Groundwater pollution risk evaluation of pharmaceuticals and personal care products in land application of sludge
-
摘要:
为进一步明确污泥土地利用过程中新型有机污染物——药物和个人护理用品（PPCPs）对地下水污染的风险，采用数学模型初步预测和评价了29种PPCPs在砂土和壤土2种介质条件下对地下水污染的风险。结果表明：砂土条件下，环丙沙星、氧氟沙星、土霉素、诺氟沙星和咖啡因等5种PPCPs的风险指数大于1，具有高地下水污染风险，其中，除咖啡因外，其余4种PPCPs均为抗生素类药物，应加强其在地下水中的监测和防控。壤土条件下，29种PPCPs对地下水均表现为低污染风险。吸附强度是影响PPCPs对地下水污染风险的最主要因素。PPCPs在包气带中的半衰期、有机碳-水分配系数、土壤密度、有机碳含量、含有机质的上层土壤层厚度是模型主要的敏感参数。不确定性分析显示，PPCPs的有机碳-水分配系数和其在包气带中的半衰期的改变对地下水污染风险评价结果影响较大。验证表明，地下水污染风险指数越大的PPCPs在地下水中的检出率也越高，说明评价结果具有一定的合理性。今后应加强对PPCPs降解产物、地下水中安全浓度值、共存PPCPs相互作用及介质非均质性影响等方面的研究，以便更加精确地评价PPCPs对地下水污染的风险。
Abstract:In order to further clarify the groundwater pollution risk of the pharmaceutical and personal care products (PPCPs), also known as emerging organic contaminants, in land application of sludge, groundwater pollution risks of 29 PPCPs under sand and loam soil conditions are primarily evaluated using a mathematical model. The results show that ciprofloxacin, ofloxacin, oxytetracycline, norfloxacin and caffeine have risk index values higher than 1 under sand soil conditions, indicating high groundwater pollution risks. Except caffeine, all the other 4 PPCPs with high groundwater pollution risks are antibiotics, which need to be further monitored and controlled in groundwater. Under loam soil conditions, all the 29 PPCPs show low groundwater pollution risks. Sorption is the main factor affecting the groundwater pollution risk of PPCPs. Sensitivity analyses indicate that the half-life of PPCPs in soil, organic carbon partition coefficient, soil density, organic carbon content and depth of the zone with organic matter are the key parameters affecting the model output. Uncertainty analyses show that changes in the organic carbon partition coefficient and half-life of PPCPs in soil have great impact on groundwater pollution risks. Test and verification show that PPCPs with higher groundwater pollution risk index values had higher detection rates in groundwater, indicating that the evaluation results are reliable. Further researches on degradation products of PPCPs, their safe levels in groundwater, interactions between coexisting PPCPs and medium heterogeneity effects should be strengthened in order to evaluate the groundwater pollution risk of PPCPs with reasonable accuracy.
-
-
表 1 污泥中代表性PPCPs及其理化性质等参数
Table 1. Common PPCPs in sludge and their physicochemical properties
名称 CAS号 半衰期
/d有机碳-
水分配系数
/（cm3·g−1）土地利用量
/（g·a−1·m−2）最大安全
浓度
/（mg·L−1）名称 CAS号 半衰期
/d有机碳-
水分配系数
/（cm3·g−1）土地利用量
/（g·a−1·m−2）最大安全
浓度
