基于失效概率的边坡降雨阈值曲面探讨

邓夕胜; 张元; 唐煜

doi:10.16031/j.cnki.issn.1003-8035.2021.03-09

基于失效概率的边坡降雨阈值曲面探讨

1.
西南石油大学土木工程与测绘学院，四川成都　610500

2.
中国铁建大桥工程局集团第五工程有限公司，四川成都　610500

基金项目: 国家自然科学基金青年基金项目（51808470）

详细信息

作者简介: 邓夕胜（1977-），男，四川南部人，硕士，副教授，主要从事结构工程与防灾减灾研究。E-mail：dxish@swpu.edu.cn

通讯作者: 张元（1993-），男，四川成都人，土木工程专业，硕士，工程师，主要从事土木工程施工方面的工作。E-mail：djyaizhang@163.com

中图分类号: P642;U213.1+3

收稿日期: 2020-08-09

修回日期: 2020-09-20

刊出日期: 2021-06-25

Investigation on slope rainfall threshold surface based on failure probablolity

1.
School of Civil Engineering and Geomatics, Southwest Petrolcum University, Chengdu, Sichuan　610500, China

2.
China Railway Construction Bridge Engineering Bureau Group 5St Engineering Co. Ltd., Chengdu, Sichuan　610500, China

More Information

Corresponding author: ZHANG Yuan, djyaizhang@163.com

Received Date: 09 August 2020

Revised Date: 20 September 2020

Publish Date: 25 June 2021

摘要

摘要:
降雨是诱发边坡变形失稳的主要因素，而针对降雨型边坡的预警预报也一直是工程领域的核心问题。本文将蒙特卡罗方法引入降雨型滑坡的预警预报，首先基于正态分布的岩土体物理力学参数，建立了边坡的有限元数值计算模型，并分析了9种不同型式降雨下边坡稳定性系数的变化情况。结果显示递增型降雨对边坡的稳定性尤为不利，均匀型降雨次之，递减型降雨影响最小。其次，将降雨过程划分为前期降雨+当期降雨，并确定了前期降雨对于当期降雨的有效时间为6 d。最后，论文结合可靠度理论，选取失效概率P_f=10%作为预警指标，通过把前期降雨引入降雨强度-降雨历时关系曲线并作为第三坐标轴，最终将该曲线扩展成为前期降雨(A)-当期降雨(I)-降雨历时(D)曲面(A-I-D阈值曲面)，研究结果对于降雨型边坡的预警预报具有一定的指导意义。
- 降雨型边坡 /
- 预警预报 /
- 失效概率 /
- 阈值曲面
Abstract:
Rainfall is the main factor inducing slope deformation and instability, and the early warning and prediction of rainfall-triggered landslide has always been the core issue in the field of engineering. In this paper, the Monte Carlo method is introduced into the early warning and prediction of rainfall-triggered landslide. Firstly, based on the physical and mechanical parameters of rock and soil mass with normal distribution, the finite element numerical calculation model of slope is established, and the variation of slope stability coefficient under 9 different types of rainfall is analyzed. The results show that the incremental rainfall is particularly unfavorable to the stability of the slope, the uniform rainfall is the second, and the decreasing rainfallis the least. Secondly, the rainfall process is divided into antecedent and current rainfall, and the effective time of antecedent rainfall for current rainfall is 6 days. Finally, combined with the reliability theory, the failure probability P_f=10% is selected as the early warning index. By introducing the previous rainfall into the rainfall intensity-rainfall duration relation curve and taking it as the third coordinate axis, the curve is finally extended to the antecedent rainfall (A) - current rainfall (I) - rainfall duration (D) surface (A-I-D threshold surface). The research results have acertain guiding significance for the early warning and prediction of rainfall type slope.
- rainfall type slope /
- early warning and prediction /
- failure probability /
- threshold surface

HTML全文

图 1 边坡模型尺寸参数 (单位：m)

Figure 1.

下载: 全尺寸图片幻灯片

图 2 网格剖分图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 黏聚力C、内摩擦角$\varphi $、重度$\gamma $分布曲线

Figure 3.

下载: 全尺寸图片幻灯片

图 4 A-I-D阈值曲面（失效概率P_f=10%）

Figure 4.

下载: 全尺寸图片幻灯片

图 5 A-I-D等值线图（失效概率P_f=10%）

Figure 5.

