Analysis of development characteristics of high-elevationchain geological hazard in Zelongnong, Nyingchi, Tibet based on high resolution image and InSAR interpretation
-
摘要:
则隆弄沟位于西藏林芝米林县雅鲁藏布江右岸，属于震后影响区，因沟内地形陡峻、物源充足以及水源充沛，1950—2020年期间沟内高位地质灾害活动频繁，沟口村庄和桥梁长期遭受其严重威胁。根据现场调查与无人机航拍，结合多期遥感影像和InSAR数据，对则隆弄沟形成区高风险物源类别、数量以及流通区、堆积区的松散堆积物运动堆积特征进行解译，结果显示:目前则隆弄沟内形成区与流通区陡缓坡交界区域多级多期堆积有大量冰碛物松散物源，流动性较强，区域地质条件、地震活动、气象水文等因素为则隆弄高位链式地质灾害发生提供不稳定的物源结构、良好的临空条件和储藏平台、充足的势动能转换条件以及水动力条件。总结出则隆弄高位地质灾害链形成及演化过程为：高位冰崩（岩崩）-碎屑流-泥石流-堵江堰塞坝（湖）-洪水灾害，其长期具备高易发性和高危险性，后期应加强则隆弄沟高位地质灾害链的监测预警与风险防控。
-
关键词:
- 高位链式地质灾害 /
- 遥感和InSAR解译 /
- 发育特征 /
- 成因机制 /
- 西藏林芝
Abstract:Zelongnong Gully is located on the right bank of YarlungZangbo River in Milin County, Nyingchi, Tibet, which belongs to the post-earthquake affected area. Due to the steep terrain, abundant material sources and abundant water sources in the gully, the high-level geological disasters occurred frequently in the gully during 1950—2020, and the villages and bridges in the gully suffered serious threats for a long time. According to the field investigation and UAV aerial photography, combined with multi-stage remote sensing images and InSAR data, this paper interprets the types and quantity of high-risk sources in the formation area, as well as the movement and accumulation characteristics of loose deposits in the circulation area and accumulation area of Zelongnong Gully. The results show that at present, there are a large amount of glacial moraines of multistage and multi-period accumulation in the interface area between the formation area and the circulation area, and the fluidity is strong. The regional geological conditions, seismicity, meteorology and hydrology and other factors provide unstable source structure, good free space condition and storage platform, sufficient potential energy conversion condition and hydrodynamic condition for the occurrence of Zelongnong high-level chain geological disaster. The formation and evolution process of the high-level geological disaster chain in Zelongnong gully is summarized as follows: high ice collapse (rock collapse) - debris flow - mud-rock flow - blocking river and barrier dam (lake) - flood disaster, which has high vulnerability and high risk in the long term. In the later period, the monitoring, early warning and risk prevention and control of high-level geological disaster chain in Zelongnong Gully should be strengthened.
-
-
表 1 则隆弄沟基本特征
Table 1. Basic characteristics of the Zelongnong Gully
分区 面积/km2 沟长/km 高程范围/m 高差/m 纵坡降/‰ 形成区 31.03 5.95 4000～7782 3782 468 流通区 4.73 4.54 3000～4000 1000 201 堆积区 0.63 1.08 2840～3000 160 153
下载: 导出CSV
表 2 形成区潜在高风险物源类型及参数
Table 2. Types and parameters of potential high risk sources in the formation area
形成区高风险
物源类型分布位置 数量/处
（编号范围）最小物源编号
（面积/km2）最大物源编号
（面积/km2）总面积/km2 最低位物源分布
高程范围/m最高位物源分布
高程范围/m冰崩体 则隆弄沟后缘的南侧壁 6（B1-B6） B6块体(0.034) B2块体（0.26） 0.6 4914～5235 6023～6522 岩崩体 则隆弄沟后缘的南侧壁 13（Y1-Y13） Y6块体(0.021) Y7块体（0.17） 0.96 4615～4899 6775～7051 冰碛物松散堆积体 主沟（南沟）和支沟（北沟）沟底区域 2（BQ1-BQ2） BQ02(1.42) BQ01（2.85） 4.27 3815～4000 4896～4988
下载: 导出CSV
-
[1] 胡桂胜, 陈宁生, 邓明枫, 等. 西藏林芝地区泥石流类型及形成条件分析[J]. 水土保持通报,2011,31(2):193 − 197. [HU Guisheng, CHEN Ningsheng, DENG Mingfeng, et al. Classification and initiation conditions of debris flows in Linzhi Area, Tibet[J]. Bulletin of Soil and Water Conservation,2011,31(2):193 − 197. (in Chinese with English abstract)
[2] 殷跃平, 张永双. 汶川地震工程地质与地质灾害[M]. 北京: 科学出版社, 2013.