/（mg·L−1）金霉素 57-62-5 360 1520.0 0.010 5.00×10−3 咪康唑 22916-47-8 360 61370.0 0.320 1.00×10−3 红霉素 114-07-8 360 44300.0 0.034 2.00×10−4 噻苯咪唑 148-79-8 30 2212.0 0.046 8.44×10−4 土霉素 79-57-2 120 270.0 0.036 1.70×10−3 三氯生 3380-34-5 120 18420.0 5.200 1.55×10−3 四环素 60-54-8 120 558.0 0.158 8.16×10−2 三氯卡班 101-20-2 120 5394.0 15.000 2.50×10−5 米诺环素 10118-90-8 360 437.0 0.052 2.19×10−1 甲氧苄氨嘧啶 738-70-5 120 905.0 0.011 1.78×10−2 差向四环素 23313-80-6 120 558.0 0.010 8.42×10−3 西咪替丁 51481-61-9 75 918.7 0.210 7.40×10−1 阿奇霉素 83905-01-5 360 43400.0 0.350 2.50×10−4 雷尼替丁 66357-35-5 75 27760.0 0.009 3.10×10−3 克拉霉素 81103-11-9 360 45300.0 0.027 2.50×10−3 吉非罗齐 25812-30-0 75 453.3 0.063 1.76×10−3 强力霉素 564-25-0 120 566.0 0.400 9.06×10−1 二甲双胍 657-24-9 30 140.9 0.130 1.30×10−1 环丙沙星 85721-33-1 120 305.0 2.800 2.97×10−3 氟西汀 54910-89-3 120 207400.0 0.071 8.20×10−4 诺氟沙星 70458-96-7 120 305.0 0.120 5.00×10−3 苯海拉明 58-73-1 75 8242.0 0.480 3.74×10−4 氧氟沙星 82419-36-1 120 482.0 2.300 4.74×10−3 地尔硫卓 42399-41-7 120 9502.0 0.019 8.20×10−3 布洛芬 15687-27-1 30 394.3 0.100 1.91×10−5 咖啡因 58-08-2 30 62.3 0.100 2.20×10−3 萘普生 22204-53-1 30 555.0 0.050 3.56×10−5 可替宁 486-56-6 75 807.5 0.012 2.40×10−4 卡马西平 298-46-4 75 3871.0 0.068 6.36×10−3 注：PPCPs的半衰期（T1/2）、有机碳-水分配系数（Koc）采用EPI Suite（4.11）软件和US EPA Comptox Chemistry Dashboard （https://comptox.epa.gov/dashboard/）查询得到。PPCPs的土地利用量（M）根据每年产生约5.6×106～6.9×106 t（干重）的污泥量，且60%利用于土地[17]，参照典型PPCPs的利用水平确定。PPCPs的最大安全浓度（Cs）通过ECOTOX Knowledgebase （https://cfpub.epa.gov/ecotox/search.cfm）查询得到。
下载: 导出CSV
表 2 代表性砂土和壤土介质条件参数[12, 14, 19-20]
Table 2. Selected parameters for sand and loam soils[12, 14, 19-20]
参数 砂土 壤土 G/m 2 3 Z/m 0.3 0.6 ρ/（g·cm−3） 1.25 1.49 w/（cm3·cm−3） 0.07 0.15 R/（m·a−1） 0.6 0.2 foc/（g·g−1） 0.005 0.050
下载: 导出CSV
表 3 PPCPs对地下水污染的风险指数
Table 3. Risk index of groundwater pollution by PPCPs
名称 RI砂 RI壤 等级砂 等级壤 环丙沙星 130 <0.001 高 低 氧氟沙星 21.0 <0.001 高 低 土霉素 3.68 <0.001 高 低 诺氟沙星 3.32 <0.001 高 低 咖啡因 2.08 <0.001 高 低 吉非罗齐 0.234 <0.001 中 低 米诺环素 0.129 <0.001 中 低 金霉素 0.102 <0.001 中 低 四环素 0.051 <0.001 低 低 布洛芬 0.040 <0.001 低 低 差向四环素 0.031 <0.001 低 低 强力霉素 0.011 <0.001 低 低 可替宁 0.008 <0.001 低 低 二甲双胍 0.006 <0.001 低 低 甲氧苄氨嘧啶 0.002 <0.001 低 低 萘普生 <0.001 <0.001 低 低 西咪替丁 <0.001 <0.001 低 低 三氯卡班 <0.001 <0.001 低 低 卡马西平 <0.001 <0.001 低 低 噻苯咪唑 <0.001 <0.001 低 低 地尔硫卓 <0.001 <0.001 低 低 苯海拉明 <0.001 <0.001 低 低 阿奇霉素 <0.001 <0.001 低 低 红霉素 <0.001 <0.001 低 低 克拉霉素 <0.001 <0.001 低 低 三氯生 <0.001 <0.001 低 低 咪康唑 <0.001 <0.001 低 低 雷尼替丁 <0.001 <0.001 低 低 氟西汀 <0.001 <0.001 低 低
下载: 导出CSV
-
[1] LAPWORTH D,BARAN N,STUART M,et al. Emerging organic contaminants in groundwater:A review of sources,fate and occurrence[J]. Environmental Pollution,2012,163(4):287 − 303.
