Impact of reservoir characteristics on the well spacing of sandstone geothermal reservoir: A case study of Jiyang Depression
-
摘要:
水热型地热资源的回灌式开采是公认的地热可持续开采方式,而采灌井距是地热项目中需要着重关注的问题,以避免开采井中的热突破现象。回灌水在热储中的运移取决于热储特征,也就是储层的透水能力,主要指热储的孔隙度、渗透率及砂泥岩组合关系等参数。基于济阳坳陷典型地热田的储层数据,采用Tough2为核心的Petrasim软件建立数值模型,系统研究了储层孔隙度、渗透率及单砂体厚度对热储中回灌水的运移以及温度场的影响。模拟结果显示:(1)储层孔隙度对回灌压力与采灌井距几乎没有影响;(2)储层渗透率对采灌率和采灌压力影响较大,控制着热储的回灌能力,但对采灌井距没有影响;(3)多次叠置的薄砂层热储中的泥岩隔层影响回灌水运移,在多层薄砂叠置的热储中回灌水水平运移距离远,温度影响范围更大,应扩大采灌井距。该研究对地热开发项目的可持续运行具有指导意义。
Abstract:The reinjection exploitation of hydrothermal resources is a recognized method of sustainable exploitation. The well space between the production and reinjection well is an essential issue because the thermal breakthrough in production well is the main negative impact during reinjection. The migration of reinjection water in the geothermal reservoir depends on the permeability of the reservoir, constrained by the geothermal reservoir characteristics. In this study, A numerical model using the Petrasim software with Tough2, as the core as well as reservoir data of each typical geothermal field in Jiyang depression, was established. The impact of the reservoir porosity and permeability and the thickness of a single sand layer on the migration of reinjection water and temperature field in the geothermal reservoir were analyzed systematically. The simulation results revealed that the reservoir porosity had a minor impact on the reinjection of the geothermal reservoir, including the reinjection pressure and the spacing of production and reinjection wells. The reservoir permeability affected the reinjection pressure, and then controlled the reinjection performance of the geothermal reservoir, while it had no impact on the spacing of production and reinjection wells. The sand layer superposition combination had a minor impact on the reinjection pressure of the geothermal reservoir. The distance of the horizontal migration of reinjection water in the multilayer stacked thin sand layers was longer, and the range of temperature influence was larger. Thus, it is necessary to expand the well space between production and reinjection well. This study is of significance for the stable operation of geothermal development projects.
-
-
表 1 济阳坳陷热储参数
Table 1. Geothermal parameters of Jiyang Deperssion
层位 砂岩厚度/m 地温/℃ 孔隙度/% 砂层渗透率/mD 开采流量/(m3·h−1) 回灌流量/(m3·h−1) Ng 100 65 30 800 90 35 Ed 100 85 28 600 100 30 表 2 地热井参数及抽水试验结果
Table 2. The parameters geothermal well and well test data
地热田 井号 水温/℃ 地层 顶板埋深/m 底板埋深/m 砂体厚度/m 抽水试验 降深/m 出水量/(m3·h−1) 单位降深出水量/(m3·h−1·m−1) 海洋采油厂 HY1-1 86 Ed 2155 2350 101.0 20.4 72.2 3.5 HY1-2 86 Ed 2160 2370 102.5 19.6 85.0 4.3 HY2-1 85 Ed 2146 2320 108.3 13.5 79.0 5.9 HY2-2 85 Ed 2150 2319 109.6 11.3 72.0 6.4 HY2-3 85 Ed 2138 2310 107.1 9.5 63.0 6.6 临盘宏祥小区 LR2-1 60 Ng2 1115 1280 98.2 15.0 98.0 6.5 LR2-2 60 Ng2 1130 1297 101.3 14.5 99.0 6.8 华瑞小区 HR1 64 Ng1-2 1425 1816 97.9 49.9 60.2 1.2 HR2 53 Ng2、Ed 1457 2117 298.2 25.0 105.0 4.2 表 3 岩石热导率数据
Table 3. Thermal conductivity of rocks
表 4 济阳坳陷地层平均热导率
Table 4. Mean thermal conductivity of formation in Jiyang Deperssion
地层名称 地层代号 地层岩性 平均热导率/(W·m−1·°C−1) 新近系明化镇组 Nm 泥岩、砂岩 2.04 新近系馆陶组 Ng 泥岩、砂岩 1.97 古近系东营组 Ed 泥岩、砂岩 2.09 古近系沙河街组 Es 泥岩、砂岩 1.85 古近系孔店组 Ek 泥岩、砂岩 2.23 中生代 Mz 泥岩、砂岩 2.22 古生代 Pz 灰岩、泥岩、砂岩 2.87 元古代 Pre 片麻岩 2.83 表 5 数值模型参数
