粉煤灰基地聚物加固土的强度及抗冻融性能试验研究

陈忠清; 朱泽威; 吕越

doi:10.16030/j.cnki.issn.1000-3665.202111045

粉煤灰基地聚物加固土的强度及抗冻融性能试验研究

1.
绍兴文理学院土木工程学院, 浙江绍兴　312000

2.
浙江省岩石力学与地质灾害重点实验室, 浙江绍兴　312000

基金项目: 浙江省自然科学基金项目（LY22D020001）

详细信息

作者简介: 陈忠清（1984-），男，博士，副教授，主要从事地基处理及固体废弃物资源化研究。E-mail：q_chen_yk@163.com

中图分类号: TU411.6

收稿日期: 2021-11-16

修回日期: 2021-12-23

刊出日期: 2022-07-25

Laboratory investigation on the strength and freezing-thawing resistance of fly ash based geopolymer stabilized soil

1.
School of Civil Engineering, Shaoxing University, Shaoxing, Zhejiang　312000, China

2.
Key Laboratory of Rock Mechanics and Geohazards of Zhejiang Province, Shaoxing, Zhejiang　312000, China

Received Date: 16 November 2021

Revised Date: 23 December 2021

Publish Date: 25 July 2022

摘要

摘要:
粉煤灰基地聚物作为一种低碳胶凝材料，在地基处理中的应用越来越受到关注。但是目前关于碱激发胶凝材料加固土在冻融极端气候条件下的工程特性尚不清楚，有必要进一步开展冻融循环条件下加固土的强度、变形特征及其影响因素研究。通过室内试验研究了原材料硅铝比、碱激发剂模数及碱溶液浓度对粉煤灰基地聚物固化土的强度与抗冻融性能的影响及微观机理。结果表明：地聚物加固土的无侧限抗压强度在碱激发剂模数增大及碱溶液浓度减小条件下，表现出降低趋势，而与原材料硅铝比之间在1.15~1.35范围内呈现出正相关变化趋势，28 d地聚物加固土的无侧限抗压强度最高可达8.98 MPa；当硅铝比在1.25~1.35范围、碱溶液浓度为5.42~22.78 mol/L时，28 d地聚物加固土能够抵御1次以上冻融循环，最高可达6次；地聚物加固土表现出最佳的抗冻融性能与聚合反应生成的凝胶数量多且以富硅相为主相关，而表现出抗压强度高则与聚合反应生成的凝胶数量多且以富铝相为主相关。研究成果将为粉煤灰地基地聚物加固土配合比设计提供技术参考，促进碱激发胶凝材料在地基处理中的应用。
- 地基处理 /
- 粉煤灰基地聚物 /
- 黏性土 /
- 冻融循环 /
- 无侧限抗压强度
Abstract:
As a low-carbon cementitious material, the application of fly ash based geopolymer in ground improvement has attracted more and more attention. However, the engineering characteristics of the soil stabilized by alkali activated cementitious material under the freezing-thawing extreme climate conditions are not clear. It is necessary to further study the strength, deformation characteristics and their influencing factors of the improved soil under the freezing-thawing cycle. Several laboratory tests are carried out to investigate the effects of the ratio of silicon to aluminum in raw material (Si/Al), modulus of alkali-activator and alkali solution concentration on the unconfined compressive strength (UCS) and the freezing-thawing resistance of fly ash based geopolymer stabilized soil, and the corresponding micro mechanism. The results show that (1) the UCS of geopolymer stabilized soil decreases with the increasing alkali-activator modulus and the decreasing alkali solution concentration, while increases with the Si/Al value in the range of 1.15 to 1.35, and the unconfined compressive strength of 28 d geopolymer stabilized soil can reach 8.98 MPa. (2) When the Si/Al value changes from 1.25 to 1.35 and the alkali solution concentration is within the range of 5.42 to 22.78 mol/L, the 28 d geopolymer stabilized soil can resist more than one (up to 6) freezing-thawing cycle. (3) The best performance of the freezing-thawing resistance of fly ash based geopolymer stabilized soil is mainly related to large number of Si-rich aluminosilicate gel generated by polymerization, while the highest compressive strength is related to the amount of Al-rich aluminosilicate gel generated by polymerization. The research results will provide technical reference for the mix design of soil stabilization with fly ash based geopolymer, and promote the application of alkali activated cementitious material in ground improvement.
- ground improvement /
- fly ash based geopolymer /
- cohesive soil /
- freezing-throwing cycle /
- unconfined compressive strength

HTML全文

图 1 试验材料的级配曲线

Figure 1.

