Analysis on settlement factors of shield tunnel foundation for operating metro
-
摘要:
隧道基底沉降不仅影响地铁列车的正常运行和乘客的舒适性，严重时会造成隧道结构病害，目前的研究主要集中在长期沉降预测和单因素影响分析，非常有必要开展隧道基底沉降的多影响因素分析。以郑州地铁1号线某盾构隧道区间为工程实例，构建三维有限元数值模型，采用人工激振力模拟地铁列车竖向荷载，提取数值模拟结果的动应力和静偏应力数据，引入循环荷载作用下累积塑性应变计算公式，采用分层总和法计算得到隧道基底沉降，研究了隧道周围土层性质、道床脱空深度和地铁列车运行速度等因素对隧道基底沉降的影响，研究结果表明：数值模拟的隧道基底沉降和发展规律与现场实测结果具有较高的吻合度，验证了有限元模拟的准确性；隧道基底沉降随着周围土层砂粒含量的提高而减小；道床脱空尺寸会加剧隧道和道床板中应力集中和振动放大现象，增大隧道下卧土层的动偏应力和基底沉降；提高车速会增大基底沉降的横向影响范围；采用正交试验法、极差分析法和方差分析法得到了隧道沉降对各因素的敏感性，从大到小依次为：土层性质、车速和道床脱空，其中，土层性质为高度显著水平、车速为显著水平。研究成果对运营地铁盾构隧道的变形监测、安全评估和加固处理具有一定的参考价值。
Abstract:The metro tunnel settlement would directly affect the normal train operation and the comfort of passengers; severe uneven settlement can easily cause tunnel structural diseases. The relevant studies mainly focused on long-term settlement prediction and single factor impact analysis; it is necessary to analyze the multiple factors that influence the tunnel foundation settlement. A three-dimensional finite element numerical model of one shield tunnel section of Zhengzhou metro 1st line was constructed and the vertical load of metro train was simulated as artificial excitation force to extract the dynamic stress and static deviator stress data. Introducing the cumulative plastic strain calculation formula under cyclic load, the layered summation method was used to calculate the tunnel foundation settlement. The influences of factors, such as the properties of soil where the tunnel is buried, the depth of track bed void, and metro operation velocity, on the tunnel foundation settlement were further analyzed. The results show that the numerical simulated foundation settlement and development law are consistent with on-site measured results, which verifies the accuracy of finite element simulation. The tunnel foundation settlement decreases with the increase of sand content in the surrounding soil layer; the size of the track bed void would exacerbate the stress concentration and vibration amplification in the tunnel and track bed slab, and then increase the dynamic deviatoric stress of soil layer under the tunnel and foundation settlement. Increasing the metro train velocity would increase the lateral influence range of foundation settlement. The sensitivity of tunnel settlement to various factors is obtained with orthogonal experimental method, range analysis method, and variance analysis method. The descending order of sensitivity is soil layer properties, train velocity, and track bed void, in which, soil layer property has a highly significant level and vehicle speed a has significant level. This study can provide basic information for the deformation monitoring, safety assessment, and reinforcement treatment of operating metro tunnels.
