Rainfall infiltration process of multi-layer slope based on improved Green-Ampt model stability analysis
-
摘要:
降雨作用下，边坡土体的饱和度及含水率升高，基质吸力减小。随着降雨历时的增长，雨水入渗深度对坡体的稳定性产生影响。然而传统多层结构边坡的入渗计算方法并未考虑随入渗深度不断变化的基质吸力与层间积水点的形成，且忽略饱和层内沿坡体层面流动的部分雨水对入渗过程的影响，亦未考虑潜在滑动面位置随降雨历时的变化。将入渗过程分解为若干个子过程，并基于Green-Ampt（G-A）入渗模型对传统多层结构边坡的入渗计算方法进行改进，以对每个子过程进行求解，最后将其合并为整体入渗过程的解。在此基础上对层间积水点的形成时刻进行计算，进而分析雨水入渗深度与时间的关系，并研究降雨强度与雨水入渗深度对边坡不同位置处（湿润锋、饱和层）稳定系数和滑动面位置的影响。研究表明：（1）基于G-A模型的改进计算方法所得结果比传统多层结构边坡入渗计算方法所得结果更接近于数值模拟结果。（2）对于多层结构土质边坡，其安全系数随着雨水入渗深度的增加不断降低，并且在层间积水点形成时产生突变现象。（3）随着降雨历时和降雨强度的增大，边坡中潜在滑动面位置会产生变化，前期潜在滑动面位置出现在湿润锋处，后期则出现在饱和层交界面处。该方法提高了多层结构边坡传统降雨入渗计算方法的精度，更加全面的对多层结构边坡的稳定性进行评价，其工程应用范围亦得到进一步扩大
Abstract:Under the effect of rainfall, the saturation and water content of slope soil increase, while the matric suction decreases. With the increasing rainfall duration, rainwater infiltration depth has an effect on slope stability. However, the traditional infiltration calculation method of slope with the multi-layer structure does not consider the matric suction and the formation of inter layer water points that change with the infiltration depth, and ignores the influence of part of rainwater flowing along the slope layer in saturated layer on the infiltration process. The variation of the location of potential sliding surface with the rainfall duration is also not considered. Therefore, in this paper, the infiltration process is decomposed into several sub-processes, and the infiltration calculation method of traditional multi-layer slope is improved based on the Green-Ampt (G-A) infiltration model to solve each sub-process. The solutions of sub-precesses are finally merged into the solution of the whole infiltration process. The formation time of interlayer water point is calculated, the relationship between rain water infiltration depth and time is analyzed, and the influence of rainfall intensity and rain water infiltration depth on stability coefficient and sliding surface position at different positions of slope (wet front, saturated layer) is also studied. The results show that (1) the results obtained by the improved calculation method based on the G-A model are closer to the numerical simulation results than those obtained by the traditional multi-layer structure slope infiltration calculation method. (2) For the soil slope with multi-layer structure, its safety factor decreases with the increasing rainwater infiltration depth, and the phenomenon of mutation occurs when the interlayer water point is formed. (3) With the increasing rainfall duration and rainfall intensity, the position of the potential sliding surface in the slope change. The potential sliding surface appears at the humid front in the early stage, and at the interface of the saturated layer in the later stage. This method improves the accuracy of the traditional rainfall infiltration calculation method of the multi-storey structure slope, makes a more comprehensive evaluation of the stability of the multi-storey structure slope, and further expands its engineering application scope.