下载: 全尺寸图片幻灯片

图 2 粉煤灰及试验用土的XRD图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 地聚物加固土28 d无侧限抗压强度变化曲线

Figure 3.

下载: 全尺寸图片幻灯片

图 4 吸水量与冻融循环数随模数变化曲线

Figure 4.

下载: 全尺寸图片幻灯片

图 5 地聚物加固土的XRD图

Figure 5.

下载: 全尺寸图片幻灯片

图 6 地聚物加固土的SEM图

Figure 6.

下载: 全尺寸图片幻灯片

图 7 地聚物加固土中凝胶的EDS图谱

Figure 7.

下载: 全尺寸图片幻灯片

图 8 地聚物加固土、地聚物及原材料的FTIR结果

Figure 8.

下载: 全尺寸图片幻灯片

表 1 试验用土的主要物理性质指标

Table 1. Main physical properties of the test soil

天然含水率w/%	液限w_L/%	塑限w_P/%	液性指数I_L	塑性指数I_P
43.0	45.0	22.5	0.91	22.5

下载: 导出CSV

表 2 试验分组

Table 2. Test groups

组号	Si/Al	M	L/S	C/（mol·L⁻¹）	A	B
A1	1.15	1.0	0.3	4.66	2.17	0.67
A2	1.15	1.2	0.3	3.25	2.25	0.71
A3	1.15	1.4	0.3	2.20	2.32	0.75
A4	1.15	1.6	0.3	1.40	2.38	0.78
A5	1.15	1.8	0.3	0.76	2.42	0.80
B1	1.20	1.0	0.3	7.42	1.90	0.97
B2	1.20	1.2	0.3	5.09	1.97	1.05
B3	1.20	1.4	0.3	3.57	2.07	1.15
B4	1.20	1.6	0.3	2.27	2.12	1.23
B5	1.20	1.8	0.3	1.25	2.18	1.29
C1	1.25	1.0	0.3	11.00	1.69	1.29
C2	1.25	1.2	0.3	8.10	1.78	1.46
C3	1.25	1.4	0.3	5.42	1.86	1.65
C4	1.25	1.6	0.3	3.50	1.93	1.80
C5	1.25	1.8	0.3	1.92	1.98	1.94
D1	1.30	1.0	0.3	15.89	1.52	1.64
D2	1.30	1.2	0.3	11.53	1.62	1.95
D3	1.30	1.4	0.3	8.09	1.70	2.26
D4	1.30	1.6	0.3	5.28	1.76	2.56
D5	1.30	1.8	0.3	2.94	1.81	2.86
E1	1.35	1.0	0.3	22.78	1.38	2.02
E2	1.35	1.2	0.3	17.05	1.48	2.51
E3	1.35	1.4	0.3	12.23	1.56	3.04
E4	1.35	1.6	0.3	8.13	1.62	3.61
E5	1.35	1.8	0.3	4.61	1.67	4.23

下载: 导出CSV

表 3 地聚物加固土的冻融循环次数

Table 3. Freezing-thawing cycles of different groups

组号	C1	C2	C3	D1	D2	D3	E1	E2	E3
冻融循环次数	2	2	2	3	3	2	6	4	3
注：其余试验组的冻融循环次数均小于2次。

下载: 导出CSV

参考文献(30)

