A study of the tunnel collapse mechanism based on the BP neural network inversion analysis
-
摘要:
岩溶区隧道在施工过程中易发生崩塌，针对力学方面的隧道塌方机理分析较多，而针对岩溶软弱破碎带等地层方面的隧道塌方机理研究分析较少。为保证隧道施工的安全性、经济性和可行性，掌握隧道施工中的塌方机理非常有必要。依托贵州某岩溶破碎地层隧道在开挖过程中发生的坍塌现象，结合隧道的监测数据，运用BP神经网络的构建原理，对隧道的地层参数进行反演。将反演土体力学参数输入到FLAC3D有限元软件构建的不同施工方法模型中，对典型断面的崩塌破坏机制和风险进行判断和分析。结果表明：施工方法对隧道开挖的稳定性影响较大，针对围岩等级为Ⅴ级的隧道，采用三台阶七步法和单侧壁导坑法施工较安全，隧道塌方与隧道双向同时开挖没有关系；反演所得的隧道拱顶位移预测值为2.3 cm，地表位移预测值为1.2 cm，与监测数据偏差13%左右，反演结果具有一定的可信度。研究结果对岩溶区软弱破碎地层断面隧道公路建设具有重要指导意义。
Abstract:Tunnels in karst areas are prone to collapse during construction. There are many analyses on the mechanism of tunnel collapse in mechanical aspects, but the mechanism of tunnel collapse in karst weak fracture zones and other strata were seldom examined. In order to ensure the safety, economy and feasibility of tunnel construction, it is necessary to master the mechanism of collapse in the tunnel construction. Relying on a tunnel project in a karst broken stratum in Guizhou, where the collapse phenomenon occurred during the excavation process, the monitoring data of the tunnel are examined, and the construction principle of the BP neural network is used to invert the stratum parameters of the tunnel. The inversion soil mechanical parameters are input into different construction models constructed by using the FLAC3D finite element software, and the collapse failure mechanism and risk of typical sections are judged and analyzed. The results show that the construction method has a great influence on the stability of the tunnel excavation, and for the tunnel with the surrounding rock grade V , the three-step seven-step method and the single-side wall pilot pit method are safer for construction, and the tunnel collapse has no relationship with the simultaneous excavation of the tunnel in both directions. The predicted value of the tunnel vault displacement obtained by the inversion is 2.3 cm, and the predicted value of the surface displacement is 1.2 cm. The deviation from the monitoring data is about 13%, and the inversion result has certain reliability. The research results are of important guiding significance for the construction of tunnels and highways in weak and broken strata in karst areas.
-
-
表 1 隧道不同级别围岩长度及占比
Table 1. Surrounding rock grade and length ratio of the tunnel
隧 道名称 围岩级别 长度/m 占比/% 青岗山隧道 Ⅲ 395 61.7 Ⅳ 190 29.7 Ⅴ 55 8.6
下载: 导出CSV
表 2 正交设计试验表
Table 2. Orthogonal test tables
编号 粉质黏土 围岩 位移 弹性模量/MPa 黏聚力/kPa 摩擦角/（°） 弹性模量/GPa 黏聚力/kPa 摩擦角/（°） 拱顶位移/mm 地表位移/mm 1 5 8.5 20 10 5 10 21 0.42 2 16.25 11.875 20 15 32.5 18.7 44 0.88 3 27.5 15.25 20 20 60 27.5 62 1.24 4 38.75 18.62 20 25 87.5 36.2 78.5 1.57 5 50 22 20 30 115 45 96 1.92 6 38.75 22 26.25 10 32.5 27.5 54.5 1.09 7 50 8.5 26.25 15 60 36.2 60.5 1.21 8 5 11.875 26.25 20 87.5 45 32.5 0.65 9 16.25 15.25 26.25 25 115 10 57.5 1.15 10 27.5 18.62 26.25 30 5 18.7 38 0.76 11 16.25 18.62 32.5 10 60 45 49.5 0.99 12 27.5 22 32.5 15 87.5 10 64.5 1.29 13 38.75 8.5 32.5 20 115 18.7 69 1.38 14 50 11.875 32.5 25 5 27.5 48.5 0.97 15 5 15.25 32.5 30 32.5 36.2 38.5 0.77 16 50 15.25 38.75 10 87.5 18.7 62 1.24 17 5 18.62 38.75 15 115 27.5 48 0.96 18 16.25 22 38.75 20 5 36.2 59 1.18 19 27.5 8.5 38.75 25 32.5 45 55.5 1.11 20 38.75 11.875 38.75 30 60 10 69 1.38 21 27.5 11.875 45 10 115 36.2 56 1.12 22 38.75 15.25 45 15 5 45 64 1.28 23 50 18.62 45 20 32.5 10 53 1.06 24 5 22 45 25 60 18.7 53.5 1.07 25 16.25 8.5 45 30 87.5 27.5 42 0.84
下载: 导出CSV
表 3 地层参数反演数值
Table 3. Inversion of formation parameters
地层 弹性模量/MPa 黏聚力/kPa 摩擦角/（°） 粉质黏土 5.17 13.52 13.24 围岩 142.51 428.12 25.54
下载: 导出CSV
-
[1] QIAN Qihu. New development of rock engineering and technology in China[C]. Proceedings of 12th ISRM International Congress on Rock Mechanics, Harmonising Rock Engineering and the Environment. Beijing: Taylor and Francis Group, 2011: 57 − 61.