-
-
表 1 土体力学参数
Table 1. Mechanical parameters of soil
土体力学参数 坡积土 风化土 基岩 饱和重度/（kN·m−3） 20.0 21.0 25.0 孔隙率/% 47.3 40.2 37.6 初始黏聚力/kPa 27.0 32.8 150.0 初始内摩擦角/（°） 20.0 21.0 25.0 饱和度/% 64.4 86.9 77.8 饱和度差/% 13.0 10.0 16.5 基质吸力/m 0.200 0.098 0.800 饱和黏聚力/kPa 17 26 8 拟合参数a −0.270 −0.095 −0.040 拟合参数b 0.75 0.40 0.20
下载: 导出CSV
-
[1] NG C W W,SHI Q. A numerical investigation of the stability of unsaturated soil slopes subjected to transient seepage[J]. Computers and Geotechnics,1998,22(1):1 − 28. doi: 10.1016/S0266-352X(97)00036-0
[2] 徐全, 谭晓慧, 沈梦芬. 降雨入渗条件下土质边坡的稳定性分析[J]. 岩土工程学报, 2012, 34（增刊1）: 254 − 259
XU Quan, TAN Xiaohui, SHEN Mengfen. Stability analysis of soil slopes under rainfall infiltration[J]. Chinese Journal of Geotechnical Engineering, 2012, 34（Sup 1）: 254 − 259. （in Chinese with English abstract）
[3] 王磊,李荣建,杨正午,等. 强降雨作用下黄土陡坡开裂特性测试[J]. 吉林大学学报(地球科学版),2021,51(5):1338 − 1346. [WANG Lei, LI Rongjian, YANG Zhengwu, et al. Experimental study on cracking characteristics of loess steep slope under intensive rainfall[J]. Journal of Jilin University (Earth Science Edition),2021,51(5):1338 − 1346. (in Chinese with English abstract)
[4] 李媛,孟晖,董颖,等. 中国地质灾害类型及其特征-基于全国县市地质灾害调查成果分析[J]. 中国地质灾害与防治学报,2004,15(2):29 − 34. [LI Yuan,MENG Hui,DONG Ying,et al. Types and characteristics of geological hazards in China:Based on the survey results of geological hazards in counties and cities[J]. Chinese Journal of Geological Hazards and Prevention,2004,15(2):29 − 34. (in Chinese with English abstract)
[5] GREEN H,AMPT G A. Studies on soil physics:part II—The permeability of an ideal soil to air and water[J]. The Journal of Agricultural Science,1912,5(1):1 − 26. doi: 10.1017/S0021859600001751
[6] 彭振阳,黄介生,伍靖伟,等. 基于分层假设的Green-Ampt模型改进[J]. 水科学进展,2012,23(1):59 − 66. [PENG Zhenyang,HUANG Jiesheng,WU Jingwei,et al. Modification of Green-Ampt model based on the stratification hypothesis[J]. Advances in Water Science,2012,23(1):59 − 66. (in Chinese with English abstract) doi: 10.14042/j.cnki.32.1309.2012.01.004
[7] 苏永华,李诚诚. 强降雨下基于Green-Ampt模型的边坡稳定性分析[J]. 岩土力学,2020,41(2):389 − 398. [SU Yonghua,LI Chengcheng. Stability analysis of slope based on Green-Ampt model under heavy rainfall[J]. Rock and Soil Mechanics,2020,41(2):389 − 398. (in Chinese with English abstract)
[8] 李诚诚. 强降雨作用下基于Green-Ampt入渗模型的边坡稳定性分析[D]. 长沙: 湖南大学, 2019
LI Chengcheng. Stability analysis of slope based on Green-Ampt infiltration model under heavy rainfall[D]. Changsha: Hunan University, 2019. （in Chinese with English abstract）
[9] 胡庆国,袁宁,等. 多层结构土质边坡降雨入渗过程及稳定性影响分析[J]. 中国公路学报,2018,31(2):67 − 74. [HU Qingguo,YUAN Ning,et al. Analysis of rainfall infiltration process and stability of soil slope with multilayer structure[J]. China Journal of Highway and Transport,2018,31(2):67 − 74. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-7372.2018.02.007
[10] 王继华. 降雨入渗条件下土坡水土作用机理及其稳定性分析与预测预报研究[D]. 长沙: 中南大学, 2006
WANG Jihua. Research the principle of water-soil interaction in soil-slope and analyze and predict its stability in condition of rain infiltration [D]. Changsha: Central South University, 2006. （in Chinese with English abstract）
[11] 孙子涵,王述红,杨天娇,等. 降雨条件下多层土坡入渗机理与稳定性分析[J]. 东北大学学报(自然科学版),2020,41(8):1201 − 1208. [SUN Zihan,WANG Shuhong,YANG Tianjiao,et al. Infiltration mechanism and stability analysis of multilayer soil slope under rainfall conditions[J]. Journal of Northeastern University (Natural Science),2020,41(8):1201 − 1208. (in Chinese with English abstract)