-
-
表 1 土层的相关参数
Table 1. Relevant parameters of soils
土层 平均层厚
/m密度
/（g·cm−3）弹性模量
/MPa泊松比 黏聚力
/kPa内摩擦角
/（°）杂填土 2.3 1.80 25.0 0.33 10.1 19.2 粉土 11.7 1.94 33.0 0.38 13.7 20.8 粉质黏土夹粉砂 7.0 2.00 45.0 0.37 14.6 23.2 细砂 10.2 2.13 62.4 0.35 0.0 30.0 粉质黏土 14.4 1.98 37.0 0.31 26.8 19.3
下载: 导出CSV
表 2 隧道和道床的相关参数
Table 2. Relevant parameters of tunnel and track bed
隧道结构 密度/（g·cm−3） 弹性模量/GPa 泊松比 隧道 2.50 34.5 0.20 道床 2.45 31.5 0.20
下载: 导出CSV
表 3 正交试验因素与水平
Table 3. Orthogonal experimental factors and levels
因素 土层性质 脱空深度/cm 车速/（km·h−1） 水平1 A 0 40 水平2 B 2 60 水平3 C 4 80 注：表中A为粉质黏土，B为粉质黏土夹粉砂，C为粉砂。
下载: 导出CSV
表 4 正交试验结果汇总
Table 4. Summary of orthogonal test results
组合 土层性质 脱空深度/cm 车速/（km·h−1） 沉降/mm 1 A 0 40 38.92 2 A 2 60 37.73 3 A 4 80 36.48 4 B 0 60 30.55 5 B 2 80 29.41 6 B 4 40 34.51 7 C 0 80 23.09 8 C 2 40 27.29 9 C 4 60 26.14
下载: 导出CSV
表 5 正交试验结果直观分析
Table 5. Visual analysis of orthogonal test
响应值 土层性质 脱空深度 车速 K1 37.71 30.85 33.57 K2 31.49 31.48 31.47 K3 25.51 32.38 29.66 R 12.20 1.52 3.88
下载: 导出CSV
表 6 正交试验方差分析
Table 6. Analysis of variance in orthogonal experiments
因素 偏差平方和 自由度 F F临界值 0.90 0.95 0.99 土层性质 223.41 2 1 128.21 9 19 99 脱空深度 3.52 2 3.56 9 19 99 车速 23.01 2 22.88 9 19 99 误差 0.19 2 注：F为检验统计量，与给定的F临界值比较，做出决策。
下载: 导出CSV
-
[1] 狄宏规,周顺华,宫全美,等. 软土地区地铁隧道不均匀沉降特征及分区控制[J]. 岩土工程学报,2015,37(增刊2):74 − 79. [DI Honggui,ZHOU Shunhua,GONG Quanmei,et al. Differential settlement of metro tunnels and its zonal control in soft deposits[J]. Chinese Journal of Geotechnical Engineering,2015,37(Sup 2):74 − 79. (in Chinese with English abstract)]
DI Honggui, ZHOU Shunhua, GONG Quanmei, et al. Differential settlement of metro tunnels and its zonal control in soft deposits[J]. Chinese Journal of Geotechnical Engineering, 2015, 37（Sup 2）: 74 − 79. （in Chinese with English abstract）
[2] 闫静雅,王如路. 上海软土地铁隧道沉降及横向收敛变形的原因分析及典型特征[J]. 自然灾害学报,2018,27(4):178 − 187. [YAN Jingya,WANG Rulu. Cause analysis and typical characteristics of settlement and transverse convergence deformation of metro tunnel in soft ground in Shanghai[J]. Journal of Natural Disasters,2018,27(4):178 − 187. (in Chinese with English abstract)]
YAN Jingya, WANG Rulu. Cause analysis and typical characteristics of settlement and transverse convergence deformation of metro tunnel in soft ground in Shanghai[J]. Journal of Natural Disasters, 2018, 27（4）: 178 − 187. （in Chinese with English abstract）
[3] 付君宜,陈发达,沈志平,等. 岩溶山区城市地下隧道工程地质灾害风险分析[J]. 中国地质灾害与防治学报,2023,34(3):100 − 108. [FU Junyi,CHEN Fada,SHEN Zhiping,et al. Risk analysis of the geological hazards during urban tunnel construction in mountainous Karst areas[J]. The Chinese Journal of Geological Hazard and Control,2023,34(3):100 − 108. (in Chinese with English abstract)]
FU Junyi, CHEN Fada, SHEN Zhiping, et al. Risk analysis of the geological hazards during urban tunnel construction in mountainous Karst areas[J]. The Chinese Journal of Geological Hazard and Control, 2023, 34（3）: 100 − 108. （in Chinese with English abstract）