YIN Yueping, ZHANG Yongshuang. Engineering geology and geological disasters in Wenchuan earthquake[M]. Beijing: Science Press, 2013. (in Chinese)
[3] 胡桂胜, 陈宁生, 邓虎. 基于GIS的西藏林芝地区泥石流易发与危险区分析[J]. 水土保持研究,2012,19(3):195 − 199. [HU Guisheng, CHEN Ningsheng, DENG Hu. Analysis of debris flow-prone and dangerous area in Nyingchi of Tibet Based on GIS[J]. Bulletin of Soil and Water Conservation,2012,19(3):195 − 199. (in Chinese with English abstract)
[4] 张永双, 成余粮, 姚鑫, 等. 四川汶川地震-滑坡-泥石流灾害链形成演化过程[J]. 地质通报,2013,32(12):1900 − 1910. [ZHANG Yongshuang, CHENG Yuliang, YAO Xin, et al. The evolution process of Wenchuan earthquake-landslide-debris flow geohazard chain[J]. Geologtcal Bulletin of China,2013,32(12):1900 − 1910. (in Chinese with English abstract)
[5] ZHANG Y, CHENG Y, YIN Y, et al. High-position debris flow: A long-term active geohazard after the Wenchuan earthquake[J]. Engineering Geology,2014,180:45 − 54. doi: 10.1016/j.enggeo.2014.05.014
[6] 梁京涛, 成余粮, 王军, 等. 基于无人机遥感技术的汶川震区典型高位泥石流动态监测—以绵竹市文家沟泥石流为例[J]. 中国地质灾害与防治学报,2013,24(3):54 − 61. [LIANG Jingtao, CHENG Yuliang, WANG Jun, et al. Monitoring of a typical high position debris flow dynamic change in Wenchuan earehquake areas with unmanned aerial vehicles case study of Wenjiagou debris flows in Mianzhu county[J]. The Chinese Journal of Geological Hazard and Control,2013,24(3):54 − 61. (in Chinese with English abstract)
[7] 魏昌利, 何元宵, 张瑛, 等. 汶川地震灾区高位泥石流成灾模式分析[J]. 中国地质灾害与防治学报,2013,24(4):52 − 60. [WEI Changli, HE Yuanxiao, ZHANG Ying, et al. Study on high debris flow model in Wenchuan earthquake disaster area[J]. The Chinese Journal of Geological Hazard and Control,2013,24(4):52 − 60. (in Chinese with English abstract)
[8] 张文敬. 南迦巴瓦峰的跃动冰川[J]. 冰川冻土,1983(4):45 − 76. [ZHANG Wenjing. A surging glacier in the Nanjiabawa peak area, Himalayas[J]. Journal of Glaciology and Geocryology,1983(4):45 − 76. (in Chinese with English abstract)
[9] 韩立明. 雅鲁藏布江卧龙至直白河段地质灾害发育特征及危险性评价[D]. 成都: 成都理工大学, 2018.
HAN Liming. Geological hazard characteristics and risk assessment of Brahmaputra from Wolong to Zhibai stream segment[D]. Chengdu: Chengdu University of Technology, 2018. (in Chinese with English abstract)
[10] 中国地质灾害防治工程行业协会. 地质灾害InSAR监测技术指南: T00/CAGHP 013-2017 [S]. 北京: 中国地质大学出版社, 2017.
China Association of Geological Disaster Prevention and Control Engineering. Technical Guide for InSAR monitoring of geological disasters: T00/CAGHP 013-2017 [S]. Beijing: China University of Geosciences Press, 2017. (in Chinese)
[11] 中国地质调查局. 遥感地质解译方法指南(1: 5万、1: 25万): DD 2011-03 [S]. 北京: 地质出版社, 2011.
China Geological Survey. Remote sensing geological interpretation method guide (1: 50000, 1: 250000): DD 2011-03 [S]. Beijing: Geological Publishing House, 2011. (in Chinese)
[12] 丁林, 钟大赉, 潘裕生, 等. 东喜马拉雅构造结上新世以来快速抬升的裂变径迹证据[J]. 科学通报,1995(16):1497 − 1500. [DING Lin, ZHONG Dalai, PAN Yusheng, et al. Fission track evidence for rapid uplift since the Pliocene in the eastern Himalaya tectonic junction[J]. Chinese Science Bulletin,1995(16):1497 − 1500. (in Chinese with English abstract) doi: 10.3321/j.issn:0023-074X.1995.16.018
[13] 刘桂芳, 卢鹤立. 1961~2005年来青藏高原主要气候因子的基本特征[J]. 地理研究,2010,29(12):2281 − 2288. [LIU Guifang, LU Heli. Basic characteristics of major climatic factors on Qinghai-Tibet Plateau in recent 45 years[J]. Geographical Research,2010,29(12):2281 − 2288. (in Chinese with English abstract)
[14] 韩培锋, 王镁河, 姜兆华, 等. 西藏吉隆县地质灾害及其影响因素分析[J]. 中国地质灾害与防治学报,2020,31(2):111 − 118. [HAN Peifeng, WANG Meihe, JIANG Zhaohua, et al. Geological disasters and their influencing factors in Jilong County, Tibet[J]. The Chinese Journal of Geological Hazard and Control,2020,31(2):111 − 118. (in Chinese with English abstract)
[15] 段学良, 马凤山, 郭捷, 等. 基于Massflow模型的西藏仁布杰仲沟泥石流运动特征分析[J]. 中国地质灾害与防治学报,2019,30(6):25 − 33. [DUAN Xueliang, MA Fengshan, GUO Jie, et al. Movement characteristics of Jiezhonggou debris flow of Renbu, Tibet based on massflow model,[J]. The Chinese Journal of Geological Hazard and Control,2019,30(6):25 − 33. (in Chinese with English abstract)
[16] 高波, 张佳佳, 王军朝, 等. 西藏天摩沟泥石流形成机制与成灾特征[J]. 水文地质工程地质,2019,46(5):144 − 153. [GAO Bo, ZHANG Jiajia, WANG Junchao, et al. Formation mechanism and disaster characteristics of debris flow in the Tianmo gully in Tibet[J]. Hydrogeology & Engineering Geology,2019,46(5):144 − 153. (in Chinese with English abstract)
[17] 章旭, 郝红兵, 刘康林, 等. 西藏加查象牙泉水文地球化学特征及成因[J]. 水文地质工程地质,2019,46(4):1 − 9. [ZHANC Xu, HAO Hongbing, LIU Kanglin, et al. Hydrogeochemical characteristics and formation of the Ivory Spring in Jiacha County of Tibet[J]. Hydrogeology & Engineering Geology,2019,46(4):1 − 9. (in Chinese with English abstract)
-
