Spatio-temporal change characteristics of water conservation function in the Zhang-Cheng district based on the InVEST model
-
摘要:
水源涵养作为重要的生态系统服务功能之一，对张家口和承德地区的生态系统及用水安全有着重要的意义。为了改进以往研究中对地形及土壤渗透性等考虑不足、对数据空间异质性分析不充分等问题，文章基于生态系统服务和权衡的综合评估模型（integrated valuation of ecosystem services and tradeoffs，InVEST），使用多种高精度的遥感、再分析数据等产品，对2001—2020年张承地区的水源涵养功能进行定量化评价及驱动因素分析。研究发现，2001—2020年张承地区水源涵养功能空间分布上呈现坝下高坝上低的特点，各年水源涵养功能的空间分布存在差异性的同时也具有一定的相似性。时间变化上，20年间水源涵养深度以−0.08 mm/a的平均速率呈下降波动趋势。结合Sen+Mann-Kendall分析发现区内水源涵养功能变化趋势以“基本不变”、“轻微增长”、“轻微降低”三者为主，总占比近98%。区内降水量对水源涵养功能具有很强的显著正相关关系，气温对水源涵养功能在部分地区具有显著负相关关系，植被与水源涵养功能的关系相对复杂。张承地区2020年林地的水源涵养功能最强，水源涵养深度达28.64 mm，总量而言，草地水源涵养功能的贡献最大，水源涵养量达1.12×109 m3。20年间变化中，耕地水源涵养量的降低最为明显，变化速率达−6.49×106 m3/a。上述结果说明张承地区20年间水源涵养功能的时空特征主要受到降水量与植被型土地利用的控制。研究为张承地区生态建设及水资源管理提供重要的决策依据。
-
关键词:
- 水源涵养功能 /
- InVEST模型 /
- Sen+Mann-Kendall /
- 相关性分析 /
- 张承地区
Abstract:As one of the important ecosystem service functions, water conservation function is of great significance to the ecosystem and water safety in the Zhangjiakou and Chengde districts. Based on the integrated valuation of ecosystem services and tradeoffs (InVEST) model, this study quantitatively evaluates the water conservation function and analyses its driving factors of the Zhang-Cheng district from 2001 to 2020 using high-quality remote sensing data and other reanalysis products, in order to improve the problems of insufficient consideration of topography and soil permeability, as well as the inadequate analyses of data spatial heterogeneity in previous studies. The results show that the spatial distribution of the water conservation function in the Zhang-Cheng district from 2001 to 2020 was characterized by high values in the Baxia areas and low values in the Bashang areas. Despite some differences, the spatial distribution of the water conservation function in each year had some similarities to some extent. In terms of the trend, the water conservation depth in these 20 years showed a fluctuating downward trend with an average rate of −0.08 mm/a. Combined with the Sen+Mann-Kendall analysis, the trend of the water conservation function in this area was mainly classified as "No trend", "Slight increase" and "Slight decrease", accounting for nearly 98% of the total area. The results of correlation analysis show that precipitation had a strongly significantly positive correlation with water conservation function, temperature had a significantly negative correlation with water conservation function in some areas, and the correlation between vegetation and water conservation function was complex. In the Zhang-Cheng district in 2020, the woodland had the strongest water conservation function, and the water conservation depth reached 28.64 mm. On the other hand, the grassland water conservation function had the greatest contribution in the total amount, and the water conservation reached 1.12×109 m3. During these 20 years, the water conservation of the farmland had the most obvious decrease, with a rate of −6.49×106 m3/a. The spatio-temporal change characteristics of water conservation function in the Zhang-Cheng district in these 20 years were mainly controlled by precipitation and vegetated land use. This study provides an important decision-making basis for ecological construction and water resources management in the Zhangcheng district.