[4] 尹承深,刘全明,王福强. 基于Sentinel-1A SAR数据的呼和浩特城区地表形变分析[J]. 中国地质灾害与防治学报,2023,34(2):73 − 81. [YIN Chengshen,LIU Quanming,WANG Fuqiang. Surface deformation analysis of Hohhot urban area based on SAR data from Sentinel-1A[J]. The Chinese Journal of Geological Hazard and Control,2023,34(2):73 − 81. (in Chinese with English abstract)]
YIN Chengshen, LIU Quanming, WANG Fuqiang. Surface deformation analysis of Hohhot urban area based on SAR data from Sentinel-1A[J]. The Chinese Journal of Geological Hazard and Control, 2023, 34（2）: 73 − 81. （in Chinese with English abstract）
[5] 周彩荣. 武汉某地铁盾构隧道运营期常见病害原因分析及治理措施[J]. 城市轨道交通研究,2018,21(12):153 − 157. [ZHOU Cairong. Analysis of common diseases in metro shield tunnel during operation period and the control measures[J]. Urban Mass Transit,2018,21(12):153 − 157. (in Chinese with English abstract)]
ZHOU Cairong. Analysis of common diseases in metro shield tunnel during operation period and the control measures[J]. Urban Mass Transit, 2018, 21（12）: 153 − 157. （in Chinese with English abstract）
[6] 许文. 砂层基础的运营地铁隧道异常沉降治理措施研究[J]. 都市快轨交通,2019,32(4):93 − 98. [XU Wen. Study on differential settlement control measures of subway-operated tunnel above sand layer[J]. Urban Rapid Rail Transit,2019,32(4):93 − 98. (in Chinese with English abstract)] doi: 10.3969/j.issn.1672-6073.2019.04.016
XU Wen. Study on differential settlement control measures of subway-operated tunnel above sand layer[J]. Urban Rapid Rail Transit, 2019, 32（4）: 93 − 98. （in Chinese with English abstract） doi: 10.3969/j.issn.1672-6073.2019.04.016
[7] 王伟,王兴,周勋,等. 砂卵石地层盾构区间地表沉降影响因素聚类分析[J]. 吉林大学学报(地球科学版),2024,54(1):219 − 230. [WANG Wei,WANG Xing,ZHOU Xun,et al. Cluster analysis of influencing factors of surface subsidence in shield interval of sandy gravel stratum[J]. Journal of Jilin University (Earth Science Edition),2024,54(1):219 − 230.(in Chinese with English abstract)]
WANG Wei, WANG Xing, ZHOU Xun, et al. Cluster analysis of influencing factors of surface subsidence in shield interval of sandy gravel stratum[J]. Journal of Jilin University (Earth Science Edition), 2024, 54（1）: 219 − 230.（in Chinese with English abstract）
[8] 刘明,黄茂松,李进军. 地铁荷载作用下饱和软粘土的长期沉降分析[J]. 地下空间与工程学报,2006,2(5):813 − 817. [LIU Ming,HUANG Maosong,LI Jinjun. Long-term settlement of saturated soft clay under subway loading[J]. Chinese Journal of Underground Space and Engineering,2006,2(5):813 − 817. (in Chinese with English abstract)] doi: 10.3969/j.issn.1673-0836.2006.05.026
LIU Ming, HUANG Maosong, LI Jinjun. Long-term settlement of saturated soft clay under subway loading[J]. Chinese Journal of Underground Space and Engineering, 2006, 2（5）: 813 − 817. （in Chinese with English abstract） doi: 10.3969/j.issn.1673-0836.2006.05.026
[9] 杨兵明,刘保国. 地铁列车循环荷载下软土地区盾构隧道长期沉降分析[J]. 中国铁道科学,2016,37(3):61 − 67. [YANG Bingming,LIU Baoguo. Analysis of long-term settlement of shield tunnel in soft soil area under cyclic loading of subway train[J]. China Railway Science,2016,37(3):61 − 67. (in Chinese with English abstract)] doi: 10.3969/j.issn.1001-4632.2016.03.009