Table 5. The parameters of numerical model
层位 地层平均密度/
(kg·m−3)孔隙度/% 渗透率/mD 热导率/
(W·m−1·°C−1)盖层 1800 25 10 1.34 热储层 2100 30 50 1.97 取水段 2200 30 400 1.97 底板 1900 25 10 2.21 表 6 不同砂体类型的参数概化
Table 6. Parameters conceptualization of different types of sandstone
取水段 单层砂体类型 单层砂体厚度/m 代表性沉积相 厚100 m,
储厚比60%厚层砂岩 30 辫状河道 中厚层砂岩 15 河口坝 薄层砂岩 5 三角洲前缘 -
[1] DUAN Zhongfeng,PANG Zhonghe,WANG Xinyi. Sustainability evaluation of limestone geothermal reservoirs with extended production histories in Beijing and Tianjin,China[J]. Geothermics,2011,40(2):125 − 135. doi: 10.1016/j.geothermics.2011.02.001
[2] SU Yujuan,YANG Fengtian,WANG Bing,et al. Reinjection of cooled water into sandstone geothermal reservoirs in China:A review[J]. Geosciences Journal,2018,22(1):199 − 207. doi: 10.1007/s12303-017-0019-3
[3] KAMILA Z,KAYA E,ZARROUK S J. Reinjection in geothermal fields:An updated worldwide review 2020[J]. Geothermics,2021,89:101970. doi: 10.1016/j.geothermics.2020.101970
[4] 康凤新,周群道,赵苏民,等. 砂岩热储地热尾水回灌技术规程:DZ/T 0330—2019[S]. 北京:中国标准出版社,2019. [KANG Fengxin,ZHOU Qundao,ZHAO Sumin,et al. Technical regulations of geothermal tail water reinjection in sandstone geothermal reservoir:DZ/T 0330—2019[S]. Beijing:China Standards Press,2019. (in Chinese)
KANG Fengxin, ZHOU Qundao, ZHAO Sumin, et al. Technical regulations of geothermal tail water reinjection in sandstone geothermal reservoir: DZ/T 0330—2019[S]. Beijing: China Standards Press, 2019. (in Chinese) [5] SUZUKI A,NIIBORI Y,FOMIN S,et al. Prediction of reinjection effects in fault-related subsidiary structures by using fractional derivative-based mathematical models for sustainable design of geothermal reservoirs[J]. Geothermics,2015,57:196 − 204. doi: 10.1016/j.geothermics.2015.04.001
[6] 马峰,高俊,王贵玲,等. 雄安新区容城地热田碳酸盐岩热储采灌数值模拟[J]. 吉林大学学报(地球科学版),2022,52(5):1 − 18. [MA Feng,GAO Jun,WANG Guiling,et al. Numerical simulation of exploitation and reinjection of carbonate geothermal reservoir in rongcheng geothermal field,Xiongan new area[J]. Journal of Jilin University (Earth Science Edition),2022,52(5):1 − 18. (in Chinese with English abstract)
MA Feng, GAO Jun, WANG Guiling, et al . Numerical simulation of exploitation and reinjection of carbonate geothermal reservoir in rongcheng geothermal field, Xiongan new area[J]. Journal of Jilin University (Earth Science Edition),2022 ,52 (5):1 −18 . (in Chinese with English abstract)[7] 李永利,于长生,姜智超,等. 松嫩盆地北部林甸地热田供暖尾水处理试验[J]. 水文地质工程地质,2021,48(1):188 − 194. [LI Yongli,YU Changsheng,JIANG Zhichao,et al. An experimental study of heating tail water treatment of the Lindian geothermal fields in the Northern Songnen Basin[J]. Hydrogeology & Engineering Geology,2021,48(1):188 − 194. (in Chinese with English abstract)
LI Yongli, YU Changsheng, JIANG Zhichao, et al . An experimental study of heating tail water treatment of the Lindian geothermal fields in the Northern Songnen Basin[J]. Hydrogeology & Engineering Geology,2021 ,48 (1 ):188 −194 . (in Chinese with English abstract)[8] WANG Shufang,LIU Jiurong,SUN Ying,et al. Study on the geothermal production and reinjection mode in Xiong County[J]. Journal of Groundwater Science and Engineering,2018,6(3):178 − 186.