-
-
表 2 各土地利用类型参数
Table 2. Parameters for each land use
土地利用一级分类 土地利用类型 最大根系深度/mm 蒸散系数 流速系数 林地 常绿针叶林 7 000 1.00 200 落叶针叶林 3 100 1.00 200 落叶阔叶林 3 100 1.00 180 针阔混交林 4 800 1.00 200 灌木丛 2 000 0.90 249 草地 多树草原 2 600 0.85 300 稀树草原 2 300 0.75 400 草地 2 000 0.75 500 耕地 农田 1 500 0.80 400 水域 湿地 1 000 1.20 2 012 水体 1 1.00 2 012 城建用地 城建用地 1 0.25 2 012 未利用土地 未利用土地 200 0.30 1 500
下载: 导出CSV
表 3 张承地区水源涵养功能变化趋势分级统计
Table 3. Classification statistics on the trends of water conservation function in the Zhang-Cheng district
Sen's slope Z 变化趋势分级 面积占比/% 平均变化趋势/（mm·a−1） β >0.1 |Z | >1.96 显著增长 1.11 0.70 β >0.1 |Z | ≤1.96 轻微增长 32.88 0.30 |β |≤0.1 – 基本不变 35.10 0.01 β <−0.1 |Z | ≤1.96 轻微降低 29.87 −0.54 β <−0.1 |Z | >1.96 显著降低 1.04 −1.25
下载: 导出CSV
表 4 张承地区水源涵养功能驱动因素相关性分级面积占比
Table 4. Classification area proportion of correlations between water conservation function and driving factors in the Zhang-Cheng district
/% 驱动因素 正相关（r>0） 相关性不显著 （p≥0.05）
或不相关（r=0）负相关（r<0） 极显著正相关（p≤0.01） 显著正相关（0.01<p<0.05） 显著负相关（0.01<p<0.05） 极显著负相关（p≤0.01） 降水 99.76 0.08 0.16 0.00 0.00 气温 0.00 0.00 42.95 31.12 25.92 NDVI 0.59 3.82 95.47 0.11 0.01
下载: 导出CSV
表 5 张承地区不同土地利用的水源涵养功能及其变化
Table 5. Water conservation functions and changes in different land uses in the Zhang-Cheng district
土地利用 2020年水源涵养功能 2001—2020年变化 平均水源涵养深度/mm 水源涵养量/（106 m3） 面积/km2 水源涵养量/（106 m3） 水源涵养量回归趋势/（106 m3·a−1） 林地 28.64 199.09 2 266.68 −43.11 1.80 草地 19.49 1 119.97 −1 296.32 416.76 −1.53 耕地 25.16 280.20 −1 056.87 −85.42 −6.49 水域 0.00 0.00 18.21 0.00 0.00 城建用地 8.97 5.34 85.37 3.23 0.08 未利用土地 1.45 0.05 −17.07 0.03 0.00
下载: 导出CSV
-
[1] 王云飞,叶爱中,乔飞,等. 水源涵养内涵及估算方法综述[J]. 南水北调与水利科技:中英文,2021,19(6):1041 − 1071. [WANG Yunfei,YE Aizhong,QIAO Fei,et al. Review on connotation and estimation method of water conservation[J]. South-to-North Water Transfers and Water Science & Technology,2021,19(6):1041 − 1071. (in Chinese with English abstract)
[2] 龚诗涵,肖洋,郑华,等. 中国生态系统水源涵养空间特征及其影响因素[J]. 生态学报,2017,37(7):2455 − 2462. [GONG Shihan,XIAO Yang,ZHENG Hua,et al. Spatial patterns of ecosystem water conservation in China and its impact factors analysis[J]. Acta Ecologica Sinica,2017,37(7):2455 − 2462. (in Chinese with English abstract)
[3] 吕乐婷,任甜甜,孙才志,等. 1980—2016年三江源国家公园水源供给及水源涵养功能时空变化研究[J]. 生态学报,2020,40(3):993 − 1003. [LÜ Leting,REN Tiantian,SUN Caizhi,et al. Spatial and temporal changes of water supply and water conservation function in Sanjiangyuan National Park from 1980 to 2016[J]. Acta Ecologica Sinica,2020,40(3):993 − 1003. (in Chinese with English abstract)
[4] LI Mingyue,LIANG Dong,XIA Jun,et al. Evaluation of water conservation function of Danjiang River Basin in Qinling Mountains,China based on InVEST model[J]. Journal of Environmental Management,2021,286:112212. doi: 10.1016/j.jenvman.2021.112212
[5] BENRA F,FRUTOS A D,GAGLIO M,et al. Mapping water ecosystem services:Evaluating InVEST model predictions in data scarce regions[J]. Environmental Modelling & Software,2021,138:104982.