下载: 全尺寸图片幻灯片

表 1 岩土体物理力学参数

Table 1. Physical and mechanical parameters of rock and soil mass

覆土参数	C/kPa	/ (°)	/ (kN·m⁻³)	/ (m·d⁻¹)
均值	20	22	18	0.65
最小值	15	17	13
最大值	25	27	23

下载: 导出CSV

表 2 不同降雨型式下边坡的稳定性系数变化

Table 2. Variation of slope stability coefficient under different rainfall types

降雨类型	初始稳定性系数	非均匀降雨稳定性系数	均匀降雨稳定性系数
直线递增	1.091	1.021	1.038
正弦递增	1.091	1.024	1.038
余弦递增	1.091	1.015	1.038
圆弧递增	1.091	1.020	1.038
直线递减	1.091	1.052	1.038
正弦递减	1.091	1.056	1.038
余弦递减	1.091	1.048	1.038
圆弧递减	1.091	1.059	1.038

下载: 导出CSV

参考文献(21)

[1]	冯雪莲. 基于光纤应力传感的斜倾厚层山体滑坡预警研究[J]. 灾害学,2020,35(2):13 − 17. [FENG Xuelian. Study on early warning of landslide in inclined thick layer based on fiber optic stress sensing[J]. Journal of Catastrophology,2020,35(2):13 − 17. (in Chinese with English abstract)
[2]	陈忠源, 戴自航. 降雨条件下建筑边坡稳定性的云模型评价方法[J]. 中国地质灾害与防治学报,2020,31(2):50 − 56. [CHEN Zhongyuan, DAI Zihang. Cloud model evaluation method for building slope stability under rainfall[J]. Chinese Journal of geological hazards and prevention,2020,31(2):50 − 56. (in Chinese with English abstract)
[3]	雷德鑫. 三峡库区王家坡滑坡降雨阈值及预警预报研究[D]. 宜昌: 三峡大学, 2019. LEI Dexin. Study on rainfall threshold and early warning and prediction of Wangjiapo landslide in Three Gorges Reservoir Area[D]. Yichang: Three Gorges University, 2019. (in Chinese)
[4]	CAINE N. The rainfall intensity: Duration control of shallow landslides and debris flows[J]. Geografiska Annaler. Series A, Physical Geography,1980,62(1-2):23 − 27. doi: 10.1080/04353676.1980.11879996
[5]	盛逸凡, 李远耀, 徐勇, 等. 基于有效降雨强度和逻辑回归的降雨型滑坡预测模型[J]. 水文地质工程地质,2019,46(1):156 − 162. [SHENG Yifan, LI yuanyao, XU Yong, et al. Prediction of rainfall-type landslides based on effective rainfall intensity and logistic regression[J]. Hydrogeology & Engineering Geology,2019,46(1):156 − 162. (in Chinese with English abstract)
[6]	李媛. 区域降雨型滑坡预报预警方法研究[D]. 北京: 中国地质大学(北京), 2005. LI Yuan. Method for the warning of precipitation-induced landslides[D]. Beijing: China University of Geosciences (Beijing), 2005. (in Chinese)
[7]	李秀珍, 何思明, 王震宇, 等. 降雨入渗诱发斜坡失稳的物理模型适用性分析[J]. 灾害学,2015,30(1):34 − 38. [LI Xiuzhen, HE Siming, WANG Zhenyu, et al. Applicability analysis on physical models of slope instability induced by rainfall infiltration[J]. Journal of Catastrophology,2015,30(1):34 − 38. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-811X.2015.01.008
[8]	MONTRASIO L, VALENTINO R. A model for triggering mechanisms of shallow landslides[J]. Natural Hazards and Earth System Sciences,2008,8(5):1149 − 1159. doi: 10.5194/nhess-8-1149-2008
[9]	IVERSON R M. Landslide triggering by rain infiltration[J]. Water Resources Research,2000:36.
[10]	MONTGOMERY D R, DIETRICH W E, TORRES R, et al. Hydrologic response of a steep, unchanneled valley to natural and applied rainfall[J]. Water Resources Research,1997,33(1):91 − 109. doi: 10.1029/96WR02985
[11]	沈佳, 董岩松, 简文彬, 等. 台风暴雨型土质滑坡演化过程研究[J]. 工程地质学报,2020,28(6):1290-1299. SHEN Jia, DONG Yansong, JIAN Wenbin, et al. Study on evolution process of landslides triggered by typhoon rainstorm[J]. Journal of engineering geology,2020,28(6):1290-1299.（in Chinese with English abstract）
