Research on the micro-characteristics of solidified waste sludge under the effect of three factors
-
摘要:
为揭示初始含水率、固化剂掺量和龄期3种因素对固化废弃淤泥力学性质影响的本质，以硫氧镁水泥固化废弃淤泥为研究对象，开展了不同含水率（w）、固化剂掺量（Wg）和龄期（T）条件下固化淤泥的电镜扫描试验，利用图像处理软件研究了固化淤泥的微观接触面积率（RCA）、平均丰度（Cm）和分形维数（D）受含水率、固化剂掺量和龄期的影响规律。结果发现：含水率的增加会抑制硫氧镁水泥的水化，增加固化淤泥结构的分散性，进而减小固化淤泥的接触面积率、平均丰度，提高其分形维数。而固化剂掺量和龄期有利于固化反应的发展，促进扁圆状固化产物的生成，提高固化淤泥结构的紧密性，从而增加固化淤泥的接触面积率、平均丰度，降低其分形维数。3种因素中，龄期对固化淤泥的接触面积率和分形维数影响最为显著。
Abstract:To essentially investigate the effect-mechanism of water contents (w), curing agent dosages (Wg) and ages (T) on the mechanical behavior of stabilized waste sludge, a series of Scanning Electron Microscope (SEM) tests under different w, Wg and T are conducted by taking the waste sludge solidified by magnesium oxysulfate cement as the research object. The effects of w, Wg and T on the micro-parameters of the stabilized sludge such as contact area ratio (RCA), average abundance (Cm) and fractal dimension (D) are addressed by using the Image Pro Plus. The results show that the increase in w will prevent the hydration of magnesium oxysulfate cement and enhance the dispersibility of the microstructure of the stabilized sludge, further decrease the values of RCA and Cm and improve the value of D. Among the aforementioned three factors, T has a significant influence on the development of RCA and D, and Wg plays an important role in the evolution of Cm.
-
Key words:
- solidified sludge /
- microstructure /
- contact area ratio /
- average abundance /
- fractal dimension
-
-
表 1 SEM试验方案
Table 1. Test plan of the SEM
试验编号 Wg/% w/% T/d SS0 0 50 7 S0 15 50 7 S1—S4 15 40, 45, 55, 60 7 S5—S8 5, 10, 20, 25 50 7 S9—S13 15 50 3, 5, 9, 11, 14
下载: 导出CSV
表 2 不同含水率下固化淤泥的接触面积比
Table 2. Contact area ratio of the solidified sludge under different moisture content
试验编号 w/% ST n n3D Z SCA RCA/% S1 40 1173991 0.448 0.431 123 170246 14.5 S2 45 1173991 0.481 0.472 103 156439 13.3 S0 50 1173991 0.487 0.479 168 112026 9.5 S3 55 1173991 0.512 0.513 109 101842 8.7 S4 60 1173991 0.521 0.525 119 96127 8.2 注：ST为总像素；n为实测孔隙率；n3D为三维孔隙率； SCA为接触像素。
下载: 导出CSV
表 3 不同固化剂掺量下固化土的接触面积率
Table 3. Contact area ratio of the solidified soil under different dosage of the curing agent
试验编号 Wg/% ST n n3D Z SCA RCA/% S5 5 1173991 0.548 0.539 169 88840 7.6 S6 10 1173991 0.505 0.511 162 100879 8.6 S0 15 1173991 0.487 0.479 167 112026 9.5 S7 20 1173991 0.481 0.482 157 141446 12.0 S8 25 1173991 0.459 0.461 161 164565 14.0
下载: 导出CSV
表 4 不同龄期下固化淤泥的接触面积率
Table 4. Contact area ratio of the solidified sludge at different ages
试验编号 T/d ST n n3D Z SCA RCA/% S9 3 1173991 0.548 0.538 167 85645 7.3 S10 5 1173991 0.524 0.512 156 91412 7.8 S0 7 1173991 0.487 0.479 167 112026 9.5 S11 9 1173991 0.438 0.431 136 117039 9.9 S12 11 1173991 0.468 0.452 122 132245 12.5 S13 14 1173991 0.435 0.433 103 135532 15.4
下载: 导出CSV
-