[12] 石振明,沈丹祎,彭铭,等. 考虑多层非饱和土降雨入渗的边坡稳定性分析[J]. 水利学报,2016,47(8):977 − 985. [SHI Zhenming,SHEN Danyi,PENG Ming,et al. Slope stability analysis by considering rainfall infiltration in multi-layered unsaturated soils[J]. Journal of Hydraulic Engineering,2016,47(8):977 − 985. (in Chinese with English abstract) doi: 10.13243/j.cnki.slxb.20151132
[13] FREDLUND D G,MORGENSTERN N R,WIDGER R A. The shear strength of unsaturated soils[J]. Canadian Geotechnical Journal,1978,15(3):313 − 321. doi: 10.1139/t78-029
[14] 方薇. 一种非饱和土的非线性抗剪强度包络壳模型[J]. 岩石力学与工程学报,2018,37(11):2601 − 2609. [FANG Wei. An envelope shell model of nonlinear shearing strength for unsaturated soils[J]. Chinese Journal of Rock Mechanics and Engineering,2018,37(11):2601 − 2609. (in Chinese with English abstract) doi: 10.13722/j.cnki.jrme.2018.0608
[15] 黄梦宏,丁桦. 边坡稳定性分析极限平衡法的简化条件[J]. 岩石力学与工程学报,2006,25(12):2529 − 2536. [HUANG Menghong DING Hua. Some assumption conditions of limit equilibrium method for slope stability analysis[J]. Chinese Journal of Rock Mechanics and Engineering,2006,25(12):2529 − 2536. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2006.12.020
[16] MEIN R G,LARSON C L. Modeling infiltration during a steady rain[J]. Water Resources Research,1973,9(2):384 − 394. doi: 10.1029/WR009i002p00384
[17] 邢小弟,张磊,谈叶飞,等. 降雨入渗过程中土质边坡稳定性计算[J]. 水利水运工程学报,2014(3):98 − 103. [XING Xiaodi,ZHANG Lei,TAN Yefei,et al. Calculation method for soil slope stability under the action of precipitation infiltration[J]. Hydro-Science and Engineering,2014(3):98 − 103. (in Chinese with English abstract) doi: 10.3969/j.issn.1009-640X.2014.03.015
[18] 矫滨田, 鲁晓兵, 王淑云, 等. 土体降雨滑坡中细颗粒运移及效应[J]. 地下空间与工程学报, 2005（增刊1）: 36 − 38
JIAO Bintian, LU Xiaobing, WANG Shuyun, et al. The movement of fine grains and its effects on the landslide and debris flow caused by raining[J] Journal of Underground Space and Engineering, 2005 （Sup1）: 36 − 38. （in Chinese with English abstract）
[19] 常金源,包含,伍法权,等. 降雨条件下浅层滑坡稳定性探讨[J]. 岩土力学,2015,36(4):995 − 1001. [CHANG Jinyuan,BAO Han,WU Faquan,et al. Discussion on stability of shallow landslide under rainfall[J]. Rock and Soil Mechanics,2015,36(4):995 − 1001. (in Chinese with English abstract) doi: 10.16285/j.rsm.2015.04.012
[20] CUI Y,ZHOU X J,GUO C. Experimental study on the moving characteristics of fine grains in wide grading unconsolidated soil under heavy rainfall[J]. Journal of Mountain Science,2017,14(3):417 − 431. doi: 10.1007/s11629-016-4303-x
[21] 饶鸿,王金淑,赵志明,等. 基于有限元软件自定义本构模型的膨胀土边坡降雨入渗分析[J]. 水文地质工程地质,2021,48(1):154 − 162. [RAO Hong,WANG Jinshu,ZHAO Zhiming,et al. An analysis of rainfall infiltration of expansive soil slope based on finite element software custom constitutive model[J]. Hydrogeology & Engineering Geology,2021,48(1):154 − 162. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.202002020
[22] CUI Y,NOURI A,CHAN D. A new approach to DEM simulation of sand production[J]. Journal of Petroleum Science and Engineering,2016,147:56 − 67. doi: 10.1016/j.petrol.2016.05.007
[23] 陈林万,裴向军,张晓超,等. 不同压实度下黄土填方边坡失稳的模型试验研究[J]. 水文地质工程地质,2022,49(2):137 − 147. [CHEN Linwan,PEI Xiangjun,ZHANG Xiaochao,et al. A model test study of the instability of loess fill slope under different compactness[J]. Hydrogeology & Engineering Geology,2022,49(2):137 − 147. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.202104068
[24] 罗浩,霍宇翔,巨能攀,等. 弃渣场边坡的粒径分布特征及其失稳机制研究[J]. 水文地质工程地质,2020,47(1):69 − 79. [LUO Hao,HUO Yuxiang,JU Nengpan,et al. A study of the particle size distribution characteristics and instability mechanism of the slope of an abandoned slag yard[J]. Hydrogeology & Engineering Geology,2020,47(1):69 − 79. (in Chinese with English abstract)
-