[6] ABOUABDILLAH A,WHITE M,ARNOLD J G,et al. Evaluation of soil and water conservation measures in a semi-arid river basin in Tunisia using SWAT[J]. Soil Use and Management,2014,30(4):539 − 549. doi: 10.1111/sum.12146
[7] 刘景红,郑晓,樊俊美,等. 基于SWAT模型的浑河中上游水源涵养服务价值评估[J]. 应用生态学报,2021,32(11):3905 − 3912. [LIU Jinghong,ZHENG Xiao,FAN Junmei,et al. Evaluation of the value of water retention service in the middle and upper reaches of Hunhe River based on SWAT Model[J]. Chinese Journal of Applied Ecology,2021,32(11):3905 − 3912. (in Chinese with English abstract)
[8] 王晓学,李叙勇,莫菲,等. 基于元胞自动机的森林水源涵养量模型新方法—概念与理论框架[J]. 生态学报,2010,30(20):5491 − 5500. [WANG Xiaoxue,LI Xuyong,MO Fei,et al. Exploration of a new modeling method for forest water conservation based on cellular automata:Concept and theoretical framework[J]. Acta Ecologica Sinica,2010,30(20):5491 − 5500. (in Chinese with English abstract)
[9] CHEN J M,CHEN Xiaoyong,JU Weimin,et al. Distributed hydrological model for mapping evapotranspiration using remote sensing inputs[J]. Journal of Hydrology,2005,305(1):15 − 39.
[10] JORDA-CAPDEVILA D,GAMPE D,GARCÍA V H,et al. Impact and mitigation of global change on freshwater-related ecosystem services in Southern Europe[J]. Science of the Total Environment,2019,651:895 − 908. doi: 10.1016/j.scitotenv.2018.09.228
[11] SCORDO F,LAVENDER T M,SEITZ C,et al. Modeling water yield:Assessing the role of site and region-specific attributes in determining model performance of the invest seasonal water yield model[J]. Water,2018,10(11):1496. doi: 10.3390/w10111496
[12] 杨洁,谢保鹏,张德罡. 基于InVEST模型的黄河流域产水量时空变化及其对降水和土地利用变化的响应[J]. 应用生态学报,2020,31(8):2731 − 2739. [YANG Jie,XIE Baopeng,ZHANG Degang. Spatio-temporal variation of water yield and its response to precipitation and land use change in the Yellow River Basin based on InVEST model[J]. Chinese Journal of Applied Ecology,2020,31(8):2731 − 2739. (in Chinese with English abstract)
[13] 刘宥延,刘兴元,张博,等. 基于InVEST模型的黄土高原丘陵区水源涵养功能空间特征分析[J]. 生态学报,2020,40(17):6161 − 6170. [LIU Youyan,LIU Xingyuan,ZHANG Bo,et al. Spatial features analysis of water conservation function in the hilly areas of the Loess Plateau based on InVEST model[J]. Acta Ecologica Sinica,2020,40(17):6161 − 6170. (in Chinese with English abstract)
[14] LIU Run,NIU Xiang,WANG Bing,et al. InVEST model-based spatiotemporal analysis of water supply services in the zhangcheng district[J]. Forests,2021,12(8):1082. doi: 10.3390/f12081082
[15] 李怡颖,范继辉,廖莹. 基于InVEST模型的张家口市水源涵养功能时空差异分析[J]. 草业科学,2020,37(7):1313 − 1324. [LI Yiying,FAN Jihui,LIAO Ying. Analysis of spatial and temporal differences in water conservation function in Zhangjiakou based on the InVEST model[J]. Pratacultural Science,2020,37(7):1313 − 1324. (in Chinese with English abstract) doi: 10.11829/j.issn.1001-0629.2020-0090
