摘要:
溜砂坡具有突发、不易预测，且产生危害大的特点。文章对拉萨市周边实地调研测量收集数据，采集了12组具有代表性的溜砂坡灾害点数据集合，运用贝叶斯网络与粒子群算法相结合，并利用算法更新公式弥补单一算法的不足，引入信息熵分析了降雨量、坡度、坡高和植被覆盖率在算法中的权重，以及各因素对溜砂坡稳定性的影响，并对溜砂坡的稳定性进行了等级划分，实验证明该方法有效，对溜砂坡稳定性评价具有一定参考价值。
Abstract:Sand slide slope are sudden, unpredictable and has great harm.Through field investigations around Lhasa, 12 representative data sets of sand slide slope disaster points were collected. By combining Bayesian network and Particle Swarm Optimization algorithm, and using algorithm update formula to make up for the short comings of the single algorithm, information entropy was introduced to analyze the weight of rainfall, slope, slope height and vegetation coverage in the algorithm.Then, the influence of various factors on the stability of sand-pass slope is analyzed and the stability of sand-pass slope is graded. Experiments proved that the method is effective and has certain reference value for the stability evaluation of sand slide slope.
-
Key words:
- sliding slope /
- Bayesian network /
- PSO /
- stability evaluation /
- Lhasa City
-
-
表 1 灾害点原始数据
Table 1. Raw date of disaster points
样本a 平均降雨量/mm 坡高/m 坡度/(°) 植被覆盖率/% 灾害点1 488.3 14.0 22.0 12.0 灾害点2 494.4 58.4 36.0 17.0 灾害点3 493.7 58.0 60.0 14.0 灾害点4 487.2 19.0 42.0 11.0 灾害点5 495.0 7.0 27.0 13.0 灾害点6 490.4 92.0 37.2 17.0 灾害点7 492.4 49.0 50.0 12.0 灾害点8 485.6 73.0 45.0 16.0 灾害点9 477.4 22.5 37.0 19.0 灾害点10 493.2 25.5 40.5 12.0 灾害点11 482.3 19.5 28.0 11.0 灾害点12 486.2 92.0 42.0 17.0
下载: 导出CSV
表 2 溜砂坡评价指标等级划分及标准
Table 2. Classification and standardization of evaluation factors of debris slope stability
评价指标 指标分类划分标准(分值)X 0.1～0.2 0.3～0.4 0.5～0.6 0.7～0.8 0.9～1.0 平均降雨量/mm ≤300 300～400 400～500 500～600 ≥600 坡高/m ≤10 10～20 20～30 30～40 ≥40 坡度/(°) ＜20 20～30 30～40 40～50 ≥50 植被覆盖率/% ≥70 70～50 50～30 30～10 ≤10
下载: 导出CSV
表 3 碎屑斜坡稳定性影响因素的信息熵及权重
Table 3. Entropy and weight of evaluation factors of debris slope stability
评价指标 信息熵(EGD) 权重(w) 权重排序 植被覆盖率 0.7526 0.2262 4 坡度 0.6424 0.2647 2 降雨量 0.6352 0.2801 1 坡高 0.7092 0.2290 3
下载: 导出CSV
表 4 灾害点数据处理结果
Table 4. Date processing results of disaster points
BIC值 BIC排序 稳定等级 稳定状态 灾害点1 0.353 4 7 Ⅱ 较稳定 灾害点2 0.408 9 5 Ⅰ 稳定 灾害点3 0.338 6 9 Ⅳ 较不稳定 灾害点4 0.490 4 3 Ⅴ 不稳定 灾害点5 0.340 0 8 Ⅲ 基本稳定 灾害点6 0.682 3 1 Ⅴ 不稳定 灾害点7 0.327 7 10 Ⅴ 不稳定 灾害点8 0.307 7 12 Ⅴ 不稳定 灾害点9 0.375 2 6 Ⅰ 稳定 灾害点10 0.462 1 4 Ⅳ 较不稳定 灾害点11 0.316 6 11 Ⅴ 不稳定 灾害点12 0.675 4 2 Ⅴ 不稳定
下载: 导出CSV
-
[1] 陈自生. DJ 伐恩斯的斜坡移动(广义滑坡)分类方案[C]//滑坡文集, 第九集. 北京: 中国铁道出版社, 1992: 103−109.
CHEN Zisheng. DJ Vans's slope movement (generalized landslide) classification scheme[C]//landslide corpus, ninth episode. Beijing: China Railway Publishing House, 1992: 103−109. (in Chinese)
[2] 张小刚, 杨天军, 陈伟. 藏东南溜砂坡的发育特征与防治[J]. 灾害学,2014,29(1):47 − 51. [ZHANG Xiaogang, YANG Tianjun, CHEN Wei. Development characteristics and prevention of the sand-sliding slope in south-east Tibet[J]. Journal of Catastrophology,2014,29(1):47 − 51. (in Chinese with English abstract)
[3] JAEGER C. The Vajont rock slide[J]. Water Power,1965,17(4):142 − 144.
