6):65 − 67. [LU Xiaohang, MAO Xiaoyong. Structural characteristics and target optimization of Saishitengshan area, Qinghai Province[J]. Management & Strategy of Qinghai Land & Resources,2015(6):65 − 67. (in Chinese) doi: 10.3969/j.issn.1671-8704.2015.06.023
LU Xiaohang, MAO Xiaoyong. Structural characteristics and target optimization of saishitengshan area, Qinghai Province[J]. Management & Strategy of Qinghai Land & Resources, 2015(6): 65-67. (in Chinese) doi: 10.3969/j.issn.1671-8704.2015.06.023
[19] 谢涛, 陆凡. 青海望北沟金矿地质特征及找矿潜力分析[J]. 中国金属通报,2020(16):55 − 56. [XIE Tao, LU Fan. Analysis of geological characteristics and mineral search potential of Qinghai Wangbegou Gold Mine[J]. China Metal Bulletin,2020(16):55 − 56. (in Chinese) doi: 10.3969/j.issn.1672-1667.2020.16.028
XIE Tao, LU Fan. Analysis of Geological Characteristics and Mineral Search Potential of Qinghai Wangbegou Gold Mine[J]. China Metal Bulletin, 2020(16): 55-56. . (in Chinese) doi: 10.3969/j.issn.1672-1667.2020.16.028
[20] 李坤, 尚彦军, 蒋毅, 等. 基于改进多因素相互作用关系矩阵的场址评价— 以CSNS工程选址为例[J]. 岩土力学,2016,37(增刊 1):400 − 408. [LI Kun, SHANG Yanjun, JIANG Yi, et al. Site evaluation system based on modified multifactor interaction matrix:A case study of CSNS project site[J]. Rock and Soil Mechanics,2016,37(Sup 1):400 − 408. (in Chinese with English abstract)
LI Kun, SHANG Yanjun, JIANG Yi, et al. Site evaluation system based on modified multifactor interaction matrix—A case study of CSNS project site[J]. Rock and Soil Mechanics, 2016, 37(Sup 1): 400 − 408. (in Chinese with English abstract)
[21] LI K, SHANG Y, HE W, et al. An engineering site suitability index (ESSI) for the evaluation of geological situations based on a multi-factor interaction matrix[J]. Bulletin of Engineering Geology and the Environment,2019,78(1):569 − 577. doi: 10.1007/s10064-017-1122-4
[22] MONDRAGON A E C, MASTROCINQUE E, TSAI J F, et al. An AHP and fuzzy AHP multifactor decision making approach for technology and supplier selection in the high-functionality textile industry[J]. IEEE Transactions on Engineering Management,2021,68(4):1112 − 1125. doi: 10.1109/TEM.2019.2923286
[23] 姚鑫, 张路青, 李凌婧, 等. 工程场址区域地壳稳定性InSAR评价研究[J]. 工程地质学报,2021,29(1):104 − 115. [YAO Xin, ZHANG Luqing, LI Lingjing, et al. Insar observing the regional crustal stability of engineering sites[J]. Journal of Engineering Geology,2021,29(1):104 − 115. (in Chinese with English abstract)
YAO Xin, ZHANG Luqing, LI Lingjing, et al. Insar observing the regional crustal stability of engineering sites[J]. Journal of Engineering Geology, 2021, 29(1): 104-115. (in Chinese with English abstract)
[24] 蔡学林, 徐赣清. 关于构造断层的分类命名问题[J]. 成都地质学院学报,1982,9(1):25 − 36. [CAI Xuelin, XU Ganqing. On the classification and nomenclature of structural faults[J]. Journal of Chengdu University of Technology (Science & Technology Edition),1982,9(1):25 − 36. (in Chinese)
CAI Xuelin, XU Ganqing. On the classification and nomenclature of structural faults [J]. Journal of Chengdu University of Technology: Science & Technology Edition, 1982, 9(1): 25-36. (in Chinese)