[2] HUDSON J A. The next 50 years of the ISRM and anticipated future progress in rock mechanics[C]. Proceedings of the 12th ISRM International Congress on Rock Mechanics, Harmonising Rock Engineering and the Environment. Beijing: Taylor and Francis Group, 2011: 47–51.
[3] 李术才,刘斌,孙怀凤,等. 隧道施工超前地质预报研究现状及发展趋势[J]. 岩石力学与工程学报,2014,33(6):1090 − 1113. [LI Shucai,LIU Bin,SUN Huaifeng,et al. State of art and trends of advanced geological prediction in tunnel construction[J]. Chinese Journal of Rock Mechanics and Engineering,2014,33(6):1090 − 1113. (in Chinese with English abstract)
[4] XIA Kaizong,CHEN Congxin,ZHENG Yun,et al. Engineering geology and ground collapse mechanism in the Chengchao Iron-ore Mine in China[J]. Engineering Geology,2019,249:129 − 147. doi: 10.1016/j.enggeo.2018.12.028
[5] HAN Lei, ZUO Yanyan, GUO Zeng,et al. Mechanical properties and deformation and failure characteristics of surrounding rocks of tunnels excavated in soft rocks[J]. Geotechnical and Geological Engineering,2017,35(6):2789 − 2801. doi: 10.1007/s10706-017-0278-9
[6] WANG Q,PAN R,JIANG B,et al. Study on failure mechanism of roadway with soft rock in deep coal mine and confined concrete support system[J]. Engineering Failure Analysis,2017,81:155 − 177. doi: 10.1016/j.engfailanal.2017.08.003
[7] HUANG Xing, LIU Quansheng, LIU Bin,et al. Experimental study on the dilatancy and fracturing behavior of soft rock under unloading conditions[J]. International Journal of Civil Engineering,2017,15(6):921 − 948. doi: 10.1007/s40999-016-0144-9
[8] ZHANG Zhiqiang, SHI Xiaoquan, WANG Bo,et al. Stability of NATM tunnel faces in soft surrounding rocks[J]. Computers and Geotechnics,2018,96:90 − 102. doi: 10.1016/j.compgeo.2017.10.009
[9] 戴永浩, 陈卫忠, 田洪铭, 等. 大梁隧道软岩大变形及其支护方案研究[J]. 岩石力学与工程学报, 2015, 34（增刊2）: 4149 − 4156
DAI Yonghao, CHEN Weizhong, TIAN Hongming, et al. Study of large deformation and support measures of Daliang Tunnel with soft surrounding rockmass[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34（Sup 2）: 4149 − 4156. （in Chinese with English abstract）
[10] XIA Kaizong, CHEN Congxin, WANG Tianlong,et al. Estimating the geological strength index and disturbance factor in the Hoek-Brown criterion using the acoustic wave velocity in the rock mass[J]. Engineering Geology,2022,306:106745. doi: 10.1016/j.enggeo.2022.106745
[11] 赵俊杰, 贾斌, 张东, 等. 基于 BP 神经网络的阿拉套山隧道围岩物理力学参数反演分析[J]. 隧道建设（中英文）, 2019, 39（增刊1）: 220 − 226
ZHAO Junjie, JIA Bin, ZHANG Dong, et al. Inverse analysis of physical and mechanical parameters of Alataoshan tunnel surrounding rock based on BP neural network[J]. Tunnel Construction, 2019, 39（Sup 1）: 220 − 226.