YANG Bingming, LIU Baoguo. Analysis of long-term settlement of shield tunnel in soft soil area under cyclic loading of subway train[J]. China Railway Science, 2016, 37（3）: 61 − 67. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-4632.2016.03.009
[10] 薛阔,王立娜,翟翅飞,等. 地铁列车荷载引起隧道基底长期沉降研究[J]. 三峡大学学报(自然科学版),2018,40(5):47 − 51. [XUE Kuo,WANG Lina,ZHAI Chifei,et al. Analysis of long-term settlement of tunnel foundation induced by metro train load[J]. Journal of China Three Gorges University (Natural Sciences),2018,40(5):47 − 51. (in Chinese with English abstract)]
XUE Kuo, WANG Lina, ZHAI Chifei, et al. Analysis of long-term settlement of tunnel foundation induced by metro train load[J]. Journal of China Three Gorges University （Natural Sciences）, 2018, 40（5）: 47 − 51. （in Chinese with English abstract）
[11] HUANG Qiang,HUANG Hongwei,YE Bin,et al. Dynamic response and long-term settlement of a metro tunnel in saturated clay due to moving train load[J]. Soils and Foundations,2017,57(6):1059 − 1075. doi: 10.1016/j.sandf.2017.08.031
[12] 石钰锋,曹成威,谈亦帆,等. 地铁隧道基底饱水风化软岩动力响应及长期沉降研究[J]. 现代隧道技术,2022,59(2):86 − 95. [SHI Yufeng,CAO Chengwei,TAN Yifan,et al. Study on dynamic response and long-term settlement of water-saturated weathered soft rocks at the base of subway tunnels[J]. Modern Tunnelling Technology,2022,59(2):86 − 95. (in Chinese with English abstract)]
SHI Yufeng, CAO Chengwei, TAN Yifan, et al. Study on dynamic response and long-term settlement of water-saturated weathered soft rocks at the base of subway tunnels[J]. Modern Tunnelling Technology, 2022, 59（2）: 86 − 95. （in Chinese with English abstract）
[13] 王国才,徐启鹏,刘祎阳,等. 地铁列车荷载下软土的动力响应和长期沉降分析[J]. 浙江工业大学学报,2022,50(2):186 − 191. [WANG Guocai,XU Qipeng,LIU Yiyang,et al. Research on the dynamic response and long-term settlement of soft soil under metro loadings[J]. Journal of Zhejiang University of Technology,2022,50(2):186 − 191. (in Chinese with English abstract)] doi: 10.3969/j.issn.1006-4303.2022.02.011
WANG Guocai, XU Qipeng, LIU Yiyang, et al. Research on the dynamic response and long-term settlement of soft soil under metro loadings[J]. Journal of Zhejiang University of Technology, 2022, 50（2）: 186 − 191. （in Chinese with English abstract） doi: 10.3969/j.issn.1006-4303.2022.02.011
[14] 张研沁,狄宏规,徐永刚. 基于机器学习的地铁盾构隧道长期沉降预测[J]. 都市快轨交通,2022,35(3):89 − 94. [ZHANG Yanqin,DI Honggui,XU Yonggang. Machine learning based prediction model for long-term settlement in a metro-shield tunnel[J]. Urban Rapid Rail Transit,2022,35(3):89 − 94. (in Chinese with English abstract)] doi: 10.3969/j.issn.1672-6073.2022.03.014
ZHANG Yanqin, DI Honggui, XU Yonggang. Machine learning based prediction model for long-term settlement in a metro-shield tunnel[J]. Urban Rapid Rail Transit, 2022, 35（3）: 89 − 94. （in Chinese with English abstract） doi: 10.3969/j.issn.1672-6073.2022.03.014
[15] TAN Yong,LI Xiang,KANG Zhijun,et al. Zoned excavation of an oversized pit close to an existing metro line in stiff clay:Case study[J]. Journal of Performance of Constructed Facilities,2015,29(6):10 − 15.