[16] 张薇,王凤春,贾悦,等. 张承水源涵养区土地利用演变及产水量的响应[J]. 中国农村水利水电,2022(5):138 − 146. [ZHANG Wei,WANG Fengchun,JIA Yue,et al. Land use evolution and water yield response in zhangcheng water source conservation area[J]. China Rural Water and Hydropower,2022(5):138 − 146. (in Chinese with English abstract)
[17] 王盛,李亚文,李庆,等. 变化环境影响下张承地区水源涵养和土壤保持服务及其权衡与协同关系研究[J]. 生态学报,2022,42(13):5391 − 5403. [WANG Sheng,LI Yawen,LI Qing,et al. Water and soil conservation and their trade-off and synergistic relationship under changing environment in Zhangjiakou-Chengde area[J]. Acta Ecologica Sinica,2022,42(13):5391 − 5403. (in Chinese with English abstract)
[18] 邵雅琪,姜群鸥,胡中民,等. 张承地区植被指数时空演变特征及其与气候因子的关系[J]. 中国农业大学学报,2018,23(7):96 − 106. [SHAO Yaqi,JIANG Qun’ou,HU Zhongmin,et al. Spatio-temporal evolution of the vegetation index and its relationship with climatic factors in the Zhangjiakou-Chengde Region[J]. Journal of China Agricultural University,2018,23(7):96 − 106. (in Chinese with English abstract) doi: 10.11841/j.issn.1007-4333.2018.07.11
[19] 傅抱璞. 论陆面蒸发的计算[J]. 大气科学,1981,5(1):23 − 31. [FU Baopu. On the calculation of the evaporation from land surface[J]. Chinese Journal of Atmospheric Sciences,1981,5(1):23 − 31. (in Chinese with English abstract) doi: 10.3878/j.issn.1006-9895.1981.01.03
[20] ZHANG L,HICKEL K,DAWES W R,et al. A rational function approach for estimating mean annual evapotranspiration[J]. Water Resources Research,2004,40(2):W02502.
[21] ZHANG L,DAWES W R,WALKER G R. Response of mean annual evapotranspiration to vegetation changes at catchment scale[J]. Water Resources Research,2001,37(3):701 − 708. doi: 10.1029/2000WR900325
[22] SHARP R, DOUGLASS J, WOLNY S, et al. InVEST 3.10.2.post17+ug.g0e9e2ef user’s guide[R]. The Natural Capital Project, Standford University, University of Minnesota, the Nature Conservancy, World Wildlife Fund: Standford, CA, USA, 2020.
[23] 傅斌,徐佩,王玉宽,等. 都江堰市水源涵养功能空间格局[J]. 生态学报,2013,33(3):789 − 797. [FU Bin,XU Pei,WANG Yukuan,et al. Spatial pattern of water retetnion in Dujiangyan County[J]. Acta Ecologica Sinica,2013,33(3):789 − 797. (in Chinese with English abstract) doi: 10.5846/stxb201203260410
[24] 刘娇,郎学东,苏建荣,等. 基于InVEST模型的金沙江流域干热河谷区水源涵养功能评估[J]. 生态学报,2021,41(20):8099 − 8111. [LIU Jiao,LANG Xuedong,SU Jianrong,et al. Evaluation of water conservation function in the dry-hot valley area of Jinsha River Basin based on InVEST model[J]. Acta Ecologica Sinica,2021,41(20):8099 − 8111. (in Chinese with English abstract)
[25] CHEN Junhe,WANG Dongchuan,LI Guodong,et al. Spatial and temporal heterogeneity analysis of water conservation in Beijing-Tianjin-Hebei urban agglomeration based on the geodetector and spatial elastic coefficient trajectory models[J]. Geohealth,2020,4(8):e2020GH000248.