[1]	（法）约瑟夫·戴维德维斯. 地聚合物化学及应用[M]. 王克俭, 译. 北京: 国防工业出版社, 2011: 3 − 6 DAVIDOVITS J. Geopolymer chemistry & applications[M]. WANG Kejian, trans. Beijing: National Defense Industry Press, 2011: 3 − 6. （in Chinese）
[2]	DUXSON P, PROVIS J L, LUKEY G C, et al. The role of inorganic polymer technology in the development of ‘green concrete’[J]. Cement and Concrete Research,2007,37(12):1590 − 1597. doi: 10.1016/j.cemconres.2007.08.018
[3]	刘之葵, 郭彤, 王剑. 粉煤灰和二灰对桂林红黏土力学性质的影响[J]. 水文地质工程地质,2017,44(3):86 − 92. [LIU Zhikui, GUO Tong, WANG Jian. Effect of the fly ash and lime fly ash on the mechanical properties of red clay in Guilin[J]. Hydrogeology & Engineering Geology,2017,44(3):86 − 92. (in Chinese with English abstract) LIU Zhikui, GUO Tong, WANG Jian. Effect of the fly ash and lime fly ash on the mechanical properties of red clay in Guilin[J]. Hydrogeology & Engineering Geology, 2017, 44(3): 86-92. (in Chinese with English abstract)
[4]	林彤. 粉煤灰加固软土地基的室内配方试验研究[J]. 水文地质工程地质, 2003, 30（增刊1）: 76 − 78 LIN Tong. Experimental study of formula indoor of fly ash improving soft foundation[J]. Hydrogeology & Engineering Geology, 2003, 30（Sup 1）: 76 − 78. （in Chinese with English abstract）
[5]	NWONU D C. Exploring soil geopolymer technology in soft ground improvement: A brief excursion[J]. Arabian Journal of Geosciences,2021,14(6):1 − 20.
[6]	CRISTELO N, GLENDINNING S, TEIXEIRA PINTO A. Deep soft soil improvement by alkaline activation[J]. Proceedings of the Institution of Civil Engineers-Ground Improvement,2011,164(2):73 − 82. doi: 10.1680/grim.900032
[7]	CRISTELO N, GLENDINNING S, FERNANDES L, et al. Effect of calcium content on soil stabilisation with alkaline activation[J]. Construction and Building Materials,2012,29:167 − 174. doi: 10.1016/j.conbuildmat.2011.10.049
[8]	SARGENT P, HUGHES P N, ROUAINIA M, et al. The use of alkali activated waste binders in enhancing the mechanical properties and durability of soft alluvial soils[J]. Engineering Geology,2013,152(1):96 − 108. doi: 10.1016/j.enggeo.2012.10.013
[9]	TEING T T. Effects of alkali-activated waste binder in soil stabilization[J]. International Journal of GEOMATE,2019,17(59):82 − 89.
[10]	AL-RKABY A H J. Evaluating shear strength of sand- ggbfs based geopolymer composite material[J]. Acta Polytechnica,2019,59(4):305 − 311. doi: 10.14311/AP.2019.59.0305
[11]	CORRÊA-SILVA M, ARAÚJO N, CRISTELO N, et al. Improvement of a clayey soil with alkali activated low-calcium fly ash for transport infrastructures applications[J]. Road Materials and Pavement Design,2019,20(8):1912 − 1926. doi: 10.1080/14680629.2018.1473286
[12]	CORRÊA-SILVA M, MIRANDA T, ROUAINIA M, et al. Geomechanical behaviour of a soft soil stabilised with alkali-activated blast-furnace slags[J]. Journal of Cleaner Production,2020,267:122017. doi: 10.1016/j.jclepro.2020.122017
[13]	孙秀丽, 童琦, 刘文化, 等. 碱激发粉煤灰和矿粉改性疏浚淤泥力学特性及显微结构研究[J]. 大连理工大学学报,2017,57(6):622 − 628. [SUN Xiuli, TONG Qi, LIU Wenhua, et al. Study of microstructure and mechanical properties of dredged silt solidified using fly ash and slag stimulated by alkali[J]. Journal of Dalian University of Technology,2017,57(6):622 − 628. (in Chinese with English abstract) doi: 10.7511/dllgxb201706011 SUN Xiuli, TONG Qi, LIU Wenhua, et al. Study of microstructure and mechanical properties of dredged silt solidified using fly ash and slag stimulated by alkali[J]. Journal of Dalian University of Technology, 2017, 57(6): 622-628. (in Chinese with English abstract) doi: 10.7511/dllgxb201706011