[16] 张书丰,高永,孙泽信. 南京河西地区地铁盾构隧道不均匀沉降分析[J]. 都市快轨交通,2017,30(2):52 − 57. [ZHANG Shufeng,GAO Yong,SUN Zexin. Causes of the uneven settlement of shield metro tunnel in Hexi district of Nanjing[J]. Urban Rapid Rail Transit,2017,30(2):52 − 57. (in Chinese with English abstract)] doi: 10.3969/j.issn.1672-6073.2017.02.011
ZHANG Shufeng, GAO Yong, SUN Zexin. Causes of the uneven settlement of shield metro tunnel in Hexi district of Nanjing[J]. Urban Rapid Rail Transit, 2017, 30（2）: 52 − 57. （in Chinese with English abstract） doi: 10.3969/j.issn.1672-6073.2017.02.011
[17] 史玉金,李明广,吴威,等. 上海地铁4号线隧道长期纵向变形特征分析与安全评估[J]. 隧道建设(中英文),2018,38(增刊1):1 − 6. [SHI Yujin,LI Mingguang,WU Wei,et al. Analysis of characteristics of long-term longitudinal deformation of tunnel on Shanghai metro line No. 4 and its safety evaluation[J]. Tunnel Construction,2018,38(Sup 1):1 − 6. (in Chinese with English abstract)]
SHI Yujin, LI Mingguang, WU Wei, et al. Analysis of characteristics of long-term longitudinal deformation of tunnel on Shanghai metro line No. 4 and its safety evaluation[J]. Tunnel Construction, 2018, 38（Sup 1）: 1 − 6. （in Chinese with English abstract）
[18] 钱晓华,秦文茜,张坤. 地铁振动荷载下小半径曲线段隧道周边土体孔隙水压力响应及沉降研究[J]. 安全与环境工程,2023,30(4):86 − 99. [QIAN Xiaohua,QIN Wenqian,ZHANG Kun. Pore water pressure response and settlement of soil around small-radius curve section of the tunnel under vibration load of subway[J]. Safety and Environmental Engineering,2023,30(4):86 − 99. (in Chinese with English abstract)]
QIAN Xiaohua, QIN Wenqian, ZHANG Kun. Pore water pressure response and settlement of soil around small-radius curve section of the tunnel under vibration load of subway[J]. Safety and Environmental Engineering, 2023, 30（4）: 86 − 99. （in Chinese with English abstract）
[19] 彭红霞,王怀东,袁云辉,等. 列车循环动荷载下地铁四孔交叠隧道长期沉降及控制分析[J]. 城市轨道交通研究,2021,24(10):31 − 35. [PENG Hongxia,WANG Huaidong,YUAN Yunhui,et al. Long-term settlement and control analysis of four-hole overlapping metro tunnel under train cyclic load[J]. Urban Mass Transit,2021,24(10):31 − 35. (in Chinese with English abstract)]
PENG Hongxia, WANG Huaidong, YUAN Yunhui, et al. Long-term settlement and control analysis of four-hole overlapping metro tunnel under train cyclic load[J]. Urban Mass Transit, 2021, 24（10）: 31 − 35. （in Chinese with English abstract）
[20] 马龙祥,靳永福,张超,等. 黏土与粉土复合地层及其中地铁隧道的车致长期沉降[J]. 西南交通大学学报,2022,57(5):1103 − 1112. [MA Longxiang,JIN Yongfu,ZHANG Chao,et al. Long-term settlements of composite stratum of clay and silt and metro tunnel in it due to train operation[J]. Journal of Southwest Jiaotong University,2022,57(5):1103 − 1112. (in Chinese with English abstract)] doi: 10.3969/j.issn.0258-2724.20200685
MA Longxiang, JIN Yongfu, ZHANG Chao, et al. Long-term settlements of composite stratum of clay and silt and metro tunnel in it due to train operation[J]. Journal of Southwest Jiaotong University, 2022, 57（5）: 1103 − 1112. （in Chinese with English abstract） doi: 10.3969/j.issn.0258-2724.20200685