[9] LEI Haiyan,ZHU Jialing. Numerical modeling of exploitation and reinjection of the Guantao geothermal reservoir in Tanggu District,Tianjin,China[J]. Geothermics,2013,48:60 − 68. doi: 10.1016/j.geothermics.2013.03.008
[10] KONG Yanlong,PANG Zhonghe,SHAO Haibing,et al. Recent studies on hydrothermal systems in China:A review[J]. Geothermal Energy,2014,2(1):1 − 12. doi: 10.5194/gtes-2-1-2014
[11] 马峰,王贵玲,魏帅超,等. 2018年地热勘探开发热点回眸[J]. 科技导报,2019,37(1):134 − 143. [MA Feng,WANG Guiling,WEI Shuaichao,et al. Summary of hot research topics in geothermal exploitation in 2018[J]. Science & Technology Review,2019,37(1):134 − 143. (in Chinese with English abstract)
MA Feng, WANG Guiling, WEI Shuaichao, et al . Summary of hot research topics in geothermal exploitation in 2018[J]. Science & Technology Review,2019 ,37 (1 ):134 −143 . (in Chinese with English abstract)[12] 林黎,王连成,赵苏民,等. 天津地区孔隙型热储层地热流体回灌影响因素探讨[J]. 水文地质工程地质,2008,35(6):125 − 128. [LIN Li,WANG Liancheng,ZHAO Sumin,et al. A discussion of the factors affecting geothermal reinjection in the geothermal reservoir of porous type in Tianjin[J]. Hydrogeology & Engineering Geology,2008,35(6):125 − 128. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-3665.2008.06.028
doi: 10.3969/j.issn.1000-3665.2008.06.028LIN Li, WANG Liancheng, ZHAO Sumin, et al . A discussion of the factors affecting geothermal reinjection in the geothermal reservoir of porous type in Tianjin[J]. Hydrogeology & Engineering Geology,2008 ,35 (6 ):125 −128 . (in Chinese with English abstract)[13] O’SULLIVAN M J,PRUESS K,LIPPMANN M J. State of the art of geothermal reservoir simulation[J]. Geothermics,2001,30(4):395 − 429. doi: 10.1016/S0375-6505(01)00005-0
[14] 周训,陈明佑,吴胜军,等. 天津市深层基岩地下热水系统数值模拟中若干问题的处理[J]. 地球科学,2002,27(2):163 − 167. [ZHOU Xun,CHEN Mingyou,WU Shengjun,et al. Treatment of some problems in numerical modeling of geothermal water system in deep-seated basement rocks near Tianjin[J]. Earth Science,2002,27(2):163 − 167. (in Chinese with English abstract)
ZHOU Xun, CHEN Mingyou, WU Shengjun, et al . Treatment of some problems in numerical modeling of geothermal water system in deep-seated basement rocks near Tianjin[J]. Earth Science,2002 ,27 (2 ):163 −167 . (in Chinese with English abstract)[15] 闫佰忠,徐文杰,李玉涵,等. 地下水源热泵抽灌井优化布置及参数灵敏度[J]. 吉林大学学报(地球科学版),2023,53(1):218 − 229. [YAN Baizhong,XU Wenjie,LI Yuhan,et al. Optimal layout of pumping and recharging wells for groundwater source heat pump and parameter sensitivity[J]. Journal of Jilin University (Earth Science Edition),2023,53(1):218 − 229. (in Chinese with English abstract)
YAN Baizhong, XU Wenjie, LI Yuhan, et al . Optimal layout of pumping and recharging wells for groundwater source heat pump and parameter sensitivity[J]. Journal of Jilin University (Earth Science Edition),2023 ,53 (1 ):218 −229 . (in Chinese with English abstract)[16] 马峰,高俊,王贵玲,等. 雄安新区容城地热田碳酸盐岩热储采灌数值模拟[J]. 吉林大学学报(地球科学版),2023,53(5):1534 − 1548. [MA Feng, GAO Jun, WANG Guiling, et al. Numerical simulation of exploitation and reinjection of carbonate geothermal reservoir in Rongcheng geothermal field, Xiongan new area[J]. Journal of Jilin University (Earth Science Edition),2023,53(5):1534 − 1548. (in Chinese with English abstract)
