Research on the characteristics of water transport in the aeration zone of loess tableland
-
摘要:
在我国西北黄土高原的黄土塬、黄土台塬区赋存有较丰富的黄土潜水，大气降水垂直入渗是其主要补给来源，但对水分赋存和运移的空间通道认识尚有不足。文章基于董志塬、渭北黄土台塬的地貌、地层结构等水文地质条件、地下水利用动态和相关试验资料，结合黄土扫描电镜图像处理与统计分析，对黄土塬区黄土潜水和包气带水分运移的孔隙特征、过程进行了探讨并分带。研究认为孔隙是黄土地下水的主要赋存、运移的空间通道，其最小渗透等效孔径约为12 μm。由孔隙发育的马兰黄土构成的黄土包气带垂向结构组合有利于大气降水的入渗，包气带孔隙中的水分运移非常微弱缓慢，但较为连续均匀。黄土包气带可划分为气候影响带、储存调节带、缓慢运移带和毛细接收带4个带，除上部气候影响带外，其余三带处于基本稳定的水分运移动平衡状态。研究成果可为全面系统地认识黄土塬区包气带水分运移特征提供参考和借鉴。
Abstract:There are abundant phreatic water in loess tablelands in the Loess Plateau of northwest China. The vertical infiltration of atmospheric precipitation is the main source of the recharge, but the spatial channels of water occurrence and migration in loess are still ambiguous. Based on the geomorphology, strata structure and other hydrogeological conditions, groundwater utilization condition and related experimental data of the Dongzhiyuan and Weibei loess tablelands, combined with scanning electron microscope image processing and statistical analysis, the pore characteristics and the migration processes of water in the loess phreatic and aeration zones are discussed and zoned. Pores are considered to be the main space channel for the occurrence and migration of loess groundwater, and the minimum equivalent pore size of seepage is about 12 μm. The vertical structural combination of the loess aeration zone composed of the Malan loess with developed pores in the upper part is conducive to the infiltration of atmospheric precipitation, and the water migration in the pores of the aeration zone is very weak and slow, but is relatively continuous and uniform. The aeration zone can be divided into four zones for loess: the climate impact zone, storage regulation zone, slow runoff zone and capillary receiving zone. Except for the upper climate impact zone, the other three zones are in a basically dynamic equilibrium state of water transport. The research results can provide important references for comprehensively and systematically understanding the characteristics of water transport in the aeration zone of loess tablelands.
-
Key words:
- loess /
- pore /
- aeration zone /
- water transport /
- groundwater
-
-
表 1 董志塬黄土孔隙特性测试结果
Table 1. Results of porosity properties of the Dongzhiyuan loess
地层 平面总孔隙率/% 可渗透等效孔隙直径/μm 1#西峰马兰黄土 8.9 14.2 2#西峰马兰黄土 13.0 12.5 5#西峰离石黄土 6.1 12.8 7#驿马马兰黄土 7.3 12.3 8#驿马马兰黄土 6.0 12.2 9#驿马离石黄土 5.2 12.8
下载: 导出CSV
-
[1] 张宗祜,姚足金,王开申. 中国黄土的主要工程地质问题[J]. 地质学报,1973,47(2):255 − 269. [ZHANG Zonghu,YAO Zujin,WANG Kaishen. Main engineering geological problems of loess in China[J]. Acta Geological Sinica,1973,47(2):255 − 269. (in Chinese) doi: 10.19762/j.cnki.dizhixuebao.1973.02.006
[2] 黄河中游地区黄土水文地质研究小组. 黄河中游地区黄土水文地质问题[J]. 地质学报,1978,52(2):106 − 114. [Research Group of the Hydrogeology of Loess in the Middle Reaches of the Yellow River. On the hydrogeology of loess in the middle reaches of the Yellow River[J]. Acta Geologica Sinica,1978,52(2):106 − 114. (in Chinese with English abstract)