[21] 刘羽航,徐国元,黎伟. 小净距平行地铁隧道下卧土体长期沉降规律研究[J]. 铁道标准设计,2022,66(2):92 − 97. [LIU Yuhang,XU Guoyuan,LI Wei. Study on long-term settlement laws of foundation soil under small-spaced double tunnels[J]. Railway Standard Design,2022,66(2):92 − 97. (in Chinese with English abstract)]
LIU Yuhang, XU Guoyuan, LI Wei. Study on long-term settlement laws of foundation soil under small-spaced double tunnels[J]. Railway Standard Design, 2022, 66（2）: 92 − 97. （in Chinese with English abstract）
[22] 王晓睿,刘旭,张昕,等. 小半径曲线隧道下地铁运行对粉砂土层引起的振动响应规律[J]. 地球科学,2023,48(6):2415 − 2426. [WANG Xiaorui,LIU Xu,ZHANG Xin,et al. Vibration response caused by silt layer in underground subway under small radius curve tunnel[J]. Earth Science,2023,48(6):2415 − 2426. (in Chinese with English abstract)]
WANG Xiaorui, LIU Xu, ZHANG Xin, et al. Vibration response caused by silt layer in underground subway under small radius curve tunnel[J]. Earth Science, 2023, 48（6）: 2415 − 2426. （in Chinese with English abstract）
[23] CHAI Jinchun,MIURA N. Traffic-load-induced permanent deformation of road on soft subsoil[J]. Journal of Geotechnical and Geoenvironmental Engineering,2002,128(11):907 − 916. doi: 10.1061/(ASCE)1090-0241(2002)128:11(907)
[24] 黄凯. 粉土在循环荷载作用下的累积变形研究[D]. 长沙:长沙理工大学,2009. [HUANG Kai. Long-term cumulative deformation of silt induced by repeated loading [D]. Changsha:Changsha University of Science and Technology,2009. (in Chinese with English abstract)]
HUANG Kai. Long-term cumulative deformation of silt induced by repeated loading [D]. Changsha: Changsha University of Science and Technology, 2009. （in Chinese with English abstract）
[25] 潘涛. 软土地区双线区间盾构隧道施工对周边地表以及建筑物沉降的影响[J]. 水文地质工程地质,2022,49(1):101 − 108. [PAN Tao. Influences of double-track shield tunnel construction on settlements of adjacent ground and buildings in a soft soil area[J]. Hydrogeology & Engineering Geology,2022,49(1):101 − 108. (in Chinese with English abstract)]
PAN Tao. Influences of double-track shield tunnel construction on settlements of adjacent ground and buildings in a soft soil area[J]. Hydrogeology & Engineering Geology, 2022, 49（1）: 101 − 108. （in Chinese with English abstract）
[26] 付钊,柯宁静,卢康明,等. 深埋小净距多线平行盾构掘进相互作用分析[J]. 水文地质工程地质,2021,48(2):44 − 54. [FU Zhao,KE Ningjing,LU Kangming,et al. An analysis of interaction of deep buried close approaching multi-line parallel shield tunneling[J]. Hydrogeology & Engineering Geology,2021,48(2):44 − 54. (in Chinese with English abstract)]
FU Zhao, KE Ningjing, LU Kangming, et al. An analysis of interaction of deep buried close approaching multi-line parallel shield tunneling[J]. Hydrogeology & Engineering Geology, 2021, 48（2）: 44 − 54. （in Chinese with English abstract）