MA Feng, GAO Jun, WANG Guiling, et al . Numerical simulation of exploitation and reinjection of carbonate geothermal reservoir in Rongcheng geothermal field, Xiongan new area[J]. Journal of Jilin University (Earth Science Edition),2023 ,53 (5 ):1534 −1548 . (in Chinese with English abstract)[17] 段忠丰,李福来,巩亮,等. 基于水热耦合模拟的油气区地热开发井网布局[J]. 天然气工业,2020,40(10):156 − 162. [DUAN Zhongfeng,LI Fulai,GONG Liang,et al. Geo-thermal development well spacing patterns based on hydrothermal coupled modeling in oil-gas bearing areas[J]. Natural Gas Industry,2020,40(10):156 − 162. (in Chinese with English abstract)
DUAN Zhongfeng, LI Fulai, GONG Liang, et al . Geo-thermal development well spacing patterns based on hydrothermal coupled modeling in oil-gas bearing areas[J]. Natural Gas Industry,2020 ,40 (10 ):156 −162 . (in Chinese with English abstract)[18] 阮传侠. 天津地区雾迷山组热储地热回灌研究[D]. 北京:中国地质大学(北京),2018. [RUAN Chuanxia. A study of reinjection of geothermal resources in the geothermal reservoir of the wumishan group in Tianjin[D]. Beijing:China University of Geosciences,2018. (in Chinese with English abstract)
RUAN Chuanxia. A study of reinjection of geothermal resources in the geothermal reservoir of the wumishan group in Tianjin[D]. Beijing: China University of Geosciences, 2018. (in Chinese with English abstract) [19] 王宽. 基于TOUGH2数值模拟软件的延津地区热储采灌研究[J]. 地下水,2019,41(1):14 − 16. [WANG Kuan. Research on thermal storage and irrigation in Yanjin area based on TOUGH2 numerical simulation software[J]. Ground Water,2019,41(1):14 − 16. (in Chinese with English abstract)
WANG Kuan . Research on thermal storage and irrigation in Yanjin area based on TOUGH2 numerical simulation software[J]. Ground Water,2019 ,41 (1 ):14 −16 . (in Chinese with English abstract)[20] 胡永乐,王燕灵,杨思玉,等. 注水油田高含水后期开发技术方针的调整[J]. 石油学报,2004,25(5):65 − 69. [HU Yongle,WANG Yanling,YANG Siyu,et al. Adjustment of technical policy for water-flooding oilfield with high water cut in the late stage of development[J]. Acta Petrolei Sinica,2004,25(5):65 − 69. (in Chinese with English abstract)
HU Yongle, WANG Yanling, YANG Siyu, et al . Adjustment of technical policy for water-flooding oilfield with high water cut in the late stage of development[J]. Acta Petrolei Sinica,2004 ,25 (5 ):65 −69 . (in Chinese with English abstract)[21] 冯曦,彭先,李隆新,等. 碳酸盐岩气藏储层非均质性对水侵差异化的影响[J]. 天然气工业,2018,38(6):67 − 75. [FENG Xi,PENG Xian,LI Longxin,et al. Influence of reservoir heterogeneity on water invasion differentiation in carbonate gas reservoirs[J]. Natural Gas Industry,2018,38(6):67 − 75. (in Chinese with English abstract) doi: 10.3787/j.issn.1000-0976.2018.06.009
doi: 10.3787/j.issn.1000-0976.2018.06.009FENG Xi, PENG Xian, LI Longxin, et al . Influence of reservoir heterogeneity on water invasion differentiation in carbonate gas reservoirs[J]. Natural Gas Industry,2018 ,38 (6 ):67 −75 . (in Chinese with English abstract)[22] BABAEI M,NICK H M. Performance of low-enthalpy geothermal systems:Interplay of spatially correlated heterogeneity and well-doublet spacings[J]. Applied Energy,2019,253:113569. doi: 10.1016/j.apenergy.2019.113569
[23] LIU Xueling,WANG Yuanming,LI Shuai,et al. The influence of reinjection and hydrogeological parameters on thermal energy storage in brine aquifer[J]. Applied Energy,2020,278:115685. doi: 10.1016/j.apenergy.2020.115685
[24] GAO Fei, LIU Feng, WANG Huajun. Numerical modelling of the dynamic process of oil displacement by water in sandstone reservoirs with random pore structures[J]. Journal of Groundwater Science and Engineering,2021,9(3):233 − 244.
[25] ZHANG Ying,LUO Jun,FENG Jianyun. Characteristics of geothermal reservoirs and utilization of geothermal resources in the southeastern coastal areas of China[J]. Journal of Groundwater Science and Engineering,2020,8(2):134 − 142.