[3] 张治平. 黄土区几个水文地质问题[J]. 陕西地质,1985,3(1):1 − 10. [ZHANG Zhiping. Some hydrogeologic problems in loess land[J]. Geology of Shaanxi,1985,3(1):1 − 10. (in Chinese with English abstract)
[4] 王德潜. 黄土含水介质特征与地下水类型[J]. 陕西地质,1985,3(1):11 − 20. [WANG Deqian. The characteristics of loessial aqueous medium and the types of groundwater[J]. Geology of Shaanxi,1985,3(1):11 − 20. (in Chinese with English abstract)
[5] 王德潜. 洛川黄土潜水补给特征[J]. 水文地质工程地质,1982,9(5):1 − 8. [WANG Deqian. Characteristics of phreatic recharge of Luochuan loess[J]. Hydrogeology & Engineering Geology,1982,9(5):1 − 8. (in Chinese) doi: 10.16030/j.cnki.issn.1000-3665.1982.05.001
[6] 阎太白,王德潜. 洛川塬黄土潜水的补给机制及黄土含水特征[J]. 地质论评,1983,29(5):418 − 427. [YAN Taibai,WANG Deqian. The recharge mechanism of unconfined groundwater in the loess of the Luochuan Yuan and its water-bearing characteristics[J]. Geological Review,1983,29(5):418 − 427. (in Chinese with English abstract) doi: 10.3321/j.issn:0371-5736.1983.05.003
[7] 王景明,倪玉兰,孙建中. 黄土构造节理研究及其应用[J]. 工程地质学报,1994,2(4):31 − 42. [WANG Jingming,NI Yulan,SUN Jianzhong. A study on structural joints in loess and its practical applications[J]. Journal of Engineering Geology,1994,2(4):31 − 42. (in Chinese with English abstract)
[8] 李春明,田润水. 渭北黄土含水介质的结构及黄土潜水赋存特征的初步研究[J]. 第四纪研究,1986,6(1):68 − 71. [LI Chunming,TIAN Runshui. Preliminary study on the structure of water-bearing medium in Weibei loess and the characteristics of groundwater occurrence in loess[J]. Quaternary Sciences,1986,6(1):68 − 71. (in Chinese)
[9] 施德鸿,贾永瑞,左秀法. 试论洛川黄土塬区包气带水分的赋存与运移[J]. 水文地质工程地质,1983,10(3):6 − 13. [SHI Dehong,JIA Yongrui,ZUO Xiufa. Occurrence and migration of water in vascular zone in Luochuan loess tableland[J]. Hydrogeology & Engineering Geology,1983,10(3):6 − 13. (in Chinese) doi: 10.16030/j.cnki.issn.1000-3665.1983.03.002
[10] 蔺如生. 渭北黄土微结构、孔隙及导水性的分析[J]. 陕西水利,1990(2):43 − 47. [LIN Rusheng. Analysis of microstructure,porosity and water conductivity of Weibei loess[J]. Shaanxi Water Resources,1990(2):43 − 47. (in Chinese)
[11] 李云峰. 黄土渗透性与空隙性关系的研究[M]. 北京: 地质出版社, 1994
LI Yunfeng. Study on the relationship between permeability and porosity of loess[M]. Beijing: Geological Publishing House, 1994. （in Chinese）
[12] 张建丰,林性粹,王文焰. 黄土的大孔隙特征和大孔隙流研究[J]. 水土保持学报,2003,17(4):168 − 171. [ZHANG Jianfeng,LIN Xingcui,WANG Wenyan. Characteristics of macro-pore and macro-pore flow in loess soil[J]. Journal of Soil and Water Conservation,2003,17(4):168 − 171. (in Chinese with English abstract) doi: 10.3321/j.issn:1009-2242.2003.04.046
[13] 赵宽耀,许强,刘方洲,等. 黄土中优势通道渗流特征研究[J]. 岩土工程学报,2020,42(5):941 − 950. [ZHAO Kuanyao,XU Qiang,LIU Fangzhou,et al. Seepage characteristics of preferential flow in loess[J]. Chinese Journal of Geotechnical Engineering,2020,42(5):941 − 950. (in Chinese with English abstract)
[14] 李鑫. 基于CT的黄土微细观空隙结构及优先流特性研究[D]. 西安: 长安大学, 2020