[14]	王东星, 王宏伟, 邹维列, 等. 活性MgO-粉煤灰固化淤泥耐久性研究[J]. 岩土力学,2019,40(12):4675 − 4684. [WANG Dongxing, WANG Hongwei, ZOU Weilie, et al. Study of durability of dredged sludge solidified with reactive MgO-fly ash[J]. Rock and Soil Mechanics,2019,40(12):4675 − 4684. (in Chinese with English abstract) WANG Dongxing, WANG Hongwei, ZOU Weilie, et al. Study of durability of dredged sludge solidified with reactive MgO-fly ash[J]. Rock and Soil Mechanics, 2019, 40(12): 4675-4684. (in Chinese with English abstract)
[15]	俞家人, 陈永辉, 陈庚, 等. 地聚物固化软黏土的力学特征及机理分析[J]. 建筑材料学报,2020,23(2):364 − 371. [YU Jiaren, CHEN Yonghui, CHEN Geng, et al. Mechanical behaviour of geopolymer stabilized clay and its mechanism[J]. Journal of Building Materials,2020,23(2):364 − 371. (in Chinese with English abstract) YU Jiaren, CHEN Yonghui, CHEN Geng, et al. Mechanical behaviour of geopolymer stabilized clay and its mechanism[J]. Journal of Building Materials, 2020, 23(2): 364-371. (in Chinese with English abstract)
[16]	吴俊, 征西遥, 杨爱武, 等. 矿渣-粉煤灰基地质聚合物固化淤泥质黏土的抗压强度试验研究[J]. 岩土力学,2021,42(3):647 − 655. [WU Jun, ZHENG Xiyao, YANG Aiwu, et al. Experimental study on the compressive strength of muddy clay solidified by the one-part slag-fly ash based geopolymer[J]. Rock and Soil Mechanics,2021,42(3):647 − 655. (in Chinese with English abstract) WU Jun, ZHENG Xiyao, YANG Aiwu, et al. Experimental study on the compressive strength of muddy clay solidified by the one-part slag-fly ash based geopolymer[J]. Rock and Soil Mechanics, 2021, 42(3): 647-655. (in Chinese with English abstract)
[17]	王伟齐, 孙红, 葛修润. 碱激发作用下海相软土固化研究[J]. 硅酸盐通报,2021,40(7):2248 − 2255. [WANG Weiqi, SUN Hong, GE Xiurun. Solidification of marine soft soil under alkali excitation[J]. Bulletin of the Chinese Ceramic Society,2021,40(7):2248 − 2255. (in Chinese with English abstract) WANG Weiqi, SUN Hong, GE Xiurun. Solidification of marine soft soil under alkali excitation[J]. Bulletin of the Chinese Ceramic Society, 2021, 40(7): 2248-2255. (in Chinese with English abstract)
[18]	FU Y W, CAI L C, WU Y G. Freeze-thaw cycle test and damage mechanics models of alkali-activated slag concrete[J]. Construction and Building Materials,2011,25(7):3144 − 3148. doi: 10.1016/j.conbuildmat.2010.12.006
[19]	ZHAO R D, YUAN Y, CHENG Z Q, et al. Freeze-thaw resistance of Class F fly ash-based geopolymer concrete[J]. Construction and Building Materials,2019,222:474 − 483. doi: 10.1016/j.conbuildmat.2019.06.166
[20]	谢凌君. Si/Al、Na/Al对偏高岭土基地聚物抗冻及抗渗性能的影响[D]. 杭州: 浙江大学, 2018 XIE Lingjun. The influence of Si/Al and Na/Al on freeze-thaw resistance and permeability of metakaolin based geopolymer[D]. Hangzhou: Zhejiang University, 2018. （in Chinese with English abstract）
[21]	TIAN L Y, HE D P, ZHAO J N, et al. Durability of geopolymers and geopolymer concretes: A review[J]. Reviews on Advanced Materials Science,2021,60(1):1 − 14. doi: 10.1515/rams-2021-0002