[26] 赵铭海,李晓燕,宋明水,等. 济阳坳陷东营组—馆陶组地热资源评价[J]. 油气地质与采收率,2015,22(4):1 − 5. [ZHAO Minghai,LI Xiaoyan,SONG Mingshui,et al. Research on geothermal resources assessment of the Guantao-Dongying Formation in Jiyang depression[J]. Petroleum Geology and Recovery Efficiency,2015,22(4):1 − 5. (in Chinese with English abstract) doi: 10.3969/j.issn.1009-9603.2015.04.001
doi: 10.3969/j.issn.1009-9603.2015.04.001ZHAO Minghai, LI Xiaoyan, SONG Mingshui, et al . Research on geothermal resources assessment of the Guantao-Dongying Formation in Jiyang depression[J]. Petroleum Geology and Recovery Efficiency,2015 ,22 (4 ):1 −5 . (in Chinese with English abstract)[27] 孟祥玲,王庆兵,杨培杰. 山东省地热资源开发利用现状调查与问题分析[J]. 山东国土资源,2021,37(11):36 − 42. [MENG Xiangling,WANG Qingbing,YANG Peijie. Investigation and problem analysis on development and utilization of geothermal resources in Shandong Province[J]. Shandong Land and Resources,2021,37(11):36 − 42. (in Chinese with English abstract)
MENG Xiangling, WANG Qingbing, YANG Peijie . Investigation and problem analysis on development and utilization of geothermal resources in Shandong Province[J]. Shandong Land and Resources,2021 ,37 (11 ):36 −42 . (in Chinese with English abstract)[28] 国景星,王永诗. 济阳坳陷新近系层序地层及沉积体系[J]. 油气地质与采收率,2006,13(6):9 − 12. [GUO Jingxing,WANG Yongshi. Sequence stratigraphy and sedimentary system of Neogene strata in Jiyang Depression[J]. Petroleum Geology and Recovery Efficiency,2006,13(6):9 − 12. (in Chinese with English abstract) doi: 10.3969/j.issn.1009-9603.2006.06.003
doi: 10.3969/j.issn.1009-9603.2006.06.003GUO Jingxing, WANG Yongshi . Sequence stratigraphy and sedimentary system of Neogene strata in Jiyang Depression[J]. Petroleum Geology and Recovery Efficiency,2006 ,13 (6 ):9 −12 . (in Chinese with English abstract)[29] 田美荣. 东营凹陷新近系馆陶组层序地层格架[J]. 油气地质与采收率,2010,17(2):1 − 3. [TIAN Meirong. Stratigraphic sequence framework of Neogene Guantao formation,Dongying Sag[J]. Petroleum Geology and Recovery Efficiency,2010,17(2):1 − 3. (in Chinese with English abstract) doi: 10.3969/j.issn.1009-9603.2010.02.001
doi: 10.3969/j.issn.1009-9603.2010.02.001TIAN Meirong . Stratigraphic sequence framework of Neogene Guantao formation, Dongying Sag[J]. Petroleum Geology and Recovery Efficiency,2010 ,17 (2 ):1 −3 . (in Chinese with English abstract)[30] 陈墨香. 华北地热[M]. 北京:科学出版社,1988. [CHEN Moxiang. North China geothermal[M]. Beijing:Science Press,1988. (in Chinese)
CHEN Moxiang. North China geothermal[M]. Beijing: Science Press, 1988. (in Chinese) [31] 龚育龄,王良书,刘绍文,等. 济阳坳陷地幔热流和深部温度[J]. 地球科学,2005,30(1):121 − 128. [GONG Yuling,WANG Liangshu,LIU Shaowen,et al. Mantle heat flow and deep temperature of Jiyang depression,Shandong,North China[J]. Earth Science,2005,30(1):121 − 128. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-2383.2005.01.017
doi: 10.3321/j.issn:1000-2383.2005.01.017GONG Yuling, WANG Liangshu, LIU Shaowen, et al . Mantle heat flow and deep temperature of Jiyang depression, Shandong, North China[J]. Earth Science,2005 ,30 (1 ):121 −128 . (in Chinese with English abstract)[32] 熊振,王良书,李成,等. 东营凹陷现代热流场特征及地热异常成因[J]. 石油勘探与开发,1999,26(4):38 − 41. [XIONG Zhen,WANG Liangshu,LI Cheng,et al. Determination and interpretation of the terrestrial heat flow in Dongying depression[J]. Petroleum Exploration and Development,1999,26(4):38 − 41. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-0747.1999.04.010
doi: 10.3321/j.issn:1000-0747.1999.04.010XIONG Zhen, WANG Liangshu, LI Cheng, et al . Determination and interpretation of the terrestrial heat flow in Dongying depression[J]. Petroleum Exploration and Development,1999 ,26 (4 ):38 −41 . (in Chinese with English abstract)[33] PRUESS K,OLDENBURG C M,MORIDIS G J,et al. TOUGH2 User’s Guide,Version 2.0. Report LBNL-43134[Z]. Earth Science Division,Lawrence Berkeley National Laboratory,University of California,Berkeley,California,1999.
-