LI Xin. Research on micro and meso void structure and preferential flow characteristics of loess based on CT[D]. Xi’an: Chang’an University, 2020. （in Chinese with English abstract）
[15] 王雨山,潘建永. 基于包气带剖面研究黄土地下水补给[J]. 地质论评,2019,65(增刊 1):15 − 16. [WANG Yushan,PAN Jianyong. The study on groundwater recharge using soil profile in the Loess Plateau[J]. Geological Review,2019,65(Sup 1):15 − 16. (in Chinese with English abstract) doi: 10.16509/j.georeview.2019.s1.008
[16] 李喜安,彭建兵,陈志新,等. 黄土地层地表径流下潜模式与地质灾害[J]. 工程地质学报,2007,15(4):495 − 499. [LI Xi’an,PENG Jianbing,CHEN Zhixin,et al. On the infiltration modes of surface runoff in the loess layer and geological hazards[J]. Journal of Engineering Geology,2007,15(4):495 − 499. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2007.04.011
[17] 吴玮江, 王念秦. 甘肃滑坡灾害[M]. 兰州: 兰州大学出版社, 2006
WU Weijiang, WANG Nianqin. Landslide hazards in Gansu[M]. Lanzhou: Lanzhou University Press, 2006. （in Chinese）
[18] 王岩,刘若琼. 论董志塬地下水资源及其可持续利用[J]. 水资源保护,2005,21(1):64 − 66. [WANG Yan,LIU Ruoqiong. Groundwater resources in Dongzhiyuan and its sustainable utilization[J]. Water Resources Protection,2005,21(1):64 − 66. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-6933.2005.01.019
[19] 魏玉涛,侯燕军,李彬. 董志塬黄土潜水资源量变化分析[J]. 甘肃科技,2009,25(24):31 − 33. [WEI Yutao,HOU Yanjun,LI Bin. Analysis of shallow water resources variation of loess in Dongzhiyuan[J]. Gansu Science and Technology,2009,25(24):31 − 33. (in Chinese) doi: 10.3969/j.issn.1000-0952.2009.24.011
[20] 邢天佑,李卓,刘平乐,等. 甘肃西峰地区“1988·7·23”特大暴雨灾害与水保措施调查评价[J]. 水土保持通报,1991,11(3):40 − 47. [XING Tianyou,LI Zhuo,LIU Pingle,et al. Survey and evaluation of disaster caused by heavy rainstorm occured on July 23,1988 and water and soil conservation measures in Xifeng area,Gansu Province[J]. Bulletin of Soil and Water Conservation,1991,11(3):40 − 47. (in Chinese with English abstract)
[21] 陈宝群,赵景波,李艳花. 特大丰水年洛川人工林地土壤水分特征研究[J]. 干旱区地理,2006,29(4):532 − 537. [CHEN Baoqun,ZHAO Jingbo,LI Yanhua. Research of soil water character below artificial forest of the heaviest rainfall year in Luochuan area of Yan’an[J]. Arid Land Geography,2006,29(4):532 − 537. (in Chinese with English abstract)
[22] 周有禄,武小鹏,房建宏,等. 大厚度黄土湿陷特性现场及室内试验对比研究[J]. 铁道建筑,2018,58(1):114 − 117. [ZHOU Youlu,WU Xiaopeng,FANG Jianhong,et al. Comparative study on field and laboratory tests for collapsibility characteristics of large thickness loess[J]. Railway Engineering,2018,58(1):114 − 117. (in Chinese with English abstract)
[23] 张晓宇. 银西高铁软塑黄土隧道地表降水试验研究[J]. 现代隧道技术,2019,56(3):154 − 160. [ZHANG Xiaoyu. Experimental study on ground dewatering of the soft plastic loess tunnel on the Yinchuan-Xi’an railway[J]. Modern Tunnelling Technology,2019,56(3):154 − 160. (in Chinese with English abstract)
[24] 陈天明. 董志塬富水黄土隧道地表降水开挖与隧底软基加固技术研究—以银西高铁驿马一号隧道为例[J]. 隧道建设,2021,41(6):1015 − 1023. [CHEN Tianming. Surface dewatering excavation and soft foundation reinforcement technology for water-rich loess tunnel in Dongzhi tableland:A case study of Yima No. 1 tunnel on Yinchuan-Xi’an high-speed railway[J]. Tunnel Construction,2021,41(6):1015 − 1023. (in Chinese)