[26] 白杨. 武汉城市圈城市化进程对水源涵养功能影响变化研究[D]. 海口: 海南大学, 2014
BAI Yang. The research on the influence of urbanization on water conservation function in wuhan city circle[D]. Haikou: Hainan University, 2014. （in Chinese with English abstract）
[27] 张绪财. 格尔木河流域植被动态变化及影响因素分析[D]. 北京: 中国地质大学（北京）, 2019
ZHANG Xucai. Analysis of vegetation dynamics and its impact factors in the Golmud River Basin[D]. Beijing: China University of Geosciences （Beijing）, 2019. （in Chinese with English abstract）
[28] ZHANG Xucai,JIN Xiaomei. Vegetation dynamics and responses to climate change and anthropogenic activities in the Three-River Headwaters Region,China[J]. Ecological Indicators,2021,131:108223. doi: 10.1016/j.ecolind.2021.108223
[29] 蔡博峰,于嵘. 基于遥感的植被长时序趋势特征研究进展及评价[J]. 遥感学报,2009,13(6):1170 − 1186. [CAI Bofeng,YU Rong. Advance and evaluation in the long time series vegetation trends research based on remote sensing[J]. Journal of Remote Sensing,2009,13(6):1170 − 1186. (in Chinese with English abstract)
[30] DA SILVA R M,SANTOS C A G,MOREIRA M,et al. Rainfall and river flow trends using Mann–Kendall and Sen’s slope estimator statistical tests in the Cobres River basin[J]. Natural Hazards,2015,77(2):1205 − 1221. doi: 10.1007/s11069-015-1644-7
[31] 甘海洪,金晓媚,张绪财,等. 三江源区蒸散量的时空分布特征[J]. 现代地质,2021,35(3):665 − 674. [GAN Haihong,JIN Xiaomei,ZHANG Xucai,et al. Temporal and spatial distribution of evapotranspiration in the Sanjiangyuan Region[J]. Geoscience,2021,35(3):665 − 674. (in Chinese with English abstract)
[32] SABATER J M. ERA5-Land monthly averaged data from 1981 to present[DB]. Copernicus Climate Change Service （C3S） Climate Data Store （CDS）, 2019, 146: 1999-2049.
[33] HENGL T,MENDES DE JESUS J,HEUVELINK G B M,et al. Soil grids 250 m:Global gridded soil information based on machine learning[J]. PLoS One,2017,12(2):e0169748. doi: 10.1371/journal.pone.0169748
[34] ZHANG Yonggen,SCHAAP M G,ZHA Yuanyuan. A high-resolution global map of soil hydraulic properties produced by a hierarchical parameterization of a physically based water retention model[J]. Water Resources Research,2018,54(12):9774 − 9790. doi: 10.1029/2018WR023539
[35] 包玉斌,李婷,柳辉,等. 基于InVEST模型的陕北黄土高原水源涵养功能时空变化[J]. 地理研究,2016,35(4):664 − 676. [BAO Yubin,LI Ting,LIU Hui,et al. Spatial and temporal changes of water conservation of Loess Plateau in northern Shaanxi Province by InVEST model[J]. Geographical Research,2016,35(4):664 − 676. (in Chinese with English abstract)
[36] MO Wenbo,ZHAO Yunlin,YANG Nan,et al. Effects of climate and land use/land cover changes on water yield services in the dongjiang lake basin[J]. ISPRS International Journal of Geo-Information,2021,10(7):466. doi: 10.3390/ijgi10070466
[37] 金晓媚,王松涛,夏薇. 柴达木盆地植被对气候与地下水变化的响应研究[J]. 水文地质工程地质,2016,43(2):31 − 36. [JIN Xiaomei,WANG Songtao,XIA Wei. Response of vegetation to variation in climate and groundwater in the Qaidam Basin[J]. Hydrogeology & Engineering Geology,2016,43(2):31 − 36. (in Chinese with English abstract)
[38] 党学亚,卢娜,顾小凡,等. 柴达木盆地生态植被的地下水阈值[J]. 水文地质工程地质,2019,46(3):1 − 8. [DANG Xueya,LU Na,GU Xiaofan,et al. Groundwater threshold of ecological vegetation in Qaidam Basin[J]. Hydrogeology & Engineering Geology,2019,46(3):1 − 8. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.2019.03.01
[39] 金晓媚,万力,张幼宽,等. 银川平原植被生长与地下水关系研究[J]. 地学前缘,2007,14(3):197 − 203. [JIN Xiaomei,WAN Li,ZHANG Youkuan,et al. A study of the relationship between vegetation growth and groundwater in the Yinchuan Plain[J]. Earth Science Frontiers,2007,14(3):197 − 203. (in Chinese with English abstract) doi: 10.3321/j.issn:1005-2321.2007.03.018
-