[27] 潘昌实,PANDE G N. 黄土隧道列车动荷载响应有限元初步数定分析研究[J]. 土木工程学报,1984,17(4):19 − 28. [PAN Changshi,PANDE G N. Preliminary deterministic finite element study on a tunnel driven in loess subjected t0 train loading[J]. China Civil Engineering Journal,1984,17(4):19 − 28. (in Chinese with English abstract)]
PAN Changshi, PANDE G N. Preliminary deterministic finite element study on a tunnel driven in loess subjected t0 train loading[J]. China Civil Engineering Journal, 1984, 17（4）: 19 − 28. （in Chinese with English abstract）
[28] 徐平,李西峰,张文跃. 近距离垂直交叠地铁盾构隧道的动力响应分析[J]. 地震工程学报,2023,45(5):1008 − 1016. [XU Ping,LI Xifeng,ZHANG Wenyue. Dynamic response analysis of short-distance vertical overlapping subway shield tunnels[J]. China Earthquake Engineering Journal,2023,45(5):1008 − 1016. (in Chinese with English abstract)]
XU Ping, LI Xifeng, ZHANG Wenyue. Dynamic response analysis of short-distance vertical overlapping subway shield tunnels[J]. China Earthquake Engineering Journal, 2023, 45（5）: 1008 − 1016. （in Chinese with English abstract）
[29] 陈国兴,苏晓梅,陈斌. 地铁列车运行引起的环境振动评价[J]. 防灾减灾工程学报,2008,28(1):70 − 74. [CHEN Guoxing,SU Xiaomei,CHEN Bin. Evaluation of ambient vibration induced by passing trains in subway tunnel[J]. Journal of Disaster Prevention and Mitigation Engineering,2008,28(1):70 − 74. (in Chinese with English abstract)] doi: 10.3969/j.issn.1672-2132.2008.01.013
CHEN Guoxing, SU Xiaomei, CHEN Bin. Evaluation of ambient vibration induced by passing trains in subway tunnel[J]. Journal of Disaster Prevention and Mitigation Engineering, 2008, 28（1）: 70 − 74. （in Chinese with English abstract） doi: 10.3969/j.issn.1672-2132.2008.01.013
[30] PECK R B. Deep excavations and tunneling in soft ground[C]//Proceedings of the 7th International Conference on Soil Mechanics and Foundation Engineering. Amsterdam:Elsevier,1969:225 − 290.
[31] 李志萍,刘宇,赵贵章,等. 基于竖管法的轻非水相液体毛细上升特性研究[J]. 水文地质工程地质,2023,50(4):105 − 114. [LI Zhiping,LIU Yu,ZHAO Guizhang,et al. A study of the capillary rise characteristics of LNAPL based on the vertical pipes method[J]. Hydrogeology & Engineering Geology,2023,50(4):105 − 114. (in Chinese with English abstract)]
LI Zhiping, LIU Yu, ZHAO Guizhang, et al. A study of the capillary rise characteristics of LNAPL based on the vertical pipes method[J]. Hydrogeology & Engineering Geology, 2023, 50（4）: 105 − 114. （in Chinese with English abstract）
[32] 胡艳香,朱厚影,陈昊,等. 贺兰山苏峪口泥石流物源启动模型试验分析[J]. 中国地质灾害与防治学报,2022,33(6):44 − 52. [HU Yanxiang,ZHU Houying,CHEN Hao,et al. Model test of debris flow source initiation mechanism in Suyu valley of Helan Mountain[J]. The Chinese Journal of Geological Hazard and Control,2022,33(6):44 − 52. (in Chinese with English abstract)]
HU Yanxiang, ZHU Houying, CHEN Hao, et al. Model test of debris flow source initiation mechanism in Suyu valley of Helan Mountain[J]. The Chinese Journal of Geological Hazard and Control, 2022, 33（6）: 44 − 52. （in Chinese with English abstract）
-