[2] LI Zhen,XIANG Xi,LI Miao,et al. Occurrence and risk assessment of pharmaceuticals and personal care products and endocrine disrupting chemicals in reclaimed water and receiving groundwater in China[J]. Ecotoxicology and Environmental Safety,2015,119:74 − 80. doi: 10.1016/j.ecoenv.2015.04.031
[3] 秦晓鹏,刘菲,王广才,等. 抗生素在土壤/沉积物中吸附行为的研究进展[J]. 水文地质工程地质,2015,42(3):142 − 148. [QIN Xiaopeng,LIU Fei,WANG Guangcai,et al. Adsorption of antibiotics in soils/sediments:A review[J]. Hydrogeology & Engineering Geology,2015,42(3):142 − 148. (in Chinese with English abstract)
[4] 靳孟贵,罗泽娇,梁杏,等. 再生水地表回灌补给地下水的水质安全保障体系[J]. 地球科学,2012,37(2):238 − 246. [JIN Menggui,LUO Zejiao,LIANG Xing,et al. Security system of water quality for groundwater recharge with infiltration basin and reclaimed water[J]. Earth Science,2012,37(2):238 − 246. (in Chinese with English abstract)
[5] WU Chenxi,SPONGBERG A,WITTER J,et al. Detection of pharmaceuticals and personal care products in agricultural soils receiving biosolids application[J]. CLEAN – Soil,Air,Water,2010,38(3):230 − 237.
[6] 黄德亮,何江涛,杨蕾,等. 某市再生水灌区水土环境中PPCPs污染特征分析[J]. 中国环境科学,2016,36(9):2614 − 2623. [HUANG Deliang,HE Jiangtao,YANG Lei,et al. Distribution characteristics of pharmaceuticals and personal care products in water and soil environment in reclaimed water irrigation area of a city[J]. China Environmental Science,2016,36(9):2614 − 2623. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-6923.2016.09.010
[7] 王博欣,李炳华,张大胜,等. 北运河河水和地下水PPCPs污染特征及风险评价[J]. 南水北调与水利科技(中英文),2020,18(6):138 − 147. [WANG Boxin,LI Binghua,ZHANG Dasheng,et al. Pollution characteristics and ecological risk assessment of pharmaceuticals and personal care products (PPCPs) in Beiyun river and groundwater of North Canal[J]. South-to-North Water Transfers and Water Science & Technology,2020,18(6):138 − 147. (in Chinese with English abstract)
[8] EKPEGHERE K,LEE J,KIM H,et al. Determination and characterization of pharmaceuticals in sludge from municipal and livestock wastewater treatment plants[J]. Chemosphere,2017,168:1211 − 1221. doi: 10.1016/j.chemosphere.2016.10.077
[9] GOTTSCHALL N,TOPP E,METCALFE C,et al. Pharmaceutical and personal care products in groundwater,subsurface drainage,soil,and wheat grain,following a high single application of municipal biosolids to a field[J]. Chemosphere,2012,87(2):194 − 203. doi: 10.1016/j.chemosphere.2011.12.018
[10] GARCÍA-SANTIAGO X,GARRIDO J,LEMA J,et al. Fate of pharmaceuticals in soil after application of STPs products:Influence of physicochemical properties and modelling approach[J]. Chemosphere,2017,182:406 − 415. doi: 10.1016/j.chemosphere.2017.05.049
[11] 殷哲云,闵露娟,金立涛,等. HPLC-MS/MS测定3类污水处理厂污泥及污水中的8种药物[J]. 环境化学,2018,37(8):1720 − 1727. [YIN Zheyun,MIN Lujuan,JIN Litao,et al. HPLC-MS/MS determination of eight PPCPs in sewage and sludge from three types of sewage treatment plants[J]. Environmental Chemistry,2018,37(8):1720 − 1727. (in Chinese with English abstract) doi: 10.7524/j.issn.0254-6108.2017110803
[12] 朱辉,叶淑君,吴吉春,等. 中国典型有机污染场地土层岩性和污染物特征分析[J]. 地学前缘,2021,28(5):26 − 34. [ZHU Hui,YE Shujun,WU Jichun,et al. Characteristics of soil lithology and pollutants in typical contamination sites in China[J]. Earth Science Frontiers,2021,28(5):26 − 34. (in Chinese with English abstract) doi: 10.13745/j.esf.sf.2021.2.15
[13] MCCLELLAN K,HALDEN R. Pharmaceuticals and personal care products in archived US biosolids from the 2001 EPA national sewage sludge survey[J]. Water Research,2010,44(2):658 − 668. doi: 10.1016/j.watres.2009.12.032
[14] HASSANPOUR B,RICHARDS B,GOEHRING L,et al. Predicting the fate of preferentially moving herbicides[J]. Vadose Zone Journal,2019,18(1):180193.