[12] 文辉辉,尹健民,秦志光,等. BP神经网络在隧道围岩力学参数反演中的应用[J]. 长江科学院院报,2013,30(2):47 − 51. [WEN Huihui,YIN Jianmin,QIN Zhiguang,et al. Application of BP neural network to the back analysis of mechanical parameters of tunnel surrounding rock[J]. Journal of Yangtze River Scientific Research Institute,2013,30(2):47 − 51. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-5485.2013.02.010
[13] 刘超,袁伟,路军富,等. 某铁路隧道底鼓段粉砂质泥岩微宏观物理力学特性研究[J]. 水文地质工程地质,2020,47(5):108 − 115. [LIU Chao,YUAN Wei,LU Junfu,et al. A study of the micro-macro-physical and mechanical properties of silty mudstone in the bottom drum section of a railway tunnel[J]. Hydrogeology & Engineering Geology,2020,47(5):108 − 115. (in Chinese with English abstract)
[14] 徐明祥,黄强兵,王庆兵,等. 西安地裂缝地段浅埋暗挖地铁隧道施工沉降规律[J]. 水文地质工程地质,2020,47(1):161 − 170. [XU Mingxiang,HUANG Qiangbing,WANG Qingbing,et al. Settlement rules of shallow-buried metro tunnel construction in the Xi'an ground fissure section[J]. Hydrogeology & Engineering Geology,2020,47(1):161 − 170. (in Chinese with English abstract)
[15] 刘科伟. 公路隧道建造期塌方风险分析及控制的系统研究[D]. 长沙: 湖南大学, 2012
LIU Kewei. The systemic landslide risk analysis and control in the construction of highway tunnels[D]. Changsha: Hunan University, 2012. （in Chinese with English abstract）
[16] 谢雄耀,蔡杰龙,周应新,等. 浅埋软弱围岩隧道施工塌方及处治措施研究[J]. 建筑施工,2022,44(3):545 − 549. [XIE Xiongyao,CAI Jielong,ZHOU Yingxin,et al. Research on collapse and treatment measures for shallowly buried weak surrounding rock construction[J]. Building Construction,2022,44(3):545 − 549. (in Chinese with English abstract) doi: 10.14144/j.cnki.jzsg.2022.03.035
[17] 丁涛. 浅埋隧道下穿高层建筑稳定性及相互影响研究[D]. 青岛: 青岛理工大学, 2013
DING Tao. Study on the stability and interplay for shallow-buried tunnel under-traversing the high-rise buildings[D]. Qingdao: Qingdao Tehcnology University, 2013. （in Chinese with English abstract）
[18] 陈洁金,周峰,阳军生,等. 山岭隧道塌方风险模糊层次分析[J]. 岩土力学,2009,30(8):2365 − 2370. [CHEN Jiejin,ZHOU Feng,YANG Junsheng,et al. Fuzzy analytic hierarchy process for risk evaluation of collapse during construction of mountain tunnel[J]. Rock and Soil Mechanics,2009,30(8):2365 − 2370. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2009.08.030
[19] 陈洁金, 高超, 晋婉晴, 等. 软弱地层大断面隧道三台阶七步法与临时仰拱法适应性分析的对比研究[J]. 工程力学, 2020, 37（增刊1）: 180-186
CHEN Jiejin, GAO Chao, JIN Wanqing, et al. Comparative study on adaptability analysis of three benching seven steps and temporary invert method for large-section tunnel in soft stratum[J]. Engineering Mechanics, 2020, 37（Sup 1）: 180-186. （in Chinese with English abstract）
[20] 许瑞宁,王志杰. 昔格达组地层大断面隧道施工工法比选分析[J]. 公路,2017,62(1):231 − 236. [XU Ruining,WANG Zhijie. Comparative analysis on construction methods of large section tunnels in xigeda formation strata[J]. Highway,2017,62(1):231 − 236. (in Chinese with English abstract)
[21] 高峰,唐星,李星,等. 基于UDEC离散元法的隧道塌方特征分析[J]. 重庆交通大学学报(自然科学版),2018,37(1):24 − 28. [GAO Feng,TANG Xing,LI Xing,et al. Tunnel collapse characteristics based on UDEC discrete element method[J]. Journal of Chongqing Jiaotong University (Natural Science),2018,37(1):24 − 28. (in Chinese with English abstract) doi: 10.3969/j.issn.1674-0696.2018.01.04
[22] 陈育民, 徐鼎平. FLAC/FLAC3D基础与工程实例[M]. 2版. 北京: 中国水利水电出版社, 2013
CHEN Yumin, XU Dingping. FLAC/FLAC3D foundation and engineering example[M]. 2nd ed. Beijing: China Water & Power Press, 2013. （in Chinese）
[23] 向欣. 边坡落石运动特性及碰撞冲击作用研究[D]. 武汉: 中国地质大学, 2010
XIANG Xin. Research on motion characteristics and impact force of rockfall[D]. Wuhan: China University of Geosciences, 2010. （in Chinese with English abstract）
[24] 杨友彬,郑俊杰,赖汉江,等. 一种改进的隧道开挖应力释放率确定方法[J]. 岩石力学与工程学报,2015,34(11):2251 − 2257. [YANG Youbin,ZHENG Junjie,LAI Hanjiang,et al. A revised method for calculating stress release ratio in tunnel excavation[J]. Chinese Journal of Rock Mechanics and Engineering,2015,34(11):2251 − 2257. (in Chinese with English abstract)
-