[12]	刘春, 范宣梅, 朱晨光, 等. 三维大规模滑坡离散元建模与模拟研究—以茂县新磨村滑坡为例[J]. 工程地质学报,2019,27(6):1362 − 1370. [LIU Chun, FAN Xuanmei, ZHU Chenguang, et al. Discrete element modeling and simulation of 3-dimen-sional large-scale landslide-taking xinmocun landslide as an example[J]. Journal of Engineering Geology,2019,27(6):1362 − 1370. (in Chinese with English abstract)
[13]	雷德鑫, 易武, 柳青, 等. 三峡库区卧沙溪滑坡稳定性的可靠度及敏感性分析[J]. 安全与环境工,2018,25(1):23 − 28. [LEI Dexin, YI Wu, LIU Qing, et al. Reliability and sensitivity analysis of Woshaxi landslide stability in Three Gorges Reservoir Area[J]. Safety and Environmental Engineering,2018,25(1):23 − 28. (in Chinese with English abstract)
[14]	郭重阳, 李典庆, 曹子君, 等. 考虑空间变异性条件下的边坡稳定可靠度高效敏感性分析[J]. 岩土力学,2018,39(6):2203 − 2210. [GUO Chongyang, LI Dianqing, CAO Zijun, et al. Efficient reliability sensitivity analysis for slope stability in spatially variable soils[J]. Rock and Soil Mechanics,2018,39(6):2203 − 2210. (in Chinese with English abstract)
[15]	杨攀. 基于力学模型的非饱和土边坡滑坡预警降雨阈值研究[D]. 北京: 清华大学, 2014. YANG Pan. Research on rainfall thresholds for forecasting unsaturated soil slope failure based on mechanical model[D]. Beijing: Tsinghua University, 2014. (in Chinese with English abstract)
[16]	黄晓虎, 雷德鑫, 夏俊宝, 等. 降雨诱发滑坡阶跃型变形的预测分析及应用[J]. 岩土力学,2019,40(9):3585 − 3592. [HUANG Xiaohu, LEI Dexin, XIA Junbao, et al. Forecast analysis and application of stepwise deformation of landslide induced by rainfall[J]. Rock and Soil Mechanics,2019,40(9):3585 − 3592. (in Chinese with English abstract)
[17]	杨攀, 杨军. 考虑前期降雨的边坡稳定降雨阈值曲面[J]. 岩土力学,2015,36(增刊1):169 − 174. [YANG Pan, YANG Jun. Rainfall threshold surface for slopes stability considering antecedent rainfall[J]. Rock and Soil Mechanics,2015,36(Sup1):169 − 174. (in Chinese with English abstract)
[18]	郭斌, 贾燕, 梁彧, 等. 四川宝轮服务区降雨型滑坡活动过程分析[J]. 中国地质灾害与防治学报,2020,31(4):45 − 51. [GUO Bin, JIA Yan, LIANG Yu, et al. Analysis on process of rainfall-induced landslide in Baolun service area, Sichuan Province[J]. The Chinese Joumal of Geological Hazard and Control,2020,31(4):45 − 51. (in Chinese with English abstract)
[19]	饶鸿, 王金淑, 赵志明, 等. 基于有限元软件自定义本构模型的膨胀土边坡降雨入渗分析[J]. 水文地质工程地质,2021,48(1):154 − 162. [RAO Hong, WANG Jinshu, ZHAO Zhiming, et al. An analysis of rainfall infiltration of expansive soil slope based on the finite element software custom constitutive model[J]. Hydrogeology & Engineering Geology,2021,48(1):154 − 162. (in Chinese with English abstract)
[20]	邬凯, 杨雪莲, 王军. 山区公路降雨型滑坡区域预警研究[J]. 公路工程,2018,43(6):127 − 133. [WU Kai, YANG Xuelian, WANG Jun. Research on regional warning of rainfall induced landslides[J]. Highway Engineering,2018,43(6):127 − 133. (in Chinese with English abstract)
[21]	王志强, 马晓亮. 持续降雨环境下高速公路边坡稳定性影响的数值模拟分析[J]. 公路工程,2018,43(5):310 − 315. [WANG Zhiqiang, MA Xiaoliang. Numerical simulation analysis on the stability of highway slope under continuous rainfall environment[J]. Highway Engineering,2018,43(5):310 − 315. (in Chinese with English abstract)