[25] HARTIGAN J A, WONG M A. Algorithm AS 136:A K-means clustering algorithm[J]. Journal of the Royal Statistical Society. Series C (Applied Statistics),1979,28(1):100 − 108. doi: 10.2307/2346830
[26] HOPFIELD J J. Neurons with graded response have collective computational properties like those of two-state neurons[J]. Proc Natl Acad Sci USA,1984,81(10):3088 − 3092. doi: 10.1073/pnas.81.10.3088
[27] RUMELHART D E, HINTON G E, WILLIAMS R J. Learning representations by back-propagating errors[J]. Nature,1986,323(6088):533 − 536. doi: 10.1038/323533a0
[28] 李敬明, 倪志伟, 朱旭辉, 等. 基于佳点萤火虫算法与BP神经网络并行集成学习的旱情预测模型[J]. 系统工程理论与实践,2018,38(5):1343 − 1353. [LI Jingming, NI Zhiwei, ZHU Xuhui, et al. Drought prediction model based on GPSGSO-BPNN parallel ensemble learning algorithm[J]. Systems Engineering-Theory & Practice,2018,38(5):1343 − 1353. (in Chinese with English abstract) doi: 10.12011/1000-6788(2018)05-1343-11
LI Jingming, NI Zhiwei, ZHU Xuhui, et al. Drought prediction model based on GPSGSO-BPNN parallel ensemble learning algorithm[J]. Systems Engineering-Theory & Practice, 2018, 38(5): 1343-1353. (in Chinese with English abstract) doi: 10.12011/1000-6788(2018)05-1343-11
[29] 任文恺, 晁海德, 王生云, 等. 青海省赛什腾山地区三角顶金矿区地质、地球化学特征及找矿方向[J]. 黄金,2018,39(9):13 − 17. [REN Wenkai, CHAO Haide, WANG Shengyun, et al. Geological, geochemical characteristics and prospecting direction of the Sanjiaoding Gold District in Saishiteng Mountain area, Qinghai Province[J]. Gold,2018,39(9):13 − 17. (in Chinese with English abstract) doi: 10.11792/hj20180903
REN Wenkai, CHAO Haide, WANG Shengyun, et al. Geological, geochemical characteristics and prospecting direction of the Sanjiaoding Gold District in Saishiteng Mountain area, Qinghai Province[J]. Gold, 2018, 39(9): 13-17. (in Chinese with English abstract) doi: 10.11792/hj20180903
[30] 谢海东, 鲁海妍, 张莹, 等. 青海省冷湖镇小赛什腾山地区奥陶纪闪长岩岩石化学特征及时代探讨[J]. 资源信息与工程,2019,34(6):13 − 16. [XIE Haidong, LU Haiyan, ZHANG Ying, et al. Petrochemical characteristics and age of Ordovician diorite in Xiaosaishitengshan area, Lenghu Town, Qinghai Province[J]. Resource Information and Engineering,2019,34(6):13 − 16. (in Chinese)
XIE Haidong, LU Haiyan, ZHANG Ying, et al. Petrochemical Characteristics and age of Ordovician diorite in Xiaosaishitengshan area, Lenghu Town, Qinghai Province[J]. Resource Information and Engineering, 2019, 34(6): 13-16. (in Chinese)
[31] 王文沛, 殷跃平, 李滨, 等. 不同坡角斜坡动力响应频谱特征研究[J]. 岩石力学与工程学报,2015,34(1):121 − 128. [WANG Wenpei, YIN Yueping, LI Bin, et al. Spectral characteristics of dynamic response of slope with different angles of inclination[J]. Chinese Journal of Rock Mechanics and Engineering,2015,34(1):121 − 128. (in Chinese with English abstract)
WANG Wenpei, YIN Yueping, LI Bin, et al. Spectral characteristics of dynamic response of slope with different angles of inclination[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34(1): 121-128. (in Chinese with English abstract)
-