[15] 童蕾,姚林林,刘慧,等. 抗生素在地下水系统中的环境行为及生态效应研究进展[J]. 生态毒理学报,2016,11(2):27 − 36. [TONG Lei,YAO Linlin,LIU Hui,et al. Review on the environmental behavior and ecological effect of antibiotics in groundwater system[J]. Asian Journal of Ecotoxicology,2016,11(2):27 − 36. (in Chinese with English abstract)
[16] WU Lin,BI E. Sorption of ionic and neutral species of pharmaceuticals to loessial soil amended with biochars[J]. Environmental Science and Pollution Research,2019,26(35):35871 − 35881. doi: 10.1007/s11356-019-06721-7
[17] JONES-LEPP T,STEVENS R. Pharmaceuticals and personal care products in biosolids/sewage sludge:The interface between analytical chemistry and regulation[J]. Analytical and Bioanalytical Chemistry,2007,387(4):1173 − 1183. doi: 10.1007/s00216-006-0942-z
[18] 钟秀,马腾,刘林,等. 地下水饮用水源地污染源风险等级评价方法研究[J]. 安全与环境工程,2014,21(2):104 − 108. [ZHONG Xiu,MA Teng,LIU Lin,et al. Method research on the risk level evaluation of contamination sources for drinking groundwater wellhead[J]. Safety and Environmental Engineering,2014,21(2):104 − 108. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1556.2014.02.022
[19] STEENHUIS T,JACKSON C,KUNG S,et al. Measurement of groundwater recharge on eastern Long Island,New York,USA[J]. Journal of Hydrology,1985,79(1):145 − 169.
[20] ABU-HAMDEH N. SW—soil and water:Measurement of the thermal conductivity of sandy loam and clay loam soils using single and dual probes[J]. Journal of Agricultural Engineering Research,2001,80(2):209 − 216. doi: 10.1006/jaer.2001.0730
[21] 张毅,马艳飞,宋帅,等. 环渤海地区2,4,4’-三氯联苯的多介质归趋模拟[J]. 环境科学,2020,41(6):2625 − 2634. [ZHANG Yi,MA Yanfei,SONG Shuai,et al. Fate simulation of 2,4,4’-trichlorobiphenyl in the Bohai rim using the multimedia model[J]. Environmental Science,2020,41(6):2625 − 2634. (in Chinese with English abstract)
[22] 吴戈男,胡中民,李胜功,等. SWH双源蒸散模型模拟效果验证及不确定性分析[J]. 地理学报,2016,71(11):1886 − 1897. [WU Genan,HU Zhongmin,LI Shenggong,et al. Evaluation and uncertainty analysis of a two-source evapotranspiration model[J]. Acta Geographica Sinica,2016,71(11):1886 − 1897. (in Chinese with English abstract) doi: 10.11821/dlxb201611002
[23] 吴林,李峰,杜蓓蓓. 药物及个人护理品在土壤中的淋溶迁移性评价[J]. 环境科学与技术,2015,38(5):163 − 167. [WU Lin,LI Feng,DU Beibei. Evaluation of leachability of pharmaceuticals and personal care products in soils[J]. Environmental Science & Technology,2015,38(5):163 − 167. (in Chinese with English abstract)
[24] MA Meng,DILLON P,ZHENG Yan. Determination of sulfamethoxazole degradation rate by an in situ experiment in a reducing alluvial aquifer of the North China Plain[J]. Environmental Science & Technology,2019,53(18):10620 − 10628.