[4] 范昊天, 孙少锐, 王亚山, 等. 基于离散元的含软弱夹层岩质边坡滑移机理分析[J]. 中国地质灾害与防治学报,2019,30(3):12 − 17. [FAN Haotian, SUN Shaorui, WANG Yashan, et al. Sliding failure mechanism of bedding rock slope with weak intercalated layer based on discrete element method[J]. The Chinese Journal of Geological Hazard and Control,2019,30(3):12 − 17. (in Chinese with English abstract)
[5] 段伟国, 孙世国, 刘玉福. 滑坡预测技术发展概论[J]. 北方工业大学学报,2008,20(1):90 − 94. [DUAN Weiguo, SUN Shiguo, LIU Yufu. Advances and trends of landslide prediction[J]. Journal of North China University of Technology,2008,20(1):90 − 94. (in Chinese with English abstract)
[6] 黄先光. 滑坡稳定系数与安全系数的异同[J]. 兰州交通大学学报,2015,34(6):32 − 37. [HUANG Xianguang. Similarities and differences between stability factor and safety factor of landslide[J]. Journal of Lanzhou Jiaotong University,2015,34(6):32 − 37. (in Chinese with English abstract)
[7] 黄勇. 模糊综合评价法在溜砂坡危险性评价中的应用[C]//西部地区公路学会2013年科技论文集. 北京: 中国公路学会, 2013: 51−56.
HUANG Yong.Application of fuzzy comprehensive evaluation method in risk assessment of sand sliding slope[C]//2013 scientific papers of China western region highway society. Beijing: China Highway Society, 2013: 51−56. (in Chinese with English abstract)
[8] 杨柯, 张军. 层次分析法在溜砂坡危险性评价中的应用[J]. 长春工程学院学报(自然科学版),2012,13(4):82 − 85. [YANG Ke, ZHANG Jun. The application of analytic hierarchy process in sand-sliding slope risk assessment[J]. Journal of Changchun Institute of Technology (Natural Science Edition),2012,13(4):82 − 85. (in Chinese with English abstract)
[9] PEARL J. Fusion, propagation, and structuring in belief networks[J]. Artificial Intelligence,1986,29(3):241 − 288. doi: 10.1016/0004-3702(86)90072-X
[10] AKAIKEH. A new look at the statistical model identification[J]. Automatic Control IEEE Transactions on.
[11] P LARRAÑAGA, POZA M, YURRAMENDI Y, et al. Structure learning of Bayesian Networks by genetic algorithms: A performance analysis of control parameters[J]. IEEE Transactions on Pattern Analysis & Machine Intelligence,1996,18(9):912 − 926.
[12] KENNEDYJ. Particle Swarm Optimization[C]//Icnn95-international Conference on Neural Networks. IEEE, 2002.
[13] MALONEB. Empirical behavior of Bayesian Network structure learning algorithms[C]//Workshop on Advanced Methodologies for Bayesian Networks. Springer, Cham, 2015.
[14] DU T, ZHANG S S, WANG Z. Efficient Learning Bayesian Networks Using PSO[C]//International Conference on Computational Intelligence & Security. Springer Berlin Heidelberg, 2005.
[15] 王耀雷, 周步祥. 基于自适应粒子群算法的直流微网能量优化管理[J]. 现代电力,2017,34(1):37 − 43. [WANG Yaolei, ZHOU Buxiang. Energy management of DC microgrid based on adaptive particle swarm optimization algorithm[J]. Modern Electric Power,2017,34(1):37 − 43. (in Chinese with English abstract)
[16] 康健, 靳斌, 段秀娟, 等. 基于贝叶斯-粒子群算法的微电网优化运行[J]. 电力系统保护与控制,2018,46(12):32 − 41. [KANG Jian, JIN Bin, DUAN Xiujuan, et al. Optimal operation of microgrid based on Bayesian-PSO algorithm[J]. Power System Protection and Control,2018,46(12):32 − 41. (in Chinese with English abstract)
[17] 刘磊, 徐勇, 李远耀, 等. 湘西陈溪峪滑坡变形机理及稳定性评价[J]. 水文地质工程地质,2019,46(2):21 − 28. [LIU Lei, XU Yong, LI Yuanyao, et al. A study of deformation mechanism and stability evaluation of the Chenxiyu landslide in western Hunan[J]. Hydrogeology & Engineering Geology,2019,46(2):21 − 28. (in Chinese with English abstract)