[25] 彭建兵, 王启耀, 门玉明. 黄土高原滑坡灾害[M]. 北京: 科学出版社, 2019
PENG Jianbing, WANG Qiyao, MEN Yuming. Landslide disaster in loess plateau[M]. Beijing: Science Press, 2019. （in Chinese with English abstract）
[26] 孙建中. 黄土学（上篇）[M]. 中国香港: 香港考古学会出版, 2011
SUN Jianzhong. Loessology[M]. Hongkong, China: Hongkong Archaeological Society, 2011. （in Chinese with English abstract）
[27] 王永焱, 林在贯. 中国黄土的结构特征及物理力学性质[M]. 北京: 科学出版社, 1990
WANG Yongyan, LIN Zaiguan. Structural characteristics and physical and mechanical properties of Chinese loess[M]. Beijing: Science Press, 1990. （in Chinese）
[28] 高国瑞. 中国黄土的微结构[J]. 科学通报,1980,25(20):945 − 948. [GAO Guorui. Microstructure of loess in China[J]. Chinese Science Bulletin,1980,25(20):945 − 948. (in Chinese) doi: 10.1360/csb1980-25-20-945
[29] 雷祥义. 西安附近黄土孔隙特征[J]. 水文地质工程地质,1984,11(4):34 − 37. [LEI Xiangyi. Pore characteristics of Huangshi near Xi’an[J]. Hydrogeology & Engineering Geology,1984,11(4):34 − 37. (in Chinese)
[30] 李林翠,李喜安,洪勃,等. 不同埋深马兰黄土孔隙结构试验[J]. 吉林大学学报(地球科学版),2019,49(2):493 − 503. [LI Lincui,LI Xi’an,HONG Bo,et al. Experiment on pore structures of Malan loess at different buried depth[J]. Journal of Jilin University (Earth Science Edition),2019,49(2):493 − 503. (in Chinese with English abstract)
[31] 李云峰. 洛川黄土地层渗透性与孔隙性的关系[J]. 地球科学与环境学报,1991,13(2):60 − 64. [LI Yunfeng. Relationship between the permeability and the porosity of Luochuan’s loess layer[J]. Journal of Earth Science and Environmental,1991,13(2):60 − 64. (in Chinese with English abstract) doi: 10.19814/j.jese.1991.02.011
[32] 赵东. 黄土高原高速铁路隧道工程地质特点与地球物理探测[D]. 长春: 吉林大学, 2019
ZHAO Dong. Engineering geological characteristics of high-speed railway tunnels in the Loess Plateau and geophysical exploration[D]. Changchun: Jilin University, 2019. （in Chinese with English abstract）
[33] HILLEL D. Soil and water: Physical principles and processes[M]. New York: Academic Press, 1971.
[34] MCQUEEN I S,MILLER R F. Approximating soil moisture characteristics from limited data:empirical evidence and tentative model[J]. Water Resources Research,1974,10(3):521 − 527. doi: 10.1029/WR010i003p00521
[35] 张之淦,刘芳珍,张洪平,等. 应用环境氚研究黄土包气带水分运移及入渗补给量[J]. 水文地质工程地质,1990,17(3):5 − 7. [ZHANG Zhigan,LIU Fangzhen,ZHANG Hongping,et al. Study of soil water movement and recharge rate of rainfall infiltration in aeration zone of loess by measuring natural tritium[J]. Hydrogeology & Engineering Geology,1990,17(3):5 − 7. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.1990.03.003
[36] 凌新颖,马金珠,陈沛源,等. 陇东黄土高原董志塬区地下水水化学特征与14C年龄[J]. 兰州大学学报(自然科学版),2021,57(1):24 − 32. [LING Xinying,MA Jinzhu,CHEN Peiyuan,et al. Hydrogeochemical characteristics and radiocarbon dating of groundwater in the Dongzhi Tableland of Longdong Loess Plateau[J]. Journal of Lanzhou University (Natural Sciences),2021,57(1):24 − 32. (in Chinese with English abstract)
-