[22]	毛明杰, 李瑞文, 杨秋宁, 等. 冻融作用下粉煤灰地聚物混凝土性能劣化研究[J]. 非金属矿,2020,43(2):48 − 50. [MAO Mingjie, LI Ruiwen, YANG Qiuning, et al. Study on deterioration of fly ash geopolymer concrete under freeze-thaw[J]. Non-Metallic Mines,2020,43(2):48 − 50. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-8098.2020.02.013 MAO Mingjie, LI Ruiwen, YANG Qiuning, et al. Study on deterioration of fly ash geopolymer concrete under freeze-thaw[J]. Non-Metallic Mines, 2020, 43(2): 48-50. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-8098.2020.02.013
[23]	American Society for Testing and Materials. Standard specification for fly ash: ASTMC 618— 19[S]. West Conshohocken: ASTM International, 2019.
[24]	贾屹海. Na-粉煤灰地质聚合物制备与性能研究[D]. 北京: 中国矿业大学（北京）, 2009 JIA Yihai. Synthesis and characterization of fly-ash-based Na-geopolymer[D]. Beijing: China University of Mining & Technology, Beijing, 2009. （in Chinese with English abstract）
[25]	American Society for Testing and Materials. Standard test method for freezing and thawing of compacted cement soil mixtures: ASTMD 560—2003[S]. West Conshohocken: ASTM International, 2003.
[26]	王华, 张强, 宋存义. 莫来石在粉煤灰碱性溶液中的反应行为[J]. 粉煤灰综合利用,2001,14(5):24 − 27. [WANG Hua, ZHANG Qiang, SONG Cunyi. Reaction behavior of mullite in alkaline solution of fly ash[J]. Fly Ash Comprehensive Utilization,2001,14(5):24 − 27. (in Chinese) doi: 10.3969/j.issn.1005-8249.2001.05.011 WANG Hua, ZHANG Qiang, SONG Cunyi. Reaction behavior of mullite in alkaline solution of fly ash[J]. Fly Ash Comprehensive Utilization, 2001, 14(5): 24-27. (in Chinese) doi: 10.3969/j.issn.1005-8249.2001.05.011
[27]	REES C A, PROVIS J L, LUKEY G C, et al. In situ ATR-FTIR study of the early stages of fly ash geopolymer gel formation[J]. Langmuir:the ACS Journal of Surfaces and Colloids,2007,23(17):9076 − 9082. doi: 10.1021/la701185g
[28]	魏威, 高彦斌, 陈忠清, 等. 室温碱激发低钙粉煤灰地质聚合物配比试验研究[J]. 硅酸盐通报,2020,39(12):3889 − 3896. [WEI Wei, GAO Yanbin, CHEN Zhongqing, et al. Experimental study on proportion of room temperature alkali-activated low-calcium fly ash geopolymer[J]. Bulletin of the Chinese Ceramic Society,2020,39(12):3889 − 3896. (in Chinese with English abstract) WEI Wei, GAO Yanbin, CHEN Zhongqing, et al. Experimental study on proportion of room temperature alkali-activated low-calcium fly ash geopolymer[J]. Bulletin of the Chinese Ceramic Society, 2020, 39(12): 3889-3896. (in Chinese with English abstract)
[29]	侯云芬, 王栋民, 李俏, 等. 水玻璃性能对粉煤灰基矿物聚合物的影响[J]. 硅酸盐学报,2008,36(1):61 − 64. [HOU Yunfen, WANG Dongmin, LI Qiao, et al. Effect of water glass performance on fly ash-based geopolymers[J]. Journal of the Chinese Ceramic Society,2008,36(1):61 − 64. (in Chinese with English abstract) doi: 10.3321/j.issn:0454-5648.2008.01.013 HOU Yunfen, WANG Dongmin, LI Qiao, et al. Effect of water glass performance on fly ash-based geopolymers[J]. Journal of the Chinese Ceramic Society, 2008, 36(1): 61-64. (in Chinese with English abstract) doi: 10.3321/j.issn:0454-5648.2008.01.013
[30]	FERNÁNDEZ-JIMÉNEZ A, PALOMO A, SOBRADOS I, et al. The role played by the reactive alumina content in the alkaline activation of fly ashes[J]. Microporous and Mesoporous Materials,2006,91(1/2/3):111 − 119.