[18] 韩培锋, 王镁河, 姜兆华, 等. 西藏吉隆县地质灾害及其影响因素分析[J]. 中国地质灾害与防治学报,2020,31(2):111 − 118. [HAN Peifeng, WANG Meihe, JIANG Zhaohua, et al. Geological disasters and their influencing factors in Jilong County, Tibet[J]. The Chinese Journal of Geological Hazard and Control,2020,31(2):111 − 118. (in Chinese with English abstract)
[19] 穆成林, 裴向军, 裴钻, 等. 基于岩体结构特征和未确知测度评价模型的岩质开挖边坡稳定性研究[J]. 水文地质工程地质,2019,46(4):150 − 158. [MU Chenglin, PEI Xiangjun, PEI Zuan, et al. A study of the stability of rock excavated slope based on rockmass structure and unascertained measure evaluation models[J]. Hydrogeology & Engineering Geology,2019,46(4):150 − 158. (in Chinese with English abstract)
[20] 罗进. 利用信息熵计算评价指标权重原理及实例[J]. 武汉纺织大学学报,2014,27(6):86 − 89. [LUO Jin. Principles and examples of using information entropy to calculate weight[J]. Journal of Wuhan Textile University,2014,27(6):86 − 89. (in Chinese with English abstract)
[21] 丁继新, 尚彦军, 杨志法, 等. 川藏公路然乌-鲁朗段地质灾害影响因素定量分析[J]. 水文地质工程地质,2005,32(4):1 − 5. [DING Jixin, SHANG Yanjun, YANG Zhifa, et al. Quantitative analysis on the influencing factors of geological hazards in Ranwu-Lulang section of Sichuan-Tibet Highway[J]. Hydrogeology & Engineering Geology,2005,32(4):1 − 5. (in Chinese with English abstract)
[22] 央金卓玛. G318拉萨至尼木段公路地质灾害危险性评价研究[D]. 成都: 西南交通大学, 2017.
YANGJIN Drolma. RISK assessment of geologic hazards along G318road from Lhasa to Nimu[D]. Chengdu: Southwest Jiaotong University, 2017. (in Chinese with English abstract)
[23] 李博文, 靳斌, 李竹, 等. 基于C-FS混合算法的微电网经济调度[J]. 现代电力,2016,33(4):8 − 14. [LI Bowen, JIN Bin, LI Zu, et al. Economic dispatch of microgrid based on C-FS hybrid algorithm[J]. Modern Electric Power,2016,33(4):8 − 14. (in Chinese with English abstract)
[24] 胡晓波, 樊晓一, 唐俊杰. 基于离散元的高速远程滑坡运动堆积特征及能量转化研究—以三溪村滑坡为例[J]. 地质力学学报,2019,25(4):527 − 535. [HU Xiaobo, FAN Xiaoyi, TANG Junjie. Accumulation characteristics and energy conversion of high-speed and long-distance landslide on the basis of DEM: A case study of Sanxicun landslide[J]. Journal of Geomechanics,2019,25(4):527 − 535. (in Chinese with English abstract)
[25] 方然可, 刘艳辉, 苏永超, 等. 于逻辑回归的四川青川县区域滑坡灾害预警模型[J]. 水文地质工程地质,2021,48(1):181 − 187. [FANG Ranke, LIU Yanhui, SU Yongchao, et al. A early warning model of regional landslide in Qingchuan County,Sichuan Province based on logistic regression[J]. Hydrogeology & Engineering Geology,2021,48(1):181 − 187. (in Chinese with English abstract)
[26] 张茂省, 薛强, 贾俊, 等. 山区城镇地质灾害调查与风险评价方法及实践[J]. 西北地质,2019,52(2):125 − 135. [ZHANG Maosheng, XUE Qiang, JIA Jun, et al. Methods and practices for the investigation and risk assessment of geo-hazards in mountainous towns[J]. Northwestern Geology,2019,52(2):125 − 135. (in Chinese with English abstract)
[27] 张茂省. 发挥新型举国体制优势提高地质灾害防治能力[J]. 西北地质,2019,52(2):Ⅰ − Ⅱ. [ZHANG Maosheng. Maximising the advantages of the new national system for improving the ability to prevent and mitigate geological disasters[J]. Northwestern Geology,2019,52(2):Ⅰ − Ⅱ. (in Chinese with English abstract)
[28] 刘畅, 张平松, 杨为民, 等. 税湾地震黄土滑坡的岩土动力特性及其稳定性评价[J]. 西北地质,2020,53(4):176 − 185. [LIU Chang, ZHANG Pingsong, YANG Weimin, et al. eotechnical dynamic characteristics and stability evaluation of loess landslides in Shuiwan Earthquake, Tianshui, Gansu[J]. Northwestern Geology,2020,53(4):176 − 185. (in Chinese with English abstract)
[29] 樊晓一, 张睿骁, 胡晓波. 沟谷地形参数对滑坡运动距离的影响研究[J]. 地质力学学报,2020,26(1):106 − 114. [FAN Xiaoyi, ZHANG Ruixiao, HU Xiaobo. Study on the influence of valley topographic parameter on the moving distance of landslide[J]. Journal of Geomechanics,2020,26(1):106 − 114. (in Chinese with English abstract)
-