[25] 赵勇胜,王卓然. 污染场地地下水中污染物迁移及风险管控[J]. 环境保护,2021,49(20):21 − 26. [ZHAO Yongsheng,WANG Zhuoran. Groundwater pollutants transport and risk control for contaminated site[J]. Environmental Protection,2021,49(20):21 − 26. (in Chinese with English abstract)
[26] 金爱芳,李广贺,张旭. 地下水污染风险源识别与分级方法[J]. 地球科学,2012,37(2):247 − 252. [JIN Aifang,LI Guanghe,ZHANG Xu. The risk source identification and classification methodology of groundwater pollution[J]. Earth Science,2012,37(2):247 − 252. (in Chinese with English abstract)
[27] LOOS R,LOCORO G,COMERO S,et al. Pan-European survey on the occurrence of selected polar organic persistent pollutants in ground water[J]. Water Research,2010,44(14):4115 − 4126. doi: 10.1016/j.watres.2010.05.032
[28] BARNES K,KOLPIN D,FURLONG E,et al. A national reconnaissance of pharmaceuticals and other organic wastewater contaminants in the United States—I) Groundwater[J]. Science of the Total Environment,2008,402(2/3):192 − 200.
[29] 陈卫平,彭程伟,杨阳,等. 北京市地下水中典型抗生素分布特征与潜在风险[J]. 环境科学,2017,38(12):5074 − 5080. [CHEN Weiping,PENG Chengwei,YANG Yang,et al. Distribution characteristics and risk analysis of antibiotic in the groundwater in Beijing[J]. Environmental Science,2017,38(12):5074 − 5080. (in Chinese with English abstract)
[30] TONG Lei,LI Ping,WANG Yanxin,et al. Analysis of veterinary antibiotic residues in swine wastewater and environmental water samples using optimized SPE-LC/MS/MS[J]. Chemosphere,2009,74(8):1090 − 1097. doi: 10.1016/j.chemosphere.2008.10.051
[31] MA Yeping,LI Miao,WU Miaomiao,et al. Occurrences and regional distributions of 20 antibiotics in water bodies during groundwater recharge[J]. Science of The Total Environment,2015,518-519:498 − 506. doi: 10.1016/j.scitotenv.2015.02.100
[32] YAO Linlin,WANG Yanxin,TONG Lei,et al. Occurrence and risk assessment of antibiotics in surface water and groundwater from different depths of aquifers:A case study at Jianghan Plain,central China[J]. Ecotoxicology and Environmental Safety,2017,135:236 − 242. doi: 10.1016/j.ecoenv.2016.10.006
[33] CHEN Liang,LANG Hang,LIU Fei,et al. Presence of antibiotics in shallow groundwater in the northern and southwestern regions of China[J]. Groundwater,2018,56(3):451 − 457. doi: 10.1111/gwat.12596
[34] LIN Yenching,LAI Weipo,TUNG Hsinhsin,et al. Occurrence of pharmaceuticals,hormones,and perfluorinated compounds in groundwater in Taiwan[J]. Environmental Monitoring and Assessment,2015,187(5):256. doi: 10.1007/s10661-015-4497-3
[35] LI Zhiping,YU Xiaopeng,YU Furong,et al. Occurrence,sources and fate of pharmaceuticals and personal care products and artificial sweeteners in groundwater[J]. Environmental Science and Pollution Research,2021,28(17):20903 − 20920. doi: 10.1007/s11356-021-12721-3
[36] SZYMCZYCHA B,BORECKA M,BIAŁK-BIELIŃSKA A,et al. Submarine groundwater discharge as a source of pharmaceutical and caffeine residues in coastal ecosystem:Bay of Puck,southern Baltic Sea case study[J]. Science of the Total Environment,2020,713:136522. doi: 10.1016/j.scitotenv.2020.136522
[37] LESSER L,MORA A,MOREAU C,et al. Survey of 218 organic contaminants in groundwater derived from the world’s largest untreated wastewater irrigation system:Mezquital Valley,Mexico[J]. Chemosphere,2018,198:510 − 521. doi: 10.1016/j.chemosphere.2018.01.154
[38] YUAN Qiaoling,LI Zhiping,LI Leicheng,et al. Pharmaceuticals and personal care products transference-transformation in aquifer system[J]. Journal of Groundwater Science and Engineering,2020,8(4):358 − 365.
[39] 张涛,郭晓,刘俊杰,等. 江西梅江流域土壤中四环素类抗生素的含量及空间分布特征[J]. 环境科学学报,2017,37(4):1493 − 1501. [ZHANG Tao,GUO Xiao,LIU Junjie,et al. Concentration and spatial distribution of tetracycline antibiotics in soil of Meijiang river catchment,Jiangxi Province[J]. Acta Scientiae Circumstantiae,2017,37(4):1493 − 1501. (in Chinese with English abstract)
-
